四冲程 电喷 EFI · USA - Cat.# 90-8M0103726 · 共 39 个部位 · 1616 条零件
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 892440A08 | 动力转向泵套件 | PUMP KIT Power Steering Pump Kit | 1 |
| - | 8M0131262 | 动力转向泵套件(12英尺) | PUMP KIT Power Steering (12 Feet) | 1 |
| - | 892440A09 | 动力转向泵套件 | PUMP KIT Power Steering Pump Kit | 1 |
| - | 8M0131263 | 动力转向泵套件(24英尺) | PUMP KIT Power Steering (24 Feet) | 1 |
| - | 892380A02 | 标准转向舵机套件(40cc) | STEERING HELM KIT Standard (40 cc) | 1 |
| - | 8M0240080 | 标准舵机套件40CM | HELM KIT-STD 40CM | 1 |
| - | 892557A02 | 标准转向舵机套件(32cc) | STEERING HELM KIT Standard (32 cc) | 1 |
| - | 8M0240079 | 标准舵机套件32CM | HELM KIT-STD 32CM | 1 |
| - | 892558A02 | 标准转向舵机套件(50cc) | STEERING HELM KIT Standard (50 cc) | 1 |
| - | 8M0240081 | 标准舵机套件50CM | HELM KIT-STD 50CM | 1 |
| - | 892450K01 | 液压软管套件(1英尺)油缸至舵机 | HOSE KIT (1 Foot) Hydraulic, Cylinder to Helm | 1 |
| - | 897982K01 | ORD 32-897982K02 | ORD 32-897982K02 | 1 |
| - | 892450K02 | 液压软管套件(2英尺)油缸至舵机 | HOSE KIT (2 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167281 | 软管套件2FT | HOSE KIT 2FT | 1 |
| - | 892450K03 | 液压软管套件(3英尺)油缸至舵机 | HOSE KIT (3 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167282 | 软管套件3FT | HOSE KIT 3 FT | 1 |
| - | 892450K04 | 液压软管套件(4英尺)油缸至舵机 | HOSE KIT (4 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167283 | 软管套件4FT | HOSE KIT 4 FT | 1 |
| - | 892450K05 | 液压软管套件(5英尺)油缸至舵机 | HOSE KIT (5 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167284 | 软管套件5FT | HOSE KIT 5 FT | 1 |
| - | 892450K06 | 液压软管套件(6英尺)油缸至舵机 | HOSE KIT (6 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167285 | 软管套件6FT | HOSE KIT 6 FT | 1 |
| - | 892450K07 | 液压软管套件(7英尺)油缸至舵机 | HOSE KIT (7 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167286 | 软管套件7FT | HOSE KIT 7 FT | 1 |
| - | 892450K08 | 液压软管套件(8英尺)油缸至舵机 | HOSE KIT (8 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167287 | 软管套件8FT | HOSE KIT 8 FT | 1 |
| - | 892450K10 | 液压软管套件(10英尺)油缸至舵机 | HOSE KIT (10 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167288 | 软管套件10FT | HOSE KIT 10 FT | 1 |
| - | 892450K12 | 液压软管套件(12英尺)油缸至舵机 | HOSE KIT (12 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167289 | 软管套件12FT | HOSE KIT 12 FT | 1 |
| - | 892450K14 | 液压软管套件(14英尺)油缸至舵机 | HOSE KIT (14 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167290 | 软管套件 14英尺 | HOSE KIT 14 FT | 1 |
| - | 892450K16 | 液压软管套件(16英尺)油缸至舵机 | HOSE KIT (16 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167291 | 软管套件 16英尺 | HOSE KIT 16 FT | 1 |
| - | 892450K18 | 液压软管套件(18英尺)油缸至舵机 | HOSE KIT (18 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167292 | 软管套件 18英尺 | HOSE KIT 18 FT | 1 |
| - | 892450K22 | 液压软管套件(22英尺)油缸至舵机 | HOSE KIT (22 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167294 | 软管套件 22英尺 | HOSE KIT 22 FT | 1 |
| - | 892450K24 | 液压软管套件(24英尺)油缸至舵机 | HOSE KIT (24 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167295 | 软管套件 24英尺 | HOSE KIT 24 FT | 1 |
| - | 892450K26 | 液压软管套件(26英尺)油缸至舵机 | HOSE KIT (26 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167296 | 软管套件 26英尺 | HOSE KIT 26 FT | 1 |
| - | 892450K30 | 液压软管套件(30英尺)油缸至舵机 | HOSE KIT (30 Feet) Hydraulic, Cylinder to Helm | 1 |
| - | 8M0167298 | 软管套件 30英尺 | HOSE KIT 30 FT | 1 |
| - | 892438K02 | 动力转向软管套件 动力模块 (2英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (2 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150604 | 泵至舱壁/舵机套件 2英尺 | PUMP TO BULKHEAD/HELM KIT 2 Ft | 1 |
| - | 892438K03 | 动力转向软管套件 动力模块 (3英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (3 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150605 | 泵至舱壁/舵机套件 3英尺 | PUMP TO BULKHEAD/HELM KIT 3 Ft | 1 |
| - | 892438K04 | 动力转向软管套件 动力模块 (4英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (4 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150606 | 泵至舱壁/舵机套件 4英尺 | PUMP TO BULKHEAD/HELM KIT 4 Ft | 1 |
| - | 892438K05 | 动力转向软管套件 动力模块 (5英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (5 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150607 | 泵至舱壁/舵机套件 5英尺 | PUMP TO BULKHEAD/HELM KIT 5 Ft | 1 |
| - | 892438K06 | 软管套件 动力模块 (6英尺) 液压, 泵至舵机 | HOSE KIT Power Module (6 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150608 | 泵至舱壁/舵机套件 6英尺 | PUMP TO BULKHEAD/HELM KIT 6 Ft | 1 |
| - | 892438K07 | 软管套件 动力模块 (7英尺) 液压, 泵至舵机 | HOSE KIT Power Module (7 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150610 | 泵至舱壁/舵机套件 7英尺 | PUMP TO BULKHEAD/HELM KIT 7 Ft | 1 |
| - | 892438K08 | 软管套件 动力模块 (8英尺) 液压, 泵至舵机 | HOSE KIT Power Module (8 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150612 | 泵至舱壁/舵机套件 8英尺 | PUMP TO BULKHEAD/HELM KIT 8 Ft | 1 |
| - | 892438K10 | 动力转向软管套件 动力模块 (10英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (10 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150613 | 泵至舱壁/舵机套件 10英尺 | PUMP TO BULKHEAD/HELM KIT 10 Ft | 1 |
| - | 892438K12 | 动力转向软管套件 动力模块 (12英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (12 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150614 | 泵至舱壁/舵机套件 12英尺 | PUMP TO BULKHEAD/HELM KIT 12 Ft | 1 |
| - | 892438K14 | 动力转向软管套件 动力模块 (14英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (14 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150615 | 泵至舱壁/舵机套件 14英尺 | PUMP TO BULKHEAD/HELM KIT 14 Ft | 1 |
| - | 892438K16 | 动力转向软管套件 动力模块 (16英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (16 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150616 | 泵至舱壁/舵机套件 16英尺 | PUMP TO BULKHEAD/HELM KIT 16 Ft | 1 |
| - | 892438K18 | 动力转向软管套件 动力模块 (18英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (18 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150617 | 泵至舱壁/舵机套件 18英尺 | PUMP TO BULKHEAD/HELM KIT 18 Ft | 1 |
| - | 892438K20 | 动力转向软管套件 动力模块 (20英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (20 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150618 | 泵至舱壁/舵机套件 20英尺 | PUMP TO BULKHEAD/HELM KIT 20 ft | 1 |
| - | 892438K22 | 动力转向软管套件 动力模块 (22英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (22 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150619 | 泵至舱壁/舵机套件 22英尺 | PUMP TO BULKHEAD/HELM KIT 22 FT | 1 |
| - | 892438K24 | 动力转向软管套件 动力模块 (24英尺) 液压, 泵至舵机 | POWER STEERING HOSE KIT Power Module (24 Feet) Hydraulic, Pump to Helm | 1 |
| - | 8M0150620 | 泵至舱壁/舵机套件 24英尺 | PUMP TO BULKHEAD/HELM KIT 24 FT | 1 |
| - | 892825008 | 液压软管 (8英尺) 舵机至压力罐 | HOSE (8 Feet) Hydraulic, Helm to Pressure Tank | 1 |
| - | 892825010 | 液压软管 (10英尺) 舵机至压力罐 | HOSE (10 Feet) Hydraulic, Helm to Pressure Tank | 1 |
| - | 892825012 | 液压软管 (12英尺) 舵机至压力罐 | HOSE (12 Feet) Hydraulic, Helm to Pressure Tank | 1 |
| - | 892825014 | 液压软管 (14英尺) 舵机至压力罐 | HOSE (14 Feet) Hydraulic, Helm to Pressure Tank | 1 |
| - | 892825016 | 液压软管 (16英尺) 舵机至压力罐 | HOSE (16 Feet) Hydraulic, Helm to Pressure Tank | 1 |
| - | 892825018 | 液压软管 (18英尺) 舵机至压力罐 | HOSE (18 Feet) Hydraulic, Helm to Pressure Tank | 1 |
| - | 892825020 | 液压软管 (20英尺) 舵机至压力罐 | HOSE (20 Feet) Hydraulic, Helm to Pressure Tank | 1 |
| - | 892825022 | 液压软管 (22英尺) 舵机至压力罐 | HOSE (22 Feet) Hydraulic, Helm to Pressure Tank | 1 |
| - | 892825024 | 液压软管 (24英尺) 舵机至压力罐 | HOSE (24 Feet) Hydraulic, Helm to Pressure Tank | 1 |
| - | 892825026 | 液压软管 (26英尺) 舵机至压力罐 | HOSE (26 Feet) Hydraulic, Helm to Pressure Tank | 1 |
| - | 893395A01 | 嵌入式安装板 | PLATE Flush Mount | 1 |
| - | 875207 | 三通接头 | TEE Fitting | 1 |
| - | 892486K08 | 模拟转换套件 | CONVERSION KIT Analog | 1 |
| - | 889611K02 | 附件电源线束套件(30英尺) | HARNESS KIT Accessory Power (30 Feet) | 1 |
| - | 899785K04 | 附件电源线束总成(30英尺) | HARNESS ASSEMBLY Accessory Power (30 Feet) | 1 |
| - | 88334A2 | 防腐电极套件 | MERCATHODE KIT | 1 |
| - | 8M0180081 | 防腐电极套件 | MERCATHODE KIT | 1 |
| - | 825191A03 | 索具软管套件 | HOSE KIT Rigging | 1 |
| - | 880717A01 | 齿轮箱螺丝/密封套件 | SCREW/SEAL KIT Gearcase | 1 |
| - | 88439A50 | 电池电缆组 | CABLE SET Battery | 1 |
| - | 8M0210761 | 电池电缆组(12英尺) | CABLE SET (12 ft) Battery | 1 |
| - | 44357Q2 | 冲洗附件 | FLUSHING ATTACHMENT | 1 |
| - | 44357T2 | 冲洗附件 | FLUSHING ATTACHMENT | 1 |
| - | 881150Q1 | 双进水口冲洗套件 | FLUSH KIT Dual Water Pick Up | 1 |
| - | 881150K1 | 双进水口冲洗密封套件 | SEAL KIT Flush - Dual Water Pickup | 1 |
| - | 897967100 | 燃油管路 (100.00英尺) | LINE Fuel (100.00 Feet) | 1 |
| - | 8M0038563 | 燃油管路 (100.00英尺) | LINE Fuel (100.00 Feet) | 1 |
| - | 899712A01 | 连续性电缆套件 | CABLE KIT Continuity | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 887623T03 | 机油收集器总成 | PICKUP ASSEMBLY Oil | 1 |
| 2 | 846594 | O型圈 (1.239 x .070) 黑色 | O-RING (1.239 x .070) Black | 1 |
| 2 | 8M0092943 | O型圈 橙色 | O-RING Orange | 1 |
| 3 | 88552525 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 3 |
| 3 | 8M0103807 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 3 |
| 4 | 889618001 | 衬垫 油底壳 | GASKET Oil Sump | 1 |
| 5 | 880626T01 | 排气管总成 | TUBE ASSEMBLY Exhaust | 1 |
| 6 | 88552635 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 6 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 7 | 880629 | 排气管密封件 | SEAL Exhaust Tube | 1 |
| 8 | 880639T | 油底壳总成 | SUMP ASSEMBLY Oil | 1 |
| 9 | 88552530 | 螺丝(M6×30毫米)不锈钢 | SCREW (M6 x 30 mm) Stainless Steel | 12 |
| 9 | 8M0103808 | 螺丝(M6×30毫米)不锈钢 | SCREW (M6 x 30 mm) Stainless Steel | 12 |
| 10 | 887753A02 | 排油管总成 | TUBE ASSEMBLY Oil Drain | 1 |
| 10 | 888513A02 | 排油管总成 | TUBE ASSEMBLY Oil Drain | 1 |
| 10 | 8M0082193 | 排油管总成 | TUBE ASSEMBLY Oil Drain | 1 |
| 11 | 892446 | O型圈(14×1.78毫米) | O-RING (14 X 1.78 MM) | 2 |
| 12 | 892228 | 定位销 | PIN Dowel | 1 |
| 13 | 888592005 | 放油塞总成 | PLUG ASSEMBLY Oil Drain | 1 |
| 14 | 888593 | 放油螺塞密封件 | SEAL Drain Plug | 1 |
| 14 | 8M0188614 | 放油螺塞密封件 | SEAL Drain Plug | 1 |
| 15 | 88552530 | 螺丝(M6×30毫米)不锈钢 | SCREW (M6 x 30 mm) Stainless Steel | 1 |
| 15 | 8M0103808 | 螺丝(M6×30毫米)不锈钢 | SCREW (M6 x 30 mm) Stainless Steel | 1 |
| 16 | 885541A01 | 水管总成 (20.00英寸) | TUBE ASSEMBLY Water (20.00 Inch) | 1 |
| 16 | 885541A02 | 水管总成 (25.00英寸) | TUBE ASSEMBLY Water (25.00 Inch) | 1 |
| 16 | 885541A03 | 水管总成 (30.00英寸) | TUBE ASSEMBLY Water (30.00 Inch) | 1 |
| 17 | 892445 | O型圈 | O-RING | 1 |
| 18 | 887987A1 | 联轴器 | COUPLING | 1 |
| 18 | 8M0214983 | 联轴器总成 | COUPLING ASSY | 1 |
| 19 | 90196 | O型圈 (.921 x .139) | O-RING (.921 x .139) | 1 |
| 19 | 8M0204673 | O型圈 .921 x .139 | O-Ring .921 x .139 | 1 |
| 20 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 20 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 21 | 888913A01 | 提升阀总成 | POPPET ASSEMBLY | 1 |
| 21 | 8M0114707 | 提升阀总成 | POPPET VALVE ASSY | 1 |
| 22 | 64878 | 弹簧(黑色) | SPRING (Black) | 1 |
| 23 | 893385001 | 固定座 | RETAINER | 1 |
| 24 | 648771 | 隔膜 | DIAPHRAGM | 1 |
| 25 | 889706 | 垫圈 | WASHER | 1 |
| 26 | 69570 | 螺钉(#10-16 x .750) | SCREW (#10-16 x .750) | 1 |
| 27 | 893384001 | 提升阀盖 | COVER Poppet | 1 |
| 28 | 889561 | 提升阀垫片 | GASKET Poppet | 1 |
| 29 | 88552535 | 不锈钢螺钉(M6×35mm) | SCREW (M6 x 35 mm) Stainless Steel | 2 |
| - | 880552A06 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 880552A07 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 895247A06 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 895247R06 | RM L6 GEN1 VERADO | RM L6 GEN1 VERADO | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 884474001 | 定位销 (12毫米) | PIN Dowel (12 mm) | 1 |
| 2 | 888819002 | 排水罩 | DRAIN Cowl | 2 |
| 3 | 888461A01 | 配件套件 | FITTING KIT | 1 |
| 4 | 892446 | O型圈(14×1.78毫米) | O-RING (14 X 1.78 MM) | 2 |
| 5 | 88552512 | 不锈钢螺钉 (M6 x 12 mm) | SCREW (M6 x 12 mm) Stainless Steel | 1 |
| 5 | 8M0103804 | 不锈钢螺钉 (M6 x 12 mm) | SCREW (M6 x 12 MM) Stainless Steel | 1 |
| 6 | 4002316 | 垫圈(6.60 X 17.0 X 1.5不锈钢) | WASHER (6.60 X 17.0 X 1.5SS) | 1 |
| 6 | 8M0214930 | 垫圈6.60 x 17.0 x 1.5 | WASHER 6.60 x 17.0 x 1.5 | 1 |
| 7 | 889792A01 | 怠速排气接头套件 | FITTING KIT Idle Exhaust | 1 |
| 8 | 889828 | O型圈 0.924×0.103 | O-RING (.924 x .103) | 1 |
| 9 | 88552512 | 不锈钢螺钉 (M6 x 12 mm) | SCREW (M6 x 12 mm) Stainless Steel | 1 |
| 9 | 8M0103804 | 不锈钢螺钉 (M6 x 12 mm) | SCREW (M6 x 12 MM) Stainless Steel | 1 |
| 10 | 889846 | 接头 | FITTING | 1 |
| 11 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 2 |
| 12 | 888981001 | 怠速排气软管 | HOSE Idle Exhaust | 1 |
| 13 | 892384T | 排气集气室 | PLENUM Exhaust | 1 |
| 14 | 4006731 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 15 | 88238A21 | 拉线总成 | CABLE ASSEMBLY | 1 |
| 16 | 40011126 | 不锈钢螺丝(M6 x 13) | SCREW (M6 x 13) Stainless Steel | 1 |
| 17 | 884548 | 歧管参考软管-下部 | HOSE Manifold Reference-Lower | 1 |
| 17 | 8M0087120 | 软管 | HOSE | 1 |
| 18 | 884546 | 护孔环 | GROMMET | 1 |
| 19 | 888523001 | 卡扣 | CLIP | 2 |
| 20 | 884547 | 进水软管-下部 | HOSE Water In-Lower | 1 |
| 20 | 8M0087106 | 软管 | HOSE | 1 |
| 21 | 884546 | 护孔环 | GROMMET | 1 |
| 22 | 892241 | 燃油供应模块输出软管 | HOSE Fuel Supply Module-Out | 1 |
| 22 | 8M0087116 | 软管 | HOSE | 1 |
| 23 | 884546 | 护孔环 | GROMMET | 1 |
| 24 | 815504104 | 蜗杆卡箍 | CLAMP Worm Gear | 3 |
| 25 | 830757130 | 管材 (.312) (70.00英寸整卷) 裁切至21英寸 | TUBING (.312) (70.00 Inches Bulk) Cut to 21 Inches | 1 |
| 25 | 8M0108349 | 软管 (70英寸散装) | HOSE (70 Inches Bulk) | 1 |
| 26 | 892562T01 | 歧管壳体 | HOUSING Manifold | 1 |
| 27 | 892117 | 密封件 | SEAL | 1 |
| 28 | 88552516 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 4 |
| 28 | 8M0103805 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 4 |
| 29 | 887756 | 进水软管-上部 | HOSE Water In-Upper | 1 |
| 30 | 887757 | 高压过滤器软管 | HOSE Hi-Pressure Filter | 1 |
| 30 | 8M0203762 | 燃油管路总成 | FUEL LINE ASSY | 1 |
| 31 | 879885T | 燃油滤清器 | FILTER Fuel | 1 |
| 31 | 879885Q | 燃油管路滤清器 | FILTER Fuel In-Line | 1 |
| 32 | 887758 | 高压滤清器至燃油轨软管 | HOSE Hi-Pressure Filter To Fuel Rail | 1 |
| 32 | 8M0203763 | 燃油管 | FUEL LINE | 1 |
| - | 880552A06 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 880552A07 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 895247A06 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 895247R06 | RM L6 GEN1 VERADO | RM L6 GEN1 VERADO | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 892940T | 70安培发电机 | ALTERNATOR 70 Ampere | 1 |
| 1 | 892940T02 | 交流发电机 | ALTERNATOR | 1 |
| 2 | 885349T05 | 皮带张紧器 | BELT TENSIONER | 1 |
| 2 | 8M0101707 | 皮带张紧器 | BELT TENSIONER | 1 |
| 3 | 885349500 | 滑轮 | PULLEY | 1 |
| 3 | 8M6003035 | 滑轮 | PULLEY | 1 |
| 4 | 885349501 | 螺钉 | SCREW | 1 |
| 5 | 855729 | 支架 | MOUNT | 4 |
| 6 | 845998 | 垫圈(0.406×1.250×0.089) | WASHER (.406 x 1.250 x .089) | 8 |
| 7 | 88552745 | 螺丝(M10 x 45) | SCREW (M10 x 45) | 5 |
| 7 | 8M0103823 | 六角法兰螺钉(M10×45) | SCREW (M10 x 45 Hex Flange) | 5 |
| 8 | 88535303S | 支架 | BRACKET | 1 |
| 8 | 8M0219204 | 支架 | BRACKET | 1 |
| 9 | 888517 | 销 | PIN | 1 |
| 10 | 880566014 | 驱动皮带 | BELT Drive | 1 |
| 10 | 8M0232583 | 蛇形皮带 | BELT SERPENTINE | 1 |
| 11 | 88552785 | 螺钉(M10×85) | SCREW (M10 x 85) | 1 |
| 11 | 8M0103824 | 螺钉 | SCREW | 1 |
| 12 | 4002319 | 垫圈 | WASHER | 1 |
| 13 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 14 | 856583A09 | 拉线总成 | CABLE ASSEMBLY | 1 |
| 14 | 856583A12 | 拉线总成 | CABLE ASSEMBLY | 1 |
| 15 | 858414A04 | 铜编织电缆总成 | CABLE ASSEMBLY Brass Braided | 1 |
| 16 | 88552516 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 2 |
| 16 | 8M0103805 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 2 |
| 17 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 1 |
| 17 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 1 |
| 18 | 828991 | 卡扣 | CLIP | 3 |
| 18 | 828991T | 卡扣 | CLIP | 3 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0092408 | 集成空气燃油模块总成 | MODULE ASSEMBLY Integrated Air Fuel | 1 |
| 1 | 8M0092462 | 中冷器总成 | CAC ASSEMBLY | 1 |
| 1 | 8M0132388 | 中冷器总成 | CAC ASSEMBLY | 1 |
| 2 | 8M0048079 | 8毫米塞 | PLUG 8MM | 1 |
| 3 | 8M0046698 | 端盖总成 | END CAP ASSEMBLY | 2 |
| 4 | 8M0039516 | O型圈 | O-RING | 1 |
| 5 | 8M0039464 | 挡圈 | RING Retaining | 1 |
| 6 | 8M0040116 | O型圈 | O-RING | 1 |
| 7 | 8M0039993 | 接头 | FITTING | 1 |
| 8 | 8M0083678 | 进气歧管总成 | MANIFOLD ASSEMBLY Intake | 1 |
| 9 | 895019 | 歧管至CAC密封件 | SEAL Manifold to CAC | 1 |
| 10 | 895020 | 歧管头部密封件 | SEAL Manifold Head | 6 |
| 11 | 891663001 | 温度传感器 | SENSOR Temperature | 1 |
| 12 | 8M0041480 | 螺钉 | SCREW | 2 |
| 12 | 895054 | 螺丝(M4×16毫米) | SCREW (M4 x 16 mm) | 2 |
| 13 | 892317001 | O型圈 | O-RING | 1 |
| 14 | 88552516 | 螺钉（M6×16毫米）不锈钢燃油轨至歧管 | SCREW (M6 x 16 mm) Stainless Steel Fuel Rail to Manifold | 3 |
| 14 | 8M0103805 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 3 |
| 14 | 88552516 | 螺钉（M6×16毫米）不锈钢CAC至歧管 | SCREW (M6 x 16 mm) Stainless Steel CAC to Manifold | 2 |
| 14 | 8M0103805 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 2 |
| 15 | 88552525 | 螺钉（M6×25毫米）不锈钢歧管至CAC | SCREW (M6 x 25 mm) Stainless Steel Manifold to CAC | 13 |
| 15 | 8M0103807 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 13 |
| 16 | 8M6000639 | 压力传感器 | SENSOR Pressure Pressure | 1 |
| 16 | 8M0234766 | 压力传感器 | SENSOR PRESSURE | 1 |
| 17 | 13791 | 卡箍(15.7) | CLAMP (15.7) | 1 |
| 17 | 8M0214911 | 卡箍@5 | CLAMP @5 | 1 |
| 18 | 8M0041053 | MAP传感器护套 | BOOT MAP Sensor | 1 |
| 19 | 888988001 | 卡箍(36.1毫米) | CLAMP (36.1 mm) | 1 |
| 19 | 8M0204719 | 卡箍 36.1毫米 | CLAMP 36.1 MM | 1 |
| 20 | 8M0041080 | 燃油导轨总成 | FUEL RAIL ASSEMBLY | 1 |
| 20 | 8M0185166 | 燃油导轨总成 | FUEL RAIL ASSY | 1 |
| 21 | 8M0047054 | 燃油进管套件 | TUBE KIT Fuel Inlet | 1 |
| 22 | NSS | O型圈(管用)不单独销售 | NOT SOLD SEPARATE O-RING Tube | 1 |
| 23 | 8M0041097 | 固定支架 | BRACKET Retaining | 1 |
| 24 | 8M0041100 | 螺钉 (M5 x 10) | SCREW (M5 x 10) | 1 |
| 25 | 8M0047053 | 施拉德阀维修包 | VALVE KIT Shrader | 1 |
| 26 | NSS | O型圈(施拉德阀用)不单独销售 | NOT SOLD SEPARATE O-ring- Shrader Valve | 1 |
| 27 | 8M0041097 | 固定支架 | BRACKET Retaining | 1 |
| 28 | 8M0041100 | 螺钉 (M5 x 10) | SCREW (M5 x 10) | 1 |
| 29 | NSS | 燃油轨不单独销售 | NOT SOLD SEPARATE FUEL RAIL | 1 |
| 30 | 8M0041096 | 喷油器安装支架 | BRACKET Fuel Injector Mounting | 3 |
| 31 | 8M0041571 | 燃油喷油器总成 | INJECTOR ASSEMBLY Fuel | 6 |
| 31 | 8M0222278 | 燃油喷射器 | FUEL INJECTOR | 6 |
| 32 | 8M0041100 | 螺钉 (M5 x 10) | SCREW (M5 x 10) | 12 |
| 33 | 8M0041101 | 燃油轨减震器 | DAMPER Fuel Rail | 1 |
| 34 | 851889 | O型圈 | O-RING | 1 |
| 35 | 8M0103315 | 皮托管传感器套件 | PITOT SENSOR KIT | 1 |
| 36 | 892403 | 接头 | FITTING | 1 |
| 36 | 8M0207782 | 直通接头 | FITTING Straight | 1 |
| 37 | 883066 | 夹子 (.865) | CLIP (.865) | 1 |
| 38 | 859731 | 适配管接头 | FITTING Adapter | 1 |
| 38 | 8M0214970 | 接头 | FITTING | 1 |
| - | 8M0132737 | O型圈套件 | O-RING KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 826292 | 螺母(M10)黄铜/镀镍 | NUT (M10) Brass/Nickel Plated | 1 |
| 2 | 892487001 | 螺钉 | SCREW | 7 |
| 2 | 8M0048051 | 不锈钢螺钉(M6x30) | SCREW (M6 x 30) Stainless Steel | 7 |
| - | NSS | 不单独出售-软管总成 | NOT SOLD SEPARATE Hose Assembly | 1 |
| 3 | 889593001 | 软管 | HOSE | 1 |
| 4 | 889633A04 | 冲洗接头总成 | FITTING ASSEMBLY Flushing | 1 |
| 4 | 8M0188433 | 冲洗接头总成 | FITTING ASY-FLUSH | 1 |
| 5 | 889592001 | 软管 | HOSE | 1 |
| 6 | 888988008 | 卡箍(34.6毫米) | CLAMP (34.6 MM) | 2 |
| 6 | 8M0187145 | 卡箍 | CLAMP | 2 |
| 7 | 892967 | 软管 | HOSE | 1 |
| 8 | 850181 | 捆扎带(11.750英寸) | TIE STRAP (11.750 Inches) | 1 |
| 9 | 888988008 | 卡箍(34.6毫米) | CLAMP (34.6 MM) | 2 |
| 9 | 8M0187145 | 卡箍 | CLAMP | 2 |
| 10 | 880529 | 增压歧管参考软管-上部 | HOSE Boost Manifold Reference-Upper | 1 |
| 10 | 8M0203767 | 软管 歧管 | HOSE MANIFOLD | 1 |
| 11 | 88552730 | 螺钉 (M10 x 30) | SCREW (M10 x 30) | 2 |
| 11 | 8M0103821 | 螺钉 | SCREW | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 892062T02 | 前侧锁扣总成 | LATCH ASSEMBLY Front and Side | 1 |
| - | 8M0100547 | 前侧锁扣总成 | LATCH ASSEMBLY Front and Side | 1 |
| 1 | 888976T01 | 支架 | BRACKET | 1 |
| 2 | 888974A02 | 侧锁扣总成 | SIDE LATCH ASSEMBLY | 2 |
| 3 | 888996 | 弹簧 | SPRING | 4 |
| 4 | 896124 | 套筒 | SLEEVE | 4 |
| 5 | 828249 | 护孔环 | GROMMET | 2 |
| 6 | 889694 | 电缆 | CABLE | 2 |
| 6 | 8M0080491 | 电缆 | CABLE | 2 |
| 7 | 27290 | 挡圈 | RING Retaining | 2 |
| 8 | 30164 | 垫圈(0.192x0.375x0.0312)不锈钢 | WASHER (.192 x .375 x .0312) Stainless Steel | 1 |
| 9 | 893380 | U型销 | PIN Clevis | 1 |
| 10 | 61319 | E型卡环 | E RING | 1 |
| 11 | 4006731 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 4 |
| 12 | 889627 | 螺柱 | STUD | 2 |
| 12 | 8M0099404 | 螺柱 | STUD | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 891644A04 | 曲轴总成 | CRANKSHAFT ASSEMBLY | 1 |
| 2 | 897498T01 | 主轴承-绿色(曲轴上端) | BEARING Main - Green Crankshaft-Upper | 12/AR |
| 2 | 897498T02 | 主轴承-海军蓝(曲轴上端) | BEARING Main - Navy Blue Crankshaft-Upper | 12/AR |
| 2 | 897498T03 | 主轴承-白色(曲轴上端) | BEARING Main - White Crankshaft-Upper | 12/AR |
| 2 | 897498T04 | 主轴承-橙色(曲轴上端) | BEARING Main - Orange Crankshaft-Upper | 12/AR |
| 3 | 892309T01 | 推力轴承-绿色(曲轴下端) | BEARING Thrust - Green Crankshaft-Lower | 2/AR |
| 3 | 8M0117003 | 轴承 | BEARING | 2/AR |
| 3 | 892309T02 | 推力轴承-海军蓝(曲轴下端) | BEARING Thrust - Navy Blue Crankshaft-Lower | 2/AR |
| 3 | 8M0117001 | 轴承 | BEARING | 2/AR |
| 3 | 892309T03 | 推力轴承-白色(曲轴下端) | BEARING Thrust - White Crankshaft-Lower | 2/AR |
| 3 | 8M0117002 | 轴承 | BEARING | 2/AR |
| 3 | 892309T04 | 推力轴承-橙色(曲轴下端) | BEARING Thrust - Orange Crankshaft-Lower | 2/AR |
| 3 | 8M0117004 | 轴承 | BEARING | 2/AR |
| 4 | 8805251 | 油封(主轴承顶部) | SEAL Top Main Bearing | 1 |
| 4 | 8M0032912 | 密封件 | SEAL | 1 |
| 5 | 896883 | 隔套 | SPACER | 1 |
| 6 | 896882 | 挡圈 | RING Retaining | 1 |
| 7 | 91800 | 半圆键 | KEY Woodruff | 1 |
| 8 | 885348 | 飞轮螺栓盖 | CAP Flywheel Bolt | 1 |
| 9 | 897796 | 链条(凸轮轴驱动滚子链) | CHAIN Roller Cam Drive | 1 |
| 9 | 8M0103398 | 链条(凸轮轴驱动滚子链) | CHAIN Roller Cam Drive | 1 |
| 10 | 881210T02 | 连杆总成 | CONNECTING ROD ASSEMBLY | 6 |
| 10 | 8M0103285 | 连杆总成 | CONNECTING ROD ASSEMBLY | 6 |
| 11 | 884441 | 螺栓 | BOLT | 12 |
| 12 | 892005A01 | 连杆轴承-蓝色 | BEARING Connecting Rod - Blue | 12/AR |
| 12 | 892005A02 | 连杆轴承-白色 | BEARING Connecting Rod - White | 12/AR |
| 12 | 892005A03 | 连杆轴承-橙色 | BEARING Connecting Rod - Orange | 12/AR |
| 13 | 897737T01 | 活塞总成 | PISTON ASSEMBLY | 6 |
| 13 | 897737A04 | 活塞/喷油嘴套件 | PISTON/OILJET KIT | 6 |
| 14 | 881180A02 | 活塞环组 | RING SET Piston | 6 |
| 15 | NSS | 活塞环-油环(不单独销售) | NOT SOLD SEPARATE Piston Ring-Oil | 6 |
| 16 | NSS | 活塞环-第二道(不单独销售) | NOT SOLD SEPARATE Piston Ring-2nd | 6 |
| 17 | NSS | 活塞销（不单独销售） | NOT SOLD SEPARATE Piston Pin | 6 |
| 18 | 881184 | 卡簧 | CIRCLIP | 12 |
| 19 | 888983T02 | 飞轮 | FLYWHEEL | 1 |
| 19 | 888983T03 | 飞轮总成 | FLYWHEEL ASSEMBLY | 1 |
| 20 | 880515 | 螺栓(M20×68) | BOLT (M20 x 68) | 1 |
| 20 | 8M0147042 | 螺栓 | BOLT | 1 |
| 21 | 880517 | 垫圈 | WASHER | 1 |
| 21 | 8M0090010 | 垫圈 | WASHER | 1 |
| - | 880552A06 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 880552A07 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 895247A06 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 895247R06 | RM L6 GEN1 VERADO | RM L6 GEN1 VERADO | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 880506A11 | 气缸体总成 | CYLINDER BLOCK ASSEMBLY | 1 |
| 2 | 8569662 | 起动机安装支架 | BRACKET Mounting-Starter Motor | 2 |
| 2 | 8M0111325 | 盖板 | COVER | 2 |
| 3 | 88552640 | 螺钉 (M8 x 40) | SCREW (M8 x 40) | 4 |
| 3 | 8M0103815 | 螺钉 | SCREW | 4 |
| 4 | 889767 | 堵头（12毫米） | PLUG (12 mm) | 1 |
| 5 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 6 | 893392001 | 减震器 | DAMPER | 14 |
| 7 | 896951 | 堵头（24毫米） | PLUG (24 mm) | 4 |
| 8 | 880524 | 定位销（14毫米） | PIN Dowel (14 MM) | 1 |
| 9 | 884409 | O型圈 | O-RING | 1 |
| 10 | 884424 | 定位销(11毫米) | PIN Dowel (11 mm) | 1 |
| 11 | 884423 | O型圈 | O-RING | 1 |
| 12 | 896923 | 螺钉（M10×342） | SCREW (M10 x 342) | 14 |
| 12 | 8M4501000 | 螺钉（M10×342） | SCREW (M10 X 342) | 14 |
| 13 | 892573001 | 垫圈 | WASHER | 14 |
| 14 | 88552675 | 螺钉 (M8 x 75) | SCREW (M8 x 75) | 1 |
| 14 | 8M0103818 | 螺丝 (M8x75) | SCREW (M8 X 75) | 1 |
| 15 | 8283582 | 传感器 | SENSOR | 1 |
| 15 | 8M0082988 | 曲轴位置传感器 | SENSOR Crankshaft Position | 1 |
| 16 | 40011107 | 不锈钢螺钉(M5x16) | SCREW (M5 x 16) Stainless Steel | 2 |
| 17 | 8M0010146 | 传感器 | SENSOR | 1 |
| 17 | 8M0205787 | 温度传感器 | SENSOR Temperature | 1 |
| 18 | 888814 | O型圈(0.351 x 0.072) | O-RING (.351 x .072) | 2 |
| 18 | 896699 | O型圈（1.78毫米 x 0.08毫米） | O-RING (1.78 mm x .08 mm) | 2 |
| 19 | 8M0010469 | 传感器 压力 | SENSOR Pressure | 1 |
| 19 | 8M0142688 | 压力传感器(机油/水) | SENSOR Pressure (Oil/Water) | 1 |
| 20 | 895374006 | 衬垫 缸盖 | GASKET Head | 1 |
| 20 | 8M0033476 | 衬垫 缸盖 | GASKET Head | 1 |
| 21 | 888517 | 销 | PIN | 1 |
| 22 | 895810115 | 螺钉(M8×115) | SCREW (M8 x 115) | 12 |
| 22 | 8M0193831 | 螺丝@2 | SCREW @2 | 12 |
| 23 | 895810050 | 螺钉(M8 x 50) | SCREW (M8 x 50) | 2 |
| 23 | 8M0193659 | 螺钉 | SCREW | 2 |
| 24 | 880624003 | 缸体至适配器衬垫 | GASKET Block to Adapter | 1 |
| 25 | 880559 | 固定导套 | GUIDE Fixed | 1 |
| 26 | 880557 | 活动导板 | GUIDE Moveable | 1 |
| 27 | 892456045 | 螺钉 | SCREW | 2 |
| 28 | 888849002 | 螺柱 | STUD | 2 |
| 28 | 8M0022160 | 双头螺柱（M8×43） | STUD (M8 x 43) | 2 |
| 29 | 401388 | 不锈钢螺母 (M8) | NUT (M8) Stainless Steel | 1 |
| 30 | 88552635 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 1 |
| 30 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 1 |
| 31 | 8M0010146 | 传感器 | SENSOR | 1 |
| 31 | 8M0205787 | 温度传感器 | SENSOR Temperature | 1 |
| - | 880552A06 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 880552A07 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 895247A06 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 895247R06 | RM L6 GEN1 VERADO | RM L6 GEN1 VERADO | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 880536A10 | 气缸盖总成 完整件 | CYLINDER HEAD ASSEMBLY Complete | 1 |
| 1 | 880536A08 | 气缸盖总成 | CYLINDER HEAD ASSEMBLY | 1 |
| 1 | 8M0152336 | 气缸盖底座 | CYLINDER HEAD BAS | 1 |
| 2 | 889767 | 堵头（12毫米） | PLUG (12 mm) | 8 |
| 3 | 891953 | 堵头（18毫米） | PLUG (18 mm) | 3 |
| 4 | 896951 | 堵头（24毫米） | PLUG (24 mm) | 1 |
| 5 | 896576 | 堵头（10毫米） | PLUG (10 mm) | 1 |
| 5 | 8M0087446 | 堵头（10毫米） | PLUG (10 mm) | 1 |
| 6 | 880524 | 定位销（14毫米） | PIN Dowel (14 MM) | 2 |
| 7 | 892454035 | 螺栓（M6×36） | BOLT (M6 x 36) | 28 |
| 7 | 8M0163131 | M6螺钉 | SCREW M6 | 28 |
| 8 | 880533 | 进气门座 | SEAT Intake Valve | 12 |
| 9 | 880535 | 排气门座 | SEAT Exhaust Valve | 12 |
| 9 | 8M0089477 | 排气门座 | SEAT Exhaust Seat | 12 |
| 10 | 880537 | 进排气门导管 | GUIDE Intake Exhaust Valve Intake and Exhaust Valves | 24 |
| 11 | 897629 | 进气阀 | VALVE Intake | 12 |
| 11 | 898907 | 进气阀 | VALVE Intake | 12 |
| 12 | 897630 | 排气阀 | VALVE Exhaust | 12 |
| 12 | 898908 | 排气阀 | VALVE Exhaust | 12 |
| 13 | 896880 | 气门油封 | SEAL Valve | 24 |
| 13 | 8M0214986 | 密封件 | SEAL | 24 |
| 14 | 895815 | 进排气门弹簧 | SPRING Intake and Exhaust Valve | 24 |
| 14 | 8M0011503 | 弹簧 | SPRING | 24 |
| 15 | 880542A1 | 气门锁夹总成 | RETAINER ASSEMBLY Valves | 24 |
| 15 | 8M0908500 | 气门锁夹总成 | RETAINER ASSEMBLY Valves | 24 |
| 16 | 880543 | 键 | KEY | 48 |
| 17 | NSS | NOT SOLD SEPARATE CAP | 10 | |
| 18 | 892112T02 | 进气凸轮轴 | CAMSHAFT Intake | 1 |
| 19 | 892113T02 | 排气凸轮轴 | CAMSHAFT Exhaust | 1 |
| 19 | 892113T04 | 排气凸轮轴 | CAMSHAFT Exhaust | 1 |
| 20 | 8805481 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912001 | 挺柱（2.996） | TAPPET (2.996) | 24/AR |
| 20 | 8805482 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912002 | 挺柱（3.021） | TAPPET (3.021) | 24/AR |
| 20 | 8805483 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912003 | 挺柱（3.046） | TAPPET (3.046) | 24/AR |
| 20 | 8805484 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912004 | 挺柱（3.071） | TAPPET (3.071) | 24/AR |
| 20 | 8805485 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912005 | 挺柱（3.096） | TAPPET (3.096) | 24/AR |
| 20 | 8805486 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912006 | 挺柱（3.118） | TAPPET (3.118) | 24/AR |
| 20 | 8805487 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912007 | 挺柱（3.138） | TAPPET (3.138) | 24/AR |
| 20 | 8805488 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912008 | 挺柱（3.158） | TAPPET (3.158) | 24/AR |
| 20 | 8805489 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912009 | 挺柱（3.178） | TAPPET (3.178) | 24/AR |
| 20 | 88054810 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912010 | 挺柱（3.198） | TAPPET (3.198) | 24/AR |
| 20 | 88054811 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912011 | 挺柱（3.218） | TAPPET (3.218) | 24/AR |
| 20 | 88054812 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912012 | 挺柱（3.238） | TAPPET (3.238) | 24/AR |
| 20 | 88054813 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912013 | 挺柱（3.258） | TAPPET (3.258) | 24/AR |
| 20 | 88054814 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912014 | 挺柱（3.278） | TAPPET (3.278) | 24/AR |
| 20 | 88054815 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912015 | 挺柱（3.298） | TAPPET (3.298) | 24/AR |
| 20 | 88054816 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912016 | 挺柱（3.318） | TAPPET (3.318) | 24/AR |
| 20 | 88054817 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912017 | 挺柱（3.338） | TAPPET (3.338) | 24/AR |
| 20 | 88054818 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912018 | 挺柱（3.358） | TAPPET (3.358) | 24/AR |
| 20 | 88054819 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912019 | 挺柱（3.378） | TAPPET (3.378) | 24/AR |
| 20 | 88054820 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912020 | 挺柱（3.398） | TAPPET (3.398) | 24/AR |
| 20 | 88054821 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912021 | 挺柱（3.418） | TAPPET (3.418) | 24/AR |
| 20 | 88054822 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912022 | 挺柱（3.438） | TAPPET (3.438) | 24/AR |
| 20 | 88054823 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912023 | 挺柱（3.458） | TAPPET (3.458) | 24/AR |
| 20 | 88054824 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912024 | 挺柱（3.478） | TAPPET (3.478) | 24/AR |
| 20 | 88054825 | 挺柱 | TAPPET | 24/AR |
| 20 | 88054826 | 挺柱 | TAPPET | 24/AR |
| 20 | 88054827 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912027 | 挺柱（3.538） | TAPPET (3.538) | 24/AR |
| 20 | 88054828 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912028 | 挺柱（3.558） | TAPPET (3.558) | 24/AR |
| 20 | 88054829 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912029 | 挺柱（3.578） | TAPPET (3.578) | 24/AR |
| 20 | 88054830 | 挺柱 | TAPPET | 24/AR |
| 20 | 88054831 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912031 | 挺杆 (3.621) | TAPPET (3.621) | 24/AR |
| 20 | 88054832 | 挺柱 | TAPPET | 24/AR |
| 20 | 88054833 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912033 | 挺杆 (3.671) | TAPPET (3.671) | 24/AR |
| 20 | 88054834 | 挺柱 | TAPPET | 24/AR |
| 20 | 899912034 | 挺杆 (3.696) | TAPPET (3.696) | 24/AR |
| 20 | 88054835 | 挺柱 | TAPPET | 24/AR |
| 21 | 892454030 | 螺钉 (M6 x 30) | SCREW (M6 x 30) | 2 |
| 22 | 892596T03 | 凸轮轴盖 | COVER Camshaft | 1 |
| 22 | 892596T04 | 凸轮盖总成 | COVER ASSEMBLY Cam | 1 |
| 23 | 892584 | 密封件 | SEAL | 3 |
| 24 | 892585 | 密封件 | SEAL | 1 |
| 24 | 8M6000959 | 密封件 | SEAL | 1 |
| 25 | 88552525 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 3 |
| 25 | 8M0103807 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 3 |
| 26 | 859578A1 | 油塞总成 | PLUG ASSEMBLY Oil | 1 |
| 26 | 8M0240831 | 油塞 | OIL PLUG | 1 |
| 27 | 90196 | O型圈 (.921 x .139) | O-RING (.921 x .139) | 1 |
| 27 | 8M0204673 | O型圈 .921 x .139 | O-Ring .921 x .139 | 1 |
| 28 | 880558 | 短导杆 | GUIDE Short | 1 |
| 29 | 8M0010146 | 传感器 | SENSOR | 1 |
| 29 | 8M0205787 | 温度传感器 | SENSOR Temperature | 1 |
| 30 | 888814 | O型圈(0.351 x 0.072) | O-RING (.351 x .072) | 1 |
| 30 | 896699 | O型圈（1.78毫米 x 0.08毫米） | O-RING (1.78 mm x .08 mm) | 1 |
| 31 | 88552660 | 螺钉 (M8 x 60) | SCREW (M8 x 60) | 4 |
| 31 | 8M0103817 | 螺钉 (M8 x 60) | SCREW (M8 x 60) | 4 |
| 32 | 897797A01 | 张紧器总成 | TENSIONER ASSEMBLY | 1 |
| 32 | 898463A01 | 张紧器总成 | TENSIONER ASSEMBLY | 1 |
| 32 | 898463A01 | 张紧器总成 | TENSIONER ASSEMBLY | 1 |
| 33 | 898836 | 棕色O型圈 | O-RING Brown | 1 |
| 33 | 8M0237361 | O型圈 | O-RING | 1 |
| 34 | 893338 | 张紧器端盖 | END CAP Tensioner | 1 |
| 34 | 8M0064752 | 凸轮张紧器端盖 | END CAP Cam Tensioner | 1 |
| 35 | 88552525 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 2 |
| 35 | 8M0103807 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 2 |
| 36 | 88552540 | 螺钉(M6x40毫米)不锈钢 | SCREW (M6 x 40 mm) Stainless Steel | 3 |
| 36 | 8M0103809 | 螺钉(M6x40毫米)不锈钢 | SCREW (M6 x 40 mm) Stainless Steel | 3 |
| 37 | 88552635 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 2 |
| 37 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 2 |
| 38 | 817274 | 垫圈(0.344×1.00×0.063)不锈钢 | WASHER (.344 x 1.00 x .063) Stainless Steel | 2 |
| 39 | 833155 | 护孔环 | GROMMET | 2 |
| 40 | 8502341 | 衬套 | BUSHING | 2 |
| 41 | 892833 | 卡扣 | CLIP | 1 |
| 42 | 889591A05 | 通气软管总成 | HOSE ASSEMBLY Breather | 1 |
| 43 | 880615T01 | 线圈总成 | COIL ASSEMBLY | 6 |
| 44 | 88552525 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 6 |
| 44 | 8M0103807 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 6 |
| 45 | 889680001 | 火花塞 NGK-ILFR6G | SPARK PLUG NGK-ILFR6G | 6 |
| 45 | 889246Q39 | NGK-ILFR6GE火花塞 | SPARK PLUG NGK-ILFR6GE | 6 |
| 46 | 858954 | 卡箍(0.625英寸) | CLIP (.625) | 3 |
| 47 | 850181 | 捆扎带(11.750英寸) | TIE STRAP (11.750 Inches) | 1 |
| 48 | 880550 | 凸轮驱动链轮 | SPROCKET Cam Drive | 2 |
| 48 | 8M0241408 | 凸轮链轮 | SPROCKET CAM | 2 |
| 49 | 884403 | 螺钉 (M12 x 40) | SCREW (M12 x 40) | 2 |
| 49 | 8M0237436 | 螺钉 | SCREW | 2 |
| 50 | 88552512 | 不锈钢螺钉 (M6 x 12 mm) | SCREW (M6 x 12 mm) Stainless Steel | 3 |
| 50 | 8M0103804 | 不锈钢螺钉 (M6 x 12 mm) | SCREW (M6 x 12 MM) Stainless Steel | 3 |
| 51 | 889746001 | 卡扣 | CLIP | 1 |
| 52 | 888988019 | 卡箍 (22.6 mm) | CLAMP (22.6 mm) | 1 |
| 53 | 880609 | 传感器总成 | SENSOR ASSEMBLY | 1 |
| 53 | 8M0233140 | 传感器 | SENSOR | 1 |
| 54 | 88552516 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 1 |
| - | 880552A06 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 895247A06 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8M0102448 | 水星贴花套装 | DECAL SET Mercury | 1 |
| 2 | 8M0043703 | M标志贴纸66mm黑色 | DECAL M-Icon, 66 MM, Black | 1 |
| 3 | 8M0085363 | 200马力银色贴花 | DECAL 200 HP Silver | 1 |
| 4 | 8M0085364 | 225马力银色贴花 | DECAL 225 HP Silver | 1 |
| 5 | 8M0085365 | 250马力银色贴花 | DECAL 250 HP Silver | 1 |
| 6 | 8M0085366 | 300马力银色贴花 | DECAL 300 HP Silver | 1 |
| 7 | 8M0075217 | 操纵杆驾驶贴花 | DECAL Joystick Piloting | 1 |
| 8 | 892870A02 | Mariner贴纸套装 | DECAL SET Mariner | 1 |
| 9 | 8M0025965 | 水星Verado贴花 | DECAL (Mariner Verado) | 1 |
| 10 | 899324003 | 水星200贴花 | DECAL (Mariner 200) | 1 |
| 11 | 899324004 | 水星225贴花 | DECAL (Mariner 225) | 1 |
| 12 | 899324005 | 水星250贴花 | DECAL (Mariner 250) | 1 |
| 13 | 899324006 | 水星275贴花 | DECAL (Mariner 275) | 1 |
| 14 | 8M0025964 | 水星300贴花 | DECAL (Mariner 300) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 880646T01 | 驱动轴壳体-黑色 | HOUSING Driveshaft, Black | 1 |
| 1 | 8M0113286 | DSH BLACK L | DSH BLACK L | 1 |
| 2 | 885366T01 | 下部护套总成-左舷 | CHAP ASSEMBLY Lower-Port | 1 |
| 2 | 885365T03 | 加长护套总成-左右舷-黑色 | CHAP ASSEMBLY Long - Port and Starboard, Black | 1 |
| 2 | 885364T01 | 下部护套总成-左舷 | CHAP ASSEMBLY Lower-Port | 1 |
| 2 | 885363T04 | 超长/特超长护套总成-左右舷 | CHAP ASSEMBLY X-Long/XX-Long - Port and Starboard | 1 |
| 3 | 885365T01 | 下部护套总成-右舷 | CHAP ASSEMBLY Lower-Starboard | 1 |
| 3 | 885365T03 | 加长护套总成-左右舷-黑色 | CHAP ASSEMBLY Long - Port and Starboard, Black | 1 |
| 3 | 885363T01 | 下部护套总成-右舷 | CHAP ASSEMBLY Lower-Starboard | 1 |
| 3 | 885363T04 | 超长/特超长护套总成-左右舷 | CHAP ASSEMBLY X-Long/XX-Long - Port and Starboard | 1 |
| 4 | 892073002 | 台阶螺丝 (M6) | SHOULDER SCREW (M6) | 8 or 12 |
| 4 | 8M0230980 | 螺丝 (M6x14) 六角法兰B型 | SCREW (M6 x 14) Hex Flange B | 8 or 12 |
| 5 | 889568001 | 护孔环 | GROMMET | 1 |
| 6 | 889656T | 蒸汽分离器罩 | SHROUD Vapor Separator | 1 |
| 6 | 889656T01 | 护罩 | SHROUD | 1 |
| 7 | 88552675 | 螺钉 (M8 x 75) | SCREW (M8 x 75) | 2 |
| 7 | 8M0103818 | 螺丝 (M8x75) | SCREW (M8 X 75) | 2 |
| 8 | 885526120 | 螺丝 (M8x120) | SCREW (M8 x 120) | 2 |
| 8 | 8M0103812 | 螺钉 | SCREW | 2 |
| 9 | 88552650 | 螺钉(M8 x 50) | SCREW (M8 x 50) | 2 |
| 9 | 8M0103816 | 螺丝 M8x50 六角法兰 | SCREW M8 x 50 HEX FLG | 2 |
| 10 | 88552640 | 螺钉 (M8 x 40) | SCREW (M8 x 40) | 1 |
| 10 | 8M0103815 | 螺钉 | SCREW | 1 |
| 11 | 88552635 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 3 |
| 11 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 3 |
| 12 | 817274 | 垫圈(0.344×1.00×0.063)不锈钢 | WASHER (.344 x 1.00 x .063) Stainless Steel | 3 |
| 13 | 897784A01 | 上部护套支架套件 | BRACKET KIT Upper Chap | 2 |
| 14 | 88552520 | 螺钉(M6 x 20毫米)不锈钢 | SCREW (M6 x 20 mm) Stainless Steel | 2 |
| 14 | 8M0103806 | 螺钉(M6 x 20毫米)不锈钢 | SCREW (M6 x 20 mm) Stainless Steel | 2 |
| 15 | 88552630 | 螺钉 (M8 x 30) | SCREW (M8 x 30) | 1 |
| 15 | 8M0103813 | 螺钉 (M8 x 30) | SCREW (M8 x 30) | 1 |
| 16 | 85944975 | 管材 (72英寸整卷) 裁切至44英寸 | TUBING (72.00 Inches Bulk) Cut to 44 Inches) | 1 |
| 17 | 889831001 | 固定座 | RETAINER | |
| 18 | NSS | 非单独销售贴纸-放油口 | NOT SOLD SEPARATE Decal-Oil Drain | 1 |
| 19 | 898033 | 卡箍（替代O型圈） | CLIP (Replaces O-Rings) | 2 |
| 20 | 856983 | 双头螺柱(M12 x 52) | STUD (M12 x 52) | 4 |
| 20 | 8M0008031 | 双头螺柱(M12 x 1.75 x 52) | STUD (M12 x 1.75 x 52) | 4 |
| 21 | 856982 | 垫圈(0.5×0.81×0.09英寸)不锈钢 | WASHER (.500 x .810 x .090) Stainless Steel | 4 or 5 |
| 22 | 896895 | 螺母(M12) | NUT (M12) | 4 |
| 23 | 88552835 | 螺钉(M12×35毫米) | SCREW (M12 x 35 MM) | 1 |
| 23 | 8M0102995 | 螺丝 (M12) | SCREW (M12) | 1 |
| 24 | 824928001 | 橡胶塞 | PLUG Rubber | 1 |
| 25 | 856774 | 垫圈(0.406×0.750×0.105)不锈钢 | WASHER (.406 x .750 x .105) Stainless Steel | 10 |
| 25 | 8M0214963 | 垫圈 | WASHER | 10 |
| 26 | 884412 | 螺母 | NUT | 10 |
| 27 | 88552845 | 螺丝 (M12x45) | SCREW (M12 x 45) | 4 |
| 27 | 8M0103825 | 螺丝@2 | SCREW @2 | 4 |
| 28 | 880647T | 隔套 | SPACER | 1 |
| 28 | 8M0105088 | 传动轴壳体加长隔套（黑色） | SPACER Driveshaft Housing X-Long, Black | 1 |
| 29 | 857137 | 螺钉 (M12 X 160) | SCREW (M12 x 160) | 1 |
| 30 | 857009 | 双头螺柱（M12×179） | STUD (M12 x 179) | 4 |
| 30 | 8M0008047 | 双头螺柱（M12×179） | STUD (M12 x 179) | 4 |
| 31 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 32 | 855623 | 衬套 (按需使用) | BUSHING (Use where Applicable) | 1 |
| 33 | 880648T01 | 驱动轴壳体-黑色 | HOUSING Driveshaft, Black | 1 |
| 33 | 8M0113287 | 驱动轴壳体黑色加长型 | DSH BLACK XL | 1 |
| 34 | 891966006 | 外罩支架 | BRACKET Cowl | 1 |
| 35 | 88552520 | 螺钉(M6 x 20毫米)不锈钢 | SCREW (M6 x 20 mm) Stainless Steel | 2 |
| 35 | 8M0103806 | 螺钉(M6 x 20毫米)不锈钢 | SCREW (M6 x 20 mm) Stainless Steel | 2 |
| 36 | 896251 | O型圈 | O-RING | 2 |
| 36 | 898033 | 卡扣 | CLIP | 2 |
| - | 895247A06 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 895247R06 | RM L6 GEN1 VERADO | RM L6 GEN1 VERADO | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | NSS | 不单独销售 电气箱总成 | NOT SOLD SEPARATE Electrical Box-Complete | 1 |
| - | NSS | 不单独销售 电气箱 | NOT SOLD SEPARATE Electrical Box | 1 |
| 1 | 885560T03 | 电气箱底座 | BASE Electrical Box | 1 |
| 2 | 885561T | 保险丝盒盖 | COVER Fuse Box | 1 |
| 3 | 888491 | 保险丝盖 | COVER Fuse | 1 |
| 3 | 8M0167280 | 保险丝盖 | FUSE COVER | 1 |
| 4 | 885583 | 密封件 | SEAL | 1 |
| 5 | 889531 | 绑带 | STRAP | 2 |
| 6 | 885584 | 铰链销 | PIN Hinge | 2 |
| 7 | 833155 | 护孔环 | GROMMET | 1 |
| 8 | 8502341 | 衬套 | BUSHING | 1 |
| 9 | 83296920 | 迷你保险丝-黄色-20安 | FUSE Mini - Yellow - 20 Ampere | 7 |
| 9 | 832969T20 | 迷你保险丝-黄色-20安 | FUSE Mini - Yellow - 20 Ampere | 7 |
| 10 | 400213 | 不锈钢螺母 (M8) | NUT (M8) Stainless Steel | 1 |
| 11 | 895099 | 保险丝拔取器 | EXTRACTOR Fuse | 1 |
| 12 | 828547753 | 导管（内径0.750英寸×3英尺散装） | CONDUIT (.750 Inside Diameter x 3.00 Feet Bulk) | 1 |
| 13 | 40011146 | 螺钉（M8×13不锈钢） | SCREW (M8 x 13) Stainless Steel | 2 |
| 14 | 843108 | 垫圈（.330 x .560 x .060）不锈钢 | WASHER (.330 x .560 x .060) Stainless Steel | 1 |
| 15 | 817274 | 垫圈(0.344×1.00×0.063)不锈钢 | WASHER (.344 x 1.00 x .063) Stainless Steel | 1 |
| 16 | 892244 | 盖板固定带 | STRAP Cover | 1 |
| 17 | 879962 | 卡扣 | CLIP | 4 |
| 18 | 89790708T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924687T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924661T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924687T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924687T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 89790712T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924688T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924606T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924688T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924688T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 89790709T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924689T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924601T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924689T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924689T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 89790713T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924690T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924608T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924690T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924690T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 89790710T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924694T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924602T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924694T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924694T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 89790714T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924691T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924609T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924691T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924691T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 89790711T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924692T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924603T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924692T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924692T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 89790715T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924693T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924610T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924693T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 18 | 88924693T | 推进控制模块PCM | PCM Propulsion Control Module | 1 |
| 19 | 880616A06 | 发动机线束总成 | HARNESS ASSEMBLY Engine | 1 |
| 19 | 8M0082643 | 发动机线束总成 | HARNESS ASSEMBLY Engine | 1 |
| - | NSS | 不单独销售 继电器支架总成 | NOT SOLD SEPARATE Relay Bracket Assembly | 1 |
| 20 | 882751A04 | 继电器总成 | RELAY ASSEMBLY | 4 |
| 21 | NSS | 微调继电器标识贴(不单独销售) | NOT SOLD SEPARATE Decal-Trim Relay | 4 |
| 22 | 889532 | 支架 | BRACKET | 1 |
| 23 | 40007103 | 螺钉 (M5 x 6) | SCREW (M5 x 6) | 2 |
| 24 | 93388A17 | 线缆总成(8.50英寸) | CABLE ASSEMBLY (8.50 Inches) | 1 |
| 25 | 819514A20 | 升降线束总成 | HARNESS ASSEMBLY Trim | 1 |
| 25 | 879345T34 | 升降线束总成 | HARNESS ASSEMBLY Trim | 1 |
| 26 | 8M0088927 | 保险丝线束总成 | HARNESS ASSEMBLY Fuse | 1 |
| 27 | 850181 | 捆扎带(11.750英寸) | TIE STRAP (11.750 Inches) | 6 |
| 27 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 28 | 891520001 | 卡扣 | CLIP | 1 |
| 29 | 82129114 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 1 |
| 30 | 877613A02 | 防水插头总成6针 | CONNECTOR ASSEMBLY Weather Cap 6 Pin | 1 |
| 31 | 879962 | 卡扣 | CLIP | 1 |
| 32 | 888416T03 | 线束总成 | HARNESS ASSEMBLY | 1 |
| 32 | 8M0113732 | DTS清洁电源线束总成(14英尺) | HARNESS ASSEMBLY DTS, Clean Power, 14 Feet | 1 |
| 33 | 862646 | 褐色保险丝-5安培 | FUSE Tan - 5 Ampere | 1 |
| 34 | 88439A25 | 电缆总成 蓄电池-正极 | CABLE ASSEMBLY Battery - Positive | 1 |
| 35 | 401388 | 不锈钢螺母 (M8) | NUT (M8) Stainless Steel | 5 |
| 36 | 86226 | 螺母(.375-16 蓄电池正极电缆) | NUT (.375-16) Battery Cable-Positive | 1 |
| 36 | 8M0204671 | 螺母 | NUT | 1 |
| 37 | 88552635 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 1 |
| 37 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 1 |
| 38 | 817274 | 垫圈(0.344×1.00×0.063)不锈钢 | WASHER (.344 x 1.00 x .063) Stainless Steel | 1 |
| 39 | 88439A26 | 蓄电池负极电缆总成 | CABLE ASSEMBLY Battery - Negative | 1 |
| 40 | 68292 | 螺母(.312-18 蓄电池负极电缆) | NUT (.312-18) Battery Cable-Negative | 1 |
| 40 | 8M0204668 | 螺母(.312-18) | NUT (.312-18) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8M0103686 | 发动机安装燃油滤清器套件 | FUEL FILTER KIT Engine Mounted | 1 |
| 2 | 8M0062950 | 滤清器总成 | FILTER ASSEMBLY | 1 |
| 3 | 8M0060041 | 燃油滤清器 | FILTER Fuel | 1 |
| 3 | 8M0122423 | 水星燃油滤清器 | FUEL FILTER Quicksilver | 1 |
| 4 | 8M0009261 | 支架总成 | BRACKET ASSEMBLY | 1 |
| 5 | 88552785 | 螺钉(M10×85) | SCREW (M10 x 85) | 1 |
| 5 | 8M0103824 | 螺钉 | SCREW | 1 |
| 6 | 8M0103724 | WIF延长线束 | HARNESS WIF Extension | 1 |
| 7 | 8M0046557 | 燃油进口软管总成（8.2英寸） | HOSE ASSMEBLY Fuel Inlet, 8.2 Inch | 1 |
| 8 | 892356 | 连接器 | CONNECTOR | 1 |
| 9 | 8M0087107 | 软管 | HOSE | 1 |
| 10 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 3 |
| 11 | 8M0095669 | 带O型圈的MPP远程安装燃油滤清器套件 | FUEL FILTER KIT with o-ring, MPP Remote Mounted | 1 |
| 11 | 8M0157707 | 燃油滤清器套件 | FUEL FILTER KIT | 1 |
| 12 | 8M0095659 | 带O型圈的MPP燃油滤清器总成 | FUEL FILTER ASSEMBLY with o-ring, MPP | 1 |
| 12 | 8M0157616 | 燃油滤清器总成 | FUEL FILTER ASSEMBLY | 1 |
| 13 | 8M0095674 | 燃油滤清器底座总成 | BASE ASSEMBLY Fuel Filter | 1 |
| 14 | 816133 | 接头 | FITTING | 1 |
| 15 | 36373 | 六角堵头（.375-18）-钢制 | PLUG (.375-18) Hex - Steel | 2 |
| 15 | 8M0204657 | 堵头 | PLUG | 2 |
| 16 | 8M0086290 | 倒钩接头 | CONNECTOR Barb | 2 |
| 16 | 8M0204732 | 倒钩接头 | CONNECTOR Barb | 2 |
| 17 | 8M0021043 | 传感器总成 燃油和水 | SENSOR ASSEMBLY Fuel and Water | 1 |
| 17 | 8M0214989 | 燃油含水传感器 | SENSOR WIF | 1 |
| 18 | 8M0042697 | 燃油滤清器传感器延长线束 (144英寸) | HARNESS Fuel Filter Sensor Extension (144 in) | 1 |
| 19 | 8M0157779 | WIF传感器总成 | SENSOR ASSEMBLY WIF | 1 |
| 20 | 8M0152433 | 弯头接头 | FITTING ELBOW | 1 |
| - | 8M0105263 | WIF传感器延长线束-36英寸 | HARNESS WIF Sensor Extension - 36 Inches | 1 |
| - | 8M0105264 | WIF传感器延长线束-72英寸 | HARNESS WIF Sensor Extension - 72 Inches | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0102455 | 燃油供应模块 | MODULE Fuel Supply | 1 |
| 1 | 8M0053756 | 螺钉 Plastite W/ HX WSR HD | SCREW Plastite W/ HX WSR HD | 4 |
| 2 | 8M0053726 | 燃油供应模块 上壳体 | FSM TOP HOUSING | 1 |
| 2 | 8M0158344 | 燃油供应模块 上壳体 | FSM TOP HOUSING | 1 |
| 3 | NSS | NOT SOLD SEPARATE O-ring | 1 | |
| 4 | 8M0053749 | 调节器总成 | REGULATOR ASSEMBLY | 1 |
| 4 | 8M0242586 | 调节器总成 | REGULATOR ASSEMBLY | 1 |
| 5 | NSS | NOT SOLD SEPARATE O-ring | 1 | |
| 6 | NSS | NOT SOLD SEPARATE O-ring | 1 | |
| 7 | NSS | 不单独销售 | NOT SOLD SEPARATE | 3 |
| 8 | NSS | 不单独销售 | NOT SOLD SEPARATE | 2 |
| 9 | 8M0053727 | 燃油供应模块 盖 | FSM CAP | 1 |
| 10 | NSS | 不单独销售 | NOT SOLD SEPARATE | 2 |
| 11 | 8M0103289 | 泵总成 低压 | PUMP ASSEMBLY Low Pressure | 1 |
| 12 | 8M0103288 | 泵总成 高压 | PUMP ASSEMBLY High Pressure | 1 |
| 13 | NSS | NOT SOLD SEPARATE O-ring | 4 | |
| 14 | 8M0053735 | 管 | TUBE | 2 |
| 14 | 8M0119250 | 管 | TUBE | 2 |
| 15 | 8M0053755 | 管 | TUBE | 1 |
| 16 | NSS | NOT SOLD SEPARATE O-ring | 4 | |
| 17 | 8M0053734 | 管 | TUBE | 2 |
| 17 | 8M0120073 | 管 | TUBE | 2 |
| 18 | NSS | 不单独销售 密封件 | NOT SOLD SEPARATE Seal | 1 |
| 19 | 8M0053725 | 燃油供应模块 下壳体 | FSM BOTTOM HOUSING | 1 |
| 19 | 8M0132733 | 燃油供应模块 双泵 | FUEL SUPPLY MODULE Dual Pump | 1 |
| 20 | 8M0103287 | FSM线束总成 | HARNESS ASSEMBLY FSM | 1 |
| 21 | NSS | NOT SOLD SEPARATE O-ring | 1 | |
| 22 | NSS | NOT SOLD SEPARATE O-ring | 1 | |
| 23 | NSS | NOT SOLD SEPARATE Spacer | 1 | |
| 24 | 8M0086888 | FSM线束护圈 | GROMMET FSM Harness | 1 |
| - | 8M0057679 | 燃油供应模块 密封件套装 | FSM SEAL KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0132732 | 燃油供给模块 | FUEL SUPPLY MODULE | 1 |
| 1 | 8M0053726 | 燃油供应模块 上壳体 | FSM TOP HOUSING | 1 |
| 1 | 8M0158344 | 燃油供应模块 上壳体 | FSM TOP HOUSING | 1 |
| 2 | 8M0053756 | 螺钉 Plastite W/ HX WSR HD | SCREW Plastite W/ HX WSR HD | 4 |
| 3 | NSS | O型圈(不单独销售) | NOT SOLD SEPARATE O-Ring | 2 |
| 4 | NSS | NOT SOLD SEPARATE Spacer | 1 | |
| 5 | 8M0053749 | 调节器总成 | REGULATOR ASSEMBLY | 1 |
| 5 | 8M0242586 | 调节器总成 | REGULATOR ASSEMBLY | 1 |
| 6 | NSS | O型圈(不单独销售) | NOT SOLD SEPARATE O-Ring | 1 |
| 7 | NSS | 不单独销售 密封件 | NOT SOLD SEPARATE Seal | 3 |
| 8 | 8M0130877 | 燃油供应模块 盖 | FSM CAP | 1 |
| 8 | 8M0158425 | 燃油供应模块 盖 | FSM CAP | 1 |
| 9 | NSS | O型圈(不单独销售) | NOT SOLD SEPARATE O-Ring | 2 |
| 10 | 8M0053755 | 油管 吸油 | TUBE Suction | 1 |
| 11 | NSS | 不单独销售 密封件 | NOT SOLD SEPARATE Seal | 2 |
| 12 | 8M0103288 | 泵总成 高压 | PUMP ASSEMBLY High Pressure | 1 |
| 13 | 8M0103289 | 泵总成 低压 | PUMP ASSEMBLY Low Pressure | 1 |
| 14 | NSS | 不单独销售 密封件 | NOT SOLD SEPARATE Seal | 4 |
| 15 | NSS | O型圈(不单独销售) | NOT SOLD SEPARATE O-Ring | 4 |
| 16 | 8M0120073 | 水管 | TUBE Water | 2 |
| 17 | 8M0130873 | 油管 燃油 | TUBE Fuel | 2 |
| 18 | NSS | 不单独销售 密封件 | NOT SOLD SEPARATE Seal | 1 |
| 19 | 8M0130878 | 燃油供应模块 下壳体 | FSM BOTTOM HOUSING | 1 |
| 19 | 8M0158426 | 燃油供应模块 下壳体 | FSM BOTTOM HOUSING | 1 |
| 20 | 895319 | 护孔环 | GROMMET | 1 |
| 21 | 856954 | 衬套 | BUSHING | 1 |
| 22 | 8M0086888 | FSM线束护圈 | GROMMET FSM Harness | 1 |
| 23 | 8M0103287 | FSM线束总成 | HARNESS ASSEMBLY FSM | 1 |
| 24 | NSS | O型圈(不单独销售) | NOT SOLD SEPARATE O-Ring | 1 |
| 25 | NSS | O型圈(不单独销售) | NOT SOLD SEPARATE O-Ring | 1 |
| - | 8M0133370 | 燃油供应模块 密封件套装 | FSM SEAL KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 880686T13 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236255 | GC L6 4S L | GC L6 4S L | 1 |
| - | 880686T14 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236256 | GC L6 4S XL | GC L6 4S XL | 1 |
| - | 880686T16 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236259 | GC L6 4S XXL | GC L6 4S XXL | 1 |
| - | 880686T15 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236258 | GC L6 4S CXL | GC L6 4S CXL | 1 |
| - | 880686T17 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236260 | GC L6 4S CXXL | GC L6 4S CXXL | 1 |
| - | 880686T54 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236264 | GC L6 1.75 L | GC L6 1.75 L | 1 |
| - | 880686T55 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236265 | GC L6 1.75 XL | GC L6 1.75 XL | 1 |
| - | 880686T56 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236266 | GC L6 1.75 XXL | GC L6 1.75 XXL | 1 |
| - | 880686T57 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236267 | GC L6 1.75 CXL | GC L6 1.75 CXL | 1 |
| - | 880686T58 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236269 | GC L6 1.75 CXL | GC L6 1.75 CXL | 1 |
| - | 880686T59 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236270 | GC L6 1.75 CXXL | GC L6 1.75 CXXL | 1 |
| 1 | 880687T01 | GEAR HOUSING ASSEMBLY Basic Used with 5/16 Inch Shift Crank | 1 | |
| 1 | 8M0056631 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 1 | 8M0046215 | 曲柄 换挡1/4枢轴销 配1/4英寸换挡曲柄 | CRANK, Shifter 1/4 Pivot Pin Used with 1/4 Inch Shift Crank | 1 |
| 1 | 8M0220880 | 曲柄，换挡器1/4枢轴销 | CRANK, Shifter 1/4 Pivot Pin | 1 |
| 2 | 821526001 | 填充块 | FILLER BLOCK | 1 |
| 2 | 8M0010459 | 填充块 | FILLER BLOCK | 1 |
| 3 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 4 | 826134Q | 阳极块 | ANODE | 2 |
| 5 | 4000333 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 1 |
| 6 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 7 | 79953A04 | 塞组件(.375-16×.250) | PLUG ASSEMBLY (.375-16 x .250) | 1 |
| 8 | 830749 | 密封件 | SEAL | 1 |
| 8 | 8M0204693 | 放油螺塞密封件 | SEAL Drain Plug | 1 |
| 9 | 76214T5 | 阳极套件 | ANODE KIT | 1 |
| 9 | 76214Q5 | 阳极套件 | ANODE KIT | 1 |
| 10 | 806327 | 螺钉(.437-14 x 1.750) | SCREW (.437-14 x 1.750) | 1 |
| 10 | 8M0204686 | 螺钉 | SCREW | 1 |
| 11 | 8245191 | 固定座 | RETAINER | 1 |
| 12 | 881866 | 接头 | FITTING | 1 |
| 13 | 880703A1 | 盖总成 | COVER ASSEMBLY | 1 |
| 13 | 8M0047129 | 盖总成 | COVER ASSEMBLY | 1 |
| 13 | 8M0047129 | 盖总成 | COVER ASSEMBLY | 1 |
| 14 | 8164641 | 油封 | SEAL Oil | 1 |
| 14 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 15 | 896522 | O型圈(799×.103) | O-RING (799 x .103) | 1 |
| 16 | 8M0046563 | 挡圈 | RING Retaining | 1 |
| 17 | 40011128 | 不锈钢螺钉(M6x20) | SCREW (M6 x 20) Stainless Steel | 4 |
| 17 | 8M0204741 | 六角带垫大帽螺钉(M6x1.0x20) | SCREW (M6 x 1.0 x 20) Hex Wash HD | 4 |
| 18 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| 19 | 880729 | 衬垫 | GASKET | 1 |
| 20 | 824145 | 换档轴 | SHIFT SHAFT | 1 |
| 21 | NSS | 不单独销售 小齿轮13齿 | NOT SOLD SEPARATE Pinion Gear 13 Teeth | 1 |
| 22 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 23 | 92721 | 垫圈(.965×0.630) | WASHER (.965 x .630) | 1 |
| 24 | 42647A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 25 | 888572 | 驱动轴 | DRIVESHAFT | 1 |
| 25 | 888573 | 驱动轴 | DRIVESHAFT | 1 |
| 25 | 888574 | 驱动轴 | DRIVESHAFT | 1 |
| 26 | 884327A02 | 垫片/轴承组件 | SHIM/BEARING ASSEMBLY | 1 |
| 27 | 38657A1 | 垫片组 | SHIM ASSEMBLY | AR |
| 27 | 8M0063268 | 垫片组 | SHIM SET | AR |
| 28 | NSS | 不单独销售 滚子轴承组件 | NOT SOLD SEPARATE Roller Bearing Assembly | 1 |
| 29 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 30 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 31 | NSS | 不单独销售 滚子轴承组件 | NOT SOLD SEPARATE Roller Bearing Assembly | 1 |
| 32 | 817275A09 | 水泵壳体-总成 | HOUSING Water Pump-Complete | 1 |
| 33 | 861415A1 | 密封套件 | SEAL KIT | 1 |
| 34 | 40011128 | 不锈钢螺钉(M6x20) | SCREW (M6 x 20) Stainless Steel | 4 |
| 34 | 8M0204741 | 六角带垫大帽螺钉(M6x1.0x20) | SCREW (M6 x 1.0 x 20) Hex Wash HD | 4 |
| 35 | 43026T2 | 叶轮 | IMPELLER | 1 |
| 36 | 8172761 | 面板 | FACEPLATE | 1 |
| 36 | 8M0204709 | 面板 | FACEPLATE | 1 |
| 37 | 880719 | 挡圈 | RING Retaining | 1 |
| 38 | 8M0007131 | 油封座组件 | CARRIER ASSEMBLY Oil Seal | 1 |
| 39 | 896523 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 39 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 40 | NSS | 不单独销售 油封 | NOT SOLD SEPARATE Oil Seal | 1 |
| 41 | NSS | 不单独销售 油封 | NOT SOLD SEPARATE Oil Seal | 1 |
| 42 | 8M0032833 | 键 | KEY | 1 |
| 42 | 8M0204723 | 键 | KEY | 1 |
| 43 | 8172771 | 水泵上垫片 | GASKET Water Pump, Upper | 1 |
| 44 | 430331 | 衬垫 | GASKET | 1 |
| 45 | 43585 | 联轴器 | COUPLING | 1 |
| 46 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 46 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 47 | NSS | 不单独销售 滚柱轴承 | NOT SOLD SEPARATE Roller Bearing | 1 |
| 48 | 8M0053110 | 垫片组 | SHIM SET | 1 |
| 48 | 8M0063267 | 垫片组 | SHIM SET | 1 |
| 49 | 48939A2 | 圆锥滚子轴承 | BEARING Taper Roller | 1 |
| 49 | 8M0146553 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 50 | NSS | NOT SOLD SEPARATE CUP | 1 | |
| - | 830749A01 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| - | 43026Q06 | 水泵叶轮维修套件 | REPAIR KIT Water Pump Impeller | 1 |
| - | 8M0100526 | 水泵叶轮维修套件 | REPAIR KIT Water Impeller | 1 |
| - | 817275A08 | 水泵上修包 | REPAIR KIT Water Pump-Upper | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 880686T13 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236255 | GC L6 4S L | GC L6 4S L | 1 |
| - | 880686T14 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236256 | GC L6 4S XL | GC L6 4S XL | 1 |
| - | 880686T16 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236259 | GC L6 4S XXL | GC L6 4S XXL | 1 |
| - | 880686T54 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236264 | GC L6 1.75 L | GC L6 1.75 L | 1 |
| - | 880686T55 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236265 | GC L6 1.75 XL | GC L6 1.75 XL | 1 |
| - | 880686T56 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 8M0236266 | GC L6 1.75 XXL | GC L6 1.75 XXL | 1 |
| 1 | 8M0056631 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 2 | NSS | 不单独销售 塞 | NOT SOLD SEPARATE Plug | 1 |
| 3 | 8M0046215 | 曲柄，换挡器1/4枢轴销 | CRANK, Shifter 1/4 Pivot Pin | 1 |
| 3 | 8M0220880 | 曲柄，换挡器1/4枢轴销 | CRANK, Shifter 1/4 Pivot Pin | 1 |
| 4 | 19755T7 | 阀芯总成 | SPOOL ASSEMBLY | 1 |
| 4 | 8M0235940 | 阀芯总成 | SPOOL ASSY | 1 |
| 5 | NSS | 不单独销售线轴 | NOT SOLD SEPARATE Spool | 1 |
| 6 | 469501 | 开口销 | COTTER PIN | 1 |
| 7 | NSS | 不单独销售 调节套筒 | NOT SOLD SEPARATE Sleeve Adjusting | 1 |
| 8 | 892595A05 | 前进/小齿轮组 | GEAR SET Forward/Pinion | 1 |
| 8 | 892595A04 | 前进/小齿轮组 | GEAR SET Forward/Pinion | 1 |
| 9 | 8M0063270 | 垫片组 | SHIM SET | AR |
| 10 | 884323T01 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 10 | 8M0142836 | 圆锥滚子轴承(外圈/内圈) | BEARING Roller Taper (Cup/Cone) | 1 |
| 11 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 12 | 8M0051043 | 挡圈 | RING Retaining | 1 |
| 13 | 8M0053823 | 止推垫圈(内径1.50×外径2.046) | WASHER Thrust, (1.50 ID x 2.046 OD) | 1 |
| 14 | 884325T01 | 圆锥滚子轴承组件 | BEARING ASSEMBLY Roller-Tappered | 1 |
| 14 | 8M0142835 | 圆锥滚子轴承(外圈/内圈) | BEARING Roller Taper (Cup/Cone) | 1 |
| 15 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 16 | 880714T | 离合器 | CLUTCH | 1 |
| 17 | 30893 | 弹簧 | SPRING | 1 |
| 18 | 828356 | 定位销 | PIN Detent | 1 |
| 19 | 8M0069774 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 19 | 8M0140446 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 20 | 8M0084681 | 十字销 | PIN Cross | 1 |
| 20 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 21 | 880695A01 | 倒车齿轮总成 | GEAR ASSEMBLY Reverse | 1 |
| 21 | 8M0142891 | 倒挡齿轮24齿 | GEAR Reverse, 24T | 1 |
| 21 | 880707A01 | 倒挡齿轮 | GEAR Reverse | 1 |
| 21 | 8M0118363 | 倒车齿轮 21齿 | GEAR Reverse, 21T | 1 |
| 22 | 880699 | 推力环 | THRUST RING | 1 |
| 23 | 8M0064306 | 止推隔套 | SPACER Thrust | 1 |
| 24 | 8M0076745 | 垫片组 | SHIM SET | 1 |
| 24 | 8M0050423 | 垫片 .020 | WASHER .020 | AR |
| 24 | 8M0050424 | 垫片 .022 | WASHER .022 | AR |
| 24 | 8M0050425 | 垫片 .024 | WASHER .024 | AR |
| 24 | 8M0050427 | 垫片 .026 | WASHER .026 | AR |
| 24 | 8M0050428 | 垫片 .028 | WASHER .028 | AR |
| 24 | 8M0050429 | 垫片 .030 | WASHER .030 | AR |
| 24 | 8M0050430 | 垫片 .032 | WASHER .032 | AR |
| 24 | 8M0050431 | 垫片 .034 | WASHER .034 | AR |
| 24 | 8M0050432 | 垫片 .036 | WASHER .036 | AR |
| 24 | 8M0050433 | 垫片 0.038 | WASHER .038 | AR |
| 24 | 8M0050434 | 垫片 0.040 | WASHER .040 | AR |
| 24 | 8M0050435 | 垫片 0.042 | WASHER .042 | AR |
| 24 | 8M0050436 | 垫片 0.044 | WASHER .044 | AR |
| 24 | 8M0050437 | 垫片 0.046 | WASHER .046 | AR |
| 24 | 8M0050438 | 垫片 0.048 | WASHER .048 | AR |
| 24 | 8M0050439 | 垫片 0.050 | WASHER .050 | AR |
| 25 | 8M0083392 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 26 | 884329T | 滚珠轴承 | BEARING Ball | 1 |
| 26 | 8M0142873 | 滚珠轴承 | BEARING Ball | 1 |
| 27 | 888483 | 油封 | SEAL Oil | 1 |
| 27 | 8M0204700 | 油封 | SEAL Oil | 1 |
| 28 | 884330T01 | 圆锥轴承组件 | BEARING ASSEMBLY Taper | 1 |
| 28 | 8M0148319 | 圆锥滚子轴承(外圈/内圈) | BEARING Roller Taper Cup/Cone | 1 |
| 29 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 30 | 888483 | 油封 | SEAL Oil | 1 |
| 30 | 8M0204700 | 油封 | SEAL Oil | 1 |
| 31 | 896524 | O型圈(3.850×.210) | O-RING (3.850 x .210) | 1 |
| 31 | 8M0142840 | O型圈(3.85×0.210) | O-RING (3.85 x 0.210) | 1 |
| 32 | 880717A01 | 螺钉/密封套件 .38英寸长 | SCREW/SEAL KIT .38 Inch Long | 1 |
| 32 | 8M0077071 | 螺钉/密封套件 .75英寸长 | SCREW/SEAL KIT .75 Inch Long | 1 |
| 33 | 830749 | 密封件 | SEAL | 1 |
| 33 | 8M0204693 | 放油螺塞密封件 | SEAL Drain Plug | 1 |
| 34 | 880697 | 键槽垫圈 | KEYED WASHER | 1 |
| 35 | 8M2011027 | 固定座 | RETAINER | 1 |
| 35 | 8M2000347 | 固定座 | RETAINER | 1 |
| - | 830749A01 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 887936T04 | 飞轮盖 | COVER Flywheel | 1 |
| 2 | 834985 | 护孔环 | GROMMET | 4 |
| 2 | 8M0190980 | 护孔环 | GROMMET | 4 |
| 3 | 893307A01 | 出管总成 | TUBE OUTLET ASSEMBLY | 1 |
| 3 | 8M0035481 | 热风管总成 | TUBE ASSEMBLY Hot Air Duct | 1 |
| 4 | 893389 | 软管(内径65) | HOSE (65 Inside Diameter) | 1 |
| 4 | 8M0035481 | 热风管总成 | TUBE ASSEMBLY Hot Air Duct | 1 |
| 5 | 893390 | 软管(内径60) | HOSE (60 Inside Diameter) | 1 |
| 5 | 8M0035481 | 热风管总成 | TUBE ASSEMBLY Hot Air Duct | 1 |
| 6 | 893342 | 卡箍 | CLAMP | 2 |
| 7 | 893391 | 软管套管 | HOSE SLEEVE | 1 |
| 7 | 8M0035481 | 热风管总成 | TUBE ASSEMBLY Hot Air Duct | 1 |
| 8 | 8079923 | 软管夹端盖 | COVER Hose Clamp End | 2 |
| 8 | 8M0074364 | 软管夹盖 | COVER Hose Clamp | 2 |
| 9 | 893342 | 卡箍 | CLAMP | 2 |
| 10 | 898022 | 机油尺 | DIPSTICK Oil | 1 |
| 11 | 888517 | 销 | PIN | 2 |
| 12 | 888991T03 | 电子节气门控制总成 | THROTTLE CONTROL ASSEMBLY Electronic | 1 |
| 12 | 8M0113515 | 节气门控制器 | THROTTLE CONTROL | 1 |
| 13 | 880576005 | 隔离器 | ISOLATOR | 1 |
| 13 | 8M0113513 | ETC隔离器 | ISOLATOR-ETC | 1 |
| 14 | 815504256 | 蜗杆卡箍 | CLAMP Worm Gear | 1 |
| 15 | 88552550 | 不锈钢螺钉 (M6 x 50 mm) | SCREW (M6 x 50 mm) Stainless Steel | 4 |
| 16 | 884353 | 支架 | BRACKET | 2 |
| 17 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 2 |
| 18 | 892383T05 | 进气总成 | INTAKE ASSEMBLY Air | 1 |
| 18 | 892383T06 | 进气总成 | INTAKE ASSEMBLY Air | 1 |
| 19 | 8349851 | 护孔环 | GROMMET | 1 |
| 20 | 856954 | 衬套 | BUSHING | 1 |
| 21 | 893318T01 | 空气滤清器 | FILTER Air | 1 |
| 21 | 893318T02 | 空气滤清器 | FILTER Air | 1 |
| 22 | 895842 | 卡箍 | CLAMP | 1 |
| 23 | 893317 | 衬垫 | GASKET | 1 |
| 24 | 892383001 | 谐振器 | RESONATOR | 1 |
| 24 | 8M0007183 | 谐振器 | RESONATOR | 1 |
| 25 | 888988027 | 卡箍 | CLAMP | 1 |
| 26 | 893314002 | 进气管 | DUCT Inlet | 1 |
| 27 | 88552525 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 1 |
| 27 | 8M0103807 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 1 |
| 28 | 65567 | 不锈钢垫圈(0.265x0.750x0.048) | WASHER (.265 x .750 x .048) Stainless Steel | 1 |
| 29 | 888988016 | 卡箍（96.5毫米） | CLAMP (96.5 mm) | 1 |
| 30 | 884408A07 | 电动增压控制阀套件 | VALVE KIT Control - Electric Boost | 1 |
| 30 | 884408A08 | 电动增压控制阀套件 | VALVE KIT Control - Electric Boost | 1 |
| 31 | 887939007 | 增压阀安装板 | PLATE Boost Valve Mounting | 1 |
| 32 | 892079 | O型圈 | O-RING | 1 |
| 33 | 88552520 | 螺钉(M6 x 20毫米)不锈钢 | SCREW (M6 x 20 mm) Stainless Steel | 4 |
| 33 | 8M0103806 | 螺钉(M6 x 20毫米)不锈钢 | SCREW (M6 x 20 mm) Stainless Steel | 4 |
| 34 | 833155 | 护孔环 | GROMMET | 2 |
| 35 | 8502341 | 衬套 | BUSHING | 2 |
| 36 | 859376 | 卡扣 | CLIP | 1 |
| 37 | 88552635 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 2 |
| 37 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 2 |
| 38 | 817274 | 垫圈(0.344×1.00×0.063)不锈钢 | WASHER (.344 x 1.00 x .063) Stainless Steel | 2 |
| 39 | 887937006 | 前部软管 | HOSE Front | 1 |
| 40 | 888988002 | 卡箍(57.5毫米 前电子增压控制) | CLAMP (57.5 mm) Front Electronic Boost Control | 2 |
| 41 | 887938003 | 后管 | TUBE Rear | 1 |
| 42 | 888988004 | 卡箍(62.0毫米 后电子增压控制) | CLAMP (62.0 mm) Rear Electronic Boost Control | 2 |
| 43 | 881879A16 | 皮托管传感器总成 | SENSOR ASSEMBLY Pitot | 1 |
| 43 | 881879T25 | 皮托管传感器总成 | SENSOR ASSEMBLY Pitot | 1 |
| 44 | 892403 | 接头 | FITTING | 1 |
| 44 | 8M0207782 | 直通接头 | FITTING Straight | 1 |
| 45 | 883066 | 夹子 (.865) | CLIP (.865) | 1 |
| 46 | 8589781 | 燃油软管卡箍（适用处使用） | CLIP Fuel Hose (Use where Applicable) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 885365T03 | 加长护套总成-左右舷-黑色 | CHAP ASSEMBLY Long - Port and Starboard, Black | 1 |
| - | 8M0090481 | 长型左右舷护板总成(冷融合) | CHAP ASSEMBLY Long - Port and Starboard, Cold Fusion | 1 |
| - | 8M0090482 | 长型左右舷护板总成(暖融合) | CHAP ASSEMBLY Long - Port and Starboard, Warm Fusion | 1 |
| - | 8M0119295 | 长型左右舷护板总成(珍珠融合) | CHAP ASSEMBLY Long - Port and Starboard, Pearl Fusion | 1 |
| - | 885363T04 | 超长/特超长护套总成-左右舷 | CHAP ASSEMBLY X-Long/XX-Long - Port and Starboard | 1 |
| - | 8M0090483 | 加长/超长型左右舷护板总成(冷融合) | CHAP ASSEMBLY X-Long/XX-Long - Port and Starboard, Cold Fusion | 1 |
| - | 8M0090484 | 加长/超长型左右舷护板总成(暖融合) | CHAP ASSEMBLY X-Long/XX-Long - Port and Starboard, Warm Fusion | 1 |
| - | 8M0119294 | 加长/超长型左右舷护板总成(珍珠融合) | CHAP ASSEMBLY X-Long/XX-Long - Port and Starboard, Pearl Fusion | 1 |
| 1 | NSS | 左舷下部护板(长型)不单独销售 | NOT SOLD SEPARATE Lower Port Chap (Long) | 1 |
| 1 | NSS | 左舷下部护板(加长-超长型)不单独销售 | NOT SOLD SEPARATE Lower Port Chap (X-Long-XX-Long) | 1 |
| 2 | NSS | 右舷下部护板(长型)不单独销售 | NOT SOLD SEPARATE Lower Starboard Chap (Long) | 1 |
| 2 | NSS | 右舷下部护板(加长-超长型)不单独销售 | NOT SOLD SEPARATE Lower Starboard Chap (X-Long-XX-Long) | 1 |
| 3 | 892073002 | 肩部螺钉(M6)长护板用 | SHOULDER SCREW (M6) Long Chaps | 8 |
| 3 | 892073002 | 肩部螺钉(M6)加长-超长护板用 | SHOULDER SCREW (M6) X-Long - XX-Long Chaps | 12 |
| 4 | 898033 | 卡扣 | CLIP | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 88334A2 | 防腐电极套件 | MERCATHODE KIT | 1 |
| 2 | 42600A09 | 防腐电极总成 | MERCATHODE ASSEMBLY | 1 |
| 3 | 22793 | 螺丝(#9-14x0.875) | SCREW (#9-14 x .875) | 2 |
| 4 | 30164 | 垫圈(0.192x0.375x0.0312)不锈钢 | WASHER (.192 x .375 x .0312) Stainless Steel | 2 |
| 5 | 45076 | 黄铜螺母(#10-32) | NUT (#10-32) Brass | 4 |
| 6 | 72958A5 | 电极总成 | ELECTRODE ASSEMBLY | 1 |
| 7 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 7 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 8 | 87698 | 螺丝(#10-16 x 1.250)不锈钢 | SCREW (#10-16 x 1.250) Stainless Steel | 2 |
| 9 | 72957A5 | 阳极总成 | ANODE ASSEMBLY | 1 |
| 9 | 8M0181304 | 阳极总成 | ANODE ASSY | 1 |
| 10 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 10 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 11 | 87698 | 螺丝(#10-16 x 1.250)不锈钢 | SCREW (#10-16 x 1.250) Stainless Steel | 2 |
| 12 | 79091 | 保险丝20安培 | FUSE 20 Ampere | 1 |
| 12 | 8M0207796 | 保险丝20安培 | FUSE 20 AMP | 1 |
| 13 | 95084A10 | 电缆总成(5.00英寸)红色 | CABLE ASSEMBLY (5.00 Inches) Red | 1 |
| 13 | 8M0207788 | 拉线总成 | CABLE ASSEMBLY | 1 |
| 14 | 95084A13 | 电缆总成(64.00英寸) | CABLE ASSEMBLY (64.00 Inches) | 1 |
| 15 | 79138A8 | 电缆总成(72.00英寸)黑色 | CABLE ASSEMBLY (72.00 Inches) Black | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 885546002 | 密封件 | SEAL | 1 |
| 1 | 8M0109275 | 密封环 | RING - SEAL | 1 |
| 2 | 884887T04 | 安装支架 | MOUNT CRADLE | 1 |
| 2 | 884887T07 | 支架安装总成 | CRADLE ASSEMBLY Mount | 1 |
| 3 | 884888003 | 密封件 | SEAL | 1 |
| 3 | 8M0060014 | 密封件 | SEAL | 1 |
| 4 | 888538T | 后安装座 | MOUNT Rear | 2 |
| 4 | 8M0103708 | 后安装座 | MOUNT Rear | 2 |
| 5 | 888535T | 前安装座 | MOUNT Front | 2 |
| 5 | 8M0103365 | 前安装座 | MOUNT Front | 2 |
| 6 | 889745030 | 螺钉（M12×30） | SCREW (M12 x 30) | 12 |
| 7 | 896531090 | 螺钉（M16×90） | SCREW (M16 x 90) | 4 |
| 7 | 8M0103832 | 螺钉 | SCREW | 4 |
| 8 | 12602002 | 护孔环 | GROMMET | 1 |
| 9 | 40011126 | 不锈钢螺丝(M6 x 13) | SCREW (M6 x 13) Stainless Steel | 1 |
| 10 | 830756109 | 软管（57英寸散装裁至35英寸） | HOSE (57.00 Inches Bulk) Cut to 35 Inches | 1 |
| 10 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 11 | 895797 | 示踪管接头 | FITTING Telltale | 1 |
| 11 | 895797001 | 接头 | FITTING | 1 |
| 12 | 895851 | 卡箍(8英寸) | CLAMP (8.00 Inches) | 2 |
| 13 | 73194 | 滚销(.125 x 1.12) | PIN Roll (.125 x 1.12) | 2 |
| 14 | 880649002 | 倾斜锁杆 | LEVER Tilt Lock | 2 |
| 15 | 47968 | 弹簧 | SPRING | 2 |
| 16 | 889540A03 | 离合器套件 | CLUTCH KIT | 1 |
| 17 | 880651002 | 倾斜锁止支架 | BRACKET Tilt Lock | 1 |
| 17 | 8M0109693 | 倾斜锁止支架 | BRACKET Tilt Lock | 1 |
| 18 | 889539001 | 倾斜锁止垫 | PAD Tilt Lock | 1 |
| 18 | 8M0076907 | 倾斜锁止垫 | PAD Tilt Lock | 1 |
| 19 | 880650003 | 倾斜锁定轴 | SHAFT Tilt Lock | 1 |
| 20 | 889546 | 螺钉 (M5 x 10) | SCREW (M5 x 10) | 1 |
| 21 | 8806641 | 轴承（0.625英寸） | BEARING (.625 Inch) | 2 |
| 22 | 888590002 | 升降位置传感器 | SENSOR Trim Position | 1 |
| 23 | 889547 | 螺丝(M5 x 30) | SCREW (M5 x 30) | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 892126A01 | 适配板套件 | ADAPTER PLATE KIT | 1 |
| 1 | 892126A03 | 适配板套件 | ADAPTER PLATE KIT | 1 |
| 2 | 892228 | 定位销 | PIN Dowel | 8 |
| 3 | 896951 | 堵头（24毫米） | PLUG (24 mm) | 1 |
| 4 | 884462 | 水封 | SEAL Water | 2 |
| 5 | 887930 | O型圈 | O-RING | 2 |
| 6 | 884461 | 油封 | SEAL Oil | 1 |
| 6 | 8M0033928 | 油封 | SEAL Oil | 1 |
| 7 | 884422A07 | 油泵泄压阀 | PRESSURE RELIEF VALVE Oil Pump | 1 |
| 8 | 884457 | 油泵驱动链条 | CHAIN Oil Pump Drive | 1 |
| 8 | 8M6002692 | 油泵驱动链条 | CHAIN Oil Pump Drive | 1 |
| 9 | 892491 | 垫圈 | WASHER | 1 |
| 10 | 892165 | 螺母 | NUT | 1 |
| 11 | 884458T06 | 油泵驱动轴 | DRIVESHAFT Oil Pump | 1 |
| 11 | 8M0217265 | 机油泵 | OIL PUMP | 1 |
| 12 | 895791 | O型圈 | O-RING | 2 |
| 12 | 8M0034912 | O型圈 3.78×21.32 | O-RING 3.78 X 21.32 | 2 |
| 13 | 884456 | 从动链轮 | SPROCKET Driven | 1 |
| 14 | 884418A1 | 油泵驱动张紧器总成 | TENSIONER ASSEMBLY Oil Pump Drive | 1 |
| 15 | 884446T04 | 油泵总成 | PUMP ASSEMBLY Oil | 1 |
| 16 | 892455065 | 螺钉 | SCREW | 5 |
| 17 | 892335001 | 导油板 | DEFLECTOR Oil | 1 |
| 18 | 88552516 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 2 |
| 18 | 8M0103805 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 2 |
| 19 | 888819002 | 排水罩 | DRAIN Cowl | 2 |
| 20 | 888163 | 护孔环 | GROMMET | 1 |
| 21 | 884477A01 | 止回阀总成 | CHECK VALVE ASSEMBLY | 1 |
| 21 | 8M0062064 | 止回阀总成 | CHECK VALVE ASSY. | 1 |
| 22 | 896213 | 泄放接头 | FITTING Dump | 1 |
| 22 | 8M0092321 | EDP黑色接头 | FITTING EDP Black | 1 |
| 23 | 846594 | O型圈 (1.239 x .070) 黑色 | O-RING (1.239 x .070) Black | 1 |
| 23 | 8M0092943 | O型圈 橙色 | O-RING Orange | 1 |
| 24 | 88552512 | 不锈钢螺钉 (M6 x 12 mm) | SCREW (M6 x 12 mm) Stainless Steel | 1 |
| 24 | 8M0103804 | 不锈钢螺钉 (M6 x 12 mm) | SCREW (M6 x 12 MM) Stainless Steel | 1 |
| 25 | 884549 | 下部通风软管 | HOSE Vent-Lower | 1 |
| 25 | 8M0087108 | 软管 | HOSE | 1 |
| 26 | 884546 | 护孔环 | GROMMET | 1 |
| 27 | 888523001 | 卡扣 | CLIP | 1 |
| 28 | 892240 | 燃油进油管至燃油供应模块 | HOSE Fuel into Fuel Supply Module | 1 |
| 28 | 8M0087118 | 软管 | HOSE | 1 |
| 29 | 884546 | 护孔环 | GROMMET | 1 |
| 30 | 889617001 | 衬垫 | GASKET | 1 |
| 31 | 8877551 | 燃油通风软管 | HOSE Fuel-Vent | 1 |
| 31 | 8M0225335 | 燃油通风软管 | HOSE FUEL VENT | 1 |
| 32 | 884545T01 | 通风罐总成 | VENT CANISTER ASSEMBLY | 1 |
| 32 | 8M0175814 | 通气罐总成 | CANISTER-VENT ASY | 1 |
| 33 | 853947 | 卡扣 | CLIP | 1 |
| 34 | 895775A01 | 燃油管路净化阀总成 | VALVE ASSEMBLY Fuel Line Purge | 1 |
| 34 | 8M0126303 | 净化通气总成 | PURGE VENT ASSY | 1 |
| 35 | 884546 | 护孔环 | GROMMET | 1 |
| - | 880552A06 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 880552A07 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 895247A06 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 895247R06 | RM L6 GEN1 VERADO | RM L6 GEN1 VERADO | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 880668001 | 双头螺柱（M10×1.5） | STUD (M10 x 1.5) | 10 |
| 1 | 8M0022158 | 双头螺柱(M10x205) | STUD (M10 x 205) | 10 |
| 2 | 888997001 | 螺柱 | STUD | 1 |
| 2 | 8M0022162 | 双头螺栓(M10×60) | STUD (M10 x 60) | 1 |
| 3 | 878187 | 爆震传感器总成 | SENSOR ASSEMBLY Knock | 2 |
| 3 | 8M6003194 | 爆震传感器总成 | SENSOR ASSEMBLY Knock | 2 |
| 4 | 892086035 | 螺钉(M10 x 35) | SCREW (M10 x 35) | 2 |
| 5 | 4002319 | 垫圈 | WASHER | 2 |
| 6 | 884268A1 | 机油喷嘴总成 | JET ASSEMBLY Oil | 6 |
| 7 | 888988008 | 卡箍(34.6毫米) | CLAMP (34.6 MM) | 2 |
| 7 | 8M0187145 | 卡箍 | CLAMP | 2 |
| 8 | 885544002 | 软管 | HOSE | 1 |
| 9 | 896094A01 | 接头总成 | FITTING ASSEMBLY | 1 |
| 10 | 888814 | O型圈(0.351 x 0.072) | O-RING (.351 x .072) | 1 |
| 10 | 896699 | O型圈（1.78毫米 x 0.08毫米） | O-RING (1.78 mm x .08 mm) | 1 |
| 11 | 85978571 | 水管(散装52英寸)-接水压传感器-裁切至21.5英寸 | TUBING (52.00 Inches Bulk) To Water Pressure Sensor - Cut to 21.5 Inches | 1 |
| 12 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 13 | 881879A20 | 水压传感器总成 | SENSOR ASSEMBLY Pressure Water Pressure | 1 |
| 13 | 881879T26 | 传感器 压力 | SENSOR Pressure | 1 |
| 14 | 888849001 | 双头螺栓(M8x49) | STUD (M8 x 49) | 2 |
| 14 | 8M0000274 | 双头螺栓(M8x44) | STUD (M8 x 44) | 2 |
| 15 | 826365 | 螺母 (M8) | NUT (M8) | 2 |
| 16 | 885517A05 | 接头总成 | FITTING ASSEMBLY | 1 |
| 17 | 892077 | O型圈 | O-RING | 1 |
| - | 880552A06 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 880552A07 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 895247A06 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 895247R06 | RM L6 GEN1 VERADO | RM L6 GEN1 VERADO | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 880552A06 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 880552A07 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 62701 | 接头总成O型圈 | O-RING Fitting Assembly | 2 |
| - | 90196 | O型圈(.921 x .139)油塞总成 | O-RING (.921 x .139) Oil Plug Assembly | 1 |
| - | 8M0204673 | O型圈 .921 x .139 | O-Ring .921 x .139 | 1 |
| - | 846594 | O型圈 (1.239 x .070) 黑色适配板排放接头 | O-RING (1.239 x .070) Black Adaptor Plate Dump Fitting | 1 |
| - | 8M0092943 | O型圈 橙色 | O-RING Orange | 1 |
| - | 846594 | O型圈 (1.239 x .070) 黑色机油吸油管 | O-RING (1.239 x .070) Black Oil Pickup | 1 |
| - | 8M0092943 | O型圈 橙色 | O-RING Orange | 1 |
| - | 8805251 | 油封(主轴承顶部) | SEAL Top Main Bearing | 1 |
| - | 8M0032912 | 密封件 | SEAL | 1 |
| - | 895374006 | 衬垫 气缸盖至缸体 | GASKET Head Cylinder Head to Block | 1 |
| - | 8M0033476 | 衬垫 缸盖 | GASKET Head | 1 |
| - | 880624003 | 衬垫 缸体至适配器 | GASKET Block to Adaptor | 1 |
| - | 880629 | 排气管密封件 | SEAL Exhaust Tube | 1 |
| - | 880631001 | O型圈 橙色张紧器盖 | O-RING Orange Tensioner Cap | 1 |
| - | 8M0237361 | O型圈 | O-RING | 1 |
| - | 898836 | 棕色张紧器盖O型圈 | O-RING Brown Tensioner Cap | 1 |
| - | 8M0237361 | O型圈 | O-RING | 1 |
| - | 884409 | O型圈 缸体机油定位销 | O-RING Block Oil Dowel | 1 |
| - | 884423 | O型圈 缸体机油定位销 | O-RING Block Oil Dowel | 1 |
| - | 884461 | 油封 适配板 | SEAL Oil Adaptor Plate | 1 |
| - | 8M0033928 | 油封 | SEAL Oil | 1 |
| - | 884462 | 水封 适配板 | SEAL Water Adaptor Plate-Water | 2 |
| - | 887930 | O型圈 适配板 | O-RING Adaptor Plate | 2 |
| - | 888593 | 油封 排油管塞 | SEAL Oil Drain Tube Plug | 1 |
| - | 8M0188614 | 放油螺塞密封件 | SEAL Drain Plug | 1 |
| - | 889617001 | 适配板垫片 | GASKET Adaptor Plate | 1 |
| - | 889618001 | 衬垫 油底壳 | GASKET Oil Sump | 1 |
| - | 892077 | O型圈 缸体接头总成 | O-RING Block Fitting Assembly | 1 |
| - | 892117 | 密封件 歧管壳体 | SEAL Manifold Housing | 1 |
| - | 892445 | O型圈 水管 | O-RING Water Tube | 1 |
| - | 892446 | O型圈 (14 X 1.78 MM) 适配板接头 | O-RING (14 X 1.78 MM) Adaptor Plate Fitting | 1 |
| - | 895791 | O型圈 机油泵驱动轴 | O-RING Oil Pump Driveshaft | 2 |
| - | 8M0034912 | O型圈 3.78×21.32 | O-RING 3.78 X 21.32 | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 896156A01 | 配平油缸套件 | TRIM CYLINDER KIT | 1 |
| 1 | 8M0118298 | 配平油缸套件 | TRIM CYLINDER KIT | 1 |
| 2 | 896157A01 | 升降杆套件 | TRIM ROD KIT | 1 |
| 2 | 8M0118299 | 升降杆套件 | TRIM ROD KIT | 1 |
| 3 | 896158A01 | O型圈套件 | O-RING KIT | 1 |
| 4 | 896159A01 | 活塞套件 | PISTON KIT | 1 |
| 5 | 896166A01 | 配平歧管套件 | MANIFOLD KIT Trim | 1 |
| 6 | 896165A01 | 配平止回套件PO型 | CHECK KIT Trim PO | 1 |
| 7 | 896160A01 | O型圈套件 | O-RING KIT | 1 |
| 8 | 8M0010183 | O型圈 | O-RING | 1 |
| 8 | 8M0204938 | O型圈 | O-RING | 1 |
| 9 | 896163A01 | 配平泵套件 | PUMP KIT Trim | 1 |
| 10 | 896164A01 | 配平过滤器套件 | TRIM FILTER KIT | 1 |
| 11 | 896162A01 | 配平颈套件 | TRIM NECK KIT | 1 |
| 12 | 895854A01 | O型圈套件 | O-RING KIT | 1 |
| 13 | 893419 | 盖套件 | CAP KIT | 1 |
| 14 | 893420A01 | 手动释放套件 | MANUAL RELEASE KIT | 1 |
| 14 | 8M0224397 | 手动释放套件 | MANUAL RELEASE KIT | 1 |
| 15 | 8M0224410 | O型圈套件 | ORING KIT | 1 |
| 16 | 8M0184377 | 卡环 | SNAP RING | 1 |
| 17 | 893408A01 | 配平销套件 | PIN KIT Trim | 1 |
| 18 | 896161A01 | 配平电机套件 | TRIM MOTOR KIT | 1 |
| 18 | 896161A02 | 配平电机套件 | TRIM MOTOR KIT | 1 |
| 18 | 896161A02 | 配平电机套件 | TRIM MOTOR KIT | 1 |
| 19 | 896167A01 | 储液罐套件 | RESERVOIR KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | NSS | 艉板总成(不单独销售) | NOT SOLD SEPARATE Transom Assembly | 1 |
| 1 | 880652T02 | 基座 | PEDESTAL | 1 |
| 2 | 896500A01 | 转向油缸套件 | STEERING CYLINDER KIT | 1 |
| 3 | 893409 | 固定座 | RETAINER | 2 |
| 4 | 895853 | 垫圈 | WASHER | 4 |
| 5 | 88509530 | 螺钉 (M8 x 30) | SCREW (M8 x 30) | 4 |
| 6 | 889552 | -6 ORB转-6 ORFS接头(90度) | FITTING -6 ORB to -6 ORFS (90 Degree) | 1 |
| 7 | 889550 | 乙烯基放气帽 | CAP Bleeder - Vinyl | 2 |
| 8 | 880667 | 密封件 | SEAL | 1 |
| 9 | 8M0045604 | 转向油缸密封件套件 | SEAL KIT Steering Cylinder | 1 |
| 10 | 892524 | 接头 | FITTING | 2 |
| 11 | 8806621 | 轴承 | BEARING | 2 |
| 12 | 880661 | 密封件 | SEAL | 2 |
| 13 | 8806561 | 轴承 | BEARING | 2 |
| 14 | 8M0103373 | 转向头 | HEAD Steering | 1 |
| 15 | 8806551 | 轴承(1.25英寸) | BEARING (1.25 Inch) | 2 |
| 16 | 885094105 | 螺钉(M14x105) | SCREW (M14 x 105) | 6 |
| 17 | 885112 | 垫圈 | WASHER | 7 |
| 18 | 88238T23 | 拉线总成 | CABLE ASSEMBLY | 1 |
| 19 | 889545 | 垫圈 | WASHER | 6 |
| 20 | 4010720 | 螺钉(M8 x 20) | SCREW (M8 x 20) | 2 |
| 21 | 72397 | 垫圈 | WASHER | 2 |
| 22 | 8M0045157 | 导流板(黑色) | PLATE Deflector (Black) | 1 |
| 23 | 4000327 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 2 |
| 24 | 893404 | 阳极块 | ANODE | 4 |
| 24 | 8M0220986 | 配平阳极 | ANODE Trim | 4 |
| 25 | 880660T02 | 转向管 | TUBE Steering | 1 |
| 26 | 885111 | 定位销(0.375x0.875英寸) | PIN Dowel (.375 x .875) | 6/8 |
| 27 | 880658T03 | 动力升降总成 | POWER TRIM ASSEMBLY | 1 |
| 27 | 8M0118296 | 动力升降总成 | POWER TRIM ASSEMBLY | 1 |
| 28 | 895854 | O型圈 | O-RING | 1 |
| 29 | 880653 | 阳极块 | ANODE | 1 |
| 29 | 8M0220987 | 配平歧管阳极 | ANODE Trim Manifold | 1 |
| 30 | 889549 | 垫圈 | WASHER | 6 |
| 31 | 889543016 | 螺栓 | BOLT | 4 |
| 32 | 88510450 | 螺钉 | SCREW | 6 |
| 33 | 88238T24 | 拉线总成 | CABLE ASSEMBLY | 1 |
| 34 | 893405T | 盖板 | COVER | 1 |
| 35 | 880665T01 | 转向臂 | ARM Steering | 1 |
| 36 | 895390 | 倾斜销 | TILT PIN | 1 |
| 37 | 8M0038931 | 挡圈 | RING Retaining | 1 |
| 38 | NSS | 不单独销售-序列号覆膜标贴 | NOT SOLD SEPARATE Decal-Serial Overlaminate | 1 |
| 39 | 8M0038370 | 螺钉(0.500-20x5.50英寸) | SCREW (.500-20 x 5.50) | 4 |
| 40 | 28421 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 41 | 895062 | 垫圈 | WASHER | 4 |
| 42 | 82671117 | 螺母(.500-20) | NUT (.500-20) | 4 |
| 43 | 884889002 | 销 | PIN | 2 |
| 44 | 821539 | 三叶销 | PIN Trilobe | 2 |
| 45 | 895304 | 挡圈 | RING Retaining | 2 |
| 46 | 8M0085825 | 法兰轴颈轴承 | BEARING Flanged Journal | 4 |
| 47 | NSS | 不单独销售 | NOT SOLD SEPARATE | 2 |
| 48 | 8M0043059 | 警告标贴 | DECAL Warning | 1 |
| 49 | 8M0109756 | 艉板螺栓双螺母套件 | DOUBLE NUT KIT Transom Bolt | 1 |
| 50 | 8M0104274 | 六角螺母(.500-20)黄铜 | NUT (.500-20) HEX, Brass | 6 |
| 51 | 82671117 | 螺母(.500-20) | NUT (.500-20) | 2 |
| 52 | 28421 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 2 |
| 53 | 54012 | 垫圈(0.530×0.870×0.105不锈钢) | WASHER (.530 x .870 x .105) Stainless Steel | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0080199 | 动力转向泵套件(4英尺) | PUMP KIT Power Steering (4 Feet) | 1 |
| - | 8M0080200 | 动力转向泵套件(12英尺) | PUMP KIT Power Steering (12 Feet) | 1 |
| - | 8M0131262 | 动力转向泵套件(12英尺) | PUMP KIT Power Steering (12 Feet) | 1 |
| - | 8M0080201 | 动力转向泵套件(24英尺) | PUMP KIT Power Steering (24 Feet) | 1 |
| - | 8M0131263 | 动力转向泵套件(24英尺) | PUMP KIT Power Steering (24 Feet) | 1 |
| 1 | NSS | 不单独销售 泵 | NOT SOLD SEPARATE PUMP | 1 |
| 2 | 892485003 | 泵盖 | CAP Pump | 1 |
| 3 | NSS | 不单独销售 油液类型标贴 | NOT SOLD SEPARATE DECAL, Fluid Type | 1 |
| 4 | 893364A05 | 动力转向泵完整外壳总成 | ENCLOSURE ASSEMBLY Complete-Power Steering Pump | 1 |
| - | 893365A03 | 动力转向泵上/下盖总成 | COVER ASSEMBLY Top/Bottom, Power Steering Pump | 1 |
| 5 | 893365T02 | 动力转向泵上外壳总成 | ENCLOSURE ASSEMBLY Top, Power Steering Pump | 1 |
| 6 | 8M0080707 | 动力转向泵下外壳总成 | ENCLOSURE ASSEMBLY Bottom-Power Steering Pump | 1 |
| 7 | 889531 | 绑带 | STRAP | 2 |
| 8 | 817519A2 | 排水单向阀总成 | CHECK VALVE ASSEMBLY Drain | 1 |
| 9 | 893368001 | 护孔环 | GROMMET | 1 |
| 10 | 893369 | 护孔环 | GROMMET | 1 |
| 11 | 815504206 | 蜗杆卡箍 | CLAMP Worm Gear | 1 |
| 12 | 4002316 | 垫圈(6.60 X 17.0 X 1.5不锈钢) | WASHER (6.60 X 17.0 X 1.5SS) | 3 |
| 12 | 8M0214930 | 垫圈6.60 x 17.0 x 1.5 | WASHER 6.60 x 17.0 x 1.5 | 3 |
| 13 | 401366 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 3 |
| 14 | 895378 | 螺钉 (M6) | SCREW (M6) | 4 |
| 15 | 895319 | 护孔环 | GROMMET | 4 |
| 16 | 4002316 | 垫圈(6.60 X 17.0 X 1.5不锈钢) | WASHER (6.60 X 17.0 X 1.5SS) | 4 |
| 16 | 8M0214930 | 垫圈6.60 x 17.0 x 1.5 | WASHER 6.60 x 17.0 x 1.5 | 4 |
| 17 | 895320F1 | 衬套 | BUSHING | 4 |
| 18 | 79023A94 | 50安培保险丝-Maxi型 | FUSE 50 Ampere - Maxi | 1 |
| 19 | 879346T24 | 保险丝盖及O型圈 | FUSE COVER AND O-RING | 1 |
| 20 | 8M0026568 | 信号驱动器线束总成 | HARNESS ASSEMBLY Signal Driver | 1 |
| 21 | 897643A01 | 减震软管套件 | HOSE KIT Dampening | 1 |
| 22 | 89879 | O型圈（0.301×0.064英寸） | O-RING (.301 x .064) | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 885358T04 | 后罩总成黑色(无贴花) | COWL ASSEMBLY Rear, Black (WITHOUT DECALS) | 1 |
| 1 | 8M0050001 | ORD 100-8M0100175 | ORD 100-8M0100175 | 1 |
| 2 | 888961A01 | 销总成 | PIN ASSEMBLY | 2 |
| 3 | 892233 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 4 |
| 4 | 885360 | 怠速泄压阀 | IDLE RELIEF | 1 |
| 5 | 893343001 | 左舷密封件 | SEAL Port | 1 |
| 6 | 893344001 | 右舷密封件 | SEAL Starboard | 1 |
| 7 | 885356T02 | 左舷进气口 | INTAKE Air - Port | 1 |
| 7 | 885356T03 | ORD 885357T04 | ORD 885357T04 | 1 |
| 8 | 885357T02 | 右舷进气口 | INTAKE Air - Starboard | 1 |
| 8 | 885357T03 | ORD 885357T04 | ORD 885357T04 | 1 |
| 9 | 892315 | 衬垫 | GASKET | 1 |
| 10 | 897125 | 密封件 | SEAL | 2 |
| 10 | 8M0043266 | 密封件 | SEAL | 2 |
| 11 | 888957 | O型圈 | O-RING | 1 |
| 12 | 889823001 | 嵌入式系绳插头 | TETHER Flush Plug | 1 |
| 12 | 8M0224266 | 嵌入式插槽密封件 | SEAL Flush Plug Pocket | 1 |
| 13 | 896620001 | 升降倾斜开关 | SWITCH Trim | 1 |
| 13 | 8M0235191 | 升降倾斜开关 | SWITCH Trim | 1 |
| 14 | 888958001 | 左舷冲洗口堵头 | PLUG Flush Port Flush | 1 |
| 14 | 8M0215105 | 嵌入式塞 | PLUG Flush | 1 |
| 15 | 892233 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 16 | 4002316 | 垫圈(6.60 X 17.0 X 1.5不锈钢) | WASHER (6.60 X 17.0 X 1.5SS) | 2 |
| 16 | 8M0214930 | 垫圈6.60 x 17.0 x 1.5 | WASHER 6.60 x 17.0 x 1.5 | 2 |
| 17 | 885361A01 | 接头总成 冲洗 | FITTING ASSEMBLY Flush | 1 |
| 18 | 4006731 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 1 |
| 19 | 858951A01 | 卡箍套件 | CLAMP KIT | 1 |
| 20 | 4002316 | 垫圈(6.60 X 17.0 X 1.5不锈钢) | WASHER (6.60 X 17.0 X 1.5SS) | 1 |
| 20 | 8M0214930 | 垫圈6.60 x 17.0 x 1.5 | WASHER 6.60 x 17.0 x 1.5 | 1 |
| 21 | 4006731 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 1 |
| 22 | 892233 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 23 | 895316 | 适配器 | ADAPTER | 1 |
| 23 | 8M0214997 | 适配器 | ADAPTOR | 1 |
| 24 | 897169 | 护孔环 | GROMMET | 1 |
| 24 | 8M0214987 | 护孔环 | GROMMET | 1 |
| 25 | 8M4501634 | 隔音毯套件(885358T04组件) | SOUND BLANKET KIT Component of 885358T04 | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 896280007 | 零件手册200/225/250/275四冲程Verado | PARTS MANUAL 200/225/250/275 4-Stroke Verado | 1 |
| - | 896579T00 | 维修手册 | SERVICE MANUAL | 1 |
| - | 8M0082470 | MNL-SERV 200-300V | MNL-SERV 200-300V | 1 |
| - | 10238070 | 安装手册 | INSTALLATION MANUAL | 1 |
| - | 10237070 | 用户手册200-275四冲程L6 SC英文版 | OWNERS MANUAL 200-275 4-Stroke L6 SC, English | 1 |
| - | 10237J70 | 用户手册200-275四冲程L6 SC西班牙文版 | OWNERS MANUAL 200-275 4-Stroke L6 SC, Spanish | 1 |
| - | 10237D70 | 用户手册200-275四冲程L6 SC法文版 | OWNERS MANUAL 200-275 4-Stroke L6 SC, French | 1 |
| - | 895269001 | 产品指南 | PRODUCT GUIDE | 1 |
| - | 895269002 | 产品指南 | GUIDE-PRODUCT | 1 |
| - | 895282A06 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 892404A05 | 导水板总成 | DEFLECTOR ASSEMBLY Water | 2 |
| 2 | 885518A02 | 接头总成 | FITTING ASSEMBLY | 1 |
| 3 | 62701 | O型圈 | O-RING | 2 |
| 4 | 88552516 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 1 |
| 4 | 8M0103805 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 1 |
| 5 | 888988011 | 卡箍(38.1毫米) | CLAMP (38.1 MM) | 1 |
| 6 | 888930003 | 软管 | HOSE | 1 |
| 7 | 888988008 | 卡箍(34.6毫米) | CLAMP (34.6 MM) | 1 |
| 7 | 8M0187145 | 卡箍 | CLAMP | 1 |
| 8 | 892864T04 | 节温器总成 | THERMOSTAT ASSEMBLY | 1 |
| 8 | 8M0174561 | 节温器总成 | THERMOSTAT ASSY | 1 |
| 9 | 892864500 | O型圈 | O-RING | 1 |
| 9 | 8M0005958 | O型圈 | O-RING | 1 |
| 10 | 888988001 | 卡箍(36.1毫米) | CLAMP (36.1 mm) | 1 |
| 10 | 8M0204719 | 卡箍 36.1毫米 | CLAMP 36.1 MM | 1 |
| 11 | 892865 | 节温器软管 | HOSE Thermostat | 1 |
| 12 | 888988007 | 卡箍(42.5毫米) | CLAMP (42.5 mm) | 1 |
| 13 | 892242T | 燃油滤清器总成 | FILTER ASSEMBLY Fuel | 1 |
| 13 | 8M0062950 | 滤清器总成 | FILTER ASSEMBLY | 1 |
| 14 | 884380T | 燃油滤清器 | FILTER Fuel | 1 |
| 14 | 8M0122423 | 水星燃油滤清器 | FUEL FILTER Quicksilver | 1 |
| 15 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 16 | 892356 | 连接器 | CONNECTOR | 1 |
| 17 | 863156 | 拉手片 | GRAB TAB | 1 |
| 18 | 880598 | 燃油至升压泵软管 | HOSE Fuel to Lift Pump | 1 |
| 18 | 8M0240714 | 燃油进油软管 | HOSE FUEL INLET | 1 |
| 19 | 892147001 | 支架 | BRACKET | 1 |
| 20 | 88552785 | 螺钉(M10×85) | SCREW (M10 x 85) | 3 |
| 20 | 8M0103824 | 螺钉 | SCREW | 3 |
| 21 | 885527105 | 螺钉(M10x105) | SCREW (M10 x 105) | 1 |
| 21 | 8M0103820 | 螺钉(M10x105) | SCREW (M10 x 105) | 1 |
| 22 | 880597 | 燃油入口软管 | HOSE Fuel Inlet | 1 |
| 22 | 8M0043788 | 31.5英寸软管 | HOSE 31.5 Inch | 1 |
| 23 | 880640T10 | 集成式机油模块总成 | MODULE ASSEMBLY Intergrated Oil - Complete | 1 |
| 23 | 8M0132390 | 机油冷却模块 | OIL COOLER MODULE | 1 |
| 24 | 883701K01 | 机油滤清器 | FILTER Oil | 1 |
| 24 | 877769K01 | 机油滤清器(水星品牌) | FILTER Oil (Mercury Branded) | 1 |
| 25 | 880640A05 | 集成式机油模块壳体总成 | HOUSING ASSEMBLY Intergrated Oil Module | 1 |
| 25 | 8M0046694 | 壳体总成 | HOUSING ASSEMBLY | 1 |
| 26 | 895336 | 螺钉(M6x18) | SCREW (M6 x 18) | 6 |
| 26 | 8M0041014 | 螺钉(M6x18) | SCREW (M6 x 18) | 6 |
| 27 | 880640500 | 衬垫 | GASKET | 1 |
| 27 | 8M0034568 | 衬垫 | GASKET | 1 |
| 28 | 880640A06 | 节温器/导套套件 | THERMOSTAT/GUIDE KIT | 1 |
| 29 | 880640508 | 节温器 | THERMOSTAT | 1 |
| 30 | 892801T53 | 大修套件 | OVERHAUL KIT | 1 |
| 31 | 880640500 | 衬垫 | GASKET | 1 |
| 31 | 8M0034568 | 衬垫 | GASKET | 1 |
| 32 | 880640A09 | O型圈套件 | O-RING KIT | 1 |
| 32 | 8M0071635 | O型圈套件 | O-RING KIT | 1 |
| 33 | 895032 | 绑带 | STRAP | 2 |
| 34 | 895336 | 螺钉(M6x18) | SCREW (M6 x 18) | 4 |
| 34 | 8M0041014 | 螺钉(M6x18) | SCREW (M6 x 18) | 4 |
| 35 | 88552525 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 2 |
| 35 | 8M0103807 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 2 |
| - | 880552A06 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 880552A07 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 895247A06 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 895247R06 | RM L6 GEN1 VERADO | RM L6 GEN1 VERADO | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | NSS | 起动机总成(不单独销售) | NOT SOLD SEPARATE Starter Motor Assembly | 1 |
| 1 | 892339T01 | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 2 | NSS | 螺钉组(不单独销售) | NOT SOLD SEPARATE Screws | 2 |
| 3 | 880805A1 | 齿轮套件 | GEAR KIT | 1 |
| 4 | 809463A1 | 电磁阀组件 | SOLENOID KIT | 1 |
| 5 | 8M0065258 | 电刷组 | BRUSH SET | 1 |
| 6 | 8M0034918 | 轴环 | COLLAR | 2 |
| 7 | 8M0043276 | 停机开关 | STOP | 1 |
| 8 | NSS | 高压警告贴纸(不单独销售) | NOT SOLD SEPARATE Decal-Waring-High Voltage | 1 |
| 9 | 93388A1 | 电缆总成(6.00英寸)黑色 | CABLE ASSEMBLY (6.00 Inches) Black | 1 |
| 10 | 69035 | 螺丝与锁紧垫圈(.250-20 x .625)不锈钢 | SCREW AND LOCKWASHER (.250-20 x .625) Stainless Steel | 1 |
| 11 | 26993 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 1 |
| 11 | 8M0204647 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 1 |
| 12 | 400213 | 不锈钢螺母 (M8) | NUT (M8) Stainless Steel | 1 |
| 13 | 400255 | 锁紧垫圈(M5) | LOCKWASHER (M5) | 1 |
| 14 | 400211 | 不锈钢螺母(M5) | NUT (M5) Stainless Steel | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 892557A02 | 标准转向舵机套件(32cc) | STEERING HELM KIT Standard (32 cc) | 1 |
| - | 892380A02 | 标准转向舵机套件(40cc) | STEERING HELM KIT Standard (40 cc) | 1 |
| - | 8M0240080 | 标准舵机套件40CM | HELM KIT-STD 40CM | 1 |
| - | 892558A02 | 标准转向舵机套件(50cc) | STEERING HELM KIT Standard (50 cc) | 1 |
| - | 8M0240081 | 标准舵机套件50CM | HELM KIT-STD 50CM | 1 |
| 1 | 892557T01 | 标准舵机(32立方厘米) | HELM Standard (32 cc) | 1 |
| 1 | 8M0137438 | 标准舵机(32立方厘米) | HELM Standard (32 cm3) | 1 |
| 1 | 892380T01 | 舵机标准型(40毫升) | HELM Standard (40 cc) | 1 |
| 1 | 8M0137444 | 舵机标准型(40立方厘米) | HELM Standard (40 cm3) | 1 |
| 1 | 892558T01 | 舵机标准型(50毫升) | HELM Standard (50 cc) | 1 |
| 1 | 8M0137448 | 舵机标准型(50立方厘米) | HELM Standard (50 cm3) | 1 |
| 2 | 627021 | O型圈(.301 x .070) | O-RING (.301 x .070) | 2 |
| 3 | 8M6001491 | O型圈(.364×.070) | O-RING (.364 x .070) | 2 |
| 3 | 8M0047399 | O型圈-6 ORFS型 | O-RING -6 ORFS | 2 |
| 4 | 893394 | 带锁片键(6.35毫米) | KEY With Lock Tab (6.35 mm) | 1 |
| 5 | 4008875 | 螺钉(M6×75) | SCREW (M6 x 75) | 4 |
| 5 | 4008850 | 螺钉(M6 x 50) | SCREW (M6 x 50) | 4 |
| 6 | 826709121 | 螺母(.625-18)不锈钢 | NUT (.625-18) Stainless Steel | 1 |
| 7 | 892328T | 舵机盖 | COVER Helm | 1 |
| 8 | 896842 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 4 |
| 9 | 892327 | 舵机背板 | PLATE Helm Backing | 4 |
| 9 | 892327 | 舵机背板 | PLATE Helm Backing | 3 |
| 9 | 892327 | 舵机背板 | PLATE Helm Backing | 2 |
| 10 | 401196 | 螺母 (M6) | NUT (M6) | 4 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 898096A02 | 机械增压器套件 | SUPERCHARGER KIT | 1 |
| 1 | 8M0103744 | 机械增压器 | SUPERCHARGER | 1 |
| 2 | 885342001 | 传感器总成 | SENSOR ASSEMBLY | 1 |
| 2 | 8M0148668 | 传感器总成 | SENSOR ASSEMBLY | 1 |
| 3 | 888814 | O型圈(0.351 x 0.072) | O-RING (.351 x .072) | 1 |
| 3 | 896699 | O型圈（1.78毫米 x 0.08毫米） | O-RING (1.78 mm x .08 mm) | 1 |
| 4 | 888947A05 | 进气导管套件 | DUCT KIT Inlet | 1 |
| 5 | 888947501 | 衬垫 | GASKET | 1 |
| 6 | 888947A04 | 出口导管套件 | OUTLET DUCT KIT | 1 |
| 6 | 8M0060303 | 机械增压器套件 | SUPERCHARGER KIT | 1 |
| 7 | 888947504 | 衬垫 | GASKET | 1 |
| 8 | 888947502 | 螺栓 | BOLT | 9 |
| - | 888947A10 | 机械增压器端盖套件 | END CAP KIT Supercharger | 1 |
| - | 8M0045222 | 机械增压器端盖套件 | END CAP KIT Supercharger | 1 |
| - | 8M0045222 | 机械增压器端盖套件 | END CAP KIT Supercharger | 1 |
| 9 | 847803A02 | 衬套/垫片套件 | BUSHING/GASKET KIT | 1 |
| 10 | 885527105 | 螺钉(M10x105) | SCREW (M10 x 105) | 4 |
| 10 | 8M0103820 | 螺钉(M10x105) | SCREW (M10 x 105) | 4 |
| 11 | 56762 | 扎带(4.00英寸) | TIE STRAP (4.00 Inches) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 895277001 | 扳手工具(75毫米x30)带槽 | TOOL Wrench (75 mm x 30) Flute | 1 |
| - | 889277Q03 | 扳手 | WRENCH | 1 |
| - | 809905001 | 扭矩转换扳手 | WRENCH Torque Adapter | 1 |
| - | 822778004 | 动力调整适配器工具 | TOOL Adaptor Fitting-Power Trim | 1 |
| - | 895343T02 | 飞轮拉拔器工具 | TOOL Flywheel Puller | 1 |
| - | 895346 | 螺栓 | BOLT | 1 |
| - | 896504A01 | 舷外机吊装机构工具 | TOOL ASSEMBLY OB Lifting Mech | 1 |
| - | 889675A01 | 14针分流器工具 | TOOL Shunt 14-Pin | 1 |
| - | 804998T | 齿轮油加注/排放工具 | DRAIN/FILL TOOL Gearlube | 1 |
| - | 896661 | 燃油滤清器工具 | TOOL Fuel Filter | 1 |
| - | 889283A01 | 燃油灌注工具包 | TOOL KIT Fuel Priming | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 885355T03 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 8M0049999 | ORD 100-8M0063711 | ORD 100-8M0063711 | 1 |
| 1 | 885355T02 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 8M0050000 | 顶罩-水星型 | COWL-TOP MARINER | 1 |
| 2 | 885354T | 空气导流帽 | CAP Air Dam | 1 |
| 2 | 885354T01 | 空气导流帽-水星黑色款 | CAP, Air Dam Mercury, Black | 1 |
| 2 | 895838T | 空气导流帽 | CAP Air Dam | 1 |
| 2 | 895838T01 | 空气导流帽-水星型 | CAP Air Dam - Mariner | 1 |
| 3 | 888971 | 前锁扣槽 | FRONT LATCH RECEIVER | 1 |
| 4 | 885545 | 上罩壳密封件 | SEAL Top Cowl | 1 |
| 4 | 8M0111178 | 密封件 | SEAL | 1 |
| 5 | 888951 | 电缆 | CABLE | 1 |
| 5 | 8M0080461 | 锁扣拉索 | CABLE Latch | 1 |
| 6 | 888959 | 铰链销 | PIN Hinge | 1 |
| 7 | 888956 | 手控锁杆 | LATCH Hand Lever | 1 |
| 8 | 895373 | 弹簧 | SPRING | 1 |
| 9 | 888955 | 锁扣连杆 | LINK Latch Connecting | 1 |
| 10 | 26953 | 开口销 | COTTER PIN | 2 |
| 11 | 89302 | 垫圈(0.203×0.406×0.040) | WASHER (.203 x .406 x .040) | 2 |
| 12 | 888952 | 联动臂 | LINKAGE ARM | 2 |
| 13 | 888953 | 弹簧 | SPRING | 2 |
| 14 | 822417 | 销 | PIN | 2 |
| 15 | 888950020 | 螺钉(M4x20毫米)(M4x1.75) | SCREW (M4 x 20 mm) (M4 x 1.75) | 6 |
| 16 | 888970 | 左舷饰板 | APPLIQUE Port | 1 |
| 16 | 888970A01 | 饰板套件 | APPLIQUE KIT | 1 |
| 16 | 895839 | 左舷饰板 | APPLIQUE Port | 1 |
| 16 | 895839A01 | 饰板套件 | APPLIQUE KIT | 1 |
| 17 | 888969 | 右舷饰板 | APPLIQUE Starboard | 1 |
| 17 | 895840 | 右舷饰板 | APPLIQUE Starboard | 1 |
| 18 | 4010610 | 不锈钢螺钉(M6x10) | SCREW (M6 x 10) Stainless Steel | 2 |
| - | 892564A05 | 贴花套件 | DECAL SET | 1 |
| - | 859271A05 | 贴花套件 | DECAL SET | 1 |
| - | 895252A05 | 贴花套件 | DECAL SET | 1 |
| - | 895253A05 | 贴花套件 | DECAL SET | 1 |
| - | 892571A07 | 贴花套件(水星200) | DECAL SET (Mariner 200) | 1 |
| - | 892871A07 | 贴花套件(水星225) | DECAL SET (Mariner 225) | 1 |
| - | 895254A07 | 贴花套件(水星250) | DECAL SET (Mariner 250) | 1 |
| - | 895255A07 | 贴花套件(水星275) | DECAL SET (Mariner 275) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 888994T03 | 前安装支架总成 | BRACKET ASSEMBLY Front Mount | 1 |
| - | 888994T04 | 前安装支架总成 | BRACKET ASSEMBLY Front Mount | 1 |
| 1 | NSS | 不单独销售 支架 | NOT SOLD SEPARATE Bracket | 1 |
| 2 | 892417 | 衬套 | BUSHING | 2 |
| 3 | 892049 | 隔套 | SPACER | 1 |
| 3 | 8M0047763 | 隔套 | SPACER | 1 |
| 4 | 885506001 | 换档轴 | SHIFT SHAFT | 1 |
| 4 | 8M0026131 | 换挡轴 | SHAFT-SHIFT | 1 |
| 5 | 889727001 | 曲柄摇臂 | BELL CRANK | 1 |
| 6 | 25319 | 销钉(.125 x 0.75英寸) | PIN (.125 x 0.75 Inches) | 1 |
| 7 | 833155 | 护孔环 | GROMMET | 2 |
| 8 | 889514A01 | 开关 | SWITCH | 1 |
| 8 | 8M0207794 | 开关 | SWITCH | 1 |
| 9 | 88075020 | 螺丝(M3 x 20) | SCREW (M3 x 20) | 2 |
| 10 | 85999 | 衬套 | BUSHING | 1 |
| 11 | 8M0048114 | 换挡执行器 | SHIFT ACTUATOR | 1 |
| 11 | 8M0124413 | 换挡执行器 | SHIFT ACTUATOR | 1 |
| 12 | 8855091 | 螺钉 | SCREW | 1 |
| 13 | 885512 | 开口销 | COTTER PIN | 2 |
| 14 | 885511003 | 垫圈 | WASHER | 2 |
| 15 | 895770 | 枢轴销 | Pin Pivot | 1 |
| 16 | 895811155 | 螺钉(M10×155) | SCREW (M10 x 155) | 2 |
| 16 | 8M0207826 | 螺钉 | SCREW | 2 |
| 17 | 88510940 | 螺钉(M14) | SCREW (M14) | 4 |
| 17 | 8M0103802 | 螺钉 | SCREW | 4 |
| 18 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 2 |
| 19 | 97896 | 衬套 | BUSHING | 2 |
| 20 | 885505 | 换挡轴连杆 | LINK Shift Shaft | 1 |
| 21 | 888987001 | 换挡轴(长型) | SHAFT Shift (Long) | 1 |
| 21 | 8M0181378 | 上部换挡轴 | SHAFT SHIFT UPPER | 1 |
| 21 | 888987002 | 换挡轴（加长型） | SHIFT SHAFT (X-Long) | 1 |
| 21 | 8M0183223 | 换挡轴上段 | SHIFT SHAFT UPPER | 1 |
| 21 | 888987003 | 换挡轴（超长型） | SHIFT SHAFT (XX-Long) | 1 |
| 21 | 8M0180097 | 超长换挡轴 | SHAFT SHIFT XXL | 1 |
