两冲程 电喷 EFI · USA - Cat.# 90-80494300 · 共 33 个部位 · 1353 条零件
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 0 | 15969A3 | 甲板加油套件 | DECK FILL KIT Oil | 1 |
| 0 | 812497A2 | 二极管总成(双引擎) | DIODE ASSEMBLY (DUAL ENGINE) | 1 |
| 0 | 898289A72 | 双拉绳二极管套件 | DIODE KIT-LANYARD Dual | 1 |
| 0 | 44357A2 | 冲洗附件 | FLUSHING ATTACHMENT | 1 |
| 0 | 44357Q2 | 冲洗附件 | FLUSHING ATTACHMENT | 1 |
| 0 | 827927A8 | 燃油管路总成(8英尺) | LINE ASSEMBLY Fuel (8 Feet) | 1 |
| 0 | 877680Q8 | 燃油软管总成(8英尺) | HOSE ASSEMBLY Fuel (8 Feet) | 1 |
| 0 | 827927A12 | 燃油管路总成(12英尺) | LINE ASSEMBLY Fuel (12 Feet) | 1 |
| 0 | 877680Q12 | 燃油软管总成(12英尺) | HOSE ASSEMBLY Fuel (12 Feet) | 1 |
| 0 | 17146A8 | 燃油管路总成(8英尺) | LINE ASSEMBLY Fuel (8 Feet) | 1 |
| 0 | 877681Q8 | 燃油软管总成(8英尺) | HOSE ASSEMBLY Fuel (8 Feet) | 1 |
| 0 | 17146A12 | 燃油管路总成(12英尺) | LINE ASSEMBLY Fuel (12 Feet) | 1 |
| 0 | 877681Q12 | 燃油软管总成(12英尺) | HOSE ASSEMBLY Fuel (12 Feet) | 1 |
| 0 | 822379A12 | 燃油管路总成(12英尺) | LINE ASSEMBLY Fuel (12 Feet) | 1 |
| 0 | 877683Q12 | 燃油软管总成(12英尺) | HOSE ASSEMBLY Fuel (12 Feet) | 1 |
| 0 | 852400 | 冲洗接头 | FLUSH COUPLING | 1 |
| 0 | 19674A2 | 开关/拉绳套件 | SWITCH/LANYARD KIT | 1 |
| 0 | 19674Q2 | 开关/拉绳套件 | SWITCH/LANYARD KIT | 1 |
| 0 | 88334A2 | 防腐电极套件 | MERCATHODE KIT | 1 |
| 0 | 8M0180081 | 防腐电极套件 | MERCATHODE KIT | 1 |
| 0 | 86300A5 | 防腐电极监测器 | MERCATHODE MONITOR | 1 |
| 0 | 41729A3 | 软管延长套件 | HOSE EXTENSION KIT | 1 |
| 0 | 825191A1 | 索具软管套件 | RIGGING HOSE KIT | 1 |
| 0 | 825191A3 | 停产参见PB99-4 | NLA SEE PB99-4 | 1 |
| 0 | 17334A2 | 视觉警告系统(低油位/过热) | VISUAL WARNING SYSTEM (LOW OIL/OVERHEAT) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 814281A2 | 开关 | SWITCH | 1 |
| 1 | 8M0052931 | 开关 | SWITCH | 1 |
| 2 | 82470620 | 螺钉 (M3.5 x 20) | SCREW (M3.5 x 20) | 2 |
| 3 | 8240102 | 支架 | BRACKET | 1 |
| 3 | 824010T05 | 支架 | BRACKET | 1 |
| 4 | 42975 | 传动螺钉 | DRIVE SCREW | 2 |
| 5 | 824016 | 闩锁 | LATCH | 1 |
| 6 | 824015 | 筒形保持杯 | CUP Barrel Retainer | 2 |
| 7 | 82155025 | 螺丝(M8 x 25 mm)不锈钢 | SCREW (M8 x 25 mm) Stainless Steel | 3 |
| 8 | 824013 | 衬套 | BUSHING | 1 |
| 9 | 812707 | 衬套 | BUSHING | 2 |
| 10 | 824014 | 弹簧 | SPRING | 1 |
| 11 | 8240111 | 导向滚轮 | GUIDE Roller | 1 |
| 12 | 8142391 | 凸轮 | CAM | 1 |
| 12 | 8142392 | 节气门凸轮 | THROTTLE CAM | 1 |
| 13 | 26856 | 衬套 | BUSHING | 2 |
| 14 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 14 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 15 | 825377 | 油门连杆 | LINK Throttle | 1 |
| 16 | 932481 | 衬套 | BUSHING | 2 |
| 16 | 8M0215006 | 旋转衬套 | BUSHING Swivel | 2 |
| 17 | 826205 | 油连杆支架 | BRACKET Oil Link | 1 |
| 18 | 1938526 | 连接杆 | LINK | 1 |
| 18 | 878190 | 连接杆 | LINK | 1 |
| 19 | 82155025 | 螺丝(M8 x 25 mm)不锈钢 | SCREW (M8 x 25 mm) Stainless Steel | 1 |
| 20 | 400635 | 螺母 (M8) | NUT (M8) | 1 |
| 20 | 401388 | 不锈钢螺母 (M8) | NUT (M8) Stainless Steel | 1 |
| 21 | 8252681 | 节气门控制杆 | LEVER Throttle Control | 1 |
| 21 | 8M0040987 | 杠杆 | LEVER | 1 |
| 22 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 1 |
| 22 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 1 |
| 23 | 36042 | 垫圈 | WASHER | 1 |
| 24 | 42927 | 嵌件 | INSERT | 1 |
| 25 | 821113 | 衬套 | BUSHING | 1 |
| 26 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 26 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 27 | 40124 | 螺钉 (M6 x 55) | SCREW (M6 x 55) | 2 |
| 28 | 400212 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 2 |
| 29 | 42942 | 盖帽 | CAP | 2 |
| 30 | 35459 | 垫圈 | WASHER | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 99130122 | 管材(20英尺散装)(裁切至13.25英寸) | TUBING (20.00 Feet Bulk) (Cut to 13-1/4 IN.) | 3 |
| 1 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 3 |
| 2 | 768431 | 接头 | FITTING | 3 |
| 3 | 8348041 | 止回阀 | CHECK VALVE | 5 |
| 4 | 8282182 | 止回阀 | CHECK VALVE | 1 |
| 5 | 99130122 | 管材(20英尺散装)(裁切至5.25英寸) | TUBING (20.00 Feet Bulk) (Cut to 5-1/4 IN.) | 2 |
| 5 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 2 |
| 6 | 99130122 | 管材(20英尺散装)(裁切至8.5英寸) | TUBING (20.00 Feet Bulk) (Cut to 8-1/2 IN.) | 3 |
| 6 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 3 |
| 7 | 99130122 | 管材(20.00英尺散装)(裁切至9-1/2英寸) | TUBING (20.00 Feet Bulk) (Cut to 9-1/2 IN.) | 1 |
| 7 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 8 | 8282182 | 止回阀 | CHECK VALVE | 4 |
| 9 | 8348041 | 止回阀 | CHECK VALVE | 2 |
| 10 | 591692 | 三通接头 | FITTING Tee | 1 |
| 10 | 59169003 | 三通接头 | FITTING Tee | 1 |
| 11 | 99130122 | 管材(20英尺散装)(裁切至5.25英寸) | TUBING (20.00 Feet Bulk) (Cut to 5-1/4 IN.) | 2 |
| 11 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 2 |
| 12 | 99130122 | 管材(20.00英尺散装)(裁切至1英寸) | TUBING (20.00 Feet Bulk) (Cut to 1 IN.) | 1 |
| 12 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 13 | 99130122 | 管材(20英尺散装)(裁切至16英寸) | TUBING (20.00 Feet Bulk) (Cut to 16 IN.) | 1 |
| 13 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| - | 848700A7 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 818448A1 | 下机罩 | BOTTOM COWL | 1 |
| 1 | 818448A2 | 下机罩 | BOTTOM COWL | 1 |
| 1 | 818448A4 | 下机罩 | BOTTOM COWL | 1 |
| 2 | 818447A1 | 下机罩 | BOTTOM COWL | 1 |
| 2 | 818447A2 | 下机罩 | BOTTOM COWL | 1 |
| 2 | 818447A4 | 下机罩 | BOTTOM COWL | 1 |
| 3 | 8253181 | 罩盖密封条(41英寸) | SEAL Cowl (41.00 Inches) | 2 |
| 3 | 8M0109217 | 罩盖密封条 | SEAL-COWL | 2 |
| 4 | 82130040 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 4 |
| 5 | 824868 | 螺钉(M6×75) | SCREW (M6 x 75) | 1 |
| 6 | 821253F1 | 前手柄黑色 | FRONT HANDLE Black | 1 |
| 6 | 889740A02 | 手柄套件 | HANDLE KIT | 1 |
| 6 | 821253F2 | 前手柄 | FRONT HANDLE | 1 |
| 6 | 889740A02 | 手柄套件 | HANDLE KIT | 1 |
| 6 | 821253F4 | 前手柄 | FRONT HANDLE | 1 |
| 6 | 889740A02 | 手柄套件 | HANDLE KIT | 1 |
| 7 | 335891 | 衬套 | BUSHING | 2 |
| 8 | 48462 | O型圈 (.614 x .070) | O-RING (.614 x .070) | 1 |
| 9 | 8219423 | 棘爪 | PAWL | 1 |
| 10 | 69057 | 垫片(.281 x .734 x .063) | WASHER (.281 x .734 x .063) | 1 |
| 11 | 401196 | 螺母 (M6) | NUT (M6) | 1 |
| 12 | 8214281 | 螺钉(#10-16x0.625) | SCREW (#10-16 x .625) | 1 |
| 13 | 822873 | 卡扣 | CLIP | 1 |
| 14 | 850691 | 开关 | SWITCH | 1 |
| 14 | 8M0235192 | 微调开关 | SWITCH TRIM | 1 |
| 15 | 8124431 | 固定件(适用处使用) | RETAINER (USE WHERE APPLICABLE) | 1 |
| 15 | 8M0032848 | 开关固定座 | RETAINER Switch | 1 |
| 16 | 822024 | 卡箍(下部) | CLAMP (LOWER) | 1 |
| 17 | 822023 | 卡箍 (上) | CLAMP (UPPER) | 1 |
| 18 | 92799 | 螺钉(#10-16x1.12) | SCREW (#10-16 x 1.12) | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9784A11 | 曲轴总成 | CRANKSHAFT ASSEMBLY | 1 |
| 2 | NSS | 磨损套筒(不单独销售) | NOT SOLD SEPARATE Wear Sleeve | 1 |
| 3 | 67923T | 球轴承(下部) | BEARING Ball (LOWER) | 1 |
| 4 | 67446 | 环 | RING | 1 |
| 5 | 19301 | 齿轮 | GEAR | 1 |
| 6 | 816106 | 环 | RING | 7 |
| 6 | 843198T01 | 密封环 | RING Seal | 7 |
| 7 | 91800 | 半圆键 | KEY Woodruff | 2 |
| 8 | 35126 | O型圈(.859 x .139) | O-RING (.859 x .139) | 1 |
| 9 | 817001A1 | 轴承座圈总成 | RACE ASSEMBLY Bearing | 2 |
| 9 | 8M0113288 | 轴承座圈总成 | RACE ASSY-BEARING | 2 |
| 9 | 88270A1 | 轴承座圈总成 | RACE ASSEMBLY | 2 |
| 9 | 88270A02 | 轴承/座圈套件 | BEARING/RACE KIT | 2 |
| 10 | NSS | 滚轮(不单独销售) | NOT SOLD SEPARATE Roller | 88 |
| 10 | NSS | 不单独销售 滚柱轴承 | NOT SOLD SEPARATE Roller Bearing | 2 |
| 11 | 858295T2 | 活塞 | PISTON | 3 |
| 11 | 858294T2 | 活塞 | PISTON | 3 |
| 12 | 841202 | 环 | RING | 12 |
| 13 | 827179A12 | 活塞环组 | RING SET Piston | 1 |
| 14 | NSS | NOT SOLD SEPARATE PISTON RING (SECOND) | 6 | |
| 15 | 822373A7 | 连杆总成 | CONNECTING ROD ASSEMBLY | 6 |
| 15 | 8M0125869 | 连杆套件 | CONN ROD KIT | 6 |
| 16 | 94320 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 12 |
| 17 | 43012A1 | 轴承/保持架套件 | BEARING/CAGE KIT | 6 |
| 17 | 8M0235070 | 轴承保持架 | CAGE BEARING | 6 |
| 18 | NSS | 轴承（不单独销售） | NOT SOLD SEPARATE Bearing | 96 |
| 19 | 88263 | 止推垫片 | THRUST WASHER | 12 |
| 20 | 88258 | 滚针轴承 | NEEDLE Roller Bearing | 204 |
| 20 | 8M0204715 | 滚针@102 | NEEDLES-BRG @102 | 204 |
| 21 | 816773A2 | 轴承总成（上部） | BEARING ASSEMBLY (UPPER) | 1 |
| 22 | 859093 | 密封件 | SEAL | 1 |
| 23 | 823683 | O型圈(1.989 x .070) | O-RING (1.989 x .070) | 1 |
| 24 | 68229 | 垫圈(.641 x 1.250 x .190) | WASHER (.641 x 1.250 x .190) | 1 |
| 24 | 33001 | 垫圈 | WASHER | 1 |
| 25 | 42979 | 螺母(M16) | NUT (M16) | 1 |
| - | 832933A98 | 衬垫套件 | GASKET SET | 1 |
| - | 848700A7 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9811A19 | 气缸体 | CYLINDER BLOCK | 1 |
| 1 | 9811A10 | 气缸体 | CYLINDER BLOCK | 1 |
| 1 | 9811A19 | 气缸体 | CYLINDER BLOCK | 1 |
| 2 | 903509 | 螺柱（M10×1.5×64） | STUD (M10 x 1.5 x 64) | 4 |
| 3 | 8154431 | 螺柱（M10×1.5×155） | STUD (M10 x 1.5 x 155) | 6 |
| 4 | 328021 | 管塞 (.125-27) | PLUG Pipe (.125-27) | 1 |
| 4 | 328022 | 黄铜管塞 (.125-27) | PLUG Pipe (.125-27) Brass | 1 |
| 5 | 36382 | 管接头 (.250-18 x .62)黄铜(按需使用) | FITTING (.250-18 x .62) Brass (USE WHERE APPLICABLE) | 2 |
| 6 | 8248572 | 导水板 | DEFLECTOR Water | 4 |
| 6 | 8248577 | 导流板 | DEFLECTOR | 4 |
| 7 | 43278 | 接头 | FITTING | 1 |
| 7 | 8781051 | 止回阀 | CHECK VALVE | 1 |
| 8 | 8245021 | 连接器 | CONNECTOR | 6 |
| 9 | 821583 | 销 | PIN | 2 |
| 9 | 8215832 | 特殊销（1.5英寸） | PIN Special (1.5 Inches) | 2 |
| 10 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 1 |
| 11 | 76843 | 接头 | FITTING | 13 |
| 11 | 768431 | 接头 | FITTING | 13 |
| 11 | 76843 | 接头 | FITTING | 6 |
| 11 | 768431 | 接头 | FITTING | 6 |
| 12 | 8348041 | 止回阀 | CHECK VALVE | 6 |
| 13 | 8282182 | 止回阀 | CHECK VALVE | 6 |
| 14 | 426585 | 止回阀 | CHECK VALVE | 2 |
| 15 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 14 |
| 15 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 14 |
| 16 | 8159234 | 止回阀 | CHECK VALVE | 2 |
| 17 | 82446180 | 螺钉(M10×80) | SCREW (M10 x 80) | 8 |
| 18 | 67296 | 销 | PIN | 3 |
| 18 | 8M0036405 | 销 | PIN | 3 |
| 19 | 825367A1 | 载体总成（含6个载体） | CARRIER ASSEMBLY (INCLUDES 6 CARRIERS) | 1 |
| 20 | 42657A3 | 止回阀 | CHECK VALVE | 6 |
| 21 | 850309 | 堵头 | PLUG | 6 |
| 21 | 850309001 | 止动塞 | PLUG Stop | 6 |
| 22 | 8217621 | 正时指针 | TIMING POINTER | 1 |
| 23 | 68727 | 管接头 (.250-18)90度-黄铜(随编号26提供) | FITTING (.250-18) 90 Degree - Brass (INCLUDED W/REF. #26) | 1 |
| 23 | 687271 | 90度弯头 (.250-18) - 黄铜 | FITTING (.250-18) 90 Degree - Brass | 1 |
| 24 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 1 |
| 25 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 25 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 26 | 826544A1 | 管件套件 | TUBING KIT | 1 |
| 27 | 99130122 | 管材（20英尺卷装）（22-1/2英寸） | TUBING (20.00 Feet Bulk) (22-1/2 IN.) | 1 |
| 27 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 28 | 45175 | 垫圈(.406 x .750 x .104) | WASHER (.406 x .750 x .104) | 10 |
| 28 | 8M0214963 | 垫圈 | WASHER | 10 |
| 29 | 400266 | 螺母(M10) | NUT (M10) | 10 |
| 29 | 4013610 | 螺母(M10不锈钢) | NUT (M10) Stainless Steel | 10 |
| 30 | 99130122 | 管材(20英尺散装)(3-3/4英寸) | TUBING (20.00 Feet Bulk) (3-3/4 IN.) | 1 |
| 30 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 30 | 99130122 | 管材（20英尺散装）（4英寸） | TUBING (20.00 Feet Bulk) (4 IN.) | 1 |
| 30 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 31 | 827201 | 管塞 | PIPE PLUG | 6 |
| 31 | 8272011 | 管塞 | PIPE PLUG | 6 |
| 32 | 8256751 | 支架 | BRACKET | 1 |
| 33 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 1 |
| 34 | 8211051 | 发电机支架 | BRACKET Alternator | 1 |
| 35 | 81893450 | 螺钉(M8 x 50) | SCREW (M8 x 50) | 2 |
| 36 | 8212251 | 支架 | BRACKET | 1 |
| 37 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 2 |
| 38 | 822486 | 导向支架 | BRACKET Guide | 1 |
| 39 | 821909 | 传感器 | SENSOR | 1 |
| 40 | 82104510 | 螺钉 (M5 x 10) | SCREW (M5 x 10) | 1 |
| 41 | 818574 | 密封件 | SEAL | 2 |
| 42 | 818573 | O型圈 | O-RING | 6 |
| 43 | 812851A2 | 气缸盖 | CYLINDER HEAD | 2 |
| 44 | 833072 | 节温器 62°C（143°F） | THERMOSTAT 62° Celsius (143° Fahrenheit) | 2 |
| 44 | 833072003 | 节温器 62°C (143°F) | THERMOSTAT 62°C (143°F) | 2 |
| 44 | 75692 | THERMOSTAT (143 DEGREES) | 2 | |
| 45 | 62386 | 衬垫 | GASKET | 2 |
| 45 | 8M0204714 | 衬垫@4 | GASKET @4 | 2 |
| 46 | 19801A1 | 节温器盖 | THERMOSTAT COVER | 2 |
| 46 | 198012 | 节温器盖 | COVER Thermostat | 2 |
| 46 | 19801A1 | 节温器盖 | THERMOSTAT COVER | 2 |
| 47 | 816781 | 管接头 (45度) | FITTING (45 DEGREE) | 2 |
| 47 | 8167811 | 弯头 | ELBOW | 2 |
| 47 | 68727 | 90度弯头 (.250-18) - 黄铜 | FITTING (.250-18) 90 Degree - Brass | 2 |
| 47 | 687271 | 90度弯头 (.250-18) - 黄铜 | FITTING (.250-18) 90 Degree - Brass | 2 |
| 48 | 77653112 | 软管（59英寸散装）（19英寸/20-1/2英寸） | HOSE (59.00 Inches Bulk) (19 IN.)(20-1/2 IN.) | 2 |
| 48 | 77653101 | 软管（散装48.00英寸） | HOSE (48.00 Inches Bulk) | 2 |
| 48 | 77653112 | 软管（59英寸散装）（20英寸/21-1/2英寸） | HOSE (59.00 Inches Bulk) (20 IN.)(21-1/2 IN.) | 2 |
| 48 | 77653101 | 软管（散装48.00英寸） | HOSE (48.00 Inches Bulk) | 2 |
| 49 | 82446090 | 螺钉（M8×90） | SCREW (M8 x 90) | 4 |
| 50 | 82446050 | 螺钉(M8 x 50) | SCREW (M8 x 50) | 36 |
| 50 | 8M0045380 | 螺钉(M8 x 50) | SCREW (M8 x 50) | 36 |
| 51 | 13536A11 | 温度传感器总成 | SENSOR ASSEMBLY Temperature | 1 |
| 51 | 13536A14 | 温度传感器总成 | SENSOR ASSEMBLY Temperature | 1 |
| 52 | 88807A42 | 电缆总成（适用时使用） | CABLE ASSEMBLY (USE WHERE APPLICABLE) | 1 |
| 53 | 828523 | 传感器固定座 | RETAINER Sensor | 1 |
| 54 | 828552 | 螺钉（.375-16×.500） | SCREW (.375-16 x .500) | 1 |
| 55 | 137151 | 固定座 | RETAINER | 1 |
| 56 | 81893412 | 螺钉（M8×12） | SCREW (M8 x 12) | 1 |
| 57 | 9787A3 | 下端盖总成 | END CAP ASSEMBLY Lower | 1 |
| 57 | 9787A5 | 端盖总成 | END CAP ASSY | 1 |
| 57 | 9787A4 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 58 | 62700 | O型圈(3.237 x .103) | O-RING (3.237 x .103) | 1 |
| 58 | 62700 | O型圈(3.237 x .103) | O-RING (3.237 x .103) | 1 |
| 59 | 8185711 | 油封 | SEAL Oil | 2 |
| 59 | 830898 | 油封 | SEAL Oil | 2 |
| 59 | 8308981 | 密封件 | SEAL | 2 |
| 60 | 815449 | 油封 | SEAL Oil | 1 |
| 60 | 859093 | 密封件 | SEAL | 1 |
| 61 | 82130020 | 螺钉 (M6 x 20) | SCREW (M6 x 20) | 4 |
| 62 | 8261211 | 支架 | BRACKET | 1 |
| 63 | 48408 | 螺钉(#10-16 x 0.500) | SCREW (#10-16 x .500) | 1 |
| 64 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 2 |
| 65 | 8266241 | 卡箍 | CLAMP | 1 |
| - | 814195A93 | 衬垫套件 | GASKET SET | 1 |
| - | 809794A97 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 809794R97 | PH 225/250 -RM | PH 225/250 -RM | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 832937A3 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 832937A06 | 传动轴壳体总成-加长型 | HOUSING ASSEMBLY Driveshaft - Long | 1 |
| 1 | 832937A05 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 832937A06 | 传动轴壳体总成-加长型 | HOUSING ASSEMBLY Driveshaft - Long | 1 |
| 1 | 832938A5 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 832938A06 | 传动轴壳体总成-超长/特超长型 | HOUSING ASSEMBLY Driveshaft - X/XX-Long | 1 |
| 2 | 856983 | 双头螺柱(M12 x 52) | STUD (M12 x 52) | 4 |
| 2 | 8M0008031 | 双头螺柱(M12 x 1.75 x 52) | STUD (M12 x 1.75 x 52) | 4 |
| 3 | 88552835 | 螺钉(M12×35毫米) | SCREW (M12 x 35 MM) | 1 |
| 3 | 8M0102995 | 螺丝 (M12) | SCREW (M12) | 1 |
| 4 | 8331231 | 护孔环 | GROMMET | 1 |
| 5 | 856982 | 垫圈(0.5×0.81×0.09英寸)不锈钢 | WASHER (.500 x .810 x .090) Stainless Steel | 4 |
| 6 | 857008 | 螺母(M12×1.75) | NUT (M12 x 1.75) | 4 |
| 6 | 896895 | 螺母(M12) | NUT (M12) | 4 |
| 7 | 64649 | 堵头 | PLUG | 1 |
| 8 | 815431 | 螺钉（M14×178） | SCREW (M14 x 178) | 2 |
| 8 | 898834 | 螺栓（M14×178） | BOLT (M14 x 178) | 2 |
| 8 | 815431002 | 螺栓（M14×178） | BOLT (M14 x 178) | 2 |
| 8 | 898834 | 螺栓（M14×178） | BOLT (M14 x 178) | 2 |
| 9 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 2 |
| 10 | 815432 | 垫圈(.562 x 2.00 x .125) | WASHER (.562 x 2.00 x .125) | 2 |
| 11 | 8154331 | 垫圈（1.25×2.00×0.19） | WASHER (1.25 x 2.00 x .19) | 2 |
| 12 | 8137711 | 支架 | MOUNT | 2 |
| 13 | 825190 | 垫圈 | WASHER | 2 |
| 14 | 815434 | 螺母 | NUT | 2 |
| 14 | 896602 | 螺母(M14) | NUT (M14) | 2 |
| 15 | 8186442 | 卡箍 | CLAMP | 2 |
| 15 | 879150A90 | 下支架盖套件 | COVER KIT Lower Mount | 2 |
| 16 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 4 |
| 16 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 17 | 72521 | 内齿锁紧垫圈 | LOCKWASHER Internal Tooth | 1 |
| 18 | 818645F1 | 黑色盖 | COVER Black | 2 |
| 18 | 8M0001136 | 下支架盖 | COVER Lower Mount | 2 |
| 19 | 69079 | 螺钉 (#10-16 x .440) | SCREW (#10-16 x .440) | 2 |
| 20 | 8329321 | 密封件 | SEAL | 1 |
| 21 | 833116A4 | 排气管总成 | TUBE ASSEMBLY Exhaust | 1 |
| 22 | 8524052 | 滤网 | STRAINER | 1 |
| 22 | 8M0026113 | 滤网 | STRAINER | 1 |
| 23 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 6 |
| 23 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 6 |
| 24 | 8329417 | 水管 | TUBE Water | 1 |
| 24 | 8M0042785 | 水管 | TUBE-WATER | 1 |
| 24 | 8329418 | 水管 | TUBE Water | 1 |
| 24 | 8M0042786 | 水管 | TUBE Water | 1 |
| 24 | 8329419 | 水管 | TUBE Water | 1 |
| 24 | 8M0042787 | 水管 | TUBE-WATER | 1 |
| 25 | 832940 | 密封件 | SEAL | 1 |
| 25 | 832940001 | 密封件 | SEAL | 1 |
| 25 | 832940001 | 密封件 | SEAL | 1 |
| 26 | 8329391 | 卡箍 | CLAMP | 1 |
| 27 | 41508 | 螺钉(0.250-20×0.500)不锈钢 | SCREW (.250-20 x .500) Stainless Steel | 1 |
| 28 | 823979T1 | 隔套 | SPACER | 1 |
| 28 | 8M0105088 | 传动轴壳体加长隔套（黑色） | SPACER Driveshaft Housing X-Long, Black | 1 |
| 29 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 30 | 857009 | 双头螺柱（M12×179） | STUD (M12 x 179) | 4 |
| 30 | 8M0008047 | 双头螺柱（M12×179） | STUD (M12 x 179) | 4 |
| 31 | 857137 | 螺钉 (M12 X 160) | SCREW (M12 x 160) | 1 |
| 32 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 2 |
| 32 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 92876A8 | 转向安装套件 | ATTACHING KIT Steering | 1 |
| 1 | 41055A1 | 支架总成 | BRACKET ASSEMBLY | 1 |
| 2 | 71565A2 | 管总成 | TUBE ASSEMBLY | 1 |
| 3 | 48462 | O型圈 (.614 x .070) | O-RING (.614 x .070) | 1 |
| 4 | 821203 | 锁紧垫圈 | LOCKWASHER | 2 |
| 5 | 37984 | 螺母 (.875-14) | NUT (.875-14) | 2 |
| 5 | 8M0041651 | 螺母 (.875-14) | NUT (.875-14) | 2 |
| 6 | 38601 | 螺丝(.250-28 x 1.250) | SCREW (.250-28 x 1.250) | 4 |
| 7 | 78968 | 内锁紧垫圈 (.250) | LOCKWASHER Internal (.250) | 4 |
| 8 | 850791T | 联轴器 | COUPLER | 1 |
| 9 | 73732 | 螺钉 (.375-24 x 1.120) | SCREW (.375-24 x 1.120) | 2 |
| 10 | 37828 | 不锈钢垫圈 (.390 x .625 x .062) | WASHER (.390 x .625 x .062) Stainless Steel | 2 |
| 11 | 826709113 | 不锈钢螺母 (.375-24) | NUT (.375-24) Stainless Steel | 3 |
| 11 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 3 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 825296T1 | 电气安装板 | PLATE Electrical Mounting | 1 |
| 2 | 82129114 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 2 |
| 3 | 827509T7 | CDM模块总成 | CDM MODULE ASSEMBLY | 6 |
| 4 | 857124A1 | 高压线总成 | CABLE ASSEMBLY Hi-Tension | 6 |
| 5 | 857074A1 | 护套/端子套件 | BOOT/TERMINAL KIT | 6 |
| 6 | 82129116 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 12 |
| 7 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 8 | 941 | 火花塞 | SPARK PLUG | 6 |
| 9 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 4 |
| 9 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 10 | 49436 | 垫圈 | WASHER | 4 |
| 11 | 825380 | 护孔环 | GROMMET | 4 |
| 11 | 825380001 | 护孔环 | GROMMET | 4 |
| 12 | 19064 | 衬套 | BUSHING | 4 |
| 13 | 83004419S | 发动机控制单元(CDI) | ECU Engine Control Unit (CDI) | 1 |
| 14 | 83004615S | 发动机控制单元(EFI) | ECU Engine Control Unit (EFI) | 1 |
| 14 | 83004615T | 电控单元 | ECU | 1 |
| 15 | 82129145 | 螺钉（M6 x 45） | SCREW (M6 x 45) | 8 |
| 16 | 826188 | 卡箍 | CLAMP | 1 |
| 17 | 82104520 | 螺钉（M5×20） | SCREW (M5 x 20) | 1 |
| 18 | 825763A5 | 线束总成(EFI) | HARNESS ASSEMBLY (EFI) | 1 |
| 19 | 13541 | 公插头 | PLUG Male | 3 |
| 20 | 825433A11 | 点火线束总成 | HARNESS ASSEMBLY Ignition | 1 |
| 21 | 828151A1 | 继电器总成 | RELAY ASSEMBLY | 2 |
| 21 | 8M0207773 | 调整继电器总成 | RELAY ASSEMBLY Trim | 2 |
| 22 | 818967 | 护孔环 | GROMMET | 2 |
| 22 | 8M0207785 | 护孔环 | GROMMET | 2 |
| 23 | 828102 | 支架 | BRACKET | 2 |
| 23 | 8M0207771 | 安装支架 | BRACKET Mounting | 2 |
| 24 | 818968 | 衬套 | BUSHING | 2 |
| 24 | 8M0214955 | 衬套 | BUSHING | 2 |
| 25 | NSS | NOT SOLD SEPARATE DECAL, Trim Relay | 2 | |
| 26 | 826802A2 | 升降线束总成 | HARNESS ASSEMBLY Trim | 1 |
| 27 | 88439A34 | 正极电缆总成-蓄电池 | CABLE ASSEMBLY Positive - Battery | 1 |
| 28 | 88439A24 | 蓄电池负极电缆总成 | CABLE ASSEMBLY Negative - Battery | 1 |
| 29 | 827356A2 | 线束总成（26英寸） | HARNESS ASSEMBLY (26 IN.) | 1 |
| 30 | 8216091 | 盖板 | COVER | 1 |
| 31 | 82239320 | 螺钉（M5×20） | SCREW (M5 x 20) | 3 |
| 32 | 812619 | 黄色保险丝-20安培 | FUSE Yellow - 20 Ampere | 1 |
| 33 | 19637 | 保险丝插座 | SOCKET Fuse | 1 |
| 34 | 93388A8 | 黑色电缆总成(12.5英寸) | CABLE ASSEMBLY (12.5 Inchs) Black | 1 |
| 35 | 8212282 | 电磁阀安装板 | PLATE Solenoid Mounting | 1 |
| 36 | 82155025 | 螺丝(M8 x 25 mm)不锈钢 | SCREW (M8 x 25 mm) Stainless Steel | 3 |
| 37 | 82129125 | 螺丝(M6 x 25毫米) | SCREW (M6 x 25 mm) | 4 |
| 38 | 88807A16 | 黑色电缆总成(4.00英寸) | CABLE ASSEMBLY (4.00 Inches) Black | 1 |
| 39 | 45915 | 端子排 | TERMINAL BLOCK | 1 |
| 40 | 878608 | 螺钉(#10-16 x 0.500) | SCREW (#10-16 x .500) | 2 |
| 41 | 878607 | 螺钉（#10-16 x 0.375） | SCREW (#10-16 x .375) | 1 |
| 42 | 817109A2 | 电磁阀总成(#10-32/.3125-18端子) | SOLENOID ASSEMBLY (#10-32 / .3125-18 Terminals) | 1 |
| 43 | 822179 | 护孔环 | GROMMET | 2 |
| 44 | 818968 | 衬套 | BUSHING | 2 |
| 44 | 8M0214955 | 衬套 | BUSHING | 2 |
| 45 | 53166 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 2 |
| 46 | 68292 | 螺母(.312-18) | NUT (.312-18) | 2 |
| 46 | 8M0204668 | 螺母(.312-18) | NUT (.312-18) | 2 |
| 47 | 45076 | 黄铜螺母(#10-32) | NUT (#10-32) Brass | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 818450A2 | 排气板总成 | PLATE ASSEMBLY Exhaust | 1 |
| 1 | 832935A1 | 排气板总成 | PLATE ASSEMBLY Exhaust | 1 |
| 2 | 832994 | 滤网 | STRAINER | 2 |
| 3 | 8139322 | 衬垫 | GASKET | 1 |
| 3 | 8329331 | 衬垫 | GASKET | 1 |
| 3 | 8329335 | 衬垫 | GASKET | 1 |
| 4 | 823988 | 衬垫(下部) | GASKET (LOWER) | 1 |
| 5 | 64878 | 弹簧(黑色) | SPRING (Black) | 1 |
| 5 | 854478 | 弹簧 | SPRING | 1 |
| 5 | 64878 | 弹簧(黑色) | SPRING (Black) | 1 |
| 6 | 8329342 | 衬垫(下部) | GASKET (LOWER) | 1 |
| 6 | 8329344 | 衬垫 | GASKET | 1 |
| 7 | 8238051 | 密封件 | SEAL | 1 |
| 7 | 8M0043157 | 密封件 | SEAL | 1 |
| 8 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 2 |
| 8 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 2 |
| 9 | 656632 | 盖板 | COVER | 1 |
| 9 | 8M0237835 | 罩盖总成 | COVER ASSY | 1 |
| 10 | 65664A1 | 隔板总成 | PLATE ASSEMBLY | 1 |
| 11 | 88907 | 衬垫 | GASKET | 2 |
| 11 | 88907003 | 衬垫 | GASKET | 2 |
| 12 | 69570 | 螺钉(#10-16 x .750) | SCREW (#10-16 x .750) | 1 |
| 13 | 76451 | 垫圈 | WASHER | 1 |
| 14 | 64877 | 隔膜 | DIAPHRAGM | 1 |
| 14 | 648771 | 隔膜 | DIAPHRAGM | 1 |
| 15 | 814189 | 提动阀 | POPPET | 1 |
| 16 | 814191 | 护孔环 | GROMMET | 1 |
| 17 | 814190 | 托架 | CARRIER | 1 |
| 18 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 4 |
| 18 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 19 | 34982 | 连接器 | CONNECTOR | 2 |
| 20 | 78279 | 弯头（45度） | ELBOW (45 DEGREES) | 1 |
| 20 | 8M0207781 | 弯头 | ELBOW | 1 |
| 21 | 821975 | 45度弯头 | ELBOW 45 Degree | 1 |
| 22 | 821255 | 怠速排气套 | BOOT Idle Exhaust | 1 |
| 23 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 23 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 24 | 830756109 | 软管(57英寸散装)(2-1/2英寸) | HOSE (57.00 Inches Bulk) (2-1/2 IN.) | 1 |
| 24 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 25 | 821904 | 示流器接头 | FITTING Tell-Tale | 1 |
| 25 | 8M0077650 | 示流器接头 | FITTING Tell-Tale | 1 |
| 26 | 821908 | 堵头 | PLUG | 1 |
| 27 | 821915 | 垫圈 | WASHER | 1 |
| 28 | 821963 | 止回阀 | CHECK VALVE | 1 |
| 28 | 8219631 | 止回阀 | CHECK VALVE | 1 |
| 29 | 30641 | O型圈(0.299x0.103) | O-RING (.299 x .103) | 1 |
| 30 | 821952 | 接头 | FITTING | 1 |
| 31 | 821976 | 软管 | HOSE | 1 |
| 32 | 817519A1 | 排水单向阀总成 | CHECK VALVE ASSEMBLY Drain | 2 |
| 33 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 4 |
| 34 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 34 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 35 | 35459 | 垫圈 | WASHER | 1 |
| 36 | 824012 | 滚轮 | ROLLER | 1 |
| 37 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 37 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 38 | 8141935 | 换挡连杆 | SHIFT LINK | 1 |
| 38 | 883142A03 | 换挡连杆套件 | SHIFT LINK KIT | 1 |
| 39 | 42994 | 衬套 | BUSHING | 1 |
| 40 | 8240701 | 上换挡轴 | SHIFT SHAFT Upper | 1 |
| 40 | 8M0036408 | 换挡轴 | SHAFT-SHIFT | 1 |
| 40 | 8240702 | 上换挡轴 | SHIFT SHAFT Upper | 1 |
| 40 | 8M0187153 | XL型上换挡轴 | SHAFT SHIFT UP XL | 1 |
| 40 | 8240703 | 上换挡轴 | SHIFT SHAFT Upper | 1 |
| 41 | 48237 | 衬套 | BUSHING | 1 |
| 42 | 19565 | 护孔环 | GROMMET | 1 |
| 42 | 19565002 | 护孔环 | GROMMET | 1 |
| 43 | 43585 | 联轴器 | COUPLING | 1 |
| 44 | 828808 | 堵头 | PLUG | 2 |
| - | 814195A93 | 衬垫套件 | GASKET SET | 1 |
| - | 809794A97 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 809794R97 | PH 225/250 -RM | PH 225/250 -RM | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 1 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 2 | 45907 | 黄色塞 | PLUG Yellow | 1 |
| 3 | 821033A2 | 飞轮 | FLYWHEEL | 1 |
| 3 | 821033T2 | 飞轮 | FLYWHEEL | 1 |
| 4 | 821935A5 | 定子 | STATOR | 1 |
| 5 | 82494830 | 螺钉 (M6 x 30) | SCREW (M6 x 30) | 4 |
| 6 | 821663A1 | 交流发电机 | ALTERNATOR | 1 |
| 7 | 82446155 | 螺钉(M10×55) | SCREW (M10 x 55) | 1 |
| 8 | 82130140 | 螺钉(M10×40) | SCREW (M10 x 40) | 1 |
| 9 | 796431 | 垫圈 | WASHER | 2 |
| 10 | 400266 | 螺母(M10) | NUT (M10) | 1 |
| 10 | 4013610 | 螺母(M10不锈钢) | NUT (M10) Stainless Steel | 1 |
| 11 | 497561 | V型皮带 | V BELT | 1 |
| 11 | 49756Q1 | V型皮带 | V BELT | 1 |
| 12 | 17457 | 垫圈 | WASHER | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 825818A13 | 燃油管理系统总成 | MANAGEMENT ASSEMBLY Fuel | 1 |
| - | 825818A14 | 燃油管理系统总成 | MANAGEMENT ASSEMBLY Fuel | 1 |
| - | 825818A12 | 燃油管理系统总成 | MANAGEMENT ASSEMBLY Fuel | 1 |
| 1 | 8276934 | 节气门体 | THROTTLE BODY | 1 |
| 1 | 827693T4 | 节气门体 | THROTTLE BODY | 1 |
| 1 | 8276935 | 节气门体 | THROTTLE BODY | 1 |
| 1 | 827693T5 | 节气门体 | THROTTLE BODY | 1 |
| 1 | 8276931 | 节气门体 | THROTTLE BODY | 1 |
| 1 | 827693T4 | 节气门体 | THROTTLE BODY | 1 |
| 1 | 8276932 | 节气门体 | THROTTLE BODY | 1 |
| 1 | 827693T5 | 节气门体 | THROTTLE BODY | 1 |
| 2 | 8090571 | 燃油管接头套件 | JOINT KIT Fuel Pipe | 1 |
| 3 | 8276983 | 螺钉套件 | SCREW KIT | 1 |
| 4 | 150291 | O型圈套件 | O-RING KIT | 1 |
| 5 | 8142331 | FMA接头套件 | FMA JOINT KIT | 1 |
| 5 | 814233T1 | FMA接头套件 | FMA JOINT KIT | 1 |
| 6 | 8090591 | 施拉德阀套件 | SCHRADER VALVE KIT | 1 |
| 7 | 827694 | 管件套件 | TUBING KIT | 1 |
| 7 | 827694A02 | 软管套件 | HOSE KIT | 1 |
| 8 | 8276941 | 管件套件 | TUBING KIT | 1 |
| 8 | 897992A01 | 管件套件 | TUBING KIT | 1 |
| 9 | 8090843 | 油门轴 | SHAFT Throttle | 1 |
| 9 | 809084 | 油门轴 | SHAFT Throttle | 1 |
| 9 | 8090843 | 油门轴 | SHAFT Throttle | 1 |
| 10 | 8090842 | 节气门轴套件 | SHAFT KIT Throttle | 1 |
| 10 | 8090841 | 节气门轴套件 | SHAFT KIT Throttle | 1 |
| 10 | 8090842 | 节气门轴套件 | SHAFT KIT Throttle | 1 |
| 11 | 827697A1 | 连杆杠杆套件 | LEVER KIT Link | 1 |
| 12 | 154441 | 连接杆 | LINK | 1 |
| 13 | 8276991 | 燃油导轨 | FUEL RAIL | 1 |
| 14 | 154432 | 线束套件 | HARNESS KIT | 1 |
| 14 | 154431 | 线束套件 | HARNESS KIT | 1 |
| 15 | 8276921 | 盖板 | COVER | 1 |
| 16 | 187921 | 密封件 | SEAL | 1 |
| 17 | 827696 | 固定套件 | RETAINER KIT | 1 |
| 18 | 809093 | TPS支架套件 | BRACKET KIT TPS | 5 |
| 19 | 187151 | 喷油器套件 | INJECTOR KIT | 6 |
| 19 | 805225A1 | 燃油喷油器总成 | INJECTOR ASSEMBLY Fuel | 6 |
| 20 | 67748 | 滚轮 | ROLLER | 1 |
| 21 | 89694 | 键 | KEY | 1 |
| 22 | 821153 | 联轴器 | COUPLING | 1 |
| 23 | 821664 | 节气门位置传感器 | SENSOR Throttle Position | 1 |
| 24 | 4005685 | 螺钉（M4×10） | SCREW (M4 x 10) | 2 |
| 25 | 26995 | 防松垫圈(#8不锈钢) | LOCKWASHER (#8) Stainless Steel | 2 |
| 26 | 30164 | 垫圈(0.192x0.375x0.0312)不锈钢 | WASHER (.192 x .375 x .0312) Stainless Steel | 2 |
| 27 | 13221A1 | 温度传感器总成 | SENSOR ASSEMBLY Temperature | 1 |
| 27 | 13221T01 | 温度传感器 | SENSOR TEMP | 1 |
| 28 | 4005685 | 螺钉（M4×10） | SCREW (M4 x 10) | 3 |
| 29 | 26995 | 防松垫圈(#8不锈钢) | LOCKWASHER (#8) Stainless Steel | 3 |
| 30 | 45711 | O型圈 (.612 x .103) | O-RING (.612 x .103) | 1 |
| 31 | 40132 | 螺钉(M8×125) | SCREW (M8 x 125) | 12 |
| 32 | 70132 | 垫圈(0.323×0.563×0.063)不锈钢 | WASHER (.323 x .563 x .063) Stainless Steel | 12 |
| 32 | 8M0042642 | 垫圈(.323 x .562 x .063) | WASHER (.323 x .562 x .063) | 12 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 14360A43 | 燃油泵总成 | PUMP ASSEMBLY Fuel | 1 |
| 1 | 14360A78 | 燃油泵套件 | PUMP KIT Fuel | 1 |
| 2 | 42990A10 | 膜片组件 | DIAPHAGM KIT | 1 |
| 2 | 857005A1 | 膜片组件 | DIAPHRAGM KIT | 1 |
| 3 | NSS | 橡胶止回阀(不单独销售) | NOT SOLD SEPARATE Check Valve-Rubber | 2 |
| 4 | NSS | 止回阀(不单独销售) | NOT SOLD SEPARATE Check Valve | 2 |
| 5 | NSS | 固定座(不单独销售) | NOT SOLD SEPARATE Retainer | 2 |
| 6 | NSS | 增压垫片(不单独销售) | NOT SOLD SEPARATE Gasket-Boost | 1 |
| 7 | NSS | 盖帽(不单独销售) | NOT SOLD SEPARATE Cap | 1 |
| 8 | NSS | 弹簧(不单独销售) | NOT SOLD SEPARATE Spring | 1 |
| 9 | NSS | 膜片(不单独销售) | NOT SOLD SEPARATE Diaphragm | 2 |
| 10 | NSS | 脉冲垫片(不单独销售) | NOT SOLD SEPARATE Gasket-Pulse | 1 |
| 11 | NSS | 弹簧(不单独销售) | NOT SOLD SEPARATE Spring | 1 |
| 12 | NSS | 盖帽(不单独销售) | NOT SOLD SEPARATE Cap | 1 |
| 13 | 987691 | 底座衬垫 | GASKET Base | 1 |
| 13 | 8M0204705 | 衬垫@2 | GASKET @2 | 1 |
| 14 | 144303 | 底座 | BASE | 1 |
| 15 | 987752 | 安装板 | PLATE | 1 |
| 16 | 62910 | 90度弯头(0.125-27) | ELBOW (.125-27) (90 DEGREES) | 1 |
| 16 | 629101 | 90度弯头接头(0.125-27) | FITTING Elbow - 90 Degree (.125-27) | 1 |
| 17 | 82130050 | 螺钉(M6 x 50) | SCREW (M6 x 50) | 2 |
| 18 | 82104540 | 螺钉(M5 x 40) | SCREW (M5 x 40) | 2 |
| 19 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 19 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 20 | 83075780 | 管材(28.00英寸散装)(17英寸) | TUBING (28.00 Inches Bulk) (17 IN.) | 3 |
| 20 | 8M0108349 | 软管 (70英寸散装) | HOSE (70 Inches Bulk) | 3 |
| 21 | 822769 | 连接器 | CONNECTOR | 1 |
| 22 | 136071 | 弯头(含参考号25) | ELBOW (INCLUDED WITH REF. #25) | 1 |
| 23 | 18458A3 | 燃油滤清器总成 | FILTER ASSEMBLY Fuel | 1 |
| 23 | 18458Q3 | 燃油滤清器 | FILTER-FUEL | 1 |
| 23 | 18458A4 | 滤清器套件 | FILTER KIT | 1 |
| 23 | 18458Q4 | 燃油水分离滤清器 | FILTER Fuel-Water Separating | 1 |
| 24 | 14570 | 探头 | PROBE | 1 |
| 24 | 828586 | 探头 | PROBE | 1 |
| 24 | 8M0204710 | 探头 | PROBE | 1 |
| 25 | 13170A3 | 底座 | BASE | 1 |
| 26 | 82130030 | 螺钉 (M6 x 30) | SCREW (M6 x 30) | 2 |
| 27 | 897712 | 直型连接器(.250-18) | CONNECTOR (.250-18) (STRAIGHT) | 1 |
| 27 | 89771Q2 | 连接器(.250-18) | CONNECTOR (.250-18) | 1 |
| - | 814195A93 | 衬垫套件 | GASKET SET | 1 |
| - | 809794A97 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 809794R97 | PH 225/250 -RM | PH 225/250 -RM | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 849012T10 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY (COMPLETE) | 1 |
| - | 840470T6 | 齿轮箱-1.75右旋 | G CASE-1.75 RH | 1 |
| 1 | 849012T11 | 齿轮箱总成(基础) | GEAR HOUSING ASSEMBLY (BASIC) | 1 |
| 1 | 840470T5 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 2 | 379721 | 销 | PIN | 1 |
| 3 | 821526 | 填充块 | FILLER BLOCK | 1 |
| 3 | 821526001 | 填充块 | FILLER BLOCK | 1 |
| 4 | 826134Q | 阳极块 | ANODE | 2 |
| 5 | 4000333 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 1 |
| 6 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 7 | 42647A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 8 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 9 | 79953Q2 | 排水螺钉套件(.375-16 x .250) | SCREW KIT (.375-16 x .250) Drain | 1 |
| 9 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 10 | 191832 | 垫圈 | WASHER | 1 |
| 10 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 11 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 12 | 56762 | 扎带(4.00英寸) | TIE STRAP (4.00 Inches) | 1 |
| 13 | NSS | 小齿轮(不单独销售) | NOT SOLD SEPARATE Pinion Gear | 1 |
| 14 | 92721 | 垫圈(.965×0.630) | WASHER (.965 x .630) | 1 |
| 15 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 16 | 815921A4 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 17 | 8164641 | 油封 | SEAL Oil | 1 |
| 17 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 18 | 36318 | O型圈(0.799英寸) | O-RING (.799) | 2 |
| 18 | 8M0214927 | O型圈@5 | O RING @5 | 2 |
| 19 | 82130016 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 20 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| 21 | 824145 | 换挡轴(下部) | SHIFT SHAFT (LOWER) | 1 |
| 22 | 848831 | 驱动轴 | DRIVESHAFT | 1 |
| 23 | 43037 | 键 | KEY | 1 |
| 23 | 8M0204723 | 键 | KEY | 1 |
| 24 | 38657A1 | 垫片组 | SHIM ASSEMBLY | AR |
| 24 | 8M0063268 | 垫片组 | SHIM SET | AR |
| 25 | 48939A2 | 圆锥滚子轴承 | BEARING Taper Roller | 1 |
| 25 | 8M0146553 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 26 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 27 | 42637A1 | 垫片组 | SHIM SET | AR |
| 27 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 28 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 28 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 29 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 30 | 8245191 | 固定座 | RETAINER | 1 |
| 31 | 807929A1 | 托架总成 | CARRIER ASSEMBLY | 1 |
| 31 | 8M0214948 | 托架总成 | CARRIER ASSY | 1 |
| 32 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 32 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 33 | 66302 | 油封 | SEAL Oil | 1 |
| 33 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 34 | 66302 | 油封 | SEAL Oil | 1 |
| 34 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 35 | 817275A1 | 水泵壳体套件 | HOUSING KIT Water Pump | 1 |
| 36 | 816575A2 | 密封套件 | SEAL KIT | 1 |
| 37 | 430331 | 衬垫 | GASKET | 1 |
| 38 | 8172771 | 水泵上垫片 | GASKET Water Pump, Upper | 1 |
| 39 | 8172761 | 面板 | FACEPLATE | 1 |
| 39 | 8M0204709 | 面板 | FACEPLATE | 1 |
| 40 | 43026T2 | 叶轮 | IMPELLER | 1 |
| 41 | 82130016 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 4 |
| 42 | 832942A1 | 联轴器总成 | COUPLING ASSEMBLY | 1 |
| 43 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 43 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 44 | 35027 | O型圈(1.046英寸) | O-RING (1.046) | 1 |
| 44 | 8M0204654 | O型圈 | O-RING | 1 |
| 45 | 848832A1 | 驱动轴总成 | DRIVESHAFT ASSEMBLY | 1 |
| 46 | 823902 | 联轴器 | COUPLING | 1 |
| - | 816575A6 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| - | 817275A5 | 水泵修理包 | REBUILD KIT Water Pump | 1 |
| - | 43026T11 | 水泵叶轮维修套件 | REPAIR KIT Water Pump Impeller | 1 |
| - | 8M0100526 | 水泵叶轮维修套件 | REPAIR KIT Water Impeller | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 840470T10 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY (COMPLETE) | 1 |
| 1 | 840470T5 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 2 | 379721 | 销 | PIN | 1 |
| 3 | 821526 | 填充块 | FILLER BLOCK | 1 |
| 3 | 821526001 | 填充块 | FILLER BLOCK | 1 |
| 4 | 859402 | 皮托管 | PITOT TUBE | 1 |
| 5 | 826134Q | 阳极块 | ANODE | 2 |
| 6 | 4000333 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 1 |
| 7 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 8 | 42647A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 9 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 10 | 85944975 | 管材(72英寸整料)(裁切至7英寸) | TUBING (72.00 Inches Bulk) (Cut to 7 IN.) | 1 |
| 11 | 859432 | 接头 | FITTING | 1 |
| 11 | 881866 | 接头 | FITTING | 1 |
| 12 | 858934 | 盖板 | COVER | 1 |
| 13 | 858935 | 衬垫 | GASKET | 1 |
| 14 | 8164641 | 油封 | SEAL Oil | 1 |
| 14 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 15 | 36318 | O型圈(0.799英寸) | O-RING (.799) | 1 |
| 15 | 8M0214927 | O型圈@5 | O RING @5 | 1 |
| 16 | 82130016 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 17 | 92721 | 垫圈(.965×0.630) | WASHER (.965 x .630) | 1 |
| 18 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 19 | NSS | 小齿轮(不单独销售) | NOT SOLD SEPARATE Pinion Gear | 1 |
| 20 | 79953Q2 | 排水螺钉套件(.375-16 x .250) | SCREW KIT (.375-16 x .250) Drain | 2 |
| 20 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 2 |
| 21 | 191832 | 垫圈 | WASHER | 2 |
| 21 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 2 |
| 22 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| 23 | 824145 | 换挡轴(下部) | SHIFT SHAFT (LOWER) | 1 |
| 24 | 881938 | 驱动轴 | DRIVESHAFT | 1 |
| 25 | 38657A1 | 垫片组 | SHIM ASSEMBLY | AR |
| 25 | 8M0063268 | 垫片组 | SHIM SET | AR |
| 26 | 48939A2 | 圆锥滚子轴承 | BEARING Taper Roller | 1 |
| 26 | 8M0146553 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 27 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 28 | 43037 | 键 | KEY | 1 |
| 28 | 8M0204723 | 键 | KEY | 1 |
| 29 | 42637A1 | 垫片组 | SHIM SET | AR |
| 29 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 30 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 30 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 31 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 32 | 8245191 | 固定座 | RETAINER | 1 |
| 33 | 807929A1 | 托架总成 | CARRIER ASSEMBLY | 1 |
| 33 | 8M0214948 | 托架总成 | CARRIER ASSY | 1 |
| 34 | 840836A2 | 托架总成 | CARRIER ASSEMBLY | 1 |
| 34 | 8M0192207 | 密封载体套件 | CARRIER KIT-SEAL | 1 |
| 35 | 82130016 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 36 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 36 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 37 | 66302 | 油封 | SEAL Oil | 1 |
| 37 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 38 | 66302 | 油封 | SEAL Oil | 1 |
| 38 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 39 | 817275A1 | 水泵壳体套件 | HOUSING KIT Water Pump | 1 |
| 40 | 816575A2 | 密封套件 | SEAL KIT | 1 |
| 41 | 430331 | 衬垫 | GASKET | 1 |
| 42 | 8172771 | 水泵上垫片 | GASKET Water Pump, Upper | 1 |
| 43 | 8172761 | 面板 | FACEPLATE | 1 |
| 43 | 8M0204709 | 面板 | FACEPLATE | 1 |
| 44 | 43026T2 | 叶轮 | IMPELLER | 1 |
| 45 | 82130016 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 4 |
| 46 | 832942A1 | 联轴器总成 | COUPLING ASSEMBLY | 1 |
| 47 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 47 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 48 | 35027 | O型圈(1.046英寸) | O-RING (1.046) | 1 |
| 48 | 8M0204654 | O型圈 | O-RING | 1 |
| 49 | 848832A1 | 驱动轴总成 | DRIVESHAFT ASSEMBLY | 1 |
| 50 | 823902 | 联轴器 | COUPLING | 1 |
| - | 816575A6 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| - | 817275A5 | 水泵修理包 | REBUILD KIT Water Pump | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 849012T10 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY (COMPLETE) | 1 |
| - | 840470T6 | 齿轮箱-1.75右旋 | G CASE-1.75 RH | 1 |
| 1 | 849012T11 | 齿轮箱总成(基础) | GEAR HOUSING ASSEMBLY (BASIC) | 1 |
| 1 | 840470T5 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 47 | 823903 | 换挡曲柄 | SHIFT CRANK | 1 |
| 47 | 8M0226861 | 换挡曲柄 | CRANK-SHIFTER | 1 |
| 48 | 19755T7 | 阀芯总成 | SPOOL ASSEMBLY | 1 |
| 48 | 8M0235940 | 阀芯总成 | SPOOL ASSY | 1 |
| 49 | NSS | NOT SOLD SEPARATE Shift Pool | 1 | |
| 50 | NSS | 不单独销售开口销 | NOT SOLD SEPARATE Cotter Pin | 1 |
| 51 | NSS | 不单独销售套筒 | NOT SOLD SEPARATE Sleeve | 1 |
| 52 | 47397A1 | 垫片组 | SHIM SET | AR |
| 53 | 828168T3 | 前进/小齿轮组 | GEAR SET Forward/Pinion | 1 |
| 53 | 859321T04 | 前进/小齿轮组 | GEAR SET Forward/Pinion | 1 |
| 54 | 828437A2 | 轴承总成 | BEARING ASSEMBLY | 1 |
| 55 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 56 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 57 | 856823 | 挡圈 | RING Retaining | 1 |
| 58 | 78962 | 弹簧 | SPRING | 2 |
| 59 | 848878T | 离合器 | CLUTCH | 1 |
| 60 | 78909 | 定位销 | PIN Detent | 2 |
| 61 | 848838 | 十字销 | PIN Cross | 1 |
| 62 | 848829 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 63 | 848881A1 | 倒挡齿轮 | GEAR Reverse | 1 |
| 63 | 8M0192235 | 倒挡齿轮 | GEAR-REVERSE | 1 |
| 64 | 8241081 | 推力垫片 | THRUST SPACER | 1 |
| 65 | 681001 | 止推环 | RING Thrust | 1 |
| 66 | 88957T | 滚珠轴承 | BEARING Ball | 1 |
| 67 | 31534 | O型圈 | O-RING | 1 |
| 67 | 8M0214920 | O型圈 | O RING | 1 |
| 68 | 848840T1 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 68 | 848840A1 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 69 | 817072 | 滚柱轴承 | BEARING Roller | 1 |
| 70 | 815565 | 油封 | SEAL Oil | 2 |
| 71 | 817071 | 卡环 | RING Snap | 1 |
| 72 | 67892A1 | 磁吸式注油/放油塞套件 | FITTING KIT Magnetic, Plug Fill/Drain | 1 |
| 72 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 73 | 191832 | 垫圈 | WASHER | 1 |
| 73 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 74 | 30281 | 键 | KEY | 1 |
| 75 | 79447 | 锁紧垫圈 | TAB WASHER | 1 |
| 76 | 79448 | 固定座 | RETAINER | 1 |
| 76 | 8M2011027 | 固定座 | RETAINER | 1 |
| 77 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 78 | 423511 | 齿形锁紧垫圈 | LOCKWASHER Toothed | 1 |
| 79 | 832066A1 | 进水口板套件 | PLATE KIT Water Inlet | 1 |
| 80 | 188642 | 螺钉(#8-32 x .500) | SCREW (#8-32 x .500) | 4 |
| 81 | 76214Q5 | 阳极套件 | ANODE KIT | 1 |
| 82 | 66024 | 螺钉(.437-14 x 1.75) | SCREW (.437-14 x 1.75) | 1 |
| - | 816575A6 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 840470T10 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY (COMPLETE) | 1 |
| 1 | 840470T5 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 51 | 823903 | 换挡曲柄 | SHIFT CRANK | 1 |
| 51 | 8M0226861 | 换挡曲柄 | CRANK-SHIFTER | 1 |
| 52 | 19755T7 | 阀芯总成 | SPOOL ASSEMBLY | 1 |
| 52 | 8M0235940 | 阀芯总成 | SPOOL ASSY | 1 |
| 53 | NSS | NOT SOLD SEPARATE Shift Pool | 1 | |
| 54 | 469501 | 开口销 | COTTER PIN | 1 |
| 55 | NSS | 不单独销售套筒 | NOT SOLD SEPARATE Sleeve | 1 |
| 56 | 47397A1 | 垫片组 | SHIM SET | AR |
| 57 | 828168T3 | 前进/小齿轮组 | GEAR SET Forward/Pinion | 1 |
| 57 | 859321T04 | 前进/小齿轮组 | GEAR SET Forward/Pinion | 1 |
| 58 | 828437A2 | 轴承总成 | BEARING ASSEMBLY | 1 |
| 59 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 60 | 856823 | 挡圈 | RING Retaining | 1 |
| 61 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 62 | 78962 | 弹簧 | SPRING | 2 |
| 63 | 848878T | 离合器 | CLUTCH | 1 |
| 64 | 78909 | 定位销 | PIN Detent | 1 |
| 65 | 848838 | 十字销 | PIN Cross | 1 |
| 66 | 848829 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 67 | 848881A1 | 倒挡齿轮 | GEAR Reverse | 1 |
| 67 | 8M0192235 | 倒挡齿轮 | GEAR-REVERSE | 1 |
| 68 | 8241081 | 推力垫片 | THRUST SPACER | 1 |
| 69 | 681001 | 止推环 | RING Thrust | 1 |
| 70 | 88957T | 滚珠轴承 | BEARING Ball | 1 |
| 71 | 31534 | O型圈 | O-RING | 1 |
| 71 | 8M0214920 | O型圈 | O RING | 1 |
| 72 | 848840T1 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 72 | 848840A1 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 73 | 817072 | 滚柱轴承 | BEARING Roller | 1 |
| 74 | 815565 | 油封 | SEAL Oil | 2 |
| 75 | 817071 | 卡环 | RING Snap | 1 |
| 76 | 67892A1 | 磁吸式注油/放油塞套件 | FITTING KIT Magnetic, Plug Fill/Drain | 1 |
| 76 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 77 | 191832 | 垫圈 | WASHER | 1 |
| 77 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 78 | 30281 | 键 | KEY | 1 |
| 79 | 79447 | 锁紧垫圈 | TAB WASHER | 1 |
| 80 | 79448 | 固定座 | RETAINER | 1 |
| 80 | 8M2011027 | 固定座 | RETAINER | 1 |
| 81 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 82 | 423511 | 齿形锁紧垫圈 | LOCKWASHER Toothed | 1 |
| 83 | 76214Q5 | 阳极套件 | ANODE KIT | 1 |
| 84 | 66024 | 螺钉(.437-14 x 1.75) | SCREW (.437-14 x 1.75) | 1 |
| - | 816575A6 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 19674A1 | 拉绳开关总成 | SWITCH ASSEMBLY Lanyard | 1 |
| 1 | 19674A07 | 开关/拉绳套件 | SWITCH/LANYARD KIT | 1 |
| 2 | 18303 | 螺钉 (.190-16 x 1.750) 不锈钢 | SCREW (.190-16 x 1.750) Stainless Steel | 2 |
| 3 | 813679 | 适配器 | ADAPTER | 1 |
| 4 | 15920A54 | 拉绳总成 | LANYARD ASSEMBLY | 1 |
| 4 | 15920Q54 | 拉绳总成 | LANYARD ASSEMBLY | 1 |
| 5 | 32866 | 螺钉 (#10-32 x 2.00) 不锈钢 | SCREW (#10-32 x 2.00) Stainless Steel | 2 |
| 6 | 18321 | 安装夹 | CLAMP Mounting | 1 |
| 7 | 24676 | 垫圈 (.200 x .440 x .032) | WASHER (.200 x .440 x .032) | 2 |
| 8 | 68219 | 螺母 (#10-32) 不锈钢 | NUT (#10-32) Stainless Steel | 4 |
| 9 | 79146 | 固定座 | RETAINER | 3 |
| 10 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 10 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 11 | 812497A2 | 二极管总成 | DIODE ASSEMBLY | 1 |
| 11 | 898289A72 | 双拉绳二极管套件 | DIODE KIT-LANYARD Dual | 1 |
| 12 | 11149A2 | 线缆总成 (6.00英寸) | CABLE ASSEMBLY (6.00 Inches) | 1 |
| 13 | 827871A1 | 警报仪表套件 | WARNING GAUGE KIT | 1 |
| 13 | 859698A1 | 警报仪表套件 | WARNING GAUGE KIT | 1 |
| 14 | 823486 | 卡箍 | CLAMP | 1 |
| 15 | 817315 | 边框 | BEZEL | 1 |
| 16 | 26419 | 黄铜螺母 (#8-32) | NUT (#8-32) Brass | 2 |
| 17 | 15163 | 灯 | LAMP | 3 |
| 18 | 79888 | 灯泡插座 | SOCKET Light Bulb | 3 |
| 19 | 827752A1 | 电缆总成(20.00英尺) | CABLE ASSEMBLY (20.00 Feet) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 816626A20 | 钥匙开关线束总成(20英尺) | HARNESS ASSEMBLY Key Switch (20.00 Feet) | 1 |
| 2 | 90468A1 | 钥匙盖总成 | COVER ASSEMBLY Key | 2 |
| 3 | 76424 | 支架 | BRACKET | 1 |
| 4 | 55422 | 双头螺柱 (#10-32 x 2.00) | STUD (#10-32 x 2.00) | 2 |
| 5 | 24676 | 垫圈 (.200 x .440 x .032) | WASHER (.200 x .440 x .032) | 2 |
| 6 | 68219 | 螺母 (#10-32) 不锈钢 | NUT (#10-32) Stainless Steel | 2 |
| 7 | 816479A3 | 板组件套件 | PLATE KIT | 2 |
| 8 | 88107A5 | 钥匙开关套件(钥匙型号参见下表) | SWITCH KIT Key (SEE CHART BELOW FOR KEY) | 1 |
| 9 | 879755 | 特殊螺母-黑色尼龙 | NUT Special - Black Nylon | 1 |
| 10 | 816492A1 | 音响报警器总成 | ALARM ASSEMBLY Audio Warning | 1 |
| 10 | 8M0210763 | 报警器 | ALARM | 1 |
| 11 | 8127111 | 垫片(0.375) | SPACER (.375) | 2 |
| 11 | 812711 | 隔套(0.250) | SPACER (.250) | 2 |
| - | 894911 | 点火钥匙(1A) | KEY Ignition (1A) | 1 |
| - | 894912 | 点火钥匙(1B) | KEY Ignition (1B) | 1 |
| - | 894913 | 点火钥匙(1C) | KEY Ignition (1C) | 1 |
| - | 894914 | 点火钥匙(1D) | KEY Ignition (1D) | 1 |
| - | 894915 | 点火钥匙(1E) | KEY Ignition (1E) | 1 |
| - | 894916 | 点火钥匙(1F) | KEY Ignition (1F) | 1 |
| - | 894917 | 点火钥匙(2A) | KEY Ignition (2A) | 1 |
| - | 894918 | 点火钥匙(2B) | KEY Ignition (2B) | 1 |
| - | 894919 | 点火钥匙(2C) | KEY Ignition (2C) | 1 |
| - | 8949110 | 点火钥匙(2D) | KEY Ignition (2D) | 1 |
| - | 8949111 | 点火钥匙(2E) | KEY Ignition (2E) | 1 |
| - | 8949112 | 点火钥匙(2F) | KEY Ignition (2F) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 818456A1 | 油箱总成 | TANK ASSEMBLY Oil | 1 |
| 2 | 830889A1 | 油箱总成 | TANK ASSEMBLY Oil | 1 |
| 3 | 8260841 | 隔套 | SPACER | 1 |
| 4 | 58376 | 螺钉(.164-18 x .375) | SCREW (.164-18 x .375) | 1 |
| 5 | 72761 | 不锈钢垫圈(.203 x .562 x .060) | WASHER (.203 x .562 x .060) Stainless Steel | 1 |
| 6 | 814449A2 | 盖总成 | CAP ASSEMBLY | 1 |
| 6 | 814449A3 | 盖总成 | CAP ASSEMBLY | 1 |
| 6 | 814449A3 | 盖总成 | CAP ASSEMBLY | 1 |
| 7 | 42999 | 衬垫 | GASKET | 1 |
| 7 | 42999T | 衬垫 | GASKET | 1 |
| 8 | 12886A6 | 开关总成 | SWITCH ASSEMBLY | 1 |
| 8 | 12886A7 | 开关总成 | SWITCH ASSEMBLY | 1 |
| 9 | 19064 | 衬套 | BUSHING | 3 |
| 10 | 825380 | 护孔环 | GROMMET | 3 |
| 10 | 825380001 | 护孔环 | GROMMET | 3 |
| 11 | 56720 | 垫圈(0.330×0.750×0.060)不锈钢 | WASHER (.330 x .750 x .060) Stainless Steel | 3 |
| 12 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 3 |
| 12 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 3 |
| 13 | 830756109 | 软管(57英寸整卷)(10英寸段) | HOSE (57.00 Inches Bulk) (10 IN.) | 1 |
| 13 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 13 | 830756109 | 软管(57英寸整卷)(8英寸段) | HOSE (57.00 Inches Bulk) (8 IN.) | 1 |
| 13 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 14 | 424254 | 接头 | FITTING | 1 |
| 14 | 8M0207780 | 接头 | FITTING | 1 |
| 15 | 82104530 | 螺钉(30毫米) | SCREW (30MM) | 1 |
| 16 | 8155361 | 油泵 | PUMP Oil | 1 |
| 16 | 815536T1 | 油泵 | PUMP Oil | 1 |
| 17 | 11379 | O型圈 | O-RING | 1 |
| 18 | 48462 | O型圈 (.614 x .070) | O-RING (.614 x .070) | 1 |
| 19 | 817631 | 从动齿轮轴承 | BEARING Driven Gear | 1 |
| 20 | 430204 | 从动齿轮 | GEAR Driven | 1 |
| 21 | 816974 | 推力轴承 | BEARING Thrust | 1 |
| 22 | 82104520 | 螺钉（M5×20） | SCREW (M5 x 20) | 1 |
| 23 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 23 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 24 | 82381451 | 管材(8.5英寸) | TUBING (8-1/2 IN.) | 1 |
| 24 | 82381455 | 油管（25.00英寸散装） | TUBING (25.00 Inches Bulk) | 1 |
| 25 | 87421 | 油箱 | TANK | 1 |
| 26 | 43298A2 | 盖总成 | CAP ASSEMBLY | 1 |
| 27 | 11332 | O型圈(2.225 x .210) | O-RING (2.225 x .210) | 1 |
| 28 | 816190A3 | 外壳总成适配器 | HOUSING ASSEMBLY Adapter | 1 |
| 28 | 816190A4 | 机油收集器总成(无传感器) | OIL PICK UP ASSEMBLY Without Sender | 1 |
| 29 | 11332 | O型圈(2.225 x .210) | O-RING (2.225 x .210) | 1 |
| 30 | 99802 | 管 | TUBE | 1 |
| 31 | 99439 | 软管(114.00英寸) | HOSE (114.00 Inches) | 1 |
| 32 | 12335A1 | 支架套件 | BRACKET KIT | 1 |
| 33 | 12323A1 | 绳索/挂钩套件 | CORD/HOOK KIT | 1 |
| 34 | 82381329 | 管材(12英寸散装)(7英寸) | TUBING (12.00 Inches Bulk) (7 IN.) | 1 |
| 34 | 82381335 | 油管(15.00英寸 散装) | TUBING (15.00 Inches Bulk) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 855998A3 | 动力升降倾斜装置总成 | POWER TRIM Complete | 1 |
| - | 855998A11 | 动力调整套件 | POWER TRIM KIT | 1 |
| 1 | 878265A4 | 配平电机 | TRIM MOTOR | 1 |
| 1 | 8M0031551 | 配平电机 | TRIM MOTOR | 1 |
| 2 | NSS | 电枢(不单独销售) | NOT SOLD SEPARATE Armature | 1 |
| 3 | NSS | 端架(不单独销售) | NOT SOLD SEPARATE End Frame | 1 |
| 4 | 82494830 | 螺钉 (M6 x 30) | SCREW (M6 x 30) | 2 |
| 5 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 2 |
| 6 | 878245 | 联轴器 | COUPLING | 1 |
| 6 | 8782451 | 驱动轴 | DRIVESHAFT | 1 |
| 7 | 878410A1 | 压力检查套件 | PO CHECK KIT | 1 |
| 8 | 813442A2 | 手动释放总成 | MANUAL RELEASE ASSEMBLY | 1 |
| 8 | 893929A01 | 安全阀套件 | VALVE KIT Relief | 1 |
| 9 | 878241A1 | 轴套件(含参考号26) | SHAFT KIT (Incls. Ref. #26) | 1 |
| 9 | 8M0142997 | 倾斜轴套件 | TILT SHAFT KIT | 1 |
| 10 | 878267 | 销 | PIN | 1 |
| 11 | 878235A1 | 倾斜油缸总成 | TILT CYLINDER ASSEMBLY | 1 |
| 11 | 878235A03 | 倾斜油缸套件 | CYLINDER KIT Tilt | 1 |
| 12 | 878239A1 | 导向套件(含参考号26) | GUIDE KIT (Incls. Ref. #26) | 1 |
| 12 | 878239A02 | 倾斜缸端盖套件 | END CAP KIT Tilt Cylinder | 1 |
| 13 | 878409A1 | O型圈套件(含参考号26) | O-RING KIT (Incls. Ref. #26) | 1 |
| 13 | 8M0142999 | 倾斜油缸O型圈套件 | O RING KIT TILT CYLINDER | 1 |
| 14 | 878412A1 | 减震杆套件(含参考号26) | SHOCK ROD KIT (Incls. Ref. #26) | 1 |
| 14 | 8M0168219 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 15 | 878242A1 | 记忆活塞总成 | PISTON ASSEMBLY Memory | 1 |
| 15 | 8M0143000 | 记忆活塞套件 | MEMORY PISTON KIT | 1 |
| 16 | 878406A1 | 止回阀维修套件(含参考号26) | REPAIR KIT Check Valve (Incls. Ref. #26) | 1 |
| 16 | 878406A02 | 止回阀修理包 | REPAIR KIT Check Valve | 1 |
| 17 | 878414A1 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 17 | 878414T01 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 18 | 878413A1 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 19 | 878243A1 | 导向器总成 | GUIDE ASSEMBLY | 2 |
| 19 | 8M0021648 | 端盖总成 | END CAP ASSEMBLY | 2 |
| 20 | 878264A1 | 储液罐套件 | RESERVOIR KIT | 1 |
| 21 | 811613 | 塞子总成 | PLUG ASSEMBLY | 1 |
| 22 | 4000327 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 4 |
| 23 | 43450 | 垫圈 | WASHER | 4 |
| 23 | 4002315 | 垫圈(6.60x12.5x1.5mm-不锈钢) | WASHER (6.60 X 12.5 X 1.5 mm -SS) | 4 |
| 24 | 878411A1 | 泵套件 | PUMP KIT | 1 |
| 24 | 892251A01 | 泵套件 | PUMP KIT | 1 |
| 25 | 878408A1 | 动力升降倾斜装置维修包 | REPAIR KIT Power Trim | 1 |
| 26 | 821539 | 三叶销 | PIN Trilobe | 1 |
| 27 | 858771 | 螺钉 (M10 x 30) | SCREW (M10 x 30) | 6 |
| 28 | 4002319 | 垫圈 | WASHER | 6 |
| 29 | 818298Q1 | 阳极套件 | ANODE KIT | 1 |
| 30 | 4000330 | 螺钉(M6x25) | SCREW (M6 x 25) | 2 |
| 30 | 8M0204707 | 不锈钢六角大帽螺钉(M6x25) | SCREW M6 x 25 HX HD CAP SS | 2 |
| 31 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 31 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 32 | 996251 | 轴 | SHAFT | 1 |
| 32 | 99625002 | 轴 | SHAFT | 1 |
| 33 | 69205 | C形垫圈 | C WASHER | 2 |
| 33 | 8M0084613 | C形垫圈 | C-WASHER | 2 |
| 34 | 22875 | 卡扣 | CLIP | 2 |
| 35 | 878608 | 螺钉(#10-16 x 0.500) | SCREW (#10-16 x .500) | 2 |
| 36 | 828547353 | 导管 (.350内径 x 3.00英尺 散装) | CONDUIT (.350 Inside Diameter x 3.00 Feet Bulk) | 1 |
| 37 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 826729T2 | 完整动力升降总成 | POWER TRIM ASSEMBLY Complete | 1 |
| - | 855998A11 | 动力调整套件 | POWER TRIM KIT | 1 |
| 1 | 811604F | 歧管总成 | MANIFOLD ASSEMBLY | 1 |
| 2 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 9 |
| 3 | 880952A1 | 倾斜油缸总成 | CYLINDER ASSEMBLY Tilt | 1 |
| 3 | 880952A03 | ORD 8M0078330 | ORD 8M0078330 | 1 |
| 4 | 823553T | 升降活塞杆 | ROD Trim Piston | 1 |
| 4 | 880952A02 | 液压油缸套件 | CYLINDER KIT-HYD | 1 |
| 5 | 878239A1 | 导向套件 | GUIDE KIT | 1 |
| 5 | 878239A02 | 倾斜缸端盖套件 | END CAP KIT Tilt Cylinder | 1 |
| 6 | 811607A1 | 维修套件 | REPAIR KIT | 1 |
| 7 | 811610A1 | 止回阀套件 | CHECK VALVE KIT | 1 |
| 7 | 823553T | 升降活塞杆 | ROD Trim Piston | 1 |
| 8 | 878243A1 | 导向器总成 | GUIDE ASSEMBLY | 2 |
| 8 | 8M0021648 | 端盖总成 | END CAP ASSEMBLY | 2 |
| 9 | 878413A1 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 9 | 878414A1 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 9 | 878414T01 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 10 | 12184A1 | 升降过滤器总成 | TRIM FILTER ASSEMBLY | 1 |
| 11 | 813442A2 | 手动释放总成 | MANUAL RELEASE ASSEMBLY | 1 |
| 11 | 893929A01 | 安全阀套件 | VALVE KIT Relief | 1 |
| 12 | 812844 | E型卡环 | E RING | 1 |
| 12 | 815949001 | E形环 | E-RING | 1 |
| 13 | 811612A3 | O型圈套件 | O-RING KIT | 1 |
| 14 | 811617T1 | 泵 | PUMP | 1 |
| 15 | 811613 | 塞子总成 | PLUG ASSEMBLY | 1 |
| 16 | 4000327 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 4 |
| 17 | 43450 | 垫圈 | WASHER | 4 |
| 17 | 4002315 | 垫圈(6.60x12.5x1.5mm-不锈钢) | WASHER (6.60 X 12.5 X 1.5 mm -SS) | 4 |
| 18 | 811611 | 盖板 | COVER | 1 |
| 19 | 828710 | 驱动接头 | DRIVE JOINT | 1 |
| 20 | 828708T | 配平电机 | TRIM MOTOR | 1 |
| 20 | 878265A4 | 配平电机 | TRIM MOTOR | 1 |
| 21 | 828709 | 螺钉 (长) | SCREW (LONG) | 2 |
| 21 | 881768A1 | 螺钉/垫圈套件 | SCREW/WASHER KIT | 2 |
| 21 | 811616 | 螺钉 (短) | SCREW (SHORT) | 2 |
| 22 | 811614T | 轴总成 | SHAFT ASSEMBLY | 1 |
| 22 | 8M0142997 | 倾斜轴套件 | TILT SHAFT KIT | 1 |
| 23 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 2 |
| 24 | 44431 | 槽销 | PIN Groove | 1 |
| 24 | 878267 | 销 | PIN | 1 |
| 25 | 821539 | 三叶销 | PIN Trilobe | 1 |
| 26 | 996251 | 轴 | SHAFT | 1 |
| 26 | 99625002 | 轴 | SHAFT | 1 |
| 27 | 818298Q1 | 阳极套件 | ANODE KIT | 1 |
| 28 | 4000330 | 螺钉(M6x25) | SCREW (M6 x 25) | 2 |
| 28 | 8M0204707 | 不锈钢六角大帽螺钉(M6x25) | SCREW M6 x 25 HX HD CAP SS | 2 |
| 29 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 29 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 30 | 4000377 | 螺钉 (M10 x 30) | SCREW (M10 x 30) | 6 |
| 31 | 4002319 | 垫圈 | WASHER | 6 |
| 32 | 26550 | 卡箍 | CLAMP | 2 |
| 33 | 878608 | 螺钉(#10-16 x 0.500) | SCREW (#10-16 x .500) | 2 |
| 34 | 69205 | C形垫圈 | C WASHER | 2 |
| 34 | 8M0084613 | C形垫圈 | C-WASHER | 2 |
| 35 | 435301 | 警示贴纸-动力微调 | DECAL Caution-Power Trim | 1 |
| 36 | 828547353 | 导管 (.350内径 x 3.00英尺 散装) | CONDUIT (.350 Inside Diameter x 3.00 Feet Bulk) | 1 |
| 37 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0231193 | 动力升降总成 | POWER TRIM ASSEMBLY | 1 |
| 1 | 8M0225363 | 电机套件 | MOTOR KIT | 1 |
| 2 | 8M0225369 | 阀套件 | VALVE KIT | 1 |
| 3 | 8M0225371 | 手动释放套件 | MANUAL RELEASE KIT | 1 |
| 4 | 8M0245633 | 倾斜油缸套件 | TILT CYLINDER KIT | 1 |
| 5 | 8M0225370 | 枢轴销套件 | PIVOT PIN KIT | 1 |
| 6 | 8M0244575 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 7 | 8M0244425 | 销杆眼套件 | PIN ROD EYE KIT | 1 |
| 8 | 8M0232231 | 螺钉螺母套件 | SCREW NUT KIT | 1 |
| 9 | 8M0225373 | 记忆活塞套件 | MEMORY PISTON KIT | 1 |
| 10 | 8M0225368 | 储液罐套件 | RESERVOIR KIT | 1 |
| 11 | 8M0174135 | 储液罐塞总成 | PLUG RESERVOIR ASSEMBLY | 1 |
| 12 | 8M0237525 | 泵套件 | PUMP KIT | 1 |
| 13 | 8M0225367 | 升降杆套件 | TRIM ROD KIT | 1 |
| 14 | 8M0242846 | 升降杆套件 | TRIM ROD KIT | 1 |
| 15 | 8M0225372 | 重建套件 | REBUILD KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0168222 | 动力升降总成 | POWER TRIM ASSEMBLY | 1 |
| 1 | 8M0142591 | 电机套件 | MOTOR KIT | 1 |
| 2 | 82494830 | 螺钉 (M6 x 30) | SCREW (M6 x 30) | 2 |
| 3 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 2 |
| 4 | 8M0090403 | 驱动联轴器 | COUPLING Drive | 1 |
| 5 | 8M0142996 | 压力检查套件 | PO CHECK KIT | 1 |
| 6 | 8M0060141 | 手动释放套件 | MANUAL RELEASE KIT | 1 |
| 7 | 8M0142997 | 倾斜轴套件 | TILT SHAFT KIT | 1 |
| 8 | 878267 | 销 | PIN | 1 |
| 9 | 8M0142998 | 倾斜油缸总成 | TILT CYLINDER ASSEMBLY | 1 |
| 9 | 8M0168220 | 倾斜油缸总成 | TILT CYLINDER ASSEMBLY | 1 |
| 10 | 8M0142999 | 倾斜油缸O型圈套件 | O RING KIT TILT CYLINDER | 1 |
| 11 | 8M0143000 | 记忆活塞套件 | MEMORY PISTON KIT | 1 |
| 12 | 8M0142592 | 升降杆套件 左舷 | TRIM ROD KIT Port | 1 |
| 13 | 8M0143001 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 14 | 8M0143003 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 15 | 878264A1 | 储液罐套件 | RESERVOIR KIT | 1 |
| 16 | 811613 | 塞子总成 | PLUG ASSEMBLY | 1 |
| 17 | 4000327 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 4 |
| 18 | 4002315 | 垫圈(6.60x12.5x1.5mm-不锈钢) | WASHER (6.60 X 12.5 X 1.5 mm -SS) | 4 |
| 19 | 8M0143004 | 泵套件 | PUMP KIT | 1 |
| 20 | 8M0148385 | 动力升降倾斜装置维修包 | REPAIR KIT Power Trim | 1 |
| 21 | 858771 | 螺钉 (M10 x 30) | SCREW (M10 x 30) | 6 |
| 22 | 4002319 | 垫圈 | WASHER | 6 |
| 23 | 8M0094889 | 销 | PIN | 1 |
| 23 | 8M0161312 | 连杆销眼总成 | PIN ROD EYE ASSEMBLY | 1 |
| 24 | 8M0143005 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 24 | 8M0168219 | 减震杆套件 | SHOCK ROD KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 49542 | 卡箍 | CLAMP | 2 |
| 2 | 825815 | 衬垫 | GASKET | 3 |
| 3 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 2 |
| 4 | 8251785 | 适配板 | ADAPTER PLATE | 1 |
| 4 | 825178T5 | 适配板 | ADAPTER PLATE | 1 |
| 4 | 8251783 | 适配板 | ADAPTER PLATE | 1 |
| 4 | 825178T5 | 适配板 | ADAPTER PLATE | 1 |
| 5 | 67015 | 卡箍 | CLAMP | 2 |
| 5 | 859172 | 卡箍 | CLAMP | 2 |
| 6 | 827507 | 固定座 | RETAINER | 1 |
| 7 | 82130025 | 螺钉(M6x25) | SCREW (M6 x 25) | 12 |
| 8 | 8141951 | 衬垫 | GASKET | 1 |
| 9 | 828623 | 簧片阀组 | REED BLOCK | 6 |
| 9 | 828623T6 | 簧片阀总成 | REED BLOCK ASSEMBLY | 6 |
| 10 | 816032A1 | 簧片阀组 | REED BLOCK | 6 |
| 10 | 816032T1 | 簧片阀总成 | REED BLOCK ASSY | 6 |
| 10 | 8160321 | 簧片阀组 | REED BLOCK | 6 |
| 10 | 816032T1 | 簧片阀总成 | REED BLOCK ASSY | 6 |
| 11 | 816107A1 | 簧片组 | REED SET | 6 |
| 12 | 8161081 | 簧片夹 | CLAMP Reed | 12 |
| 12 | 816032A1 | 簧片阀组 | REED BLOCK | 12 |
| 12 | 8161082 | 簧片夹 | CLAMP Reed | 12 |
| 13 | 8211108 | 螺钉(M4×0.7) | SCREW (M4 X .7) | 48 |
| 13 | 8211108 | 螺钉(M4×0.7) | SCREW (M4 X .7) | 72 |
| 14 | 4007420 | 螺钉 (M6 x 20) | SCREW (M6 x 20) | 12 |
| 15 | 825832 | 飞轮盖 | FLYWHEEL COVER | 1 |
| 16 | 821555 | 护孔环 | GROMMET | 4 |
| 16 | 8M0153609 | 护孔环 | GROMMET | 4 |
| - | 814195A93 | 衬垫套件 | GASKET SET | 1 |
| - | 809794A97 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 809794R97 | PH 225/250 -RM | PH 225/250 -RM | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 803199004 | 零件手册200/225/250(3.0L)SeaPro/Marathon EFI | PARTS MANUAL 200/225/250 (3.0L) SeaPro/Marathon EFI | 1 |
| - | 884294 | 维修手册 | SERVICE MANUAL | 1 |
| - | 884294R01 | 维修手册 | SERVICE MANUAL | 1 |
| - | 884294R01 | 维修手册 | SERVICE MANUAL | 1 |
| - | 10128040 | 用户手册 | OWNERS MANUAL | 1 |
| - | 10128041 | 用户手册 | MANUAL-OWNERS | 1 |
| - | 10128050 | 用户手册 | OWNERS MANUAL | 1 |
| - | 10128060 | 用户手册 | OWNERS MANUAL | 1 |
| - | 10128J60 | 用户手册(西班牙语) | OWNERS MANUAL Spanish | 1 |
| - | 10128D60 | 用户手册(法语) | OWNERS MANUAL French | 1 |
| - | 818937060 | 安装手册 | INSTALLATION MANUAL | 1 |
| - | 891764A04 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| - | 891764A05 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| - | 891764A06 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| - | 804670A04 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| - | 804670A05 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| - | 804670A06 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| - | 826798A1 | 工具套件(SeaPro/Marathon) | TOOL KIT (SeaPro/Marathon) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8184453 | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 1 | 898265009 | 启动马达 | STARTER MOTOR | 1 |
| 2 | 823639 | 驱动端盖 | DRIVE CAP | 1 |
| 2 | 8236392 | 驱动端盖 | DRIVE CAP | 1 |
| 3 | 823641 | 贯穿螺栓 | THRU BOLT | 2 |
| 4 | 823640 | 驱动套件 | DRIVE KIT | 1 |
| 4 | 823640T | 驱动套件 | DRIVE KIT | 1 |
| 5 | 13310 | 驱动器 | DRIVE | 1 |
| 5 | 13310T1 | 小齿轮总成 | PINION ASSEMBLY | 1 |
| 6 | 823638 | 电枢 | ARMATURE | 1 |
| 7 | 75384 | 电刷/弹簧套件 | BRUSH/SPRING KIT | 1 |
| 7 | 898265016 | 电刷/弹簧套件 | BRUSH/SPRING KIT | 1 |
| 8 | 61787 | 支架 | HOLDER | 1 |
| 8 | 898265014 | 电刷支架 | HOLDER-BRUSH | 1 |
| 9 | 8119011 | 换向器端盖 | CAP Commutator | 1 |
| 10 | F15158 | 螺钉 | SCREW | 2 |
| 11 | 8272822 | 警告标贴 | DECAL Warning | 1 |
| 12 | 26992 | 锁紧垫圈(.250)不锈钢 | LOCKWASHER (.250) Stainless Steel | 2 |
| 13 | 94330 | 螺母 (.250-20) 黄铜 | NUT (.250-20) Brass | 2 |
| 14 | 26992 | 锁紧垫圈(.250)不锈钢 | LOCKWASHER (.250) Stainless Steel | 1 |
| 15 | 20890 | 螺母 (.250-20) | NUT (.250-20) | 1 |
| 16 | 81893450 | 螺钉(M8 x 50) | SCREW (M8 x 50) | 3 |
| 17 | 824921 | 隔套 | SPACER | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8710A20 | 旋转支架总成 | SWIVEL BRACKET ASSEMBLY | 1 |
| 1 | 8M0102865 | 黑色旋转支架总成 | SWIVEL BRACKET ASSEMBLY Black | 1 |
| 1 | 8710A21 | 旋转支架总成 | SWIVEL BRACKET ASSEMBLY | 1 |
| 1 | 8710T21 | 灰色旋转支架总成 | SWIVEL BRACKET ASSEMBLY Gray | 1 |
| 1 | 8710A23 | 旋转支架 | SWIVEL BRACKET | 1 |
| 2 | 33504 | O型圈 | O-RING | 1 |
| 2 | 8M0214926 | O型圈 @10 | O RING @10 | 1 |
| 3 | 818764 | 衬套 | BUSHING | 2 |
| 4 | 816039 | 隔套 | SPACER | 1 |
| 5 | 87735 | 油封(下) | SEAL Oil (LOWER) | 1 |
| 6 | 74036 | 润滑脂接头 | FITTING Grease | 2 |
| 6 | 8M0169589 | 润滑脂接头 | FITTING Grease | 2 |
| 7 | 821207 | 衬套 | BUSHING | 2 |
| 8 | 816432 | 止推垫片 | THRUST WASHER | 1 |
| 9 | 814084F1 | 下轭架 | YOKE Bottom | 1 |
| 9 | 8M0219200 | 黑色下轭架 | YOKE-BOTTOM-BLACK | 1 |
| 9 | 814084F2 | 下轭架 | YOKE Bottom | 1 |
| 9 | 826364F1 | 下轭架 | YOKE Bottom | 1 |
| 9 | 826364T | 下轭架 | YOKE Bottom | 1 |
| 9 | 826364F2 | 下轭架 | YOKE Bottom | 1 |
| 9 | 826364F3 | 下轭架 | YOKE Bottom | 1 |
| 10 | 67684 | 挡圈 | RING Retaining | 1 |
| 11 | 996301 | 冲击板 | STRIKER PLATE | 2 |
| 11 | 8M0045383 | 冲击板 | STRIKER PLATE | 2 |
| 12 | 58643 | 锁紧垫圈 (.375) | LOCKWASHER (.375) | 2 |
| 13 | 46335 | 螺母 (.375-24) | NUT (.375-24) | 2 |
| 14 | 64014 | 螺钉(.250-28x.500) | SCREW (.250-28 x .500) | 2 |
| 15 | 821180A6 | 调整传感器总成 | SENDER ASSEMBLY Trim | 1 |
| 15 | 8M0074846 | ORDER 8M0098273 | ORDER 8M0098273 | 1 |
| 16 | 56682 | 螺钉（#10-24 X 0.750） | SCREW (#10-24 x .750) | 2 |
| 16 | 852368 | 螺钉（#10-24 X 0.750） | SCREW (#10-24 x .750) | 2 |
| 17 | 26996 | 锁紧垫圈(#10)(不锈钢) | LOCKWASHER (#10) Stainless Steel | 2 |
| 18 | 89302 | 垫圈(0.203×0.406×0.040) | WASHER (.203 x .406 x .040) | 2 |
| 19 | 67706A55 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 19 | 826432A2 | 转向臂旋转销总成-不锈钢 | SWIVEL PIN ASSEMBLY Steering Arm - Stainless Steel | 1 |
| 19 | 67706A56 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 19 | 67706A55 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 19 | 826432A2 | 转向臂旋转销总成-不锈钢 | SWIVEL PIN ASSEMBLY Steering Arm - Stainless Steel | 1 |
| 19 | 8M0132731 | 旋转销总成 | SWIVEL PIN ASSY | 1 |
| 19 | 826432A3 | 转向臂旋转销总成-不锈钢 | SWIVEL PIN ASSEMBLY Steering Arm - Stainless Steel | 1 |
| 19 | 826432A2 | 转向臂旋转销总成-不锈钢 | SWIVEL PIN ASSEMBLY Steering Arm - Stainless Steel | 1 |
| 19 | 826432A6 | 旋转销总成 | SWIVEL PIN ASSEMBLY | 1 |
| 19 | 8M0132731 | 旋转销总成 | SWIVEL PIN ASSY | 1 |
| 20 | 816386 | 螺钉(M12×190) | SCREW (M12 x 190) | 2 |
| 20 | 8M0141069 | 螺钉 | SCREW | 2 |
| 21 | 824998 | 缓冲垫 | BUMPER | 1 |
| 21 | 824998001 | 缓冲垫 | BUMPER | 1 |
| 22 | 8163851 | 上部支架 | MOUNT Upper | 2 |
| 23 | 815437 | 垫圈 | WASHER | 2 |
| 23 | 8154371 | 垫圈 | WASHER | 2 |
| 24 | 815436 | 垫圈 | WASHER | 2 |
| 25 | 90099 | 螺母(M12) | NUT (M12) | 2 |
| 25 | 896963 | 螺母(M12) | NUT (M12) | 2 |
| 26 | 813769 | 卡箍 | CLAMP | 1 |
| 26 | 8M0036783 | 卡箍 | CLAMP | 1 |
| 27 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 3 |
| 27 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 3 |
| 28 | 92876A1 | 转向连杆总成 | LINK ASSEMBLY Steering | 1 |
| 28 | 92876A12 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 29 | 14000 | 螺钉(.375-24x1.25) | SCREW (.375-24 x 1.25) | 1 |
| 29 | 849838 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 1 |
| 30 | 34863 | 螺母 (.375-24) | NUT (.375-24) | 2 |
| 30 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 2 |
| 31 | 37828 | 不锈钢垫圈 (.390 x .625 x .062) | WASHER (.390 x .625 x .062) Stainless Steel | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 58222A1 | 百分表工具 | DIAL INDICATOR TOOL | 1 |
| - | 8226084 | DDT诊断模块 | DDT CARTRIDGE | 1 |
| - | 8226086 | 模块 | CARTRIDGE | 1 |
| - | 822560A7 | 适配器线束总成 | HARNESS ASSEMBLY Adaptor | 1 |
| - | 52344 | 飞轮固定器工具(齿型) | FLYWHEEL HOLDER TOOL Teeth Type | 1 |
| - | 73687A2 | 飞轮拉拔器套件 | PULLER KIT Flywheel | 1 |
| - | 849154T1 | 拉拔器总成 | PULLER ASSEMBLY | 1 |
| - | 825003A1 | DDT诊断线束总成 | CABLE ASSEMBLY DDT | 1 |
| - | 823686A2 | 数字诊断测试仪 | DIGITAL DIAGNOSTIC TESTER | 1 |
| - | 99750A1 | 万用表 | MULTI METER | 1 |
| - | 24161 | 飞轮拉拔器盖工具 | CAP TOOL Flywheel Puller | 1 |
| - | 52024A1 | 开关总成 | SWITCH ASSEMBLY | 1 |
| - | 59339 | 维修用转速表 | SERVICE TACHOMETER | 1 |
| - | 892647A01 | DMT万用表套件 | MULTI-METER KIT DMT | 1 |
| - | 850439T1 | 八腔测试仪 | TESTER Eight Chamber | 1 |
| - | 63998A1 | 单腔间隙工具 | GAP TOOL Single Chamber | 1 |
| - | 850439 | 火花测试器 | SPARK TESTER | 1 |
| - | 850439T1 | 八腔测试仪 | TESTER Eight Chamber | 1 |
| - | 822560A6 | 测试线束总成 | HARNESS ASSEMBLY Test | 1 |
| - | 99379 | 正时灯 | TIMING LIGHT | 1 |
| - | 825207A1 | TPI/CDM测试线束总成 | HARNESS ASSEMBLY TPI/CDM Test | 1 |
| - | 825207A2 | 线束总成 | HARNESS ASSEMBLY | 1 |
| - | 29287 | 量规工具 | GAUGE TOOL | 1 |
| - | 55919 | 驱动头 | DRIVER HEAD | 1 |
| - | 52344 | 飞轮固定器工具(齿型) | FLYWHEEL HOLDER TOOL Teeth Type | 1 |
| - | 73687A2 | 飞轮拉拔器套件 | PULLER KIT Flywheel | 1 |
| - | 849154T1 | 拉拔器总成 | PULLER ASSEMBLY | 1 |
| - | 90455 | 吊环 | LIFTING EYE | 1 |
| - | 904551 | 吊环 | LIFTING EYE | 1 |
| - | 93004A2 | 锁环安装工具 | INSTALLATION TOOL Lock Ring | 1 |
| - | 52952A1 | 活塞销锁环拆卸工具 | REMOVAL TOOL Piston Pin Lock Ring | 1 |
| - | 52952T1 | 活塞销锁环拆卸工具 | REMOVAL TOOL Piston Pin Lock Ring | 1 |
| - | 92973A1 | 活塞销心轴工具 | MANDREL TOOL Piston Pin | 1 |
| - | 24697 | 活塞环扩张工具 | EXPANDER TOOL Piston Ring | 1 |
| - | 812549 | 动力头支架 | STAND Powerhead | 1 |
| - | 812549T | 动力头支架 | STAND Powerhead | 1 |
| - | 24161 | 飞轮拉拔器盖工具 | CAP TOOL Flywheel Puller | 1 |
| - | 823237 | 环压缩工具 | COMPRESSOR TOOL Ring | 1 |
| - | 823237T | 活塞环压缩工具(3.625英寸) | COMPRESSOR TOOL Piston Ring (3.625) | 1 |
| - | 24283 | 卡簧钳 | PLIERS Snap Ring | 1 |
| - | 66274 | 扭矩扳手(0-150磅英寸) | TORQUE WRENCH (0-150 lb-in) | 1 |
| - | 37241 | 通用拉拔板 | PULLER PLATE Universal | 1 |
| - | 112301 | 对正工具 | ALIGNMENT TOOL | 1 |
| - | 99750A1 | 万用表 | MULTI METER | 1 |
| - | 74951 | 扳手 | SPANNER WRENCH | 1 |
| - | 63209 | 加热灯 | HEAT LAMP | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 814277A14 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 814277T14 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 814277A15 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 814277T15 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 814277A25 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 814277T25 | 白色顶盖总成 | COWL ASSY-TOP-WHI | 1 |
| 2 | 821256F1 | 进气口 | INLET Air | 1 |
| 2 | 821256T03 | 进气口 | INLET Air | 1 |
| 2 | 821256F2 | 进气口 | INLET Air | 1 |
| 2 | 821256T2 | 银色进气口 | INLET Air - Silver | 1 |
| 2 | 821256F6 | 进气口 | INLET Air | 1 |
| 3 | 82130016 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 4 |
| 4 | 821250A1 | 隔音毯套装 | SOUND BLANKET KIT | 1 |
| 5 | 823865 | 盖塞 | CAP PLUG | 2 |
| 6 | 821248 | 后闩锁钩 | REAR LATCH HOOK | 2 |
| 7 | 8237951 | 挡圈 | RING Retaining | 3 |
| 8 | 815263 | 滚轮 | ROLLER | 3 |
| 8 | 8M0207770 | 滚轮@3 | ROLLER @3 | 3 |
| 9 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 4 |
| 9 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 4 |
| 10 | 401196 | 螺母 (M6) | NUT (M6) | 4 |
| 11 | 821249M2 | 前支架 | BRACKET Front | 1 |
| 11 | 8M0036792 | 支架 | BRACKET | 1 |
| 12 | 815477 | 缓冲器锁扣 | BUMPER Latch | 1 |
| 13 | 8155381 | 滚动销 | PIN Roll | 1 |
| 14 | 401196 | 螺母 (M6) | NUT (M6) | 3 |
| 15 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 3 |
| 15 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 3 |
| 16 | 826639T | 盖板 | COVER | 1 |
| 17 | 47341A1 | 手动/应急启动绳柄套件 | ROPE AND HANDLE KIT Manual/Emergency Start | 1 |
| 17 | 47341A11 | 手动启动绳柄套件 | ROPE AND HANDLE KIT Manual Starting | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 828334T03 | 艉板支架总成-右舷 | BRACKET ASSEMBLY Transom-Starboard | 1 |
| 2 | 828333T08 | 艉板支架总成-左舷 | BRACKET ASSEMBLY Transom-Port | 1 |
| 3 | 98727 | 润滑脂接头(左舷) | FITTING Grease (PORT) | 1 |
| 3 | 8M0169588 | 润滑脂接头 | FITTING Grease | 1 |
| 4 | 826125A1 | 倾斜管 | TILT TUBE | 1 |
| 5 | 826135 | 尼龙锁紧螺母(1.00-14) | NUT Lock (1.00-14) Nylon Insert | 1 |
| 6 | 45711 | O型圈 (.612 x .103) | O-RING (.612 x .103) | 1 |
| 7 | 88750 | 波浪垫圈 (1.62 x 1.05) | WASHER Wave (1.62 x 1.05) | 2 |
| 8 | 826164 | 螺母 (.875-14) | NUT (.875-14) | 1 |
| 8 | 8M0231351 | 锁紧螺母 | NUT Lock | 1 |
| 9 | 677551 | 螺钉(.500-20×4.500) | SCREW (.500-20 x 4.500) | 4 |
| 9 | 8M0149747 | 螺钉 | SCREW | 4 |
| 10 | 54012 | 垫圈(0.530×0.870×0.105不锈钢) | WASHER (.530 x .870 x .105) Stainless Steel | 4 |
| 10 | 8M0204665 | 垫圈(0.530×0.880×0.104 630不锈钢) | WASHER (.530 x .880 x .104) 630 Stainless Steel | 4 |
| 11 | 28421 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 11 | 8M0204648 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 12 | 82671117 | 螺母(.500-20) | NUT (.500-20) | 4 |
| 13 | 99629T2 | 倾斜锁定杆总成 | LEVER ASSEMBLY Tilt Lock | 1 |
| 13 | 8M0115104 | 倾斜锁定杆总成 | LEVER ASSEMBLY Tilt Lock | 1 |
| 14 | 830899 | 张力弹簧 | SPRING Tension | 1 |
| 15 | 65830 | 尼龙衬套 | NYLINER | 2 |
| 16 | 830900 | 压缩弹簧 | SPRING Compression | 1 |
| 17 | 99633 | 旋钮 | KNOB | 1 |
| 18 | 99615 | 槽销 | PIN Groove | 1 |
| 19 | 99617 | 销 | PIN | 1 |
| 19 | 893709 | 销 | PIN | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 825818A14 | 燃油管理系统总成 | MANAGEMENT ASSEMBLY Fuel | 1 |
| 1 | 8140111 | 阀体套件 | BODY KIT | 1 |
| 2 | 809091 | 螺钉套件 | SCREW KIT | 1 |
| 3 | 809086 | O型圈 | O-RING | 1 |
| 4 | 424811 | 阀门 | VALVE | 1 |
| 5 | 809092 | 安装螺钉套件 | SCREW KIT Mounting | 1 |
| 6 | 809061 | 螺栓 | BOLT | 3 |
| 7 | 809080 | 锁紧垫圈 | LOCKWASHER | 3 |
| 7 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 3 |
| 8 | 8090621 | 垫圈 | WASHER | 3 |
| 9 | 8090622 | 垫圈 | WASHER | 3 |
| 10 | 809079 | 护孔环 | GROMMET | 3 |
| 10 | 88033 | 护孔环 | GROMMET | 3 |
| 11 | 809078 | 轴环 | COLLAR | 3 |
| 12 | 15445 | 浮子套件 | FLOAT KIT | 1 |
| 13 | 15446 | 浮子阀套件 | VALVE KIT Float | 1 |
| 14 | 8140101 | 盖板 | COVER | 1 |
| 15 | 809085 | 弯头套件 | ELBOW KIT | 1 |
| 16 | 8140761 | 螺钉套件 | SCREW KIT | 1 |
| 17 | 809090 | 电气连接套件 | CONNECTION KIT Electrical | 1 |
| 18 | 8276941 | 管件套件 | TUBING KIT | 1 |
| 18 | 897992A01 | 管件套件 | TUBING KIT | 1 |
| 19 | 809087 | 安装套件 | ATTACHING KIT | 1 |
| 20 | 814012T1 | 燃油压力调节器套件 | REGULATOR KIT Fuel Pressure | 1 |
| 21 | 809088T | 燃油泵套件 | PUMP KIT Fuel | 1 |
| 21 | 808505T01 | 燃油泵套件 | PUMP KIT-FUEL | 1 |
| 22 | 808504T1 | 滤网套件 | STRAINER KIT | 1 |
| 23 | 809089 | 燃油泵接头套件 | FITTING KIT Fuel Pump | 1 |
| 24 | 150291 | O型圈套件 | O-RING KIT | 1 |
| 25 | 8237515 | 螺母(M4) | NUT (M4) | 1 |
| 26 | 400211 | 不锈钢螺母(M5) | NUT (M5) Stainless Steel | 1 |
| 27 | 26995 | 防松垫圈(#8不锈钢) | LOCKWASHER (#8) Stainless Steel | 1 |
| 28 | 825762 | MAP传感器 | SENSOR MAP | 1 |
| 29 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 2 |
| 30 | 804675A00 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| 30 | 804675A01 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| 30 | 804675A02 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| 30 | 804675A03 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| 31 | NSS | 不单独出售 警示贴纸(空档怠速) | NOT SOLD SEPARATE DECAL, Caution (In Gear Idle) | 1 |
| 32 | 881865 | 警示贴纸-挂档启动 | DECAL Caution-Start in Gear | 1 |
