两冲程 直喷 DFI OptiMax · USA - Cat.# 90-803485 · 共 34 个部位 · 1544 条零件
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 887767K03 | 启动/停止开关套件-三引擎 | SWITCH KIT Start/Stop - Triple (Triple Engine) | 1 |
| - | 8M0117133 | 仪表板安装启停开关面板-三引擎 | START/STOP SWITCH PAD Dash Mount - Triple | 1 |
| - | 852400 | 冲洗接头 | FLUSH COUPLING | 1 |
| - | 15969A3 | 甲板加油套件 | DECK FILL KIT Oil | 1 |
| - | 812497A2 | 二极管总成 | DIODE ASSEMBLY | 1 |
| - | 898289A72 | 双拉绳二极管套件 | DIODE KIT-LANYARD Dual | 1 |
| - | 44357Q2 | 冲洗附件 | FLUSHING ATTACHMENT | 1 |
| - | 881150Q1 | 双进水口冲洗套件 | FLUSH KIT Dual Water Pick Up | 1 |
| - | 825191A03 | 索具软管套件 | HOSE KIT Rigging | 1 |
| - | 19674A2 | 开关/拉绳套件 | SWITCH/LANYARD KIT | 1 |
| - | 19674Q2 | 开关/拉绳套件 | SWITCH/LANYARD KIT | 1 |
| - | 88334A2 | 防腐电极套件 | MERCATHODE KIT | 1 |
| - | 8M0180081 | 防腐电极套件 | MERCATHODE KIT | 1 |
| - | 879899K04 | 系统转速/速度套件-灰色表盘 | SYSTEM TACK/SPEED KIT Gray Face | 1 |
| - | 8M0063203 | KT-TACH/SPD 80GRY | KT-TACH/SPD 80GRY | 1 |
| - | 879897K03 | 系统转速表-灰色表盘 | SYSTEM TACH Gray Face | 1 |
| - | 8M6001270 | 转速表套件-7K灰色 | TACH KIT-7K GRAY | 1 |
| - | 879899K14 | 系统转速/速度套件-白色表盘 | STSTEM TACH/SPEED KIT White Face | 1 |
| - | 889223K32 | 转速表/速度表套件 | TACHOMETER / SPEEDOMETER KIT | 1 |
| - | 879897K13 | 系统转速表-白色表盘 | SYSTEM TACH White Face | 1 |
| - | 889222K22 | 转速表套件0-7000转-白色表盘 | TACHOMETER KIT 0-7000 RPM White Face | 1 |
| - | 41729A3 | 软管延长套件 | HOSE EXTENSION KIT | 1 |
| - | 877561A2 | 适配器线束总成 | HARNESS ASSEMBLY Adapter | 1 |
| - | 859187A1 | 调整传感器总成 | SENDER ASSEMBLY Trim | 1 |
| - | 887979A2 | 倾斜限位开关套件 | SWITCH KIT Tilt Limit | 1 |
| 1 | 8742A22 | 遥控油箱总成 | TANK ASSEMBLY Remote Oil Remote Oil | 1 |
| 1 | 8742A21 | 遥控机油箱总成 | TANK ASSEMBLY Remote Oil | 1 |
| 2 | 12335A1 | 支架套件 | BRACKET KIT | 1 |
| 3 | 12323A1 | 绳索/挂钩套件 | CORD/HOOK KIT | 1 |
| 4 | 12320 | 支架 | BRACKET | 2 |
| 5 | 79968 | 螺丝(#12-11 x .750) | SCREW (#12-11 x .750) | 4 |
| 6 | 43298A2 | 盖总成 | CAP ASSEMBLY | 1 |
| 7 | 11332 | O型圈(2.225 x .210) | O-RING (2.225 x .210) | 1 |
| 8 | 816190A4 | 机油收集器总成(无传感器) | OIL PICK UP ASSEMBLY Without Sender | 1 |
| 8 | 816190A5 | 带传感器的吸油总成 | OIL PICK UP ASSEMBLY With Sender | 1 |
| 9 | 43298A2 | 盖总成 | CAP ASSEMBLY | 1 |
| 10 | 11332 | O型圈(2.225 x .210) | O-RING (2.225 x .210) | 1 |
| 11 | 99802 | 管 | TUBE | 12 |
| 12 | 99439 | 软管(114.00英寸) | HOSE (114.00 Inches) | 1 |
| 13 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 5 |
| 14 | 17334A2 | 视觉警告系统 | VISUAL WARNING SYSTEM | 1 |
| 15 | 17429 | 灯 | LAMP | 1 |
| 16 | 76424 | 支架 | BRACKET | 1 |
| 17 | 55422 | 双头螺柱 (#10-32 x 2.00) | STUD (#10-32 x 2.00) | 2 |
| 18 | 24676 | 垫圈 (.200 x .440 x .032) | WASHER (.200 x .440 x .032) | 2 |
| 19 | 68219 | 螺母 (#10-32) 不锈钢 | NUT (#10-32) Stainless Steel | 2 |
| 20 | 15969A3 | 甲板加油套件 | DECK FILL KIT Oil | 1 |
| 21 | 15969A5 | 甲板加油套件 | DECK FILL KIT Oil | 1 |
| 21 | 15969A13 | 甲板加油套件 | DECK FILL KIT Oil | 1 |
| 22 | 15966 | 安装板 | PLATE | 1 |
| 23 | 815504228 | 蜗杆卡箍 | CLAMP Worm Gear | 2 |
| 23 | 8M0232395 | 软管卡箍 | CLAMP HOSE | 2 |
| 24 | 15967 | 加油口适配器 | ADAPTER Oil Filler | 1 |
| 25 | 11332 | O型圈(2.225 x .210) | O-RING (2.225 x .210) | 1 |
| 26 | 850719 | 软管(100.00英尺整卷) | HOSE (100.00 Feet Bulk) | AR |
| 27 | 812497A2 | 二极管总成 | DIODE ASSEMBLY | 1 |
| 27 | 898289A72 | 双拉绳二极管套件 | DIODE KIT-LANYARD Dual | 1 |
| 28 | 19674Q2 | 开关/拉绳套件 | SWITCH/LANYARD KIT | 1 |
| 29 | 19674A1 | 拉绳开关总成 | SWITCH ASSEMBLY Lanyard | 1 |
| 29 | 19674A07 | 开关/拉绳套件 | SWITCH/LANYARD KIT | 1 |
| 30 | 18303 | 螺钉 (.190-16 x 1.750) 不锈钢 | SCREW (.190-16 x 1.750) Stainless Steel | 2 |
| 31 | 813679 | 适配器 | ADAPTER | 1 |
| 32 | 15920Q54 | 拉绳总成 | LANYARD ASSEMBLY | 1 |
| 33 | 32866 | 螺钉 (#10-32 x 2.00) 不锈钢 | SCREW (#10-32 x 2.00) Stainless Steel | 2 |
| 34 | 18321 | 安装夹 | CLAMP Mounting | 1 |
| 35 | 24676 | 垫圈 (.200 x .440 x .032) | WASHER (.200 x .440 x .032) | 2 |
| 36 | 68219 | 螺母 (#10-32) 不锈钢 | NUT (#10-32) Stainless Steel | 4 |
| 37 | 79146 | 固定座 | RETAINER | 1 |
| 38 | 11149A2 | 线缆总成 (6.00英寸) | CABLE ASSEMBLY (6.00 Inches) | 1 |
| 39 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 40 | 88334A2 | 防腐电极套件 | MERCATHODE KIT | 1 |
| 40 | 8M0180081 | 防腐电极套件 | MERCATHODE KIT | 1 |
| 41 | 22793 | 螺丝(#9-14x0.875) | SCREW (#9-14 x .875) | 2 |
| 42 | 30164 | 垫圈(0.192x0.375x0.0312)不锈钢 | WASHER (.192 x .375 x .0312) Stainless Steel | 2 |
| 43 | 72958A5 | 电极总成 | ELECTRODE ASSEMBLY | 1 |
| 44 | 72957A5 | 阳极总成 | ANODE ASSEMBLY | 1 |
| 44 | 8M0181304 | 阳极总成 | ANODE ASSY | 1 |
| 45 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 2 |
| 45 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 2 |
| 46 | 87698 | 螺丝(#10-16 x 1.250)不锈钢 | SCREW (#10-16 x 1.250) Stainless Steel | 4 |
| 47 | 79091 | 保险丝20安培 | FUSE 20 Ampere | 1 |
| 47 | 8M0207796 | 保险丝20安培 | FUSE 20 AMP | 1 |
| 48 | 95084A10 | 电缆总成(5.00英寸)红色 | CABLE ASSEMBLY (5.00 Inches) Red | 1 |
| 48 | 8M0207788 | 拉线总成 | CABLE ASSEMBLY | 1 |
| 49 | 95084A13 | 电缆总成(64.00英寸) | CABLE ASSEMBLY (64.00 Inches) | 1 |
| 50 | 45076 | 黄铜螺母(#10-32) | NUT (#10-32) Brass | 4 |
| 51 | 79138A8 | 电缆总成(72.00英寸)黑色 | CABLE ASSEMBLY (72.00 Inches) Black | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 828123T19 | 空气压缩机总成 | COMPRESSOR ASSEMBLY Air | 1 |
| 1 | 8M0060052 | 空气压缩机总成 | COMPRESSORY ASSEMBLY Air | 1 |
| 1 | 828123T26 | 空气压缩机总成 | COMPRESSOR ASSEMBLY Air | 1 |
| 1 | 8M0060052 | 空气压缩机总成 | COMPRESSORY ASSEMBLY Air | 1 |
| 1 | 828123T29 | 空气压缩机总成 | COMPRESSOR ASSEMBLY Air | 1 |
| 1 | 8M0060052 | 空气压缩机总成 | COMPRESSORY ASSEMBLY Air | 1 |
| 2 | 828131A8 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 2 | 8M0050792 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 2 | 828131A09 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 2 | 8M0050792 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 3 | NSS | 卡环(不单独销售) | NOT SOLD SEPARATE Snap Ring | 1 |
| 4 | 82130020 | 螺钉 (M6 x 20) | SCREW (M6 x 20) | 4 |
| 5 | 832804 | O型圈（2.739 x 0.070） | O-RING (2.739 x .070) | 1 |
| 6 | 832804 | O型圈（2.739 x 0.070） | O-RING (2.739 x .070) | 1 |
| 7 | 833146T3 | 连杆总成 | CONNECTING ROD ASSEMBLY | 1 |
| 7 | 833146T06 | 连杆总成 | CONNECTING ROD ASSEMBLY | 1 |
| 7 | 833146T05 | 连杆总成 | CONNECTING ROD ASSEMBLY | 1 |
| 7 | 833146T06 | 连杆总成 | CONNECTING ROD ASSEMBLY | 1 |
| 7 | 833146T06 | 连杆总成 | CONNECTING ROD ASSEMBLY | 1 |
| 8 | NSS | 活塞总成(不单独销售) | NOT SOLD SEPARATE Piston assembly | 1 |
| 9 | 8348101 | 锁环 | RING Lock | 2 |
| 10 | 835088A10 | 簧片阀板总成 | REED PLATE ASSEMBLY | 1 |
| 11 | 67207 | O型圈（3.489 x 0.070） | O-RING (3.489 x .070) | 2 |
| 12 | 832804 | O型圈（2.739 x 0.070） | O-RING (2.739 x .070) | 1 |
| 13 | 828225 | 密封件 | SEAL | 1 |
| 14 | 835087A8 | 压缩机缸盖套件 | HEAD KIT Compressor | 1 |
| 14 | 8M0073889 | 压缩机缸盖套件 | HEAD KIT Compressor | 1 |
| 15 | 8812711 | 接头 | FITTING | 1 |
| 16 | 856744 | 接头 | FITTING | 1 |
| 17 | 831985 | O型圈（0.468 x 0.078） | O-RING (.468 x .078) | 1 |
| 18 | 996642 | 90度弯头接头(0.125-27x0.250)尼龙 | FITTING Elbow 90 Degree (.125-27 x .250) Nylon | 1 |
| 19 | 428641 | 止回阀接头 | FITTING Check Valve | 2 |
| 20 | 151331 | 接头 | FITTING | 1 |
| 21 | 16604 | 直通接头（0.125-27） | FITTING Straight (.125-27) | 1 |
| 22 | 82446035 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 23 | 13536A14 | 温度传感器总成 | SENSOR ASSEMBLY Temperature | 1 |
| 24 | 137151 | 固定座 | RETAINER | 1 |
| 25 | 81893414 | 螺钉（M8 x 14） | SCREW (M8 x 14) | 1 |
| 26 | 8215832 | 特殊销（1.5英寸） | PIN Special (1.5 Inches) | 1 |
| 27 | 85593912 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 6 |
| 28 | 8328233 | 滑轮 | PULLEY | 1 |
| 28 | 8M0175171 | 滑轮 | PULLEY | 1 |
| 29 | 81893450 | 螺钉(M8 x 50) | SCREW (M8 x 50) | 4 |
| 30 | 13541 | 公插头 | PLUG Male | 1 |
| - | 832804A1 | O型圈套件 | O-RING KIT | 1 |
| - | 832804A03 | O型圈套件 | O-RING KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 884552T1 | 空气处理器总成 | AIR HANDLER ASSEMBLY | 1 |
| - | 884552T03 | 空气处理器总成 | AIR HANDLER ASSEMBLY | 1 |
| - | 884552T07 | 空气处理器总成 (完整) | AIR HANDLER ASSEMBLY Complete | 1 |
| 1 | 858541T3 | 安装板 | PLATE | 1 |
| 2 | 804680 | 衬垫 | GASKET | 1 |
| 3 | 828623T6 | 簧片阀总成 | REED BLOCK ASSEMBLY | 6 |
| 4 | 8555252 | 螺钉 (M6) | SCREW (M6) | 12 |
| 5 | 855364 | 衬套 | BUSHING | 3 |
| 6 | 855362 | 护孔环 | GROMMET | 3 |
| 6 | 855362001 | 护孔环 | GROMMET | 3 |
| 6 | 855362001 | 护孔环 | GROMMET | 3 |
| 7 | 817274 | 垫圈(0.344×1.00×0.063)不锈钢 | WASHER (.344 x 1.00 x .063) Stainless Steel | 3 |
| 8 | 81893430 | 螺钉 (M8 x 30) | SCREW (M8 x 30) | 3 |
| 8 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 3 |
| 9 | 858539T6 | 空气集气室套件 | PLENUM KIT Air | 1 |
| 10 | 8046793 | 衬垫 | GASKET | 1 |
| 10 | 804679004 | 衬垫 | GASKET | 1 |
| 10 | 804679004 | 衬垫 | GASKET | 1 |
| 11 | 883942 | 螺钉(M4×16) | SCREW (M4 x 16) | 2 |
| 12 | 854445 | MAP传感器 | SENSOR MAP | 1 |
| 12 | 8M0237529 | MAP传感器 | SENSOR MAP | 1 |
| 13 | 884522 | MAP传感器支架 | BRACKET MAP Sensor | 1 |
| 14 | 889575 | 传感器总成 | SENSOR ASSEMBLY | 1 |
| 14 | 8M0214984 | 温度传感器 | SENSOR Temperature | 1 |
| 14 | 885342001 | 传感器总成 | SENSOR ASSEMBLY | 1 |
| 14 | 8M0148668 | 传感器总成 | SENSOR ASSEMBLY | 1 |
| 15 | 627021 | O型圈(.301 x .070) | O-RING (.301 x .070) | 1 |
| 15 | 888814 | O型圈(0.351 x 0.072) | O-RING (.351 x .072) | 1 |
| 15 | 896699 | O型圈（1.78毫米 x 0.08毫米） | O-RING (1.78 mm x .08 mm) | 1 |
| 16 | 877828T02 | 电子节气门控制器 | CONTROL Throttle - Electronic | 1 |
| 17 | 881852 | 螺柱 M6 X 50 | STUD M6 x 50 | 4 |
| 18 | 889452 | 螺母 | NUT | 4 |
| 19 | 881005 | 隔离器 | ISOLATOR | 1 |
| 20 | 880791 | 安装板 | PLATE | 1 |
| 21 | 889594 | 卡箍 | CLAMP | 1 |
| 21 | 889594001 | 卡箍 | CLAMP | 1 |
| 22 | 881004 | 安装板 | PLATE | 1 |
| 23 | 82130014 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 4 |
| 24 | 855426 | O型圈 | O-RING | 1 |
| 25 | 859230 | 固定座 | RETAINER | 1 |
| 25 | 859230T | 固定座 | RETAINER | 1 |
| 26 | 804842 | 卡箍 | CLAMP | 1 |
| 27 | 857149T2 | 油泵总成 | PUMP ASSEMBLY Oil | 1 |
| 27 | 8M0185614 | 机油泵 | OIL PUMP | 1 |
| 28 | 884353 | 支架 | BRACKET | 1 |
| 29 | 858870 | 止回阀 | CHECK VALVE | 6 |
| 30 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 1 |
| 31 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 32 | 82130040 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 12 |
| 33 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 1 |
| 33 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 1 |
| 34 | 880083T1 | 盖总成 | COVER ASSEMBLY | 1 |
| 35 | 13467 | 衬套（内径0.88） | GROMMET (.88 Inside Diameter) | 3 |
| 36 | 89219 | 堵头 | PLUG | 1 |
| 36 | 89219001 | 堵头 | PLUG | 1 |
| 36 | 89219001 | 堵头 | PLUG | 1 |
| 37 | 821555 | 护孔环 | GROMMET | 2 |
| 37 | 8M0153609 | 护孔环 | GROMMET | 2 |
| 37 | 821555001 | 护孔环 | GROMMET | 2 |
| 37 | 8M0153609 | 护孔环 | GROMMET | 2 |
| 38 | 881277T2 | 衰减器 | ATTENUATOR | 1 |
| 39 | 856954 | 衬套 | BUSHING | 2 |
| 40 | 834985 | 护孔环 | GROMMET | 2 |
| 40 | 8M0190980 | 护孔环 | GROMMET | 2 |
| 41 | NSS | 不单独销售 密封件 | NOT SOLD SEPARATE Seal | 1 |
| 42 | 20116 | 护孔环 | GROMMET | 1 |
| 43 | 880084T | 滤清器总成 | FILTER ASSEMBLY | 1 |
| 43 | 880084T01 | 空气滤清器总成 | FILTER ASSEMBLY Air | 1 |
| 44 | 881865 | 挂档启动警示贴纸 | DECAL Caution-Start in Gear (Start In Gear) | 1 |
| 45 | 65567 | 不锈钢垫圈(0.265x0.750x0.048) | WASHER (.265 x .750 x .048) Stainless Steel | 2 |
| 46 | 82130025 | 螺钉(M6x25) | SCREW (M6 x 25) | 2 |
| 47 | 858902 | 卡箍 | CLAMP | 1 |
| - | 832934A00 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 877869A03 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A07 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A04 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A07 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 850287A2 | 空气处理器总成 | AIR HANDLER ASSEMBLY | 1 |
| - | 850287T10 | 空气处理器总成 | AIR HANDLER ASSEMBLY | 1 |
| 1 | 850281A1 | 适配板套件 | ADAPTER PLATE KIT | 1 |
| 2 | 850283 | 衬垫 | GASKET | 1 |
| 2 | 804680 | 衬垫 | GASKET | 1 |
| 3 | 850282 | 衬垫 | GASKET | 1 |
| 4 | 828623 | 簧片阀组 | REED BLOCK | 6 |
| 4 | 828623T6 | 簧片阀总成 | REED BLOCK ASSEMBLY | 6 |
| 5 | 855525 | 螺钉 (M6 X 1) | SCREW (M6 X 1) | 12 |
| 6 | 855644 | 分电器 | DISTRIBUTOR | 1 |
| 6 | 855644T | 分电器 | DISTRIBUTOR | 1 |
| 7 | 855364 | 衬套 | BUSHING | 6 |
| 8 | 855362 | 护孔环 | GROMMET | 6 |
| 8 | 855362001 | 护孔环 | GROMMET | 6 |
| 9 | 4000355 | 螺钉(M8×35) | SCREW (M8 x 35) | 3 |
| 10 | 817274 | 垫圈(0.344×1.00×0.063)不锈钢 | WASHER (.344 x 1.00 x .063) Stainless Steel | 3 |
| 11 | 855631A1 | 空气集气室套件 | PLENUM KIT Air | 1 |
| 12 | 8554243 | 接头 | FITTING | 1 |
| 13 | 8554242 | 弯头 | ELBOW | 1 |
| 14 | 879194027 | 衬垫 | GASKET | 1 |
| 15 | 13221A1 | 温度传感器总成 | SENSOR ASSEMBLY Temperature | 1 |
| 15 | 13221T01 | 温度传感器 | SENSOR TEMP | 1 |
| 16 | 4005685 | 螺钉（M4×10） | SCREW (M4 x 10) | 3 |
| 17 | 26995 | 防松垫圈(#8不锈钢) | LOCKWASHER (#8) Stainless Steel | 3 |
| 18 | 4001987 | 螺钉(M4×16) | SCREW (M4 x 16) | 2 |
| 19 | 855425A1 | 节气门体套件 | THROTTLE BODY KIT | 1 |
| 19 | 841194T04 | 节气门体总成 | THROTTLE BODY ASSEMBLY | 1 |
| 20 | 855426 | O型圈 | O-RING | 1 |
| 21 | 82130040 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 4 |
| 22 | 855524 | 安装板 | PLATE | 1 |
| 23 | 81893450 | 螺钉(M8 x 50) | SCREW (M8 x 50) | 3 |
| 24 | 855588 | 支架 | BRACKET | 1 |
| 25 | 81893440 | 螺钉 (M8 x 40) | SCREW (M8 x 40) | 3 |
| 26 | 85583445 | 管材 (6英寸) | TUBING (6 IN.) | 6 |
| 26 | 85583464 | 管材 (34.00英寸整卷) | TUBING (34.00 Inches Bulk) | 6 |
| 27 | 56762 | 扎带(4.00英寸) | TIE STRAP (4.00 Inches) | 13 |
| 28 | 85606064 | 管材 (36.00英寸散装) | TUBING (36.00 Inches Bulk) | 1 |
| 28 | 8M0054152 | 管材(39.00英寸整卷) | TUBING (39.00 Inches Bulk) | 1 |
| 29 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 3 |
| 29 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 3 |
| 30 | 81893440 | 螺钉 (M8 x 40) | SCREW (M8 x 40) | 2 |
| 31 | 8552842 | 支架 | BRACKET | 1 |
| 32 | 8554243 | 接头 | FITTING | 1 |
| 33 | 64705 | 接头 | FITTING | 1 |
| 34 | 855884P1 | 油泵 | PUMP Oil | 1 |
| 35 | 856542 | 衬垫 | GASKET | 1 |
| 36 | 8565421 | 衬垫 | GASKET | 1 |
| 37 | 82381455 | 油管（25.00英寸散装） | TUBING (25.00 Inches Bulk) | 1 |
| - | 832934A98 | 衬垫套件 | GASKET SET | 1 |
| - | 8M0133170 | 衬垫套件 | GASKET SET | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 850302A1 | 下罩-左舷(左) | BOTTOM COWL Port (Port) | 1 |
| 1 | 850302A07 | 下罩盖（左舷） | BOTTOM COWL Port | 1 |
| 2 | 854367001 | 堵头 | PLUG | 1 |
| 3 | 850301A1 | 下罩-右舷(右) | BOTTOM COWL Starboard (Starboard) | 1 |
| 3 | 850301A07 | 下罩盖（右舷） | BOTTOM COWL Starboard | 1 |
| 4 | 8253183 | 密封条(44英寸) | SEAL (44.00 Inches) | 2 |
| 4 | 8M0109218 | 罩盖密封条 | SEAL - COWL | 2 |
| 5 | 82130040 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 4 |
| 6 | 824868 | 螺钉(M6×75) | SCREW (M6 x 75) | 3 |
| 7 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 7 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 8 | 850684F1 | 前手柄 | FRONT HANDLE | 1 |
| 8 | 8M0053903 | 前手柄 | FRONT HANDLE | 1 |
| 9 | 335891 | 衬套 | BUSHING | 2 |
| 10 | 48462 | O型圈 (.614 x .070) | O-RING (.614 x .070) | 1 |
| 11 | 8219423 | 棘爪 | PAWL | 1 |
| 12 | 69057 | 垫片(.281 x .734 x .063) | WASHER (.281 x .734 x .063) | 1 |
| 13 | 401366 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 3 |
| 14 | 8214281 | 螺钉(#10-16x0.625) | SCREW (#10-16 x .625) | 1 |
| 15 | 822873 | 卡扣 | CLIP | 1 |
| 16 | 8569901 | 升降倾斜开关 | SWITCH Trim | 1 |
| 16 | 8M0235191 | 升降倾斜开关 | SWITCH Trim | 1 |
| 16 | 896620001 | 升降倾斜开关 | SWITCH Trim | 1 |
| 16 | 8M0235191 | 升降倾斜开关 | SWITCH Trim | 1 |
| 17 | 859359A2 | 索具套件(上部) | RIGGING KIT (Upper) | 1 |
| 17 | 8M8027677 | 3.0升索具套件 | RIGGING KIT 3.0L | 1 |
| 18 | NSS | 下部夹具(不单独销售) | NOT SOLD SEPARATE Clamp-Lower | 1 |
| 19 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 2 |
| 20 | NSS | 绑带(不单独销售) | NOT SOLD SEPARATE Strap | 1 |
| 21 | 859343 | 泡沫垫 | FOAM | 1 |
| 22 | 850181 | 捆扎带(11.750英寸) | TIE STRAP (11.750 Inches) | 2 |
| 23 | 852361T1 | 机罩手柄 | HANDLE Cowl | 2 |
| 23 | 850682A06 | 支架和手柄套件 | BRACKET AND HANDLE KIT | 2 |
| 24 | 29402 | 波形垫圈 | WAVE WASHER | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9784A8 | 曲轴 | CRANKSHAFT | 1 |
| 1 | 9784A11 | 曲轴总成 | CRANKSHAFT ASSEMBLY | 1 |
| 2 | NSS | 磨损套筒(不单独销售) | NOT SOLD SEPARATE Wear Sleeve | 1 |
| 3 | 67923 | 球轴承(下部) | BEARING Ball (LOWER) | 1 |
| 3 | 67923T | 滚珠轴承 | BEARING Ball | 1 |
| 4 | 67446 | 环 | RING | 1 |
| 5 | 816106 | 环 | RING | 7 |
| 5 | 843198T01 | 密封环 | RING Seal | 7 |
| 6 | 91800 | 半圆键 | KEY Woodruff | 1 |
| 7 | 35126 | O型圈(.859 x .139) | O-RING (.859 x .139) | 1 |
| 8 | 817001A1 | 轴承座圈总成 | RACE ASSEMBLY Bearing | 2 |
| 8 | 8M0113288 | 轴承座圈总成 | RACE ASSY-BEARING | 2 |
| 9 | NSS | 滚针轴承(不单独销售) | NOT SOLD SEPARATE Needle Roller | 88 |
| 10 | 855354A3 | 活塞 | PISTON | 3 |
| 10 | 859297T2 | 活塞 | PISTON | 3 |
| 10 | 855353A3 | 活塞 | PISTON | 3 |
| 10 | 855353T3 | 活塞 | PISTON | 3 |
| 10 | 856936A2 | 活塞总成 | PISTON ASSEMBLY | AR |
| 10 | 859444A2 | 活塞总成 | PISTON ASSEMBLY | AR |
| 10 | 856938A2 | 活塞总成 | PISTON ASSEMBLY | AR |
| 10 | 859446A2 | 活塞总成 | PISTON ASSEMBLY | AR |
| 10 | 856935A2 | 活塞总成 | PISTON ASSEMBLY | AR |
| 10 | 859443A2 | 活塞总成 | PISTON ASSEMBLY | AR |
| 10 | 856937A2 | 活塞总成 | PISTON ASSEMBLY | AR |
| 10 | 859445A2 | 活塞总成 | PISTON ASSEMBLY | AR |
| 11 | 8320811 | 锁紧环 | LOCK RING | 12 |
| 12 | 834805A12 | 活塞环组 | RING SET Piston | 12 |
| 12 | 856939A12 | 活塞环组 | RING SET Piston | 3 |
| 12 | 875252A12 | 活塞环组 | RING SET Piston | 3 |
| 12 | 856940A12 | 活塞环组 | RING SET Piston | 3 |
| 12 | 875257A12 | 活塞环组 | RING SET Piston | 3 |
| 13 | 822373A3 | 连杆总成 | CONNECTING ROD ASSEMBLY | 6 |
| 13 | 8M0125869 | 连杆套件 | CONN ROD KIT | 6 |
| 14 | 94320 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 12 |
| 15 | 43012A1 | 轴承/保持架套件 | BEARING/CAGE KIT | 12 |
| 15 | 8M0235070 | 轴承保持架 | CAGE BEARING | 12 |
| 16 | NSS | 不单独销售 滚针轴承 | NOT SOLD SEPARATE Needle Roller Bearing | 96 |
| 17 | 88263 | 止推垫片 | THRUST WASHER | 12 |
| 18 | 88258 | 滚针轴承 | NEEDLE Roller Bearing | 204 |
| 18 | 8M0204715 | 滚针@102 | NEEDLES-BRG @102 | 204 |
| 19 | 816773A2 | 轴承总成（上部） | BEARING ASSEMBLY (UPPER) | 1 |
| 20 | 815449 | 油封 | SEAL Oil | 1 |
| 20 | 859093 | 密封件 | SEAL | 1 |
| 21 | 823683 | O型圈(1.989 x .070) | O-RING (1.989 x .070) | 1 |
| - | 854198A98 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 854198A99 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 854199A98 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 854199A99 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 832934A98 | 衬垫套件 | GASKET SET | 1 |
| - | 8M0133170 | 衬垫套件 | GASKET SET | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9811T87 | 气缸体总成 | CYLINDER BLOCK ASSEMBLY | 1 |
| 1 | 899162A06 | 气缸体总成 | CYLINDER BLOCK ASSEMBLY | 1 |
| 1 | 9811T92 | 气缸体 | CYLINDER BLOCK | 1 |
| 1 | 899162A06 | 气缸体总成 | CYLINDER BLOCK ASSEMBLY | 1 |
| 2 | 81893440 | 螺钉 (M8 x 40) | SCREW (M8 x 40) | 4 |
| 3 | 8569662 | 支架 | BRACKET | 2 |
| 3 | 8M0111325 | 盖板 | COVER | 2 |
| 4 | 903509 | 螺柱（M10×1.5×64） | STUD (M10 x 1.5 x 64) | 4 |
| 5 | 8154431 | 螺柱（M10×1.5×155） | STUD (M10 x 1.5 x 155) | 6 |
| 6 | 8248577 | 导流板 | DEFLECTOR | 6 |
| 7 | 8781051 | 止回阀 | CHECK VALVE | 1 |
| 8 | 67296 | 销 | PIN | 3 |
| 8 | 8M0036405 | 销 | PIN | 3 |
| 9 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 1 |
| 10 | 850309 | 堵头 | PLUG | 6 |
| 10 | 850309001 | 止动塞 | PLUG Stop | 6 |
| 10 | 850309001 | 止动塞 | PLUG Stop | 6 |
| 11 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 14 |
| 11 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 14 |
| 12 | 82446180 | 螺钉(M10×80) | SCREW (M10 x 80) | 8 |
| 13 | 8245021 | 连接器 | CONNECTOR | 1 |
| 14 | 63779 | 定位销 (.250 x .625) | PIN Dowel (.250 x .625) | 4 |
| 15 | 856774 | 垫圈(0.406×0.750×0.105)不锈钢 | WASHER (.406 x .750 x .105) Stainless Steel | 10 |
| 15 | 8M0214963 | 垫圈 | WASHER | 10 |
| 16 | 4013610 | 螺母(M10不锈钢) | NUT (M10) Stainless Steel | 10 |
| 17 | 8283582 | 传感器 | SENSOR | 1 |
| 17 | 8M0082988 | 曲轴位置传感器 | SENSOR Crankshaft Position | 1 |
| 18 | 40011107 | 不锈钢螺钉(M5x16) | SCREW (M5 x 16) Stainless Steel | 2 |
| 19 | 9787A4 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 20 | 62700 | O型圈(3.237 x .103) | O-RING (3.237 x .103) | 1 |
| 21 | 8308981 | 密封件 | SEAL | 2 |
| 22 | 82130020 | 螺钉 (M6 x 20) | SCREW (M6 x 20) | 4 |
| 23 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 1 |
| 24 | 858902 | 卡箍 | CLAMP | 1 |
| 25 | 65292 | J型卡扣 | J CLIP | 3 |
| 25 | 8M0024808 | J型夹 | J-CLIP | 3 |
| 26 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 2 |
| 27 | 818574 | 密封件 | SEAL | 2 |
| 28 | 884391 | 密封件 | SEAL | 6 |
| 29 | 858485T6 | 气缸盖 | CYLINDER HEAD | 1 |
| 29 | 858485T07 | 右舷气缸盖 | CYLINDER HEAD Starboard | 1 |
| 29 | 858485T07 | 右舷气缸盖 | CYLINDER HEAD Starboard | 1 |
| 29 | 858483T6 | 气缸盖 | CYLINDER HEAD | 1 |
| 29 | 858483T07 | 左舷气缸盖 | CYLINDER HEAD Port | 1 |
| 29 | 858483T07 | 左舷气缸盖 | CYLINDER HEAD Port | 1 |
| 30 | 885599003 | 节温器 54°C (130°F) | THERMOSTAT 54°C (130°F) (130 Degrees) | 2 |
| 30 | 8M0057307 | 节温器 54°C/130°F | THERMOSTAT 54 Degree C/130 Degree F | 2 |
| 30 | 885599004 | 节温器 54°C/130°F | THERMOSTAT 54 Degree C/130 Degree F | 2 |
| 30 | 8M0057307 | 节温器 54°C/130°F | THERMOSTAT 54 Degree C/130 Degree F | 2 |
| 31 | 8503181 | 衬垫 | GASKET | 2 |
| 32 | 887601 | 节温器盖 | COVER Thermostat | 1 |
| 32 | 887601002 | 左舷盖 | COVER Port | 1 |
| 32 | 887602 | 节温器盖 | COVER Thermostat | 1 |
| 32 | 887602002 | 右舷盖 | COVER Starboard | 1 |
| 33 | 82130025 | 螺钉(M6x25) | SCREW (M6 x 25) | 4 |
| 34 | 859096 | 螺钉(M8 x 50) | SCREW (M8 x 50) | 40 |
| 34 | 8M0045380 | 螺钉(M8 x 50) | SCREW (M8 x 50) | 40 |
| 35 | 889575 | 传感器总成 | SENSOR ASSEMBLY | 2 |
| 35 | 8M0214984 | 温度传感器 | SENSOR Temperature | 2 |
| 35 | 885342001 | 传感器总成 | SENSOR ASSEMBLY | 2 |
| 35 | 8M0148668 | 传感器总成 | SENSOR ASSEMBLY | 2 |
| 36 | 627021 | O型圈(.301 x .070) | O-RING (.301 x .070) | 2 |
| 36 | 888814 | O型圈(0.351 x 0.072) | O-RING (.351 x .072) | 2 |
| 36 | 896699 | O型圈（1.78毫米 x 0.08毫米） | O-RING (1.78 mm x .08 mm) | 2 |
| 37 | 328022 | 黄铜管塞 (.125-27) | PLUG Pipe (.125-27) Brass | 1 or 2 |
| 38 | 857186A1 | 隔板总成 | PLATE ASSEMBLY | 1 |
| 38 | 857186T02 | 隔板总成 | PLATE ASSEMBLY | 1 |
| 39 | 855729 | 支架 | MOUNT | 3 |
| 40 | 82130145 | 螺丝(M10 x 45) | SCREW (M10 x 45) | 3 |
| 41 | 19565 | 护孔环 | GROMMET | 1 |
| 41 | 19565002 | 护孔环 | GROMMET | 1 |
| 41 | 19565002 | 护孔环 | GROMMET | 1 |
| 42 | 855725 | 垫圈 | WASHER | 6 |
| 43 | 858424 | 卡箍 | CLAMP | 1 |
| 44 | 858951 | J型卡扣 | J CLIP | 1 |
| 45 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 1 |
| 46 | 888435 | 支架 | BRACKET | 1 |
| 47 | 82130016 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 48 | 858932 | 卡扣 | CLIP | 1 |
| 49 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 1 |
| 49 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 1 |
| 50 | 8405101 | 销 | PIN | 1 |
| 51 | 82494810 | 螺丝 (M6 x 10) | SCREW (M6 x 10) | 1 |
| - | 832934A00 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 877869A03 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A07 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A04 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A07 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 832937A05 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 832937A06 | 传动轴壳体总成-加长型 | HOUSING ASSEMBLY Driveshaft - Long | 1 |
| 1 | 832938A5 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 832938A06 | 传动轴壳体总成-超长/特超长型 | HOUSING ASSEMBLY Driveshaft - X/XX-Long | 1 |
| 2 | 856983 | 双头螺柱(M12 x 52) | STUD (M12 x 52) | 4 |
| 2 | 8M0008031 | 双头螺柱(M12 x 1.75 x 52) | STUD (M12 x 1.75 x 52) | 4 |
| 3 | 857136 | 螺钉(M12×35毫米) | SCREW (M12 x 35 MM) | 1 |
| 4 | 8331231 | 护孔环 | GROMMET | 1 |
| 5 | 856982 | 垫圈(0.5×0.81×0.09英寸)不锈钢 | WASHER (.500 x .810 x .090) Stainless Steel | 5 |
| 6 | 896895 | 螺母(M12) | NUT (M12) | 4 |
| 7 | 64649 | 堵头 | PLUG | 1 |
| 8 | 898834 | 螺栓（M14×178） | BOLT (M14 x 178) | 2 |
| 9 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 2 |
| 10 | 815432 | 垫圈(.562 x 2.00 x .125) | WASHER (.562 x 2.00 x .125) | 2 |
| 11 | 8154331 | 垫圈（1.25×2.00×0.19） | WASHER (1.25 x 2.00 x .19) | 2 |
| 12 | 8137711 | 支架 | MOUNT | 2 |
| 13 | 825190 | 垫圈 | WASHER | 2 |
| 14 | 896602 | 螺母(M14) | NUT (M14) | 2 |
| 15 | 8186442 | 卡箍 | CLAMP | 2 |
| 15 | 879150A90 | 下支架盖套件 | COVER KIT Lower Mount | 2 |
| 16 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 4 |
| 16 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 17 | 72521 | 内齿锁紧垫圈 | LOCKWASHER Internal Tooth | 1 |
| 18 | 8M0001136 | 下支架盖 | COVER Lower Mount | 2 |
| 18 | 879150A90 | 下支架盖套件 | COVER KIT Lower Mount | 2 |
| 19 | 69079 | 螺钉 (#10-16 x .440) | SCREW (#10-16 x .440) | 2 |
| 20 | 8329321 | 密封件 | SEAL | 1 |
| 21 | 833116A4 | 排气管总成 | TUBE ASSEMBLY Exhaust | 1 |
| 22 | 8524052 | 滤网 | STRAINER | 1 |
| 22 | 8M0026113 | 滤网 | STRAINER | 1 |
| 23 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 6 |
| 23 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 6 |
| 24 | 8329417 | 水管 | TUBE Water | 1 |
| 24 | 8M0042785 | 水管 | TUBE-WATER | 1 |
| 24 | 8329418 | 水管 | TUBE Water | 1 |
| 24 | 8M0042786 | 水管 | TUBE Water | 1 |
| 24 | 8329419 | 水管 | TUBE Water | 1 |
| 24 | 8M0042787 | 水管 | TUBE-WATER | 1 |
| 25 | 832940001 | 密封件 | SEAL | 1 |
| 26 | 8329391 | 卡箍 | CLAMP | 1 |
| 27 | 41508 | 螺钉(0.250-20×0.500)不锈钢 | SCREW (.250-20 x .500) Stainless Steel | 1 |
| 28 | 823979T1 | 隔套 | SPACER | 1 |
| 28 | 8M0105088 | 传动轴壳体加长隔套（黑色） | SPACER Driveshaft Housing X-Long, Black | 1 |
| 29 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 30 | 857009 | 双头螺柱（M12×179） | STUD (M12 x 179) | 4 |
| 30 | 8M0008047 | 双头螺柱（M12×179） | STUD (M12 x 179) | 4 |
| 31 | 857137 | 螺钉 (M12 X 160) | SCREW (M12 x 160) | 1 |
| 32 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 2 |
| 32 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 92876A9 | 双机延长套件 | EXTENSION KIT Dual Engine | 1 |
| 1 | 71565A2 | 管总成 | TUBE ASSEMBLY | 1 |
| 2 | 48462 | O型圈 (.614 x .070) | O-RING (.614 x .070) | 1 |
| 3 | 41055 | 支架 | MOUNT | 1 |
| 4 | 42100 | 锁紧垫圈 | TAB WASHER | 2 |
| 5 | 37984 | 螺母 (.875-14) | NUT (.875-14) | 2 |
| 5 | 8M0041651 | 螺母 (.875-14) | NUT (.875-14) | 2 |
| 6 | 88404 | 锁紧垫圈 | TAB WASHER | 2 |
| 7 | 38601 | 螺丝(.250-28 x 1.250) | SCREW (.250-28 x 1.250) | 4 |
| 8 | 17729A1 | 支架 | BRACKET | 2 |
| 9 | 62055 | 螺钉(.312-24 x 1.250) | SCREW (.312-24 x 1.250) | 4 |
| 10 | 17728 | 锁紧垫圈 | TAB WASHER | 4 |
| 11 | 140001 | 螺钉(0.375-24×1.38) | SCREW (.375-24 x 1.38) | 2 |
| 12 | 34863 | 螺母 (.375-24) | NUT (.375-24) | 6 |
| 12 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 6 |
| 13 | 979331 | 转向眼环 | STEERING EYE | 2 |
| 13 | 8M0026167 | 转向眼环 | STEERING EYE | 2 |
| 14 | 23651 | 衬套(1.625) | SLEEVE (1.625) | 2 |
| 15 | 97931 | 管材(4.00英寸) | TUBING (4.00 Inches) | 2 |
| 16 | 8149513 | 联轴器(15.00英寸) | COUPLER (15.00 Inches) | 1 |
| 16 | 8M0026098 | 联轴器15英寸 | COUPLER 15 In. | 1 |
| 17 | 42099 | 螺母(.562-18) | NUT (.562-18) | 1 |
| 18 | 821169 | 联轴器 | COUPLING | 1 |
| 19 | 34931 | 不锈钢垫圈(.406x.734x.063) | WASHER (.406 x .734 x .063) Stainless Steel | 2 |
| 20 | 94319 | 螺钉(.375-24 x 1.5) | SCREW (.375-24 x 1.5) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8502953 | 电气安装板 | PLATE Electrical Mounting | 1 |
| 1 | 850295T4 | 安装板 | PLATE | 1 |
| 2 | 850227 | 点火线圈 | COIL Ignition | 6 |
| 2 | 856991A1 | 线圈套件 | COIL KIT | 6 |
| 3 | 821945A63 | 高压电缆总成 | CABLE ASSEMBLY Hi Tension | 1 |
| 4 | 63709A1 | 护套/端子套件 | BOOT/TERMINAL KIT | 6 |
| 5 | 855672 | 火花塞 | SPARK PLUG | 6 |
| 5 | 889597Q | NGK IZFR5G @4 | NGK IZFR5G @4 | 6 |
| 5 | 855717 | 火花塞 | SPARK PLUG | OPT |
| 5 | 8557171 | 火花塞 | SPARK PLUG | OPT |
| 6 | 82129130 | 螺钉 (M6 x 30) | SCREW (M6 x 30) | 12 |
| 7 | 856535 | 传感器 | SENSOR | 1 |
| 7 | 8M6000628 | 压力传感器 | SENSOR PRESSURE | 1 |
| 8 | 856594 | 倒钩接头 | FITTING Barbed | 1 |
| 9 | 856600 | 固定座 | RETAINER | 1 |
| 10 | 856567A1 | 适配器线束总成 | HARNESS ASSEMBLY Adaptor | 1 |
| 11 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 11 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 12 | 9912878 | 软管 (.187) (26英寸散装) (15英寸) | HOSE (.187) (26.00 Inches Bulk) (15 IN.) | 1 |
| 13 | 825762 | MAP传感器 | SENSOR MAP | 1 |
| 14 | 82129114 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 2 |
| 15 | 85606064 | 管材(36英寸整卷)(28-1/2英寸) | TUBING (36.00 Inches Bulk) (28-1/2 IN.) | 1 |
| 15 | 8M0054152 | 管材(39.00英寸整卷) | TUBING (39.00 Inches Bulk) | 1 |
| 16 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 4 |
| 16 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 17 | 49436 | 垫圈 | WASHER | 4 |
| 18 | 833155 | 护孔环 | GROMMET | 4 |
| 19 | 8502341 | 衬套 | BUSHING | 4 |
| 20 | 82129114 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 2 |
| 21 | 819514A14 | 升降线束总成 | HARNESS ASSEMBLY Trim | 1 |
| 22 | 828151A1 | 继电器总成 | RELAY ASSEMBLY | 3 |
| 22 | 8M0207773 | 调整继电器总成 | RELAY ASSEMBLY Trim | 3 |
| 23 | NSS | 微调继电器标识贴(不单独销售) | NOT SOLD SEPARATE Decal-Trim Relay | 3 |
| 24 | 828102 | 支架 | BRACKET | 3 |
| 24 | 8M0207771 | 安装支架 | BRACKET Mounting | 3 |
| 25 | 818968 | 衬套 | BUSHING | 3 |
| 25 | 8M0214955 | 衬套 | BUSHING | 3 |
| 26 | 818967 | 护孔环 | GROMMET | 3 |
| 26 | 8M0207785 | 护孔环 | GROMMET | 3 |
| 27 | 82129125 | 螺丝(M6 x 25毫米) | SCREW (M6 x 25 mm) | 3 |
| 28 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 28 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 29 | 850385A2 | 发动机线束总成 | HARNESS ASSEMBLY Engine | 1 |
| 30 | 856624A2 | 线束总成 (维修件) | HARNESS ASSEMBLY (SERVICE ITEM) | 1 |
| 31 | 812619 | 黄色保险丝-20安培 | FUSE Yellow - 20 Ampere | 4 |
| 32 | 8289471 | 保险丝支架 | BRACKET Fuse Holder | 1 |
| 33 | 855634 | 螺钉(M4×0.7) | SCREW (M4 X .7) | 2 |
| 34 | 85649613 | 发动机控制单元ECU | ECU Engine Control Unit | 1 |
| 34 | 858891A23 | 电控单元 | ECU | 1 |
| 34 | 85649612 | 发动机控制单元ECU | ECU Engine Control Unit | 1 |
| 34 | 858891A22 | 电控单元 | ECU | 1 |
| 35 | 82130025 | 螺钉(M6x25) | SCREW (M6 x 25) | 3 |
| 36 | 8318701 | 衬套 | BUSHING | 6 |
| 37 | 834985 | 护孔环 | GROMMET | 3 |
| 37 | 8M0190980 | 护孔环 | GROMMET | 3 |
| 38 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 2 |
| 39 | 830897 | 垫 | PAD | 1 |
| 40 | 833136 | 卡扣 | CLIP | 1 |
| 41 | 8331371 | 电磁阀安装板 | PLATE Solenoid Mounting | 1 |
| 42 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 3 |
| 43 | 88439A26 | 蓄电池负极电缆总成 | CABLE ASSEMBLY Battery - Negative | 1 |
| 44 | 82129114 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 2 |
| 45 | 817109A2 | 电磁阀总成(#10-32/.3125-18端子) | SOLENOID ASSEMBLY (#10-32 / .3125-18 Terminals) | 1 |
| 46 | 822179 | 护孔环 | GROMMET | 2 |
| 47 | 82129125 | 螺丝(M6 x 25毫米) | SCREW (M6 x 25 mm) | 2 |
| 48 | 93388A7 | 线缆总成(黑色) | CABLE ASSEMBLY (BLACK) | 1 |
| 48 | 93388A14 | 线缆总成(黄/黑) | CABLE ASSEMBLY Yellow/Black | 1 |
| 49 | 818968 | 衬套 | BUSHING | 2 |
| 49 | 8M0214955 | 衬套 | BUSHING | 2 |
| 50 | 88439A25 | 电缆总成 蓄电池-正极 | CABLE ASSEMBLY Battery - Positive | 1 |
| 51 | 53166 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 2 |
| 52 | 68292 | 螺母(.312-18) | NUT (.312-18) | 2 |
| 52 | 8M0204668 | 螺母(.312-18) | NUT (.312-18) | 2 |
| 53 | 45076 | 黄铜螺母(#10-32) | NUT (#10-32) Brass | 2 |
| 54 | 813938 | 盖形螺母(#10-32) | CAP NUT (#10-32) | 1 |
| 55 | 81893412 | 螺钉（M8×12） | SCREW (M8 x 12) | 1 |
| 56 | 78866 | 绝缘体 | INSULATOR | 1 |
| 57 | 45076 | 螺母 (#10-32) 黄铜 | NUT (#10-32) Brass (BRASS) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 832935A16 | 排气板总成 | PLATE ASSEMBLY Exhaust | 1 |
| 1 | 832935A17 | 排气板总成 | PLATE ASSEMBLY Exhaust | 1 |
| 1 | 832935A17 | 排气板总成 | PLATE ASSEMBLY Exhaust | 1 |
| 2 | 8329335 | 衬垫 | GASKET | 1 |
| 2 | 832933006 | 衬垫 | GASKET | 1 |
| 3 | 8329344 | 衬垫(下部) | GASKET (Lower) | 1 |
| 3 | 832934006 | 衬垫 | GASKET | 1 |
| 4 | 8238051 | 密封件 | SEAL | 1 |
| 4 | 8M0043157 | 密封件 | SEAL | 1 |
| 5 | 8320761 | 止回阀接头 | FITTING Check Valve | 1 |
| 6 | 817519A1 | 排水单向阀总成 | CHECK VALVE ASSEMBLY Drain | 2 |
| 7 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 4 |
| 8 | 8348084 | 滤网 | STRAINER | 1 |
| 9 | 887603 | 接头 | FITTING | 1 |
| 10 | 65663A2 | 盖总成 | COVER ASSEMBLY | 1 |
| 10 | 8M0237835 | 罩盖总成 | COVER ASSY | 1 |
| 11 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 2 |
| 11 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 2 |
| 12 | 814190 | 托架 | CARRIER | 1 |
| 13 | 814191 | 护孔环 | GROMMET | 1 |
| 14 | 814189 | 提动阀 | POPPET | 1 |
| 15 | 64878 | 弹簧(黑色) | SPRING (Black) | 1 |
| 16 | 65664A1 | 隔板总成 | PLATE ASSEMBLY | 1 |
| 17 | 88907003 | 衬垫 | GASKET | 2 |
| 18 | 648771 | 隔膜 | DIAPHRAGM | 1 |
| 19 | 76451 | 垫圈 | WASHER | 1 |
| 20 | 69570 | 螺钉(#10-16 x .750) | SCREW (#10-16 x .750) | 1 |
| 21 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 4 |
| 21 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 22 | 8503061 | 怠速排气套 | BOOT Idle Exhaust | 1 |
| 22 | 850306A04 | 怠速排气护套套件 | BOOT KIT Idle Exhaust | 1 |
| 22 | 850306A04 | 怠速排气护套套件 | BOOT KIT Idle Exhaust | 1 |
| 23 | 888910 | 安装板 | PLATE | 1 |
| 24 | 82239312 | 螺钉(M5 x 12) | SCREW (M5 x 12) | 2 |
| 25 | 821908 | 堵头 | PLUG | 1 |
| 26 | 821915 | 垫圈 | WASHER | 1 |
| 27 | 859626A1 | 冲洗软管套件(进口) | FLUSH HOSE KIT (Inlet) | 1 |
| 28 | 8596001 | 接头 | FITTING | 1 |
| 29 | 30641 | O型圈(0.299x0.103) | O-RING (.299 x .103) | 1 |
| 30 | 8219631 | 止回阀 | CHECK VALVE | 1 |
| 31 | 850896 | 卡箍 (28.6) | CLAMP (28.6) | 2 |
| 32 | 821904 | 示流器接头 | FITTING Tell-Tale | 1 |
| 32 | 8M0077650 | 示流器接头 | FITTING Tell-Tale | 1 |
| 33 | 48237 | 衬套 | BUSHING | 1 |
| 34 | 43585 | 联轴器 | COUPLING | 1 |
| 35 | 126021 | 护孔环 | GROMMET | 1 |
| 35 | 12602002 | 护孔环 | GROMMET | 1 |
| 35 | 12602002 | 护孔环 | GROMMET | 1 |
| 36 | 822002 | 护孔环 | GROMMET | 1 |
| 37 | 94848 | 接头 | FITTING | 1 |
| - | 832934A00 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 881247A1 | 交流发电机 | ALTERNATOR | 1 |
| 1 | 8M6013461 | 交流发电机 | ALTERNATOR | 1 |
| 2 | 8523742 | 弹簧 | SPRING | 1 |
| 3 | 856815T2 | 张紧臂总成 | ARM TENSIONER ASSEMBLY | 1 |
| 4 | 4002320 | 垫圈 | WASHER | 2 |
| 5 | 8568941 | 衬套 | BUSHING | 1 |
| 6 | 856900 | 螺柱(M10×85) | STUD (M10 x 85) | 1 |
| 6 | 8M0034457 | 螺柱(M10×85) | STUD (M10 x 85) | 1 |
| 7 | 826292 | 螺母(M10)黄铜/镀镍 | NUT (M10) Brass/Nickel Plated | 1 |
| 8 | 852385A2 | 皮带轮总成 | PULLEY ASSEMBLY | 1 |
| 8 | 8M6005030 | 皮带轮总成 | PULLEY ASSY | 1 |
| 9 | 4010835 | 螺钉(M10×35)六角法兰-不锈钢 | SCREW (M10 x 35) Hex Flange - Stainless Steel | 1 |
| 10 | 828507Q5 | 皮带 | BELT | 1 |
| 11 | 859619T1 | 飞轮 | FLYWHEEL | 1 |
| 12 | 42979 | 螺母(M16) | NUT (M16) | 1 |
| 13 | 68229 | 垫圈(.641 x 1.250 x .190) | WASHER (.641 x 1.250 x .190) | 1 |
| 13 | 33001 | 垫圈 | WASHER | 1 |
| 14 | 45907 | 黄色塞 | PLUG Yellow | 1 |
| 15 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 16 | 856583A5 | 拉线总成 | CABLE ASSEMBLY | 1 |
| 17 | 4002319 | 垫圈 | WASHER | 1 |
| 18 | 82130150 | 螺丝(M10 x 50) | SCREW (M10 x 50) | 2 |
| 19 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 14360T77 | 燃油泵总成 | PUMP ASSEMBLY Fuel | 1 |
| - | 14360T74 | 燃油泵总成 | PUMP ASSEMBLY Fuel | 1 |
| 1 | NSS | 不单独销售 燃油泵 | NOT SOLD SEPARATE Fuel Pump | 1 |
| 2 | 857005A1 | 膜片组件 | DIAPHRAGM KIT | 2 |
| 3 | NSS | 膜片(不单独销售) | NOT SOLD SEPARATE Diaphragm | 1 |
| 4 | NSS | 固定座(不单独销售) | NOT SOLD SEPARATE Retainer | 2 |
| 5 | NSS | 弹簧(不单独销售) | NOT SOLD SEPARATE Spring | 1 |
| 6 | NSS | 盖帽(不单独销售) | NOT SOLD SEPARATE Cap | 1 |
| 7 | NSS | 弹簧(不单独销售) | NOT SOLD SEPARATE Spring | 1 |
| 8 | NSS | 盖帽(不单独销售) | NOT SOLD SEPARATE Cap | 1 |
| 9 | NSS | 膜片(不单独销售) | NOT SOLD SEPARATE Diaphragm | 1 |
| 10 | NSS | 增压垫片(不单独销售) | NOT SOLD SEPARATE Gasket-Boost | 1 |
| 11 | NSS | 脉冲垫片(不单独销售) | NOT SOLD SEPARATE Gasket-Pulse | 1 |
| 12 | 987691 | 衬垫 | GASKET | 1 |
| 12 | 8M0204705 | 衬垫@2 | GASKET @2 | 1 |
| 13 | 987752 | 安装板 | PLATE | 1 |
| 14 | 996642 | 90度弯头接头(0.125-27x0.250)尼龙 | FITTING Elbow 90 Degree (.125-27 x .250) Nylon | 1 |
| 15 | 82104540 | SCREW (M5 x 40) Fuel Pump | 2 | |
| 16 | 82130050 | 螺钉(M6×50)泵至曲轴箱 | SCREW (M6 x 50) Pump to Crankcase | 2 |
| 17 | 144303 | 底座 | BASE | 1 |
| 18 | 291112 | 接头 | FITTING | 1 |
| 18 | 782792 | 45度弯头接头(1.25) | FITTING Elbow 45 Degree (1.25) | 1 |
| 18 | 8M0207781 | 弯头 | ELBOW | 1 |
| 19 | 888493 | 弯头 | ELBOW | 1 |
| 20 | 805063 | O型圈(.301 x .070) | O-RING (.301 x .070) | 1 |
| 20 | 8M0204683 | O型圈(.070×.301内径) | O-Ring (.070 x .301 ID) | 1 |
| 21 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 2 |
| 22 | 856822A2 | 软管套管总成(18.00英寸) | HOSE AND SLEEVE ASSEMBLY (18.00 Inches) | 1 |
| 22 | 8M0043979 | 软管套管总成 | HOSE AND SLEEVE ASSEMBLY | 1 |
| 23 | 822769 | 连接器 | CONNECTOR | 1 |
| - | 832934A00 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 877869A03 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A07 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A04 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A07 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 883078A4 | 空气喷射器维修包 | INJECTOR KIT Air | 6 |
| 1 | 8M6001743 | 空气喷射器总成 | INJECTOR ASSEMBLY Air | 6 |
| - | 804875 | 密封套件 | SEAL KIT | 1 |
| 2 | 828694A1 | 杯形垫片总成 | WASHER ASSEMBLY Cupped | 6 |
| - | NSS | 燃油轨总成(不单独销售) | NOT SOLD SEPARATE Fuel Rail Assembly | 1 |
| 3 | 884429T16 | 燃油轨(左舷) | FUEL RAIL (Port) | 1 |
| 4 | 884430T06 | 燃油轨(右舷) | FUEL RAIL (Starboard) | 1 |
| 5 | 804830 | 卡箍 | CLAMP | 4 |
| 6 | 804831 | 卡箍 | CLAMP | 4 |
| 6 | 8048311 | 卡箍 | CLAMP | 4 |
| 6 | 8048311 | 卡箍 | CLAMP | 4 |
| 7 | 804832 | 卡箍 | CLAMP | 2 |
| 8 | 880816 | 卡箍 | CLAMP | 1 |
| 8 | 8M0041097 | 支架 | BRACKET | 1 |
| 9 | 804529 | O型圈套件(含6件) | O-RING KIT Contains 6 pcs | 1 |
| 10 | 804835 | 堵头 | PLUG | 1 |
| 11 | 804836 | 接头 | FITTING | 1 |
| 12 | 804837 | 阀门总成（0.5英寸直径） | VALVE ASSEMBLY (.5 Inch Diameter) | 1 |
| 12 | 883542 | 阀门总成(0.375英寸直径) | VALVE ASSEMBLY (.375 Inch Diameter) | 1 |
| 12 | 8M0047053 | 施拉德阀维修包 | VALVE KIT Shrader | 1 |
| 13 | 883542 | 阀门总成(0.375英寸直径) | VALVE ASSEMBLY (.375 Inch Diameter) | 1 |
| 13 | 8M0047053 | 施拉德阀维修包 | VALVE KIT Shrader | 1 |
| 14 | 804839001 | 盖帽 | CAP | 2 |
| 14 | 805515 | 施拉德阀帽-黄铜 | CAP Shrader Valve - Brass | 2 |
| 14 | 805515 | 施拉德阀帽-黄铜 | CAP Shrader Valve - Brass | 2 |
| 14 | 8M0046566 | 阀帽 | CAP Valve | 2 |
| 15 | 804840 | O型圈套件 | O-RING KIT | 1 |
| 16 | 804530 | O型圈套件(含6件) | O-RING KIT Contains 6 pcs | 1 |
| 17 | 804533 | 膜片总成 | DIAPHRAGM ASSEMBLY | 1 |
| 18 | 804534 | 弹簧 | SPRING | 1 |
| 19 | 804536 | O型圈 | O-RING | 1 |
| 20 | 804535 | 盖板 | COVER | 1 |
| 20 | 804535001 | 盖板 | COVER | 1 |
| 21 | 804526 | 螺丝包(M5x16)(2件) | SCREW PACKAGE (M5 x 16) (2 Per) | 4 |
| 22 | 804532 | O型圈套件(每套16个) | O-RING KIT (16 per kit) | 1 |
| 23 | 804525 | 螺丝包(M5 x 8)(每包2个) | SCREW PACKAGE (M5 x 8) (2 Per) | 15 |
| 23 | 804525001 | 螺丝包(2件)(M5x10) | SCREW PACKAGE (2 Per)(M5 x 10) | 15 |
| 24 | 804827 | 燃油平衡软管 | HOSE Fuel Balance | 1 |
| 24 | 8M6001364 | 软管总成 | HOSE ASSEMBLY | 1 |
| 25 | 889310 | 燃油供给至蒸汽分离器软管 | HOSE Fuel Supply To Vapor Separator | 1 |
| 25 | 8M6001362 | 软管总成 | HOSE ASSEMBLY | 1 |
| 26 | 889311 | 燃油旁通软管 | HOSE Fuel By Pass | 1 |
| 26 | 8M6001363 | 软管总成 | HOSE ASSEMBLY | 1 |
| 27 | 804528 | 燃油喷油器 | INJECTOR Fuel | 6 |
| 27 | 8M0222157 | 燃油喷射器 | FUEL INJECTOR | 6 |
| 28 | 803987 | 密封件 | SEAL | 1 |
| 28 | 804532 | O型圈套件 | O-RING KIT | 1 |
| 28 | 804532 | O型圈套件 | O-RING KIT | 1 |
| 29 | 826292 | 螺母(M10)黄铜/镀镍 | NUT (M10) Brass/Nickel Plated | 4 |
| 30 | 859376 | 导管夹 | CLIP Conduit | 4 |
| 31 | 858778 | 双头螺栓(M10x91) | STUD (M10 x 91) | 4 |
| 31 | 8M0063255 | 双头螺栓M10x92 | STUD M10x92 | 4 |
| 32 | 856880 | 软管卡箍（15.3） | CLAMP Hose (15.3) | 1 |
| 32 | 8M0214964 | 卡箍 | CLAMP | 1 |
| 33 | 888852 | 燃油导向器密封件 | SEAL Fuel Director | 1 |
| - | 877869A03 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A07 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A04 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| - | 877869A07 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 804514 | 燃油轨 (右舷) 不含喷油器 | FUEL RAIL (STARBOARD) W/OUT INJECTORS | 1 |
| 1 | 852395T5 | 燃油导轨 | FUEL RAIL | 1 |
| 2 | 804513 | 燃油轨 (左舷) 不含喷油器 | FUEL RAIL (PORT) W/OUT INJECTORS | 1 |
| 2 | 852394T5 | 燃油导轨 | FUEL RAIL | 1 |
| 3 | 804521 | 施拉德阀套件(气/油) | SCHRADER VALVE KIT (AIR AND FUEL) | 2 |
| 4 | 804516 | 进气接头 | FITTING (AIR INLET) | 1 |
| 5 | 804515 | 燃油入口接头 | FITTING (FUEL INLET) | 1 |
| 6 | 804524 | 接头固定夹 | CLAMP (FITTING RETAINER) | 4 |
| 7 | 804525 | 螺丝包(M5 x 8)(每包2个) | SCREW PACKAGE (M5 x 8) (2 Per) | 10 |
| 7 | 804525001 | 螺丝包(2件)(M5x10) | SCREW PACKAGE (2 Per)(M5 x 10) | 10 |
| 8 | 804526 | 螺丝包(M5x16)(2件) | SCREW PACKAGE (M5 x 16) (2 Per) | 4 |
| 9 | 804535 | 追踪阀盖 | COVER (TRACKER VALVE) | 1 |
| 9 | 804535001 | 盖板 | COVER | 1 |
| 10 | 804534 | 追踪阀弹簧 | SPRING (TRACKER VALVE) | 1 |
| 11 | 804533 | 追踪阀膜片总成 | DIAPHRAGM ASSEMBLY (TRACKER VALVE) | 1 |
| 12 | 804536 | O型圈(追踪阀盖) | O-RING (TRACKER COVER) | 1 |
| 13 | 804520 | 气油接头(右舷) | FITTING (AIR/FUEL) STARBOARD | 2 |
| 14 | 804522 | 喷油器卡箍 | CLAMP (INJECTOR) | 6 |
| 15 | 804528 | 喷油器 | INJECTOR (FUEL) | 6 |
| 15 | 8M0222157 | 燃油喷射器 | FUEL INJECTOR | 6 |
| 16 | 804530 | O型圈套件(大号6件装) | O-RING KIT Contains 6 pcs (LARGE) 6 PER KIT | 1 |
| 17 | 804529 | O型圈套件(小号6件装) | O-RING KIT Contains 6 pcs (SMALL) 6 PER KIT | 1 |
| 18 | 804518 | 空气旁通接头 | FITTING (AIR BYPASS) | 2 |
| 19 | 804517 | 燃油旁通接头 | FITTING (FUEL BYPASS) | 1 |
| 20 | 804531 | O型圈(2件套) | O-RING (2 PER KIT) | 1 |
| 21 | 804532 | O-RING KIT (16 PER KIT) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 857113T3 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 859399T18 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 2 | 379721 | 销 | PIN | 1 |
| 3 | 821526 | 填充块 | FILLER BLOCK | 1 |
| 3 | 821526001 | 填充块 | FILLER BLOCK | 1 |
| 4 | 67892A1 | 磁吸式注油/放油塞套件 | FITTING KIT Magnetic, Plug Fill/Drain | 1 |
| 4 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 5 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 5 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 6 | 826134 | 阳极块 | ANODE | 2 |
| 6 | 826134Q | 阳极块 | ANODE | 2 |
| 7 | 4000333 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 1 |
| 8 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 8 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 9 | 42647A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 10 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 11 | 79953A2 | 螺丝套件(.375-16 x .250) | SCREW KIT (.375-16 x .250) | 1 |
| 11 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 12 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 12 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 13 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 13 | 85822A6 | 连接器 | CONNECTOR | 1 |
| 14 | 56762 | 扎带(4.00英寸) | TIE STRAP (4.00 Inches) | 1 |
| 15 | NSS | NOT SOLD SEPARATE Pinion Gear (Part of 43-828695A1) | 1 | |
| 16 | 92721 | 垫圈(.965×0.630) | WASHER (.965 x .630) | 1 |
| 17 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 18 | 815921A4 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 19 | 8164641 | 油封 | SEAL Oil | 1 |
| 19 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 20 | 36318 | O型圈(0.799英寸) | O-RING (.799) | 2 |
| 20 | 8M0214927 | O型圈@5 | O RING @5 | 2 |
| 21 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 22 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| 23 | 824145 | 换挡轴(下部) | SHIFT SHAFT (LOWER) | 1 |
| 24 | 816472 | 传动轴(下) | DRIVESHAFT (LOWER) | 1 |
| 24 | 8M0140442 | 驱动轴 | DRIVESHAFT | 1 |
| 25 | 43037 | 键 | KEY | 1 |
| 25 | 8M0204723 | 键 | KEY | 1 |
| 26 | 42637A1 | 垫片组 | SHIM SET | AR |
| 26 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 27 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 27 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 28 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 29 | 824519 | 固定座 | RETAINER | 1 |
| 29 | 8245191 | 固定座 | RETAINER | 1 |
| 30 | 821759A4 | 托架总成 | CARRIER ASSEMBLY | 1 |
| 30 | 8M0214948 | 托架总成 | CARRIER ASSY | 1 |
| 31 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 31 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 32 | 66302 | 油封 | SEAL Oil | 1 |
| 32 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 33 | 66302 | 油封 | SEAL Oil | 1 |
| 33 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 34 | 817275A1 | 水泵壳体套件 | HOUSING KIT Water Pump | 1 |
| 35 | 816575A2 | 密封套件 | SEAL KIT | 1 |
| 36 | 430331 | 衬垫 | GASKET | 1 |
| 37 | 817277 | 衬垫 | GASKET | 1 |
| 37 | 8172771 | 水泵上垫片 | GASKET Water Pump, Upper | 1 |
| 38 | 8172761 | 面板 | FACEPLATE | 1 |
| 38 | 8M0204709 | 面板 | FACEPLATE | 1 |
| 39 | 43026T2 | 叶轮 | IMPELLER | 1 |
| 40 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 4 |
| 41 | 832942A1 | 联轴器总成 | COUPLING ASSEMBLY | 1 |
| 42 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 42 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 43 | 35027 | O型圈(1.046英寸) | O-RING (1.046) | 1 |
| 43 | 8M0204654 | O型圈 | O-RING | 1 |
| 44 | 827755A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| 44 | 826353A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| 45 | 823902 | 联轴器 | COUPLING | 1 |
| 46 | NSS | 不单独销售-反向旋转标识 | NOT SOLD SEPARATE Decal-Counter Rotation | 1 |
| - | 816575A4 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| - | 817275A5 | 水泵修理包 | REBUILD KIT Water Pump | 1 |
| - | 43026T11 | 水泵叶轮维修套件 | REPAIR KIT Water Pump Impeller | 1 |
| - | 8M0100526 | 水泵叶轮维修套件 | REPAIR KIT Water Impeller | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 857113T3 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 859399T18 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 2 | 379721 | 销 | PIN | 1 |
| 3 | 821526 | 填充块 | FILLER BLOCK | 1 |
| 3 | 821526001 | 填充块 | FILLER BLOCK | 1 |
| 4 | 67892A1 | 磁吸式注油/放油塞套件 | FITTING KIT Magnetic, Plug Fill/Drain | 1 |
| 4 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 5 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 5 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 6 | 826134 | 阳极块 | ANODE | 2 |
| 6 | 826134Q | 阳极块 | ANODE | 2 |
| 7 | 4000333 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 1 |
| 8 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 8 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 9 | 42647A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 10 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 11 | 79953A2 | 螺丝套件(.375-16 x .250) | SCREW KIT (.375-16 x .250) | 1 |
| 11 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 12 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 12 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 13 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 13 | 85822A6 | 连接器 | CONNECTOR | 1 |
| 14 | 56762 | 扎带(4.00英寸) | TIE STRAP (4.00 Inches) | 1 |
| 15 | NSS | NOT SOLD SEPARATE Pinion Gear (Part of 43-828168A2) | 1 | |
| 16 | 92721 | 垫圈(.965×0.630) | WASHER (.965 x .630) | 1 |
| 17 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 18 | 815921A4 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 19 | 8164641 | 油封 | SEAL Oil | 1 |
| 19 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 20 | 36318 | O型圈(0.799英寸) | O-RING (.799) | 2 |
| 20 | 8M0214927 | O型圈@5 | O RING @5 | 2 |
| 21 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 22 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| 23 | 824145 | 换挡轴(下部) | SHIFT SHAFT (LOWER) | 1 |
| 24 | 816472 | 传动轴(下) | DRIVESHAFT (LOWER) | 1 |
| 24 | 8M0140442 | 驱动轴 | DRIVESHAFT | 1 |
| 25 | 43037 | 键 | KEY | 1 |
| 25 | 8M0204723 | 键 | KEY | 1 |
| 26 | 42637A1 | 垫片组 | SHIM SET | AR |
| 26 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 27 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 27 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 28 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 29 | 824519 | 固定座 | RETAINER | 1 |
| 29 | 8245191 | 固定座 | RETAINER | 1 |
| 30 | 821759A4 | 托架总成 | CARRIER ASSEMBLY | 1 |
| 30 | 8M0214948 | 托架总成 | CARRIER ASSY | 1 |
| 31 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 31 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 32 | 66302 | 油封 | SEAL Oil | 1 |
| 32 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 33 | 66302 | 油封 | SEAL Oil | 1 |
| 33 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 34 | 817275A1 | 水泵壳体套件 | HOUSING KIT Water Pump | 1 |
| 35 | 816575A2 | 密封套件 | SEAL KIT | 1 |
| 36 | 430331 | 衬垫 | GASKET | 1 |
| 37 | 817277 | 衬垫 | GASKET | 1 |
| 37 | 8172771 | 水泵上垫片 | GASKET Water Pump, Upper | 1 |
| 38 | 8172761 | 面板 | FACEPLATE | 1 |
| 38 | 8M0204709 | 面板 | FACEPLATE | 1 |
| 39 | 43026T2 | 叶轮 | IMPELLER | 1 |
| 40 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 4 |
| 41 | 832942A1 | 联轴器总成 | COUPLING ASSEMBLY | 1 |
| 42 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 42 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 43 | 35027 | O型圈(1.046英寸) | O-RING (1.046) | 1 |
| 43 | 8M0204654 | O型圈 | O-RING | 1 |
| 44 | 827754A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| 44 | 827755A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| 44 | 826353A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| 45 | 823902 | 联轴器 | COUPLING | 1 |
| - | 816575A4 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| - | 817275A5 | 水泵修理包 | REBUILD KIT Water Pump | 1 |
| - | 43026T11 | 水泵叶轮维修套件 | REPAIR KIT Water Pump Impeller | 1 |
| - | 8M0100526 | 水泵叶轮维修套件 | REPAIR KIT Water Impeller | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 859399T16 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| - | 8M0236248 | GC组件3.0L CXL | GC COMP 3.0L CXL | 1 |
| - | 859399T17 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| 1 | 859399T18 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 2 | 859403 | 堵头 | PLUG | 1 |
| 3 | 823903 | 换挡曲柄 | SHIFT CRANK | 1 |
| 3 | 8M0226861 | 换挡曲柄 | CRANK-SHIFTER | 1 |
| 4 | 19755T7 | 阀芯总成 | SPOOL ASSEMBLY | 1 |
| 4 | 8M0235940 | 阀芯总成 | SPOOL ASSY | 1 |
| 5 | NSS | 不单独销售线轴 | NOT SOLD SEPARATE Spool | 1 |
| 6 | NSS | 不单独销售套筒 | NOT SOLD SEPARATE Sleeve | 1 |
| 7 | 469501 | 开口销 | COTTER PIN | 1 |
| 8 | 44491A1 | 垫片组 | SHIM SET | AR |
| 8 | 8M0063266 | 垫片组 | SHIM SET | AR |
| 9 | 828830A2 | 轴承适配器总成 | ADAPTER ASSEMBLY Bearing | 1 |
| 10 | 814653T | 滚针轴承总成 | BEARING ASSEMBLY Needle Rollers | 1 |
| 11 | 815481 | 止推垫片 | THRUST WASHER | 1 |
| 12 | 815480 | 推力轴承 | BEARING Thrust | 1 |
| 13 | 828696T2 | 倒挡齿轮(12/21齿) | GEAR Reverse (12/21) | 1 |
| 14 | 15844 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 15 | 30893 | 弹簧 | SPRING | 1 |
| 16 | 859340T | 离合器 | CLUTCH | 1 |
| 17 | 30632 | 十字销 | PIN Cross | 1 |
| 17 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 18 | 828356 | 定位销 | PIN Detent | 1 |
| 19 | 824111 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 19 | 8M0140448 | 左螺旋桨轴 | PROP SHAFT LH | 1 |
| 20 | 828695A1 | 前进/小齿轮组(12/21齿) | GEAR SET Forward/Pinion (12/21) | 1 |
| 21 | 1761514 | 垫片(0.206) | SPACER SHIM (.206) | AR |
| 21 | 1761515 | 垫片(0.208) | SPACER SHIM (.208) | AR |
| 21 | 1761516 | 垫片(0.210) | SPACER SHIM (.210) | AR |
| 21 | 1761517 | 垫片(0.212) | SPACER SHIM (.212) | AR |
| 21 | 1761518 | 垫片(0.214) | SPACER SHIM (.214) | AR |
| 21 | 1761519 | 垫片(0.216) | SPACER SHIM (.216) | AR |
| 21 | 1761520 | 垫片(0.218) | SPACER SHIM (.218) | AR |
| 21 | 1761521 | 垫片(0.220) | SPACER SHIM (.220) | AR |
| 21 | 1761522 | 垫片(0.222) | SPACER SHIM (.222) | AR |
| 21 | 1761523 | 垫片(0.224) | SPACER SHIM (.224) | AR |
| 21 | 1761524 | 垫片(0.226) | SPACER SHIM (.226) | AR |
| 21 | 1761525 | 垫片(0.228) | SPACER SHIM (.228) | AR |
| 21 | 1761526 | 垫片(0.230) | SPACER SHIM (.230) | AR |
| 22 | 815480 | 推力轴承 | BEARING Thrust | 1 |
| 23 | 815481 | 止推垫片 | THRUST WASHER | 1 |
| 24 | 828831A3 | 轴承适配器总成 | ADAPTER ASSEMBLY Bearing | 1 |
| 25 | 814653T | 滚针轴承总成 | BEARING ASSEMBLY Needle Rollers | 1 |
| 26 | 18448 | 止推垫片 | THRUST WASHER | 2 |
| 27 | 15842 | 推力轴承 | BEARING Thrust | 2 |
| 28 | 8182911 | 推力座圈 | RACE Thrust | 2 |
| 29 | 814605 | 定位器 | KEEPER | 2 |
| 30 | 31534 | O型圈 | O-RING | 1 |
| 30 | 8M0214920 | O型圈 | O RING | 1 |
| 30 | 896524 | O型圈(3.850×.210) | O-RING (3.850 x .210) | 1 |
| 30 | 8M0142840 | O型圈(3.85×0.210) | O-RING (3.85 x 0.210) | 1 |
| 31 | 818290T8 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 32 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 33 | 14077 | SEAL Oil (Inside) | 1 | |
| 34 | 76868 | SEAL (Outside) | 1 | |
| 34 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 1 |
| 35 | 18323 | 锁紧垫圈 | TAB WASHER | 1 |
| 36 | 79448 | 固定座 | RETAINER | 1 |
| 36 | 8M2011027 | 固定座 | RETAINER | 1 |
| 37 | 76214Q5 | 阳极套件 | ANODE KIT | 1 |
| 38 | 806327 | 螺钉(.437-14 x 1.750) | SCREW (.437-14 x 1.750) | 1 |
| 38 | 8M0204686 | 螺钉 | SCREW | 1 |
| 39 | NSS | 不单独出售 贴纸-反转标志 | NOT SOLD SEPARATE Decal- Counter Rotation | 1 |
| - | NS | 未显示-参见螺旋桨附件指南选择合适硬件(推力垫圈/螺母) | NOT SHOWN See Accessory Guide-Propellers-For Appropriate Hardware. (Thrust Washers/Nuts) | 1 |
| - | 816575A4 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 859399T13 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| - | 8M0236231 | GC组件3.0L LG | GC COMP 3.0L LG | 1 |
| - | 859399T14 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| - | 8M0236242 | GC组件3.0L XL | GC COMP 3.0L XL | 1 |
| - | 859399T15 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| 1 | 859399T18 | 基础齿轮箱总成 | GEAR HOUSING ASSEMBLY Basic | 1 |
| 2 | 859403 | 堵头 | PLUG | 1 |
| 3 | 823903 | 换挡曲柄 | SHIFT CRANK | 1 |
| 3 | 8M0226861 | 换挡曲柄 | CRANK-SHIFTER | 1 |
| 4 | 19755T7 | 阀芯总成 | SPOOL ASSEMBLY | 1 |
| 4 | 8M0235940 | 阀芯总成 | SPOOL ASSY | 1 |
| 5 | NSS | 不单独销售换挡轴 | NOT SOLD SEPARATE Shift Spool | 1 |
| 6 | 469501 | 开口销 | COTTER PIN | 1 |
| 7 | NSS | 不单独销售套筒 | NOT SOLD SEPARATE Sleeve | 1 |
| 8 | 859321A3 | 前进/小齿轮组(12/21齿) | GEAR SET Forward/Pinion (12/21) | 1 |
| 9 | 44491A1 | 垫片组 | SHIM SET | AR |
| 9 | 8M0063266 | 垫片组 | SHIM SET | AR |
| 10 | 30894A1 | 圆锥轴承组 | BEARING SET Cup And Cone | 1 |
| 11 | NSS | 杯状件(不单独销售) | NOT SOLD SEPARATE Cup | 1 |
| 12 | 856823 | 挡圈 | RING Retaining | 1 |
| 13 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 14 | 30893 | 弹簧 | SPRING | 1 |
| 15 | 859340T | 离合器 | CLUTCH | 1 |
| 16 | 828356 | 定位销 | PIN Detent | 1 |
| 17 | 30632 | 十字销 | PIN Cross | 1 |
| 17 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 18 | 824110 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 18 | 8M0140440 | 右螺旋桨轴 | PROPSHAFT RH | 1 |
| 19 | 859322A1 | 倒挡齿轮(12/21齿) | GEAR Reverse (12/21) | 1 |
| 20 | 824108 | 隔套 | SPACER | 1 |
| 21 | 681001 | 止推环 | RING Thrust | 1 |
| 22 | 88957T | 滚珠轴承 | BEARING Ball | 1 |
| 23 | 31534 | O型圈 | O-RING | 1 |
| 23 | 8M0214920 | O型圈 | O RING | 1 |
| 23 | 896524 | O型圈(3.850×.210) | O-RING (3.850 x .210) | 1 |
| 23 | 8M0142840 | O型圈(3.85×0.210) | O-RING (3.85 x 0.210) | 1 |
| 24 | 818763T11 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 25 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 26 | 14077 | SEAL Oil (Inside) | 1 | |
| 27 | 76868 | SEAL (Outside) | 1 | |
| 27 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 1 |
| 28 | 18323 | 锁紧垫圈 | TAB WASHER | 1 |
| 29 | 79448 | 固定座 | RETAINER | 1 |
| 29 | 8M2011027 | 固定座 | RETAINER | 1 |
| 30 | 76214Q5 | 阳极套件 | ANODE KIT | 1 |
| 31 | 806327 | 螺钉(.437-14 x 1.750) | SCREW (.437-14 x 1.750) | 1 |
| 31 | 8M0204686 | 螺钉 | SCREW | 1 |
| - | NS | 未显示-参见螺旋桨附件指南选择合适硬件(推力垫圈/螺母) | NOT SHOWN See Accessory Guide-Propellers-For Appropriate Hardware. (Thrust Washers/Nuts) | 1 |
| - | 816575A4 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 19674A1 | 拉绳开关总成 | SWITCH ASSEMBLY Lanyard | 1 |
| 1 | 19674A07 | 开关/拉绳套件 | SWITCH/LANYARD KIT | 1 |
| 2 | 18303 | 螺钉 (.190-16 x 1.750) 不锈钢 | SCREW (.190-16 x 1.750) Stainless Steel | 2 |
| 3 | 813679 | 适配器 | ADAPTER | 1 |
| 4 | 15920A54 | 拉绳总成 | LANYARD ASSEMBLY | 1 |
| 4 | 15920Q54 | 拉绳总成 | LANYARD ASSEMBLY | 1 |
| 5 | 32866 | 螺钉 (#10-32 x 2.00) 不锈钢 | SCREW (#10-32 x 2.00) Stainless Steel | 2 |
| 6 | 18321 | 安装夹 | CLAMP Mounting | 1 |
| 7 | 24676 | 垫圈 (.200 x .440 x .032) | WASHER (.200 x .440 x .032) | 2 |
| 8 | 68219 | 螺母 (#10-32) 不锈钢 | NUT (#10-32) Stainless Steel | 4 |
| 9 | 79146 | 固定座 | RETAINER | 3 |
| 10 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 9 |
| 10 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 9 |
| 11 | 812497A2 | 二极管总成 | DIODE ASSEMBLY | 1 |
| 11 | 898289A72 | 双拉绳二极管套件 | DIODE KIT-LANYARD Dual | 1 |
| 12 | 11149A2 | 线缆总成 (6.00英寸) | CABLE ASSEMBLY (6.00 Inches) | 1 |
| 13 | 835360A2 | 警报仪表套件 | WARNING GAUGE KIT | 1 |
| 13 | 859699A1 | 警报仪表套件 | GAUGE KIT-WARNING | 1 |
| 14 | 850020 | 卡箍 | CLAMP | 1 |
| 15 | 825361 | 星形锁紧垫圈(#8) | LOCKWASHER Star (#8) | 1 |
| 16 | 26419 | 黄铜螺母 (#8-32) | NUT (#8-32) Brass | 2 |
| 17 | 15163 | 灯 | LAMP | 4 |
| 18 | 79888 | 灯泡插座 | SOCKET Light Bulb | 4 |
| 19 | 835359A1 | 电缆总成(20.00英尺) | CABLE ASSEMBLY (20.00 Feet) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 830889A1 | 油箱总成 | TANK ASSEMBLY Oil | 1 |
| 2 | NSS | 不单独销售标签-储液罐 | NOT SOLD SEPARATE Decal-Reservoir | 1 |
| 3 | 8260841 | 隔套 | SPACER | 1 |
| 4 | 58376 | 螺钉(.164-18 x .375) | SCREW (.164-18 x .375) | 1 |
| 5 | 72761 | 不锈钢垫圈(.203 x .562 x .060) | WASHER (.203 x .562 x .060) Stainless Steel | 1 |
| 6 | 814449A3 | 盖总成 | CAP ASSEMBLY | 1 |
| 7 | 42999 | 衬垫 | GASKET | 1 |
| 7 | 42999T | 衬垫 | GASKET | 1 |
| 8 | 12886A7 | 开关总成 | SWITCH ASSEMBLY | 1 |
| 9 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 1 |
| 9 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 1 |
| 10 | 49436 | 垫圈 | WASHER | 3 |
| 11 | 855362 | 护孔环 | GROMMET | 3 |
| 11 | 855362001 | 护孔环 | GROMMET | 3 |
| 12 | 855364 | 衬套 | BUSHING | 3 |
| 13 | 830756109 | 软管(57英寸整卷)(8英寸段) | HOSE (57.00 Inches Bulk) (8 IN.) | 1 |
| 13 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 14 | 424254 | 接头 | FITTING | 1 |
| 14 | 8M0207780 | 接头 | FITTING | 1 |
| 15 | 12335A1 | 支架套件 | BRACKET KIT | 1 |
| 16 | 12323A1 | 绳索/挂钩套件 | CORD/HOOK KIT | 1 |
| 17 | 87421 | 油箱 | TANK | 1 |
| 18 | 43298A2 | 盖总成 | CAP ASSEMBLY | 1 |
| 19 | NSS | 不单独销售嵌件 | NOT SOLD SEPARATE Insert | 1 |
| 20 | 11332 | O型圈(2.225 x .210) | O-RING (2.225 x .210) | 1 |
| 21 | 816190A3 | 外壳总成适配器 | HOUSING ASSEMBLY Adapter | 1 |
| 21 | 816190A4 | 机油收集器总成(无传感器) | OIL PICK UP ASSEMBLY Without Sender | 1 |
| 22 | 11332 | O型圈(2.225 x .210) | O-RING (2.225 x .210) | 1 |
| 23 | 99802 | 管 | TUBE | 1 |
| 24 | 99439 | 软管(114.00英寸) | HOSE (114.00 Inches) | 1 |
| 25 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 7 |
| 25 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 7 |
| 26 | NSS | 警示标贴-远程油箱(不单独销售) | NOT SOLD SEPARATE Decal-Caution Remote Tank | 1 |
| 27 | 81893445 | 螺钉(M8×45) | SCREW (M8 X 45) | 2 |
| 28 | 8558412 | 燃油冷却器 | COOLER Fuel | 1 |
| 28 | 855841T2 | 燃油冷却器 | COOLER Fuel | 1 |
| 29 | 8502341 | 衬套 | BUSHING | 2 |
| 30 | 833155 | 护孔环 | GROMMET | 2 |
| 31 | 85466755 | 软管(25英寸) | HOSE (25 IN.) | 1 |
| 32 | 856819 | 软管 | HOSE | 1 |
| 33 | 856880 | 软管卡箍（15.3） | CLAMP Hose (15.3) | 4 |
| 33 | 8M0214964 | 卡箍 | CLAMP | 4 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0231193 | 动力升降总成 | POWER TRIM ASSEMBLY | 1 |
| 1 | 8M0225363 | 电机套件 | MOTOR KIT | 1 |
| 2 | 8M0225369 | 阀套件 | VALVE KIT | 1 |
| 3 | 8M0225371 | 手动释放套件 | MANUAL RELEASE KIT | 1 |
| 4 | 8M0245633 | 倾斜油缸套件 | TILT CYLINDER KIT | 1 |
| 5 | 8M0225370 | 枢轴销套件 | PIVOT PIN KIT | 1 |
| 6 | 8M0244575 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 7 | 8M0244425 | 销杆眼套件 | PIN ROD EYE KIT | 1 |
| 8 | 8M0232231 | 螺钉螺母套件 | SCREW NUT KIT | 1 |
| 9 | 8M0225373 | 记忆活塞套件 | MEMORY PISTON KIT | 1 |
| 10 | 8M0225368 | 储液罐套件 | RESERVOIR KIT | 1 |
| 11 | 8M0174135 | 储液罐塞总成 | PLUG RESERVOIR ASSEMBLY | 1 |
| 12 | 8M0237525 | 泵套件 | PUMP KIT | 1 |
| 13 | 8M0225367 | 升降杆套件 | TRIM ROD KIT | 1 |
| 14 | 8M0242846 | 升降杆套件 | TRIM ROD KIT | 1 |
| 15 | 8M0225372 | 重建套件 | REBUILD KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 855998A3 | 动力升降倾斜装置总成 | POWER TRIM Complete | 1 |
| - | 855998A11 | 动力调整套件 | POWER TRIM KIT | 1 |
| - | 855998A05 | 完整动力升降总成 | POWER TRIM ASSEMBLY Complete | 1 |
| - | 855998A11 | 动力调整套件 | POWER TRIM KIT | 1 |
| 1 | 878265A4 | 配平电机 | TRIM MOTOR | 1 |
| 1 | 8M0031551 | 配平电机 | TRIM MOTOR | 1 |
| 2 | NSS | 电枢(不单独销售) | NOT SOLD SEPARATE Armature | 1 |
| 3 | NSS | 端架(不单独销售) | NOT SOLD SEPARATE End Frame | 1 |
| 4 | 82494830 | 螺钉 (M6 x 30) | SCREW (M6 x 30) | 2 |
| 5 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 2 |
| 6 | 8782451 | 驱动轴 | DRIVESHAFT | 1 |
| 7 | 878410A1 | 压力检查套件 | PO CHECK KIT | 1 |
| 8 | 813442A2 | 手动释放总成 (含参考号#26) | MANUAL RELEASE ASSEMBLY (Includes Reference #26) | 1 |
| 8 | 893929A01 | 安全阀套件 | VALVE KIT Relief | 1 |
| 9 | 878241A02 | 轴套件 | SHAFT KIT | 1 |
| 9 | 8M0142997 | 倾斜轴套件 | TILT SHAFT KIT | 1 |
| 10 | 878267 | 销 | PIN | 1 |
| 11 | 878235A1 | 倾斜油缸总成 | TILT CYLINDER ASSEMBLY | 1 |
| 11 | 878235A03 | 倾斜油缸套件 | CYLINDER KIT Tilt | 1 |
| 11 | 878235A02 | 倾斜油缸总成 | TILT CYLINDER ASSEMBLY | 1 |
| 11 | 878235A03 | 倾斜油缸套件 | CYLINDER KIT Tilt | 1 |
| 12 | 878239A1 | 导向套件 (含参考号#26) | GUIDE KIT (Includes Reference #26) | 1 |
| 12 | 878239A02 | 倾斜缸端盖套件 | END CAP KIT Tilt Cylinder | 1 |
| 13 | 878409A1 | O型圈套件 (含参考号#26) | O-RING KIT (Includes Reference #26) | 1 |
| 13 | 8M0142999 | 倾斜油缸O型圈套件 | O RING KIT TILT CYLINDER | 1 |
| 14 | 878412A1 | 减震杆套件 (含参考号#26) | SHOCK ROD KIT (Includes Reference #26) | 1 |
| 14 | 8M0168219 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 15 | 878242A1 | 记忆活塞总成 | PISTON ASSEMBLY Memory | 1 |
| 15 | 8M0143000 | 记忆活塞套件 | MEMORY PISTON KIT | 1 |
| 16 | 878406A1 | 止回阀修理包 (含参考号#26) | REPAIR KIT Check Valve (Includes Reference #26) | 1 |
| 16 | 878406A02 | 止回阀修理包 | REPAIR KIT Check Valve | 1 |
| 17 | 878414A1 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 17 | 878414T01 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 18 | 878413A1 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 19 | 878243A1 | 导向器总成 | GUIDE ASSEMBLY | 2 |
| 19 | 8M0021648 | 端盖总成 | END CAP ASSEMBLY | 2 |
| 20 | 878264A1 | 储液罐套件 | RESERVOIR KIT | 1 |
| 21 | 811613 | 塞子总成 | PLUG ASSEMBLY | 1 |
| 22 | 4000327 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 4 |
| 23 | 43450 | 垫圈 | WASHER | 4 |
| 23 | 4002315 | 垫圈(6.60x12.5x1.5mm-不锈钢) | WASHER (6.60 X 12.5 X 1.5 mm -SS) | 4 |
| 24 | 892251A01 | 泵套件 | PUMP KIT | 1 |
| 25 | 878408A1 | 动力升降倾斜装置维修包 | REPAIR KIT Power Trim | 1 |
| 26 | 821539 | 三叶销 | PIN Trilobe | 1 |
| 27 | 858771 | 螺钉 (M10 x 30) | SCREW (M10 x 30) | 6 |
| 28 | 4002319 | 垫圈 | WASHER | 6 |
| 29 | 818298Q1 | 阳极套件 | ANODE KIT | 1 |
| 30 | 4000330 | 螺钉(M6x25) | SCREW (M6 x 25) | 2 |
| 30 | 8M0204707 | 不锈钢六角大帽螺钉(M6x25) | SCREW M6 x 25 HX HD CAP SS | 2 |
| 31 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 31 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 32 | 996251 | 轴 | SHAFT | 1 |
| 32 | 99625002 | 轴 | SHAFT | 1 |
| 32 | 99625002 | 轴 | SHAFT | 11 |
| 33 | 69205 | C形垫圈 | C WASHER | 1 |
| 33 | 8M0084613 | C形垫圈 | C-WASHER | 1 |
| 34 | 26550 | 卡箍 | CLAMP | 2 |
| 35 | 878609 | 螺钉 (#10-16 x .600) | SCREW (#10-16 x .600) | 1 |
| 36 | 828547353 | 导管(内径0.350x3英尺散装)(裁切至12英寸) | CONDUIT (.350 Inside Diameter x 3.00 Feet Bulk) (Cut to 12 Inches) | 1 |
| 37 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0168222 | 动力升降总成 | POWER TRIM ASSEMBLY | 1 |
| 1 | 8M0142591 | 电机套件 | MOTOR KIT | 1 |
| 2 | 82494830 | 螺钉 (M6 x 30) | SCREW (M6 x 30) | 2 |
| 3 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 2 |
| 4 | 8M0090403 | 驱动联轴器 | COUPLING Drive | 1 |
| 5 | 8M0142996 | 压力检查套件 | PO CHECK KIT | 1 |
| 6 | 8M0060141 | 手动释放套件 | MANUAL RELEASE KIT | 1 |
| 7 | 8M0142997 | 倾斜轴套件 | TILT SHAFT KIT | 1 |
| 8 | 878267 | 销 | PIN | 1 |
| 9 | 8M0142998 | 倾斜油缸总成 | TILT CYLINDER ASSEMBLY | 1 |
| 9 | 8M0168220 | 倾斜油缸总成 | TILT CYLINDER ASSEMBLY | 1 |
| 10 | 8M0142999 | 倾斜油缸O型圈套件 | O RING KIT TILT CYLINDER | 1 |
| 11 | 8M0143000 | 记忆活塞套件 | MEMORY PISTON KIT | 1 |
| 12 | 8M0142592 | 升降杆套件 左舷 | TRIM ROD KIT Port | 1 |
| 13 | 8M0143001 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 14 | 8M0143003 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 15 | 878264A1 | 储液罐套件 | RESERVOIR KIT | 1 |
| 16 | 811613 | 塞子总成 | PLUG ASSEMBLY | 1 |
| 17 | 4000327 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 4 |
| 18 | 4002315 | 垫圈(6.60x12.5x1.5mm-不锈钢) | WASHER (6.60 X 12.5 X 1.5 mm -SS) | 4 |
| 19 | 8M0143004 | 泵套件 | PUMP KIT | 1 |
| 20 | 8M0148385 | 动力升降倾斜装置维修包 | REPAIR KIT Power Trim | 1 |
| 21 | 858771 | 螺钉 (M10 x 30) | SCREW (M10 x 30) | 6 |
| 22 | 4002319 | 垫圈 | WASHER | 6 |
| 23 | 8M0094889 | 销 | PIN | 1 |
| 23 | 8M0161312 | 连杆销眼总成 | PIN ROD EYE ASSEMBLY | 1 |
| 24 | 8M0143005 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 24 | 8M0168219 | 减震杆套件 | SHOCK ROD KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 889453003 | 零件手册200/225 DFI (3.0L)(DTS) | PARTS MANUAL 200/225 DFI (3.0L)(DTS) | 1 |
| - | 859769R2 | 维修手册 | SERVICE MANUAL | 1 |
| - | 859769R03 | 维修手册 | SERVICE MANUAL | 1 |
| - | 859769R03 | 维修手册 | SERVICE MANUAL | 1 |
| - | 10233030 | 用户手册 | OWNERS MANUAL | 1 |
| - | 10233040 | 用户手册 | OWNERS MANUAL | 1 |
| - | 10233050 | 用户手册 | OWNERS MANUAL | 1 |
| - | 10233060 | 用户手册 | OWNERS MANUAL | 1 |
| - | 10234060 | 安装手册 | INSTALLATION MANUAL | 1 |
| - | 88343311 | 加州超低排放贴花 | DECAL California-Very Low Emission | 1 |
| - | 804658A03 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| - | 804658A04 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| - | 804658A05 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| - | 804658A06 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 853329T | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 1 | 892339T01 | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 1 | 892339T | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 1 | 892339T01 | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 2 | 803005 | 贯穿螺栓 | THRU BOLT | 2 |
| 3 | 880805A1 | 齿轮套件 | GEAR KIT | 1 |
| 4 | 809463A1 | 电磁阀组件 | SOLENOID KIT | 1 |
| 5 | 8M0065258 | 电刷组 | BRUSH SET | 1 |
| 6 | 69035 | 螺丝与锁紧垫圈(.250-20 x .625)不锈钢 | SCREW AND LOCKWASHER (.250-20 x .625) Stainless Steel | 1 |
| 7 | 93388A1 | 电缆总成(6.00英寸)黑色 | CABLE ASSEMBLY (6.00 Inches) Black | 1 |
| 8 | 8272822 | 高压警告标贴 | DECAL Warning High Voltage | 1 |
| 8 | NSS | 高压警告贴纸 (不单独销售) | NOT SOLD SEPARATE Decal-Warning-High Voltage | 1 |
| 9 | 400255 | 锁紧垫圈(M5) | LOCKWASHER (M5) | 1 |
| 10 | 400211 | 不锈钢螺母(M5) | NUT (M5) Stainless Steel | 1 |
| 11 | 26993 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 1 |
| 11 | 8M0204647 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 1 |
| 12 | 400213 | 不锈钢螺母 (M8) | NUT (M8) Stainless Steel | 1 |
| 13 | 56703 | 轴环 | COLLAR | 2 |
| 13 | 8M0034918 | 轴环 | COLLAR | 2 |
| 14 | 879845 | 停机开关 | STOP | 1 |
| 14 | 8M0043276 | 停机开关 | STOP | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8710T20 | 黑色旋转支架总成 | SWIVEL BRACKET ASSEMBLY Black | 1 |
| 1 | 8M0102865 | 黑色旋转支架总成 | SWIVEL BRACKET ASSEMBLY Black | 1 |
| 2 | 33504 | O型圈 | O-RING | 1 |
| 2 | 8M0214926 | O型圈 @10 | O RING @10 | 1 |
| 3 | 818764 | 衬套 | BUSHING | 2 |
| 4 | 816039 | 隔套 | SPACER | 1 |
| 5 | 87735 | SEAL Oil (Lower) | 1 | |
| 6 | 74036 | 润滑脂接头 | FITTING Grease | 2 |
| 6 | 8M0169589 | 润滑脂接头 | FITTING Grease | 2 |
| 7 | 821207 | 衬套 | BUSHING | 2 |
| 8 | 816432 | 止推垫片 | THRUST WASHER | 1 |
| 9 | 814084F1 | 下轭架 | YOKE Bottom | 1 |
| 9 | 8M0219200 | 黑色下轭架 | YOKE-BOTTOM-BLACK | 1 |
| 9 | 826364F1 | 下轭架 | YOKE Bottom | 1 |
| 9 | 826364T | 下轭架 | YOKE Bottom | 1 |
| 10 | 67684 | 挡圈 | RING Retaining | 1 |
| 11 | 996301 | 冲击板 | STRIKER PLATE | 2 |
| 11 | 8M0045383 | 冲击板 | STRIKER PLATE | 2 |
| 12 | 58643 | 锁紧垫圈 (.375) | LOCKWASHER (.375) | 2 |
| 13 | 46335 | 螺母 (.375-24) | NUT (.375-24) | 2 |
| 14 | 64014 | 螺钉(.250-28x.500) | SCREW (.250-28 x .500) | 2 |
| 15 | NSS | 不单独销售-序列号覆膜标贴 | NOT SOLD SEPARATE Decal-Serial Overlaminate | 1 |
| 16 | 859187A1 | 调整传感器总成 | SENDER ASSEMBLY Trim | 1 |
| 17 | 852368 | 螺钉（#10-24 X 0.750） | SCREW (#10-24 x .750) | 2 |
| 18 | 26996 | 锁紧垫圈(#10)(不锈钢) | LOCKWASHER (#10) Stainless Steel | 2 |
| 19 | 89302 | 垫圈(0.203×0.406×0.040) | WASHER (.203 x .406 x .040) | 2 |
| 20 | 67706A55 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 20 | 826432A2 | 转向臂旋转销总成-不锈钢 | SWIVEL PIN ASSEMBLY Steering Arm - Stainless Steel | 1 |
| 20 | 826432A2 | 转向臂旋转销总成-不锈钢 | SWIVEL PIN ASSEMBLY Steering Arm - Stainless Steel | 1 |
| 20 | 8M0132731 | 旋转销总成 | SWIVEL PIN ASSY | 1 |
| 21 | 816386 | 螺钉(M12×190) | SCREW (M12 x 190) | 2 |
| 21 | 8M0141069 | 螺钉 | SCREW | 2 |
| 22 | 824998 | 缓冲垫 | BUMPER | 1 |
| 22 | 824998001 | 缓冲垫 | BUMPER | 1 |
| 22 | 824998001 | 缓冲垫 | BUMPER | 1 |
| 23 | 8163851 | 上部支架 | MOUNT Upper | 2 |
| 24 | 8154371 | 垫圈 | WASHER | 2 |
| 25 | 815436 | 垫圈 | WASHER | 2 |
| 26 | 896963 | 螺母(M12) | NUT (M12) | 2 |
| 27 | 813769 | 卡箍 | CLAMP | 1 |
| 27 | 8M0036783 | 卡箍 | CLAMP | 1 |
| 28 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 3 |
| 28 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 3 |
| 29 | 92876A10 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 29 | 92876A12 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 30 | 849838 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 1 |
| 31 | 826709113 | 不锈钢螺母 (.375-24) | NUT (.375-24) Stainless Steel | 2 |
| 31 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 2 |
| 32 | 37828 | 不锈钢垫圈 (.390 x .625 x .062) | WASHER (.390 x .625 x .062) Stainless Steel | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8252681 | 节气门控制杆 | LEVER Throttle Control | 1 |
| 1 | 8M0040987 | 杠杆 | LEVER | 1 |
| 2 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) | 1 |
| 2 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 1 |
| 3 | 36042 | 垫圈 | WASHER | 1 |
| 4 | 821113 | 衬套 | BUSHING | 1 |
| 5 | 40124 | 螺钉 (M6 x 55) | SCREW (M6 x 55) | 2 |
| 6 | 400212 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 2 |
| 7 | 42942 | 盖帽 | CAP | 2 |
| 8 | 42927 | 嵌件 | INSERT | 1 |
| 9 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 9 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 10 | 856896 | 轴承 | BEARING | 1 |
| 11 | 8503825 | 凸轮 | CAM | 1 |
| 11 | 850382A3 | 凸轮 | CAM | 1 |
| 12 | 856895 | 衬套 | BUSHING | 1 |
| 13 | 81893440 | 螺钉 (M8 x 40) | SCREW (M8 x 40) | 1 |
| 14 | 8235694 | 螺纹球头 | BALL Threaded | 1 |
| 15 | 932481 | 衬套 | BUSHING | 2 |
| 15 | 8M0215006 | 旋转衬套 | BUSHING Swivel | 2 |
| 16 | 8524353 | 连接杆 | LINK | 1 |
| 17 | 67748 | 滚轮 | ROLLER | 1 |
| 18 | 850286 | 油门滚轮 | ROLLER Throttle | 1 |
| 18 | 8502861 | 杠杆 | LEVER | 1 |
| 19 | 8237951 | 挡圈 | RING Retaining | 1 |
| 20 | 40056107 | 螺钉(M5×16) | SCREW (M5 x 16) | 1 |
| 21 | 89302 | 垫圈(0.203×0.406×0.040) | WASHER (.203 x .406 x .040) | 1 |
| 22 | 69432 | 外锁紧垫圈(#10) | LOCKWASHER External (#10) | 1 |
| 23 | 8240102 | 支架 | BRACKET | 1 |
| 23 | 824010T05 | 支架 | BRACKET | 1 |
| 24 | 824016 | 闩锁 | LATCH | 1 |
| 25 | 42975 | 传动螺钉 | DRIVE SCREW | 2 |
| 26 | 824015 | 筒形保持杯 | CUP Barrel Retainer | 2 |
| 27 | 82155025 | 螺丝(M8 x 25 mm)不锈钢 | SCREW (M8 x 25 mm) Stainless Steel | 3 |
| 28 | 82155025 | 螺丝(M8 x 25 mm)不锈钢 | SCREW (M8 x 25 mm) Stainless Steel | 1 |
| 29 | 854653 | 导向滚轮 | GUIDE Roller | 1 |
| 29 | 8M0039052 | 滑动支架 | BRACKET Slide | 1 |
| 30 | 814281A2 | 开关 | SWITCH | 1 |
| 30 | 8M0052931 | 开关 | SWITCH | 1 |
| 31 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 31 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 32 | 82470620 | 螺钉 (M3.5 x 20) | SCREW (M3.5 x 20) | 2 |
| 33 | 8568331 | 支架 | BRACKET | 1 |
| 34 | 856879 | 支架 | BRACKET | 1 |
| 35 | 856840 | 扎带(5.20英寸) | TIE STRAP (5.20 Inches) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8226086 | 模块 | CARTRIDGE | 1 |
| - | 822560A5 | 线束总成-DDT适配器 | HARNESS ASSEMBLY DDT Adapter | 1 |
| - | 825003A1 | DDT诊断线束总成 | CABLE ASSEMBLY DDT | 1 |
| - | 823686A2 | 数字诊断测试仪 | DIGITAL DIAGNOSTIC TESTER | 1 |
| - | 99750A1 | 万用表 | MULTI METER | 1 |
| - | 52024A1 | 开关总成 | SWITCH ASSEMBLY | 1 |
| - | 59339 | 维修用转速表 | SERVICE TACHOMETER | 1 |
| - | 892647A01 | DMT万用表套件 | MULTI-METER KIT DMT | 1 |
| - | 850439T | 八腔测试仪 | TESTER EIGHT CHAMBER | 1 |
| - | 850439T1 | 八腔测试仪 | TESTER Eight Chamber | 1 |
| - | 63998A1 | 单腔间隙工具 | GAP TOOL Single Chamber | 1 |
| - | 825824A2 | 转速表接口模块 | TACH INTERFACE MODULE | 1 |
| - | 99379 | 正时灯 | TIMING LIGHT | 1 |
| - | 112301 | 对正工具 | ALIGNMENT TOOL | 1 |
| - | 99750A1 | 万用表 | MULTI METER | 1 |
| - | 52915A6 | 测试仪表套件 | TEST GAUGE KIT | 1 |
| - | 74951 | 扳手 | SPANNER WRENCH | 1 |
| - | 44487T1 | 调整杆导向器拆卸工具 | REMOVER TOOL Trim Rod Guide | 1 |
| - | 44486A1 | 调整杆拆卸工具 | REMOVAL TOOL Trim Rod | 1 |
| - | 29287 | 量规工具 | GAUGE TOOL | 1 |
| - | 55919 | 驱动头 | DRIVER HEAD | 1 |
| - | 52344 | 飞轮固定器工具(齿型) | FLYWHEEL HOLDER TOOL Teeth Type | 1 |
| - | 73687A2 | 飞轮拉拔器套件 | PULLER KIT Flywheel | 1 |
| - | 849154T1 | 拉拔器总成 | PULLER ASSEMBLY | 1 |
| - | 90455T | 吊环 | LIFTING EYE | 1 |
| - | 904551 | 吊环 | LIFTING EYE | 1 |
| - | 93004A2 | 锁环安装工具 | INSTALLATION TOOL Lock Ring | 1 |
| - | 52952T1 | 活塞销锁环拆卸工具 | REMOVAL TOOL Piston Pin Lock Ring | 1 |
| - | 24697 | 活塞环扩张工具 | EXPANDER TOOL Piston Ring | 1 |
| - | 92973A1 | 活塞销心轴工具 | MANDREL TOOL Piston Pin | 1 |
| - | 812549T | 动力头支架 | STAND Powerhead | 1 |
| - | 24161 | 飞轮拉拔器盖工具 | CAP TOOL Flywheel Puller | 1 |
| - | 823237T | 活塞环压缩工具(3.625英寸) | COMPRESSOR TOOL Piston Ring (3.625) | 1 |
| - | 66274 | 扭矩扳手(0-150磅英寸) | TORQUE WRENCH (0-150 lb-in) | 1 |
| - | 37241 | 通用拉拔板 | PULLER PLATE Universal | 1 |
| - | 852087A3 | 压力表 | PRESSURE GAUGE | 1 |
| - | 881834A1 | 仪表 | GAUGE | 1 |
| - | 4007325 | 螺丝(M5 x 25) | SCREW (M5 x 25) | 1 |
| - | 851980 | 密封/特氟龙环安装工具 | INSTALLATION TOOL Seal/Teflon Ring | 1 |
| - | 8519803 | 安装帽 | CAP Installation | 1 |
| - | 8519801 | 密封/特氟龙环定型工具 | SIZING TOOL Seal/Teflon Ring | 1 |
| - | 8519802 | 定型工具 | SIZING TOOL | 1 |
| - | 16850A7 | 仪表套件 | GAUGE KIT | 1 |
| - | 881833A03 | 气油压力表套件 | GAUGE KIT Air/Fuel Pressure | 1 |
| - | 99750A1 | 万用表 | MULTI METER | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 881288T1 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 8M0059965 | 顶罩-黑色 | COWL-TOP-BLACK | 1 |
| 1 | 881288T2 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 8M0059966 | 顶罩-银色 | COWL-TOP-SILVER | 1 |
| 2 | 82130030 | 螺钉 (M6 x 30) | SCREW (M6 x 30) | 4 |
| 3 | 884041A1 | 隔音毯套装 | SOUND BLANKET KIT | 1 |
| 3 | 884041A04 | 隔音毯套装 | SOUND BLANKET KIT | 1 |
| 4 | NSS | 不单独出售-顶部隔音垫 | NOT SOLD SEPARATE Sound Blanket-Top | 1 |
| 5 | NSS | 不单独销售 隔音垫-左舷 | NOT SOLD SEPARATE Sound Blanket-Port | 1 |
| 6 | 93702 | 垫圈(.250外齿星形) | WASHER (.250 External Star) | 6 |
| 7 | 826639T | 盖板 | COVER | 1 |
| 8 | 850682T4 | 后锁钩总成 | HOOK ASSEMBLY Rear Latch | 2 |
| 8 | 850682A06 | 支架和手柄套件 | BRACKET AND HANDLE KIT | 2 |
| 9 | NSS | NOT SOLD SEPARATE Pin | 2 | |
| 10 | 8237951 | 挡圈 | RING Retaining | 2 |
| 11 | 815263 | 滚轮 | ROLLER | 2 |
| 11 | 8M0207770 | 滚轮@3 | ROLLER @3 | 2 |
| 12 | 8506851 | 护孔环 | GROMMET | 1 |
| 12 | 850685T02 | 护孔环 | GROMMET | 1 |
| 12 | 850685002 | 护孔环 | GROMMET | 1 |
| 12 | 850685T02 | 护孔环 | GROMMET | 1 |
| 13 | 821249M2 | 前支架 | BRACKET Front | 1 |
| 13 | 8M0036792 | 支架 | BRACKET | 1 |
| 14 | 82130020 | 螺钉 (M6 x 20) | SCREW (M6 x 20) | 2 |
| 15 | 815477 | 缓冲器锁扣 | BUMPER Latch | 1 |
| 16 | 8155381 | 滚动销 | PIN Roll | 1 |
| 17 | 401366 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 18 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 1 |
| 18 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 1 |
| 19 | 8237951 | 挡圈 | RING Retaining | 1 |
| 20 | 815263 | 滚轮 | ROLLER | 1 |
| 20 | 8M0207770 | 滚轮@3 | ROLLER @3 | 1 |
| 21 | 87161 | 垫圈 | WASHER | 1 |
| 22 | NSS | 不单独销售 贴花-磨合 | NOT SOLD SEPARATE Decal-Break-In | 1 |
| 23 | NSS | 不单独销售-反向旋转标识 | NOT SOLD SEPARATE Decal-Counter Rotation | 1 |
| - | 855410A04 | 贴花套件 | DECAL SET | 1 |
| - | 8M0065127 | ORD 8M0099561 | ORD 8M0099561 | 1 |
| - | 855412A04 | 贴花套件 | DECAL SET | 1 |
| - | 8M0065131 | ORD 8M0099562 | ORD 8M0099562 | 1 |
| - | 855412A06 | 贴花套件 | DECAL SET | 1 |
| - | 855405A03 | 贴花套件 | DECAL SET | 1 |
| - | 855405A04 | 贴花套件 | DECAL SET | 1 |
| - | 855405A04 | 贴花套件 | DECAL SET | 1 |
| - | 8M0065127 | ORD 8M0099561 | ORD 8M0099561 | 1 |
| - | 855408A03 | 贴花套件 | DECAL SET | 1 |
| - | 855408A04 | 贴花套件 | DECAL SET | 1 |
| - | 855408A04 | 贴花套件 | DECAL SET | 1 |
| - | 8M0065131 | ORD 8M0099562 | ORD 8M0099562 | 1 |
| - | 855408A06 | 贴花套件 | DECAL SET | 1 |
| - | 855409A03 | 贴花套件 | DECAL SET | 1 |
| - | 8M0065129 | 贴花套件 | DECAL SET | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 828334T03 | 艉板支架总成-右舷 | BRACKET ASSEMBLY Transom-Starboard | 1 |
| 2 | 828333T08 | 艉板支架总成-左舷 | BRACKET ASSEMBLY Transom-Port | 1 |
| 3 | 98727 | 润滑脂接头(左舷) | FITTING Grease (PORT) | 1 |
| 3 | 8M0169588 | 润滑脂接头 | FITTING Grease | 1 |
| 4 | 826125A1 | 倾斜管 | TILT TUBE | 1 |
| 5 | 826135 | 尼龙锁紧螺母(1.00-14) | NUT Lock (1.00-14) Nylon Insert | 1 |
| 6 | 45711 | O型圈 (.612 x .103) | O-RING (.612 x .103) | 1 |
| 7 | 88750 | 波浪垫圈 (1.62 x 1.05) | WASHER Wave (1.62 x 1.05) | 2 |
| 8 | 826164 | 螺母 (.875-14) | NUT (.875-14) | 1 |
| 8 | 8M0231351 | 锁紧螺母 | NUT Lock | 1 |
| 9 | 677551 | 螺钉(.500-20×4.500) | SCREW (.500-20 x 4.500) | 4 |
| 9 | 8M0149747 | 螺钉 | SCREW | 4 |
| 10 | 54012 | 垫圈(0.530×0.870×0.105不锈钢) | WASHER (.530 x .870 x .105) Stainless Steel | 4 |
| 10 | 8M0204665 | 垫圈(0.530×0.880×0.104 630不锈钢) | WASHER (.530 x .880 x .104) 630 Stainless Steel | 4 |
| 11 | 28421 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 11 | 8M0204648 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 12 | 82671117 | 螺母(.500-20) | NUT (.500-20) | 4 |
| 13 | 99629T2 | 倾斜锁定杆总成 | LEVER ASSEMBLY Tilt Lock | 1 |
| 13 | 8M0115104 | 倾斜锁定杆总成 | LEVER ASSEMBLY Tilt Lock | 1 |
| 14 | 830899 | 张力弹簧 | SPRING Tension | 1 |
| 15 | 65830 | 尼龙衬套 | NYLINER | 2 |
| 16 | 830900 | 压缩弹簧 | SPRING Compression | 1 |
| 17 | 99633 | 旋钮 | KNOB | 1 |
| 18 | 99615 | 槽销 | PIN Groove | 1 |
| 19 | 99617 | 销 | PIN | 1 |
| 19 | 893709 | 销 | PIN | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | NSS | 不单独销售 蒸汽分离器总成 | NOT SOLD SEPARATE Vapor Separator Assembly | 1 |
| - | 880133T07 | 蒸汽分离器总成 | VAPOR SEPARATOR ASSEMBLY | 1 |
| - | 880133T12 | 蒸汽分离器总成 | VAPOR SEPARATOR ASSEMBLY | 1 |
| 1 | 889317T1 | 盖板套件 | COVER KIT | 1 |
| 2 | NSS | 阀座(不单独销售) | NOT SOLD SEPARATE Seat | 1 |
| 3 | 889318 | 挡板 | PLATE Baffle | 1 |
| 3 | 889318001 | 挡板 | PLATE Baffle | 1 |
| 3 | 889318001 | 挡板 | PLATE Baffle | 1 |
| 4 | 883223 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 5 | 889319 | 衬垫 | GASKET | 1 |
| 6 | 883556 | 接头 | FITTING | 1 |
| 7 | 883209 | O型圈 | O-RING | 1 |
| 7 | 8M0062785 | O型圈 | O-RING | 1 |
| 8 | 889329 | 接头 | FITTING | 1 |
| 9 | 883208 | 堵头 | PLUG | 1 |
| 10 | 884380T | 燃油滤清器 | FILTER Fuel | 1 |
| 10 | 8M0122423 | 水星燃油滤清器 | FUEL FILTER Quicksilver | 1 |
| 11 | 889320A1 | 浮子套件 | FLOAT KIT | 1 |
| 12 | F10064 | 轴 | SHAFT | 1 |
| 13 | 888725T1 | 燃油泵总成-高压 | PUMP ASSEMBLY Fuel - High Pressure | 1 |
| 13 | 888725T02 | 燃油泵总成-高压 | PUMP ASSEMBLY Fuel - High Pressure | 1 |
| 13 | 888725T02 | 燃油泵总成-高压 | PUMP ASSEMBLY Fuel - High Pressure | 1 |
| 14 | 855428 | 套筒 | SLEEVE | 1 |
| 14 | 8M6000589 | 套筒 | SLEEVE | 1 |
| 15 | 8893162 | O型圈 | O-RING | 1 |
| 16 | 889321 | 密封件 | SEAL | 1 |
| 16 | 8M6001412 | 密封件 | SEAL | 1 |
| 17 | 889328 | 固定座 | RETAINER | 1 |
| 18 | 9643 | 螺钉 | SCREW | 11 |
| 19 | 888733T1 | 增压泵 | PUMP Boost | 1 |
| 19 | 888733T02 | 增压泵总成 | PUMP ASSEMBLY Boost | 1 |
| 19 | 888733T02 | 增压泵总成 | PUMP ASSEMBLY Boost | 1 |
| 20 | 889322 | 护孔环 | GROMMET | 1 |
| 21 | 889316 | O型圈 | O-RING | 1 |
| 22 | 889323 | 密封件 | SEAL | 1 |
| 22 | 8M6001413 | 密封件 | SEAL | 1 |
| 23 | 889324T1 | 油杯套件 | BOWL KIT | 1 |
| 23 | 889324T02 | 油杯套件 | BOWL KIT | 1 |
| 23 | 889324T02 | 油杯套件 | BOWL KIT | 1 |
| 23 | 889324T03 | 油杯套件 | BOWL KIT | 1 |
| 24 | 889325A1 | 电线 | WIRE | 1 |
| 24 | 889325A02 | 电线 | WIRE | 1 |
| 25 | NSS | 止回阀(不单独销售) | NOT SOLD SEPARATE Check Valve | 1 |
| 26 | 8554241 | 接头 | FITTING | 2 |
| 26 | 855424011 | 接头 | FITTING | 2 |
| 27 | 889326A1 | 进气阀套件 | VALVE KIT Inlet | 1 |
| 28 | 889327A1 | 放油螺钉 | SCREW Drian | 2 |
| 29 | 8893161 | O型圈 | O-RING | 2 |
| 30 | 889330 | 水温传感器 | SENSOR Water | 1 |
| 30 | 8M0214989 | 燃油含水传感器 | SENSOR WIF | 1 |
| 31 | 996642 | 90度弯头接头(0.125-27x0.250)尼龙 | FITTING Elbow 90 Degree (.125-27 x .250) Nylon | 1 |
| 31 | 782792 | 45度弯头接头(1.25) | FITTING Elbow 45 Degree (1.25) | 1 |
| 31 | 8M0207781 | 弯头 | ELBOW | 1 |
| 32 | 627021 | O型圈(.301 x .070) | O-RING (.301 x .070) | 2 |
| 33 | 889430 | 嵌件 | INSERT | 1 |
| 34 | 8835451 | 软管 | HOSE | 1 |
| 34 | 883545002 | 软管 | HOSE | 1 |
| 35 | 884820 | 施拉德阀 | SHRADER VALVE | 1 |
| 36 | 891778 | O型圈 | O-RING | 1 |
| 37 | 884819 | 卡扣 | CLIP | 1 |
| 38 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 1 |
| 39 | 855362 | 护孔环 | GROMMET | 3 |
| 39 | 855362001 | 护孔环 | GROMMET | 3 |
| 39 | 855362001 | 护孔环 | GROMMET | 3 |
| 40 | 883050 | 隔套 | SPACER | 3 |
| 41 | 81893460 | 螺钉 (M8 x 60) | SCREW (M8 x 60) | 3 |
| 42 | 4002318 | 垫圈 8.90 x 24.0x 2.4 不锈钢 | WASHER 8.90 x 24.0x 2.4 PL SS | 3 |
| - | 889316A1 | 蒸汽分离器O型圈套件 | O-RING KIT Vapor Seperator | 1 |
