四冲程 化油器 · Belgium - Cat.# 90-803599 · 共 28 个部位 · 1051 条零件
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0236724 | 快速冲洗连接套件 | FLUSH QUICK CONNECT KIT | 1 |
| - | 893395A01 | 嵌入式安装板 | PLATE Flush Mount | 1 |
| - | 875207 | 三通接头 | TEE Fitting | 1 |
| - | 892486K08 | 模拟转换套件 | CONVERSION KIT Analog | 1 |
| - | 899785K04 | 附件电源线束总成(30英尺) | HARNESS ASSEMBLY Accessory Power (30 Feet) | 1 |
| - | 880717A01 | 齿轮箱螺丝/密封套件 | SCREW/SEAL KIT Gearcase | 1 |
| - | 88439A50 | 电池电缆组 | CABLE SET Battery | 1 |
| - | 8M0210761 | 电池电缆组(12英尺) | CABLE SET (12 ft) Battery | 1 |
| - | 8M0133542 | 电池电缆套件(12英尺) | CABLE KIT (12 ft) Battery | 1 |
| - | 44357Q2 | 冲洗附件 | FLUSHING ATTACHMENT | 1 |
| - | 44357T2 | 冲洗附件 | FLUSHING ATTACHMENT | 1 |
| - | 881150Q1 | 双进水口冲洗套件 | FLUSH KIT Dual Water Pick Up | 1 |
| - | 881150K1 | 双进水口冲洗密封套件 | SEAL KIT Flush - Dual Water Pickup | 1 |
| - | 899712A01 | 连续性电缆套件 | CABLE KIT Continuity | 1 |
| - | 8M0131810 | MP警报罩套件(镀铬边框) | MP ALERT COWL KIT (Chrome Bezel) | 1 |
| - | 8M0072341 | MP警报边框-椭圆形(镀铬) | BEZEL MP Alert - Oval (Chrome) | 1 |
| - | 8M0138978 | MP警报边框(暖融白) | BEZEL MP Alert (Warm Fusion White) | 1 |
| - | 8M0142265 | 油位传感器 | SENSOR Oil Level | 1 |
| - | 8M0145987 | 重新供电方案线束套件 | HARNESS KIT Re-power Plan | 1 |
| - | 8M0142696 | 压力传感器-DTS | SENSOR Pressure-DTS | 1 |
| - | 8M0145165 | 模拟水压块套件 | BLOCK WATER PRESSURE KIT Analog | 1 |
| - | 8M0146953 | 大孔衬套-机械式 | GROMMET Large Hole, Mechanical | 1 |
| - | 8M0146954 | 大孔衬套-DTS CMS | GROMMET Large Hole, DTS CMS | 1 |
| - | 8M0146955 | 大孔衬套-DTS | GROMMET Large Hole, DTS | 1 |
| - | 825191A03 | 索具软管套件 | HOSE KIT Rigging | 1 |
| - | 8M0135386 | 船用燃油滤清器套件 | FUEL FILTER KIT Boat Mounted | 1 |
| - | 8M0126144 | 燃油滤清器 | FUEL FILTER | 1 |
| - | 8M0113732 | DTS清洁电源线束总成(14英尺) | HARNESS ASSEMBLY DTS, Clean Power, 14 Feet | 1 |
| - | 889244T01 | 线束总成 DTS清洁电源(25英尺) | HARNESS ASSEMBLY DTS Clean Power (25 Feet) | 1 |
| - | 8M0207790 | DTS清洁电源线束总成(25英尺) | HARNESS ASSEMBLY DTS Clean Power, 25 Feet | 1 |
| - | 8M0127682 | 操舵电源线束总成(15英尺) | POWER HARNESS ASSEMBLY Helm (15 feet) | 1 |
| - | 8M0127681 | 操舵电源线束总成(10英尺) | POWER HARNESS ASSEMBLY Helm (10 feet) | 1 |
| - | 896333T25 | 线束总成(25英尺) | HARNESS ASSEMBLY (25 Feet) | 1 |
| - | 896305001 | 支架 | BRACKET | 1 |
| - | 896392 | 垫圈 | WASHER | 1 |
| - | 67755A22 | 艉板螺栓套件(2.50英寸) | BOLT KIT Transom (2.50 Inch) | 1 |
| - | 67755A26 | 艉板螺栓套件(3.50英寸) | BOLT KIT Transom (3.50 Inch) | 1 |
| - | 67755A13 | 艉板螺栓套件(4.50英寸) | BOLT KIT Transom (4.50 Inch) | 1 |
| - | 67755A14 | 艉板螺栓套件(5.50英寸) | BOLT KIT Transom (5.50 Inch) | 1 |
| - | 67755A15 | 艉板螺栓套件(6.50英寸) | BOLT KIT Transom (6.50 Inch) | 1 |
| - | 67755A17 | 艉板螺栓套件(7.50英寸) | BOLT KIT Transom (7.50 Inch) | 1 |
| - | 67755A18 | 艉板螺栓套件(8.00英寸) | BOLT KIT Transom (8.00 Inches) | 1 |
| - | 8M0149614 | 艉板螺栓套件(8.00英寸) | BOLT KIT Transom (8.00 Inches) | 1 |
| - | 8M0109756 | 艉板螺栓双螺母套件 | DOUBLE NUT KIT Transom Bolt | 1 |
| - | 28421 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 1 |
| - | 8M0204648 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 1 |
| - | 895062 | 垫圈 | WASHER | 1 |
| - | 8M0204704 | 垫圈 | WASHER | 1 |
| - | 82671117 | 螺母(.500-20) | NUT (.500-20) | 1 |
| - | 8M0097226 | 转速表套件 舵机安装 | TACHOMETER KIT Helm Mount | 1 |
| - | 8M0150994 | 接头连接套件 | FITTING CONNECTOR KIT | 1 |
| - | 8M0225356 | 卡箍套件 全套 | CLAMP KIT Clamp Kit-Complete | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 16837A2 | 交流发电机套件 | ALTERNATOR KIT | 1 |
| 2 | 16074T | 交流发电机 | ALTERNATOR | 1 |
| 3 | 16059 | 螺钉 | SCREW | 2 |
| 4 | 16060 | 卡箍 | CLAMP | 1 |
| 5 | 16821 | 螺钉 | SCREW | 1 |
| 6 | 17175 | 线束总成 | HARNESS ASSEMBLY | 1 |
| 7 | 16838A4 | 充电套件 电池整流器 | CHARGING KIT Battery Rectifier | 1 |
| 8 | 16076 | 整流器 | RECTIFIER | 1 |
| 8 | 16076A1 | 整流器套装 | RECTIFIER KIT | 1 |
| 8 | 16076A1 | 整流器套装 | RECTIFIER KIT | 1 |
| 9 | 16077 | 保险丝 | FUSE | 1 |
| 10 | 16123 | 螺钉(25毫米) | SCREW (25 mm) | 1 |
| 10 | 16078 | 螺钉 | SCREW | 1 |
| 11 | 16079 | 锁紧垫圈 | LOCKWASHER | 1 |
| 12 | 16080 | 不锈钢垫圈 | WASHER Stainless Steel | 1 |
| 12 | 8M0108373 | 垫圈 | WASHER | 1 |
| 13 | 813275 | 卡箍 | CLAMP | 1 |
| 14 | 16081 | 不锈钢螺母 | NUT Stainless Steel | 1 |
| 15 | 16082 | 蓄电池电缆 | CABLE Battery | 1 |
| 16 | 16839A4 | 垂直绳索导向套件 | GUIDE KIT Vertical Rope | 1 |
| 17 | NSS | 不单独销售 导向件 | NOT SOLD SEPARATE Guide | 1 |
| 18 | 16113 | 密封板 | PLATE Seal | 1 |
| 19 | 17173 | 螺钉 | SCREW | 4 |
| 20 | 853828 | 手柄(0.8米) | HANDLE (0.8 Meters) | 1 |
| 20 | 8538281 | 手柄(1.0米) | HANDLE (1.0 Meters) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 803819T1 | 化油器 | CARBURETOR | 1 |
| 1 | 803819T2 | 化油器 | CARBURETOR | 1 |
| 1 | 879817A1 | 化油器 | CARBURETOR | 1 |
| 1 | 879658A1 | 化油器 | CARBURETOR | 1 |
| 1 | 803522T1 | 化油器 | CARBURETOR | 1 |
| 1 | 803522T2 | 化油器 | CARBURETOR | 1 |
| 1 | 879818A1 | 化油器 | CARBURETOR | 1 |
| 1 | 879659A1 | 化油器 | CARBURETOR | 1 |
| 1 | 804766T1 | 化油器 | CARBURETOR | 1 |
| 1 | 804766T2 | 化油器 | CARBURETOR | 1 |
| 1 | 804766T2 | 化油器 | CARBURETOR | 1 |
| 1 | 879819A1 | 化油器 | CARBURETOR | 1 |
| 1 | 879660A1 | 化油器 | CARBURETOR | 1 |
| 2 | 8035095 | 螺钉 | SCREW | 1 |
| 3 | 803554 | 弹簧 | SPRING | 1 |
| 4 | 8035241 | 怠速量孔 | PILOT JET | 1 |
| 4 | 803524 | 怠速量孔 | PILOT JET | 1 |
| 4 | 8035243 | 怠速量孔(#38) | JET Pilot (#38) | 1 |
| 4 | 8035242 | 怠速量孔 | PILOT JET | 1 |
| 4 | 8035241 | 怠速量孔 | PILOT JET | 1 |
| 5 | 8035094 | 导向螺钉总成 | SCREW ASSEMBLY Pilot | 1 |
| 5 | 8035098 | 导向螺钉总成 | SCREW ASSEMBLY Pilot | 1 |
| 5 | 8035099 | 导向螺钉总成 | SCREW ASSEMBLY Pilot | 1 |
| 6 | 8126505 | 主喷管 | MAIN NOZZLE | 1 |
| 6 | 8126507 | 主喷管 | MAIN NOZZLE | 1 |
| 6 | 8126504 | 主喷管 | MAIN NOZZLE | 1 |
| 6 | 8126509 | 主喷管 | MAIN NOZZLE | 1 |
| 6 | 8126507 | 主喷管 | MAIN NOZZLE | 1 |
| 6 | 81265011 | 主喷管 | MAIN NOZZLE | 1 |
| 6 | 8126508 | 主喷管 | MAIN NOZZLE | 1 |
| 6 | 8126509 | 主喷管 | MAIN NOZZLE | 1 |
| 6 | 81265011 | 主喷管 | MAIN NOZZLE | 1 |
| 6 | 8126506 | 主喷管 | MAIN NOZZLE | 1 |
| 6 | 81265010 | 主喷管 | MAIN NOZZLE | 1 |
| 6 | 879660A1 | 化油器 | CARBURETOR | 1 |
| 7 | 162502 | 主量孔(#70) | JET Main (#70) | 1 |
| 7 | 162505 | 主量孔(#60) | JET Main (#60) | 1 |
| 7 | 162508 | 主量孔(#65) | JET Main (#65) | 1 |
| 7 | 162509 | 主量孔(#62) | JET Main (#62) | 1 |
| 7 | 162506 | 主量孔(#75) | JET Main (#75) | 1 |
| 7 | 162507 | 主量孔(#68) | JET Main (#68) | 1 |
| 8 | 162543 | 铜质浮子阀 | FLOAT VALVE Brass | 1 |
| 9 | 803525 | 不锈钢卡扣 | CLIP Stainless Steel | 1 |
| 10 | 162562 | 不锈钢浮子销 | PIN Float - Stainless Steel | 1 |
| 11 | 162533 | 浮子 | FLOAT | 1 |
| 12 | 8035084 | 橡胶衬垫 | GASKET Rubber | 1 |
| 13 | 16258T5 | 浮子室 | FLOAT BOWL | 1 |
| 14 | 16260 | 螺钉(M4 x 12) | SCREW (M4 x 12) | 2 |
| 15 | 8035093 | 放油螺钉(M5×6) | SCREW Drain (M5 x 6) | 1 |
| 16 | 8035131 | 橡胶O型圈 | O-RING Rubber | 1 |
| 17 | 881837 | 堵头 | PLUG | 1 |
| 17 | 881836 | 堵头 | PLUG | 1 |
| - | 803508A99 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 8M0114820 | 动力头衬垫 | POWERHEAD GASKET | 1 |
| - | 803508A05 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9622T6 | 右舷夹紧支架 | CLAMP BRACKET Starboard | 1 |
| 2 | 96231 | 左舷夹紧支架 | CLAMP BRACKET Port | 1 |
| 3 | 95373 | 螺栓 | BOLT | 1 |
| 3 | 898101337 | 螺钉 | SCREW | 1 |
| 4 | 95375 | 垫圈 | WASHER | 2 |
| 5 | 16192 | 垫圈 | WASHER | 1 |
| 6 | 815088 | 螺母 (M8) | NUT (M8) | 1 |
| 6 | 95374 | 尼龙螺母 | NUT Nylon | 1 |
| 7 | 161931 | 间隔板 | DISTANCE PLATE | 1 |
| 8 | 16194 | 螺钉 | SCREW | 2 |
| 9 | 16212 | 弹簧 | SPRING | 1 |
| 10 | 825112A3 | 倾斜止动器总成 | STOPPER ASSEMBLY Tilt | 1 |
| 10 | 8M0045584 | 倾斜止动块 | STOP-TILT | 1 |
| 11 | 162081 | 握把 | GRIP | 1 |
| 11 | 8M0090337 | 握把 | GRIP | 1 |
| 12 | 162111 | 螺栓 | BOLT | 2 |
| 12 | 8230427 | 螺栓总成(M6 x 12) | BOLT ASSEMBLY (M6 x 12) | 2 |
| 13 | 16210 | 定位板 | SET PLATE | 1 |
| 13 | 16210002 | 定位板 | SET PLATE | 1 |
| 14 | 825113 | 衬套 | BUSHING | 2 |
| 15 | 16200 | 夹紧螺钉总成 | CLAMP SCREW ASSEMBLY | 2 |
| 15 | 8M0059063 | 螺钉 | SCREW | 2 |
| 16 | 95379 | 垫 | PAD | 2 |
| 17 | 16198 | 推力杆 | THRUST ROD | 1 |
| 17 | 16198004 | 推力杆 | THRUST ROD | 1 |
| 18 | 8150931 | 弹簧 | SPRING | 1 |
| 18 | 815093003 | 弹簧 | SPRING | 1 |
| 19 | 161951 | 弹簧 | SPRING | 1 |
| 20 | 16197 | 垫圈 | WASHER | 1 |
| 21 | 16196 | 螺钉 | SCREW | 1 |
| 22 | 813029T9 | 旋转支架 | SWIVEL BRACKET | 1 |
| 23 | 883300T | 旋转支架 | SWIVEL BRACKET | 1 |
| 24 | 8035674 | 下轴套 | BUSHING Lower | 1 |
| 25 | 883301 | 摩擦带 | FRICTION BAND | 1 |
| 25 | 8M0124744 | 摩擦带总成 | FRICTION BAND ASSEMBLY | 1 |
| 26 | 883302 | 蝶形螺母 | WING NUT | 1 |
| 27 | 953921 | 不锈钢垫圈 | WASHER Stainless Steel | 1 |
| 28 | 953839 | 弹簧 | SPRING | 1 |
| 29 | 803582 | 推力板 | THRUST PLATE | 1 |
| 30 | 8035672 | 衬套 上部 | BUSHING Upper | 1 |
| 31 | 8035821 | 推力板 | THRUST PLATE | 2 |
| 32 | 82304222 | 不锈钢螺栓 | BOLT Stainless Steel | 4 |
| 32 | 8M0102279 | 螺栓 | BOLT | 4 |
| 33 | 824969 | 润滑脂接头 | FITTING Grease | 2 |
| 34 | 162133 | 倒车锁臂 | ARM Reverse Lock | 1 |
| 35 | 82304223 | 螺栓 | BOLT | 2 |
| 36 | 16216 | 弹簧 | SPRING | 1 |
| 37 | 16215 | 弹簧 | SPRING | 1 |
| 38 | 808599 | 盖帽 | CAP | 2 |
| 39 | 813029T10 | 旋转支架 | SWIVEL BRACKET | 1 |
| 40 | 8035673 | 下轴套 | BUSHING Lower | 1 |
| 41 | 162061 | 调节螺钉 | SCREW Adjusting | 1 |
| 41 | 8M0155324 | 螺钉垫片套件 | SCREW WASHER KIT | 1 |
| 42 | 953838 | 弹簧 | SPRING | 1 |
| 43 | 16826 | 不锈钢垫圈 | WASHER Stainless Steel | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 898103T78 | 顶罩总成(水星款) | TOP COWL ASSEMBLY Mercury | 1 |
| 1 | 8M0061798 | 顶罩总成-黑色无标 | TOP COWL ASSEMBLY Black, no decals | 1 |
| 1 | 8M0130974 | 顶罩总成 | TOP COWL ASSY | 1 |
| 1 | 898103T80 | 顶罩总成（水星款） | TOP COWL ASSEMBLY Mariner | 1 |
| 1 | 8M0130976 | 灰色顶罩 | TOP COWL GRAY | 1 |
| 1 | 8M0058617 | 顶罩总成-银色无标 | TOP COWL ASSEMBLY Silver, no decals | 1 |
| 1 | 8M0130976 | 灰色顶罩 | TOP COWL GRAY | 1 |
| 2 | 898101348 | 罩盖密封件 | SEAL Cowl | 1 |
| 2 | 8M0105122 | 密封组件 | SEAL ASSEMBLY | 1 |
| 2 | 8M0072631 | 密封件 | SEAL | 1 |
| 2 | 8M0111073 | 密封组件 | SEAL ASSEMBLY | 1 |
| 2 | 8M0157116 | 罩壳密封套件 | COWL SEAL KIT | 1 |
| 3 | 898103T77 | 倾斜手柄(水星款) | HANDLE Tilt Mercury | 1 |
| 3 | 8M0130969 | 倾斜手柄(水星款) | HANDLE Tilt, Mercury | 1 |
| 3 | 898103T79 | 倾斜手柄(马林纳款) | HANDLE Tilt Mariner | 1 |
| 3 | 8M0130971 | 倾斜手柄(马林纳款) | HANDLE Tilt, Mariner | 1 |
| 4 | 895106 | 不锈钢垫圈 | WASHER Stainless Steel | 4 |
| 4 | 16826 | 不锈钢垫圈 | WASHER Stainless Steel | 4 |
| 5 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 4 |
| 6 | 853722022 | 螺母 | NUT | 4 |
| 6 | 400212 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 4 |
| 7 | 898103T76 | 下机罩 | BOTTOM COWL | 1 |
| 7 | 8M0224582 | 下机罩 | BOTTOM COWL | 1 |
| 8 | NSS | 火花塞标贴(不单独销售) | NOT SOLD SEPARATE Decal-Spark Plug | 1 |
| 9 | 817015001 | 罩壳锁扣总成 | COWL LATCH ASSEMBLY | 1 |
| 9 | 8M0063135 | 罩壳锁扣总成 | COWL LATCH ASSEMBLY | 1 |
| 9 | 817015005 | 罩壳锁扣总成 | COWL LATCH ASSEMBLY | 1 |
| 9 | 8M0063135 | 罩壳锁扣总成 | COWL LATCH ASSEMBLY | 1 |
| 9 | 8M0063135 | 罩壳锁扣总成 | COWL LATCH ASSEMBLY | 1 |
| 10 | 952868 | 轴环 | COLLAR | 1 |
| 11 | 8248324 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 1 |
| 12 | 16832 | 螺栓(M6 x 16) | BOLT (M6 x 16) | 4 |
| 13 | 895118002 | 垫圈 | WASHER | 4 |
| 13 | 953921 | 不锈钢垫圈 | WASHER Stainless Steel | 4 |
| 14 | 9528611 | 轴环 | COLLAR | 4 |
| 15 | 898101373 | 衬套 | BUSHING | 1 |
| 16 | 16230 | 安全绳 | SAFETY ROPE | 1 |
| 17 | 803581 | 工具包 | TOOL KIT | 1 |
| 18 | 16841A2 | 冲洗附件 | FLUSHING ATTACHMENT | 1 |
| 18 | 16841Q02 | 冲洗套件 | FLUSHING KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 803515T | 曲轴 | CRANKSHAFT | 1 |
| 2 | 803516 | 垫圈 | WASHER | 1 |
| 3 | 16053 | 键 | KEY | 1 |
| 4 | 813047A1 | 连杆 | CONNECTING ROD | 1 |
| 4 | 8M0124936 | 连杆 | CONNECTING ROD | 1 |
| 5 | 8035092 | 螺栓 | BOLT | 2 |
| 6 | 804768A03 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 6 | 804768T3 | 活塞 | PISTON | 1 |
| 6 | 804768A03 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 6 | 804768T2 | 活塞 | PISTON | 1 |
| 6 | 804768T3 | 活塞 | PISTON | 1 |
| 6 | 804768T | 活塞 | PISTON | 1 |
| 6 | 804768T3 | 活塞 | PISTON | 1 |
| 6 | 804768A04 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 6 | 8M0094922 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 6 | 804768T4 | 活塞 | PISTON | 1 |
| 6 | 804768A04 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 6 | 804768T1 | 活塞 | PISTON | AR |
| 6 | 804768T4 | 活塞 | PISTON | AR |
| 6 | 803517T | 活塞 | PISTON | 1 |
| 6 | 803517T1 | 活塞 | PISTON | AR |
| 6 | 804768T | 活塞 | PISTON | 1 |
| 6 | 804768T3 | 活塞 | PISTON | 1 |
| 6 | 804768T1 | 活塞 | PISTON | AR |
| 6 | 804768T4 | 活塞 | PISTON | AR |
| 7 | 160573 | E型卡环 | E RING | 2 |
| 8 | 803521 | 活塞销 | PIN Piston | 1 |
| 8 | 898103113 | 活塞销 | PIN Piston | 1 |
| - | 803518T01 | 活塞环组 | RING SET Piston | 1 |
| - | 803518T02 | 活塞环组 | RING SET Piston | AR |
| 9 | 803518 | 活塞环-顶环 | RING Piston - Top | 1 |
| 9 | 803518T01 | 活塞环组 | RING SET Piston | 1 |
| 9 | 8035181 | 活塞环-顶环 | RING Piston - Top | AR |
| 10 | 803519 | 活塞环-第二环 | RING Piston - Second | 1 |
| 10 | 803518T01 | 活塞环组 | RING SET Piston | 1 |
| 10 | 8035191 | 活塞环-第二环 | RING Piston - Second | AR |
| 11 | 803520 | 油环 | RING Oil | 1 |
| 11 | 8035201 | 油环 | RING Oil | AR |
| 11 | 803518T02 | 活塞环组 | RING SET Piston | AR |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8M0142344 | 气缸体 | CYLINDER BLOCK | 1 |
| 2 | NSS | 不单独销售 | NOT SOLD SEPARATE | 1 |
| 3 | 8M0142349 | 气缸体盖 | COVER Cylinder Block | 1 |
| 4 | 8M0080651 | 螺钉 (M6 x 20) | SCREW (M6 x 20) | 5 |
| 5 | 8M0142352 | 18毫米螺塞 | PLUG 18 MM | 1 |
| 6 | 8M0142353 | O型圈(0.614x0.070) | O-RING (0.614 x 0.070) | 1 |
| 7 | 893540 | 定位销 8x12长 | PIN Dowel, 8x12 long | 6 |
| 8 | 8M0087447 | 堵头(10毫米) | PLUG (10MM) | 2 |
| 9 | 8M0142348 | 盖板垫片 | GASKET Cover Plate | 1 |
| 10 | 8M0103809 | 螺钉(M6x40毫米)不锈钢 | SCREW (M6 x 40 mm) Stainless Steel | 10 |
| 11 | 8M0142347 | 螺钉(M10x96毫米)六角凸缘头 | SCREW (M10 x 96 MM) HEX FLG HD | 10 |
| 11 | 8M0168893 | 螺钉 M10x96 | SCREW M10 x 96 | 10 |
| 12 | 8M0142346 | 螺钉(M11x107毫米)12角头 | SCREW (M11 x 107 MM) 12 POINT HEX HEAD | 10 |
| 13 | 8M0087454 | 30毫米螺塞 | PLUG (30 mm) | 1 |
| 14 | 8M0142409 | 平衡器螺塞 | PLUG Balancer | 1 |
| 15 | 8M0142421 | 平衡轴 | BALANCE SHAFT | 1 |
| 16 | 8M0142429 | 滚珠轴承 | BEARING Ball | 1 |
| 17 | 8M0142427 | 挡板 | PLATE Retainer | 1 |
| 18 | 8M0142428 | 螺钉(M5x12)六角凸缘 | SCREW (M5 x 12) HEX FLG | 2 |
| 19 | 8M0142426 | 定位销 | PIN Dowel | 1 |
| 20 | 8M0142423 | 螺钉(M8x1.25)六角凸缘带垫 | SCREW (M8 x 1.25) HEX FL SEMS | 1 |
| 21 | 8M0142422 | 链轮 | SPROCKET | 1 |
| 22 | 8M0142410 | 平衡器盖 冲压件 | COVER Balancer, Stamped | 1 |
| 23 | 40011106 | 不锈钢螺钉(M5x13) | SCREW (M5 x 13) Stainless Steel | 10 |
| 24 | 8M0103807 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 2 |
| 25 | 8M0064752 | 凸轮张紧器端盖 | END CAP Cam Tensioner | 1 |
| 26 | 898836 | 棕色O型圈 | O-RING Brown | 1 |
| 26 | 8M0237361 | O型圈 | O-RING | 1 |
| 27 | 8M0142394 | 正时链条张紧器总成 | TENSIONER ASSEMBLY Timing Chain | 1 |
| 27 | 8M0231253 | 正时链条张紧器总成 | TENSIONER ASSEMBLY Timing Chain | 1 |
| 28 | 8M0142399 | 凸轮驱动链条 | CHAIN CAM DRIVE | 1 |
| 29 | 8M0142395 | 凸轮螺栓 M12特殊左旋 | CAM BOLT M12 Special Left Hand | 2 |
| 30 | 8M0142390 | 凸轮轴链轮 | SPROCKET Camshaft | 2 |
| 31 | 8M0142400 | 短跨距导板 | GUIDE SHORT SPAN | 2 |
| 32 | 8M0086569 | 台阶螺钉(M8x1.25) | SCREW Shoulder (M8 x 1.25) | 2 |
| 33 | 8M0142393 | 凸轮驱动导板 | GUIDE Cam Drive | 1 |
| 34 | 8M0142392 | 活动导板 | GUIDE Moveable | 1 |
| 35 | 8M0103821 | 螺钉 | SCREW | 4 |
| 36 | 8M0142459 | 左舷吊环 | LIFTING EYE Port | 1 |
| 37 | 8M0142448 | 右舷吊环 | LIFTING EYE Starboard | 1 |
| - | 8M0142279 | 长缸体总成 | LONG BLOCK | 1 |
| - | 8M0149557 | 长缸体总成 | LONG BLOCK | 1 |
| - | 8M0149551 | 动力头垫片套装 | POWERHEAD GASKET SET | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8M0142775 | 驱动轴壳体-黑色 | HOUSING Driveshaft, Black | 1 |
| 2 | 8M0142713 | 支撑盖帽 | CAP Chap Support | 4 |
| 3 | 8M0112869 | 油塞总成 | OIL PLUG ASSEMBLY | 1 |
| 4 | 85045 | O型圈(.551 x .070) | O-RING (.551 x .070) | 1 |
| 5 | 863006 | O型圈(10.82x1.78) | O-RING (10.82 x 1.78) | 1 |
| 6 | 8M0036228 | O型圈(8.1x1.6) | O-RING (8.1 X 1.6) | 1 |
| 7 | 8M0142829 | 螺钉 (M6 x 20) | SCREW (M6 x 20) | 4 |
| 8 | 8M0142253 | 换挡执行器 | SHIFT ACTUATOR | 1 |
| 8 | 8M0204944 | 换挡执行器 | SHIFT ACTUATOR | 1 |
| 9 | 8M0147857 | 联轴器轴 | SHAFT Coupling | 1 |
| 10 | 8M0142978 | 执行器密封件 | SEAL ACTUATOR | 1 |
| 11 | 69355 | 扎带(5.50英寸) | TIE STRAP (5.50 Inches) | 1 |
| 11 | 8M0214940 | 扎带 | TIE STRAP | 1 |
| 12 | 8M0147674 | 换挡执行器线束护套 | BOOT Shift Actuator Wires | 1 |
| 13 | 8M0147675 | 卡扣 | CLIP | 1 |
| 14 | 8M0142714 | 接头 | FITTING | 1 |
| 15 | 8M0155119 | 乐可利接头 | FITTING Legris | 1 |
| 16 | 8M0142715 | 围嘴安装支架 | BRACKET Bib Mount | 2 |
| 17 | 8M0142716 | 嵌件 | INSERT | 2 |
| 18 | 40011106 | 不锈钢螺钉(M5x13) | SCREW (M5 x 13) Stainless Steel | 2 |
| 19 | 8M0008031 | 双头螺柱(M12 x 1.75 x 52) | STUD (M12 x 1.75 x 52) | 5 |
| 19 | 8M0142781 | 双头螺柱（M12×179） | STUD (M12 x 179) | 5/AR |
| 19 | 8M0142788 | 双头螺柱(M12x306) | STUD (M12 x 306) | 5/AR |
| 20 | 856982 | 垫圈(0.5×0.81×0.09英寸)不锈钢 | WASHER (.500 x .810 x .090) Stainless Steel | 5/AR |
| 21 | 896895 | 螺母(M12) | NUT (M12) | 5/AR |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 16071 | 螺母 | NUT | 1 |
| 2 | 16072 | 垫圈 | WASHER | 1 |
| 3 | 803557T | 飞轮 | FLYWHEEL | 1 |
| 4 | 16060 | 卡箍 | CLAMP | 1 |
| 5 | 16821 | 螺钉 | SCREW | 1 |
| 6 | 803844T | 励磁线圈 | COIL Exciter | 1 |
| 7 | 16059 | 螺钉 | SCREW | 2 |
| 8 | 803559T1 | 点火线圈 | COIL Ignition | 1 |
| 9 | 803560 | 护套 | BOOT | 1 |
| 9 | 803560001 | 护套 | BOOT | 1 |
| 10 | 167051 | 螺栓 (M6 x 20) | BOLT (M6 x 20) | 2 |
| 11 | 878062 | 减震器 | DAMPER | 1 |
| 12 | 803558T1 | CD单元 | CD UNIT | 1 |
| 12 | 803558T02 | CD单元 | CD UNIT | 1 |
| 12 | 803558T02 | CD单元 | CD UNIT | 1 |
| 13 | 878061 | 前减震器 | FRONT DAMPER | 1 |
| 14 | 879705 | 套筒 | SLEEVE | 1 |
| 15 | 803563 | 卡箍 | CLAMP | 1 |
| 15 | 803563005 | 卡箍 | CLAMP | 1 |
| 15 | 8035631 | 卡箍 | CLAMP | 1 |
| 15 | 803563005 | 卡箍 | CLAMP | 1 |
| 15 | 95306 | 卡箍 | CLAMP | 1 |
| 15 | 8M0130961 | 卡箍 | CLAMP | 1 |
| 15 | 813275 | 卡箍 | CLAMP | 1 |
| 16 | 16827 | 螺钉 | SCREW | 1 |
| 17 | 803562 | 警告灯 | WARNING LAMP | 1 |
| 18 | 823037A3 | 停机开关总成 | SWITCH ASSEMBLY Stop | 1 |
| 18 | 823037A05 | 停机开关总成 | SWITCH ASSEMBLY Stop | 1 |
| 18 | 823037A05 | 停机开关总成 | SWITCH ASSEMBLY Stop | 1 |
| 19 | 823054 | 拉绳 | LANYARD | 1 |
| 20 | 16068 | 护孔环 | GROMMET | 1 |
| 21 | 803561 | 脉冲线圈 | COIL Pulser | 1 |
| 22 | 82303110 | 螺钉(M5×16) | SCREW (M5 x 16) | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 803508A99 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 803508A05 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 8035131 | 化油器放油螺钉橡胶O型圈 | O-RING Rubber Carburetor Drain Screw | 1 |
| - | 8035133 | 进气歧管O型圈 | O-RING Inlet Manifold | 1 |
| - | 8035085 | 化油器衬垫 | GASKET Carburetor | 2 |
| - | 803508013 | 衬垫 | GASKET | 2 |
| - | 803514 | 气缸体油封 | SEAL Oil Cylinder Block | 1 |
| - | 898101285 | 油封 | SEAL Oil | 1 |
| - | 803513 | 加注口盖O型圈 | O-RING Filler Cap | 1 |
| - | 80350811 | 盖衬垫 | GASKET Cap | 1 |
| - | 803508 | 气缸盖衬垫 | GASKET Cylinder Head | 1 |
| - | 8035081 | 气缸盖衬垫 | GASKET Cylinder Head | 1 |
| - | 803508012 | 衬垫 | GASKET | 1 |
| - | 853702 | 节温器盖/支架垫片 | GASKET Thermostat Cover/Bracket | 1 |
| - | 8M0214960 | 衬垫 | GASKET | 1 |
| - | 8035082 | 气缸盖罩衬垫 | GASKET Cylinder Head Cover | 1 |
| - | 8035088 | 排气板衬垫 | GASKET Exhaust Plate | 1 |
| - | 803508015 | 衬垫 | GASKET | 1 |
| - | 8035134 | 油底壳盖O型圈 | O-RING Oil Pan Cover | 1 |
| - | 8035087 | 油底壳衬垫 | GASKET Oil Pan | 1 |
| - | 803508014 | 衬垫 | GASKET | 1 |
| - | 168231 | 油底壳座O型圈 | O-RING Oil Pan Seat | 1 |
| - | 8035089 | 驱动轴壳体垫片 | GASKET DriveShaft Housing | 1 |
| - | 803508016 | 驱动轴壳体衬垫 | GASKET Driveshaft Housing | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8M0132732 | 燃油供给模块 | FUEL SUPPLY MODULE | 1 |
| 2 | 65567 | 不锈钢垫圈(0.265x0.750x0.048) | WASHER (.265 x .750 x .048) Stainless Steel | 1 |
| 3 | 8M0103807 | 不锈钢螺钉 (M6 x 25毫米) | SCREW (M6 x 25 mm) Stainless Steel | 1 |
| 4 | 8M0142432 | 进气至燃油模块软管 | HOSE Intake to FSM | 1 |
| 4 | 8M0231308 | 歧管参考下软管 | HOSE Manifold Reference Lower | 1 |
| 5 | 8M0142436 | 歧管参考上软管总成 | HOSE ASSEMBLY Manifold Ref Upper | 1 |
| 5 | 8M0203775 | 上部歧管参考软管 | HOSE Manifold Reference, Upper | 1 |
| 6 | 884546 | 护孔环 | GROMMET | 3 |
| 7 | 8M0005773 | 螺钉(M6x14)带肩六角凸缘不锈钢 | SCREW (M6 x 14) Shoulder HEX FLG SS | 4 |
| 8 | 8M0142475 | 左舷燃油轨盖 | COVER Fuel Rail, Port | 1 |
| 9 | 8M0142830 | 螺钉 (M6 x 20) | SCREW (M6 x 20) | 4 |
| 10 | 8M0142434 | 燃油轨 左舷 | FUEL RAIL Port | 1 |
| 10 | 8M0220616 | 燃油轨 左舷 | FUEL RAIL Port | 1 |
| 10 | 8M0142433 | 燃油轨 右舷 | FUEL RAIL Starboard | 1 |
| 10 | 8M0220615 | 燃油轨 右舷 | FUEL RAIL Starboard | 1 |
| 11 | 8M0046566 | 阀帽 | CAP Valve | 2 |
| 12 | 8M0142264 | 燃油喷射器 | FUEL INJECTOR | 8 |
| 13 | 8M0221321 | O型圈套件 | ORING KIT | 1 |
| 14 | 8M0090809 | 燃油轨滤网 | SCREEN Fuel Rail | 2 |
| 15 | 8M0142585 | 卡箍(16.2x7x0.6毫米) | CLAMP (16.2 x 7 x .6 MM) | 3 |
| 16 | 8M0142442 | 燃油供给模块至左舷轨软管总成 | HOSE ASSEMBLY FSM To Port Rail | 1 |
| 17 | 8M0142437 | 燃油供给模块至燃油轨软管总成 | HOSE ASSEMBLY FSM To Fuel Rail | 1 |
| 18 | 8M0142444 | 燃油供给模块至右舷轨软管总成 | HOSE ASSEMBLY FSM To Starboard Rail | 1 |
| 19 | 8M0142476 | 右舷燃油轨盖 | COVER Fuel Rail, Starboard | 1 |
| 20 | 8M0142445 | 卡扣 | CLIP | 1 |
| 21 | 899145 | 绑带夹 | CLIP Tie Strap | 2 |
| 22 | 8M0142446 | 罩壳至燃油供给模块软管总成 | HOSE ASSEMBLY Cowl to FSM | 1 |
| 23 | 8M0106635 | 燃油滤清器 | FUEL FILTER | 1 |
| 23 | 8M0176313 | 燃油滤清器 | FUEL FILTER | 1 |
| 24 | 8M0142430 | 燃油滤清器至燃油供给模块软管 | HOSE Fuel Filter to FSM | 1 |
| 24 | 8M0203776 | 燃油滤清器至燃油供给模块软管 | HOSE Fuel Filter to Fuel Supply Module | 1 |
| 25 | 8M0037209 | 燃油供给模块固定衬套 | GROMMET FSM Retainer | 1 |
| 26 | 8M0142722 | 燃油供给模块支架 | BRACKET FSM | 1 |
| 27 | 8M0142724 | 护孔环 | GROMMET | 5 |
| 28 | 8M0103805 | 螺丝 (M6 x 16毫米) 不锈钢 | SCREW (M6 x 16 mm) Stainless Steel | 4 |
| 29 | 8M0208431 | 燃油入口套件3/8英寸转1/2英寸 | FUEL INLET KIT 3/8 Inch to 1/2 Inch | 1 |
| 30 | 8M0157397 | 欧梯克卡箍17.5 | CLAMP Oetiker, 17.5 | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 880686T60 | 齿轮箱总成-标准型-长轴 | GEAR HOUSING ASSEMBLY Complete-Standard-Long | 1 |
| - | 880686T61 | 齿轮箱总成-标准型-加长轴 | GEAR HOUSING ASSEMBLY Complete-Standard-X-Long | 1 |
| - | 880686T63 | 齿轮箱总成-标准型-超长轴 | GEAR HOUSING ASSEMBLY Complete-Standard-XX-Long | 1 |
| - | 8M0049872 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 880686T65 | 齿轮箱总成-反转型-长轴 | GEAR HOUSING ASSEMBLY Complete-Counter Rotation-Long | 1 |
| - | 880686T62 | 齿轮箱总成-反转型-加长轴 | GEAR HOUSING ASSEMBLY Complete-Counter Rotation X-Long | 1 |
| - | 8M0049871 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 880686T64 | 齿轮箱总成-反转型-超长轴 | GEAR HOUSING ASSEMBLY Complete-Counter Rotation-XX-Long | 1 |
| 1 | 880686T66 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 2 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 3 | 79953A04 | 塞组件(.375-16×.250) | PLUG ASSEMBLY (.375-16 x .250) | 1 |
| 4 | 830749 | 密封件 | SEAL | 1 |
| 4 | 8M0204693 | 放油螺塞密封件 | SEAL Drain Plug | 1 |
| 5 | 847635001 | 阳极块 | ANODE | 1 |
| 6 | 8M0036047 | 螺钉(0.375x0.62英寸) | SCREW (.375 x .62) | 2 |
| 7 | 841388 | 垫圈(0.410x0.810x0.050英寸)不锈钢 | WASHER (.410 x .810 x .050) Stainless Steel | 2 |
| 8 | 817072 | 滚柱轴承 | BEARING Roller | 1 |
| 9 | 8M0033810 | 水道板 | PLATE Water Passge | 1 |
| 10 | 8M0033809 | 水泵垫片 | GASKET Water Pump | 1 |
| 11 | 8M8022275 | 换挡轴盖总成 | COVER ASSEMBLY Shift Shaft | 1 |
| 12 | 8164641 | 油封 | SEAL Oil | 1 |
| 12 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 13 | 896522 | O型圈(799×.103) | O-RING (799 x .103) | 1 |
| 14 | 1993720 | 螺钉 (M6 x 20) | SCREW (M6 x 20) | 4 |
| 14 | 8M0204706 | 螺丝M6x20六角 | SCREW M6 x 20 Hex | 4 |
| 15 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| 16 | 8M0033641 | 衬垫 | GASKET | 1 |
| 17 | 824145 | 换档轴 | SHIFT SHAFT | 1 |
| 18 | NSS | 不单独销售-16齿小齿轮 | NOT SOLD SEPARATE Pinion Gear 16 Teeth | 1 |
| 19 | 8M0030976 | 螺母 | NUT | 1 |
| 20 | 888572T01 | 长驱动轴 | DRIVESHAFT Long | 1 |
| 20 | 888573T01 | 加长驱动轴 | DRIVESHAFT X-Long | 1 |
| 20 | 888574T01 | 传动轴 超长型 | DRIVESHAFT XX-Long | 1 |
| 21 | 884327A02 | 垫片/轴承组件 | SHIM/BEARING ASSEMBLY | 1 |
| 22 | 38657A1 | 垫片组 | SHIM ASSEMBLY | AR |
| 22 | 8M0063268 | 垫片组 | SHIM SET | AR |
| 23 | NSS | 不单独销售 滚子轴承组件 | NOT SOLD SEPARATE Roller Bearing Assembly | 1 |
| 24 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 25 | NSS | 不单独销售 滚子轴承组件 | NOT SOLD SEPARATE Roller Bearing Assembly | 1 |
| 26 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 27 | 8245191 | 固定座 | RETAINER | 1 |
| 28 | 817275A13 | 水泵总成(完整) | WATER PUMP ASSEMBLY Complete | 1 |
| 29 | 861415A1 | 密封套件 | SEAL KIT | 1 |
| 30 | 1993720 | 螺钉 (M6 x 20) | SCREW (M6 x 20) | 4 |
| 30 | 8M0204706 | 螺丝M6x20六角 | SCREW M6 x 20 Hex | 4 |
| 31 | 43026T2 | 叶轮 | IMPELLER | 1 |
| 32 | 8M0032833 | 键 | KEY | 1 |
| 32 | 8M0204723 | 键 | KEY | 1 |
| 33 | 8172771 | 水泵上垫片 | GASKET Water Pump, Upper | 1 |
| 34 | 8172761 | 面板 | FACEPLATE | 1 |
| 34 | 8M0204709 | 面板 | FACEPLATE | 1 |
| 35 | 430331 | 衬垫 | GASKET | 1 |
| 36 | 880719 | 挡圈 | RING Retaining | 1 |
| 37 | 8M8022274 | 油封座组件 | CARRIER ASSEMBLY Oil Seal | 1 |
| 37 | 8M8023745 | 托架总成 | CARRIER ASSY | 1 |
| 38 | 896523 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 38 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 39 | NSS | 不单独销售 油封 | NOT SOLD SEPARATE Oil Seal | 1 |
| 40 | NSS | 不单独销售 油封 | NOT SOLD SEPARATE Oil Seal | 1 |
| 41 | 43585 | 联轴器 | COUPLING | 1 |
| - | 830749A02 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| - | 43026Q06 | 水泵叶轮维修套件 | REPAIR KIT Water Pump Impeller | 1 |
| - | 8M0100526 | 水泵叶轮维修套件 | REPAIR KIT Water Impeller | 1 |
| - | 817275A08 | 水泵上修包 | REPAIR KIT Water Pump-Upper | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 880686T60 | 齿轮箱总成-标准型-长轴 | GEAR HOUSING ASSEMBLY Complete-Standard-Long | 1 |
| - | 880686T61 | 齿轮箱总成-标准型-加长轴 | GEAR HOUSING ASSEMBLY Complete-Standard-X-Long | 1 |
| - | 880686T63 | 齿轮箱总成-标准型-超长轴 | GEAR HOUSING ASSEMBLY Complete-Standard-XX-Long | 1 |
| - | 8M0049872 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 880686T65 | 齿轮箱总成-反转型-长轴 | GEAR HOUSING ASSEMBLY Complete-Counter Rotation-Long | 1 |
| - | 880686T62 | 齿轮箱总成-反转型-加长轴 | GEAR HOUSING ASSEMBLY Complete-Counter Rotation X-Long | 1 |
| - | 8M0049871 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 880686T64 | 齿轮箱总成-反转型-超长轴 | GEAR HOUSING ASSEMBLY Complete-Counter Rotation-XX-Long | 1 |
| 1 | 880686T66 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 2 | NSS | 不单独销售 塞 | NOT SOLD SEPARATE Plug | 1 |
| 3 | 896847A01 | 换挡曲柄5/16枢轴销 | CRANK, Shifter 5/16 Pivot Pin | 1 |
| 4 | 896847A01 | 换挡曲柄5/16枢轴销 | CRANK, Shifter 5/16 Pivot Pin | 1 |
| 5 | 19755T7 | 阀芯总成 | SPOOL ASSEMBLY | 1 |
| 5 | 8M0235940 | 阀芯总成 | SPOOL ASSY | 1 |
| 6 | NSS | 不单独销售线轴 | NOT SOLD SEPARATE Spool | 1 |
| 7 | 469501 | 开口销 | COTTER PIN | 1 |
| 8 | NSS | 不单独销售 调节套筒 | NOT SOLD SEPARATE Sleeve Adjusting | 1 |
| 9 | 892595A06 | 前进齿轮套件 | GEAR KIT Forward | 1 |
| 10 | 884323T01 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 10 | 8M0142836 | 圆锥滚子轴承(外圈/内圈) | BEARING Roller Taper (Cup/Cone) | 1 |
| 11 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 12 | 23721 | 挡圈 | RING Retaining | 1 |
| 12 | 8M0051043 | 挡圈 | RING Retaining | 1 |
| 13 | 892805 | 止推垫片 | THRUST WASHER | 1 |
| 13 | 8M0053823 | 止推垫圈(内径1.50×外径2.046) | WASHER Thrust, (1.50 ID x 2.046 OD) | 1 |
| 14 | 884325T01 | 圆锥滚子轴承组件 | BEARING ASSEMBLY Roller-Tappered | 1 |
| 14 | 8M0142835 | 圆锥滚子轴承(外圈/内圈) | BEARING Roller Taper (Cup/Cone) | 1 |
| 15 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 16 | 884328A01 | 垫片组 | SHIM SET | AR |
| 16 | 8M0063270 | 垫片组 | SHIM SET | AR |
| 17 | 30893 | 弹簧 | SPRING | 1 |
| 18 | 880714T02 | 离合器 | CLUTCH | 1 |
| 19 | 8M0020941 | 十字销 | PIN Cross | 1 |
| 19 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 20 | 828356 | 定位销 | PIN Detent | 1 |
| 21 | 888530T01 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 22 | 880707A03 | 倒档与小齿轮组 | GEAR SET Reverse and Pinion | 1 |
| 23 | 8M0030983 | 止推垫圈 | WASHER Thrust | 1 |
| 24 | 892818 | 适配器 | ADAPTER | 1 |
| 24 | 8M0053183 | 前进齿轮适配器 | ADAPTER Foward Gear | 1 |
| 25 | 8M8023633 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 26 | 815480 | 推力轴承 | BEARING Thrust | 1 |
| 27 | 8M0000190 | O型圈(4.475x0.210英寸) | O-RING (4.475 x .210) | 1 |
| 28 | 814653T | 滚针轴承总成 | BEARING ASSEMBLY Needle Rollers | 1 |
| 29 | 880728 | 轴承适配器 | ADAPTER Bearing | 1 |
| 29 | 8M0148384 | 前进齿轮轴承适配器 | ADAPTER Bearing Forward Gear | 1 |
| 30 | 47397A1 | 垫片组 | SHIM SET | AR |
| 31 | 891936A01 | 垫片组 | SHIM SET | AR |
| 32 | 884330T01 | 圆锥轴承组件 | BEARING ASSEMBLY Taper | 1 |
| 32 | 8M0148319 | 圆锥滚子轴承(外圈/内圈) | BEARING Roller Taper Cup/Cone | 1 |
| 33 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 34 | 888483 | 油封 | SEAL Oil | 2 |
| 34 | 8M0204700 | 油封 | SEAL Oil | 2 |
| 35 | 880717A01 | 螺丝/密封套件 | SCREW/SEAL KIT | 1 |
| 36 | 830749 | 密封件 | SEAL | 1 |
| 36 | 8M0204693 | 放油螺塞密封件 | SEAL Drain Plug | 1 |
| 37 | 891919001 | 止推隔套 | SPACER Thrust | 1 |
| 38 | 8M0027416 | 锁紧垫圈 | TAB WASHER | 1 |
| 39 | 8M0001491 | 固定螺母 | NUT Retainer | 1 |
| 39 | 8M0162798 | 轴承座固定环 | RETAINER Bearing Carrier | 1 |
| - | 8M8023718 | 齐平式盖板套件-标准型 | COVER KIT Flush-Standard | 1 |
| - | 8M8023719 | 齐平式盖板套件-0.03英寸加长型 | COVER KIT Flush-.03 Extension | 1 |
| 40 | 8M0033816 | 盖板 | COVER | 1 |
| 41 | 8M0036819 | 紧定螺钉(10-32) | SET SCREW (10-32) | 1 |
| - | 830749A02 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 803545T2 | 凸轮轴 | CAMSHAFT | 1 |
| 1 | 8M0147019 | 凸轮轴 | CAMSHAFT | 1 |
| 1 | 803545T1 | 凸轮轴 | CAMSHAFT | 1 |
| 1 | 803545T | 凸轮轴 | CAMSHAFT | 1 |
| 1 | 803545T2 | 凸轮轴 | CAMSHAFT | 1 |
| 1 | 8M0147019 | 凸轮轴 | CAMSHAFT | 1 |
| 2 | 803546 | 挺杆 | LIFTER | 2 |
| 3 | 803547 | 推杆 | PUSH ROD | 2 |
| 4 | 803548 | 安装板 | PLATE | 1 |
| 5 | 8035097 | 螺栓 | BOLT | 2 |
| 6 | 803549 | 摇臂 | ROCKER ARM | 2 |
| 6 | 8M0056319 | 摇臂 | ROCKER ARM | 2 |
| 7 | 803550 | 枢轴 | PIVOT | 2 |
| 8 | 803551 | 螺母 | NUT | 2 |
| 8 | 803551001 | 螺母 | NUT | 2 |
| 9 | 803553T | 排气阀 | VALVE Exhaust | 1 |
| 9 | 8M0056316 | 排气阀 | VALVE Exhaust | 1 |
| 10 | 803552T | 进气阀 | VALVE Intake | 1 |
| 10 | 8M0056312 | 进气阀 | VALVE Intake | 1 |
| 11 | 803598 | 阀座 | SEAT | 2 |
| 11 | 8M0158660 | 气门弹簧座 | SEAT VALVE SPRING | 2 |
| 12 | 8035544 | 弹簧 | SPRING | 2 |
| 12 | 898101214 | 气门弹簧 | SPRING Valve | 2 |
| 13 | 803555 | 固定座 | RETAINER | 2 |
| 13 | 8M0152418 | 固定座总成 | RETAINER ASSEMBLY | 2 |
| 14 | 803556 | 气门锁夹 | KEEPER Valve | 4 |
| 14 | 8M0152418 | 固定座总成 | RETAINER ASSEMBLY | 4 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 878355A1 | 燃油箱总成 | TANK ASSEMBLY Fuel | 1 |
| 1 | 878355A2 | 燃油箱总成 | TANK ASSEMBLY Fuel | 1 |
| 2 | 878352A1 | 燃油盖总成 | CAP ASSEMBLY Fuel | 1 |
| 2 | 8M0056977 | 盖总成 | CAP ASSEMBLY | 1 |
| 2 | 878352A2 | 燃油盖总成 | CAP ASSEMBLY Fuel | 1 |
| 2 | 8M0058610 | ORD 8M0126977 | ORD 8M0126977 | 1 |
| 3 | 878353 | 衬垫 | GASKET | 1 |
| 3 | 8M0126977 | 燃油箱盖 | CAP-FUEL TANK | 1 |
| 4 | 878354 | 密封件 | SEAL | 1 |
| 5 | 4000330 | 螺钉(M6x25) | SCREW (M6 x 25) | 2 |
| 5 | 8M0204707 | 不锈钢六角大帽螺钉(M6x25) | SCREW M6 x 25 HX HD CAP SS | 2 |
| 6 | 161404 | 垫圈 | WASHER | 4 |
| 7 | 8537437 | 橡胶支座 | MOUNT Rubber | 4 |
| 8 | 8537154 | 隔套 | SPACER | 2 |
| 8 | 853715007 | 隔套 | SPACER | 2 |
| 9 | 16705 | 螺栓 | BOLT | 1 |
| 10 | 878388 | 不锈钢螺钉 | SCREW Stainless Steel | 1 |
| 10 | 8M0051381 | 螺钉 | SCREW | 1 |
| 11 | 813275 | 卡箍 | CLAMP | 1 |
| 12 | 881305 | 橡胶支座 | MOUNT Rubber | 1 |
| 13 | 400212 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | AR |
| 14 | 878350 | 支架 | BRACKET | 1 |
| 15 | 878351 | 支架 | BRACKET | 1 |
| 16 | 953949 | 燃油管(1000毫米)(9.875英寸) | LINE Fuel (1000 mm) (9.875 Inch) | 1 |
| 16 | 8M0057113 | 油管 | TUBING | 1 |
| 17 | 95395 | 不锈钢卡扣 | CLIP Stainless Steel | 14 |
| 18 | 953949 | 燃油管(1000毫米)(14.00英寸) | LINE Fuel (1000 mm) (14.00 Inch) | 1 |
| 18 | 8M0057113 | 油管 | TUBING | 1 |
| 19 | 878387 | 燃油旋塞总成 | FUEL COCK ASSEMBLY | 1 |
| 20 | 815046 | 不锈钢螺钉 | SCREW Stainless Steel | 2 |
| 21 | 953949 | 燃油管(1000毫米)(1.375英寸) | LINE Fuel (1000 mm) (1.375 Inch) | 1 |
| 21 | 8M0057113 | 油管 | TUBING | 1 |
| 22 | 953949 | 燃油管(1000毫米)(8.50英寸) | LINE Fuel (1000 mm) (8.50 Inch) | 1 |
| 22 | 8M0057113 | 油管 | TUBING | 1 |
| 23 | 73318 | 塑料三通 | TEE Plastic | 1 |
| 24 | 953949 | 燃油管(1000毫米)(5.25英寸) | LINE Fuel (1000 mm) (5.25 Inch) | 1 |
| 24 | 8M0057113 | 油管 | TUBING | 1 |
| 25 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 2 |
| 26 | 815048 | 塑料接头 | CONNECTOR Plastic | 1 |
| 27 | 815049 | 橡胶软管(1.75英寸) | HOSE Rubber (1.75 Inch) | 1 |
| 27 | 8M0168427 | 软管 | HOSE | 1 |
| 28 | 15781A5 | 燃油接头(黄铜) | CONNECTOR Fuel - Brass | 1 |
| 28 | 8M0182334 | 燃油接头 | CONNECTOR FUEL | 1 |
| 29 | 4000333 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 1 |
| 30 | 16826 | 不锈钢垫圈 | WASHER Stainless Steel | 1 |
| 31 | 878311 | 盖帽 | CAP | 1 |
| 32 | 16248 | 燃油滤清器 | FILTER Fuel | 1 |
| 32 | 8M0157133 | 燃油滤清器 | FILTER Fuel | 1 |
| 33 | 17668 | 软管(7.125英寸) | HOSE (7.125 Inch) | 1 |
| 34 | 8797051 | 套筒 | SLEEVE | 1 |
| 35 | 82304235 | 螺栓(M6 x 45) | BOLT (M6 x 45) | 1 |
| 35 | 82304221 | 螺栓 | BOLT | 1 |
| 36 | 162232 | 螺栓 | BOLT | 1 |
| 36 | 8230421 | 螺栓 | BOLT | 1 |
| 37 | 881306 | 安装板 | PLATE | 1 |
| 38 | 881307 | 隔套 | SPACER | 1 |
| 38 | 881307001 | 隔套 | SPACER | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | NOPART | 无零件清单 | NO PARTS LIST | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 82303110 | 螺钉(M5×16) | SCREW (M5 x 16) | 1 |
| 2 | 803543 | 止动器 | STOPPER | 1 |
| 3 | 952237 | 油管 | TUBING | 1 |
| 4 | 8035202 | 密封件 | SEAL | 2 |
| 5 | 855558 | 螺钉(M5×16) | SCREW (M5 x 16) | 2 |
| 6 | 160721 | 垫圈 | WASHER | 2 |
| 7 | 803540 | 滤网壳体 | HOUSING Strainer | 1 |
| 8 | 803542 | 滤网 | STRAINER | 1 |
| 9 | 803541 | 杯套 | CUP | 1 |
| 10 | 16119 | 定位销 | PIN Dowel | 2 |
| 11 | 803539 | 引线 | LEAD WIRE | 1 |
| 12 | 803538 | 油压开关总成 | SWITCH ASSEMBLY Oil Pressure | 1 |
| 12 | 8M0163139 | 油压开关总成 | SWITCH ASSEMBLY Oil Pressure | 1 |
| 13 | 8035135 | 护孔环 | GROMMET | 1 |
| 14 | 168305 | 螺栓 (M6 x 20) | BOLT (M6 x 20) | 3 |
| 14 | 810755007 | 螺栓 | BOLT | 3 |
| 15 | 803532 | 排气板 | PLATE Exhaust | 1 |
| 15 | 803532001 | 排气板 | PLATE Exhaust | 1 |
| 16 | 8035088 | 衬垫 | GASKET | 1 |
| 16 | 803508015 | 衬垫 | GASKET | 1 |
| 17 | 803531T | 油底壳 | PAN Oil | 1 |
| 17 | 8M0227936 | 油底壳 | OIL PAN | 1 |
| 17 | 803531T01 | 油底壳 | PAN Oil | 1 |
| 17 | 8M0227936 | 油底壳 | OIL PAN | 1 |
| 18 | 168306 | 螺栓(M6x40) | BOLT (M6 x 40) | 3 |
| 19 | 8035331 | 外转子 | ROTOR Outer | 1 |
| 20 | 162563 | 销 | PIN | 1 |
| 21 | 803533 | 内转子 | ROTOR Inner | 1 |
| 22 | 8035134 | O型圈 | O-RING | 1 |
| 22 | 803513010 | O型圈 | O-RING | 1 |
| 23 | 803534 | 盖板 | COVER | 1 |
| 24 | 168287 | 螺栓(M6 x 16) | BOLT (M6 x 16) | 2 |
| 25 | 167051 | 螺栓 (M6 x 20) | BOLT (M6 x 20) | 2 |
| 26 | 8150162 | 壳体 | HOUSING | 1 |
| 27 | 16703 | 油封 | SEAL Oil | 2 |
| 27 | 8M0101649 | 密封件 | SEAL | 2 |
| 28 | 815018 | 隔套 | SPACER | 1 |
| 29 | 16704 | 衬垫 | GASKET | 1 |
| 29 | 8M0152378 | 曲轴箱衬垫 | GASKET Crankcase | 1 |
| 30 | 8537077 | 油封 | SEAL Oil | 1 |
| 30 | 8M0056308 | 油封 | OIL SEAL | 1 |
| 31 | 8035096 | 螺栓 | BOLT | 1 |
| 31 | 803509021 | 螺栓 | BOLT | 1 |
| 32 | 8035161 | 垫圈 | WASHER | 1 |
| 33 | 8150685 | 螺栓(M8x40) | BOLT (M8 x 40) | 6 |
| 34 | 8035087 | 衬垫 | GASKET | 1 |
| 34 | 803508014 | 衬垫 | GASKET | 1 |
| 35 | 803535 | 控制柱塞 | CONTROL PLUNGER | 1 |
| 36 | 8035541 | 弹簧 | SPRING | 1 |
| 37 | 168231 | O型圈 | O-RING | 1 |
| 38 | 803536 | 阀座 | SEAT | 1 |
| 39 | 803537 | 盖板 | COVER | 1 |
| 40 | 168287 | 螺栓(M6 x 16) | BOLT (M6 x 16) | 1 |
| - | 803508A99 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 8M0114820 | 动力头衬垫 | POWERHEAD GASKET | 1 |
| - | 803508A05 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 898103T61 | 手拉启动器总成 | STARTER ASSEMBLY Recoil | 1 |
| 2 | 898101316 | 弹簧 | SPRING | 1 |
| 3 | 898101317 | 卷轴 | REEL | 1 |
| 4 | 898101318 | 棘轮 | RATCHET | 2 |
| 5 | 898101319 | 回位弹簧 | SPRING Return | 2 |
| 6 | 898101320 | 摩擦片 | PLATE Friction | 1 |
| 7 | 898101321 | 螺钉 | SCREW | 1 |
| 8 | 898101322 | 摩擦弹簧 | SPRING Friction | 1 |
| 9 | 8M0160482 | 启动绳 | ROPE Starter | 1 |
| 10 | 898101324 | 起动手柄 | HANDLE Starter | 1 |
| 11 | 898101325 | 锚绳 | ANCHOR Rope | 1 |
| 12 | 898101366 | 锚绳板 | PLATE Rope Anchor | 1 |
| 13 | 803720001 | 启动器密封件 | SEAL Starter | 1 |
| 13 | 8M0138706 | 启动器密封件 | SEAL Starter | 1 |
| 14 | 898101327 | 螺钉 | SCREW | 3 |
| 15 | 895118002 | 垫圈 | WASHER | 3 |
| 15 | 953921 | 不锈钢垫圈 | WASHER Stainless Steel | 3 |
| 16 | 8035631 | 卡箍 | CLAMP | 1 |
| 16 | 803563005 | 卡箍 | CLAMP | 1 |
| - | 898103193 | 干扰贴花 | DECAL Interferance | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 16908A1 | 遥控装置 | REMOTE CONTROL | 1 |
| 1 | 16910A1 | 前壳体套件含标贴-前部 | HOUSING KIT Front With Decals-Front | 1 |
| 2 | 89774 | 堵头 | PLUG | 1 |
| 3 | 17192 | 停机开关孔塞 | PLUG Stop Switch Hole | 1 |
| 4 | 17191 | 线束孔塞 | PLUG Wire Harness Hole | 1 |
| 5 | 16917 | 盖板 | COVER | 1 |
| 6 | 16899 | 空档锁支架 | HOLDER Neutral Lock | 1 |
| 6 | 16899T | 空档锁支架 | HOLDER Neutral Lock | 1 |
| 7 | 40118107 | 螺钉（M5×18） | SCREW (M5 x 18) | 7 |
| 8 | 16923 | 外锁紧垫圈 | LOCKWASHER External | 2 |
| 9 | 16913T | 杠杆 | LEVER | 1 |
| 10 | 16916A1 | 盖总成含标贴 | CAP ASSEMBLY With Decal | 1 |
| 11 | 16921 | 锁杆支架 | BRACKET Lock Bar Support | 1 |
| 12 | 4005685 | 螺钉（M4×10） | SCREW (M4 x 10) | 2 |
| 13 | 16915 | 锁臂 | LOCK ARM | 1 |
| 14 | 40056105 | 螺钉 (M5 x 10) | SCREW (M5 x 10) | 1 |
| 15 | 16924 | 弹簧 | SPRING | 1 |
| 16 | 16914 | 握把 | GRIP | 1 |
| 17 | 17016 | 堵头 | PLUG | 1 |
| 18 | 40116110 | 螺钉（M6×110） | SCREW (M6 x 110) | 3 |
| 18 | 40116110T | 螺钉（M6×110） | SCREW (M6 x 110) | 3 |
| 19 | 35280 | 垫圈(.255 x .620 x .030) 不锈钢 | WASHER (.255 x .620 x .030) Stainless Steel | 3 |
| 20 | 401196 | 螺母 (M6) | NUT (M6) | 3 |
| 21 | 16920 | 制动调节器 | BRAKE ADJUSTER | 1 |
| 22 | 16896 | 垫圈 | WASHER | 1 |
| 23 | 13194 | 挡圈 | RING Retaining | 1 |
| 24 | 16895 | 制动臂总成 | ARM ASSEMBLY Brake | 1 |
| 25 | 16875 | 轴承(1.750内径) | BEARING (1.750 Inside Diameter) (1.750 ID) | 2 |
| 26 | 16874 | 垫圈 | WASHER | 1 |
| 27 | 16892T | 驱动齿轮 | GEAR Drive | 1 |
| 28 | 850724A2 | 板/螺柱总成 | PLATE/STUD ASSEMBLY | 1 |
| 29 | 16873 | 凸轮滚轮 | ROLLER Cam | 1 |
| 30 | 4007154 | 螺钉 (M8 x 30) | SCREW (M8 x 30) | 1 |
| 31 | 12038 | 垫圈 | WASHER | 1 |
| 31 | 8M0207778 | 垫圈（0.344×0.625×0.063英寸） | WASHER .344 x .625 x.063 | 1 |
| 32 | 85899A1 | 卡箍总成 | CLIP ASSEMBLY | 2 |
| 33 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 2 |
| 34 | 16918A3 | 换挡总成 | GEAR SHIFT ASSEMBLY | 1 |
| 35 | 16868 | 轴承(0.750内径) | BEARING (.750 Inside Diameter) (.750 ID) | 1 |
| 36 | 16870 | 垫圈 | WASHER | 1 |
| 37 | 16882 | 弹簧 | SPRING | 5 |
| 38 | 16879 | 定位滚轮 | ROLLER Detent | 1 |
| 39 | 16880 | 卡扣 | CLIP | 1 |
| 40 | 4005683 | 螺钉（M4×6） | SCREW (M4 x 6) | 2 |
| 41 | 16888 | 弹簧 | SPRING | 1 |
| 42 | 16886 | 卡扣 | CLIP | 1 |
| 43 | 16884 | 滚轮 | ROLLER | 1 |
| 44 | 16883 | 鼓轮总成 | DRUM ASSEMBLY | 1 |
| 45 | 16922 | 波形垫圈 | WAVE WASHER | 1 |
| 46 | 16912T | 下盖 | COVER Bottom | 1 |
| 46 | 881170A8 | 手动启动遥控器（无动力升降） | REMOTE CONTROL Manual Start - Non Power Trim | 1 |
| 47 | 16911T | 上盖 | COVER Top | 1 |
| 48 | 16887 | 轴承(0.810内径) | BEARING (.810 Inside Diameter) (.810 ID) | 1 |
| 49 | 16919A1 | 带贴花杆总成 | LEVER ASSEMBLY With Decal | 1 |
| 50 | 40118106 | 螺钉(M5 x 12) | SCREW (M5 x 12) | 2 |
| 51 | 17063T | 隔套 | SPACER | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 881170A8 | 手动启动遥控器（无动力升降） | REMOTE CONTROL Manual Start - Non Power Trim | 1 |
| - | 8M0178530 | 遥控装置 | REMOTE CONTROL | 1 |
| 1 | NSS | 不单独销售-前壳体 | NOT SOLD SEPARATE Housing-Front | 1 |
| 2 | NSS | 不单独销售-前进空倒标贴 | NOT SOLD SEPARATE Decal-F-N-R | 1 |
| 3 | NSS | 不单独销售-油门摩擦标贴 | NOT SOLD SEPARATE Decal-Throttle Friction | 1 |
| 4 | NSS | 不单独销售-运行/关闭标贴 | NOT SOLD SEPARATE Decal-Run/Off | 1 |
| 5 | 89774 | 钥匙开关孔塞 | PLUG Key Swith Hole | 1 |
| 6 | 17192 | 停机开关孔塞 | PLUG Stop Switch Hole | 1 |
| 7 | 17191 | 线束孔塞 | PLUG Wire Harness Hole | 1 |
| 8 | 4005685 | 螺钉（M4×10） | SCREW (M4 x 10) | 2 |
| 9 | 16921 | 锁杆支架 | BRACKET Lock Bar Support | 1 |
| 10 | 87775510 | 螺钉（M4×10） | SCREW (M4 x 10) | 1 |
| 11 | 881138 | 红色锁杆 | LOCK BAR Red | 1 |
| 11 | 8M0207317 | 黑色锁杆 | LOCK BAR-BLACK | 1 |
| 12 | 16924 | 弹簧 | SPRING | 1 |
| 13 | 881139T2 | 轮毂手柄 | HUB Handle | 1 |
| 14 | 8811411 | 握把 | GRIP | 1 |
| 15 | 881146 | 堵头 | PLUG | 1 |
| 16 | 881137A1 | 盖/贴花总成 | CAP/DECAL ASSEMBLY | 1 |
| 17 | 40118107 | 螺钉（M5×18） | SCREW (M5 x 18) | 7 |
| 18 | 16923 | 外锁紧垫圈 | LOCKWASHER External | 2 |
| 19 | 16899 | 空档锁支架 | HOLDER Neutral Lock | 1 |
| 19 | 16899T | 空档锁支架 | HOLDER Neutral Lock | 1 |
| 20 | 16917 | 盖板 | COVER | 1 |
| 21 | 40116110 | 螺钉（M6×110） | SCREW (M6 x 110) | 3 |
| 21 | 40116110T | 螺钉（M6×110） | SCREW (M6 x 110) | 3 |
| 22 | 881145 | 油门摩擦旋钮 | KNOB Throttle Friction | 1 |
| 23 | 16896 | 垫圈 | WASHER | 1 |
| 24 | 13194 | 挡圈 | RING Retaining | 1 |
| 25 | 16895 | 制动臂总成 | ARM ASSEMBLY Brake | 1 |
| 26 | 16875 | 轴承(1.750内径) | BEARING (1.750 Inside Diameter) (1.750 ID) | 2 |
| 27 | 16874 | 垫圈 | WASHER | 1 |
| 28 | 401385 | 不锈钢螺母(M5) | NUT (M5) Stainless Steel | 2 |
| 29 | 85899A1 | 卡箍总成 | CLIP ASSEMBLY | 2 |
| 30 | NSS | 不单独出售换挡总成 | NOT SOLD SEPARATE Gear Shift Assembly | 1 |
| 31 | 16868 | 轴承(0.750内径) | BEARING (.750 Inside Diameter) (.750 ID) | 1 |
| 32 | 16870 | 垫圈 | WASHER | 1 |
| 33 | 16873 | 凸轮滚轮 | ROLLER Cam | 1 |
| 34 | NSS | 不单独出售驱动齿轮 | NOT SOLD SEPARATE Drive Gear | 1 |
| 35 | NSS | 不单独销售 板/螺柱总成 | NOT SOLD SEPARATE Plate/Stud Assembly | 1 |
| 36 | 12038 | 垫圈 | WASHER | 1 |
| 36 | 8M0207778 | 垫圈（0.344×0.625×0.063英寸） | WASHER .344 x .625 x.063 | 1 |
| 37 | 4007154 | 螺钉 (M8 x 30) | SCREW (M8 x 30) | 1 |
| 38 | 4005683 | 螺钉（M4×6） | SCREW (M4 x 6) | 2 |
| 39 | 16886 | 卡扣 | CLIP | 1 |
| 40 | 16888 | 弹簧 | SPRING | 1 |
| 41 | 16884 | 滚轮 | ROLLER | 1 |
| 42 | 16883 | 鼓轮总成 | DRUM ASSEMBLY | 1 |
| 43 | 16922 | 波形垫圈 | WAVE WASHER | 1 |
| 44 | NSS | 不单独销售 底盖 | NOT SOLD SEPARATE Cover-Bottom | 1 |
| 45 | NSS | 不单独销售 顶盖 | NOT SOLD SEPARATE Cover-Top | 1 |
| 46 | 16887 | 轴承(0.810内径) | BEARING (.810 Inside Diameter) (.810 ID) | 1 |
| 47 | 40118106 | 螺钉(M5 x 12) | SCREW (M5 x 12) | 2 |
| 48 | 16919A1 | 杠杆总成 | LEVER ASSEMBLY | 1 |
| 49 | NSS | 不单独销售 快怠速提升贴花 | NOT SOLD SEPARATE Decal-Lift for Fast Idle | 1 |
| 50 | 35280 | 垫圈(.255 x .620 x .030) 不锈钢 | WASHER (.255 x .620 x .030) Stainless Steel | 3 |
| 51 | 401196 | 螺母 (M6) | NUT (M6) | 3 |
| 52 | 17063T | 隔套 | SPACER | 1 |
| 53 | 71942 | 衬套 | BUSHING | 1 |
| 54 | 16879 | 定位滚轮 | ROLLER Detent | 1 |
| 55 | 16880 | 卡扣定位器 | CLIP Detent | 1 |
| 56 | 16882 | 定位弹簧 | SPRING Detent | 5 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 803583A2 | 遥控器安装套件 | ATTACHING KIT Remote Control | 1 |
| - | 8M0172938 | 安装套件 | ATTACHING KIT | 1 |
| - | 803583A4 | 遥控器安装套件 | ATTACHING KIT Remote Control | 1 |
| - | 8M0172938 | 安装套件 | ATTACHING KIT | 1 |
| 1 | 170242 | 转向钩板 | PLATE Steering Hook | 1 |
| 1 | 8M0062171 | 安装板 | PLATE | 1 |
| 2 | 4000354 | 螺钉 (M8 x 30) | SCREW (M8 x 30) | 2 |
| 3 | 17023 | 支架 | BRACKET | 1 |
| 4 | 8230421 | 螺栓 | BOLT | 1 |
| 5 | 162233 | 螺钉 | SCREW | 1 |
| 6 | 17029 | 垫圈 | WASHER | 2 |
| 7 | 17028 | 弹簧 | SPRING | 1 |
| 8 | 17027 | 盖帽 | CAP | 1 |
| 9 | 17026 | 支架 | BRACKET | 1 |
| 10 | 804357 | 节气门杠杆总成 | LEVER ASSEMBLY Throttle | 1 |
| 11 | 16221 | 波形垫圈 | WAVE WASHER | 1 |
| 12 | 16219 | 密封件 | SEAL | 1 |
| 13 | 16220 | 衬套 | BUSHING | 1 |
| 14 | 162232 | 螺栓 | BOLT | 1 |
| 15 | 17031 | 锁止销 | PIN Lock | 1 |
| 16 | 17033 | 销 | PIN | 1 |
| 17 | 17032 | 弹簧 | SPRING | 1 |
| 18 | 17030 | 套筒 | SLEEVE | 1 |
| 19 | 400212 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 2 |
| 20 | 803584 | 油门连杆 | ROD Throttle Link | 1 |
| 21 | 16849 | 轴环 | COLLAR | 1 |
| 22 | 803585 | 油门连杆杆 | LEVER Throttle Link | 1 |
| 23 | 804993A1 | 螺母套件 | NUT KIT | 1 |
| 24 | 804992 | 垫圈 | WASHER | 2 |
| 25 | 804993 | 垫圈 | WASHER | 2 |
| 26 | 17035 | 线束总成 | HARNESS ASSEMBLY | 1 |
| 27 | 803588 | 销 | PIN | 2 |
| 28 | 803587 | 节气门拉索 | CABLE Throttle | 1 |
| 29 | 16335 | 垫圈 | WASHER | 2 |
| 30 | 16189 | 开口销 | COTTER PIN | 2 |
| 31 | 803590 | 支架 | BRACKET | 1 |
| 32 | 803589 | 油门连杆 | LINK Throttle | 1 |
| 33 | 16223 | 螺栓(M6x14) | BOLT (M6 x 14) | 1 |
| 34 | 16333 | 卡扣拉杆 | ROD Snap | 1 |
| 35 | 16192 | 垫圈 | WASHER | 2 |
| 36 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 2 |
| 37 | 400213 | 不锈钢螺母 (M8) | NUT (M8) Stainless Steel | 2 |
| 38 | 885154 | 护孔环 | GROMMET | 1 |
| 39 | 855544 | 螺钉总成 | SCREW ASSEMBLY | 2 |
| 40 | 17162 | 线束总成(5.9M) | HARNESS ASSEMBLY (5.9M) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 16074T | 交流发电机 | ALTERNATOR | 1 |
| 2 | 16059 | 螺钉 | SCREW | 2 |
| 3 | 16060 | 卡箍 | CLAMP | 1 |
| 4 | 16821 | 螺钉 | SCREW | 1 |
| 5 | 16076 | 整流器 | RECTIFIER | 1 |
| 5 | 16076A1 | 整流器套装 | RECTIFIER KIT | 1 |
| 5 | 16076A1 | 整流器套装 | RECTIFIER KIT | 1 |
| 6 | 16077 | 保险丝 | FUSE | 1 |
| 7 | 16123 | 螺钉(25毫米) | SCREW (25 mm) | 1 |
| 7 | 16078 | 螺钉 | SCREW | 1 |
| 8 | 16079 | 锁紧垫圈 | LOCKWASHER | 1 |
| 9 | 16080 | 不锈钢垫圈 | WASHER Stainless Steel | 1 |
| 9 | 8M0108373 | 垫圈 | WASHER | 1 |
| 10 | 813275 | 卡箍 | CLAMP | 1 |
| 11 | 16081 | 不锈钢螺母 | NUT Stainless Steel | 1 |
| 12 | 16822 | 延长线束 | HARNESS Extension | 1 |
| 13 | 16823 | 护孔环 | GROMMET | 1 |
| 14 | 16082 | 蓄电池电缆 | CABLE Battery | 1 |
| 15 | 823037A1 | 紧急停止开关总成 | SWITCH ASSEMBLY Emergency Stop | 1 |
| 15 | 823037A04 | 紧急停止开关总成 | SWITCH ASSEMBLY Emergency Stop | 1 |
| 15 | 823037A04 | 紧急停止开关总成 | SWITCH ASSEMBLY Emergency Stop | 1 |
| 16 | 823054 | 拉绳 | LANYARD | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0142639 | 零件手册250R/300R 4.6L V8四冲程 | PARTS MANUAL 250R/300R 4.6L V8 4 Stroke | 1 |
| - | 8M0146888 | 维修手册250R/300R/300R HD 4.6L V8 | SERVICE MANUAL 250R/300R/300R HD 4.6L V8 | 1 |
| - | 8M0145934 | 安装手册V6/V8 CMS | INSTALLATION MANUAL V6/V8 CMS | 1 |
| - | 8M0156797 | 安装手册V6(175-225)/V8(200-300)CMS | INSTALLATION MANUAL V6 (175-225), V8 (200-300) CMS | 1 |
| - | 8M0140588 | 300R HD安装手册 | INSTALLATION MANUAL 300R HD | 1 |
| - | 8M0156799 | IM-300R HD CMS | IM-300R HD CMS | 1 |
| - | 8M0145541 | 操作手册V6/V8 CMS机械式 | OPERATION MANUAL V6/V8 CMS Mechanical | 1 |
| - | 8M0175491 | 操作手册 | MANUAL- OPERATION | 1 |
| - | 8M0145542 | 操作手册V6/V8 CMS DTS | OPERATION MANUAL V6/V8 CMS DTS | 1 |
| - | 8M0230588 | 操作手册150R和200R | OPERATION MANUAL 150R and 200R | 1 |
| - | 8M0140585 | 300R CMS HD机械版操作手册 | OPERATION MANUAL 300R CMS HD Mechanical | 1 |
| - | 8M0175494 | 操作手册 | MANUAL-OPERATION | 1 |
| - | 8M0140789 | 300R CMS HD DTS版操作手册 | OPERATION MANUAL 300R CMS HD DTS | 1 |
| - | 8M0175495 | 操作手册 | MANUAL-OPERATIONS | 1 |
| - | 8M0146617 | 诊断维修手册 | SERVICE MANUAL Diagnostic | 1 |
| - | 8M0182076 | 诊断手册 | DIAGNOSTIC MANUAL | 1 |
| - | NSS | 不单独销售贴纸, EPA | NOT SOLD SEPARATE DECAL, EPA | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 24937A1 | 固定工具 | HOLDER TOOL | 1 |
| 2 | 58222A1 | 百分表工具 | DIAL INDICATOR TOOL | 1 |
| 3 | 63998A1 | 单腔间隙工具 | GAP TOOL Single Chamber | 1 |
| 4 | 83155 | 千分表转接套件 | ADAPTER KIT Dial Indicator | 1 |
| 4 | 8M0237356 | 适配器套件 | ADAPTER KIT | 1 |
| 5 | 83164M | 飞轮拉拔器 | FLYWHEEL PULLER | 1 |
| 5 | 8M0227579 | 飞轮拉拔器 | FLYWHEEL PULLER | 1 |
| 6 | 890451 | 直流电压适配工具 | ADAPTER TOOL Direct Voltage | 1 |
| 7 | 99379 | 正时灯 | TIMING LIGHT | 1 |
| 8 | 99750A1 | 万用表 | MULTI METER | 1 |
| 9 | 854009A3 | 转速多功能表DMT 2000数字式 | TACH MULTI METER DMT 2000 Digital | 1 |
| 9 | 892647A01 | DMT万用表套件 | MULTI-METER KIT DMT | 1 |
| 10 | 804552 | 飞轮固定/拉拔工具 | HOLDER/PULLER TOOL Flywheel | 1 |
| 10 | 8M0059838 | 飞轮固定/拉拔工具 | HOLDER/PULLER TOOL Flywheel | 1 |
| 11 | 37299Q2 | 黄油枪 | GREASE GUN | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 803565T1 | 转向手柄套件 | HANDLE KIT Steering | 1 |
| 1 | 803565T | 转向手柄 | HANDLE Steering | 1 |
| 2 | 16085 | 销 | PIN | 1 |
| 3 | 16093 | 油门轴 | SHAFT Throttle | 1 |
| 4 | 16338 | 支架 | BRACKET | 1 |
| 5 | 16827 | 螺钉 | SCREW | 1 |
| 6 | 16087 | 调节螺钉 | SCREW Adjusting | 1 |
| 7 | 16826 | 不锈钢垫圈 | WASHER Stainless Steel | 1 |
| 8 | 813026 | 摩擦片 | FRICTION PIECE | 1 |
| 9 | 400212 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 10 | 16094 | 螺钉 | SCREW | 1 |
| 11 | 16086 | 握把 | GRIP | 1 |
| 12 | 803569 | 橡胶轴 | SHAFT Rubber | 1 |
| 13 | 8035671 | 衬套 | BUSHING | 1 |
| 14 | 16090 | 贴花 | DECAL | 1 |
| 14 | 8M0097201 | 舵柄贴花 | DECAL Tiller | 1 |
| 15 | 815028 | 双头螺栓 | STUD BOLT | 2 |
| 16 | 804508 | 垫圈 | WASHER | 1 |
| 17 | 803566 | 隔套 | SPACER | 1 |
| 18 | 803567 | 衬套 | BUSHING | 2 |
| 19 | 16085 | 销 | PIN | 1 |
| 20 | 8035681 | 止动器 | STOPPER | 1 |
| 21 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 2 |
| 22 | 400212 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 2 |
| 23 | 16827 | 螺钉 | SCREW | 1 |
| 24 | 953951 | 卡箍 | CLAMP | 1 |
| 25 | 803570 | 油门拉线 | WIRE Throttle | 2 |
| 25 | 803570001 | 油门拉线 | WIRE Throttle | 1 |
| 26 | 8035731 | 轴环 | COLLAR | 2 |
| 27 | 803575 | 支架 | BRACKET | 1 |
| 28 | 82304235 | 螺栓(M6 x 45) | BOLT (M6 x 45) | 2 |
| 28 | 82304221 | 螺栓 | BOLT | 2 |
| 29 | 803571 | 节流鼓 | DRUM Throttle | 1 |
| 30 | 803574 | 杆 油门 | ROD Throttle | 1 |
| 31 | 803572 | 节气门开启器 | OPENER Throttle | 1 |
| 32 | 803573 | 轴环 | COLLAR | 1 |
| 33 | 953921 | 不锈钢垫圈 | WASHER Stainless Steel | 1 |
| 34 | 82304220 | 螺栓总成 (M6 x 35) | BOLT ASSEMBLY (M6 x 35) | 1 |
| 35 | 803564 | 保护套 | PROTECTIVE SLEEVE | 1 |
| 35 | 853740018 | 保护套 | SLEEVE Protective | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 16908A1 | 遥控装置 | REMOTE CONTROL | 1 |
| 1 | 8M0178530 | 遥控装置 | REMOTE CONTROL | 1 |
| 2 | 8098945 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085942 | T/S拉索G1 5FT | CABLE T/S G1 5FT | 2 |
| 2 | 8098946 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085940 | T/S拉索G1 6FT | CABLE T/S G1 6FT | 2 |
| 2 | 8098947 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085964 | T/S拉索G1 7FT | CABLE T/S G1 7FT | 2 |
| 2 | 8098948 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085941 | T/S拉索G1 8FT | CABLE T/S G1 8FT | 2 |
| 2 | 8098949 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085946 | T/S拉索G1 9FT | CABLE T/S G1 9FT | 2 |
| 2 | 80989410 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085937 | T/S拉索G1 10FT | CABLE T/S G1 10FT | 2 |
| 2 | 80989411 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085951 | T/S拉索G1 11FT | CABLE T/S G1 11FT | 2 |
| 2 | 80989412 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085949 | T/S拉索G1 12FT | CABLE T/S G1 12FT | 2 |
| 2 | 80989413 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085952 | T/S拉索G1 13FT | CABLE T/S G1 13FT | 2 |
| 2 | 80989414 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085945 | T/S拉索G1 14FT | CABLE T/S G1 14FT | 2 |
| 2 | 80989415 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085960 | T/S拉索G1 15FT | CABLE T/S G1 15FT | 2 |
| 2 | 80989416 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085963 | T/S拉索G1 16FT | CABLE T/S G1 16FT | 2 |
| 2 | 80989417 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085956 | T/S拉索G1 17FT | CABLE T/S G1 17FT | 2 |
| 2 | 80989418 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085947 | T/S拉索G1 18FT | CABLE T/S G1 18FT | 2 |
| 2 | 80989419 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085954 | T/S拉索G1 19FT | CABLE T/S G1 19FT | 2 |
| 2 | 80989420 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085957 | T/S拉索G1 20FT | CABLE T/S G1 20FT | 2 |
| 2 | 80989422 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085959 | T/S拉索G1 22FT | CABLE T/S G1 22FT | 2 |
| 2 | 80989424 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085943 | T/S拉索G1 24FT | CABLE T/S G1 24FT | 2 |
| 2 | 80989426 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085950 | T/S拉索G1 26FT | CABLE T/S G1 26FT | 2 |
| 2 | 80989428 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085938 | T/S拉索G1 28FT | CABLE T/S G1 28FT | 2 |
| 2 | 80989430 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 8M0085953 | T/S拉索G1 30FT | CABLE T/S G1 30FT | 2 |
| 2 | 80989432 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 896143A32 | 油门换挡拉索总成 - 32英尺 | CABLE ASSEMBLY Throttle Shift - 32 Feet | 2 |
| 2 | 80989434 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 896143A34 | 油门换挡拉索总成 - 34英尺 | CABLE ASSEMBLY Throttle Shift - 34 Feet | 2 |
| 2 | 80989436 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 896143A36 | 油门换挡拉索总成 - 36英尺 | CABLE ASSEMBLY Throttle Shift - 36 Feet | 2 |
| 2 | 80989438 | 油门换挡拉索总成 | CABLE ASSEMBLY Throttle Shift | 2 |
| 2 | 896143A38 | 油门换挡拉索总成 - 38英尺 | CABLE ASSEMBLY Throttle Shift - 38 Feet | 2 |
| 2 | 80989440 | 油门/换挡线缆总成 | CABLE ASSEMBLY Throttle/Shift | 2 |
| 2 | 896143A40 | 油门换挡拉索总成 - 40英尺 | CABLE ASSEMBLY Throttle Shift - 40 Feet | 2 |
