两冲程 直喷 DFI OptiMax · USA - Cat.# 90-80917097 · 共 39 个部位 · 1497 条零件
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 827927A8 | 燃油管路总成（8英尺） | LINE ASSEMBLY Fuel (8 Feet) (8 FT.) | 1 |
| - | 877680Q8 | 燃油软管总成(8英尺) | HOSE ASSEMBLY Fuel (8 Feet) | 1 |
| - | 827927A12 | 燃油管路总成 (12英尺) | LINE ASSEMBLY Fuel (12 Feet) (12 FT.) | 1 |
| - | 877680Q12 | 燃油软管总成(12英尺) | HOSE ASSEMBLY Fuel (12 Feet) | 1 |
| - | 17146A8 | 燃油管路总成（8英尺） | LINE ASSEMBLY Fuel (8 Feet) (8 FT.) | 1 |
| - | 877681Q8 | 燃油软管总成(8英尺) | HOSE ASSEMBLY Fuel (8 Feet) | 1 |
| - | 17146A12 | 燃油管路总成 (12英尺) | LINE ASSEMBLY Fuel (12 Feet) (12 FT.) | 1 |
| - | 877681Q12 | 燃油软管总成(12英尺) | HOSE ASSEMBLY Fuel (12 Feet) | 1 |
| - | 822379A12 | 燃油管路总成(12英尺) | LINE ASSEMBLY Fuel (12 Feet) | 1 |
| - | 877683Q12 | 燃油软管总成(12英尺) | HOSE ASSEMBLY Fuel (12 Feet) | 1 |
| - | 852400 | 冲洗接头 | FLUSH COUPLING | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 828127A2 | 空气管理系统 | AIR MANAGEMENT | 1 |
| 2 | 832952 | 油门位置指示器 | INDICATOR Throttle Position | 2 |
| 3 | 8318701 | 衬套 | BUSHING | 8 |
| 4 | 834985 | 护孔环 | GROMMET | 4 |
| 4 | 8M0190980 | 护孔环 | GROMMET | 4 |
| 5 | 852085 | 安装板 | PLATE | 1 |
| 6 | 852086 | 壳体 | HOUSING | 1 |
| 7 | 40056107 | 螺钉(M5×16) | SCREW (M5 x 16) | 2 |
| 8 | 400255 | 锁紧垫圈(M5) | LOCKWASHER (M5) | 2 |
| 9 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 4 |
| 9 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 4 |
| 10 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 4 |
| 11 | 40104 | 螺钉(M6×25) | SCREW (M6 x 25) (M6 X 25) | 4 |
| 12 | 40056110 | 螺钉(M5×30) | SCREW (M5 x 30) (M5 X 30) | 4 |
| 13 | 89302 | 垫圈(0.203×0.406×0.040) | WASHER (.203 x .406 x .040) | 4 |
| 14 | 400255 | 锁紧垫圈(M5) | LOCKWASHER (M5) | 4 |
| 15 | 13221A1 | 温度传感器总成 | SENSOR ASSEMBLY Temperature | 1 |
| 15 | 13221T01 | 温度传感器 | SENSOR TEMP | 1 |
| 16 | 4005685 | 螺钉(M4×10) | SCREW (M4 x 10) (M4 X 10) | 3 |
| 17 | 26995 | 防松垫圈(#8不锈钢) | LOCKWASHER (#8) Stainless Steel | 3 |
| 18 | 45711 | O型圈 (.612 x .103) | O-RING (.612 x .103) | 1 |
| 19 | 40132 | 螺钉(M8×125) | SCREW (M8 x 125) | 12 |
| 20 | 70132 | 垫圈(0.323×0.563×0.063)不锈钢 | WASHER (.323 x .563 x .063) Stainless Steel | 12 |
| 20 | 8M0042642 | 垫圈(.323 x .562 x .063) | WASHER (.323 x .562 x .063) | 12 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 814281A2 | 开关 | SWITCH | 1 |
| 1 | 8M0052931 | 开关 | SWITCH | 1 |
| 2 | 82470620 | 螺钉(M3.5×20) | SCREW (M3.5 x 20) (M3.5 X 20) | 2 |
| 3 | 8240101 | 锚支架 | BRACKET Anchor | 1 |
| 3 | 824010T05 | 支架 | BRACKET | 1 |
| 4 | 42975 | 传动螺钉 | DRIVE SCREW | 2 |
| 5 | 824016 | 闩锁 | LATCH | 1 |
| 6 | 824015 | 筒形保持杯 | CUP Barrel Retainer | 2 |
| 7 | 82155025 | 不锈钢螺钉(M8×25mm) | SCREW (M8 x 25 mm) Stainless Steel (M8 X 25) | 3 |
| 8 | 824013 | 衬套 | BUSHING | 1 |
| 9 | 812707 | 衬套 | BUSHING | 2 |
| 10 | 824014 | 弹簧 | SPRING | 1 |
| 11 | 8240111 | 导向滚轮 | GUIDE Roller | 1 |
| 12 | 834978 | 油门连杆 | LINK Throttle | 1 |
| 13 | 932481 | 衬套 | BUSHING | 2 |
| 13 | 8M0215006 | 旋转衬套 | BUSHING Swivel | 2 |
| 14 | 8252681 | 节气门控制杆 | LEVER Throttle Control | 1 |
| 14 | 8M0040987 | 杠杆 | LEVER | 1 |
| 15 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 1 |
| 15 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 1 |
| 16 | 36042 | 垫圈 | WASHER | 1 |
| 17 | 42927 | 嵌件 | INSERT | 1 |
| 18 | 821113 | 衬套 | BUSHING | 1 |
| 19 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 19 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 20 | 850156 | 螺钉(M6×70) | SCREW (M6 X 70) | 2 |
| 21 | 400212 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 2 |
| 22 | 42942 | 盖帽 | CAP | 2 |
| 23 | 35459 | 垫圈 | WASHER | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 827210A1 | 泄放系统歧管总成 | MANIFOLD ASSEMBLY Bleed System | 1 |
| 2 | 426231 | 止回阀 | CHECK VALVE | 6 |
| 2 | 426233 | 止回阀 | CHECK VALVE | 6 |
| 3 | 15133 | 接头 | FITTING | 1 |
| 4 | 92051 | 螺钉(10-16×0.75)(10-16×3/4英寸) | SCREW (10-16 x .75) (10-16 X 3/4 IN.) | 1 |
| 5 | 99130122 | 管材(20英尺整卷)(9英寸) | TUBING (20.00 Feet Bulk) (9 IN.) | 1 |
| 5 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 6 | 99130122 | 管材(20.00英尺散装)(5-1/4英寸) | TUBING (20.00 Feet Bulk) (5-1/4 IN.) | 2 |
| 6 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 2 |
| 7 | 76843 | 接头 | FITTING | 3 |
| 7 | 768431 | 接头 | FITTING | 3 |
| 8 | 18206 | 滤清器 | FILTER | 1 |
| 8 | 8M0207786 | 滤清器 | FILTER | 1 |
| 9 | 9912688 | 管材(36.00英寸散装)(2-3/4英寸) | TUBING (36.00 Inches Bulk) (2-3/4 IN.) | 1 |
| 10 | 827200 | 三通接头 | FITTING Tee | 1 |
| 11 | 99130122 | 管材(20英尺散装)(9-1/2英寸) | TUBING (20.00 Feet Bulk) (9-1/2 IN.) | 1 |
| 11 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 12 | 15026 | 盖帽 | CAP | 3 |
| 13 | 827210A1 | 泄放系统歧管总成 | MANIFOLD ASSEMBLY Bleed System | 1 |
| 14 | 426231 | 止回阀 | CHECK VALVE | 6 |
| 14 | 426233 | 止回阀 | CHECK VALVE | 6 |
| 15 | 15133 | 接头 | FITTING | 1 |
| 16 | 92051 | 螺钉(10-16×0.75)(10-16×3/4英寸) | SCREW (10-16 x .75) (10-16 X 3/4 IN.) | 1 |
| 17 | 99130122 | 管材(20.00英尺散装)(5-1/4英寸) | TUBING (20.00 Feet Bulk) (5-1/4 IN.) | 1 |
| 17 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 18 | 99130122 | 管材(20.00英尺散装)(20-1/2英寸) | TUBING (20.00 Feet Bulk) (20-1/2 IN.) | 1 |
| 18 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 19 | 99130122 | 管材(20.00英尺散装)(7英寸) | TUBING (20.00 Feet Bulk) (7 IN.) | 1 |
| 19 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 20 | 99130122 | 管材(20英尺散装)(8-1/2英寸) | TUBING (20.00 Feet Bulk) (8-1/2 IN.) | 1 |
| 20 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 21 | 76843 | 接头 | FITTING | 3 |
| 21 | 768431 | 接头 | FITTING | 3 |
| 22 | 15026 | 盖帽 | CAP | 3 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 818448A1 | 下机罩 | BOTTOM COWL | 1 |
| 1 | 818448A2 | 下机罩 | BOTTOM COWL | 1 |
| 1 | 818448A4 | 下机罩 | BOTTOM COWL | 1 |
| 2 | 818447A1 | 下机罩 | BOTTOM COWL | 1 |
| 2 | 818447A2 | 下机罩 | BOTTOM COWL | 1 |
| 2 | 818447A4 | 下机罩 | BOTTOM COWL | 1 |
| 3 | 8253181 | 罩盖密封条(41英寸) | SEAL Cowl (41.00 Inches) | 2 |
| 3 | 8M0109217 | 罩盖密封条 | SEAL-COWL | 2 |
| 4 | 82130040 | 螺钉 (M6 x 40) | SCREW (M6 x 40) (M6 X 1.0) | 4 |
| 5 | 824868 | 螺钉 (M6 x 75) | SCREW (M6 x 75) (M6 X 1 X 75) | 1 |
| 6 | 821253F1 | 前手柄黑色 | FRONT HANDLE Black | 1 |
| 6 | 889740A02 | 手柄套件 | HANDLE KIT | 1 |
| 6 | 821253F2 | 前手柄 | FRONT HANDLE | 1 |
| 6 | 889740A02 | 手柄套件 | HANDLE KIT | 1 |
| 6 | 821253F4 | 前手柄 | FRONT HANDLE | 1 |
| 6 | 889740A02 | 手柄套件 | HANDLE KIT | 1 |
| 7 | 335891 | 衬套 | BUSHING | 2 |
| 8 | 48462 | O型圈 (.614 x .070) | O-RING (.614 x .070) | 1 |
| 9 | 8219423 | 棘爪 | PAWL | 1 |
| 10 | 69057 | 垫片(.281 x .734 x .063) | WASHER (.281 x .734 x .063) | 1 |
| 11 | 401196 | 螺母 (M6) | NUT (M6) | 1 |
| 12 | 8214281 | 螺钉 (#10-16 x 0.625) | SCREW (#10-16 x .625) (10-16 X .625) | 1 |
| 13 | 822873 | 卡扣 | CLIP | 1 |
| 14 | 18286A40 | 开关总成 | SWITCH ASSEMBLY | 1 |
| 14 | 8M0235192 | 微调开关 | SWITCH TRIM | 1 |
| 15 | 8124431 | 固定座 | RETAINER | 1 |
| 15 | 8M0032848 | 开关固定座 | RETAINER Switch | 1 |
| 16 | 822024 | 卡箍(下部) | CLAMP (LOWER) | 1 |
| 17 | 822023 | 卡箍 (上) | CLAMP (UPPER) | 1 |
| 18 | 92799 | 螺钉 (#10-16 x 1.12) | SCREW (#10-16 x 1.12) (10-16 X 1.12) | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9784A8 | 曲轴 | CRANKSHAFT | 1 |
| 1 | 9784A11 | 曲轴总成 | CRANKSHAFT ASSEMBLY | 1 |
| 2 | 67923 | 球轴承(下部) | BEARING Ball (LOWER) | 1 |
| 2 | 67923T | 滚珠轴承 | BEARING Ball | 1 |
| 3 | 67446 | 环 | RING | 1 |
| 4 | 816106 | 环 | RING | 7 |
| 4 | 843198T01 | 密封环 | RING Seal | 7 |
| 5 | 91800 | 半圆键 | KEY Woodruff | 1 |
| 6 | 35126 | O型圈(.859 x .139) | O-RING (.859 x .139) | 1 |
| 7 | 817001A1 | 轴承座圈总成 | RACE ASSEMBLY Bearing | 2 |
| 7 | 8M0113288 | 轴承座圈总成 | RACE ASSY-BEARING | 2 |
| 8 | 827902A4 | 活塞总成 | PISTON ASSEMBLY | 3 |
| 8 | 827902T4 | 活塞总成-右舷 | PISTON ASSY-STBD | 3 |
| 8 | 827901A4 | 活塞总成 | PISTON ASSEMBLY | 3 |
| 8 | 827901T4 | 活塞总成-左舷 | PISTON ASSY-PORT | 3 |
| 9 | 832081 | 锁紧环 | LOCK RING | 12 |
| 9 | 8320811 | 锁紧环 | LOCK RING | 12 |
| 10 | 834805A12 | 活塞环组 | RING SET Piston | 1 |
| 11 | 822373A3 | 连杆总成 | CONNECTING ROD ASSEMBLY | 6 |
| 11 | 8M0125869 | 连杆套件 | CONN ROD KIT | 6 |
| 12 | 94320 | 螺钉 (0.375-24 x 1.25) | SCREW (.375-24 x 1.250) (1-1/4 IN.) | 12 |
| 13 | 43012A1 | 轴承/保持架套件 | BEARING/CAGE KIT | 6 |
| 13 | 8M0235070 | 轴承保持架 | CAGE BEARING | 6 |
| 14 | 88263 | 止推垫片 | THRUST WASHER | 12 |
| 15 | 88258 | 滚针轴承 | NEEDLE Roller Bearing | 204 |
| 15 | 8M0204715 | 滚针@102 | NEEDLES-BRG @102 | 204 |
| 16 | 816773A2 | 轴承总成（上部） | BEARING ASSEMBLY (UPPER) | 1 |
| 17 | 815449 | 油封 | SEAL Oil | 1 |
| 17 | 859093 | 密封件 | SEAL | 1 |
| 18 | 823683 | O型圈(1.989 x .070) | O-RING (1.989 x .070) | 1 |
| 19 | 68229 | 垫圈(.641 x 1.250 x .190) | WASHER (.641 x 1.250 x .190) | 1 |
| 19 | 33001 | 垫圈 | WASHER | 1 |
| 20 | 42979 | 螺母 (M16) | NUT (M16) (M16 X 1.5) | 1 |
| - | 814195A97 | 衬垫套件 | GASKET SET | 1 |
| - | 809973A97 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9811A18 | 气缸体 | CYLINDER BLOCK | 1 |
| 2 | 903509 | 双头螺栓 (M10 x 1.5 x 64) | STUD (M10 x 1.5 x 64) (M10 X 1.5 X 64) | 4 |
| 3 | 8154431 | 双头螺栓 (M10 x 1.5 x 155) | STUD (M10 x 1.5 x 155) (M10 X 1.5 X 155) | 6 |
| 4 | 328021 | 管塞 (1/8") | PLUG Pipe (.125-27) (1/8") | 2 |
| 4 | 328022 | 黄铜管塞 (.125-27) | PLUG Pipe (.125-27) Brass | 2 |
| 5 | 8248572 | 导水板 | DEFLECTOR Water | 4 |
| 5 | 8248577 | 导流板 | DEFLECTOR | 4 |
| 6 | 43278 | 接头 | FITTING | 1 |
| 6 | 8781051 | 止回阀 | CHECK VALVE | 1 |
| 7 | 821583 | 销 | PIN | 1 |
| 7 | 8215832 | 特殊销（1.5英寸） | PIN Special (1.5 Inches) | 1 |
| 8 | 67296 | 销 | PIN | 3 |
| 8 | 8M0036405 | 销 | PIN | 3 |
| 9 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 1 |
| 10 | 76843 | 接头 | FITTING | 6 |
| 10 | 768431 | 接头 | FITTING | 6 |
| 11 | 426581 | 止回阀 | CHECK VALVE | 2 |
| 11 | 426585 | 止回阀 | CHECK VALVE | 2 |
| 12 | 68727 | 90度弯头 (.250-18) - 黄铜 | FITTING (.250-18) 90 Degree - Brass | 1 |
| 12 | 687271 | 90度弯头 (.250-18) - 黄铜 | FITTING (.250-18) 90 Degree - Brass | 1 |
| 13 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 14 |
| 13 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 14 |
| 14 | 8159231 | 止回阀 | CHECK VALVE | 2 |
| 14 | 8159234 | 止回阀 | CHECK VALVE | 2 |
| 15 | 82446180 | 螺钉 (M10 x 80) | SCREW (M10 x 80) (M10 X 1.5) | 8 |
| 16 | 825367A1 | 托架总成 | CARRIER ASSEMBLY | 1 |
| 17 | 42657A3 | 止回阀 | CHECK VALVE | 6 |
| 18 | 99130122 | 管材（20英尺卷装）（22-1/2英寸） | TUBING (20.00 Feet Bulk) (22-1/2 IN.) | 1 |
| 18 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 19 | 99130122 | 管材（20英尺散装）（4英寸） | TUBING (20.00 Feet Bulk) (4 IN.) | 1 |
| 19 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 20 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 20 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 21 | 826544 | 模制软管 | TUBING Molded | 1 |
| 22 | 45175 | 垫圈(.406 x .750 x .104) | WASHER (.406 x .750 x .104) | 10 |
| 22 | 8M0214963 | 垫圈 | WASHER | 10 |
| 23 | 400266 | 螺母(M10) | NUT (M10) | 10 |
| 23 | 4013610 | 螺母(M10不锈钢) | NUT (M10) Stainless Steel | 10 |
| 24 | 8212251 | 支架 | BRACKET | 1 |
| 25 | 82130016 | 螺钉 (M6 x 16) | SCREW (M6 x 16) (M6 X 16) | 2 |
| 26 | 35462 | 垫圈(.2656 x .625 x .0625)不锈钢 | WASHER (.2656 x .625 x .0625) Stainless Steel | 2 |
| 27 | 822486 | 导向支架 | BRACKET Guide | 1 |
| 28 | 828558 | 曲轴位置传感器 | SENSOR Crank Position | 1 |
| 28 | 8285581 | 编码器 | ENCODER | 1 |
| 29 | 82104510 | 螺钉 (M5 x 10) | SCREW (M5 x 10) (M5 X 10) | 1 |
| 30 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 1 |
| 30 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 1 |
| 31 | 828635 | 爆震传感器 | SENSOR Knock | 1 |
| 32 | 850075A2 | 适配器线束总成 | HARNESS ASSEMBLY Adaptor | 1 |
| - | 809973A97 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 818452A1 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 818452A2 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 818452A1 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 818453A1 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 818453A2 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 818453A1 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 2 | 822257 | 双头螺柱（M12×1.75×50） | STUD (M12 X 1.75 X 50) | 4 |
| 2 | 8M0008031 | 双头螺柱(M12 x 1.75 x 52) | STUD (M12 x 1.75 x 52) | 4 |
| 3 | 82130130 | 螺钉 (M10 x 30) | SCREW (M10 x 30) (M10 X 1.5 X 30) | 1 |
| 4 | 89417 | 护孔环 | GROMMET | 1 |
| 5 | 4002321 | 垫圈(12.80 mm x 24.0 mm x 2.4 mm)不锈钢 | WASHER (12.80 mm x 24.0 mm x 2.4 mm) Stainless Steel | 4 |
| 6 | 821280 | 螺母（M12×1.75） | NUT (M12 X 1.75) | 4 |
| 6 | 4013812 | 螺母(M12)不锈钢 | NUT (M12) Stainless Steel | 4 |
| 7 | 64649 | 堵头 | PLUG | 1 |
| 8 | 815431 | 螺钉 (M14 x 178) | SCREW (M14 x 178) (M14 X 2 X 178) | 2 |
| 8 | 898834 | 螺栓（M14×178） | BOLT (M14 x 178) | 2 |
| 9 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 1 |
| 10 | 815432 | 垫圈(.562 x 2.00 x .125) | WASHER (.562 x 2.00 x .125) | 2 |
| 11 | 815433 | 垫圈 | WASHER | 2 |
| 11 | 8154331 | 垫圈（1.25×2.00×0.19） | WASHER (1.25 x 2.00 x .19) | 2 |
| 12 | 8137711 | 支架 | MOUNT | 2 |
| 13 | 825190 | 垫圈 | WASHER | 1 |
| 14 | 815434 | 螺母 | NUT | 2 |
| 14 | 896602 | 螺母(M14) | NUT (M14) | 2 |
| 15 | 8186442 | 卡箍 | CLAMP | 2 |
| 15 | 879150A90 | 下支架盖套件 | COVER KIT Lower Mount | 2 |
| 16 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 4 |
| 16 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 17 | 72521 | 内齿锁紧垫圈 | LOCKWASHER Internal Tooth | 1 |
| 18 | 818645F1 | 黑色盖 | COVER Black | 2 |
| 18 | 8M0001136 | 下支架盖 | COVER Lower Mount | 2 |
| 18 | 818645F2 | 盖板 | COVER | 2 |
| 19 | 69079 | 螺钉 (#10-16 x 0.440) | SCREW (#10-16 x .440) (5/8 IN.) | 2 |
| 20 | 816503 | 密封件 | SEAL | 1 |
| 21 | 8263841 | 排气管 | TUBE Exhaust | 1 |
| 21 | 826384T1 | 排气管 | TUBE-EXHAUST | 1 |
| 22 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 6 |
| 22 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 6 |
| 23 | 8141964 | 水管 | TUBE Water | 1 |
| 23 | 8141965 | 水管 | TUBE Water | 1 |
| 24 | 814080 | 密封件 | SEAL | 1 |
| 24 | 814080001 | 密封件 | SEAL | 1 |
| 25 | 814081 | 卡箍 | CLAMP | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 832937A1 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 832937A06 | 传动轴壳体总成-加长型 | HOUSING ASSEMBLY Driveshaft - Long | 1 |
| 1 | 832937A2 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 832937A06 | 传动轴壳体总成-加长型 | HOUSING ASSEMBLY Driveshaft - Long | 1 |
| 1 | 832938A1 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 832938A06 | 传动轴壳体总成-超长/特超长型 | HOUSING ASSEMBLY Driveshaft - X/XX-Long | 1 |
| 1 | 832938A3 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 2 | 822257 | 双头螺柱（M12×1.75×50） | STUD (M12 X 1.75 X 50) | 4 |
| 2 | 8M0008031 | 双头螺柱(M12 x 1.75 x 52) | STUD (M12 x 1.75 x 52) | 4 |
| 3 | 82130130 | 螺钉 (M10 x 30) | SCREW (M10 x 30) (M10 X 1.5 X 30) | 1 |
| 4 | 8331231 | 护孔环 | GROMMET | 1 |
| 5 | 4002321 | 垫圈(12.80 mm x 24.0 mm x 2.4 mm)不锈钢 | WASHER (12.80 mm x 24.0 mm x 2.4 mm) Stainless Steel | 4 |
| 6 | 821280 | 螺母（M12×1.75） | NUT (M12 X 1.75) | 4 |
| 6 | 4013812 | 螺母(M12)不锈钢 | NUT (M12) Stainless Steel | 4 |
| 7 | 64649 | 堵头 | PLUG | 1 |
| 8 | 815431 | 螺钉 (M14 x 178) | SCREW (M14 x 178) (M14 X 2 X 178) | 2 |
| 8 | 898834 | 螺栓（M14×178） | BOLT (M14 x 178) | 2 |
| 9 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 1 |
| 10 | 815432 | 垫圈(.562 x 2.00 x .125) | WASHER (.562 x 2.00 x .125) | 2 |
| 11 | 815433 | 垫圈 | WASHER | 2 |
| 11 | 8154331 | 垫圈（1.25×2.00×0.19） | WASHER (1.25 x 2.00 x .19) | 2 |
| 12 | 8137711 | 支架 | MOUNT | 2 |
| 13 | 825190 | 垫圈 | WASHER | 1 |
| 14 | 815434 | 螺母 | NUT | 2 |
| 14 | 896602 | 螺母(M14) | NUT (M14) | 2 |
| 15 | 8186442 | 卡箍 | CLAMP | 2 |
| 15 | 879150A90 | 下支架盖套件 | COVER KIT Lower Mount | 2 |
| 16 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 4 |
| 16 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 17 | 72521 | 内齿锁紧垫圈 | LOCKWASHER Internal Tooth | 1 |
| 18 | 818645F1 | 黑色盖 | COVER Black | 2 |
| 18 | 8M0001136 | 下支架盖 | COVER Lower Mount | 2 |
| 18 | 818645F2 | 盖板 | COVER | 2 |
| 18 | 818645F4 | 盖板 | COVER | 2 |
| 19 | 69079 | 螺钉 (#10-16 x 0.440) | SCREW (#10-16 x .440) (5/8 IN.) | 2 |
| 20 | 8329321 | 密封件 | SEAL | 1 |
| 21 | 832931 | 排气管 | TUBE Exhaust | 1 |
| 21 | 833116A7 | 排气管总成 | TUBE ASSEMBLY Exhaust | 1 |
| 22 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 6 |
| 22 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 6 |
| 23 | 8329411 | 水管 | TUBE Water | 1 |
| 23 | 8M0042785 | 水管 | TUBE-WATER | 1 |
| 23 | 8329412 | 水管 | TUBE Water | 1 |
| 23 | 8M0042786 | 水管 | TUBE Water | 1 |
| 24 | 832940 | 密封件 | SEAL | 1 |
| 24 | 832940001 | 密封件 | SEAL | 1 |
| 25 | 8329391 | 卡箍 | CLAMP | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 92876A9 | 双机延长套件 | EXTENSION KIT Dual Engine | 1 |
| 1 | 48462 | O型圈 (.614 x .070) | O-RING (.614 x .070) | 1 |
| 2 | 715651 | 转向拉索套管 | TUBE Steering Cable | 1 |
| 3 | 41055 | 支架 | MOUNT | 1 |
| 4 | 42100 | 锁紧垫圈 | TAB WASHER | 2 |
| 5 | 37984 | 螺母 (.875-14) | NUT (.875-14) | 2 |
| 5 | 8M0041651 | 螺母 (.875-14) | NUT (.875-14) | 2 |
| 6 | 88404 | 锁紧垫圈 | TAB WASHER | 2 |
| 7 | 38601 | 螺丝(.250-28 x 1.250) | SCREW (.250-28 x 1.250) | 4 |
| 8 | 17729A1 | 支架 | BRACKET | 2 |
| 9 | 62055 | 螺钉(.312-24 x 1.250) | SCREW (.312-24 x 1.250) | 4 |
| 10 | 17728 | 锁紧垫圈 | TAB WASHER | 4 |
| 11 | 14000 | 螺钉(.375-24x1.25) | SCREW (.375-24 x 1.25) | 4 |
| 11 | 849838 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 4 |
| 12 | 34863 | 螺母 (.375-24) | NUT (.375-24) | 6 |
| 12 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 6 |
| 13 | 979331 | 转向眼环 | STEERING EYE | 2 |
| 13 | 8M0026167 | 转向眼环 | STEERING EYE | 2 |
| 14 | 23651 | 衬套(1.625) | SLEEVE (1.625) | 2 |
| 15 | 97931 | 管材(4.00英寸) | TUBING (4.00 Inches) | 2 |
| 16 | 8149513 | 联轴器(15.00英寸) | COUPLER (15.00 Inches) | 1 |
| 16 | 8M0026098 | 联轴器15英寸 | COUPLER 15 In. | 1 |
| 17 | 42099 | 螺母(.562-18) | NUT (.562-18) | 1 |
| 18 | 821169 | 联轴器 | COUPLING | 1 |
| 19 | 34931 | 不锈钢垫圈(.406x.734x.063) | WASHER (.406 x .734 x .063) Stainless Steel | 2 |
| 20 | 94319 | 螺钉(.375-24 x 1.5) | SCREW (.375-24 x 1.5) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8300151 | 电气安装板 | PLATE Electrical Mounting | 1 |
| 2 | 82129114 | 螺钉 (M6 x 14) | SCREW (M6 x 14) (M6 X 14) | 1 |
| 3 | 65292 | J型卡扣 | J CLIP | 1 |
| 3 | 8M0024808 | J型夹 | J-CLIP | 1 |
| 4 | 82129110 | 螺钉 (M6 x 10) | SCREW (M6 x 10) (M6 X 10) | 7 |
| 5 | 831254 | 绑带 | STRAP | 2 |
| 6 | 828559 | 点火线圈 | COIL Ignition | 6 |
| 6 | 828559T | 点火线圈 | COIL-IGNITION | 6 |
| 7 | 821945A63 | 高压电缆总成 | CABLE ASSEMBLY Hi Tension | 1 |
| 8 | 918 | 火花塞 | SPARK PLUG | 6 |
| 9 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 4 |
| 9 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 10 | 830752 | 护孔环 | GROMMET | 4 |
| 11 | 830040 | 衬套 | BUSHING | 4 |
| 12 | 88439A25 | 电缆总成 蓄电池-正极 | CABLE ASSEMBLY Battery - Positive | 1 |
| 13 | 88439A26 | 蓄电池负极电缆总成 | CABLE ASSEMBLY Battery - Negative | 1 |
| 14 | 81893412 | 螺钉 (M8 x 12) | SCREW (M8 x 12) (M8 X 12) | 1 |
| 15 | 833136 | 卡扣 | CLIP | 1 |
| 16 | 8502701 | 发动机控制单元ECU | ECU Engine Control Unit | 1 |
| 16 | 850270T6 | 电控单元 | ECU | 1 |
| 16 | 8502706 | 发动机控制单元ECU | ECU Engine Control Unit | 1 |
| 16 | 850270T6 | 电控单元 | ECU | 1 |
| 17 | 834985 | 护孔环 | GROMMET | 3 |
| 17 | 8M0190980 | 护孔环 | GROMMET | 3 |
| 18 | 82129114 | 螺钉 (M6 x 14) | SCREW (M6 x 14) (M6 X 14) | 2 |
| 19 | 8318701 | 衬套 | BUSHING | 6 |
| 20 | 82130025 | 螺钉(M6×25) | SCREW (M6 x 25) (M6 X 25) | 3 |
| 21 | 830897 | 垫 | PAD | 1 |
| 22 | 833137 | 电磁阀安装板 | SOLENOID MOUNTING PLATE | 1 |
| 22 | 8331371 | 电磁阀安装板 | PLATE Solenoid Mounting | 1 |
| 23 | 82130012 | 螺钉 (M6 x 12) | SCREW (M6 x 12) (M6 X 12) | 3 |
| 24 | 82129114 | 螺钉 (M6 x 14) | SCREW (M6 x 14) (M6 X 14) | 2 |
| 25 | 817109A2 | 电磁阀总成(#10-32/.3125-18端子) | SOLENOID ASSEMBLY (#10-32 / .3125-18 Terminals) | 1 |
| 26 | 818968 | 衬套 | BUSHING | 5 |
| 26 | 8M0214955 | 衬套 | BUSHING | 5 |
| 27 | 82129125 | 螺钉 (M6 x 25) | SCREW (M6 x 25 mm) (M6 X 25) | 5 |
| 28 | 53166 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 2 |
| 29 | 68292 | 螺母 (5/16-18) | NUT (.312-18) (5/16-18) | 2 |
| 29 | 8M0204668 | 螺母(.312-18) | NUT (.312-18) | 2 |
| 30 | 45076 | 黄铜螺母 (#10-32) | NUT (#10-32) Brass (10-32) | 2 |
| 31 | 813938 | 盖形螺母(#10-32) | CAP NUT (#10-32) | 1 |
| 32 | 818967 | 护孔环 | GROMMET | 3 |
| 32 | 8M0207785 | 护孔环 | GROMMET | 3 |
| 33 | 828102 | 支架 | BRACKET | 3 |
| 33 | 8M0207771 | 安装支架 | BRACKET Mounting | 3 |
| 34 | 828151 | 继电器 | RELAY | 3 |
| 34 | 8M0207773 | 调整继电器总成 | RELAY ASSEMBLY Trim | 3 |
| 35 | 819514A14 | 升降线束总成 | HARNESS ASSEMBLY Trim | 1 |
| 36 | 93388A7 | 线缆总成(黑色) | CABLE ASSEMBLY (BLACK) | 1 |
| 36 | 93388A14 | 线缆总成(黄/黑) | CABLE ASSEMBLY Yellow/Black | 1 |
| 37 | 828562A4 | 发动机线束总成 | HARNESS ASSEMBLY Engine | 1 |
| 38 | 8289471 | 保险丝支架 | BRACKET Fuse Holder | 1 |
| 39 | 812619 | 黄色保险丝-20安培 | FUSE Yellow - 20 Ampere | 4 |
| 40 | 61990 | 扎带(14.00英寸) | TIE STRAP (14.00 Inches) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 818450A4 | 排气板总成 | PLATE ASSEMBLY Exhaust | 1 |
| 2 | 832994 | 滤网 | STRAINER | 2 |
| 3 | 8139322 | 衬垫 | GASKET | 1 |
| 4 | 823988 | 衬垫(下部) | GASKET (LOWER) | 1 |
| 5 | 64878 | 弹簧(黑色) | SPRING (Black) | 1 |
| 5 | 851907 | 弹簧 | SPRING | 1 |
| 5 | 854478 | 弹簧 | SPRING | 1 |
| 1 | 832935A1 | 排气板总成 | PLATE ASSEMBLY Exhaust | 1 |
| 3 | 8329331 | 衬垫 | GASKET | 1 |
| 3 | 8329335 | 衬垫 | GASKET | 1 |
| 6 | 8329342 | 衬垫(下部) | GASKET (LOWER) | 1 |
| 6 | 8329344 | 衬垫 | GASKET | 1 |
| 7 | 8238051 | 密封件 | SEAL | 1 |
| 7 | 8M0043157 | 密封件 | SEAL | 1 |
| 8 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 2 |
| 8 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 2 |
| 9 | 656632 | 盖板 | COVER | 1 |
| 9 | 8M0237835 | 罩盖总成 | COVER ASSY | 1 |
| 10 | 65664A1 | 隔板总成 | PLATE ASSEMBLY | 1 |
| 11 | 88907 | 衬垫 | GASKET | 2 |
| 11 | 88907003 | 衬垫 | GASKET | 2 |
| 12 | 69570 | 螺钉(#10-16 x .750) | SCREW (#10-16 x .750) | 1 |
| 13 | 76451 | 垫圈 | WASHER | 1 |
| 14 | 64877 | 隔膜 | DIAPHRAGM | 1 |
| 14 | 648771 | 隔膜 | DIAPHRAGM | 1 |
| 15 | 814189 | 提动阀 | POPPET | 1 |
| 16 | 814191 | 护孔环 | GROMMET | 1 |
| 17 | 814190 | 托架 | CARRIER | 1 |
| 18 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 6 |
| 18 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 6 |
| 19 | 34982 | 连接器 | CONNECTOR | 3 |
| 20 | 36382 | 管接头（0.250-18×0.62）黄铜 | FITTING (.250-18 x .62) Brass | 2 |
| 21 | 821975 | 45度弯头 (455) | ELBOW 45 Degree (455) | 1 |
| 22 | 821255 | 怠速排气套 | BOOT Idle Exhaust | 1 |
| 23 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 23 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 24 | 83476456 | 软管 | HOSE | 1 |
| 24 | 83476463 | 软管 (32英寸) | TUBING (32.00 Inches Bulk) | 1 |
| 25 | 821904 | 出水指示器接头 | FITTING Tell-Tale TELL TALE | 1 |
| 25 | 8M0077650 | 示流器接头 | FITTING Tell-Tale | 1 |
| 26 | 821908 | 堵头 | PLUG | 1 |
| 27 | 821915 | 垫圈 | WASHER | 1 |
| 28 | 821963 | 止回阀 | CHECK VALVE | 1 |
| 28 | 8219631 | 止回阀 | CHECK VALVE | 1 |
| 29 | 30641 | O型圈(0.299x0.103) | O-RING (.299 x .103) | 1 |
| 30 | 821952 | 接头 | FITTING | 1 |
| 31 | 821976 | 软管 | HOSE | 1 |
| 32 | 834808 | 燃油冷却器滤网 | STRAINER FUEL COOLER | 1 |
| 32 | 8348083 | 滤网 | STRAINER | 1 |
| 33 | 817519A1 | 排水单向阀总成 | CHECK VALVE ASSEMBLY Drain | 2 |
| 34 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 4 |
| 35 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 35 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 36 | 35459 | 垫圈 | WASHER | 1 |
| 37 | 824012 | 滚轮 | ROLLER | 1 |
| 38 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 38 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 39 | 8141935 | 换挡连杆 | SHIFT LINK | 1 |
| 39 | 883142A03 | 换挡连杆套件 | SHIFT LINK KIT | 1 |
| 40 | 42994 | 衬套 | BUSHING | 1 |
| 41 | 8240701 | 上换挡轴 | SHIFT SHAFT Upper | 1 |
| 41 | 8M0036408 | 换挡轴 | SHAFT-SHIFT | 1 |
| 41 | 8240702 | 上换挡轴 | SHIFT SHAFT Upper | 1 |
| 41 | 8M0187153 | XL型上换挡轴 | SHAFT SHIFT UP XL | 1 |
| 42 | 48237 | 衬套 | BUSHING | 1 |
| 43 | 43585 | 联轴器 | COUPLING | 1 |
| - | 814195A97 | 衬垫套件 | GASKET SET | 1 |
| - | 809973A97 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 1 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 2 | 828506 | 交流发电机 | ALTERNATOR | 1 |
| 2 | 8M6013461 | 交流发电机 | ALTERNATOR | 1 |
| 3 | 82130155 | 螺钉 (M10 x 55) | SCREW (M10 X 55) | 2 |
| 3 | 82446155 | 螺钉(M10×55) | SCREW (M10 x 55) | 2 |
| 4 | 828507 | 皮带 | BELT | 1 |
| 4 | 828507Q | 蛇形皮带 | BELT-SERPENTINE | 1 |
| 5 | 45907 | 黄色塞 | PLUG Yellow | 1 |
| 6 | 828519A3 | 飞轮 | FLYWHEEL | 1 |
| 7 | 833132 | 皮带张紧器 | BELT TENSIONER | 1 |
| 8 | 1995670 | 螺钉 (M10 x 70) | SCREW (M10 x 70) (M10 X 70) | 1 |
| 9 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 1 |
| 9 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 1 |
| 10 | 832092 | 支架 | BRACKET | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 14360A43 | 燃油泵总成 | PUMP ASSEMBLY Fuel | 1 |
| 1 | 14360A78 | 燃油泵套件 | PUMP KIT Fuel | 1 |
| 2 | 42990A10 | 膜片组件 | DIAPHAGM KIT | 1 |
| 2 | 857005A1 | 膜片组件 | DIAPHRAGM KIT | 1 |
| 3 | NSS | NOT SOLD SEPARATE CHECK VALVE | 2 | |
| 4 | NSS | NOT SOLD SEPARATE CHECK VALVE | 2 | |
| 5 | NSS | NOT SOLD SEPARATE RETAINER | 2 | |
| 6 | NSS | NOT SOLD SEPARATE GASKET | 1 | |
| 7 | NSS | NOT SOLD SEPARATE CAP | 1 | |
| 8 | NSS | NOT SOLD SEPARATE SPRING | 1 | |
| 9 | NSS | NOT SOLD SEPARATE DIAPHRAGM | 2 | |
| 10 | NSS | NOT SOLD SEPARATE GASKET | 1 | |
| 11 | NSS | NOT SOLD SEPARATE SPRING | 1 | |
| 12 | NSS | NOT SOLD SEPARATE CAP | 1 | |
| 13 | 987691 | 衬垫 | GASKET | 1 |
| 13 | 8M0204705 | 衬垫@2 | GASKET @2 | 1 |
| 14 | 144303 | 底座 | BASE | 1 |
| 15 | 987752 | 安装板 | PLATE | 1 |
| 16 | 62910 | 90度弯头(0.125-27) | ELBOW (.125-27) (90 DEGREES) | 1 |
| 16 | 629101 | 90度弯头接头(0.125-27) | FITTING Elbow - 90 Degree (.125-27) | 1 |
| 17 | 82130050 | 螺钉 (M6 x 50) | SCREW (M6 x 50) (M6 X 1) | 2 |
| 18 | 82104540 | 螺钉 (M5 x 40) | SCREW (M5 x 40) (M5 X 0.8 X 40) | 2 |
| 19 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 19 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 20 | 83075780 | 管材(28.00英寸散装)(17英寸) | TUBING (28.00 Inches Bulk) (17 IN.) | 3 |
| 20 | 8M0108349 | 软管 (70英寸散装) | HOSE (70 Inches Bulk) | 3 |
| 21 | 822769 | 连接器 | CONNECTOR | 1 |
| 22 | 13607 | 接头 (随零件#25提供) | FITTING (INCLUDED WITH REF. #25) | 1 |
| 22 | 136071 | 弯头 | ELBOW | 1 |
| 23 | 18458A4 | 滤清器套件 | FILTER KIT | 1 |
| 23 | 18458Q4 | 燃油水分离滤清器 | FILTER Fuel-Water Separating | 1 |
| 24 | 828586 | 探头 | PROBE | 1 |
| 24 | 8M0204710 | 探头 | PROBE | 1 |
| 25 | 13170A3 | 底座 | BASE | 1 |
| 26 | 82130030 | 螺钉 (M6 x 30) | SCREW (M6 x 30) (M6 X 30) | 2 |
| 27 | 89771 | 直型连接器(.250-18) | CONNECTOR (.250-18) (STRAIGHT) | 1 |
| 27 | 89771Q2 | 连接器(.250-18) | CONNECTOR (.250-18) | 1 |
| - | 814195A97 | 衬垫套件 | GASKET SET | 1 |
| - | 809973A97 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 82130012 | 螺钉（M6 x 12） | SCREW (M6 x 12) | 3 |
| 2 | 828223 | 滑轮 | PULLEY | 1 |
| 3 | 828123A5 | 空气压缩机总成 | COMPRESSOR ASSEMBLY Air | 1 |
| 4 | 828293A3 | 簧片阀组件 | REED PLATE KIT | 1 |
| 5 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 4 |
| 5 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 4 |
| 6 | 67207 | O型圈（3.489 x 0.070） | O-RING (3.489 x .070) | 2 |
| 7 | 832804 | O型圈（2.739 x 0.070） | O-RING (2.739 x .070) | 1 |
| 8 | 828225 | 密封件 | SEAL | 1 |
| 9 | 81893450 | 螺钉(M8 x 50) | SCREW (M8 x 50) | 4 |
| 10 | 830018A1 | 软管 | HOSE | 1 |
| 11 | 828126A2 | 燃油导轨总成 | FUEL RAIL ASSEMBLY | 1 |
| 11 | 828126T2 | 燃油导轨-右舷 | FUEL RAIL-STBD | 1 |
| 12 | 828812 | 喷油器 | INJECTOR | 6 |
| 12 | 828812T | 空气喷射器 | AIR INJECTOR | 6 |
| - | 835083 | 密封套件 | SEAL KIT | 1 |
| - | 804875 | 密封套件 | SEAL KIT | 1 |
| 13 | 830020 | 软管 | HOSE | 1 |
| 14 | 831859 | 软管 | HOSE | 1 |
| 15 | 1350382 | 软管 (30英寸) | TUBING (30.00 Inches Bulk) (8 IN.) | 1 |
| 15 | 1350385 | 管材(33英寸整卷) | TUBING (33.00 Inches Bulk) | 1 |
| 16 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 16 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 17 | 828125A2 | 燃油导轨总成 | FUEL RAIL ASSEMBLY | 1 |
| 17 | 828125T2 | 燃油导轨-左舷 | FUEL RAIL-PORT | 1 |
| 18 | 830756109 | 软管 (57英寸) | HOSE (57.00 Inches Bulk) (11 IN.) | 1 |
| 18 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 19 | 826810 | 止回阀 | CHECK VALVE | 1 |
| 20 | 83075780 | 管材(28英寸整卷)(2-1/2英寸) | TUBING (28.00 Inches Bulk) (2-1/2 IN.) | 1 |
| 20 | 8M0108349 | 软管 (70英寸散装) | HOSE (70 Inches Bulk) | 1 |
| 21 | 9912688 | 管材(36.00英寸散装)(8英寸) | TUBING (36.00 Inches Bulk) (8 IN.) | 1 |
| 22 | 850241 | 卡箍 | CLAMP | AR |
| 23 | 834757 | 软管 | HOSE | 1 |
| 24 | 830019 | 软管 | HOSE | 1 |
| 25 | 833126 | 燃油冷却器 | COOLER Fuel | 1 |
| 26 | 833159 | 软管 | HOSE | 1 |
| 27 | 833160 | 成型软管 | HOSE (MOLDED) | 1 |
| 28 | 83476456 | 成型软管 | HOSE (MOLDED) | 1 |
| 28 | 83476463 | 软管 (32英寸) | TUBING (32.00 Inches Bulk) | 1 |
| 27 | 1350382 | 软管 (30英寸) | TUBING (30.00 Inches Bulk) (8 IN.) | 1 |
| 27 | 1350385 | 管材(33英寸整卷) | TUBING (33.00 Inches Bulk) | 1 |
| 28 | 1350382 | 软管 (30英寸) | TUBING (30.00 Inches Bulk) (19 IN.) | 1 |
| 28 | 1350385 | 管材(33英寸整卷) | TUBING (33.00 Inches Bulk) | 1 |
| 29 | 851974A1 | 止回阀 | CHECK VALVE | 1 |
| 30 | 1350382 | 软管 (30英寸) | TUBING (30.00 Inches Bulk) (8 IN.) | 1 |
| 30 | 1350385 | 管材(33英寸整卷) | TUBING (33.00 Inches Bulk) | 1 |
| 31 | 13791 | 卡箍(15.7) | CLAMP (15.7) | 2 |
| 31 | 8M0214911 | 卡箍@5 | CLAMP @5 | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 822442A51 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| - | 822442T77 | REF OB PB 99-02 | REF OB PB 99-02 | 1 |
| - | 822442A52 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| - | 822442T78 | REF OB PB 99-02 | REF OB PB 99-02 | 1 |
| - | 822442A53 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| - | 857113T2 | 齿轮箱 | GEAR HOUSING | 1 |
| - | 822442A54 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| - | 822442T82 | 灰色齿轮箱CXL | GEAR HSG GRAY CXL | 1 |
| - | 827754A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| - | 827755A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| - | 826353A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 822442A77 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| - | 822442T77 | REF OB PB 99-02 | REF OB PB 99-02 | 1 |
| - | 822442A78 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| - | 822442T78 | REF OB PB 99-02 | REF OB PB 99-02 | 1 |
| - | 822442A80 | 齿轮箱总成 (白色) | GEAR HOUSING ASSEMBLY (WHITE) | 1 |
| - | 822442T80 | 白色齿轮箱 | GEAR HSG -WHITE | 1 |
| - | 822442A81 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| - | 857113T2 | 齿轮箱 | GEAR HOUSING | 1 |
| - | 822442A82 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| - | 822442T82 | 灰色齿轮箱CXL | GEAR HSG GRAY CXL | 1 |
| - | 822442A85 | 齿轮箱总成 (白色) | GEAR HOUSING ASSEMBLY (WHITE) | 1 |
| - | 822442T85 | 白色齿轮箱C/R | GEAR HSG.-WH C/R | 1 |
| - | 822442A95 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| - | 822442T95 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| - | 822442A96 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| - | 822442T96 | 灰色齿轮箱 | GEAR HOUSING-GR | 1 |
| - | 827754A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| - | 827755A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| - | 826353A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 822442A25 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 822442A26 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 2 | 379721 | 销 | PIN | 1 |
| 3 | 821526 | 填充块 | FILLER BLOCK | 1 |
| 3 | 821526001 | 填充块 | FILLER BLOCK | 1 |
| 4 | 67892A1 | 磁吸式注油/放油塞套件 | FITTING KIT Magnetic, Plug Fill/Drain | 1 |
| 4 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 5 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 5 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 6 | 826134 | 阳极块 | ANODE | 2 |
| 6 | 826134Q | 阳极块 | ANODE | 2 |
| 7 | 4000333 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 1 |
| 8 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 8 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 9 | 42647A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 10 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 11 | 79953A2 | 螺丝套件(.375-16 x .250) | SCREW KIT (.375-16 x .250) | 1 |
| 11 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 12 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 12 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 13 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 14 | NSS | 不单独销售 (43-826287A1部件) | NOT SOLD SEPARATE (PART OF 43-826287A1 ) | 1 |
| 15 | 92721 | 垫圈(.965×0.630) | WASHER (.965 x .630) | 1 |
| 16 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 17 | 815921A4 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 18 | 8164641 | 油封 | SEAL Oil | 1 |
| 18 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 19 | 36318 | O型圈(0.799英寸) | O-RING (.799) | 2 |
| 19 | 8M0214927 | O型圈@5 | O RING @5 | 2 |
| 20 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 21 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| 22 | 824145 | 换挡轴(下部) | SHIFT SHAFT (LOWER) | 1 |
| 23 | 816472 | 传动轴(下) | DRIVESHAFT (LOWER) | 1 |
| 23 | 8M0140442 | 驱动轴 | DRIVESHAFT | 1 |
| 24 | 43037 | 键 | KEY | 1 |
| 24 | 8M0204723 | 键 | KEY | 1 |
| 25 | 42637A1 | 垫片组 | SHIM SET | AR |
| 25 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 26 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 26 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 27 | 824519 | 固定座 | RETAINER | 1 |
| 27 | 8245191 | 固定座 | RETAINER | 1 |
| 28 | 821759A2 | 托架总成 | CARRIER ASSEMBLY | 1 |
| 28 | 8M0214948 | 托架总成 | CARRIER ASSY | 1 |
| 29 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 29 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 30 | 16977 | 油封 | SEAL Oil | 1 |
| 31 | 89238 | 油封 | SEAL Oil | 1 |
| 32 | 817275A1 | 水泵壳体套件 | HOUSING KIT Water Pump | 1 |
| 33 | 816575A2 | 密封套件 | SEAL KIT | 1 |
| 34 | 430331 | 衬垫 | GASKET | 1 |
| 35 | 817277 | 衬垫 | GASKET | 1 |
| 35 | 8172771 | 水泵上垫片 | GASKET Water Pump, Upper | 1 |
| 36 | 817276 | 面板 | FACEPLATE | 1 |
| 36 | 8M0204709 | 面板 | FACEPLATE | 1 |
| 37 | 430262 | 叶轮 | IMPELLER | 1 |
| 37 | 43026T2 | 叶轮 | IMPELLER | 1 |
| 38 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 4 |
| 39 | 816597A1 | 联轴器总成 | COUPLING ASSEMBLY | 1 |
| 40 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 2 |
| 40 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 2 |
| 41 | 827755A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| 42 | 823902 | 联轴器 | COUPLING | 1 |
| - | 816575A5 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| - | 817275A6 | 水泵维修套件 | REPAIR KIT Water Pump | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 822442A83 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T77 | REF OB PB 99-02 | REF OB PB 99-02 | 1 |
| 1 | 822442A84 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T84 | 灰色齿轮箱 | GEAR HOUSING-GR | 1 |
| 1 | 822442A79 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T79 | 基础白色齿轮箱 | GEAR HSG-BASIC-WH | 1 |
| 2 | 379721 | 销 | PIN | 1 |
| 3 | 821526 | 填充块 | FILLER BLOCK | 1 |
| 3 | 821526001 | 填充块 | FILLER BLOCK | 1 |
| 4 | 67892A1 | 磁吸式注油/放油塞套件 | FITTING KIT Magnetic, Plug Fill/Drain | 1 |
| 4 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 5 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 5 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 6 | 826134 | 阳极块 | ANODE | 2 |
| 6 | 826134Q | 阳极块 | ANODE | 2 |
| 7 | 4000333 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 1 |
| 8 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 8 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 9 | 42647A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 10 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 11 | 79953A2 | 螺丝套件(.375-16 x .250) | SCREW KIT (.375-16 x .250) | 1 |
| 11 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 12 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 12 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 13 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 14 | 56762 | 扎带(4.00英寸) | TIE STRAP (4.00 Inches) | 1 |
| 15 | NSS | 不单独销售 (43-828695A1部件) | NOT SOLD SEPARATE (PART OF 43-828695A1) | 1 |
| 16 | 92721 | 垫圈(.965×0.630) | WASHER (.965 x .630) | 1 |
| 17 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 18 | 815921A4 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 19 | 8164641 | 油封 | SEAL Oil | 1 |
| 19 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 20 | 36318 | O型圈(0.799英寸) | O-RING (.799) | 2 |
| 20 | 8M0214927 | O型圈@5 | O RING @5 | 2 |
| 21 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 22 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| 23 | 824145 | 换挡轴(下部) | SHIFT SHAFT (LOWER) | 1 |
| 24 | 816472 | 传动轴(下) | DRIVESHAFT (LOWER) | 1 |
| 24 | 8M0140442 | 驱动轴 | DRIVESHAFT | 1 |
| 25 | 43037 | 键 | KEY | 1 |
| 25 | 8M0204723 | 键 | KEY | 1 |
| 26 | 42637A1 | 垫片组 | SHIM SET | AR |
| 26 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 27 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 27 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 28 | 824519 | 固定座 | RETAINER | 1 |
| 28 | 8245191 | 固定座 | RETAINER | 1 |
| 29 | 821759A4 | 托架总成 | CARRIER ASSEMBLY | 1 |
| 29 | 8M0214948 | 托架总成 | CARRIER ASSY | 1 |
| 30 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 30 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 31 | 66302 | 油封 | SEAL Oil | 1 |
| 31 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 32 | 66302 | 油封 | SEAL Oil | 1 |
| 32 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 33 | 817275A1 | 水泵壳体套件 | HOUSING KIT Water Pump | 1 |
| 34 | 816575A2 | 密封套件 | SEAL KIT | 1 |
| 35 | 430331 | 衬垫 | GASKET | 1 |
| 36 | 817277 | 衬垫 | GASKET | 1 |
| 36 | 8172771 | 水泵上垫片 | GASKET Water Pump, Upper | 1 |
| 37 | 817276 | 面板 | FACEPLATE | 1 |
| 37 | 8M0204709 | 面板 | FACEPLATE | 1 |
| 38 | 430262 | 叶轮 | IMPELLER | 1 |
| 38 | 43026T2 | 叶轮 | IMPELLER | 1 |
| 39 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 4 |
| 40 | 832942A1 | 联轴器总成 | COUPLING ASSEMBLY | 1 |
| 41 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 41 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 42 | 35027 | O型圈(1.046英寸) | O-RING (1.046) | 1 |
| 42 | 8M0204654 | O型圈 | O-RING | 1 |
| 43 | 827755A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| 44 | 823902 | 联轴器 | COUPLING | 1 |
| - | 816575A4 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| - | 817275A6 | 水泵维修套件 | REPAIR KIT Water Pump | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 822442A83 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T77 | REF OB PB 99-02 | REF OB PB 99-02 | 1 |
| 1 | 822442A84 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T84 | 灰色齿轮箱 | GEAR HOUSING-GR | 1 |
| 1 | 822442A79 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T79 | 基础白色齿轮箱 | GEAR HSG-BASIC-WH | 1 |
| 2 | 379721 | 销 | PIN | 1 |
| 3 | 821526 | 填充块 | FILLER BLOCK | 1 |
| 3 | 821526001 | 填充块 | FILLER BLOCK | 1 |
| 4 | 67892A1 | 磁吸式注油/放油塞套件 | FITTING KIT Magnetic, Plug Fill/Drain | 1 |
| 4 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 5 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 5 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 6 | 826134 | 阳极块 | ANODE | 2 |
| 6 | 826134Q | 阳极块 | ANODE | 2 |
| 7 | 4000333 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 1 |
| 8 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 8 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 9 | 42647A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 10 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 11 | 79953A2 | 螺丝套件(.375-16 x .250) | SCREW KIT (.375-16 x .250) | 1 |
| 11 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 12 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 12 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 13 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 14 | 56762 | 扎带(4.00英寸) | TIE STRAP (4.00 Inches) | 1 |
| 15 | NSS | 不单独销售 | NOT SOLD SEPARATE | 1 |
| 16 | 92721 | 垫圈(.965×0.630) | WASHER (.965 x .630) | 1 |
| 17 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 18 | 815921A4 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 19 | 8164641 | 油封 | SEAL Oil | 1 |
| 19 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 20 | 36318 | O型圈(0.799英寸) | O-RING (.799) | 2 |
| 20 | 8M0214927 | O型圈@5 | O RING @5 | 2 |
| 21 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 22 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| 23 | 824145 | 换挡轴(下部) | SHIFT SHAFT (LOWER) | 1 |
| 24 | 816472 | 传动轴(下) | DRIVESHAFT (LOWER) | 1 |
| 24 | 8M0140442 | 驱动轴 | DRIVESHAFT | 1 |
| 25 | 43037 | 键 | KEY | 1 |
| 25 | 8M0204723 | 键 | KEY | 1 |
| 26 | 42637A1 | 垫片组 | SHIM SET | AR |
| 26 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 27 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 27 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 28 | 824519 | 固定座 | RETAINER | 1 |
| 28 | 8245191 | 固定座 | RETAINER | 1 |
| 29 | 821759A4 | 托架总成 | CARRIER ASSEMBLY | 1 |
| 29 | 8M0214948 | 托架总成 | CARRIER ASSY | 1 |
| 30 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 30 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 31 | 66302 | 油封 | SEAL Oil | 1 |
| 31 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 32 | 66302 | 油封 | SEAL Oil | 1 |
| 32 | 8M0214939 | 油封@3 | SEAL @3 | 1 |
| 33 | 817275A1 | 水泵壳体套件 | HOUSING KIT Water Pump | 1 |
| 34 | 816575A2 | 密封套件 | SEAL KIT | 1 |
| 35 | 430331 | 衬垫 | GASKET | 1 |
| 36 | 817277 | 衬垫 | GASKET | 1 |
| 36 | 8172771 | 水泵上垫片 | GASKET Water Pump, Upper | 1 |
| 37 | 817276 | 面板 | FACEPLATE | 1 |
| 37 | 8M0204709 | 面板 | FACEPLATE | 1 |
| 38 | 430262 | 叶轮 | IMPELLER | 1 |
| 38 | 43026T2 | 叶轮 | IMPELLER | 1 |
| 39 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 4 |
| 40 | 832942A1 | 联轴器总成 | COUPLING ASSEMBLY | 1 |
| 41 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 41 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 1 |
| 42 | 35027 | O型圈(1.046英寸) | O-RING (1.046) | 1 |
| 42 | 8M0204654 | O型圈 | O-RING | 1 |
| 43 | 827754A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| 43 | 827755A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| 44 | 823902 | 联轴器 | COUPLING | 1 |
| - | 816575A4 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| - | 817275A6 | 水泵维修套件 | REPAIR KIT Water Pump | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 822442A25 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 822442A26 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 2 | 379721 | 销 | PIN | 1 |
| 3 | 821526 | 填充块 | FILLER BLOCK | 1 |
| 3 | 821526001 | 填充块 | FILLER BLOCK | 1 |
| 4 | 67892A1 | 磁吸式注油/放油塞套件 | FITTING KIT Magnetic, Plug Fill/Drain | 1 |
| 4 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 5 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 5 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 6 | 826134 | 阳极块 | ANODE | 2 |
| 6 | 826134Q | 阳极块 | ANODE | 2 |
| 7 | 4000333 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 1 |
| 8 | 8268336 | 螺母 (M6) | NUT (M6) | 1 |
| 8 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 9 | 42647A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 10 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 11 | 79953A2 | 螺丝套件(.375-16 x .250) | SCREW KIT (.375-16 x .250) | 1 |
| 11 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 12 | 19183 | 纤维垫圈 | WASHER Fiber | 1 |
| 12 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 1 |
| 13 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 14 | NSS | 不单独销售 (43-826181A2部件) | NOT SOLD SEPARATE (PART OF 43-826181A2) | 1 |
| 15 | 92721 | 垫圈(.965×0.630) | WASHER (.965 x .630) | 1 |
| 16 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 17 | 815921A4 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 18 | 8164641 | 油封 | SEAL Oil | 1 |
| 18 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 19 | 36318 | O型圈(0.799英寸) | O-RING (.799) | 2 |
| 19 | 8M0214927 | O型圈@5 | O RING @5 | 2 |
| 20 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 2 |
| 21 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| 22 | 824145 | 换挡轴(下部) | SHIFT SHAFT (LOWER) | 1 |
| 23 | 816472 | 传动轴(下) | DRIVESHAFT (LOWER) | 1 |
| 23 | 8M0140442 | 驱动轴 | DRIVESHAFT | 1 |
| 24 | 43037 | 键 | KEY | 1 |
| 24 | 8M0204723 | 键 | KEY | 1 |
| 25 | 42637A1 | 垫片组 | SHIM SET | AR |
| 25 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 26 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 26 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 27 | 824519 | 固定座 | RETAINER | 1 |
| 27 | 8245191 | 固定座 | RETAINER | 1 |
| 28 | 821759A2 | 托架总成 | CARRIER ASSEMBLY | 1 |
| 28 | 8M0214948 | 托架总成 | CARRIER ASSY | 1 |
| 29 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 29 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 30 | 16977 | 油封 | SEAL Oil | 1 |
| 31 | 89238 | 油封 | SEAL Oil | 1 |
| 32 | 817275A1 | 水泵壳体套件 | HOUSING KIT Water Pump | 1 |
| 33 | 816575A2 | 密封套件 | SEAL KIT | 1 |
| 34 | 430331 | 衬垫 | GASKET | 1 |
| 35 | 817277 | 衬垫 | GASKET | 1 |
| 35 | 8172771 | 水泵上垫片 | GASKET Water Pump, Upper | 1 |
| 36 | 817276 | 面板 | FACEPLATE | 1 |
| 36 | 8M0204709 | 面板 | FACEPLATE | 1 |
| 37 | 430262 | 叶轮 | IMPELLER | 1 |
| 37 | 43026T2 | 叶轮 | IMPELLER | 1 |
| 38 | 1993716 | 螺钉(M6 x 16) | SCREW (M6 x 16) | 4 |
| 39 | 816597A1 | 联轴器总成 | COUPLING ASSEMBLY | 1 |
| 40 | 21836 | O型圈(.796 x .139) | O-RING (.796 x .139) | 2 |
| 40 | 8M0204645 | O型圈(.796 x .139) | O-RING (.796 x .139) | 2 |
| 41 | 827754A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| 41 | 827755A1 | 传动轴延长套件 | EXTENSION KIT Driveshaft | 1 |
| 42 | 823902 | 联轴器 | COUPLING | 1 |
| - | 816575A5 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| - | 817275A6 | 水泵维修套件 | REPAIR KIT Water Pump | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 822442A83 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T77 | REF OB PB 99-02 | REF OB PB 99-02 | 1 |
| 1 | 822442A84 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T84 | 灰色齿轮箱 | GEAR HOUSING-GR | 1 |
| 1 | 822442A79 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T79 | 基础白色齿轮箱 | GEAR HSG-BASIC-WH | 1 |
| 61 | 815480 | 推力轴承 | BEARING Thrust | 1 |
| 62 | 815481 | 止推垫片 | THRUST WASHER | 1 |
| 63 | 828831A1 | 轴承适配器总成 | ADAPTER ASSEMBLY Bearing | 1 |
| 63 | 828831A3 | 轴承适配器总成 | ADAPTER ASSEMBLY Bearing | 1 |
| 64 | 814653 | 滚针轴承总成 | BEARING ASSEMBLY Needle Rollers | 1 |
| 64 | 814653T | 滚针轴承总成 | BEARING ASSEMBLY Needle Rollers | 1 |
| 65 | 18448 | 止推垫片 | THRUST WASHER | 2 |
| 66 | 15842 | 推力轴承 | BEARING Thrust | 2 |
| 67 | 8182911 | 推力座圈 | RACE Thrust | 2 |
| 68 | 814605 | 定位器 | KEEPER | 2 |
| 69 | 31534 | O型圈 | O-RING | 1 |
| 69 | 8M0214920 | O型圈 | O RING | 1 |
| 70 | 818290A8 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 70 | 818290T8 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 71 | 30956 | 滚针轴承 | BEARING Needle | 1 |
| 71 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 72 | 14077 | 油封(内侧) | SEAL Oil (INSIDE) | 1 |
| 73 | 76868 | 油封(外侧) | SEAL (OUTSIDE) | 1 |
| 73 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 1 |
| 74 | 18323 | 锁紧垫圈 | TAB WASHER | 1 |
| 75 | 79448 | 固定座 | RETAINER | 1 |
| 75 | 8M2011027 | 固定座 | RETAINER | 1 |
| 76 | 76214A5 | 阳极套件 | ANODE KIT | 1 |
| 76 | 76214Q5 | 阳极套件 | ANODE KIT | 1 |
| 77 | 806327 | 螺钉(.437-14 x 1.750) | SCREW (.437-14 x 1.750) | 1 |
| 77 | 8M0204686 | 螺钉 | SCREW | 1 |
| 78 | 835467 | 推力毂 | THRUST HUB | 1 |
| 78 | 835467Q01 | 止推垫片套件 | THRUST WASHER KIT | 1 |
| 79 | 423511 | 齿形锁紧垫圈 | LOCKWASHER Toothed | 1 |
| 80 | 31211A2 | 花键垫圈 | WASHER Splined | 1 |
| 80 | 31211Q03 | 垫圈总成 | WASHER ASSEMBLY | 1 |
| 81 | 816629 | 锁紧垫圈 | TAB WASHER | 1 |
| 81 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 82 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 82 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| - | 816575A4 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 822442A25 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 822442A26 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 59 | 15841 | 滚柱轴承 | BEARING Roller | 1 |
| 60 | 17616 | 推力环 | THRUST RING | 1 |
| 61 | 818292A1 | 轴承适配器总成 | ADAPTER ASSEMBLY Bearing | 1 |
| 62 | 814653 | 滚针轴承总成 | BEARING ASSEMBLY Needle Rollers | 1 |
| 62 | 814653T | 滚针轴承总成 | BEARING ASSEMBLY Needle Rollers | 1 |
| 63 | 18448 | 止推垫片 | THRUST WASHER | 2 |
| 64 | 15842 | 推力轴承 | BEARING Thrust | 2 |
| 65 | 8182911 | 推力座圈 | RACE Thrust | 2 |
| 66 | 814605 | 定位器 | KEEPER | 2 |
| 67 | 31534 | O型圈 | O-RING | 1 |
| 67 | 8M0214920 | O型圈 | O RING | 1 |
| 68 | 818290A1 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 68 | 818290T1 | 轴承座总成 | CARRIER ASSY-BRG | 1 |
| 69 | 30956 | 滚针轴承 | BEARING Needle | 1 |
| 69 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 70 | 14077 | 油封(内侧) | SEAL Oil (INSIDE) | 1 |
| 71 | 76868 | 油封(外侧) | SEAL (OUTSIDE) | 1 |
| 71 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 1 |
| 72 | 18323 | 锁紧垫圈 | TAB WASHER | 1 |
| 73 | 79448 | 固定座 | RETAINER | 1 |
| 73 | 8M2011027 | 固定座 | RETAINER | 1 |
| 74 | 76214A5 | 阳极套件 | ANODE KIT | 1 |
| 74 | 76214Q5 | 阳极套件 | ANODE KIT | 1 |
| 75 | 806327 | 螺钉(.437-14 x 1.750) | SCREW (.437-14 x 1.750) | 1 |
| 75 | 8M0204686 | 螺钉 | SCREW | 1 |
| 76 | 835467 | 推力毂 | THRUST HUB | 1 |
| 76 | 835467Q01 | 止推垫片套件 | THRUST WASHER KIT | 1 |
| 77 | 423511 | 齿形锁紧垫圈 | LOCKWASHER Toothed | 1 |
| 78 | 31211A2 | 花键垫圈 | WASHER Splined | 1 |
| 78 | 31211Q03 | 垫圈总成 | WASHER ASSEMBLY | 1 |
| 79 | 816629 | 锁紧垫圈 | TAB WASHER | 1 |
| 79 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 80 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 80 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| - | 816575A5 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 822442A83 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T77 | REF OB PB 99-02 | REF OB PB 99-02 | 1 |
| 1 | 822442A84 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T84 | 灰色齿轮箱 | GEAR HOUSING-GR | 1 |
| 1 | 822442A79 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T79 | 基础白色齿轮箱 | GEAR HSG-BASIC-WH | 1 |
| 45 | 823903 | 换挡曲柄 | SHIFT CRANK | 1 |
| 45 | 8M0226861 | 换挡曲柄 | CRANK-SHIFTER | 1 |
| 46 | 19755A7 | 阀芯总成 | SPOOL ASSEMBLY | 1 |
| 46 | 8M0235940 | 阀芯总成 | SPOOL ASSY | 1 |
| 47 | 44491A1 | 垫片组 | SHIM SET | AR |
| 47 | 8M0063266 | 垫片组 | SHIM SET | AR |
| 48 | 828830A2 | 轴承适配器总成 | ADAPTER ASSEMBLY Bearing | 1 |
| 49 | 814653 | 滚针轴承总成 | BEARING ASSEMBLY Needle Rollers | 1 |
| 49 | 814653T | 滚针轴承总成 | BEARING ASSEMBLY Needle Rollers | 1 |
| 50 | 815481 | 止推垫片 | THRUST WASHER | 1 |
| 51 | 815480 | 推力轴承 | BEARING Thrust | 1 |
| 52 | 828696A2 | 倒车齿轮总成 | GEAR ASSEMBLY Reverse | 1 |
| 52 | 828696T2 | 倒挡齿轮(12/21齿) | GEAR Reverse (12/21) | 1 |
| 53 | 15844 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 54 | 30893 | 弹簧 | SPRING | 1 |
| 55 | 828288 | 滑动离合器 | SLIDING CLUTCH | 1 |
| 55 | 859340T | 离合器 | CLUTCH | 1 |
| 56 | 30632 | 十字销 | PIN Cross | 1 |
| 56 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 57 | 828356 | 定位销 | PIN Detent | 1 |
| 58 | 824111 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 58 | 8M0140448 | 左螺旋桨轴 | PROP SHAFT LH | 1 |
| 59 | 828695A1 | 前进/小齿轮组(12/21齿)(含小齿轮) | GEAR SET Forward/Pinion (12/21) (INCLUDES PINION) | 1 |
| 60 | 1761514 | 垫片(0.206) | SPACER SHIM (.206) | AR |
| 60 | 1761515 | 垫片(0.208) | SPACER SHIM (.208) | AR |
| 60 | 1761516 | 垫片(0.210) | SPACER SHIM (.210) | AR |
| 60 | 1761517 | 垫片(0.212) | SPACER SHIM (.212) | AR |
| 60 | 1761518 | 垫片(0.214) | SPACER SHIM (.214) | AR |
| 60 | 1761519 | 垫片(0.216) | SPACER SHIM (.216) | AR |
| 60 | 1761520 | 垫片(0.218) | SPACER SHIM (.218) | AR |
| 60 | 1761521 | 垫片(0.220) | SPACER SHIM (.220) | AR |
| 60 | 1761522 | 垫片(0.222) | SPACER SHIM (.222) | AR |
| 60 | 1761523 | 垫片(0.224) | SPACER SHIM (.224) | AR |
| 60 | 1761524 | 垫片(0.226) | SPACER SHIM (.226) | AR |
| 60 | 1761525 | 垫片(0.228) | SPACER SHIM (.228) | AR |
| 60 | 1761526 | 垫片(0.230) | SPACER SHIM (.230) | AR |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 822442A25 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 822442A26 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 43 | 823903 | 换挡曲柄 | SHIFT CRANK | 1 |
| 43 | 8M0226861 | 换挡曲柄 | CRANK-SHIFTER | 1 |
| 44 | 818349A1 | 阀芯套件 | SPOOL KIT | 1 |
| 44 | 818349T1 | 1 | ||
| 45 | 47397A1 | 垫片组 | SHIM SET | AR |
| 46 | 35928A1 | 圆锥滚子轴承总成 | BEARING ASSEMBLY Taper Roller | 1 |
| 46 | 35928T1 | 圆锥滚子轴承总成 | BEARING ASSEMBLY Tapered Roller | 1 |
| 46 | 828439A2 | 圆锥滚子轴承总成 | BEARING ASSEMBLY Taper Roller | 1 |
| 47 | 826181A2 | 前进齿轮组(含小齿轮) | GEAR SET Forward (INCLUDES PINION GEAR) | 1 |
| 48 | 30895 | 滚针轴承 | BEARING Needle | 1 |
| 48 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 49 | 30893 | 弹簧 | SPRING | 1 |
| 50 | 824112 | 滑动离合器 | SLIDING CLUTCH | 1 |
| 50 | 853594T | 离合器 | CLUTCH | 1 |
| 51 | 78909 | 定位销 | PIN Detent | 1 |
| 52 | 30632 | 十字销 | PIN Cross | 1 |
| 52 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 53 | 824110 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 53 | 8M0140440 | 右螺旋桨轴 | PROPSHAFT RH | 1 |
| 54 | 826182A1 | 倒车齿轮总成 | GEAR ASSEMBLY Reverse | 1 |
| 55 | 824108 | 隔套 | SPACER | 1 |
| 56 | 681001 | 止推环 | RING Thrust | 1 |
| 57 | 88957 | 滚珠轴承总成 | BEARING ASSEMBLY Ball | 1 |
| 57 | 88957T | 滚珠轴承 | BEARING Ball | 1 |
| 58 | 31534 | O型圈 | O-RING | 1 |
| 58 | 8M0214920 | O型圈 | O RING | 1 |
| 59 | 818763A11 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 59 | 818763T11 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 60 | 30956 | 滚针轴承 | BEARING Needle | 1 |
| 60 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 61 | 14077 | 油封(内侧) | SEAL Oil (INSIDE) | 1 |
| 62 | 76868 | 油封(外侧) | SEAL (OUTSIDE) | 1 |
| 62 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 1 |
| 63 | 18323 | 锁紧垫圈 | TAB WASHER | 1 |
| 64 | 79448 | 固定座 | RETAINER | 1 |
| 64 | 8M2011027 | 固定座 | RETAINER | 1 |
| 65 | 76214A5 | 阳极套件 | ANODE KIT | 1 |
| 65 | 76214Q5 | 阳极套件 | ANODE KIT | 1 |
| 66 | 806327 | 螺钉(.437-14 x 1.750) | SCREW (.437-14 x 1.750) | 1 |
| 66 | 8M0204686 | 螺钉 | SCREW | 1 |
| 67 | 835467 | 推力毂 | THRUST HUB | 1 |
| 67 | 835467Q01 | 止推垫片套件 | THRUST WASHER KIT | 1 |
| 68 | 423511 | 齿形锁紧垫圈 | LOCKWASHER Toothed | 1 |
| 69 | 31211A2 | 花键垫圈 | WASHER Splined | 1 |
| 69 | 31211Q03 | 垫圈总成 | WASHER ASSEMBLY | 1 |
| 70 | 816629 | 锁紧垫圈 | TAB WASHER | 1 |
| 70 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 71 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 71 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| - | 816575A5 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 822442A83 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T77 | REF OB PB 99-02 | REF OB PB 99-02 | 1 |
| 1 | 822442A84 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T84 | 灰色齿轮箱 | GEAR HOUSING-GR | 1 |
| 1 | 822442A79 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 822442T79 | 基础白色齿轮箱 | GEAR HSG-BASIC-WH | 1 |
| 45 | 823903 | 换挡曲柄 | SHIFT CRANK | 1 |
| 45 | 8M0226861 | 换挡曲柄 | CRANK-SHIFTER | 1 |
| 46 | 19755A7 | 阀芯总成 | SPOOL ASSEMBLY | 1 |
| 46 | 8M0235940 | 阀芯总成 | SPOOL ASSY | 1 |
| 47 | 44491A1 | 垫片组 | SHIM SET | AR |
| 47 | 8M0063266 | 垫片组 | SHIM SET | AR |
| 48 | 828168A2 | 前进齿轮总成(含小齿轮) | GEAR ASSEMBLY Forward (INCLUDES PINION GEAR) | 1 |
| 48 | 859321A3 | 前进/小齿轮组(12/21齿) | GEAR SET Forward/Pinion (12/21) | 1 |
| 48 | 828170A2 | 前进齿轮与小齿轮组(含小齿轮) | GEAR SET Forward And Pinion (INCLUDES PINION GEAR) | 1 |
| 48 | 878611A2 | 前进/小齿轮组 | GEAR SET Forward/Pinion | 1 |
| 49 | 30894A1 | 圆锥轴承组 | BEARING SET Cup And Cone | 1 |
| 50 | 30895 | 滚针轴承 | BEARING Needle | 1 |
| 50 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 51 | 30893 | 弹簧 | SPRING | 1 |
| 52 | 828288 | 滑动离合器 | SLIDING CLUTCH | 1 |
| 52 | 859340T | 离合器 | CLUTCH | 1 |
| 53 | 828356 | 定位销 | PIN Detent | 1 |
| 54 | 30632 | 十字销 | PIN Cross | 1 |
| 54 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 55 | 824110 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 55 | 8M0140440 | 右螺旋桨轴 | PROPSHAFT RH | 1 |
| 56 | 828169A1 | 倒车齿轮总成 | GEAR ASSEMBLY Reverse | 1 |
| 56 | 859322A1 | 倒挡齿轮(12/21齿) | GEAR Reverse (12/21) | 1 |
| 56 | 828171A1 | 倒挡齿轮 | GEAR Reverse | 1 |
| 56 | 844147T01 | 倒挡齿轮 | GEAR Reverse | 1 |
| 57 | 824108 | 隔套 | SPACER | 1 |
| 58 | 681001 | 止推环 | RING Thrust | 1 |
| 59 | 88957 | 滚珠轴承总成 | BEARING ASSEMBLY Ball | 1 |
| 59 | 88957T | 滚珠轴承 | BEARING Ball | 1 |
| 60 | 31534 | O型圈 | O-RING | 1 |
| 60 | 8M0214920 | O型圈 | O RING | 1 |
| 61 | 818763A11 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 61 | 818763T11 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 62 | 30956 | 滚针轴承 | BEARING Needle | 1 |
| 62 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 63 | 14077 | 油封(内侧) | SEAL Oil (INSIDE) | 1 |
| 64 | 76868 | 油封(外侧) | SEAL (OUTSIDE) | 1 |
| 64 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 1 |
| 65 | 18323 | 锁紧垫圈 | TAB WASHER | 1 |
| 66 | 79448 | 固定座 | RETAINER | 1 |
| 66 | 8M2011027 | 固定座 | RETAINER | 1 |
| 67 | 76214A5 | 阳极套件 | ANODE KIT | 1 |
| 67 | 76214Q5 | 阳极套件 | ANODE KIT | 1 |
| 68 | 806327 | 螺钉(.437-14 x 1.750) | SCREW (.437-14 x 1.750) | 1 |
| 68 | 8M0204686 | 螺钉 | SCREW | 1 |
| 69 | 835467 | 推力毂 | THRUST HUB | 1 |
| 69 | 835467Q01 | 止推垫片套件 | THRUST WASHER KIT | 1 |
| 70 | 423511 | 齿形锁紧垫圈 | LOCKWASHER Toothed | 1 |
| 71 | 31211A2 | 花键垫圈 | WASHER Splined | 1 |
| 71 | 31211Q03 | 垫圈总成 | WASHER ASSEMBLY | 1 |
| 72 | 816629 | 锁紧垫圈 | TAB WASHER | 1 |
| 72 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 73 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 73 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| - | 816575A4 | 齿轮箱密封套件 | SEAL KIT Gear Housing | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 822442A25 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 822442A26 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 43 | 823903 | 换挡曲柄 | SHIFT CRANK | 1 |
| 43 | 8M0226861 | 换挡曲柄 | CRANK-SHIFTER | 1 |
| 44 | 818349A1 | 阀芯套件 | SPOOL KIT | 1 |
| 44 | 818349T1 | 1 | ||
| 45 | 47397A1 | 垫片组 | SHIM SET | AR |
| 46 | 815362A1 | 轴承适配器总成 | ADAPTER ASSEMBLY Bearing | 1 |
| 46 | 815362T1 | 轴承适配器总成 | ADAPTER ASSEMBLY Bearing | 1 |
| 46 | 828830A2 | 轴承适配器总成 | ADAPTER ASSEMBLY Bearing | 1 |
| 47 | 814653 | 滚针轴承总成 | BEARING ASSEMBLY Needle Rollers | 1 |
| 47 | 814653T | 滚针轴承总成 | BEARING ASSEMBLY Needle Rollers | 1 |
| 48 | 815481 | 止推垫片 | THRUST WASHER | 1 |
| 49 | 815480 | 推力轴承 | BEARING Thrust | 1 |
| 50 | 826288A1 | 倒车齿轮总成 | GEAR ASSEMBLY Reverse | 1 |
| 50 | 826288T1 | 倒挡齿轮总成 | GEAR ASSY-REVERSE | 1 |
| 51 | 815482 | 滚柱轴承 | BEARING Roller | 1 |
| 52 | 30893 | 弹簧 | SPRING | 1 |
| 53 | 824112 | 滑动离合器 | SLIDING CLUTCH | 1 |
| 53 | 853594T | 离合器 | CLUTCH | 1 |
| 54 | 30632 | 十字销 | PIN Cross | 1 |
| 54 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 55 | 78909 | 定位销 | PIN Detent | 1 |
| 56 | 824111 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 56 | 8M0140448 | 左螺旋桨轴 | PROP SHAFT LH | 1 |
| 57 | 826287A1 | 前进齿轮总成(含小齿轮) | GEAR ASSEMBLY Forward (INCLUDES PINION) | 1 |
| 58 | 1761514 | 垫片(0.206) | SPACER SHIM (.206) | AR |
| 58 | 1761515 | 垫片(0.208) | SPACER SHIM (.208) | AR |
| 58 | 1761516 | 垫片(0.210) | SPACER SHIM (.210) | AR |
| 58 | 1761517 | 垫片(0.212) | SPACER SHIM (.212) | AR |
| 58 | 1761518 | 垫片(0.214) | SPACER SHIM (.214) | AR |
| 58 | 1761519 | 垫片(0.216) | SPACER SHIM (.216) | AR |
| 58 | 1761520 | 垫片(0.218) | SPACER SHIM (.218) | AR |
| 58 | 1761521 | 垫片(0.220) | SPACER SHIM (.220) | AR |
| 58 | 1761522 | 垫片(0.222) | SPACER SHIM (.222) | AR |
| 58 | 1761523 | 垫片(0.224) | SPACER SHIM (.224) | AR |
| 58 | 1761524 | 垫片(0.226) | SPACER SHIM (.226) | AR |
| 58 | 1761525 | 垫片(0.228) | SPACER SHIM (.228) | AR |
| 58 | 1761526 | 垫片(0.230) | SPACER SHIM (.230) | AR |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 19674A1 | 拉绳开关总成 | SWITCH ASSEMBLY Lanyard | 1 |
| 1 | 19674A07 | 开关/拉绳套件 | SWITCH/LANYARD KIT | 1 |
| 2 | 18303 | 螺钉 (.190-16 x 1.750) 不锈钢 | SCREW (.190-16 x 1.750) Stainless Steel | 2 |
| 3 | 813679 | 适配器 | ADAPTER | 1 |
| 4 | 15920A54 | 拉绳总成 | LANYARD ASSEMBLY | 1 |
| 4 | 15920Q54 | 拉绳总成 | LANYARD ASSEMBLY | 1 |
| 5 | 32866 | 不锈钢螺钉 (#10-32 x 2.00) | SCREW (#10-32 x 2.00) Stainless Steel (10-32 X 2 IN.) | 2 |
| 6 | 18321 | 安装夹 | CLAMP Mounting | 1 |
| 7 | 24676 | 垫圈 (.200 x .440 x .032) | WASHER (.200 x .440 x .032) | 2 |
| 8 | 68219 | 不锈钢螺母 (#10-32) | NUT (#10-32) Stainless Steel (10-32) | 4 |
| 9 | 79146 | 固定座 | RETAINER | 3 |
| 10 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 16 |
| 10 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 16 |
| 11 | 812497A2 | 二极管总成 | DIODE ASSEMBLY | 1 |
| 11 | 898289A72 | 双拉绳二极管套件 | DIODE KIT-LANYARD Dual | 1 |
| 12 | 11149A2 | 线缆总成 (6英寸) | CABLE ASSEMBLY (6.00 Inches) (6 IN.) | 1 |
| 13 | 835360A1 | 警报仪表套件 | WARNING GAUGE KIT | 1 |
| 13 | 859699A1 | 警报仪表套件 | GAUGE KIT-WARNING | 1 |
| 14 | 850020 | 卡箍 | CLAMP | 1 |
| 15 | 26419 | 黄铜螺母 (#8-32) | NUT (#8-32) Brass | 1 |
| 16 | 825361 | 星形锁紧垫圈(#8) | LOCKWASHER Star (#8) | 1 |
| 17 | 72729 | 楔形底座灯泡(14V - 1.9W) | LIGHT BULB Wedge Base (14V - 1.9W) | 4 |
| 18 | 79888 | 灯泡插座 | SOCKET Light Bulb | 4 |
| 19 | 835359A1 | 电缆总成(20.00英尺) | CABLE ASSEMBLY (20.00 Feet) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 80917097 | 200 DFI 3.0L | 200 DFI 3.0L | 1 |
| - | 830169A97 | 贴花套件 | DECAL SET | 1 |
| - | 824105A97 | 贴花套件 | DECAL SET | 1 |
| - | 83016957 | 装饰贴条 | DECAL STRIPING | 1 |
| - | 830169A25 | 贴条-25英尺卷 | STRIPING-25FTROLL | 1 |
| - | 824104A97 | 贴花套件 | DECAL SET | 1 |
| - | 824106A97 | 贴花套件 | DECAL SET | 1 |
| - | 851989A97 | 贴花套件 | DECAL SET | 1 |
| - | 824911 | 装饰贴条 | DECAL STRIPING | 1 |
| - | 824911A25 | 条纹贴花 | DECAL Striping | 1 |
| - | 10130971 | 用户手册 | OWNERS MANUAL | 1 |
| - | 10130972 | 用户手册 | MANUAL-OWNERS | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 830889A1 | 油箱总成 | TANK ASSEMBLY Oil | 1 |
| 2 | 8260841 | 隔套 | SPACER | 1 |
| 3 | 58376 | 螺钉 (0.164-18 x 0.375) | SCREW (.164-18 x .375) (.164-18 X .375) | 1 |
| 4 | 72761 | 不锈钢垫圈(.203 x .562 x .060) | WASHER (.203 x .562 x .060) Stainless Steel | 1 |
| 5 | 814449A3 | 盖总成 | CAP ASSEMBLY | 1 |
| 6 | 42999 | 衬垫 | GASKET | 1 |
| 6 | 42999T | 衬垫 | GASKET | 1 |
| 7 | 12886A7 | 开关总成 | SWITCH ASSEMBLY | 1 |
| 8 | 83476945 | 螺钉(M8×45) | SCREW (M8 X 45) | 2 |
| 9 | 834758 | 衬套 | BUSHING | 2 |
| 10 | 833155 | 护孔环 | GROMMET | 2 |
| 11 | 834756 | 护孔环 | GROMMET | 2 |
| 12 | 19064 | 衬套 | BUSHING | 2 |
| 13 | 83476935 | 螺钉 (M8 x 35) | SCREW (M8 X 35) | 1 |
| 14 | 56720 | 垫圈(0.330×0.750×0.060)不锈钢 | WASHER (.330 x .750 x .060) Stainless Steel | 1 |
| 15 | 825380 | 护孔环 | GROMMET | 1 |
| 15 | 825380001 | 护孔环 | GROMMET | 1 |
| 16 | 19064 | 衬套 | BUSHING | 1 |
| 17 | 830756109 | 软管(57英寸整卷)(8英寸段) | HOSE (57.00 Inches Bulk) (8 IN.) | 1 |
| 17 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 18 | 424254 | 接头 | FITTING | 1 |
| 18 | 8M0207780 | 接头 | FITTING | 1 |
| 19 | 99439 | 软管(114.00英寸) | HOSE (114.00 Inches) | 1 |
| 20 | 87421 | 油箱 | TANK | 1 |
| 21 | 43298A2 | 盖总成 | CAP ASSEMBLY | 1 |
| 22 | 11332 | O型圈(2.225 x .210) | O-RING (2.225 x .210) | 1 |
| 23 | 816190A3 | 外壳总成适配器 | HOUSING ASSEMBLY Adapter | 1 |
| 23 | 816190A4 | 机油收集器总成(无传感器) | OIL PICK UP ASSEMBLY Without Sender | 1 |
| 24 | 11332 | O型圈(2.225 x .210) | O-RING (2.225 x .210) | 1 |
| 25 | 99802 | 管 | TUBE | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0231193 | 动力升降总成 | POWER TRIM ASSEMBLY | 1 |
| 1 | 8M0225363 | 电机套件 | MOTOR KIT | 1 |
| 2 | 8M0225369 | 阀套件 | VALVE KIT | 1 |
| 3 | 8M0225371 | 手动释放套件 | MANUAL RELEASE KIT | 1 |
| 4 | 8M0245633 | 倾斜油缸套件 | TILT CYLINDER KIT | 1 |
| 5 | 8M0225370 | 枢轴销套件 | PIVOT PIN KIT | 1 |
| 6 | 8M0244575 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 7 | 8M0244425 | 销杆眼套件 | PIN ROD EYE KIT | 1 |
| 8 | 8M0232231 | 螺钉螺母套件 | SCREW NUT KIT | 1 |
| 9 | 8M0225373 | 记忆活塞套件 | MEMORY PISTON KIT | 1 |
| 10 | 8M0225368 | 储液罐套件 | RESERVOIR KIT | 1 |
| 11 | 8M0174135 | 储液罐塞总成 | PLUG RESERVOIR ASSEMBLY | 1 |
| 12 | 8M0237525 | 泵套件 | PUMP KIT | 1 |
| 13 | 8M0225367 | 升降杆套件 | TRIM ROD KIT | 1 |
| 14 | 8M0242846 | 升降杆套件 | TRIM ROD KIT | 1 |
| 15 | 8M0225372 | 重建套件 | REBUILD KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 826729A2 | 升降倾斜总成 | TRIM AND TILT ASSEMBLY | 1 |
| - | 855998A11 | 动力调整套件 | POWER TRIM KIT | 1 |
| 1 | 811604F | 歧管总成 | MANIFOLD ASSEMBLY | 1 |
| 2 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 9 |
| 3 | 823552F | 气缸总成 | CYLINDER ASSEMBLY | 1 |
| 3 | 880952A03 | ORD 8M0078330 | ORD 8M0078330 | 1 |
| 4 | 823553 | 配平活塞杆套件 | ROD KIT Trim Piston | 1 |
| 4 | 823553T | 升降活塞杆 | ROD Trim Piston | 1 |
| 5 | 811606 | 导向套件 | GUIDE KIT | 1 |
| 5 | 878239A02 | 倾斜缸端盖套件 | END CAP KIT Tilt Cylinder | 1 |
| 6 | 811607A1 | 维修套件 | REPAIR KIT | 1 |
| 7 | 811610A1 | 止回阀套件 | CHECK VALVE KIT | 1 |
| 7 | 823553T | 升降活塞杆 | ROD Trim Piston | 1 |
| 8 | 99638A1 | 导向器总成 | GUIDE ASSEMBLY | 2 |
| 8 | 8M0021648 | 端盖总成 | END CAP ASSEMBLY | 2 |
| 9 | 43397A6 | 动力升降倾斜装置活塞/杆总成 | PISTON/ROD ASSEMBLY Power Trim | 1 |
| 9 | 878413A1 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 9 | 43398A3 | 动力升降倾斜装置活塞/杆总成 | PISTON/ROD ASSEMBLY Power Trim | 1 |
| 9 | 878414T01 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 10 | 12184A1 | 升降过滤器总成 | TRIM FILTER ASSEMBLY | 1 |
| 11 | 813442A2 | 手动释放总成 | MANUAL RELEASE ASSEMBLY | 1 |
| 11 | 893929A01 | 安全阀套件 | VALVE KIT Relief | 1 |
| 12 | 812844 | E型卡环 | E RING | 1 |
| 12 | 815949001 | E形环 | E-RING | 1 |
| 13 | 811612A2 | O型圈套件 | O-RING KIT | 1 |
| 13 | 811612A3 | O型圈套件 | O-RING KIT | 1 |
| 14 | 811617F | 泵 | PUMP | 1 |
| 14 | 811617T1 | 泵 | PUMP | 1 |
| 15 | 811613 | 塞子总成 | PLUG ASSEMBLY | 1 |
| 16 | 4000327 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 4 |
| 17 | 43450 | 垫圈 | WASHER | 4 |
| 17 | 4002315 | 垫圈(6.60x12.5x1.5mm-不锈钢) | WASHER (6.60 X 12.5 X 1.5 mm -SS) | 4 |
| 18 | 811611 | 盖板 | COVER | 1 |
| 19 | 828710 | 驱动接头 | DRIVE JOINT | 1 |
| 20 | 828708 | 电机总成 | MOTOR ASSEMBLY | 1 |
| 20 | 878265A4 | 配平电机 | TRIM MOTOR | 1 |
| 21 | 828709 | 螺钉 | SCREW | 2 |
| 21 | 881768A1 | 螺钉/垫圈套件 | SCREW/WASHER KIT | 2 |
| 21 | 811616 | 螺钉 | SCREW | 2 |
| 22 | 811614 | 轴总成 | SHAFT ASSEMBLY | 1 |
| 22 | 8M0142997 | 倾斜轴套件 | TILT SHAFT KIT | 1 |
| 23 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 2 |
| 24 | 44431 | 槽销 | PIN Groove | 1 |
| 24 | 878267 | 销 | PIN | 1 |
| 25 | 821539 | 三叶销 | PIN Trilobe | 1 |
| 26 | 996251 | 轴 | SHAFT | 1 |
| 26 | 99625002 | 轴 | SHAFT | 1 |
| 27 | 818298A1 | 阳极套件 | ANODE KIT | 1 |
| 27 | 818298Q1 | 阳极套件 | ANODE KIT | 1 |
| 28 | 4000330 | 螺钉 (M6 x 25) | SCREW (M6 x 25) (M6 X 1 X 25) | 2 |
| 28 | 8M0204707 | 不锈钢六角大帽螺钉(M6x25) | SCREW M6 x 25 HX HD CAP SS | 2 |
| 29 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 29 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 30 | 4000377 | 螺钉 (M10 x 30) | SCREW (M10 x 30) (M10 X 1.5 X 30) | 6 |
| 31 | 4002319 | 垫圈 | WASHER | 6 |
| 32 | 26550 | 卡箍 | CLAMP | 2 |
| 33 | 69079 | 螺钉 (#10-16 x .440) | SCREW (#10-16 x .440) (10-16 X .44) | 2 |
| 34 | 69205 | C形垫圈 | C WASHER | 2 |
| 34 | 8M0084613 | C形垫圈 | C-WASHER | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 8M0168222 | 动力升降总成 | POWER TRIM ASSEMBLY | 1 |
| 1 | 8M0142591 | 电机套件 | MOTOR KIT | 1 |
| 2 | 82494830 | 螺钉 (M6 x 30) | SCREW (M6 x 30) | 2 |
| 3 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 2 |
| 4 | 8M0090403 | 驱动联轴器 | COUPLING Drive | 1 |
| 5 | 8M0142996 | 压力检查套件 | PO CHECK KIT | 1 |
| 6 | 8M0060141 | 手动释放套件 | MANUAL RELEASE KIT | 1 |
| 7 | 8M0142997 | 倾斜轴套件 | TILT SHAFT KIT | 1 |
| 8 | 878267 | 销 | PIN | 1 |
| 9 | 8M0142998 | 倾斜油缸总成 | TILT CYLINDER ASSEMBLY | 1 |
| 9 | 8M0168220 | 倾斜油缸总成 | TILT CYLINDER ASSEMBLY | 1 |
| 10 | 8M0142999 | 倾斜油缸O型圈套件 | O RING KIT TILT CYLINDER | 1 |
| 11 | 8M0143000 | 记忆活塞套件 | MEMORY PISTON KIT | 1 |
| 12 | 8M0142592 | 升降杆套件 左舷 | TRIM ROD KIT Port | 1 |
| 13 | 8M0143001 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 14 | 8M0143003 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 15 | 878264A1 | 储液罐套件 | RESERVOIR KIT | 1 |
| 16 | 811613 | 塞子总成 | PLUG ASSEMBLY | 1 |
| 17 | 4000327 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 4 |
| 18 | 4002315 | 垫圈(6.60x12.5x1.5mm-不锈钢) | WASHER (6.60 X 12.5 X 1.5 mm -SS) | 4 |
| 19 | 8M0143004 | 泵套件 | PUMP KIT | 1 |
| 20 | 8M0148385 | 动力升降倾斜装置维修包 | REPAIR KIT Power Trim | 1 |
| 21 | 858771 | 螺钉 (M10 x 30) | SCREW (M10 x 30) | 6 |
| 22 | 4002319 | 垫圈 | WASHER | 6 |
| 23 | 8M0094889 | 销 | PIN | 1 |
| 23 | 8M0161312 | 连杆销眼总成 | PIN ROD EYE ASSEMBLY | 1 |
| 24 | 8M0143005 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 24 | 8M0168219 | 减震杆套件 | SHOCK ROD KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 830051A1 | 飞轮盖 | FLYWHEEL COVER | 1 |
| 2 | 834921 | 护孔环 | GROMMET | 3 |
| 3 | 86361 | 护孔环 | GROMMET | 1 |
| 4 | 834925 | 限流器 (8MM) | RESTRICTOR (8MM) | 1 |
| 5 | 834922 | 空气滤清器 | FILTER AIR | 1 |
| 6 | 49542 | 卡箍 | CLAMP | 2 |
| 7 | 82130012 | 螺钉 (M6 x 12) | SCREW (M6 x 12) (M6 X 12) | 2 |
| 8 | 825815 | 衬垫 | GASKET | 3 |
| 9 | 8283721 | 适配板 | ADAPTER PLATE | 1 |
| 9 | 828372T1 | 安装板 | PLATE | 1 |
| 10 | 834828 | 衬垫 | GASKET | 1 |
| 11 | 8283711 | 背板 | BACKING PLATE | 1 |
| 12 | 8141951 | 衬垫 | GASKET | 1 |
| 13 | 82130025 | 螺钉(M6×25) | SCREW (M6 x 25) (M6 X 25) | 12 |
| 14 | 828623 | 簧片阀组 (一体式) | REED BLOCK (1-PIECE) | 6 |
| 14 | 828623T6 | 簧片阀总成 | REED BLOCK ASSEMBLY | 6 |
| 15 | 4007425 | 螺钉 (M6 X 1 X 25) | SCREW (M6 X 1 X 25) | 12 |
| 16 | 8281241 | 油泵 | PUMP Oil | 1 |
| 16 | 828124T1 | 机油泵 | OIL PUMP | 1 |
| 17 | 828432 | 衬垫 | GASKET | 1 |
| 18 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 2 |
| 18 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 2 |
| 18 | 12516F2 | 螺钉 (M8 X 133.35) 上支架 | SCREW (M8 x 133.35) Upper Mount (M8 X 133.35) | 1 |
| 18 | 125161 | 螺丝 M8×133 | SCREW (M8 x 133) | 1 |
| 19 | 4002317 | 垫圈 (8.90 X 17.0 X 1.9SS) | WASHER (8.90 X 17.0 X 1.9SS) | 1 |
| 20 | 853565 | 机油泵支架 | BRACKET Oil Pump | 1 |
| 21 | 81893445 | 螺钉(M8×45) | SCREW (M8 X 45) | 2 |
| 22 | 99498 | 接头 | FITTING | 1 |
| 23 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 23 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 24 | 82381451 | 管材 (23英寸) | TUBING (23 IN.) | 1 |
| 24 | 82381455 | 油管（25.00英寸散装） | TUBING (25.00 Inches Bulk) | 1 |
| 25 | 76843 | 接头 | FITTING | 1 |
| 25 | 768431 | 接头 | FITTING | 1 |
| 26 | 99130122 | 管材 (20英尺散装) (31英寸) | TUBING (20.00 Feet Bulk) (31 IN.) | 1 |
| 26 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| - | 814195A97 | 衬垫套件 | GASKET SET | 1 |
| - | 809973A97 | 动力头总成 | POWERHEAD ASSEMBLY | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 833153 | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 1 | 898265008 | 启动马达 | STARTER MOTOR | 1 |
| 2 | 823639 | 驱动端盖 | DRIVE CAP | 1 |
| 2 | 8236392 | 驱动端盖 | DRIVE CAP | 1 |
| 3 | 8236411 | 贯穿螺栓 | THRU BOLT | 2 |
| 4 | 8236401 | 驱动套件 | DRIVE KIT | 1 |
| 5 | 86177 | 小齿轮 | PINION | 1 |
| 5 | 898265015 | 小齿轮 | PINION | 1 |
| 6 | 8236381 | 电枢 | ARMATURE | 1 |
| 7 | 753841 | 电刷/弹簧套件 | BRUSH/SPRING KIT | 1 |
| 7 | 898265016 | 电刷/弹簧套件 | BRUSH/SPRING KIT | 1 |
| 8 | 61787 | 支架 | HOLDER | 1 |
| 8 | 898265014 | 电刷支架 | HOLDER-BRUSH | 1 |
| 9 | 8119011 | 换向器端盖 | CAP Commutator | 1 |
| 10 | F15158 | 螺钉 | SCREW | 2 |
| 11 | 26992 | 锁紧垫圈(.250)不锈钢 | LOCKWASHER (.250) Stainless Steel | 2 |
| 12 | 94330 | 螺母 (.250-20) 黄铜 | NUT (.250-20) Brass (1/4-20) | 2 |
| 13 | 26992 | 锁紧垫圈(.250)不锈钢 | LOCKWASHER (.250) Stainless Steel | 1 |
| 14 | 20890 | 螺母（1/4-20） | NUT (.250-20) (1/4-20) | 1 |
| 15 | 81893450 | 螺钉 (M8 X 50) | SCREW (M8 x 50) (M8 X 40) | 3 |
| 16 | 824921 | 隔套 | SPACER | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8710A20 | 旋转支架总成 | SWIVEL BRACKET ASSEMBLY | 1 |
| 1 | 8M0102865 | 黑色旋转支架总成 | SWIVEL BRACKET ASSEMBLY Black | 1 |
| 1 | 8710A21 | 旋转支架总成 | SWIVEL BRACKET ASSEMBLY | 1 |
| 1 | 8710T21 | 灰色旋转支架总成 | SWIVEL BRACKET ASSEMBLY Gray | 1 |
| 1 | 8710A23 | 旋转支架 | SWIVEL BRACKET | 1 |
| 2 | 33504 | O型圈 | O-RING | 1 |
| 2 | 8M0214926 | O型圈 @10 | O RING @10 | 1 |
| 3 | 818764 | 衬套 | BUSHING | 2 |
| 4 | 816039 | 隔套 | SPACER | 1 |
| 5 | 87735 | 油封(下) | SEAL Oil (LOWER) | 1 |
| 6 | 74036 | 润滑脂接头 | FITTING Grease | 2 |
| 6 | 8M0169589 | 润滑脂接头 | FITTING Grease | 2 |
| 7 | 821207 | 衬套 | BUSHING | 2 |
| 8 | 816432 | 止推垫片 | THRUST WASHER | 1 |
| 9 | 814084F1 | 下轭架 | YOKE Bottom | 1 |
| 9 | 8M0219200 | 黑色下轭架 | YOKE-BOTTOM-BLACK | 1 |
| 9 | 814084F2 | 下轭架 | YOKE Bottom | 1 |
| 9 | 826364F1 | 下轭架 | YOKE Bottom | 1 |
| 9 | 826364T | 下轭架 | YOKE Bottom | 1 |
| 9 | 826364F2 | 下轭架 | YOKE Bottom | 1 |
| 9 | 826364F3 | 下轭架 | YOKE Bottom | 1 |
| 10 | 67684 | 挡圈 | RING Retaining | 1 |
| 11 | 996301 | 冲击板 | STRIKER PLATE | 2 |
| 11 | 8M0045383 | 冲击板 | STRIKER PLATE | 2 |
| 12 | 58643 | 锁紧垫圈 (.375) | LOCKWASHER (.375) | 2 |
| 13 | 46335 | 螺母 (.375-24) | NUT (.375-24) | 2 |
| 14 | 64014 | 螺钉 (.250-28 x .500) | SCREW (.250-28 x .500) (1/4-28) | 2 |
| 15 | 821180A6 | 调整传感器总成 | SENDER ASSEMBLY Trim | 1 |
| 15 | 8M0074846 | ORDER 8M0098273 | ORDER 8M0098273 | 1 |
| 16 | 56682 | 螺钉 (#10-24 x .750) | SCREW (#10-24 x .750) (10-24 X 3/4 IN.) | 2 |
| 16 | 852368 | 螺钉（#10-24 X 0.750） | SCREW (#10-24 x .750) | 2 |
| 17 | 26996 | 锁紧垫圈(#10)(不锈钢) | LOCKWASHER (#10) Stainless Steel | 2 |
| 18 | 89302 | 垫圈(0.203×0.406×0.040) | WASHER (.203 x .406 x .040) | 2 |
| 19 | 67706A55 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 19 | 826432A2 | 转向臂旋转销总成-不锈钢 | SWIVEL PIN ASSEMBLY Steering Arm - Stainless Steel | 1 |
| 19 | 67706A56 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 19 | 67706A55 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 19 | 826432A2 | 转向臂旋转销总成-不锈钢 | SWIVEL PIN ASSEMBLY Steering Arm - Stainless Steel | 1 |
| 19 | 8M0132731 | 旋转销总成 | SWIVEL PIN ASSY | 1 |
| 19 | 826432A3 | 转向臂旋转销总成-不锈钢 | SWIVEL PIN ASSEMBLY Steering Arm - Stainless Steel | 1 |
| 19 | 826432A2 | 转向臂旋转销总成-不锈钢 | SWIVEL PIN ASSEMBLY Steering Arm - Stainless Steel | 1 |
| 19 | 826432A6 | 旋转销总成 | SWIVEL PIN ASSEMBLY | 1 |
| 19 | 8M0132731 | 旋转销总成 | SWIVEL PIN ASSY | 1 |
| 20 | 816386 | 螺钉 (M12 X 190) | SCREW (M12 x 190) (M12 X 1.75 X 190) | 2 |
| 20 | 8M0141069 | 螺钉 | SCREW | 2 |
| 21 | 824998 | 缓冲垫 | BUMPER | 1 |
| 21 | 824998001 | 缓冲垫 | BUMPER | 1 |
| 22 | 8163851 | 上部支架 | MOUNT Upper | 2 |
| 23 | 815437 | 垫圈 | WASHER | 2 |
| 23 | 8154371 | 垫圈 | WASHER | 2 |
| 24 | 815436 | 垫圈 | WASHER | 2 |
| 25 | 90099 | 螺母(M12) | NUT (M12) | 2 |
| 25 | 896963 | 螺母(M12) | NUT (M12) | 2 |
| 26 | 813769 | 卡箍 | CLAMP | 1 |
| 26 | 8M0036783 | 卡箍 | CLAMP | 1 |
| 27 | 81893435 | 螺钉(M8×35) | SCREW (M8 x 35) (M8 X 35) | 3 |
| 27 | 8M0103814 | 螺钉 (M8 x 35 毫米) | SCREW (M8 x 35 MM) | 3 |
| 28 | 92876A1 | 转向连杆总成 | LINK ASSEMBLY Steering | 1 |
| 28 | 92876A12 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 29 | 14000 | 螺钉(.375-24x1.25) | SCREW (.375-24 x 1.25) | 1 |
| 29 | 849838 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 1 |
| 30 | 34863 | 螺母 (.375-24) | NUT (.375-24) (.375-24) | 2 |
| 30 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 2 |
| 31 | 37828 | 不锈钢垫圈 (.390 x .625 x .062) | WASHER (.390 x .625 x .062) Stainless Steel | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 833096A2 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 833096A3 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 833096T3 | 银色顶罩 | TOP COWL-SILVER | 1 |
| 1 | 833096A4 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 2 | 834806F1 | 盖帽 | CAP | 1 |
| 2 | 834806T2 | 黑色外罩盖 | CAP-COWL-BLACK | 1 |
| 2 | 8348061 | 盖帽 | CAP | 1 |
| 2 | 834806T1 | 镀铬盖 | CAP-CHROME | 1 |
| 2 | 834806F3 | 盖帽 | CAP | 1 |
| 3 | 82130012 | 螺钉 (M6 x 12) | SCREW (M6 x 12) (M6 X 12) | 3 |
| 4 | 821250A1 | 隔音毯套装 | SOUND BLANKET KIT | 1 |
| 5 | NSS | 不单独销售 | NOT SOLD SEPARATE | 2 |
| 6 | 823865 | 盖塞 | CAP PLUG | 3 |
| 7 | 821248 | 后闩锁钩 | REAR LATCH HOOK | 2 |
| 8 | 8237951 | 挡圈 | RING Retaining | 3 |
| 9 | 815263 | 滚轮 | ROLLER | 3 |
| 9 | 8M0207770 | 滚轮@3 | ROLLER @3 | 3 |
| 10 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 4 |
| 10 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 4 |
| 11 | 401196 | 螺母 (M6) | NUT (M6) (M6 X 1) | 4 |
| 12 | 821249M2 | 前支架 | BRACKET Front | 1 |
| 12 | 8M0036792 | 支架 | BRACKET | 1 |
| 13 | 815477 | 缓冲器锁扣 | BUMPER Latch | 1 |
| 14 | 8155381 | 滚动销 | PIN Roll | 1 |
| 15 | 401196 | 螺母 (M6) | NUT (M6) | 3 |
| 16 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 3 |
| 16 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 3 |
| 17 | 826639T | 盖板 | COVER | 1 |
| 18 | 47341A1 | 手动/应急启动绳柄套件 | ROPE AND HANDLE KIT Manual/Emergency Start | 1 |
| 18 | 47341A11 | 手动启动绳柄套件 | ROPE AND HANDLE KIT Manual Starting | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8718F7 | 艉板支架 | BRACKET Transom | 1 |
| 1 | 8718F8 | 艉板支架 | BRACKET Transom | 1 |
| 1 | 8718F11 | 艉板支架 | BRACKET Transom | 1 |
| 2 | 8716A8 | 艉板支架总成 | BRACKET ASSEMBLY Transom | 1 |
| 2 | 8716A9 | 艉板支架总成 | BRACKET ASSEMBLY Transom | 1 |
| 2 | 8716A11 | 艉板支架总成 | BRACKET ASSEMBLY Transom | 1 |
| 3 | 98727 | 润滑脂接头 | FITTING Grease | 1 |
| 3 | 8M0169588 | 润滑脂接头 | FITTING Grease | 1 |
| 4 | 826125A1 | 倾斜管 | TILT TUBE | 1 |
| 5 | 826135 | 锁紧螺母 (1.00-14) 尼龙嵌件 | NUT Lock (1.00-14) Nylon Insert (1 IN. -14) | 1 |
| 6 | 45711 | O型圈 (.612 x .103) | O-RING (.612 x .103) | 1 |
| 7 | 88750 | 波浪垫圈 (1.62 x 1.05) | WASHER Wave (1.62 x 1.05) | 2 |
| 8 | 826164 | 螺母 (.875-14) | NUT (.875-14) (7/8-14) | 1 |
| 8 | 8M0231351 | 锁紧螺母 | NUT Lock | 1 |
| 9 | 96930A1 | 螺栓总成 | BOLT ASSEMBLY | 1 |
| 10 | 23161 | 螺母 (.375-24) | NUT (.375-24) (.375-24) | 1 |
| 11 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 1 |
| 12 | 41508 | 螺钉 (.250-20 x .500) 不锈钢 | SCREW (.250-20 x .500) Stainless Steel (1/4-20 X .375) | 1 |
| 13 | 677551 | 螺钉(.500-20×4.500) | SCREW (.500-20 x 4.500) | 4 |
| 13 | 8M0149747 | 螺钉 | SCREW | 4 |
| 14 | 28421 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 14 | 8M0204648 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 15 | 8M0027784 | 螺母 | NUT | 4 |
| 15 | 82671117 | 螺母(.500-20) | NUT (.500-20) | 4 |
| 16 | 99629A2 | 杠杆总成 | LEVER ASSEMBLY | 1 |
| 16 | 8M0115104 | 倾斜锁定杆总成 | LEVER ASSEMBLY Tilt Lock | 1 |
| 17 | 99611 | 波形垫圈 | WAVE WASHER | 1 |
| 18 | 65830 | 尼龙衬套 | NYLINER | 2 |
| 19 | 814207 | 停机开关 | STOP | 1 |
| 20 | 99633 | 旋钮 | KNOB | 1 |
| 21 | 99615 | 槽销 | PIN Groove | 1 |
| 22 | 99622 | 弹簧 | SPRING | 1 |
| 23 | 99604 | 槽销 | PIN Groove | 1 |
