两冲程 化油器 · USA - Cat.# 90-814115 · 共 97 个部位 · 4588 条零件
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 7785A55 | 化油器总成(9-1) | CARBURETOR ASSEMBLY (9-1) | 1 |
| 1 | 7785A56 | 化油器总成(9-2) | CARBURETOR ASSEMBLY (9-2) | 1 |
| 1 | 7785A57 | 化油器总成(9-3) | CARBURETOR ASSEMBLY (9-3) | 1 |
| 1 | 7785A58 | 化油器总成(9-4) | CARBURETOR ASSEMBLY (9-4) | 1 |
| 1 | 7785A59 | 化油器总成(9-5) | CARBURETOR ASSEMBLY (9-5) | 1 |
| 1 | 7785A60 | 化油器总成(9-6) | CARBURETOR ASSEMBLY (9-6) | 1 |
| 1 | 7785A61 | 化油器总成(8-1) | CARBURETOR ASSEMBLY (8-1) | 1 |
| 1 | 7785A62 | 化油器总成(8-2) | CARBURETOR ASSEMBLY (8-2) | 1 |
| 1 | 7785A63 | 化油器总成(8-3) | CARBURETOR ASSEMBLY (8-3) | 1 |
| 1 | 7785A64 | 化油器总成(8-4) | CARBURETOR ASSEMBLY (8-4) | 1 |
| 1 | 7785A65 | 化油器总成(8-5) | CARBURETOR ASSEMBLY (8-5) | 1 |
| 1 | 7785A66 | 化油器总成(8-6) | CARBURETOR ASSEMBLY (8-6) | 1 |
| 2 | 6201 | 量孔(0.080)通风碗 | JET (.080) VENT BOWL | 6 |
| 3 | NSS | NOT SOLD SEPARATE GASKET | 6 | |
| 4 | 9122 | 盖板 | COVER PLATE | 6 |
| 5 | NSS | NOT SOLD SEPARATE SCREW | 24 | |
| 6 | 813274 | 喉管 | VENTURI | 6 |
| 6 | 9481 | 喉管 | VENTURI | 6 |
| 7 | 9478 | 燃油杯 | BOWL Fuel | 1 |
| 7 | 9478 | 燃油杯 | BOWL Fuel | 5 |
| 8 | NSS | NOT SOLD SEPARATE SCREW | 24 | |
| 9 | 6199 | 主量孔塞 | PLUG MAIN JET | 6 |
| 10 | NSS | 主量孔垫片(不单独销售) | NOT SOLD SEPARATE GASKET, MAIN JET | 6 |
| 11 | 6680 | 主量孔(0.078)燃油 | JET (.078) MAIN FUEL | 5 |
| 11 | 3517 | 主量孔(0.084)燃油 | JET (.084) MAIN FUEL | 1 |
| 11 | 6202 | 主量孔燃油 | JET MAIN MAIN FUEL | 1 |
| 11 | 3518 | 主量孔(0.082)燃油 | JET (.082) MAIN FUEL | 5 |
| 12 | NSS | 燃油碗垫片(不单独销售) | NOT SOLD SEPARATE GASKET, FUEL BOWL | 6 |
| 13 | 813470 | 浮子 | FLOAT | 6 |
| 14 | NSS | 浮子销(不单独销售) | NOT SOLD SEPARATE FLOAT PIN | 6 |
| 15 | NSS | 浮子杆(不单独销售) | NOT SOLD SEPARATE FLOAT LEVER | 6 |
| 16 | NSS | 销(不单独销售) | NOT SOLD SEPARATE PIN | 6 |
| 17 | NSS | 主喷嘴(不单独销售) | NOT SOLD SEPARATE MAIN NOZZLE | 6 |
| 18 | 8318 | 进油针阀 | NEEDLE Inlet | 6 |
| 18 | 83181 | 阀座套件 | VALVE SEAT KIT | 6 |
| 19 | NSS | NOT SOLD SEPARATE GASKET | 6 | |
| 20 | 9118 | 油门轴 | SHAFT Throttle | 1 |
| 20 | 9117 | 油门轴 | SHAFT Throttle | 5 |
| 21 | 814679 | 杠杆 | LEVER | 6 |
| 21 | 814677 | 油门杆 | LEVER Throttle | 1 |
| 22 | NSS | NOT SOLD SEPARATE SCREW | 6 | |
| 23 | NSS | NOT SOLD SEPARATE SPRING | 6 | |
| 24 | NSS | 隔套(不单独销售) | NOT SOLD SEPARATE SPACER | 6 |
| 25 | 9480 | 油门阀 | VALVE Throttle | 6 |
| 26 | NSS | NOT SOLD SEPARATE SCREW | 12 | |
| 27 | 886111 | 衬垫 | GASKET | 6 |
| 28 | NSS | 怠速空气量孔塞(不单独销售) | NOT SOLD SEPARATE PLUG, IDLE AIR JET | 6 |
| 29 | NSS | NOT SOLD SEPARATE GASKET | 6 | |
| 30 | 6487 | 主量孔(0.060)怠速 | JET Main (.060) IDLE | 6 |
| 30 | 7831 | 主量孔(0.058)怠速燃油 | JET Main Fuel (.058) IDLE | 6 |
| - | 9482 | 化油器维修套件 | REPAIR KIT Carburetor | 1 |
| - | 9062 | 化油器衬垫组 | GASKET SET Carburetor | 1 |
| - | 88605A89 | 衬垫套件 | GASKET SET | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9242A10 | 化油器(上) | CARBURETOR (TOP) | 1 |
| 2 | 9242A11 | 化油器(中) | CARBURETOR (CENTER) | 1 |
| 3 | 9242A12 | 化油器(下) | CARBURETOR (BOTTOM) | 1 |
| 4 | 6232 | 燃油入口接头(上/下) | FITTING FUEL INLET (UPPER/LOWER) | 2 |
| 5 | 70007 | 45度燃油入口接头(中部) | FITTING 45 Degree FUEL INLET (MIDDLE) | 1 |
| 6 | 904301 | 化油器衬垫 | GASKET CARBURETOR | 3 |
| 7 | 20184 | 化油器安装螺母(1/4-28X7/32) | NUT (1/4-28X7/32) CARBURETOR MOUNTING | 12 |
| 7 | 8M0207775 | 螺母 @5 | NUT @5 | 12 |
| 8 | 90077 | 化油器燃油管束带 | TIE STRAP FUEL HOSE TO CARBURETOR | AR |
| 8 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 9 | 42859A2 | 加浓阀总成 | VALVE ASSEMBLY Enrichner | 1 |
| 10 | 633001 | 加浓阀卡箍 | CLAMP ENRICHNER VALVE | 1 |
| 11 | 73286 | 螺钉(0.250-20×0.500)不锈钢阀门卡箍 | SCREW (.250-20 x .500) Stainless Steel VALVE CLAMP | 1 |
| 12 | 45915 | 端子排簧片块壳体 | TERMINAL BLOCK REED BLOCK HOUSING | 1 |
| 13 | 35519 | 端子块固定螺钉(#10-16 x .500) | SCREW (#10-16 x .500) TERMINAL BLOCK ATTACHING | 1 |
| 14 | 99130122 | 上部化油器至阀门管路(20英尺散装,7-3/4英寸) | TUBING (20.00 Feet Bulk) TOP CARBURETOR TO VALVE (7-3/4") | 1 |
| 14 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 15 | 9912688 | 化油器间连接管路(36英寸散装,4-1/4英寸) | TUBING (36.00 Inches Bulk) CARBURETOR TO CARBURETOR (4-1/4") | 2 |
| 16 | 15930A15 | 燃油泵套件 | PUMP KIT Fuel | 1 |
| 17 | 42990A6 | 膜片组件 | DIAPHRAGM KIT | 1 |
| 17 | 857005A1 | 膜片组件 | DIAPHRAGM KIT | 1 |
| 18 | NSS | 橡胶止回阀(不单独销售) | NOT SOLD SEPARATE CHECK VALVE, RUBBER | 2 |
| 19 | NSS | NOT SOLD SEPARATE GASKET, BOOST | 1 | |
| 20 | NSS | NOT SOLD SEPARATE DIAPHRAGM | 2 | |
| 21 | NSS | NOT SOLD SEPARATE GASKET, PULSE | 1 | |
| 22 | NSS | NOT SOLD SEPARATE SPRING | 1 | |
| 23 | NSS | NOT SOLD SEPARATE CAP | 1 | |
| 24 | NSS | NOT SOLD SEPARATE CHECK VALVE | 2 | |
| 25 | NSS | NOT SOLD SEPARATE RETAINER | 2 | |
| 26 | NSS | NOT SOLD SEPARATE SPRING | 1 | |
| 27 | NSS | NOT SOLD SEPARATE CAP | 1 | |
| 28 | 987691 | 底座衬垫 | GASKET BASE | 1 |
| 28 | 8M0204705 | 衬垫@2 | GASKET @2 | 1 |
| 29 | 144303 | 燃油泵底座 | BASE FUEL PUMP | 1 |
| 30 | 98775A2 | 燃油泵板 | PLATE FUEL PUMP | 1 |
| 30 | 987752 | 安装板 | PLATE | 1 |
| 31 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 1 |
| 32 | 19688 | 接头 | FITTING | 1 |
| 33 | 16452 | 燃油泵螺钉(#12-24 x 2.00) | SCREW (#12-24 x 2.00) FUEL PUMP | 2 |
| 34 | 4000310 | 燃油泵至曲轴箱螺钉(M5 x 40) | SCREW (M5 x 40) FUEL PUMP TO CRANKCASE | 2 |
| 35 | 4002314 | 燃油泵螺钉垫圈 | WASHER FUEL PUMP SCREW | 2 |
| 36 | 14868 | 燃油泵弯头接头 | FITTING FUEL PUMP (ELBOW) | 1 |
| 37 | 19688 | 燃油泵弯头接头 | FITTING FUEL PUMP (ELBOW) | 1 |
| 38 | 99127109 | 管路(57.00英寸 散装) | LINE (57.00 Inches Bulk) | 1 |
| 38 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 39 | 16494 | 燃油滤清器 | FILTER Fuel | 1 |
| 39 | 816296Q03 | 燃油滤清器@3 | FILTER-FUEL @3 | 1 |
| 40 | 15279 | 燃油滤清器卡箍 | CLAMP FUEL FILTER | 1 |
| 41 | 64705 | 脉冲软管接头 | FITTING PULSE HOSE | 1 |
| 42 | 9912976 | 油管 | TUBING | 2 |
| 42 | 8M0108349 | 软管 (70英寸散装) | HOSE (70 Inches Bulk) | 2 |
| 43 | 424251 | 三通 | TEE | 2 |
| 43 | 424253 | 接头 | FITTING | 2 |
| 44 | 15781A1 | 燃油连接器 | CONNECTOR Fuel | 1 |
| 44 | 816856Q3 | 燃油接头总成 | CONNECTOR ASSEMBLY Fuel | 1 |
| 45 | 69067 | 螺钉(.250-20×1.375) | SCREW (.250-20 x 1.375) | 1 |
| 46 | 812782 | 密封件 | SEAL | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8712A41 | 气缸体 | CYLINDER BLOCK | 1 |
| 2 | 76175 | 动力头螺柱 | STUD POWERHEAD | 6 |
| 3 | 67065 | 动力头螺柱 | STUD POWERHEAD | 2 |
| 3 | 670654 | 螺柱(.375-16/.375-24 x 5.620) | STUD (.375-16/.375-24 x 5.620) | 2 |
| 3 | 78438 | 动力头螺柱 | STUD POWERHEAD | 2 |
| 3 | 8M0034454 | 螺柱(.375-16/.375-24 x 6.87) | STUD (.375-16/.375-24 x 6.87) | 2 |
| 4 | 20033 | 定位销 | PIN Dowel LOCATING | 2 |
| 4 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 5 | 67296 | 气缸体销(轴承座圈) | PIN CYLINDER BLOCK (BEARING RACE) | 2 |
| 5 | 8M0036405 | 销 | PIN | 2 |
| 6 | 11338 | 密封垫片 | GASKET SEALING | 2 |
| 7 | 42249 | 启动马达上盖 | COVER STARTER MOTOR (UPPER) | 1 |
| 7 | 8M0088723 | 启动器支架 | BRACKET-STARTER | 1 |
| 8 | 73657 | 盖至曲轴箱螺钉(.312-18 x 1.50) | SCREW (.312-18 x 1.50) COVER TO CRANKCASE | 2 |
| 9 | 26993 | 启动马达盖螺钉锁紧垫圈(0.312) | LOCKWASHER (.312) STARTER MOTOR COVER SCREW | 4 |
| 9 | 8M0204647 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 4 |
| 10 | 76867 | 启动电机盖(下部) | COVER STARTER MOTOR (LOWER) | 1 |
| 11 | 77065 | 盖至曲轴箱螺钉(.312-18 x 2) | SCREW (.312-18 x 2) COVER TO CRANKCASE | 2 |
| 11 | 815549 | 螺钉(.312-18 x 2.00) | SCREW (.312-18 x 2.00) | 2 |
| 12 | 88801 | 杯形塞 | PLUG CUPPED | 2 |
| 12 | 99448 | 衬套 | BUSHING | 1 |
| 13 | 88807A20 | 线束总成盖 | CABLE ASSEMBLY COVER | 1 |
| 14 | 66717 | 螺钉 (.375-16 x 3.250) 曲轴箱气缸体 | SCREW (.375-16 x 3.250) CRANKCASE CYLINDER BLOCK | 8 |
| 14 | 74824 | 曲轴箱至气缸体螺丝(.312-18 x 1.250) | SCREW (.312-18 x 1.250) CRANKCASE TO CYLINDER BLOCK | 6 |
| 15 | 9608A1 | 上端盖总成 | END CAP ASSEMBLY (UPPER) | 1 |
| 15 | 9608T1 | 上盖总成 | CAP-ASSY-UPPER | 1 |
| 16 | 54029 | 端盖O型圈(2.800 x .103) | O-RING (2.800 x .103) END CAP | 1 |
| 17 | 93496 | 端盖滚柱轴承 | BEARING Roller END CAP | 1 |
| 17 | 93496T | 轴承 | BEARING | 1 |
| 18 | 41953 | 端盖密封件 | SEAL END CAP | 1 |
| 19 | 69034 | 螺钉与锁紧垫圈 (.312-18 x 1.00) 上端盖至气缸体 (1") | SCREW AND LOCKWASHER (.312-18 x 1.00) UPPER END CAP TO CYLINDER BLOCK (1") | 4 |
| 19 | 30225 | 螺钉带锁紧垫圈(.312-18 x 1.00) | SCREW WITH LOCKWASHER (.312-18 x 1.00) | 4 |
| 20 | 24220 | 螺钉 (.190-24 x .190) 定位 - 气缸体 (旧设计) | SCREW (.190-24 x .190) SET - CYLINDER BLOCK (OLD DESIGN) | 2 |
| 21 | 38407 | 堵头(.500-14) | PLUG (.500-14) | 1 |
| 22 | 15094 | 飞轮盖至气缸体双头螺柱(.190-32 x 1.870) | STUD (.190-32 x 1.870) FLYWHEEL COVER TO CYLINDER BLOCK | 1 |
| 23 | 15093 | 飞轮盖至支架双头螺柱(#10-32 x 1.00) | STUD (#10-32 x 1.00) FLYWHEEL COVER TO BRACKET | 2 |
| 23 | 8M0034435 | 螺柱 | STUD | 2 |
| 24 | 67269 | 飞轮盖螺柱隔套 | SPACER FLYWHEEL COVER STUD | 1 |
| 25 | 492211 | 飞轮盖螺柱垫圈 | WASHER FLYWHEEL COVER STUD | 6 |
| 25 | 8M0204663 | 垫片@5 | WASHER @5 | 6 |
| 26 | 72761 | 垫圈 (.203 x .562 x .060) 不锈钢 飞轮盖螺柱 | WASHER (.203 x .562 x .060) Stainless Steel FLYHWEEL COVER STUD | 3 |
| 27 | 73651 | 飞轮盖螺柱螺母 | NUT FLYWHEEL COVER STUD | 3 |
| 27 | 816874 | 蝶形螺母 (#10-32) | WING NUT (#10-32) | 3 |
| 28 | 42248 | 飞轮罩支架 | BRACKET FLYWHEEL COVER | 1 |
| 28 | 422482 | 支架 | BRACKET | 1 |
| 29 | 49668 | 支架至曲轴箱螺钉(.250-20 x .750) | SCREW (.250-20 x .750) BRACKET TO CRANKCASE | 2 |
| 30 | 7809A1 | 下端盖总成 | END CAP ASSEMBLY (LOWER) | 1 |
| 30 | 7809T1 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 31 | 62700 | O型圈 (3.237 x .103) 端盖 (3 3/4" 内径) | O-RING (3.237 x .103) END CAP (3 3/4" I.D.) | 1 |
| 32 | 41953 | 端盖密封件 | SEAL END CAP | 2 |
| 33 | 28636 | 螺钉（0.250-20 x 0.750）下端盖至气缸体 | SCREW (.250-20 x .750) LOWER END CAP TO CYLINDER BLOCK | 4 |
| 34 | 26992 | 下端盖螺钉不锈钢锁紧垫圈(.250) | LOCKWASHER (.250) Stainless Steel LOWER END CAP SCREW | 4 |
| 35 | 64022 | 调节螺钉(.250-20 x 2.125)-气缸体 | SCREW (.250-20 x 2.125) ADJUSTING - CYLINDER BLOCK | 1 |
| 36 | 64015 | 锁紧螺母(.250-20)-调节螺钉 | NUT (.250-20) JAM - ADJUSTING SCREW | 1 |
| 37 | 26852 | 调节螺钉尼龙帽 | CAP Nylon NYLON - ADJUSTING SCREW | 1 |
| 38 | 16793 | 卡箍 | CLAMP | 1 |
| 39 | 73286 | 螺钉(0.250-20×0.500)不锈钢 | SCREW (.250-20 x .500) Stainless Steel | 1 |
| 40 | 87076A6 | 怠速控制总成 | IDLE SPEED CONTROL ASSEMBLY | 1 |
| 40 | 87076A10 | 怠速控制器 | IDLE SPEED CONTROL | 1 |
| 41 | 69020 | 螺丝(#10-32 x .875)怠速控制 | SCREW (#10-32 x .875) IDLE SPEED CONTROL | 3 |
| 41 | 690201 | 螺钉(#10-32 x .875) | SCREW (#10-32 x .875) | 3 |
| 42 | 38833 | 垫圈 怠速控制螺钉 | WASHER IDLE SPEED SONTROL SCREW | 3 |
| 43 | 194372 | 端子排 | TERMINAL BLOCK | 1 |
| 44 | 48409 | 螺钉 (#10-16 x .625) 不锈钢 | SCREW (#10-16 x .625) Stainless Steel | 2 |
| 45 | 89302 | 垫圈(0.203×0.406×0.040) | WASHER (.203 x .406 x .040) | 2 |
| 46 | 45076 | 黄铜螺母(#10-32) | NUT (#10-32) Brass | 2 |
| 47 | 813938 | 盖形螺母(#10-32) | CAP NUT (#10-32) | 2 |
| 48 | 63153 | J型卡扣 | J CLIP | 1 |
| - | 812827A89 | 动力总成完整组件 | POWERHEAD ASSEMBLY COMPLETE | 1 |
| - | 812827T89 | 船用动力头 | POWERHEAD MARINE | 1 |
| - | 14697A87 | 衬垫套件 | GASKET SET |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 878587A1 | 下罩总成 | BOTTOM COWL ASSEMBLY | 1 |
| 2 | 858743A2 | 下罩总成 | BOTTOM COWL ASSEMBLY | 1 |
| 2 | 8M0113913 | 右舷下罩B | COWL-LOWER STBD B | 1 |
| 3 | 8253181 | 罩盖密封条(41英寸) | SEAL Cowl (41.00 Inches) | 2 |
| 3 | 8M0109217 | 罩盖密封条 | SEAL-COWL | 2 |
| 4 | 878547T | 嵌件 | INSERT | 1 |
| 5 | 82130040 | 螺钉(M6 x 40) | SCREW (M6 x 40) | 8 |
| 6 | 831209 | 固定座 | RETAINER | 1 |
| 7 | 858742 | 怠速排气套 | BOOT Idle Exhaust | 1 |
| 8 | 859251 | 护孔环 | GROMMET | 1 |
| 8 | 8M0039078 | 护孔环 | GROMMET | 1 |
| 9 | 827948 | 接头 | FITTING | 1 |
| 10 | 855576 | 垫圈 | WASHER | 1 |
| 11 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 6 |
| 12 | 830756109 | 软管(57英寸整卷)(裁切至5英寸长度) | HOSE (57.00 Inches Bulk) (Cut To 5.00 Inch Length) | 1 |
| 12 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 13 | 881535 | 软管(32.00英寸) | HOSE (32.00 Inches) | 1 |
| 14 | 9912688 | 管材(36.00英寸散装)(26.00英寸) | TUBING (36.00 Inches Bulk) (26.00 Inch) | 1 |
| 15 | 817518 | 三通 | TEE | 1 |
| 16 | 82130020 | 螺钉 (M6 x 20) | SCREW (M6 x 20) | 2 |
| 17 | 8587411 | 护孔环 | GROMMET | 1 |
| 17 | 889724 | 护孔环 | GROMMET | 1 |
| 18 | 856990 | 开关总成 | SWITCH ASSEMBLY | 1 |
| 18 | 8M0235192 | 微调开关 | SWITCH TRIM | 1 |
| 19 | 824868 | 螺钉(M6×75) | SCREW (M6 x 75) | 1 |
| 20 | 821253F1 | 前手柄黑色 | FRONT HANDLE Black | 1 |
| 20 | 889740A02 | 手柄套件 | HANDLE KIT | 1 |
| 21 | 33589 | 衬套 | BUSHING | 2 |
| 22 | 48462 | O型圈 (.614 x .070) | O-RING (.614 x .070) | 1 |
| 23 | 8219423 | 棘爪 | PAWL | 1 |
| 24 | 69057 | 垫片(.281 x .734 x .063) | WASHER (.281 x .734 x .063) | 1 |
| 25 | 401366 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 1 |
| 26 | 13541 | 公插头 | PLUG Male | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 830250T3 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 1 | 811666A1 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 1 | 8M0171821 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 2 | 809872A2 | O型圈维修包 | O-RING KIT Rebuild | 1 |
| 2 | 8M0171819 | O型圈套件 | O-RING KIT | 1 |
| 3 | 810776A1 | 记忆活塞总成 | PISTON ASSEMBLY Memory | 1 |
| 3 | 8M0171822 | 记忆活塞套件 | MEMORY PISTON KIT | 1 |
| 4 | 811669A1 | 气缸总成 | CYLINDER ASSEMBLY | 1 |
| 4 | 893916A01 | 气缸总成 | CYLINDER ASSEMBLY | 1 |
| 5 | 809873A1 | 配平限位阀套件 | VALVE KIT Trim Limit | 1 |
| 5 | 893905A02 | 阀套件 | VALVE KIT | 1 |
| 6 | 809874A1 | 泵总成 | PUMP ASSEMBLY | 1 |
| 6 | 893906A02 | 泵总成 | PUMP ASSEMBLY | 1 |
| 7 | 809885A2 | 电机套件 | MOTOR KIT | 1 |
| 7 | 893907A02 | 电机套件 | MOTOR KIT | 1 |
| 8 | 8134351 | 堵头 | PLUG | 1 |
| 9 | 813442A2 | 手动释放总成 | MANUAL RELEASE ASSEMBLY | 1 |
| 9 | 893929A01 | 安全阀套件 | VALVE KIT Relief | 1 |
| 10 | 809875A1 | 歧管套件 | MANIFOLD KIT | 1 |
| 10 | 893909A02 | 歧管套件 | MANIFOLD KIT | 1 |
| 11 | 809876A1 | 电机螺钉套件 | SCREW KIT Motor | 1 |
| 12 | 88238A18 | 拉线总成 | CABLE ASSEMBLY | 1 |
| 13 | 809877A1 | 驱动轴/密封套件 | DRIVESHAFT/SEAL KIT | 1 |
| 14 | 809878A1 | 滤清器套件 | FILTER KIT | 1 |
| 14 | 893912A02 | 滤清器套件 | FILTER KIT | 1 |
| 15 | 809879A1 | 提升阀套件 | POPPET KIT | 1 |
| 15 | 893913A02 | 提升阀套件 | POPPET KIT | 1 |
| - | 809880A1 | 完整配平O型圈套件 | O-RING KIT Complete Trim | 1 |
| - | 893914A02 | O型圈套件 | O-RING KIT | 1 |
| 16 | 821539 | 三叶销 | PIN Trilobe | 2 |
| 17 | 818898 | 锚销 | PIN Anchor | 1 |
| 18 | 996251 | 轴 | SHAFT | 1 |
| 18 | 99625002 | 轴 | SHAFT | 1 |
| 19 | 22740 | 卡扣 | CLIP | 2 |
| 20 | 878609 | 螺钉 (#10-16 x .600) | SCREW (#10-16 x .600) | 1 |
| 21 | 69205 | C形垫圈 | C WASHER | 1 |
| 21 | 8M0084613 | C形垫圈 | C-WASHER | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 79472 | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 1 | 90645 | 驱动套件 | DRIVE KIT | 1 |
| 2 | 75661 | 驱动小齿轮总成 | PINION ASSEMBLY Drive | 1 |
| 2 | 13310T1 | 小齿轮总成 | PINION ASSEMBLY | 1 |
| 3 | 75660 | 驱动端板 | PLATE DRIVE END | 1 |
| 4 | 74968 | 贯穿螺栓 | BOLT THRU | 2 |
| 6 | N.S.S. | 贯穿螺栓 (不单独销售) | Not Sold Separate THRU BOLT | 1 |
| 7 | 79216 | 电枢 | ARMATURE | 1 |
| 8 | 75384 | 电刷/弹簧套件 | BRUSH/SPRING KIT | 1 |
| 8 | 898265016 | 电刷/弹簧套件 | BRUSH/SPRING KIT | 1 |
| 9 | 61787 | 电刷架 | HOLDER BRUSH | 2 |
| 9 | 898265014 | 电刷支架 | HOLDER-BRUSH | 2 |
| 10 | 68586 | 电刷及支架螺钉 | SCREW BRUSH AND HOLDER | 2 |
| 11 | 15386 | 换向器端盖 | END CAP COMMUTATOR | 1 |
| 11 | 15386001 | 端盖 | END CAP | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 12430A4 | 传感器总成 | SENSOR ASSEMBLY | 1 |
| 2 | 48409 | 螺钉(#10-16 x .625)不锈钢传感器固定(5/8") | SCREW (#10-16 x .625) Stainless Steel SENSOR ATTACHING (5/8") | 1 |
| 3 | 815699 | 油泵总成 | PUMP ASSEMBLY Oil | 1 |
| 3 | 815699T | 油泵总成 | PUMP ASSEMBLY Oil | 1 |
| 3A | 814103 | 轴承(带密封) | BEARING (W/SEAL) | 1 |
| 3A | 8141032 | 蜗杆衬套 | BUSHING Worm | 1 |
| 4 | 11379 | 油泵O型圈 | O-RING OIL PUMP | 1 |
| 5 | 41429A2 | 驱动齿轮轴承总成 | BEARING ASSEMBLY DRIVE GEAR | 1 |
| 6 | 12726 | 从动齿轮 | GEAR Driven | 1 |
| 6 | 14563 | 从动齿轮 | GEAR Driven | 1 |
| 7 | 32228 | 螺钉(#10-32 x .625)油泵至曲轴箱(5/8") | SCREW (#10-32 x .625) OIL PUMP TO CRANKCASE (5/8") | 1 |
| 7 | 41507 | 螺钉(#10-32 x 1.120)油泵至曲轴箱(1-1/8") | SCREW (#10-32 x 1.120) OIL PUMP TO CRANKCASE (1-1/8") | 1 |
| 8 | 1938512 | 油门连杆至油泵总成 | LINK ASSEMBLY THROTTLE LEVER TO OIL PUMP | 1 |
| 9 | 4301619 | 油泵油管 | TUBING OIL PUMP | 1 |
| 9 | 82381335 | 油管(15.00英寸 散装) | TUBING (15.00 Inches Bulk) | 1 |
| 10 | 99443T | 油箱 | RESERVOIR Oil | 1 |
| 10 | 994436 | 储液罐 | RESERVOIR | 1 |
| 11 | 415823 | 油管卡箍(大) | CLAMP OIL HOSE (LARGE) | 2 |
| 12 | 4301736 | 油箱至油泵油管 | TUBING OIL RESERVOIR TO OIL PUMP | 1 |
| 12 | 82381455 | 油管（25.00英寸散装） | TUBING (25.00 Inches Bulk) | 1 |
| 13 | 69020 | 螺钉(#10-32 x .875)油箱固定(7/8") | SCREW (#10-32 x .875) OIL RESERVOIR ATTACHING (7/8") | 3 |
| 13 | 690201 | 螺钉(#10-32 x .875) | SCREW (#10-32 x .875) | 3 |
| 14 | 42118 | 油箱螺钉垫圈 | WASHER OIL RESERVOIR SCREW | 6 |
| 15 | 42117 | 油箱螺钉衬套 | GROMMET OIL RESERVOIR SCREW | 3 |
| 16 | 42116 | 油箱螺钉轴套 | BUSHING OIL RESERVOIR SCREW | 3 |
| 17 | 99127109 | 油管(57.00英寸散装) | LINE (57.00 Inches Bulk) OIL | 1 |
| 17 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 18 | 42425 | 油管三通 | TEE OIL TUBING | 1 |
| 19 | 9072925 | 油管(6-3/4") | HOSE OIL (6-3/4") | 1 |
| 20 | NA | 不可用壳体总成 | NOT AVAILABLE HOUSING ASSEMBLY | 1 |
| 21 | 99439 | 油管(114.00英寸) | HOSE (114.00 Inches) OIL | 1 |
| 22 | 12540A3 | 壳体 | HOUSING | 1 |
| 23 | 12242A1 | 闩锁 | LATCH | 1 |
| 24 | 43278 | 止回阀接头(曲轴箱) | FITTING CHECK CALVE (CRANKCASE) | 1 |
| 24 | 8781051 | 止回阀 | CHECK VALVE | 1 |
| 25 | 87421 | 油箱 | TANK | 1 |
| 26 | 43298A2 | 油箱盖总成 | CAP ASSEMBLY OIL TANK | 1 |
| 27 | 11332 | O型圈(2.225 x .210)盖 | O-RING (2.225 x .210) CAP | 1 |
| 28 | 43295A5 | 壳体总成适配器 | HOUSING ASSEMBLY Adaptor | 1 |
| 28 | 816190A4 | 机油收集器总成(无传感器) | OIL PICK UP ASSEMBLY Without Sender | 1 |
| 29 | 11332 | O型圈(2.225 x .210)适配器壳体 | O-RING (2.225 x .210) ADAPTOR HOUSING | 1 |
| 30 | 99802 | 吸油管 | TUBE OIL PICK-UP | 1 |
| 31 | 43300A1 | 油箱盖总成 | CAP ASSEMBLY OIL RESERVOIR | 1 |
| 31 | 43300A9 | 盖总成 | CAP ASSEMBLY | 1 |
| 32 | 43307 | 油箱盖衬垫 | GASKET RESERVOIR CAP | 1 |
| 32 | 43307T | 衬垫 | GASKET | 1 |
| 33 | 99022A1 | 浮子总成 | FLOAT ASSEMBLY | 1 |
| 33 | 8M0187298 | 浮子总成 | FLOAT ASSY | 1 |
| 34 | 99265 | 压入式螺母 | PUSH NUT | 1 |
| 35 | 415824 | 油管卡箍(小) | CLAMP OIL HOSE (SMALL) | 2 |
| 36 | 90077 | 扎带 | TIE STRAP | AR |
| 36 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 37 | 12335A1 | 支架套件 | BRACKET KIT | 1 |
| 38 | 12323A1 | 绳索/挂钩套件 | CORD/HOOK KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 17771 | 支架 | MOUNT | 1 |
| 2 | 59702 | 螺钉 (.250-28 x .875) 不锈钢 | SCREW (.250-28 x .875) Stainless Steel | 4 |
| 3 | 88404 | 锁紧垫圈 | TAB WASHER | 4 |
| 4 | 78862A2 | 密封套件 | SEAL KIT | 1 |
| 4 | 19624A1 | 密封套件 | SEAL KIT | 1 |
| 5 | 71565 | 导向套管 | TUBE Cable Guide | 1 |
| 6 | 17776 | 联轴器 | COUPLING | 1 |
| 7 | 817040 | 螺钉 (.375-24 x 2.75) | SCREW (.375-24 x 2.75) | 1 |
| 8 | 34931 | 不锈钢垫圈(.406x.734x.063) | WASHER (.406 x .734 x .063) Stainless Steel | 1 |
| 9 | 90092 | 螺钉 | SCREW | 1 |
| 9 | 856722 | 螺钉 | SCREW | 1 |
| 10 | 34863 | 螺母 (.375-24) | NUT (.375-24) | 2 |
| 10 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 2 |
| 11 | 42100 | 锁紧垫圈 | TAB WASHER | 2 |
| 12 | 37984 | 螺母 (.875-14) | NUT (.875-14) | 2 |
| 12 | 8M0041651 | 螺母 (.875-14) | NUT (.875-14) | 2 |
| 13 | 811290 | 蓄能器 | ACCUMULATOR | 1 |
| 14 | 817372 | 支架 | BRACKET | 1 |
| 15 | 16862 | 螺钉 (.250-10 x 1.25) | SCREW (.250-10 x 1.25) | 4 |
| 16 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 4 |
| 16 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 4 |
| 17 | 4000383 | 螺钉 (M10 x 70) | SCREW (M10 x 70) | 2 |
| 18 | 4002319 | 垫圈 | WASHER | 4 |
| 19 | 13914 | 螺母(M10) | NUT (M10) | 2 |
| 19 | 40140 | 螺母(M10) | NUT (M10) | 2 |
| 20 | 811289 | 执行器 | ACTUATOR | 1 |
| 20 | 828588A2 | 执行器套件 | ACTUATOR KIT | 1 |
| 21 | 94319 | 螺钉(.375-24 x 1.5) | SCREW (.375-24 x 1.5) | 1 |
| 22 | 17405 | 隔套 | SPACER | 2 |
| 23 | 34863 | 螺母 (.375-24) | NUT (.375-24) | 3 |
| 23 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 3 |
| 24 | 14000 | 螺钉(.375-24x1.25) | SCREW (.375-24 x 1.25) | 1 |
| 24 | 849838 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 1 |
| 25 | 92876A4 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 26 | 68300 | 垫圈 (.88 x .39 x .06) | WASHER (..88 x .39 x .06) | 1 |
| 27 | 4000330 | 螺钉(M6x25) | SCREW (M6 x 25) | 2 |
| 27 | 8M0204707 | 不锈钢六角大帽螺钉(M6x25) | SCREW M6 x 25 HX HD CAP SS | 2 |
| 28 | 43450 | 垫圈 | WASHER | 2 |
| 28 | 4002315 | 垫圈(6.60x12.5x1.5mm-不锈钢) | WASHER (6.60 X 12.5 X 1.5 mm -SS) | 2 |
| 29 | 400634 | 螺母 (M6) | NUT (M6) | 2 |
| 29 | 401386 | 螺母(M6)不锈钢 | NUT (M6) Stainless Steel | 2 |
| 30 | 811292 | 卡箍 | CLAMP | 1 |
| 31 | 818182 | 螺钉 | SCREW | 2 |
| 32 | 400263 | 螺母 (M5) | NUT (M5) | 2 |
| 33 | 811291 | 支架 | BRACKET | 1 |
| 34 | 38601 | 螺丝(.250-28 x 1.250) | SCREW (.250-28 x 1.250) | 4 |
| 35 | 197491 | 卡箍 | CLAMP | 1 |
| 36 | 18211 | 继电器开关 | RELAY SWITCH | 1 |
| 37 | 18244A1 | 线束总成 | HARNESS ASSEMBLY | 1 |
| 38 | 18124 | 螺钉 (#10-32 x .750) | SCREW (#10-32 x .750) | 1 |
| 39 | 90329 | 护孔环 | GROMMET | 1 |
| 40 | 309772 | 隔套 | SPACER | 1 |
| 41 | 816994 | 支架 | BRACKET | 1 |
| 42 | 42118 | 垫圈 | WASHER | 1 |
| 43 | 29488 | 螺母 (#10-32) | NUT (#10-32) | 1 |
| 43 | 8M0204718 | 螺母 | NUT | 1 |
| 44 | 81563024 | 贴花 | DECAL | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 76258A2 | 后罩支架（黑色） | BRACKET REAR COWL (BLACK) | 1 |
| 1 | 76258A3 | 后罩支架（灰色） | BRACKET REAR COWL (GRAY) | 1 |
| 2 | 76256 | 示流喷嘴 | NOZZLE TELL TALE | 1 |
| 3 | 67984 | 后罩支架密封垫 | SEAL REAR COWL BRACKET TO COWL | 1 |
| 4 | 67228 | 后罩支架密封垫 | SEAL REAR COWL BRACKET TO COWL | 1 |
| 5 | 67999 | 后罩支架密封垫 | SEAL REAR COWL BRACKET TO COWL | 2 |
| 6 | 99127109 | 管线（57英寸散装）示流管（截断至4英寸） | LINE (57.00 Inches Bulk) TELL TALE (Cut to 4 Inches) | 2 |
| 6 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 2 |
| 7 | 90824 | 指示器软管三通 | TEE TELL TALE HOSE | 1 |
| 7 | 90824001 | 三通接头 | TEE FITTING | 1 |
| 8 | 73498 | 指示软管卡箍 | CLAMP TELL TALE HOSE | AR |
| 8 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 9 | 86386A1 | 罩壳支撑支架总成 | BRACKET ASSEMBLY COWL SUPPORT | 1 |
| 10 | 66687 | 螺钉 (#10-32 x 1.50) 后罩支架 | SCREW (#10-32 x 1.50) REAR COWL BRACKET | 4 |
| 11 | 85651 | 罩壳铰链壳体-左舷 | HOUSING COWL HINGE - PORT | 2 |
| 11 | 85650 | 罩壳铰链壳体-右舷 | HOUSING COWL HINGE - STARBOARD | 2 |
| 12 | 64278 | 螺钉 (0.250-28 x 1.00) 罩壳铰链壳体 | SCREW (.250-28 x 1.00) COWL HINGE HOUSING | 8 |
| 13 | 20583 | 罩壳铰链壳体螺钉垫圈 | WASHER COWL HINGE HOUSING SCREW | 8 |
| 14 | 35888 | 螺母 (0.250-28) 不锈钢罩壳铰链壳体螺钉 | NUT (.250-28) Stainless Steel COWL HINGE HOUSING SCREW | 8 |
| 15 | 90435 | 罩壳安装支架座 | MOUNT COWL MOUNTING BRACKET | 3 |
| 16 | 29245 | 垫圈 (0.281 x 0.500 x 0.060) 不锈钢罩壳安装支架座 | WASHER (.281 x .500 x .060) Stainless Steel COWL MOUNTING BRACKET MOUNT | 6 |
| 16 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 6 |
| 17 | 35888 | 螺母 (0.250-28) 不锈钢罩壳安装支架座 | NUT (.250-28) Stainless Steel COWL MOUNTING BRACKET MOUNT | 6 |
| 18 | 99424 | 机罩支架（下部） | BRACKET COWL MOUNTING (LOWER) | 1 |
| 19 | 99447T | 拉线固定器 | RETAINER CABLE | 1 |
| 19 | 99447 | 固定座 | RETAINER | 1 |
| 20 | 22411 | 电缆固定器螺钉（.190-24 x 1.00） | SCREW (.190-24 x 1.00) CABLE RETAINER | 2 |
| 20 | 68918 | 螺丝（#10-24 x 1.00） | SCREW (#10-24 x 1.00) | 2 |
| 21 | 67260 | 控制线密封套 | SEAL CONTROL CABLES | 1 |
| 22 | 67241 | 罩壳锁扣壳体 | HOUSING COWL LATCH | 1 |
| 23 | 92051 | 螺钉 (10-16 x 0.75) 罩壳锁扣壳体 | SCREW (10-16 x .75) COWL LATCH HOUSING | 2 |
| 24 | 87608 | 盖锁扣 | LATCH Cowl | 1 |
| 25 | 60295 | 罩壳锁扣弹簧 | SPRING COWL LATCH | 1 |
| 26 | 88622 | 电缆固定板 | PLATE CABLE RETAINER | 1 |
| 27 | 99391 | 油管固定器 | RETAINER OIL LINES | 1 |
| 28 | 69067 | 螺钉 (0.250-20 x 1.375) 下部支架 | SCREW (.250-20 x 1.375) LOWER BRACKET | 2 |
| 29 | 20346 | 下部支架螺钉垫圈（小） | WASHER LOWER BRACKET SCREW (SMALL) | 4 |
| 29 | 69057 | 垫片(.281 x .734 x .063) | WASHER (.281 x .734 x .063) | 4 |
| 30 | 57427 | 下部支架螺钉垫圈（大） | WASHER LOWER BRACKET SCREW (LARGE) | 4 |
| 30 | 35280 | 垫圈(.255 x .620 x .030) 不锈钢 | WASHER (.255 x .620 x .030) Stainless Steel | 4 |
| 31 | 88180 | 下部支架衬套 | BUSHING LOWER BRACKET GROMMET | 2 |
| 32 | 88033 | 下部支架护孔环 | GROMMET LOWER BRACKET | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 79472 | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 1 | 90645 | 驱动套件 | DRIVE KIT | 1 |
| 2 | 75661 | 驱动小齿轮总成 | PINION ASSEMBLY Drive | 1 |
| 2 | 13310T1 | 小齿轮总成 | PINION ASSEMBLY | 1 |
| 3 | 75660 | 驱动端板 | PLATE DRIVE END | 1 |
| 4 | 74968 | 贯穿螺栓 | BOLT THRU | 2 |
| 6 | N.S.S. | 贯穿螺栓 (不单独销售) | Not Sold Separate THRU BOLT | 1 |
| 7 | 79216 | 电枢 | ARMATURE | 1 |
| 8 | 75384 | 电刷/弹簧套件 | BRUSH/SPRING KIT | 1 |
| 8 | 898265016 | 电刷/弹簧套件 | BRUSH/SPRING KIT | 1 |
| 9 | 61787 | 电刷架 | HOLDER BRUSH | 2 |
| 9 | 898265014 | 电刷支架 | HOLDER-BRUSH | 2 |
| 10 | 68586 | 电刷及支架螺钉 | SCREW BRUSH AND HOLDER | 2 |
| 11 | 15386 | 换向器端盖 | END CAP COMMUTATOR | 1 |
| 11 | 15386001 | 端盖 | END CAP | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 0 | 88183801 | 零件手册-115EFI(四冲程) | PARTS MANUAL 115 EFI (4-Stroke) Parts Manual | 1 |
| 0 | 881980 | 维修手册 | SERVICE MANUAL | 1 |
| 0 | 881980R03 | SM O/B 115 EFI 4S | SM O/B 115 EFI 4S | 1 |
| 0 | 10225030 | 用户手册 | OWNERS MANUAL | 1 |
| 0 | 858610A31 | 燃油软管总成 | HOSE ASSEMBLY Fuel | 1 |
| 0 | 8M0038610 | 带注油球的燃油软管总成(9英尺) | HOSE ASSEMBLY Fuel (9 Feet) With Primer Bulb | 1 |
| 0 | 880177 | 组合扳手工具(10毫米) | SCRENCH TOOL (10 mm) | 1 |
| 0 | 881828 | 星形头工具套件 | STARBIT TOOL KIT | 1 |
| 0 | 881649A01 | 贴花套件 | DECAL SET | 1 |
| 0 | 881649A05 | 贴花套件 | DECAL SET | 1 |
| 0 | 881840A01 | 贴花套件 | DECAL SET | 1 |
| 0 | 881840A03 | 贴花套件 | DECAL SET | 1 |
| 0 | 881840A03 | 贴花套件 | DECAL SET | 1 |
| 0 | 881840A05 | 贴花套件 | DECAL SET | 1 |
| 0 | 881650A01 | 贴花套件 | DECAL SET | 1 |
| 0 | 881650A03 | 贴花套件 | DECAL SET | 1 |
| 0 | 881650A03 | 贴花套件 | DECAL SET | 1 |
| 0 | 881702A01 | 贴花套件 | DECAL SET | 1 |
| 0 | 881839A01 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| 0 | 881839A02 | EPA标签信息贴花 | Decal EPA Label Information | 1 |
| 0 | 881839A03 | EPA标签信息贴花 | DECAL EPA Label Information | 1 |
| 0 | 816834A1 | 转速表 | TACHOMETER | 1 |
| 0 | 816932A1 | 温度表 | TEMPERATURE GAUGE | 1 |
| 0 | 86306 | 适配器 | ADAPTER | 1 |
| 0 | 86306A01 | 适配器 | ADAPTER | 1 |
| 0 | 817054A3 | 水压表总成 | GAUGE ASSEMBLY Water Pressure | 1 |
| 0 | 821400A2 | 动力升降倾斜传感器套件 | SENDER KIT Power Trim | 1 |
| 0 | 8M0074845 | ORD 8M0098264 | ORD 8M0098264 | 1 |
| 0 | 92876A8 | 转向安装套件 | ATTACHING KIT Steering | 1 |
| 0 | 92876A9 | 双机延长套件 | EXTENSION KIT Dual Engine | 1 |
| 0 | 883040A1 | 转速表模块套件 | TACH MODULE KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 9572A3 | 齿轮箱总成(长型)(黑色) | GEAR HOUSING ASSEMBLY (LONG) (BLACK) | 1 |
| - | 9572A4 | 齿轮箱总成(长型)(灰色) | GEAR HOUSING ASSEMBLY (LONG) (GRAY) | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 9572A1 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| 1 | 814247T8 | 齿轮箱 | GEAR HSG | 1 |
| 1 | 9572A2 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| 1 | 814247T9 | 齿轮箱 | GEAR HSG | 1 |
| 2 | 85822A1 | CONNECTOR ASSEMBLY SPEEDOMETER | 1 | |
| 2 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 3 | 20033 | 定位销 齿轮箱定位 | PIN Dowel GEAR HOUSING LOCATING | 2 |
| 3 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 4 | 78638 | 齿轮箱螺柱(0.438×3.12) | STUD (.438 x 3.12) GEAR HOUSING | 1 |
| 4 | 786382 | 螺柱(.437-14/.437-20 x 3.120) | STUD (.437-14/.437-20 x 3.120) | 1 |
| 5 | 57920 | 双头螺栓(.44 x 2.06)齿轮箱 | STUD (.44 x 2.06) GEAR HOUSING | 2 |
| 5 | 8M0133358 | 双头螺栓(.437-14/.437-20×2.060) | STUD (.437-14/.437-20 x 2.060) | 2 |
| 6 | 56297 | 双头螺栓(.312 x 3.38)水泵 | STUD (.312 x 3.38) WATER PUMP | 1 |
| 6 | 8M0034463 | 螺柱(.312-24 x 3.38) | STUD (.312-24 x 3.38) | 1 |
| 7 | 30667 | 双头螺栓(.250-20/.250-28 x 3.125)水泵 | STUD (.250-20/.250-28 x 3.125) WATER PUMP | 2 |
| 7 | 306671 | 螺柱 | STUD | 2 |
| 8 | 32898 | 驱动轴轴承 | BEARING DRIVESHAFT | 1 |
| 8 | 32898T | 轴承 | BEARING | 1 |
| 9 | 79953 | SCREW (.375-16 x .250) GREASE FILLER | 1 | |
| 9 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 10 | 67892 | SCREW Magnetic DRAIN | 1 | |
| 10 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 11 | 15298 | 驱动轴 | DRIVESHAFT | 1 |
| 12 | N.S.S. | 小齿轮(不单独销售)(属于43-16279A2部件) | Not Sold Separate Pinion Gear (PART OF 43-16279A2) | 1 |
| 13 | 20260 | 润滑脂加注与排放螺钉垫圈 | WASHER GREASE FILLER AND DRAIN SCREW | 2 |
| 13 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 2 |
| 14 | 35921 | 小齿轮至传动轴螺母(0.625-18) | NUT (.625-18) PINION GEAR TO DRIVESHAFT | 1 |
| 15 | 42637A1 | 滚柱轴承至齿轮箱垫片组 | SHIM SET ROLLER BEARING TO GEAR HOUSING | AR |
| 15 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 16 | 36387A1 | 传动轴滚柱/杯形轴承总成 | BEARING ASSEMBLY Roller/Cup DRIVESHAFT | 1 |
| 16 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 17 | 42633 | 传动轴轴承螺母 | NUT DRIVESHAFT BEARING | 1 |
| 17 | 8245191 | 固定座 | RETAINER | 1 |
| 18 | 42579A3 | 水泵底座总成 | BASE ASSEMBLY Water Pump | 1 |
| 18 | 8M0077147 | 带水泵底座总成 | BASE ASSY-W/P | 1 |
| 19 | 42631 | 水泵至齿轮箱衬垫 | GASKET WATER PUMP TO GEAR HOUSING | 1 |
| 19 | 8M0204678 | 衬垫 | GASKET | 1 |
| 20 | 90011 | O型圈(2.175×0.175)水泵 | O-RING (2.175 x .175) WATER PUMP | 1 |
| 20 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 20 | 38099 | O型圈水泵(内径2.109) | O-RING WATER PUMP (2.109 I.D.) | 1 |
| 21 | 89238 | 水泵油封 | SEAL Oil WATER PUMP | 1 |
| 22 | 16977 | 水泵油封 | SEAL Oil WATER PUMP | 1 |
| 23 | 85608 | 水泵下衬垫 | GASKET LOWER - WATER PUMP | 1 |
| 23 | 8M0090319 | 衬垫@5 | GASKET @5 | 1 |
| 24 | 85609 | 水泵上衬垫 | GASKET UPPER - WATER PUMP | 1 |
| 24 | 858524 | 衬垫 | GASKET | 1 |
| 25 | 32435 | 水泵面板 | FACE PLATE WATER PUMP | 1 |
| 25 | 8M0204677 | 面板 | PLATE-FACE | 1 |
| 26 | 96148A1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 26 | 96148T1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 27 | 48752 | 水泵体嵌件 | INSERT WATER PUMP BODY | 1 |
| 27 | 48752T | 嵌件 | INSERT | 1 |
| 28 | 38970 | 橡胶密封圈-进水管 | SEAL RUBBER - WATER INLET TUBE | 1 |
| 29 | 89984 | 水泵叶轮 | IMPELLER WATER PUMP | 1 |
| 29 | 89984T4 | 叶轮 | IMPELLER | 1 |
| 30 | 56654 | 叶轮驱动键 | KEY IMPELLER DRIVE | 1 |
| 30 | 8M0214992 | 键@5 | KEY @5 | 1 |
| 31 | 96411 | 螺钉(#14-8×2.25)水泵 | SCREW (#14-8 x 2.25) WATER PUMP | 1 |
| 31 | 8M0215009 | 螺钉 | SCREW | 1 |
| 32 | 29245 | 垫圈(0.281×0.500×0.060)不锈钢水泵螺钉与螺柱 | WASHER (.281 x .500 x .060) Stainless Steel WATER PUMP SCREW AND STUD | 2 |
| 32 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 33 | 13438 | 螺母(0.250-28)水泵螺柱 | NUT (.250-28) WATER PUMP STUD | 2 |
| 33 | 8267119 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 34 | 36001 | 水泵螺柱垫圈 | WASHER WATER PUMP STUD | 1 |
| 35 | 13436 | 水泵螺柱螺母 | NUT WATER PUMP STUD | 1 |
| 36 | 30271 | 橡胶环（驱动轴） | RING Rubber RUBBER (DRIVESHAFT) | 1 |
| 36 | 8M0214918 | 环@5 | RING @5 | 1 |
| 37 | 29804 | 进水管导向套 | SLEEVE GUIDE - WATER INLET TUBE | 1 |
| 37 | 29804T | 套筒 | SLEEVE | 1 |
| 38 | 15299 | 换挡轴-下部 | SHAFT SHIFT - LOWER | 1 |
| 39 | 29641 | E型挡圈-换挡轴 | E RING RETAINING - SHIFT SHAFT | 1 |
| 40 | 25439 | O-RING (.862 x .103) SHIFT SHAFT BUSHING | 1 | |
| 41 | 77631A2 | 换挡轴衬套总成 | BUSHING ASSEMBLY SHIFT SHAFT | 1 |
| 42 | 76384 | 换挡轴衬套油封 | SEAL Oil SHIFT SHAFT BUSHING | 1 |
| 42 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 43 | 77674 | WASHER (.35 x .75 x .12) RUBBER - SHIFT SHAFT BUSHING | 1 | |
| - | 42579A4 | 水泵修理包 | REBUILD KIT Water Pump | 1 |
| - | 96148A8 | 水泵维修套件 | WATER PUMP REPAIR KIT | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9242A10 | 化油器(上) | CARBURETOR (TOP) | 1 |
| 2 | 9242A11 | 化油器(中) | CARBURETOR (CENTER) | 1 |
| 3 | 9242A12 | 化油器(下) | CARBURETOR (BOTTOM) | 1 |
| 4 | 6232 | 燃油入口接头(上/下) | FITTING FUEL INLET (UPPER/LOWER) | 2 |
| 5 | 70007 | 45度燃油入口接头(中部) | FITTING 45 Degree FUEL INLET (MIDDLE) | 1 |
| 6 | 904301 | 化油器衬垫 | GASKET CARBURETOR | 3 |
| 7 | 20184 | 化油器安装螺母(1/4-28X7/32) | NUT (1/4-28X7/32) CARBURETOR MOUNTING | 12 |
| 7 | 8M0207775 | 螺母 @5 | NUT @5 | 12 |
| 8 | 90077 | 化油器燃油管束带 | TIE STRAP FUEL HOSE TO CARBURETOR | AR |
| 8 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 9 | 42859A2 | 加浓阀总成 | VALVE ASSEMBLY Enrichner | 1 |
| 10 | 633001 | 加浓阀卡箍 | CLAMP ENRICHNER VALVE | 1 |
| 11 | 73286 | 螺钉(0.250-20×0.500)不锈钢阀门卡箍 | SCREW (.250-20 x .500) Stainless Steel VALVE CLAMP | 1 |
| 12 | 45915 | 端子排簧片块壳体 | TERMINAL BLOCK REED BLOCK HOUSING | 1 |
| 13 | 35519 | 端子块固定螺钉(#10-16 x .500) | SCREW (#10-16 x .500) TERMINAL BLOCK ATTACHING | 1 |
| 14 | 99130122 | 上部化油器至阀门管路(20英尺散装,7-3/4英寸) | TUBING (20.00 Feet Bulk) TOP CARBURETOR TO VALVE (7-3/4") | 1 |
| 14 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 15 | 9912688 | 化油器间连接管路(36英寸散装,4-1/4英寸) | TUBING (36.00 Inches Bulk) CARBURETOR TO CARBURETOR (4-1/4") | 2 |
| 16 | 15930A15 | 燃油泵套件 | PUMP KIT Fuel | 1 |
| 17 | 42990A6 | 膜片组件 | DIAPHRAGM KIT | 1 |
| 17 | 857005A1 | 膜片组件 | DIAPHRAGM KIT | 1 |
| 18 | NSS | 橡胶止回阀(不单独销售) | NOT SOLD SEPARATE CHECK VALVE, RUBBER | 2 |
| 19 | NSS | NOT SOLD SEPARATE GASKET, BOOST | 1 | |
| 20 | NSS | NOT SOLD SEPARATE DIAPHRAGM | 2 | |
| 21 | NSS | NOT SOLD SEPARATE GASKET, PULSE | 1 | |
| 22 | NSS | NOT SOLD SEPARATE SPRING | 1 | |
| 23 | NSS | NOT SOLD SEPARATE CAP | 1 | |
| 24 | NSS | NOT SOLD SEPARATE CHECK VALVE | 2 | |
| 25 | NSS | NOT SOLD SEPARATE RETAINER | 2 | |
| 26 | NSS | NOT SOLD SEPARATE SPRING | 1 | |
| 27 | NSS | NOT SOLD SEPARATE CAP | 1 | |
| 28 | 987691 | 底座衬垫 | GASKET BASE | 1 |
| 28 | 8M0204705 | 衬垫@2 | GASKET @2 | 1 |
| 29 | 144303 | 燃油泵底座 | BASE FUEL PUMP | 1 |
| 30 | 98775A2 | 燃油泵板 | PLATE FUEL PUMP | 1 |
| 30 | 987752 | 安装板 | PLATE | 1 |
| 31 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 1 |
| 32 | 19688 | 接头 | FITTING | 1 |
| 33 | 16452 | 燃油泵螺钉(#12-24 x 2.00) | SCREW (#12-24 x 2.00) FUEL PUMP | 2 |
| 34 | 4000310 | 燃油泵至曲轴箱螺钉(M5 x 40) | SCREW (M5 x 40) FUEL PUMP TO CRANKCASE | 2 |
| 35 | 4002314 | 燃油泵螺钉垫圈 | WASHER FUEL PUMP SCREW | 2 |
| 36 | 14868 | 燃油泵弯头接头 | FITTING FUEL PUMP (ELBOW) | 1 |
| 37 | 19688 | 燃油泵弯头接头 | FITTING FUEL PUMP (ELBOW) | 1 |
| 38 | 99127109 | 管路(57.00英寸 散装) | LINE (57.00 Inches Bulk) | 1 |
| 38 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 39 | 16494 | 燃油滤清器 | FILTER Fuel | 1 |
| 39 | 816296Q03 | 燃油滤清器@3 | FILTER-FUEL @3 | 1 |
| 40 | 15279 | 燃油滤清器卡箍 | CLAMP FUEL FILTER | 1 |
| 41 | 64705 | 脉冲软管接头 | FITTING PULSE HOSE | 1 |
| 42 | 9912976 | 油管 | TUBING | 2 |
| 42 | 8M0108349 | 软管 (70英寸散装) | HOSE (70 Inches Bulk) | 2 |
| 43 | 424251 | 三通 | TEE | 2 |
| 43 | 424253 | 接头 | FITTING | 2 |
| 44 | 15781A1 | 燃油连接器 | CONNECTOR Fuel | 1 |
| 44 | 816856Q3 | 燃油接头总成 | CONNECTOR ASSEMBLY Fuel | 1 |
| 45 | 69067 | 螺钉(.250-20×1.375) | SCREW (.250-20 x 1.375) | 1 |
| 46 | 812782 | 密封件 | SEAL | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 814247A3 | 齿轮箱总成1.78:1速比-黑色 | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Black | 1 |
| - | 814247A4 | 齿轮箱总成 1.78:1 减速比 - 灰色 | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Gray | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| - | 814247A3 | 齿轮箱总成1.78:1速比-黑色 | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Black | 1 |
| - | 814247A4 | 齿轮箱总成 1.78:1 减速比 - 灰色 | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Gray | 1 |
| 1 | 814247A8 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| 1 | 814247T8 | 齿轮箱 | GEAR HSG | 1 |
| 1 | 814247A9 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| 1 | 814247T9 | 齿轮箱 | GEAR HSG | 1 |
| 1 | 814247A1 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 814247T1 | 齿轮箱总成基础型-黑色 | GEAR HOUSING ASSEMBLY Basic-Black | 1 |
| 1 | 814247A2 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 1 | 814247T2 | ORD 1674-814247T1 | ORD 1674-814247T1 | 1 |
| 44 | 76039 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 44 | 760394 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 45 | 12239A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 45 | 850315A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 46 | 30622 | 凸轮从动件压缩弹簧 | SPRING COMPRESSION - CAM FOLLOWER | 1 |
| 47 | 44491A1 | 垫片组 | SHIM SET | AR |
| 47 | 8M0063266 | 垫片组 | SHIM SET | AR |
| 48 | 30894A1 | 圆锥轴承组 | BEARING SET Cup And Cone | 1 |
| 49 | 16279A2 | 前进齿轮总成 | GEAR ASSEMBLY Forward | 1 |
| 50 | 30895 | 滚针轴承 | BEARING Needle | 1 |
| 50 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 51 | 814756 | 离合器 | CLUTCH | 1 |
| 51 | 822539T | 离合器 | CLUTCH | 1 |
| 52 | 30632 | 十字销 | PIN Cross | 1 |
| 52 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 53 | 30893 | 弹簧 | SPRING | 1 |
| 54 | 12238T | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 55 | NSS | 倒车齿轮(不单独销售)(43-16279A2部件) | NOT SOLD SEPARATE Reverse Gear (Part of 43-16279A2) | 1 |
| 56 | 76358 | 止推垫片轴承座 | THRUST WASHER BEARING CARRIER | 1 |
| 57 | 29976 | 轴承座O型圈 | O-RING BEARING CARRIER | 1 |
| 58 | 41529A2 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 58 | 41529T2 | 托架总成 | CARRIER ASSY | 1 |
| 59 | 98727 | 润滑脂接头 | FITTING Grease | 2 |
| 59 | 8M0169588 | 润滑脂接头 | FITTING Grease | 2 |
| 60 | 30956 | 滚针轴承-轴承座 | BEARING Needle BEARING CARRIER | 1 |
| 60 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 61 | 76868 | 密封件 | SEAL | 2 |
| 61 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 2 |
| 62 | 30281 | KEY LOCATING - BEARING CARRIER | 1 | |
| 63 | 52700 | 齿轮箱盖锁紧垫圈 | TAB WASHER GEAR HOUSING COVER | 1 |
| 64 | 52699 | 齿轮箱盖 | COVER GEAR HOUSING | 1 |
| 65 | 67891 | 填充块 | FILLER BLOCK | 1 |
| 65 | 8M0039169 | 填充块 | FILLER BLOCK | 1 |
| 66 | 30206 | 螺钉(.375-16 x 1.00)不锈钢(内六角头) | SCREW (.375-16 x 1.00) Stainless Steel (SOCKET HEAD) | 1 |
| 66 | 65210 | 螺钉(.375-16 x 1.00)(六角头) | SCREW (.375-16 x 1.00) (HEX HEAD) | 1 |
| 68 | 816629 | 螺旋桨螺母锁紧垫圈 | TAB WASHER PROPELLER NUT | 1 |
| 68 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 69 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 69 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 70 | 15300 | 阳极配平片 | TRIM TAB Anodic | 1 |
| 71 | 15797 | 阳极板螺钉 | SCREW ANODIC PLATE | 1 |
| 70 | 31640A1 | 平衡板总成 | TRIM TAB ASSEMBLY | 2 |
| 70 | 31640Q4 | 平衡鳍板 | TRIM TAB | 2 |
| 71 | 66024 | 螺钉(.437-14 x 1.75) | SCREW (.437-14 x 1.75) | 1 |
| 72 | 45176 | 垫圈(.453 x .812 x .105)不锈钢驱动轴壳体螺柱 | WASHER (.453 x .812 x .105) Stainless Steel DRIVE SHAFT HOUSING STUDS | 2 |
| 73 | 34933 | 螺母(.437-20)不锈钢驱动轴壳体螺柱 | NUT (.437-20) Stainless Steel DRIVE SHAFT HOUSING STUDS | 2 |
| 73 | 8M0204653 | 螺母 | NUT | 2 |
| 74 | 13191A1 | 止推垫片 | THRUST WASHER | 1 |
| 74 | 13191Q01 | 止推垫片 | THRUST WASHER | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| - | 815791A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815809A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815810A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 74897 | PIVOT TRIGGER PLATE | 1 | |
| 2 | 62459 | 球头总成触发板 | BALL JOINT ASSEMBLY TRIGGER PLATE | 1 |
| 2 | 62459T | 球头节总成 | BALL JOINT ASSY | 1 |
| 3 | 45076 | 螺母(#10-32)黄铜连杆 | NUT (#10-32) Brass LINK ROD | 1 |
| 4 | 76035 | 触发板连杆 | ROD TRIGGER PLATE | 1 |
| 5 | 46438 | 螺母(#10-32)球头 | NUT (#10-32) BALL JOINT | 1 |
| 6 | 41094A3 | 点火提前杆总成 | LEVER ASSEMBLY SPARK ADVANCE | 1 |
| 7 | 64022 | 螺丝(.250-20x2.125)点火提前杆-止动 | SCREW (.250-20 x 2.125) SPARK ADVANCE LEVER - STOP | 1 |
| 8 | 64015 | 螺母(.250-20)点火提前止动螺丝 | NUT (.250-20) SPARK ADVANCE STOP SCREW | 1 |
| 9 | 26852 | 尼龙帽点火提前杆止动螺丝 | CAP Nylon SPARK ADVANCE LEVER STOP SCREW | 1 |
| 10 | 13627 | 螺钉（0.190-32 x 1.250）点火提前杠杆-止动（1-1/4英寸） | SCREW (.190-32 x 1.250) SPARK ADVANCE LEVER - STOP (1-1/4") | 1 |
| 11 | 68219 | 螺母(#10-32)不锈钢点火提前杆止动螺丝 | NUT (#10-32) Stainless Steel SPARK ADVANCE LEVER STOP SCREW | 1 |
| 12 | 48039 | 点火提前杆止动螺丝帽 | CAP SPARK ADVANCE LEVER STOP SCREW | 1 |
| 13 | 41095T | 油门控制杆 | LEVER THROTTLE CONTROL | 1 |
| 13 | 410952 | 杠杆 | LEVER | 1 |
| 14 | 55337 | 螺钉（0.375-16 x 1.75）节气门杠杆/提前杠杆（1-3/4英寸） | SCREW (.375-16 x 1.75) THROTTLE LEVER/ADVANCE LEVER (1-3/4") | 1 |
| 14 | 818165 | 螺钉 (.375-16 x 1.75) | SCREW (.375-16 x 1.75) | 1 |
| 15 | 55164 | 油门杠杆衬套 | BUSHING THROTTLE LEVER | 1 |
| 16 | 55171 | 点火提前杆衬套 | BUSHING SPARK ADVANCE LEVER | 1 |
| 17 | 68784 | 节气门与点火提前杆弹簧 | SPRING THROTTLE AND SPARK ADVANCE LEVER | 1 |
| 18 | 68410 | 点火提前杆垫片 | WASHER SPARK ADVANCE LEVER | 1 |
| 18 | 46765 | 垫圈 (.390 x 1.50 x .120) | WASHER (.390 x 1.50 x .120) | 1 |
| 19 | 64022 | 螺钉（0.250-20 x 2.125）节气门杠杆-止动（2-1/8英寸） | SCREW (.250-20 x 2.125) THROTTLE LEVER - STOP (2-1/8") | 1 |
| 20 | 64015 | 螺母(.250-20)节气门杆止动螺丝 | NUT (.250-20) THROTTLE LEVER STOP SCREW | 1 |
| 21 | 26852 | 尼龙帽节气门杆止动螺丝 | CAP Nylon THROTTLE LEVER STOP SCREW | 1 |
| 22 | 39483 | 锁扣拉线 | LATCH CABLE | 1 |
| 23 | 22486 | 螺丝(.250-28x.880)拉线锁扣至节气门杆 | SCREW (.250-28 x .880) CABLE LATCH TO THROTTLE LEVER | 1 |
| 23 | 69026 | 螺钉 (.250-28 x .880) | SCREW (.250-28 x .880) | 1 |
| 24 | 20099 | 拉线锁扣至节气门杆弹簧 | SPRING CABLE LATCH TO THROTTLE LEVER | 1 |
| 25 | 20586 | 螺母(.250-28)拉线锁扣螺丝 | NUT (.250-28) CABLE LATCH SCREW | 1 |
| 25 | 826709109 | 不锈钢螺母(.250-28) | NUT (.250-28) Stainless Steel | 1 |
| 26 | 14634 | 节气门控制杆 | ROD THROTTLE CONTROL | 1 |
| 27 | 14638 | 节气门控制杆套筒 | BARREL THROTTLE CONTROL ROD | 1 |
| 28 | 146351 | 节气门凸轮 | CAM Throttle | 1 |
| 29 | 93248 | 衬套 | BUSHING | 1 |
| 29 | 8M0215006 | 旋转衬套 | BUSHING Swivel | 1 |
| 30 | 26856 | 节气门凸轮衬套 | BUSHING THROTTLE CAM | 2 |
| 31 | 35045 | 螺母（0.250-28）节气门凸轮螺柱 | NUT (.250-28) THROTTLE CAM STUD | 1 |
| 31 | 826709109 | 不锈钢螺母(.250-28) | NUT (.250-28) Stainless Steel | 1 |
| 32 | 41050 | 节气门复位弹簧 | SPRING THROTTLE RETURN | 1 |
| 33 | 92032A2 | 支架锚-控制电缆 | BRACKET ANCHOR - CTRL CABLES | 1 |
| 33 | 814283A2 | 支架总成 | BRACKET ASSEMBLY | 1 |
| 33 | 814283A1 | 控制线缆锚定支架 | BRACKET ANCHOR - CONTROL CABLES | 1 |
| 33 | 814283A2 | 支架总成 | BRACKET ASSEMBLY | 1 |
| 34 | 98889 | 控制线缆锁扣 | LATCH CONTROL CABLE | 1 |
| 35 | 42975 | 闩锁传动螺钉 | DRIVE SCREW LATCH | 2 |
| 36 | 53167 | 螺丝(.312-18x.880)锚定支架固定 | SCREW (.312-18 x .880) ANCHOR BRACKET ATTACHING | 3 |
| 36 | 53167T | 螺钉 0.312-18X 0.88 | SCREW .312-18X .88 | 3 |
| 37 | 37896 | 连杆导向块 | GUIDE BLOCK LINK ROD | 1 |
| 37 | 814284 | 连杆导向块 | GUIDE BLOCK LINK ROD | 1 |
| 38 | 20099 | 连杆至导向块弹簧 | SPRING LINK ROD TO GUIDE BLOCK | 1 |
| 39 | 67073A1 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 40 | 52100 | 连杆耐磨板 | WEAR PLATE LINK ROD | 1 |
| 41 | 38279 | 控制线缆闩锁紧固件 | LATCH CONTROL CABLE FASTENING | 1 |
| 41 | 8M0036768 | 闩锁 | LATCH | 1 |
| 42 | 35462 | 垫圈(.2656x.625x.0625)不锈钢锁扣 | WASHER (.2656 x .625 x .0625) Stainless Steel LATCH | 1 |
| 43 | 35045 | 螺母（0.250-28）连杆 | NUT (.250-28) LINK ROD | 1 |
| 43 | 826709109 | 不锈钢螺母(.250-28) | NUT (.250-28) Stainless Steel | 1 |
| 44 | 79932A11 | 换挡轴总成 | SHIFT SHAFT ASSEMBLY | 1 |
| 44 | 79932A16 | 换挡轴总成 | SHIFT SHAFT ASSEMBLY | 1 |
| 45 | 29720 | 连杆波形垫圈 | WAVE WASHER LINK ROD | 1 |
| 46 | 26600 | 尼龙衬套-连杆 | BUSHING NYLON - LINK ROD | 1 |
| 47 | 35462 | 垫圈(.2656 x .625 x .0625)不锈钢连杆 | WASHER (.2656 x .625 x .0625) Stainless Steel LINK ROD | 1 |
| 48 | 35045 | 螺母（0.250-28）连杆至换挡轴 | NUT (.250-28) LINK ROD TO SHIFT SHAFT | 1 |
| 48 | 826709109 | 不锈钢螺母(.250-28) | NUT (.250-28) Stainless Steel | 1 |
| 49 | 39519 | 杯形保持器-锚杆 | CUP BARRELL RETAINER - ANCHOR BAR | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8343A10 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 8343A11 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 8343T11 | ORD 1590-8343T10 | ORD 1590-8343T10 | 1 |
| 1 | 813563A1 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 813563T1 | 传动轴壳体-黑色-加长型 | HOUSING Driveshaft - Black - X-Long | 1 |
| 1 | 813563A2 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 813563T2 | ORD 3503-813563T1 | ORD 3503-813563T1 | 1 |
| 2 | 56295 | 双头螺柱(.437 x 2.69) | STUD (.437 x 2.69) | 2 |
| 3 | 63474 | 螺钉(.500-20 x 6.00) | SCREW (.500-20 x 6.00) | 2 |
| 3 | 898831 | 螺钉(.500-20 x 6.220) | SCREW (.500-20 x 6.220) | 2 |
| 4 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 1 |
| 5 | 77327 | 支架 | MOUNT | 2 |
| 6 | 49339 | 垫圈(.8125) | WASHER (.8125) | 2 |
| 7 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 1 |
| 8 | 28040 | 螺母(.500-20) | NUT (.500-20) | 2 |
| 8 | 898832 | 螺母(.500-20) | NUT (.500-20) | 2 |
| 9 | 41508 | 螺钉(0.250-20×0.500)不锈钢 | SCREW (.250-20 x .500) Stainless Steel | 1 |
| 10 | 45176 | 垫圈(.453 x .812 x .105)不锈钢 | WASHER (.453 x .812 x .105) Stainless Steel | 2 |
| 11 | 34933 | 螺母(.437-20)不锈钢 | NUT (.437-20) Stainless Steel | 2 |
| 11 | 8M0204653 | 螺母 | NUT | 2 |
| 12 | 67076 | 卡箍 | CLAMP | 2 |
| 12 | 8M0036782 | 卡箍 | CLAMP | 2 |
| 13 | 66727 | 螺钉(.312-18 x 1.250) | SCREW (.312-18 x 1.250) | 4 |
| 14 | 67077T | 黑色盖 | COVER Black | 2 |
| 14 | 8M4500752 | 盖板 | COVER | 2 |
| 14 | 67077F1 | 灰色盖板 | COVER Gray | 2 |
| 14 | 67077T | 黑色盖 | COVER Black | 2 |
| 15 | 88417 | 螺钉(#12-24×0.620) | SCREW (#12-24 x .620) | 4 |
| 16 | 35521 | 螺母 | NUT | 4 |
| 17 | 48926 | 垫圈 | WASHER | 1 |
| 18 | 34933 | 螺母(.437-20)不锈钢 | NUT (.437-20) Stainless Steel | 1 |
| 18 | 8M0204653 | 螺母 | NUT | 1 |
| 19 | 20553 | 垫圈(.406 x .734 x .063) | WASHER (.406 x .734 x .063) | 4 |
| 20 | 69254 | 螺母 | NUT | 4 |
| 21 | 828212 | 怠速排气套 | BOOT Idle Exhaust | 1 |
| 21 | 8M0039081 | 护套 | BOOT | 1 |
| 22 | 64649 | 堵头 | PLUG | 1 |
| 23 | 991732 | 衬垫 | GASKET | 1 |
| 23 | 991734 | 衬垫 | GASKET | 1 |
| 24 | 66350 | 下密封件 | SEAL (LOWER) | 1 |
| 24 | 66350001 | 密封件 | SEAL | 1 |
| 25 | 18276 | 排气管 | TUBE Exhaust | 1 |
| 25 | 18276T | 排气管 | EXHAUST TUBE | 1 |
| 26 | 177261 | 上密封件 | SEAL (UPPER) | 1 |
| 26 | 8M0039076 | 密封件 | SEAL | 1 |
| 27 | 812834 | 排气管延长段 | EXTENSION Exhaust | 1 |
| 27 | 812834A2 | 排气延长总成 | EXTENSION ASSEMBLY Exhaust | 1 |
| 27 | 41942F3 | 排气管延长段 | EXTENSION Exhaust | 1 |
| 27 | 879288T71 | 排气管延长段 | EXTENSION Exhaust | 1 |
| 28 | 67295 | 水管 | TUBE Water | 1 |
| 28 | 8M0042788 | 长型水管 | TUBE-WATER-LONG | 1 |
| 28 | 74729 | 管 | TUBE | 1 |
| 28 | 8M0042790 | 水管 | TUBE-WATER | 1 |
| 29 | 78246 | 衬垫 | GASKET | 1 |
| 29 | 782461 | 衬垫 | GASKET | 1 |
| 30 | 18233A3 | 隔板总成 | PLATE ASSEMBLY | 1 |
| 30 | 18233A20 | 传动轴壳体板总成 | PLATE ASSEMBLY Driveshaft Housing | 1 |
| 31 | 8147012 | 密封件 | SEAL | 1 |
| 31 | 8M0043165 | 密封件-27.00英寸 | SEAL-27.00 INCH | 1 |
| 32 | 68011 | 支架 | BRACKET | 1 |
| 33 | 812832 | 螺钉(#10-16 x 0.500) | SCREW (#10-16 x .500) | 12 |
| 33 | 878608 | 螺钉(#10-16 x 0.500) | SCREW (#10-16 x .500) | 12 |
| 34 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 35 | 38970 | 密封件 | SEAL | 1 |
| 36 | 90192 | 螺钉(.250-20 x .750)不锈钢 | SCREW (.250-20 x .750) Stainless Steel | 6 |
| 37 | 183071 | 衬垫 | GASKET | 1 |
| 37 | 183076 | 衬垫 | GASKET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8745A5 | 曲轴总成(含8个39-67377) | CRANKSHAFT ASSEMBLY (INCLUDES 8 OF 39-67377) | 1 |
| 2 | 67923 | 曲轴下球轴承 | BEARING Ball CRANKSHAFT (LOWER) | 1 |
| 2 | 67923T | 滚珠轴承 | BEARING Ball | 1 |
| 3 | 67446 | 球轴承挡圈 | RING BALL BEARING | 1 |
| 4 | 99727A1 | 驱动齿轮 | GEAR Drive | 1 |
| 5 | 54196A6 | 密封载体总成 | CARRIER ASSEMBLY SEAL | 1 |
| 6 | 65800 | 填料载体 | PACKING CARRIER | 1 |
| 7 | 67377 | 曲轴密封环(.124厚度) | RING Sealing SEALING - CRANKSHAFT (.124 THICK) | AR |
| 7 | 67377T | 密封环 | RING Sealing | AR |
| 7 | 78633 | 曲轴密封环(.139厚度) | RING SEALING - CRANKSHAFT (.139 THICK) | AR |
| 8 | 88903 | 保持式滚柱轴承 | BEARING Roller RETAINED BEARING | 2 |
| 8 | 88903T | 轴承座圈 | RACE Bearing | 2 |
| 9 | 67444 | 保持轴承挡圈 | RING Retaining RETAINED BEARING | 2 |
| 10 | 67445 | 保持式滚柱轴承 | BEARING Roller RETAINED BEARING | 2 |
| 8 | 93495 | 非保持式滚柱轴承 | BEARING Roller LOOSE BEARING | 2 |
| 8 | 93495T | 滚柱轴承 | BEARING Roller | 2 |
| 9 | 67444 | 非保持轴承挡圈 | RING Retaining LOOSE BEARING | 2 |
| 11 | 7441A3 | 活塞总成(右舷-标准) | PISTON ASSEMBLY (STARBOARD-STANDARD) | 3 |
| 11 | 7441T36 | 活塞-右舷-标准 | PISTON-STBD-STD | 3 |
| 11 | 7443A2 | 活塞总成(右舷-加大0.015) | PISTON ASSEMBLY (STARBOARD - .015 O.S.) | AR |
| 11 | 7443A12 | 活塞-右舷-0.015 | PISTON-STBD-.015 | AR |
| 11 | 7445A2 | 活塞总成(右舷-加大0.030) | PISTON ASSEMBLY (STARBOARD-.030 O.S.) | AR |
| 11 | 7445A12 | 活塞-右舷-0.030 | PISTON-STBD-.030 | AR |
| 11 | 7442A3 | 活塞总成(左舷-标准) | PISTON ASSEMBLY (PORT-STANDARD) | 3 |
| 11 | 7442T36 | 活塞-左舷-标准 | PISTON-PORT-STD | 3 |
| 11 | 7444A2 | 活塞总成(左舷-0.015加大) | PISTON ASSEMBLY (PORT-.015 O.S.) | AR |
| 11 | 7444A12 | 活塞-左舷-0.015 | PISTON-PORT-.015 | AR |
| 11 | 7446A2 | 活塞总成(左舷-0.030加大) | PISTON ASSEMBLY (PORT-.030 O.S.) | AR |
| 11 | 7446T12 | 活塞-左舷-0.030 | PISTON-PORT-.030 | AR |
| 12 | 93481A12 | 活塞环组-标准(标准) | RING SET Piston - Standard (STANDARD) | 1 |
| 12 | 78918A4 | 活塞环组-0.015加大(0.015加大) | RING SET Piston - .015 Oversize (.015 O.S.) | AR |
| 12 | 85636A4 | 活塞环组-0.030加大(0.030加大) | RING SET Piston - .030 Oversize (.030 O.S.) | AR |
| 13 | 52035 | 锁环 | RING Lock | 12 |
| 13 | 857196 | 锁紧环 | LOCK RING | 12 |
| 14 | 8119A5 | 连杆总成 | CONNECTING ROD ASSEMBLY | 6 |
| 14 | 8119A6 | 连杆套件 | CONN ROD KIT | 6 |
| 15 | 93886 | 螺钉(0.312-28×0.875)连杆 | SCREW (.312-28 x .875) CONNECTING ROD | 12 |
| 16 | 47247 | 定位针垫圈 | WASHER NEEDLE LOCATING | 12 |
| 16 | 8M0032839 | 垫片@5 | WASHER @5 | 12 |
| 17 | 17514A1 | 轴承套件 | BEARING KIT | 6 |
| 17 | 8M0234886 | 轴承保持架 | CAGE BEARING | 6 |
| 18 | 67483 | 活塞端滚针轴承 | BEARING Needle PISTON END | 174 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 814247A3 | 齿轮箱总成1.78:1速比-黑色 | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Black | 1 |
| - | 814247A4 | 齿轮箱总成 1.78:1 减速比 - 灰色 | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Gray | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 814247A1 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 814247T1 | 齿轮箱总成基础型-黑色 | GEAR HOUSING ASSEMBLY Basic-Black | 1 |
| 1 | 814247A2 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 1 | 814247T2 | ORD 1674-814247T1 | ORD 1674-814247T1 | 1 |
| 2 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 2A | 43998 | 套筒 | SLEEVE | 1 |
| 3 | 20033 | 定位销 | PIN Dowel | 2 |
| 3 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 4 | 78638 | 双头螺柱(.438 x 3.12) | STUD (.438 x 3.12) | 1 |
| 4 | 786382 | 螺柱(.437-14/.437-20 x 3.120) | STUD (.437-14/.437-20 x 3.120) | 1 |
| 5 | 57920 | 双头螺柱(.44 x 2.06) | STUD (.44 x 2.06) | 2 |
| 5 | 8M0133358 | 双头螺栓(.437-14/.437-20×2.060) | STUD (.437-14/.437-20 x 2.060) | 2 |
| 6 | 56297 | 双头螺栓(.312×3.38) | STUD (.312 x 3.38) | 1 |
| 6 | 8M0034463 | 螺柱(.312-24 x 3.38) | STUD (.312-24 x 3.38) | 1 |
| 7 | 30667 | 双头螺栓(.250-20/.250-28×3.125) | STUD (.250-20/.250-28 x 3.125) | 2 |
| 7 | 306671 | 螺柱 | STUD | 2 |
| 8 | 35934A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 9 | 79953 | SCREW (.375-16 x .250) GREASE FILLER | 1 | |
| 9 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 10 | 67892 | SCREW Magnetic DRAIN | 1 | |
| 10 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 11 | 815168 | 驱动轴 | DRIVESHAFT | 1 |
| 12 | N.S.S. | 小齿轮(不单独销售)(属于43-16279A2部件) | Not Sold Separate Pinion Gear (PART OF 43-16279A2) | 1 |
| 13 | 19183 | 纤维垫圈 | WASHER Fiber | 2 |
| 13 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 2 |
| 14 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 15 | 42637A1 | 垫片组 | SHIM SET | AR |
| 15 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 16 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 16 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 17 | 42633 | 螺母 | NUT | 1 |
| 17 | 8245191 | 固定座 | RETAINER | 1 |
| 18 | 42579A3 | 水泵底座总成 | BASE ASSEMBLY Water Pump | 1 |
| 18 | 8M0077147 | 带水泵底座总成 | BASE ASSY-W/P | 1 |
| 19 | 426311 | 衬垫 | GASKET | 1 |
| 19 | 8M0204678 | 衬垫 | GASKET | 1 |
| 20 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 20 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 21 | 89238 | 油封 | SEAL Oil | 1 |
| 22 | 16977 | 油封 | SEAL Oil | 1 |
| 23 | 856081 | 下部衬垫 | GASKET LOWER | 1 |
| 23 | 8M0090319 | 衬垫@5 | GASKET @5 | 1 |
| 24 | 856091 | 上衬垫 | GASKET UPPER | 1 |
| 24 | 858524 | 衬垫 | GASKET | 1 |
| 25 | 32435 | 面板 | FACE PLATE | 1 |
| 25 | 8M0204677 | 面板 | PLATE-FACE | 1 |
| 26 | 96148A1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 26 | 96148T1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 27 | 48752 | 嵌件 | INSERT | 1 |
| 27 | 48752T | 嵌件 | INSERT | 1 |
| 28 | 38970 | 橡胶密封件 | SEAL RUBBER | 1 |
| 29 | 899841 | 叶轮 | IMPELLER | 1 |
| 29 | 89984T3 | 叶轮 | IMPELLER | 1 |
| 30 | 56654 | 键 | KEY | 1 |
| 30 | 8M0214992 | 键@5 | KEY @5 | 1 |
| 31 | 96411 | 螺钉(#14-8×2.25) | SCREW (#14-8 x 2.25) | 1 |
| 31 | 8M0215009 | 螺钉 | SCREW | 1 |
| 32 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 32 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 33 | 13438 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 33 | 8267119 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 34 | 36001 | 垫圈 | WASHER | 1 |
| 35 | 13436 | 螺母 | NUT | 1 |
| 37 | 29804 | 套筒 | SLEEVE | 1 |
| 37 | 29804T | 套筒 | SLEEVE | 1 |
| 38 | 815264 | 换挡轴下段 | SHIFT SHAFT LOWER | 1 |
| 38 | 8152641 | 换档轴 | SHIFT SHAFT | 1 |
| 39 | 29641 | E型卡环 | E RING | 1 |
| 40 | 25439 | O型圈(.862×0.103) | O-RING (.862 x .103) | 1 |
| 41 | 77631A2 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 42 | 816464 | 油封 | SEAL Oil | 1 |
| 42 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 43 | 77674 | WASHER (.35 x .75 x .12) RUBBER - SHIFT SHAFT BUSHING | 1 | |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| - | 96148A5 | 水泵维修套件 | REPAIR KIT Water Pump | 1 |
| - | 96148A8 | 水泵维修套件 | WATER PUMP REPAIR KIT | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 830250T3 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 1 | 811666A1 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 1 | 8M0171821 | 减震杆套件 | SHOCK ROD KIT | 1 |
| 2 | 809872A2 | O型圈维修包 | O-RING KIT Rebuild | 1 |
| 2 | 8M0171819 | O型圈套件 | O-RING KIT | 1 |
| 3 | 810776A1 | 记忆活塞总成 | PISTON ASSEMBLY Memory | 1 |
| 3 | 8M0171822 | 记忆活塞套件 | MEMORY PISTON KIT | 1 |
| 4 | 811669A1 | 气缸总成 | CYLINDER ASSEMBLY | 1 |
| 4 | 893916A01 | 气缸总成 | CYLINDER ASSEMBLY | 1 |
| 5 | 809873A1 | 配平限位阀套件 | VALVE KIT Trim Limit | 1 |
| 5 | 893905A02 | 阀套件 | VALVE KIT | 1 |
| 6 | 809874A1 | 泵总成 | PUMP ASSEMBLY | 1 |
| 6 | 893906A02 | 泵总成 | PUMP ASSEMBLY | 1 |
| 7 | 809885A2 | 电机套件 | MOTOR KIT | 1 |
| 7 | 893907A02 | 电机套件 | MOTOR KIT | 1 |
| 8 | 8134351 | 堵头 | PLUG | 1 |
| 9 | 813442A2 | 手动释放总成 | MANUAL RELEASE ASSEMBLY | 1 |
| 9 | 893929A01 | 安全阀套件 | VALVE KIT Relief | 1 |
| 10 | 809875A1 | 歧管套件 | MANIFOLD KIT | 1 |
| 10 | 893909A02 | 歧管套件 | MANIFOLD KIT | 1 |
| 11 | 809876A1 | 电机螺钉套件 | SCREW KIT Motor | 1 |
| 12 | 88238A18 | 拉线总成 | CABLE ASSEMBLY | 1 |
| 13 | 809877A1 | 驱动轴/密封套件 | DRIVESHAFT/SEAL KIT | 1 |
| 14 | 809878A1 | 滤清器套件 | FILTER KIT | 1 |
| 14 | 893912A02 | 滤清器套件 | FILTER KIT | 1 |
| 15 | 809879A1 | 提升阀套件 | POPPET KIT | 1 |
| 15 | 893913A02 | 提升阀套件 | POPPET KIT | 1 |
| - | 809880A1 | 完整配平O型圈套件 | O-RING KIT Complete Trim | 1 |
| - | 893914A02 | O型圈套件 | O-RING KIT | 1 |
| 16 | 821539 | 三叶销 | PIN Trilobe | 2 |
| 17 | 818898 | 锚销 | PIN Anchor | 1 |
| 18 | 996251 | 轴 | SHAFT | 1 |
| 18 | 99625002 | 轴 | SHAFT | 1 |
| 19 | 22740 | 卡扣 | CLIP | 2 |
| 20 | 878609 | 螺钉 (#10-16 x .600) | SCREW (#10-16 x .600) | 1 |
| 21 | 69205 | C形垫圈 | C WASHER | 1 |
| 21 | 8M0084613 | C形垫圈 | C-WASHER | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 9148A8 | 齿轮箱总成 标准旋转 1.87:1 齿轮比 | GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio | 1 |
| - | 9148A9 | 齿轮箱总成 标准旋转 1.87:1 齿轮比 | GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio | 1 |
| - | 9148T85 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| - | 9148A10 | 齿轮箱总成 标准旋转 1.87:1 齿轮比 | GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio | 1 |
| - | 9148T84 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| - | 9148A13 | 齿轮箱总成 标准旋转 1.87:1 齿轮比 | GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio | 1 |
| - | 9148T91 | ORD 1647-9148T85 | ORD 1647-9148T85 | 1 |
| - | 9148A30 | 齿轮箱总成 反向旋转 | GEAR HOUSING ASSEMBLY Counter Rotation | 1 |
| - | 9148T86 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| - | 9148A31 | 齿轮箱总成 反向旋转 | GEAR HOUSING ASSEMBLY Counter Rotation | 1 |
| - | 9148T92 | ORD 1647-9148T86 | ORD 1647-9148T86 | 1 |
| 1 | 9148A11 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 9148T47 | 齿轮箱-基础型-黑 | GEAR HSG-BASIC-BL | 1 |
| 1 | 9148A12 | 齿轮箱总成 | GEAR HOUSING ASSEMBLY | 1 |
| 1 | 9148T47 | 齿轮箱-基础型-黑 | GEAR HSG-BASIC-BL | 1 |
| 2 | 85822A1 | CONNECTOR ASSEMBLY SPEEDOMETER | 1 | |
| 2 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 3 | 20033 | 定位销 齿轮箱定位 | PIN Dowel GEAR HOUSING LOCATING | 2 |
| 3 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 4 | 78638 | 齿轮箱螺柱(0.438×3.12) | STUD (.438 x 3.12) GEAR HOUSING | 1 |
| 4 | 786382 | 螺柱(.437-14/.437-20 x 3.120) | STUD (.437-14/.437-20 x 3.120) | 1 |
| 4 | 18978 | 齿轮箱螺柱(0.438×3.69) | STUD (.438 x 3.69) GEAR HOUSING | 1 |
| 4 | 8M0034464 | 螺柱 | STUD | 1 |
| 5 | 57920 | 齿轮箱螺柱(0.44×2.06) | STUD (.44 x 2.06) GER HOUSING | 2 |
| 5 | 8M0133358 | 双头螺栓(.437-14/.437-20×2.060) | STUD (.437-14/.437-20 x 2.060) | 2 |
| 6 | 56297 | 双头螺栓(.312 x 3.38)水泵 | STUD (.312 x 3.38) WATER PUMP | 1 |
| 6 | 8M0034463 | 螺柱(.312-24 x 3.38) | STUD (.312-24 x 3.38) | 1 |
| 7 | 30667 | 双头螺栓(.250-20/.250-28 x 3.125)水泵 | STUD (.250-20/.250-28 x 3.125) WATER PUMP | 2 |
| 7 | 306671 | 螺柱 | STUD | 2 |
| 8 | 42647A1 | 传动轴滚柱轴承总成 | BEARING ASSEMBLY Roller DRIVESHAFT | 1 |
| 9 | 43998 | 润滑套筒 | SLEEVE LUBRICATION | 1 |
| 11 | 44000 | 驱动轴 | DRIVESHAFT | 1 |
| 11 | 897624T | 长驱动轴 | DRIVESHAFT Long | 1 |
| 11 | 44209 | 驱动轴 | DRIVESHAFT | 1 |
| 11 | 897625T | 加长驱动轴 | DRIVESHAFT X-Long | 1 |
| 12 | N.S.S. | 不单独出售小齿轮(43-44104A2或43-18475A1部件) | Not Sold Separate Pinion Gear-Part of 43-44104A2 or 43-18475A1 | 1 |
| 13 | 92721 | 垫圈(.965 x .630)小齿轮 | WASHER (.965 x .630) PINION GEAR | 1 |
| 14 | 35921 | 小齿轮至传动轴螺母(0.625-18) | NUT (.625-18) PINION GEAR TO DRIVESHAFT | 1 |
| 15 | 42637A1 | 垫片组 | SHIM SET | AR |
| 15 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 16 | 36387A1 | 传动轴滚柱/杯形轴承总成 | BEARING ASSEMBLY Roller/Cup DRIVESHAFT | 1 |
| 16 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 17 | 42633 | 传动轴轴承螺母 | NUT DRIVESHAFT BEARING | 1 |
| 17 | 8245191 | 固定座 | RETAINER | 1 |
| 18 | 42579A3 | 水泵底座总成 | BASE ASSEMBLY Water Pump | 1 |
| 18 | 8M0077147 | 带水泵底座总成 | BASE ASSY-W/P | 1 |
| 19 | 426311 | 水泵至齿轮箱衬垫 | GASKET WATER PUMP TO GEAR HSG | 1 |
| 19 | 8M0204678 | 衬垫 | GASKET | 1 |
| 20 | 90011 | O型圈(2.175×0.175)水泵 | O-RING (2.175 x .175) WATER PUMP | 1 |
| 20 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 20 | 38099 | O型圈水泵(内径2.109) | O-RING WATER PUMP (2.109 I.D.) | 1 |
| 21 | 89238 | 水泵油封 | SEAL Oil WATER PUMP | 1 |
| 22 | 16977 | 水泵油封 | SEAL Oil WATER PUMP | 1 |
| 23 | 856081 | 水泵下衬垫 | GASKET LOWER - WATER PUMP | 1 |
| 23 | 8M0090319 | 衬垫@5 | GASKET @5 | 1 |
| 24 | 856091 | 水泵上衬垫 | GASKET UPPER - WATER PUMP | 1 |
| 24 | 858524 | 衬垫 | GASKET | 1 |
| 25 | 32435 | 水泵面板 | FACE PLATE WATER PUMP | 1 |
| 25 | 8M0204677 | 面板 | PLATE-FACE | 1 |
| 26 | 96148A1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 26 | 96148T1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 27 | 48752 | 水泵体嵌件 | INSERT WATER PUMP BODY | 1 |
| 27 | 48752T | 嵌件 | INSERT | 1 |
| 28 | 38970 | 橡胶密封圈-进水管 | SEAL RUBBER - WATER INLET TUBE | 1 |
| 29 | 89984 | 水泵叶轮 | IMPELLER WATER PUMP | 1 |
| 29 | 89984T4 | 叶轮 | IMPELLER | 1 |
| 30 | 56654 | 叶轮驱动键 | KEY IMPELLER DRIVE | 1 |
| 30 | 8M0214992 | 键@5 | KEY @5 | 1 |
| 31 | 96411 | 螺钉(#14-8×2.25)水泵 | SCREW (#14-8 x 2.25) WATER PUMP | 1 |
| 31 | 8M0215009 | 螺钉 | SCREW | 1 |
| 32 | 29245 | 垫圈(0.281×0.500×0.060)不锈钢水泵螺钉与螺柱 | WASHER (.281 x .500 x .060) Stainless Steel WATER PUMP SCREW AND STUD | 2 |
| 32 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 33 | 13438 | 螺母(0.250-28)水泵螺柱 | NUT (.250-28) WATER PUMP STUD | 2 |
| 33 | 8267119 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 34 | 36001 | 水泵螺柱垫圈 | WASHER WATER PUMP STUD | 1 |
| 35 | 13436 | 水泵螺柱螺母 | NUT WATER PUMP STUD | 1 |
| 36 | 30271 | 传动轴橡胶环 | RING Rubber DRIVESHAFT | 1 |
| 36 | 8M0214918 | 环@5 | RING @5 | 1 |
| 37 | 29804 | 进水管导向套 | SLEEVE GUIDE - WATER INLET TUBE | 1 |
| 37 | 29804T | 套筒 | SLEEVE | 1 |
| 38 | 78902 | 换挡轴-下部 | SHAFT SHIFT - LOWER | 1 |
| 38 | 789022 | 换档轴 | SHIFT SHAFT | 1 |
| 39 | 29641 | 换挡轴E型挡圈 | E RING RETIANING - SHIFT SHAFT | 1 |
| 40 | 78907 | 挡圈 | RING Retaining | 1 |
| 41 | 25439 | O-RING (.862 x .103) SHIFT SHAFT BUSHING | 1 | |
| 42 | 77631A2 | 换挡轴衬套总成 | BUSHING ASSEMBLY SHIFT SHAFT | 1 |
| 43 | 76384 | 换挡轴衬套油封 | SEAL Oil SHIFT SHAFT BUSHING | 1 |
| 43 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 44 | 77674 | WASHER (.35 x .75 x .12) RUBBER - SHIFT SHAFT BUSHING | 1 | |
| 45 | 79953 | SCREW (.375-16 x .250) GREASE FILLER | 1 | |
| 45 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 46 | 67892 | SCREW Magnetic DRAIN | 1 | |
| 46 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 47 | 19183 | 纤维垫圈-润滑脂加注与排放螺钉 | WASHER Fiber GREASE FILLER AND DRAIN SCREW | 2 |
| 47 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 2 |
| - | 42579A4 | 水泵修理包 | REBUILD KIT Water Pump | 1 |
| - | 96148A8 | 水泵维修套件 | WATER PUMP REPAIR KIT | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 904841 | 分隔板衬垫 | GASKET DIVIDER PLATE | 2 |
| 2 | 99169A1 | 分隔板 | PLATE DIVIDER | 1 |
| 3 | 69668 | 分隔板密封件 | SEAL DIVIDER PLATE | 1 |
| 3 | 814754 | 密封件(12.50英寸) | SEAL (12.50 Inches) | 1 |
| 4 | 193071 | 排气歧管盖 | COVER EXHAUST MANIFOLD | 1 |
| 5 | 74824 | 螺钉（0.312-18 x 1.250）盖和板至气缸体 | SCREW (.312-18 x 1.250) COVER AND PLATE TO CYLINDER BLOCK | 21 |
| 6 | 194373 | 接线板（3端子） | TERMINAL BLOCK (3 TERMIALS) | 1 |
| 7 | 13716 | 零件手册 7.5/9.8马力 接线板 | PARTS MANUAL 7.5 /9.8 H.P. TERMIAL BL0CK | 2 |
| 8 | 29245 | 垫圈（0.281 x 0.500 x 0.060）不锈钢接线板螺钉 | WASHER (.281 x .500 x .060) Stainless Steel TERMIMAL BLOCK SCREW | 2 |
| 8 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 9 | 45076 | 端子排黄铜螺母(#10-32) | NUT (#10-32) Brass TERMINAL BLOCK | 3 |
| 10 | 813938 | 盖螺母（#10-32）接线板 | CAP NUT (#10-32) TERMINAL BLOCK | 3 |
| 11 | 74824 | 缸体盖板螺钉(.312-18 x 1.250) | SCREW (.312-18 x 1.250) COVER TO CYLINDER BLOCK | 4 |
| 12 | 69570 | 膜片至板件螺钉(#10-16 x .750) | SCREW (#10-16 x .750) DIAPHRAGM TO PLATE | 1 |
| 13 | 76451 | 膜片螺钉垫片 | WASHER DIAPHRAGM SCREW | 1 |
| 14 | 14479 | 隔膜 | DIAPHRAGM | 1 |
| 14 | 144791 | 隔膜 | DIAPHRAGM | 1 |
| 15 | 16496 | 导水板 | DEFLECTOR Water | 1 |
| 16 | 16497A1 | 安全阀板 | PLATE RELIEF VALVE | 1 |
| 17 | 78690 | 安全阀板衬垫 | GASKET RELIEF VALVE PLATE | 2 |
| 17 | 78690002 | 衬垫 | GASKET | 2 |
| 18 | 64878 | 弹簧（黑色）压缩弹出阀 | SPRING (Black) COMPERSSION POPPER VALVE | 1 |
| 19 | 85303 | 提升阀弹簧垫片 | WASHER POPPET SPRING | 1 |
| 20 | 14480 | 提升阀 | POPPET VALVE | 1 |
| 21 | 64872 | 提升阀衬套 | GROMMET POPPET VALVE | 1 |
| 22 | 65848 | 提升阀座 | CARRIER POPPET VALVE | 1 |
| 23 | 991763 | 排气板衬垫 | GASKET EXHAUST PLATE | 1 |
| 23 | 991764 | 衬垫 | GASKET | 1 |
| 24 | 41944A5 | 排气板总成 | PLATE ASSEMBLY EXHAUST | 1 |
| 25 | 99664 | 排气板弯头 | ELBOW EXHAUST PLATE | 1 |
| 25 | 996642 | 90度弯头接头(0.125-27x0.250)尼龙 | FITTING Elbow 90 Degree (.125-27 x .250) Nylon | 1 |
| 26 | 20033 | 排气板定位销 | PIN Dowel LOCATING - EXHAUST PLATE | 2 |
| 26 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 27 | 183982 | 排气板密封件 | SEAL EXHAUST PLATE | 1 |
| 27 | 8M0043165 | 密封件-27.00英寸 | SEAL-27.00 INCH | 1 |
| 28 | 680101 | 密封件固定支架 | BRACKET SEAL RETAINING | 1 |
| 29 | 812832 | 支架至排气板螺钉(#10-16 x .500) | SCREW (#10-16 x .500) BRACKET TO EXHAUST PLATE | 6 |
| 29 | 878608 | 螺钉(#10-16 x 0.500) | SCREW (#10-16 x .500) | 6 |
| 30 | 25970 | 动力头螺柱垫圈 | WASHER POWERHEAD STUD | 6 |
| 30 | 20553 | 垫圈(.406 x .734 x .063) | WASHER (.406 x .734 x .063) | 6 |
| 31 | 69254 | 螺母 动力头螺柱 | NUT POWWERHEAD STUD | 6 |
| 32 | 27132 | 排气板衬套 | BUSHING EXHAUST PLATE | 1 |
| 33 | 19564 | 护孔环 | GROMMET | 1 |
| 33 | 8M0179867 | 护孔环 | GROMMET | 1 |
| 34 | 12602 | 排气板衬套 | GROMMET EXHAUST PLATE | 1 |
| 34 | 12602002 | 护孔环 | GROMMET | 1 |
| 35 | 66727 | 螺钉(.312-18 x 1.250)排气板固定 | SCREW (.312-18 x 1.250) EXHAUST PLATE ATTACHING | 1 |
| 36 | 68783 | 螺钉(.312-18 x 2.50)排气板固定 | SCREW (.312-18 x 2.50) EXHAUST PLATE ATTACHING | 1 |
| 37 | 66725 | 螺钉(.375-16 x 3.50)排气板固定 | SCREW (.375-16 x 3.50) EXHAUST PLATE ATTACHING | 3 |
| 37 | 898833 | 螺钉(.375-16 x 3.500) | SCREW (.375-16 x 3.500) | 3 |
| 38 | 812905A2 | 前支架总成 | BRACKET ASSEMBLY FRONT | 1 |
| 38 | 812905T | 前支架 | BRACKET Front | 1 |
| 39 | 90285 | 螺钉（0.312-18 x 0.625）前支架 | SCREW (.312-18 x .625) FRONT BRAKET | 4 |
| 40 | 187031 | 垫圈 | WASHER | 4 |
| 41 | 18778 | 护孔环 | GROMMET | 4 |
| 41 | 18778001 | 护孔环 | GROMMET | 4 |
| 42 | 18578A3 | 后支架总成 | BRACKET ASSEMBLY Rear REAR | 1 |
| 42 | 18578T09 | 支架总成(后部) | BRACKET ASSEMBLY Rear | 1 |
| 43 | 14462A1 | 安全阀盖(旧设计) | COVER RELIEF VALVE (OLD DESIGN) | 1 |
| 43 | 68729 | 泄压阀盖（新设计） | COVER RELIEF VALVE (NEW DESIGN) | 1 |
| 43 | 8M0039767 | 盖板 | COVER | 1 |
| 44 | 92007 | 接头（0.250-18）（90度）（新设计） | FITTING (.250-18) (90 DEGREES) (NEW DESIGN) | 1 |
| 44 | 920071 | 90度弯头 | FITTING (90 Degree) | 1 |
| 45 | 99127109 | 管路（57.00英寸散装）（新设计） | LINE (57.00 Inches Bulk) (NEW DESIGN) | 1 |
| 45 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 46 | 90077 | 扎带（新设计） | TIE STRAP (NEW DESIGN) | 2 |
| 46 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 2 |
| 47 | 814430 | 接头（0.500-14）（新设计） | FITTING (.500-14) (NEW DESIGN) | 1 |
| 47 | 8144301 | 接头 | FITTING | 1 |
| - | 14697A87 | 衬垫套件 | GASKET SET | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 15221A2 | 气缸盖总成 | CYLINDER HEAD ASSEMBLY | 2 |
| 2 | 41246 | 气缸盖衬垫 | GASKET CYLINDER HEAD | 2 |
| 2 | 41247T01 | 衬垫 | GASKET | 2 |
| 3 | 98534 | 螺钉 (0.375-16 x 2.30) 气缸盖（2英寸） | SCREW (.375-16 x 2.30) CYLINDER HEAD (2") | 23 |
| 3 | 13450 | 螺钉 (0.375-16 x 2.30) 气缸盖（专用） | SCREW (.375-16 x 2.30) CYLINDER HEAD (SPECIAL) | 1 |
| 4 | 25909 | 气缸盖螺钉垫圈 (.406 x .812 x .065) | WASHER (.406 x .812 x .065) CYLINDER HEAD SCREW | 24 |
| 5 | 75692 | 节温器 | THERMOSTAT | 2 |
| 6 | 62386 | 节温器衬垫 | GASKET THERMOSTAT | 2 |
| 6 | 8M0204714 | 衬垫@4 | GASKET @4 | 2 |
| 7 | 90390A1 | 节温器盖套件 | COVER KIT THERMOSTAT | 2 |
| 8 | 35386 | 螺钉 (0.312-18 x 1.00) 节温器盖（1英寸） | SCREW (.312-18 x 1.00) THERMOSTAT COVER (1") | 4 |
| 9 | 68727 | 90度黄铜弯头接头 (.250-18)（水管用） | FITTING (.250-18) 90 Degree - Brass ELBOW - WATER HOSES | 1 |
| 9 | 687271 | 90度弯头 (.250-18) - 黄铜 | FITTING (.250-18) 90 Degree - Brass | 1 |
| 10 | 7765377 | 配水软管（散装24.500英寸） | HOSE (24.500 Inches Bulk) WATER DISTRIBUTION | 2 |
| 10 | 77653101 | 软管（散装48.00英寸） | HOSE (48.00 Inches Bulk) | 2 |
| 11 | 68728 | 节温器盖至水管接头 | FITTING THERMOSTAT COVER TO WATER HOSES | 1 |
| 12 | 90077 | 水管束带 | TIE STRAP WATER HOSES | AR |
| 12 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 13 | 97465 | 温度传感器（右舷） | SENDER Temperature (STARBOARD) | 1 |
| 13 | 13536A6 | 温度传感器总成（左舷） | SENSOR ASSEMBLY Temperature (PORT) | 1 |
| 14 | 13715 | 传感器固定座 | RETAINER SENSOR AND SENDER | 2 |
| 14 | 137151 | 固定座 | RETAINER | 2 |
| 15 | 98257 | 螺钉 (0.312-18 x 0.500) 固定座 | SCREW (.312-18 x .500) RETAINER | 2 |
| 16 | 13192 | 爆震传感器 | SENSOR Detonation | 1 |
| 16 | 825164A1 | 爆震传感器总成 | SENSOR ASSEMBLY Detonation | 1 |
| 17 | 45076 | 螺母 (#10-32) 黄铜爆震传感器 | NUT (#10-32) Brass DETONATION SENSOR | 1 |
| 18 | 14593A4 | 适配板总成 | ADAPTER PLATE ASSEMBLY | 1 |
| 19 | 28668 | 螺钉 (0.250-20 x 0.875) 不锈钢适配板 | SCREW (.250-20 x .875) Stainless Steel ADAPTOR PLATE | 8 |
| 20 | 146971 | 适配板垫片 | GASKET ADAPTOR PLATE | 1 |
| 21 | 75953 | 簧片阀组 | REED BLOCK | 6 |
| 22 | 75362A1 | 簧片组件 | REED ASSEMBLY | 6 |
| 23 | 96183 | 簧片夹 | CLAMP Reed | 12 |
| 23 | 961832 | 簧片夹 | CLAMP Reed | 12 |
| 24 | 14783 | 螺钉 (#8-32 x 0.187) 簧片至簧片座 | SCREW (#8-32 x .187) REEDS TO REED BLOCK | 60 |
| 24 | 823588 | 螺钉 (#8-32 x .250) | SCREW (#8-32 x .250) | 60 |
| 25 | 21558 | 螺钉 (0.250-20 x 0.75) 簧片座固定（3/4英寸） | SCREW (.250-20 x .75) REED BLOCK ATTACHING (3/4") | 6 |
| 25 | 92160 | 螺钉(.250-20 x .750)不锈钢 | SCREW (.250-20 x .750) Stainless Steel | 6 |
| 26 | 90197 | 螺钉 (0.250-20 x 1.125) 簧片座固定（2英寸） | SCREW (.250-20 x 1.125) REED BLOCK ATTACHING (2") | 6 |
| 27 | 167371 | 适配板垫片 | GASKET ADAPTOR PLATE | 1 |
| - | 14697A87 | 衬垫套件 | GASKET SET |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 195871 | 安装板 | PLATE MOUNTING | 1 |
| 2 | 30720 | 电压调节器螺钉(.250-20 x 2.25) | SCREW (.250-20 x 2.25) VOLTAGE REGULATOR | 4 |
| 3 | 26992 | 锁紧垫圈(.250)不锈钢 | LOCKWASHER (.250) Stainless Steel | 4 |
| 4 | 19661 | 衬套 | BUSHING | 4 |
| 5 | 18736A15 | 电压调节器总成 | REGULATOR ASSEMBLY Voltage | 1 |
| 5 | 18736A21 | 调节器总成 | REGULATOR ASSY | 1 |
| 6 | 18717 | 密封件 | SEAL | 1 |
| 7 | 96158 | 启动电磁阀 | SOLENOID Starter | 2 |
| 7 | 8M0185622 | 电磁阀 | SOLENOID | 2 |
| 8 | 90192 | 螺钉 (.250-20 x .750) 不锈钢 启动电磁阀 | SCREW (.250-20 x .750) Stainless Steel STARTER SOLENOID | 3 |
| 9 | 88807A6 | 线束总成 (3.50英寸) 黑色 (3-1/2" - BLACK) | CABLE ASSEMBLY (3.50 Inches) Black (3-1/2" - BLACK) | 1 |
| 10 | 56374 | 电磁阀螺钉螺母(.250-20) | NUT (.250-20) SOLENOID SCREW | 3 |
| 10 | 8267098 | 螺母 (.250-20) 不锈钢 | NUT (.250-20) Stainless Steel | 3 |
| 11 | 26419 | 螺母 (#8-32) 黄铜 电磁阀端子 (8-32) | NUT (#8-32) Brass SOLENOID TERMINAL (8-32) | 4 |
| 12 | 94330 | 螺母 (.250-20) 黄铜 电磁阀端子 (1/4-20) | NUT (.250-20) Brass SOLENOID TERMINAL (1/4-20) | 4 |
| 13 | 97861 | 绝缘体 启动电磁阀 (旧设计) | INSULATOR STARTER SOLENOID (OLD DESIGN) | 2 |
| 14 | 87379A14 | 电线总成 (2.750英寸) (2-3/4" - RED) | WIRE ASSEMBLY (2.750 Inches) (2-3/4" - RED) | 1 |
| 14 | 88807A8 | 线束总成 (3.50英寸) 黑色 (3-1/2" - BLACK) | CABLE ASSEMBLY (3.50 Inches) Black (3-1/2" - BLACK) | 2 |
| 15 | 88807A29 | 电缆总成(9英寸-黑色) | CABLE ASSEMBLY (9" - BLACK) | 1 |
| 16 | 90077 | 扎带 | TIE STRAP | AR |
| 16 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 17 | 43542 | 点火线圈盖 | COVER IGNITION COIL | 2 |
| 18 | 7370A13 | 点火线圈总成 | COIL ASSEMBLY Ignition | 6 |
| 18 | 8M0230859 | 点火线圈总成 | COIL IGNITION ASY | 6 |
| 19 | 90048 | 点火线圈盖螺钉(#10-32 x 2.125) | SCREW (#10-32 x 2.125) IGNITION COIL COVER | 8 |
| 20 | 90078 | 盖板螺钉/接地线螺母(#10-32) | NUT (#10-32) COVER SCREW/GROUND WIRE | 14 |
| 21 | 813715A9 | 高压点火线束套件 | CABLE KIT Ignition HIGH TENSION | 1 |
| 22 | 63709A1 | 高压电缆护套/端子套件 | BOOT/TERMINAL KIT HIGH TENSION CABLE | 6 |
| 23 | 14103568 | 火花塞 | SPARK PLUG | 6 |
| 23 | 896329885 | SP #L6VC @4 | SP #L6VC @4 | 6 |
| 24 | 45076 | 螺母(#10-32)黄铜点火线圈端子 | NUT (#10-32) Brass IGNITION COIL TERMINAL | 12 |
| 25 | 88807A13 | 线束总成 (5-1/2" - BLACK) | CABLE ASSEMBLY (5-1/2" - BLACK) | 6 |
| 26 | 69022 | SCREW (#10-32 x .500) Stainless Steel GROUNDING WIRE | 2 | |
| 27 | 69739A7 | 线圈至开关盒线束总成 | HARNESS ASSEMBLY COIL TO SWITCH BOX | 1 |
| 28 | 54676 | 双线固定夹 | RETAINER Two Wire | 2 |
| 29 | 814423T | 线圈板盖 | COVER COIL PLATE | 1 |
| 30 | 814343 | 螺钉 (#10-32 x 2.380) | SCREW (#10-32 x 2.380) | 4 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 15132 | 徽标（3英寸） | EMBLEM (3") | 1 |
| - | 151321 | 徽标（6英寸） | EMBLEM (6") | 2 |
| 1 | 9742A61 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 9742T92 | 顶盖总成-黑色 | TOP COWL ASY-BLK | 1 |
| 1 | 9742A19 | 顶罩总成（纪念版） | TOP COWL ASSEMBLY (ANNIVERSARY MODEL) | 1 |
| 1 | 9742T90 | 顶盖总成-黑色 | TOP COWL ASY-BLK | 1 |
| 2 | 812784 | 密封件 | SEAL | 1 |
| 3 | 815478 | 密封件 | SEAL | 1 |
| 4 | 815225 | 隔音垫(侧) | SOUND BLANKET (SIDE) | 2 |
| 5 | 815226 | 隔音垫(顶) | SOUND BLANKET (TOP) | 1 |
| 5A | 815227 | 隔音毯（前部） | SOUND BLANKET (FRONT) | 1 |
| 6 | 17196A1 | 进气口护罩（纪念版） | SHIELD AIR INLET (ANNIVERSARY MODEL) | 2 |
| 7 | 11316 | 快速螺母（纪念版） | SPEED NUT (ANNIVERSARY MODEL) | 12 |
| 8 | 17238 | 进气口密封（纪念版） | SEAL AIR INLET (ANNIVERSARY MODEL) | 4 |
| 9 | 17194 | 进气口护罩（左舷）（纪念版） | SHIELD AIR INLET (PORT) (ANNIVERSARY MODEL) | 1 |
| 9 | 17195 | 进气口护罩（右舷）（纪念版） | SHIELD AIR INLET (STARBOARD) (ANNIVERSARY MODEL) | 1 |
| 10 | 184741 | 后支架 | BRACKET REAR | 2 |
| 11 | 18506 | 护孔环 | GROMMET | 3 |
| 11 | 18506001 | 护孔环 | GROMMET | 3 |
| 12 | 28636 | 螺钉(.250-20 x .750) 后支架 | SCREW (.250-20 x .750) REAR BRACKET | 12 |
| 13 | 26992 | 锁紧垫圈(.250)不锈钢 后支架螺钉 | LOCKWASHER (.250) Stainless Steel REAR BRACKET SCREW | 10 |
| 14 | 813096 | 挂钩 | HOOK | 2 |
| 14 | 813096A2 | 挂钩套件 | HOOK KIT | 2 |
| 15 | 73286 | 螺钉(0.250-20×0.500)不锈钢 | SCREW (.250-20 x .500) Stainless Steel | 2 |
| 16 | 813074 | 滚轮 | ROLLER | 2 |
| 16 | 8M0207770 | 滚轮@3 | ROLLER @3 | 2 |
| 17 | 13194 | 挡圈 | RING Retaining | 2 |
| 18 | 813553 | 安装板 | PLATE | 1 |
| 18 | 56720 | 垫圈(0.330×0.750×0.060)不锈钢 | WASHER (.330 x .750 x .060) Stainless Steel | 1 |
| 19 | 187021 | 定位器 | LOCATOR | 1 |
| 20 | 18173 | 锁扣滚轮支架总成 | BRACKET ASSEMBLY Latch Roller | 1 |
| 20 | 893763 | 滚轮锁扣支架 | BRACKET Roller Latch | 1 |
| 21 | 813552 | 隔套 | SPACER | 1 |
| 21 | 813076A2 | 手柄套件 | HANDLE KIT | 1 |
| 22 | 31984 | 螺钉(0.312-18×1.375) | SCREW (.312-18 x 1.375) | 2 |
| 23 | 815848 | 螺母 (.312) | NUT (.312) | 2 |
| 24 | 47341A1 | 手动/应急启动绳和手柄套件 (用于手动启动) | ROPE AND HANDLE KIT Manual/Emergency Start (FOR MANUAL STARTING) | 1 |
| 24 | 47341A11 | 手动启动绳柄套件 | ROPE AND HANDLE KIT Manual Starting | 1 |
| 25 | 18755A1 | 前护罩总成 | FRONT SHIELD ASSEMBLY | 1 |
| 26 | 813562 | 密封件 | SEAL | 1 |
| 27 | 48409 | 螺钉 (#10-16 x .625) 不锈钢 | SCREW (#10-16 x .625) Stainless Steel | 4 |
| 28 | 56681 | 垫圈 (.203 x .500 x .032) | WASHER (.203 x .500 x .032) | 4 |
| 28 | 8M0204666 | 垫圈 (.203 x .500 x .032) | WASHER (.203 x .500 x .032) | 4 |
| 29 | 70132 | 垫圈(0.323×0.563×0.063)不锈钢 | WASHER (.323 x .563 x .063) Stainless Steel | 2 |
| 29 | 8M0042642 | 垫圈(.323 x .562 x .063) | WASHER (.323 x .562 x .063) | 2 |
| - | 813096A1 | 后锁扣套件 | REAR LATCH KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 816626A20 | 钥匙开关线束总成(20英尺) | HARNESS ASSEMBLY Key Switch (20.00 Feet) | 1 |
| 2 | 90468A1 | 钥匙盖总成 | COVER ASSEMBLY Key | 2 |
| 3 | 76424 | 支架 | BRACKET | 1 |
| 4 | 55422 | 双头螺柱 (#10-32 x 2.00) | STUD (#10-32 x 2.00) | 2 |
| 5 | 24676 | 垫圈 (.200 x .440 x .032) | WASHER (.200 x .440 x .032) | 2 |
| 6 | 68219 | 螺母 (#10-32) 不锈钢 | NUT (#10-32) Stainless Steel | 2 |
| 7 | 816479A3 | 板组件套件 | PLATE KIT | 2 |
| 8 | 88107A5 | 钥匙开关套件 | SWITCH KIT Key | 1 |
| 9 | 879755 | 特殊螺母-黑色尼龙 | NUT Special - Black Nylon | 1 |
| 10 | 816492A1 | 音响报警器总成 | ALARM ASSEMBLY Audio Warning | 1 |
| 10 | 8M0210763 | 报警器 | ALARM | 1 |
| 11 | 8127111 | 垫片(0.375) | SPACER (.375) | 2 |
| 11 | 812711 | 隔套(0.250) | SPACER (.250) | 2 |
| - | 894911 | 点火钥匙(1A) | KEY Ignition (1A) | 1 |
| - | 894912 | 点火钥匙(1B) | KEY Ignition (1B) | 1 |
| - | 894913 | 点火钥匙(1C) | KEY Ignition (1C) | 1 |
| - | 894914 | 点火钥匙(1D) | KEY Ignition (1D) | 1 |
| - | 894915 | 点火钥匙(1E) | KEY Ignition (1E) | 1 |
| - | 894916 | 点火钥匙(1F) | KEY Ignition (1F) | 1 |
| - | 894917 | 点火钥匙(2A) | KEY Ignition (2A) | 1 |
| - | 894918 | 点火钥匙(2B) | KEY Ignition (2B) | 1 |
| - | 894919 | 点火钥匙(2C) | KEY Ignition (2C) | 1 |
| - | 8949110 | 点火钥匙(2D) | KEY Ignition (2D) | 1 |
| - | 8949111 | 点火钥匙(2E) | KEY Ignition (2E) | 1 |
| - | 8949112 | 点火钥匙(2F) | KEY Ignition (2F) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 904841 | 分隔板衬垫 | GASKET DIVIDER PLATE | 2 |
| 2 | 99169A1 | 分隔板 | PLATE DIVIDER | 1 |
| 3 | 69668 | 分隔板密封件 | SEAL DIVIDER PLATE | 1 |
| 3 | 814754 | 密封件(12.50英寸) | SEAL (12.50 Inches) | 1 |
| 4 | 193071 | 排气歧管盖 | COVER EXHAUST MANIFOLD | 1 |
| 5 | 74824 | 螺钉（0.312-18 x 1.250）盖和板至气缸体 | SCREW (.312-18 x 1.250) COVER AND PLATE TO CYLINDER BLOCK | 21 |
| 6 | 194373 | 接线板（3端子） | TERMINAL BLOCK (3 TERMIALS) | 1 |
| 7 | 13716 | 零件手册 7.5/9.8马力 接线板 | PARTS MANUAL 7.5 /9.8 H.P. TERMIAL BL0CK | 2 |
| 8 | 29245 | 垫圈（0.281 x 0.500 x 0.060）不锈钢接线板螺钉 | WASHER (.281 x .500 x .060) Stainless Steel TERMIMAL BLOCK SCREW | 2 |
| 8 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 9 | 45076 | 端子排黄铜螺母(#10-32) | NUT (#10-32) Brass TERMINAL BLOCK | 3 |
| 10 | 813938 | 盖螺母（#10-32）接线板 | CAP NUT (#10-32) TERMINAL BLOCK | 3 |
| 11 | 74824 | 缸体盖板螺钉(.312-18 x 1.250) | SCREW (.312-18 x 1.250) COVER TO CYLINDER BLOCK | 4 |
| 12 | 69570 | 膜片至板件螺钉(#10-16 x .750) | SCREW (#10-16 x .750) DIAPHRAGM TO PLATE | 1 |
| 13 | 76451 | 膜片螺钉垫片 | WASHER DIAPHRAGM SCREW | 1 |
| 14 | 14479 | 隔膜 | DIAPHRAGM | 1 |
| 14 | 144791 | 隔膜 | DIAPHRAGM | 1 |
| 15 | 16496 | 导水板 | DEFLECTOR Water | 1 |
| 16 | 16497A1 | 安全阀板 | PLATE RELIEF VALVE | 1 |
| 17 | 78690 | 安全阀板衬垫 | GASKET RELIEF VALVE PLATE | 2 |
| 17 | 78690002 | 衬垫 | GASKET | 2 |
| 18 | 64878 | 弹簧（黑色）压缩弹出阀 | SPRING (Black) COMPERSSION POPPER VALVE | 1 |
| 19 | 85303 | 提升阀弹簧垫片 | WASHER POPPET SPRING | 1 |
| 20 | 14480 | 提升阀 | POPPET VALVE | 1 |
| 21 | 64872 | 提升阀衬套 | GROMMET POPPET VALVE | 1 |
| 22 | 65848 | 提升阀座 | CARRIER POPPET VALVE | 1 |
| 23 | 991763 | 排气板衬垫 | GASKET EXHAUST PLATE | 1 |
| 23 | 991764 | 衬垫 | GASKET | 1 |
| 24 | 41944A5 | 排气板总成 | PLATE ASSEMBLY EXHAUST | 1 |
| 25 | 99664 | 排气板弯头 | ELBOW EXHAUST PLATE | 1 |
| 25 | 996642 | 90度弯头接头(0.125-27x0.250)尼龙 | FITTING Elbow 90 Degree (.125-27 x .250) Nylon | 1 |
| 26 | 20033 | 排气板定位销 | PIN Dowel LOCATING - EXHAUST PLATE | 2 |
| 26 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 27 | 183982 | 排气板密封件 | SEAL EXHAUST PLATE | 1 |
| 27 | 8M0043165 | 密封件-27.00英寸 | SEAL-27.00 INCH | 1 |
| 28 | 680101 | 密封件固定支架 | BRACKET SEAL RETAINING | 1 |
| 29 | 812832 | 支架至排气板螺钉(#10-16 x .500) | SCREW (#10-16 x .500) BRACKET TO EXHAUST PLATE | 6 |
| 29 | 878608 | 螺钉(#10-16 x 0.500) | SCREW (#10-16 x .500) | 6 |
| 30 | 25970 | 动力头螺柱垫圈 | WASHER POWERHEAD STUD | 6 |
| 30 | 20553 | 垫圈(.406 x .734 x .063) | WASHER (.406 x .734 x .063) | 6 |
| 31 | 69254 | 螺母 动力头螺柱 | NUT POWWERHEAD STUD | 6 |
| 32 | 27132 | 排气板衬套 | BUSHING EXHAUST PLATE | 1 |
| 33 | 19564 | 护孔环 | GROMMET | 1 |
| 33 | 8M0179867 | 护孔环 | GROMMET | 1 |
| 34 | 12602 | 排气板衬套 | GROMMET EXHAUST PLATE | 1 |
| 34 | 12602002 | 护孔环 | GROMMET | 1 |
| 35 | 66727 | 螺钉(.312-18 x 1.250)排气板固定 | SCREW (.312-18 x 1.250) EXHAUST PLATE ATTACHING | 1 |
| 36 | 68783 | 螺钉(.312-18 x 2.50)排气板固定 | SCREW (.312-18 x 2.50) EXHAUST PLATE ATTACHING | 1 |
| 37 | 66725 | 螺钉(.375-16 x 3.50)排气板固定 | SCREW (.375-16 x 3.50) EXHAUST PLATE ATTACHING | 3 |
| 37 | 898833 | 螺钉(.375-16 x 3.500) | SCREW (.375-16 x 3.500) | 3 |
| 38 | 812905A2 | 前支架总成 | BRACKET ASSEMBLY FRONT | 1 |
| 38 | 812905T | 前支架 | BRACKET Front | 1 |
| 39 | 90285 | 螺钉（0.312-18 x 0.625）前支架 | SCREW (.312-18 x .625) FRONT BRAKET | 4 |
| 40 | 187031 | 垫圈 | WASHER | 4 |
| 41 | 18778 | 护孔环 | GROMMET | 4 |
| 41 | 18778001 | 护孔环 | GROMMET | 4 |
| 42 | 18578A3 | 后支架总成 | BRACKET ASSEMBLY Rear REAR | 1 |
| 42 | 18578T09 | 支架总成(后部) | BRACKET ASSEMBLY Rear | 1 |
| 43 | 14462A1 | 安全阀盖(旧设计) | COVER RELIEF VALVE (OLD DESIGN) | 1 |
| 43 | 68729 | 泄压阀盖（新设计） | COVER RELIEF VALVE (NEW DESIGN) | 1 |
| 43 | 8M0039767 | 盖板 | COVER | 1 |
| 44 | 92007 | 接头（0.250-18）（90度）（新设计） | FITTING (.250-18) (90 DEGREES) (NEW DESIGN) | 1 |
| 44 | 920071 | 90度弯头 | FITTING (90 Degree) | 1 |
| 45 | 99127109 | 管路（57.00英寸散装）（新设计） | LINE (57.00 Inches Bulk) (NEW DESIGN) | 1 |
| 45 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 46 | 90077 | 扎带（新设计） | TIE STRAP (NEW DESIGN) | 2 |
| 46 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 2 |
| 47 | 814430 | 接头（0.500-14）（新设计） | FITTING (.500-14) (NEW DESIGN) | 1 |
| 47 | 8144301 | 接头 | FITTING | 1 |
| - | 14697A87 | 衬垫套件 | GASKET SET | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 15110A1 | 转速表 | TACHOMETER | 1 |
| 2 | 79101 | 安装支架 | BRACKET MOUNTING | 1 |
| 2 | 79101T | 支架 | BRACKET | 1 |
| 3 | 72729 | 楔形底座灯泡(14V - 1.9W) | LIGHT BULB Wedge Base (14V - 1.9W) | 1 |
| 4 | 79888 | 灯泡插座 | SOCKET Light Bulb | 1 |
| 5 | 26419 | 黄铜螺母 (#8-32) | NUT (#8-32) Brass | 5 |
| 6 | 86322A7 | 电缆总成(1.50英尺)黑色 微调表 | CABLE ASSEMBLY (1.50 Feet) Black TRIM GAUGE | 1 |
| 6 | 86323A5 | 电缆总成(1.50英尺)紫色 微调表 | CABLE ASSEMBLY (1.50 Feet) Purple TRIM GAUGE | 1 |
| 7 | 15113A4 | 配平表 | TRIM GAUGE | 1 |
| 7 | 895292Q41 | 动力升降倾斜指示器 黑面橙白刻度黑边框 | GAUGE Power Trim Indicator, Black Face, Orange/White Graduations, Black Bezel | 1 |
| 8 | 79480 | 安装支架-微调表 | BRACKET MOUNTING - TRIM GAUGE | 1 |
| 9 | 72729 | 灯泡 楔形底座(14V-1.9W)微调表 | LIGHT BULB Wedge Base (14V - 1.9W) TRIM GAUGE | 1 |
| 10 | 79888 | 灯泡插座 微调表 | SOCKET Light Bulb TRIM GAUGE | 1 |
| 11 | 26419 | 螺母(#8-32)黄铜 微调表端子 | NUT (#8-32) Brass TRIM GAUGE TERMINAL | 5 |
| 12 | 26427 | 调整垫片（仪表端子） | WASHER TRIM GAUGE TERMINAL | 2 |
| 13 | 86396A8 | 转速表线束总成(5.00英尺) | HARNESS ASSEMBLY Tachometer (5.00 Feet) | 1 |
| 14 | 15166A1 | 温度表 | TEMPERATURE GAUGE | 1 |
| 14 | 895287Q41 | 水温表套件(100-240℉)黑面橙白刻度黑框 | WATER TEMPERATURE GAUGE KIT (100-240 F) Black Face, Orange/White Graduations, Black Bezel | 1 |
| 15 | 72729 | 楔形底座灯泡(14V - 1.9W) | LIGHT BULB Wedge Base (14V - 1.9W) | 1 |
| 16 | 79888 | 灯泡插座 | SOCKET Light Bulb | 1 |
| 17 | 26427 | 垫圈 | WASHER | 2 |
| 18 | 79480 | 支架 | BRACKET | 1 |
| 19 | 26419 | 黄铜螺母 (#8-32) | NUT (#8-32) Brass | 5 |
| 20 | 86323A2 | 电缆总成(2英尺)紫色 | CABLE ASSEMBLY (2.00 Feet) Purple | 1 |
| 20 | 61600A16 | 电缆总成(17英寸)黑色 | CABLE ASSEMBLY (17.00 Inches) Black | 1 |
| 20 | 88824A4 | 电缆总成(45英寸)棕褐色 | CABLE ASSEMBLY (45.00 Inches) Tan | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 92876A3 | 转向安装包 (单) | ATTACHING KIT Steering (SINGLE) | 1 |
| 1 | 41055 | 转向管支架 | MOUNT STEERING TUBE | 1 |
| 2 | 88319 | 转向连杆联轴器 | COUPLING STEERING LINK | 1 |
| 2 | 850791T | 联轴器 | COUPLER | 1 |
| 3 | 73732 | 螺钉(0.375-24×1.120)联轴器 | SCREW (.375-24 x 1.120) COUPLING | 2 |
| 4 | 34863 | 螺母(0.375-24)联轴器螺钉 | NUT (.375-24) COUPLING SCREW | 3 |
| 4 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 3 |
| 5 | 59702 | 螺钉(0.250-28×0.875)不锈钢支架固定 | SCREW (.250-28 x .875) Stainless Steel MOUNT ATTACHING | 4 |
| 6 | 88404 | 锁紧垫圈-支架螺钉 | TAB WASHER MOUNT SCREW | 2 |
| 7 | 71565 | 转向电缆导管 | TUBE Cable Guide STEERING | 1 |
| 8 | 37984 | 螺母(0.875-14)转向管 | NUT (.875-14) STEERING TUBE | 2 |
| 8 | 8M0041651 | 螺母 (.875-14) | NUT (.875-14) | 2 |
| 9 | 42100 | 锁紧垫圈-转向管螺母 | TAB WASHER STEERING TUBE NUT | 2 |
| 10 | 78862A2 | 密封套件 | SEAL KIT | 1 |
| 10 | 19624A1 | 密封套件 | SEAL KIT | 1 |
| 11 | 42101 | 隔套 | SPACER | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 7620A4 | 顶部罩壳总成左舷（黑色） | TOP COWL ASSEMBLY PORT (BLACK) | 1 |
| 1 | 7620A22 | 顶部罩壳总成左舷（灰色） | TOP COWL ASSEMBLY PORT (GRAY) | 1 |
| 1 | 9447A18 | 顶罩总成左舷(牡蛎色) | TOP COWL ASSEMBLY PORT (OYSTER) | 1 |
| 2 | 67260 | 控制电缆密封件 | SEAL CONTROL CABLE | 1 |
| 3 | 67258 | 罩垫总成至前盖 | PAD COWL ASSEMBLY TO FRONT COVER | 1 |
| 4 | 88227 | 隔音毯-罩 | BLANKET SOUND - COWL | 1 |
| 4A | 193681 | 密封件(3.20英寸)左舷罩(牡蛎色) | SEAL (3.20 Inch) PORT COWL (OYSTER) | 1 |
| 5 | 87987 | 罩安装支架-(上) | BRACKET COWL ATTACHING - (UPPER) | 2 |
| 5 | 879871 | 支架 | BRACKET | 2 |
| 6 | 87985 | 罩安装支架-(下) | BRACKET COWL ATTACHING - (LOWER) | 2 |
| 6 | 879851 | 支架 | BRACKET | 2 |
| 7 | 37562 | 螺丝(.312-18 x 1.00)不锈钢上下支架 | SCREW (.312-18 x 1.00) Stainless Steel UPPER AND LOWER BRACKETS | 8 |
| 8 | 68049 | 进气罩-右舷 | SHIELD INLET -COWL (STARBOARD) | 1 |
| 8 | 68048 | 进气罩-左舷(黑/灰) | SHIELD INLET - COWL (PORT) (BLACK/GRAY) | 1 |
| 8 | 680491 | 进气罩-右舷(牡蛎色) | SHIELD INLET - COWL (STARBOARD) - (OYSTER) | 1 |
| 8 | 680481 | 进气罩-左舷(牡蛎色) | SHIELD INLET - COWL (PORT) (OYSTER) | 1 |
| 9 | 48409 | 螺丝(#10-16 x .625)不锈钢罩至护罩 | SCREW (#10-16 x .625) Stainless Steel SHIELD TO COWL | 4 |
| 10 | 7619A1 | 顶罩总成右舷(黑色) | TOP COWL ASSEMBLY STARBOARD (BLACK) | 1 |
| 10 | 7619A5 | 顶罩总成右舷(灰色) | TOP COWL ASSEMBLY STARBOARD (GRAY) | 1 |
| 10 | 9452A3 | 顶罩总成右舷(牡蛎色) | TOP COWL ASSEMBLY STARBOARD (OYSTER) | 1 |
| 11 | 88227 | 隔音毯-罩 | BLANKET SOUND - COWL | 1 |
| 12 | 67260 | 线束密封件 | SEAL HARNESS | 1 |
| 12A | 193681 | 密封件(3.20英寸)右舷罩(牡蛎色) | SEAL (3.20 Inch) STARBOARD COWL (OYSTER) | 1 |
| 13 | 62628 | 保持筒-罩锁扣 | BARREL RETAINING - COWL LATCH | 2 |
| 14 | 46785A5 | 罩壳锁扣总成 | LATCH ASSEMBLY Cowl | 2 |
| 15 | 31312 | 螺丝(#10-32 x 0.875)筒至罩锁扣 | SCREW (#10-32 x 0.875) BARREL TO COWL LATCH | 2 |
| 16 | 15222 | 调节杆-罩锁扣 | BAR ADJUSTING - COWL LATCH | 2 |
| 17 | 62629 | 罩锁扣保持筒 | BARREL RETAINING COWL LATCH | 2 |
| 18 | 62624 | 罩壳锁扣弹簧 | SPRING COWL LATCH | 2 |
| 19 | 30164 | 垫圈(.192 x .375 x .0312)不锈钢弹簧至调节杆 | WASHER (.192 x .375 x .0312) Stainless Steel SPRING TO ADJUSTING BAR | 2 |
| 20 | 45812 | 螺母(#10-32)不锈钢弹簧至调节杆 | NUT (#10-32) Stainless Steel SPRING TO ADUSTING BAR | 2 |
| 20 | 859124 | 螺母 (#10-32) 不锈钢 | NUT (#10-32) Stainless Steel | 2 |
| 21 | 7532A2 | 前罩总成(黑色) | COVER ASSEMBLY Cowl - Front (BLACK) | 1 |
| 21 | 7532A23 | 前罩总成(灰色) | COVER ASSEMBLY Cowl - Front (GRAY) | 1 |
| 21 | 7532A32 | 前罩总成(牡蛎色) | COVER ASSEMBLY Cowl - Front (OYSTER) | 1 |
| 21 | 7532A23 | 前罩总成 | COVER ASSEMBLY Cowl - Front | 1 |
| 22 | 67615 | 隔音毯-前罩盖 | BLANKET SOUND - COWL FRONT COVER | 1 |
| 23 | 87907 | 前罩盖挂钩 | HOOK COWL FRONT COVER | 1 |
| 24 | 70332 | 螺丝(#10-16 x .500)挂钩至前罩盖 | SCREW (#10-16 x .500) HOOK TO COWL FRONT COVER | 1 |
| 24 | 95700 | 螺钉(#10-16 x .50) | SCREW (#10-16 x .50) | 1 |
| 25 | 47341A1 | 手动/应急启动绳柄套件 | ROPE AND HANDLE KIT Manual/Emergency Start | 1 |
| 25 | 47341A11 | 手动启动绳柄套件 | ROPE AND HANDLE KIT Manual Starting | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 880890T1 | 燃油泵 | PUMP Fuel | 1 |
| 2 | NSS | 不单独销售本体 | NOT SOLD SEPARATE Body | 1 |
| 3 | 881544 | 弹簧 | SPRING | 1 |
| 4 | 881545 | 柱塞 | PLUNGER | 1 |
| 5 | 881546 | 弹簧 | SPRING | 1 |
| 6 | 881547 | 隔膜 | DIAPHRAGM | 1 |
| 7 | 881548 | 销 | PIN | 1 |
| 8 | NSS | 不单独销售本体 | NOT SOLD SEPARATE Body | 1 |
| 9 | NSS | 膜片(不单独销售) | NOT SOLD SEPARATE Diaphragm | 1 |
| 10 | NSS | 不单独销售本体 | NOT SOLD SEPARATE Body | 1 |
| 11 | 881550 | 螺钉 | SCREW | 3 |
| 12 | 881333 | 螺母 | NUT | 3 |
| 13 | 804255 | O型圈 | O-RING | 1 |
| 13 | 8M0050719 | O型圈 | O-RING | 1 |
| 14 | 879650 | 卡箍 | CLAMP | 2 |
| 14 | 56762 | 扎带(4.00英寸) | TIE STRAP (4.00 Inches) | 2 |
| 15 | 804256 | 螺栓 (M6 x 30) | BOLT (M6 x 30) | 2 |
| 16 | 881543 | 软管 | HOSE | 1 |
| 16 | 881543002 | 油管 | TUBING | 1 |
| 17 | 881542 | 支架 | BRACKET | 1 |
| 18 | 8527768 | 螺栓(M6 x 16) | BOLT (M6 x 16) | 1 |
| 18 | 811188T | 螺栓 | BOLT | 1 |
| 19 | 8528161 | 螺母 | NUT | 1 |
| 19 | 82382M | 螺母 | NUT | 1 |
| 20 | 881538T1 | 滤清器总成 | FILTER ASSEMBLY | 1 |
| 20 | 881538T02 | 燃油滤清器总成 | FILTER ASSY-FUEL | 1 |
| 21 | 881540 | 滤芯1.75英寸 | ELEMENT 1.75 Inches | 1 |
| 21 | 8M0168897 | 燃油滤清器 | FUEL FILTER | 1 |
| 21 | 8M0101436 | 滤芯1.50英寸 | ELEMENT 1.50 Inches | 1 |
| 21 | 8M0117705 | 燃油滤清器 | FILTER-FUEL | 1 |
| 22 | 826966M | O型圈 | O-RING | 1 |
| 22 | 826966T | O型圈 | O RING | 1 |
| 23 | 881541 | 浮子 | FLOAT | 1 |
| 24 | 881539 | 杯套 | CUP | 1 |
| 24 | 8M0101437 | 杯套 | CUP | 1 |
| 24 | 8M0137185 | 燃油杯 | CUP FUEL | 1 |
| 25 | 879650 | 卡箍 | CLAMP | 2 |
| 25 | 56762 | 扎带(4.00英寸) | TIE STRAP (4.00 Inches) | 2 |
| 26 | 804260 | 支架 | BRACKET | 1 |
| 27 | 804112 | 螺栓(M7 x 48) | BOLT (M7 x 48) | 2 |
| 28 | 804113 | 定位销 | PIN Dowel | 2 |
| 29 | 84292M | 垫圈 | WASHER | 2 |
| 30 | 804257 | 燃油转换杆 | LEVER Fuel Change | 1 |
| 31 | 881334 | 轴 | SHAFT | 1 |
| 32 | 804259 | 销 | PIN | 2 |
| 32 | 82738M | 滚销 | PIN-ROLL | 2 |
| 33 | 830757130 | 管材(.312)(70英寸整卷)裁切至55英寸长度 | TUBING (.312) (70.00 Inches Bulk) Cut to 55.00 Inch Length. | 1 |
| 33 | 8M0108349 | 软管 (70英寸散装) | HOSE (70 Inches Bulk) | 1 |
| 34 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 1 |
| 35 | 822769 | 连接器 | CONNECTOR | 1 |
| 36 | NSS | 盖帽(不单独销售) | NOT SOLD SEPARATE Cap | 1 |
| 37 | 828547T1 | 导管(.500内径 x 3英尺整卷) | CONDUIT (.500 Inside Diameter x 3.00 Feet Bulk) | 1 |
| - | 858732T01 | 衬垫套件 | GASKET SET | 1 |
| - | 858732T02 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 858732T02 | 动力头衬垫套件 | GASKET SET Powerhead | 1 |
| - | 881310T1 | 气缸盖总成 | CYLINDER HEAD ASSEMBLY | 1 |
| - | 881310T09 | 气缸盖 | HEAD-CYLINDER | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 67245T | 上罩安装支架 | BRACKET COWL MOUNTING - UPPER | 1 |
| 2 | 67272 | 罩壳安装支架衬套 | GROMMET COWL MOUNTING BRACKET | 2 |
| 3 | 90435 | 罩壳安装支架(黑/灰) | MOUNT COWL MOUNTING BRACKET BLACK/GRAY | 2 |
| 4 | 29245 | 安装垫圈(0.281×0.500×0.060)不锈钢 | WASHER (.281 x .500 x .060) Stainless Steel MOUNT ATTACHING | 4 |
| 4 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 4 |
| 5 | 35888 | 安装螺母(0.250-28)不锈钢 | NUT (.250-28) Stainless Steel MOUNT ATTACHING | 4 |
| 6 | 87076A4 | 怠速控制总成 | IDLE SPEED CONTROL ASSEMBLY | 1 |
| 7 | 799831 | 阻风板 | PLATE CHOKE | 1 |
| 8 | 67274 | 阻风板至化油器衬垫 | GASKET CHOKE PLATE TO CARBURETOR | 1 |
| 8 | 672741 | 衬垫 | GASKET | 1 |
| 9 | 68000 | 螺丝(.250-28 x 1.00)阻风板至化油器 | SCREW (.250-28 x 1.00) CHOKE PLATE TO CARBURETOR | 6 |
| 10 | 20583 | 阻风板螺丝垫圈 | WASHER CHOKE PLATE SCREW | 6 |
| 11 | 67275 | 盖衬垫 | GASKET COVER | 1 |
| 11 | 672751 | 衬垫 | GASKET | 1 |
| 12 | 67246T | 进气消音器盖 | COVER INDUCTION SILENCER | 1 |
| 13 | 30720 | 螺丝(.250-20 x 2.25)盖至阻风板 | SCREW (.250-20 x 2.25) COVER TO CHOKE PLATE | 2 |
| 14 | 29245 | 垫圈(.281 x .500 x .060)不锈钢盖螺丝 | WASHER (.281 x .500 x .060) Stainless Steel COVER SCREW | 2 |
| 14 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 15 | 26992 | 锁紧垫圈(.250)不锈钢盖螺丝 | LOCKWASHER (.250) Stainless Steel COVER SCREW | 2 |
| 16 | 90585 | 进气消音器盖塞 | PLUG INDUCTION SILENCER COVER | 1 |
| 17 | 67760 | 油门连杆 | LINK Throttle | 1 |
| 18 | 67759 | 节气门杆(上) | LEVER Throttle UPPER | 1 |
| 19 | 41049 | 节气门杆(中) | LEVER Throttle CENTER | 1 |
| 20 | 67749 | 下节流阀杆 | LEVER Throttle LOWER | 1 |
| 21 | 15124 | 油门杆至油门连杆螺钉(#10-32×0.750) | SCREW (#10-32 x .750) THROTTLE LEVERS TO THROTTLE LINK | 3 |
| 22 | 26996 | 锁紧垫圈(#10)不锈钢节气门杆螺丝 | LOCKWASHER (#10) Stainless Steel THROTTLE LEVERS SCREW | 3 |
| 23 | 56681 | 垫圈(.203 x .500 x .032)节气门杆螺丝 | WASHER (.203 x .500 x .032) THROTTLE LEVERS SCREW | 3 |
| 23 | 8M0204666 | 垫圈 (.203 x .500 x .032) | WASHER (.203 x .500 x .032) | 3 |
| 24 | 67297 | U型销节气门杆至节气门连杆 | PIN Clevis THROTTLE LEVERS TO THROTTLE LINK | 3 |
| 25 | 89302 | 垫圈(.203 x .406 x .040)U型销 | WASHER (.203 x .406 x .040) CLEVIS PIN | 3 |
| 26 | 26953 | 开口销U型销 | COTTER PIN CLEVIS PIN | 3 |
| 27 | 67748 | 下节气门杆滚轮 | ROLLER LOWER THROTTLE LEVER | 1 |
| 28 | 69020 | 螺丝(#10-32 x .875)怠速控制 | SCREW (#10-32 x .875) IDLE SPEED CONTROL | 2 |
| 28 | 690201 | 螺钉(#10-32 x .875) | SCREW (#10-32 x .875) | 2 |
| 29 | 38833 | 怠速调节螺钉垫片 | WASHER IDLE SPEED CONTROL SCREW | 2 |
| - | 90484A88 | 衬垫套件 | GASKET SET |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 818904T1 | 旋转支架 | SWIVEL BRACKET | 1 |
| 2 | 87735 | 下油封 | SEAL Oil Lower | 1 |
| 3 | 818764 | 衬套 | BUSHING | 2 |
| 4 | 33504 | O型圈 | O-RING | 1 |
| 4 | 8M0214926 | O型圈 @10 | O RING @10 | 1 |
| 5 | 816039 | 隔套 | SPACER | 1 |
| 6 | 74036 | 润滑脂接头 | FITTING Grease | 2 |
| 6 | 8M0169589 | 润滑脂接头 | FITTING Grease | 2 |
| 7 | 821207 | 衬套 | BUSHING | 2 |
| 8 | 64014 | 螺钉(.250-28x.500) | SCREW (.250-28 x .500) | 2 |
| 9 | 99661A26 | 旋转销总成 | SWIVEL PIN ASSEMBLY | 1 |
| 9 | 99661A35 | 旋转销总成 | SWIVEL PIN ASSEMBLY | 1 |
| 10 | 92876A10 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 10 | 92876A12 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 11 | 849838 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 1 |
| 12 | 826709113 | 不锈钢螺母 (.375-24) | NUT (.375-24) Stainless Steel | 2 |
| 12 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 2 |
| 13 | 37828 | 不锈钢垫圈 (.390 x .625 x .062) | WASHER (.390 x .625 x .062) Stainless Steel | 2 |
| 14 | 42961A1 | 底部轭架总成 | YOKE ASSEMBLY Bottom | 1 |
| 14 | 42961A06 | 底部轭架总成 | YOKE ASSEMBLY Bottom | 1 |
| 15 | 67684 | 挡圈 | RING Retaining | 1 |
| 16 | 816432 | 止推垫片 | THRUST WASHER | 1 |
| 17 | NSS | 不单独销售 贴纸, 序列号覆膜 | NOT SOLD SEPARATE Decal, Serial Overlaminate | 1 |
| 18 | 11288 | 下轭缓冲垫 | BUMPER Bottom Yoke | 1 |
| 18 | 11288001 | 下轭缓冲垫 | BUMPER Bottom Yoke | 1 |
| 19 | 88882 | 上轭缓冲垫 | BUMPER Top Yoke | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8718A1 | 艉板支架总成(右舷) | BRACKET ASSEMBLY Transom (STARBOARD) | 1 |
| 2 | 8716A5 | 艉板支架总成(左舷) | BRACKET ASSEMBLY Transom (PORT) | 1 |
| 2 | 8716A8 | 艉板支架总成 | BRACKET ASSEMBLY Transom | 1 |
| 3 | 98727 | 润滑配件左舷艉板支架 | FITTING Grease PORT TRANSOM BRACKET | 1 |
| 3 | 8M0169588 | 润滑脂接头 | FITTING Grease | 1 |
| 5 | 99170A1 | 倾斜管 | TILT TUBE | 1 |
| 5 | 99170A2 | 倾斜管套件 | TUBE KIT Tilt | 1 |
| 6 | 90068T | 倾斜管螺母（1英寸-14牙） | NUT TILT TUBE (1"-14) | 1 |
| 6 | 859133 | 螺母(1.00-14) | NUT (1.00-14) | 1 |
| 7 | 45711 | O-RING (.612 x .103) TILT TUBE | 1 | |
| 8 | 88750 | 波形垫圈(1.62 x 1.05)倾斜管 | WASHER Wave (1.62 x 1.05) TILT TUBE | 2 |
| 9 | 56041 | 螺母 (.875-14) 倾斜管 (7/9-14) | NUT (.875-14) TILT TUBE (7/9-14) | 1 |
| 9 | 858869 | 螺母 (.875-14) | NUT (.875-14) | 1 |
| 10 | 677551 | 螺钉(.500-20 x 4.500)艉板支架至艉板 | SCREW (.500-20 x 4.500) TRANSOM BRACKET TO TRANSOM | 4 |
| 10 | 8M0149747 | 螺钉 | SCREW | 4 |
| 11 | 28421 | 垫圈(1.5 x 3.05 x 0.13)不锈钢艉板支架螺栓 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel TRANSOM BRACKET BOLT | 4 |
| 11 | 8M0204648 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 12 | 8M0027784 | 艉板支架螺栓螺母 | NUT TRANSOM BRACKET BOLT | 4 |
| 12 | 82671117 | 螺母(.500-20) | NUT (.500-20) | 4 |
| 13 | 99629A2 | 倾斜锁杆总成 | LEVER ASSEMBLY TILT LOCK | 1 |
| 13 | 8M0115104 | 倾斜锁定杆总成 | LEVER ASSEMBLY Tilt Lock | 1 |
| 14 | 99611 | 倾斜杆波形垫圈 | WAVE WASHER TILT LEVER | 1 |
| 15 | 65830 | 倾斜杆尼龙衬套 | NYLINER TILT LEVER | 2 |
| 16 | 99633 | 倾斜锁杆旋钮 | KNOB TILT LOCK LEVER | 1 |
| 17 | 99615 | 槽销 | PIN Groove | 1 |
| 18 | 99622 | 弹簧 | SPRING | 1 |
| 19 | 99604 | 槽销 | PIN Groove | 1 |
| 20 | 96930A1 | 倾斜锁螺栓总成 | BOLT ASSEMBLY TILT LOCK | 1 |
| 21 | 23161 | 螺栓螺母（3/8英寸-24牙） | NUT (.375-24) BOLT | 1 |
| 22 | 814207 | 倾斜止动杆 | STOP TILT LEVER | 1 |
| 23 | 37984 | 螺母 (.875-14) | NUT (.875-14) | 1 |
| 23 | 8M0041651 | 螺母 (.875-14) | NUT (.875-14) | 1 |
| - | 14697A87 | 衬垫套件 | GASKET SET |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8745A5 | 曲轴总成(含8个39-67377) | CRANKSHAFT ASSEMBLY (INCLUDES 8 OF 39-67377) | 1 |
| 2 | 67923 | 曲轴下球轴承 | BEARING Ball CRANKSHAFT (LOWER) | 1 |
| 2 | 67923T | 滚珠轴承 | BEARING Ball | 1 |
| 3 | 67446 | 球轴承挡圈 | RING BALL BEARING | 1 |
| 4 | 99727A1 | 驱动齿轮 | GEAR Drive | 1 |
| 5 | 54196A6 | 密封载体总成 | CARRIER ASSEMBLY SEAL | 1 |
| 6 | 65800 | 填料载体 | PACKING CARRIER | 1 |
| 7 | 67377 | 曲轴密封环(.124厚度) | RING Sealing SEALING - CRANKSHAFT (.124 THICK) | AR |
| 7 | 67377T | 密封环 | RING Sealing | AR |
| 7 | 78633 | 曲轴密封环(.139厚度) | RING SEALING - CRANKSHAFT (.139 THICK) | AR |
| 8 | 88903 | 保持式滚柱轴承 | BEARING Roller RETAINED BEARING | 2 |
| 8 | 88903T | 轴承座圈 | RACE Bearing | 2 |
| 9 | 67444 | 保持轴承挡圈 | RING Retaining RETAINED BEARING | 2 |
| 10 | 67445 | 保持式滚柱轴承 | BEARING Roller RETAINED BEARING | 2 |
| 8 | 93495 | 非保持式滚柱轴承 | BEARING Roller LOOSE BEARING | 2 |
| 8 | 93495T | 滚柱轴承 | BEARING Roller | 2 |
| 9 | 67444 | 非保持轴承挡圈 | RING Retaining LOOSE BEARING | 2 |
| 11 | 7441A3 | 活塞总成(右舷-标准) | PISTON ASSEMBLY (STARBOARD-STANDARD) | 3 |
| 11 | 7441T36 | 活塞-右舷-标准 | PISTON-STBD-STD | 3 |
| 11 | 7443A2 | 活塞总成(右舷-加大0.015) | PISTON ASSEMBLY (STARBOARD - .015 O.S.) | AR |
| 11 | 7443A12 | 活塞-右舷-0.015 | PISTON-STBD-.015 | AR |
| 11 | 7445A2 | 活塞总成(右舷-加大0.030) | PISTON ASSEMBLY (STARBOARD-.030 O.S.) | AR |
| 11 | 7445A12 | 活塞-右舷-0.030 | PISTON-STBD-.030 | AR |
| 11 | 7442A3 | 活塞总成(左舷-标准) | PISTON ASSEMBLY (PORT-STANDARD) | 3 |
| 11 | 7442T36 | 活塞-左舷-标准 | PISTON-PORT-STD | 3 |
| 11 | 7444A2 | 活塞总成(左舷-0.015加大) | PISTON ASSEMBLY (PORT-.015 O.S.) | AR |
| 11 | 7444A12 | 活塞-左舷-0.015 | PISTON-PORT-.015 | AR |
| 11 | 7446A2 | 活塞总成(左舷-0.030加大) | PISTON ASSEMBLY (PORT-.030 O.S.) | AR |
| 11 | 7446T12 | 活塞-左舷-0.030 | PISTON-PORT-.030 | AR |
| 12 | 93481A12 | 活塞环组-标准(标准) | RING SET Piston - Standard (STANDARD) | 1 |
| 12 | 78918A4 | 活塞环组-0.015加大(0.015加大) | RING SET Piston - .015 Oversize (.015 O.S.) | AR |
| 12 | 85636A4 | 活塞环组-0.030加大(0.030加大) | RING SET Piston - .030 Oversize (.030 O.S.) | AR |
| 13 | 52035 | 锁环 | RING Lock | 12 |
| 13 | 857196 | 锁紧环 | LOCK RING | 12 |
| 14 | 8119A5 | 连杆总成 | CONNECTING ROD ASSEMBLY | 6 |
| 14 | 8119A6 | 连杆套件 | CONN ROD KIT | 6 |
| 15 | 93886 | 螺钉(0.312-28×0.875)连杆 | SCREW (.312-28 x .875) CONNECTING ROD | 12 |
| 16 | 47247 | 定位针垫圈 | WASHER NEEDLE LOCATING | 12 |
| 16 | 8M0032839 | 垫片@5 | WASHER @5 | 12 |
| 17 | 17514A1 | 轴承套件 | BEARING KIT | 6 |
| 17 | 8M0234886 | 轴承保持架 | CAGE BEARING | 6 |
| 18 | 67483 | 活塞端滚针轴承 | BEARING Needle PISTON END | 174 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 814247A3 | 齿轮箱总成（1.78:1传动比 - 黑色）（完整） | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Black (Complete) | 1 |
| - | 814247A4 | 齿轮箱总成（1.78:1传动比 - 灰色）（完整） | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Gray (Complete) | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 814247A1 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 814247T1 | 齿轮箱总成基础型-黑色 | GEAR HOUSING ASSEMBLY Basic-Black | 1 |
| 1 | 814247A2 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 1 | 814247T2 | ORD 1674-814247T1 | ORD 1674-814247T1 | 1 |
| 44 | 76039 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 44 | 760394 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 45 | 12239A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 45 | 850315A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 46 | 30622 | 弹簧 | SPRING | 1 |
| 47 | 44491A1 | 垫片组 | SHIM SET | AR |
| 47 | 8M0063266 | 垫片组 | SHIM SET | AR |
| 48 | 30894A1 | 圆锥轴承组 | BEARING SET Cup And Cone | 1 |
| 49 | 16279A2 | 前进齿轮总成 | GEAR ASSEMBLY Forward | 1 |
| 50 | 30895 | 滚针轴承 | BEARING Needle | 1 |
| 50 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 51 | 814756 | 离合器 | CLUTCH | 1 |
| 51 | 822539T | 离合器 | CLUTCH | 1 |
| 52 | 30632 | 十字销 | PIN Cross | 1 |
| 52 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 53 | 30893 | 弹簧 | SPRING | 1 |
| 54 | 12238T | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 55 | NSS | NOT SOLD SEPARATE REVERSE GEAR (PART OF 43-16279A2) | 1 | |
| 56 | 76358 | 止推垫片 | THRUST WASHER | 1 |
| 57 | 29976 | O型圈 | O-RING | 1 |
| 58 | 41529A2 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 58 | 41529T2 | 托架总成 | CARRIER ASSY | 1 |
| 59 | 98727 | 润滑脂接头 | FITTING Grease | 2 |
| 59 | 8M0169588 | 润滑脂接头 | FITTING Grease | 2 |
| 60 | 30956 | 滚针轴承 | BEARING Needle | 1 |
| 60 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 61 | 76868 | 密封件 | SEAL | 2 |
| 61 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 2 |
| 62 | 30281 | 键 | KEY | 1 |
| 63 | 52700 | 锁紧垫圈 | TAB WASHER | 1 |
| 64 | 52699 | 盖板 | COVER | 1 |
| 65 | 67891 | 填充块 | FILLER BLOCK | 1 |
| 65 | 8M0039169 | 填充块 | FILLER BLOCK | 1 |
| 66 | 65210 | 螺钉(.375-16 x 1.00) | SCREW (.375-16 x 1.00) | 1 |
| 68 | 816629 | 锁紧垫圈 | TAB WASHER | 1 |
| 68 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 69 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 69 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 70 | 31640A1 | 平衡板总成 | TRIM TAB ASSEMBLY | 2 |
| 70 | 31640Q4 | 平衡鳍板 | TRIM TAB | 2 |
| 71 | 66024 | 螺钉(.437-14 x 1.75) | SCREW (.437-14 x 1.75) | 1 |
| 72 | 45176 | 垫圈(.453 x .812 x .105)不锈钢 | WASHER (.453 x .812 x .105) Stainless Steel | 2 |
| 73 | 34933 | 螺母(.437-20)不锈钢 | NUT (.437-20) Stainless Steel | 2 |
| 73 | 8M0204653 | 螺母 | NUT | 2 |
| 74 | 13191A1 | 止推垫片 | THRUST WASHER | 1 |
| 74 | 13191Q01 | 止推垫片 | THRUST WASHER | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 814247A3 | 齿轮箱总成（1.78:1传动比 - 黑色）（完整） | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Black (Complete) | 1 |
| - | 814247A4 | 齿轮箱总成（1.78:1传动比 - 灰色）（完整） | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Gray (Complete) | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 814247A1 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 814247T1 | 齿轮箱总成基础型-黑色 | GEAR HOUSING ASSEMBLY Basic-Black | 1 |
| 1 | 814247A2 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 1 | 814247T2 | ORD 1674-814247T1 | ORD 1674-814247T1 | 1 |
| 2 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 2A | 43998 | 套筒 | SLEEVE | 1 |
| 3 | 20033 | 定位销 | PIN Dowel | 2 |
| 3 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 4 | 78638 | 双头螺柱(.438 x 3.12) | STUD (.438 x 3.12) | 1 |
| 4 | 786382 | 螺柱(.437-14/.437-20 x 3.120) | STUD (.437-14/.437-20 x 3.120) | 1 |
| 5 | 57920 | 双头螺柱(.44 x 2.06) | STUD (.44 x 2.06) | 2 |
| 5 | 8M0133358 | 双头螺栓(.437-14/.437-20×2.060) | STUD (.437-14/.437-20 x 2.060) | 2 |
| 6 | 56297 | 双头螺栓(.312×3.38) | STUD (.312 x 3.38) | 1 |
| 6 | 8M0034463 | 螺柱(.312-24 x 3.38) | STUD (.312-24 x 3.38) | 1 |
| 7 | 30667 | 双头螺栓(.250-20/.250-28×3.125) | STUD (.250-20/.250-28 x 3.125) | 2 |
| 7 | 306671 | 螺柱 | STUD | 2 |
| 8 | 35934A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 9 | 79953 | SCREW (.375-16 x .250) GREASE FILLER | 1 | |
| 9 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 10 | 67892 | SCREW Magnetic DRAIN | 1 | |
| 10 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 11 | 815168 | 驱动轴 | DRIVESHAFT | 1 |
| 12 | NSS | 不单独出售小齿轮（43-16279A2部件） | NOT SOLD SEPARATE PINION GEAR (PART OF 43-16279A2) | 1 |
| 13 | 19183 | 纤维垫圈 | WASHER Fiber | 2 |
| 13 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 2 |
| 14 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 15 | 42637A1 | 垫片组 | SHIM SET | AR |
| 15 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 16 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 16 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 17 | 42633 | 螺母 | NUT | 1 |
| 17 | 8245191 | 固定座 | RETAINER | 1 |
| 18 | 42579A3 | 水泵底座总成 | BASE ASSEMBLY Water Pump | 1 |
| 18 | 8M0077147 | 带水泵底座总成 | BASE ASSY-W/P | 1 |
| 19 | 426311 | 衬垫 | GASKET | 1 |
| 19 | 8M0204678 | 衬垫 | GASKET | 1 |
| 20 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 20 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 21 | 89238 | 油封 | SEAL Oil | 1 |
| 22 | 16977 | 油封 | SEAL Oil | 1 |
| 23 | 856081 | 下部衬垫 | GASKET LOWER | 1 |
| 23 | 8M0090319 | 衬垫@5 | GASKET @5 | 1 |
| 24 | 856091 | 上衬垫 | GASKET UPPER | 1 |
| 24 | 858524 | 衬垫 | GASKET | 1 |
| 25 | 32435 | 面板 | FACE PLATE | 1 |
| 25 | 8M0204677 | 面板 | PLATE-FACE | 1 |
| 26 | 96148A1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 26 | 96148T1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 27 | 48752 | 嵌件 | INSERT | 1 |
| 27 | 48752T | 嵌件 | INSERT | 1 |
| 28 | 38970 | 橡胶密封件 | SEAL RUBBER | 1 |
| 29 | 899841 | 叶轮 | IMPELLER | 1 |
| 29 | 89984T3 | 叶轮 | IMPELLER | 1 |
| 30 | 56654 | 键 | KEY | 1 |
| 30 | 8M0214992 | 键@5 | KEY @5 | 1 |
| 31 | 96411 | 螺钉(#14-8×2.25) | SCREW (#14-8 x 2.25) | 1 |
| 31 | 8M0215009 | 螺钉 | SCREW | 1 |
| 32 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 32 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 33 | 13438 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 33 | 8267119 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 34 | 36001 | 垫圈 | WASHER | 1 |
| 35 | 13436 | 螺母 | NUT | 1 |
| 37 | 29804 | 套筒 | SLEEVE | 1 |
| 37 | 29804T | 套筒 | SLEEVE | 1 |
| 38 | 815264 | 换档轴 | SHIFT SHAFT | 1 |
| 38 | 8152641 | 换档轴 | SHIFT SHAFT | 1 |
| 39 | 29641 | E型卡环 | E RING | 1 |
| 40 | 25439 | O型圈(.862×0.103) | O-RING (.862 x .103) | 1 |
| 41 | 77631A2 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 42 | 816464 | 油封 | SEAL Oil | 1 |
| 42 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 43 | 77674 | 垫圈（0.35 x 0.75 x 0.12）橡胶（换挡轴衬套） | WASHER (.35 x .75 x .12) RUBBER -SHIFT SHAFT BUSHING | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| - | 96148A5 | 水泵维修套件 | REPAIR KIT Water Pump | 1 |
| - | 96148A8 | 水泵维修套件 | WATER PUMP REPAIR KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 9148A18 | 齿轮箱总成 标准旋转2:1速比(长型)(黑色) | GEAR HOUSING ASSEMBLY Standard Rotation 2:1 Gear Ratio (LONG) (BLACK) | 1 |
| - | 9148A19 | 齿轮箱总成 标准旋转2:1速比(加长型)(黑色) | GEAR HOUSING ASSEMBLY Standard Rotation 2:1 Gear Ratio (X-LONG)(BLACK) | 1 |
| - | 9148T82 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| - | 9148A20 | 齿轮箱总成 标准旋转2:1速比(长型)(灰色) | GEAR HOUSING ASSEMBLY Standard Rotation 2:1 Gear Ratio (LONG)(GRAY) | 1 |
| - | 9148T87 | ORD 1647-9148T81 | ORD 1647-9148T81 | 1 |
| - | 9148A21 | 齿轮箱总成 标准旋转2:1速比(加长型)(灰色) | GEAR HOUSING ASSEMBLY Standard Rotation 2:1 Gear Ratio (X-LONG) (GRAY) | 1 |
| - | 9148T88 | ORD 1647-9148T82 | ORD 1647-9148T82 | 1 |
| - | 9148A8 | 齿轮箱总成 标准旋转1.87:1速比(长型)(黑色) | GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio (LONG)(BLACK) | 1 |
| - | 9148T84 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| - | 9148A9 | 齿轮箱总成 标准旋转1.87:1速比(加长)(黑色) | GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio (X-LONG)(BLACK) | 1 |
| - | 9148T85 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| - | 9148A10 | 齿轮箱总成 标准旋转1.87:1速比(长型)(灰色) | GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio (LONG)(GRAY) | 1 |
| - | 9148T84 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| - | 9148A13 | 齿轮箱总成 标准旋转1.87:1速比(加长型)(灰色) | GEAR HOUSING ASSEMBLY Standard Rotation 1.87:1 Gear Ratio (X-LONG)(GRAY) | 1 |
| - | 9148T91 | ORD 1647-9148T85 | ORD 1647-9148T85 | 1 |
| 1 | 9148A11 | 齿轮箱总成(黑色)(基本型) | GEAR HOUSING ASSEMBLY (BLACK)(BASIC) | 1 |
| 1 | 9148T47 | 齿轮箱-基础型-黑 | GEAR HSG-BASIC-BL | 1 |
| 1 | 9148A12 | 齿轮箱总成(灰色)(基本型) | GEAR HOUSING ASSEMBLY (GRAY) (BASIC) | 1 |
| 1 | 9148T47 | 齿轮箱-基础型-黑 | GEAR HSG-BASIC-BL | 1 |
| 48 | 78956 | 换挡凸轮 | SHIFT CAM | 1 |
| 48 | 789562 | 换挡凸轮 | SHIFT CAM | 1 |
| 49 | 89594A1 | 凸轮从动件总成 | FOLLOWER ASSEMBLY CAM | 1 |
| 50 | 816520 | 离合器作动杆 | ROD CLUTCH ACTUATOR | 1 |
| 50 | 79911A1 | 杆 | ROD | 1 |
| 51 | 79910 | 压缩弹簧 | SPRING COMPRESSION | 1 |
| 52 | 78910 | 压缩弹簧垫圈 | WASHER COMPRESSION SPRING | AR |
| 53 | 78906 | PIN SPRING LOCATOR | 1 | |
| 53 | 8M0084245 | 弹簧定位销 | PIN Spring Locator | 1 |
| 54 | 47397A1 | 轴承外圈垫片组(.002-3-5-10) | SHIM SET BEARING OUTER RACE (.002-3-5-10) | AR |
| 55 | 78172A1 | 圆锥滚子轴承总成 | BEARING ASSEMBLY Taper Roller | 1 |
| 56 | 44102A2 | 前进齿轮总成 | GEAR ASSEMBLY Forward | 1 |
| 56 | 44104A2 | 前进齿轮总成 | GEAR ASSEMBLY Forward | 1 |
| 56 | 44104T2 | 齿轮组 | GEAR SET | 1 |
| 57 | 73363 | 滚柱轴承(5/8") | BEARING Roller (5/8") | 2 |
| 57 | 73363T | 轴承 | BEARING | 2 |
| 57 | 549281 | 滚柱轴承(1") | BEARING Roller (1") | 1 |
| 58 | 78959 | 棘轮滑动离合器 | RATCHET SLIDING CLUTCH | 1 |
| 58 | 823174T | ORD 8M0100493 | ORD 8M0100493 | 1 |
| 59 | 78905 | 棘轮到螺旋桨轴十字销 | PIN Cross RATCHET TO PROPELLER SHAFT | 1 |
| 59 | 8M0084243 | 十字销 | PIN Cross | 1 |
| 60 | 78909 | 棘轮定位销 | PIN Detent RATCHET | 2 |
| 61 | 78962 | 十字销固定弹簧 | SPRING RETAINING-CROSS PIN | 2 |
| 62 | 94148 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 63 | NSS | 倒车齿轮(不单独销售)(43-44102A2或43-44104A2部件) | NOT SOLD SEPARATE Reverse Gear (Part of 43-44102A2 or 43-44104A2) | 1 |
| 64 | 681001 | 止推环 轴承座 | RING Thrust BEARING CARRIER | 1 |
| 65 | 88957A1 | 倒车档滚珠轴承 | BEARING Ball BALL - REVERSE GEAR | 1 |
| 65 | 88957T | 滚珠轴承 | BEARING Ball | 1 |
| 66 | 31534 | 轴承座O型圈 | O-RING BEARING CARRIER | 1 |
| 66 | 8M0214920 | O型圈 | O RING | 1 |
| 67 | 43567A1 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 67 | 43567T1 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 68 | 30956 | 滚针轴承-轴承座 | BEARING Needle BEARING CARRIER | 1 |
| 68 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 69 | 76868 | 轴承座密封 | SEAL BEARING CARRIER | 2 |
| 69 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 2 |
| 70 | 30281 | KEY LOCATING - BEARING CARRIER | 1 | |
| 71 | 79447 | 齿轮箱盖锁紧垫圈 | TAB WASHER GEAR HOUSING COVER | 1 |
| 72 | 79448 | 齿轮箱固定座 | RETAINER GEAR HOUSING | 1 |
| 72 | 8M2011027 | 固定座 | RETAINER | 1 |
| 73 | 31640A1 | TRIM TAB ASSEMBLY GEAR HOUSING | 1 | |
| 73 | 31640Q4 | 平衡鳍板 | TRIM TAB | 1 |
| 74 | 66024 | SCREW (.437-14 x 1.75) TRIM TAB TO GEAR HOUSING | 1 | |
| 75 | 67891 | 填充块 | FILLER BLOCK | 1 |
| 75 | 8M0039169 | 填充块 | FILLER BLOCK | 1 |
| 76 | 34933 | 螺母(.437-20)不锈钢 | NUT (.437-20) Stainless Steel | 2 |
| 76 | 8M0204653 | 螺母 | NUT | 2 |
| 77 | 65210 | 螺钉(.375-16 x 1.00) | SCREW (.375-16 x 1.00) | 1 |
| 77 | 74727 | 螺钉(.375-16 x 6.00) | SCREW (.375-16 x 6.00) | 1 |
| 78 | 13171 | 推力毂 | THRUST HUB | 1 |
| 78 | 835467Q01 | 止推垫片套件 | THRUST WASHER KIT | 1 |
| 79 | 31211A2 | 花键垫圈 | WASHER Splined | 1 |
| 79 | 31211Q03 | 垫圈总成 | WASHER ASSEMBLY | 1 |
| 80 | 816629 | 锁紧垫圈 | TAB WASHER | 1 |
| 80 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 81 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 81 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 82 | 423511 | 齿形锁紧垫圈 | LOCKWASHER Toothed | 1 |
| 83 | 45176 | 垫圈(.453 x .812 x .105)不锈钢 | WASHER (.453 x .812 x .105) Stainless Steel | 2 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| - | 815791A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815809A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815810A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 818904T1 | 旋转支架 | SWIVEL BRACKET | 1 |
| 2 | 87735 | 下油封 | SEAL Oil Lower | 1 |
| 3 | 818764 | 衬套 | BUSHING | 2 |
| 4 | 33504 | O型圈 | O-RING | 1 |
| 4 | 8M0214926 | O型圈 @10 | O RING @10 | 1 |
| 5 | 816039 | 隔套 | SPACER | 1 |
| 6 | 74036 | 润滑脂接头 | FITTING Grease | 2 |
| 6 | 8M0169589 | 润滑脂接头 | FITTING Grease | 2 |
| 7 | 821207 | 衬套 | BUSHING | 2 |
| 8 | 64014 | 螺钉(.250-28x.500) | SCREW (.250-28 x .500) | 2 |
| 9 | 99661A26 | 旋转销总成 | SWIVEL PIN ASSEMBLY | 1 |
| 9 | 99661A35 | 旋转销总成 | SWIVEL PIN ASSEMBLY | 1 |
| 10 | 92876A10 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 10 | 92876A12 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 11 | 849838 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 1 |
| 12 | 826709113 | 不锈钢螺母 (.375-24) | NUT (.375-24) Stainless Steel | 2 |
| 12 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 2 |
| 13 | 37828 | 不锈钢垫圈 (.390 x .625 x .062) | WASHER (.390 x .625 x .062) Stainless Steel | 2 |
| 14 | 42961A1 | 底部轭架总成 | YOKE ASSEMBLY Bottom | 1 |
| 14 | 42961A06 | 底部轭架总成 | YOKE ASSEMBLY Bottom | 1 |
| 15 | 67684 | 挡圈 | RING Retaining | 1 |
| 16 | 816432 | 止推垫片 | THRUST WASHER | 1 |
| 17 | NSS | 不单独销售 贴纸, 序列号覆膜 | NOT SOLD SEPARATE Decal, Serial Overlaminate | 1 |
| 18 | 11288 | 下轭缓冲垫 | BUMPER Bottom Yoke | 1 |
| 18 | 11288001 | 下轭缓冲垫 | BUMPER Bottom Yoke | 1 |
| 19 | 88882 | 上轭缓冲垫 | BUMPER Top Yoke | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9242A33 | 化油器(上部)(WH-40) | CARBURETOR (TOP) (WH-40) | 1 |
| 1 | 9242A34 | 化油器(中部)(WH-40) | CARBURETOR (CENTER) (WH-40) | 1 |
| 1 | 9242A35 | 化油器(下部)(WH-40) | CARBURETOR (BOTTOM) ( WH-40) | 1 |
| 1 | 7563A10 | 化油器(上部)(WH-35) | CARBURETOR (TOP) (WH-35) | 1 |
| 1 | 7563A11 | 化油器(中部)(WH-35) | CARBURETOR (CENTER) (WH-35) | 1 |
| 1 | 7563A12 | 化油器(下部)(WH-35) | CARBURATOR (BOTTOM) (WH-35) | 1 |
| 1 | 7563A13 | 化油器(上部)(WH-38) | CARBURETOR (TOP) (WH-38) | 1 |
| 1 | 7563A14 | 化油器(中部)(WH-38) | CARBURETOR (CENTER) (WH-38) | 1 |
| 1 | 7563A15 | 化油器(下部)(WH-38) | CARBURETOR (BOTTOM) (WH-38) | 1 |
| 2 | 6249 | 主量孔(.096)燃油室(WH-32)(WH-38) | JET Main (.096) FUEL BOWL(WH-32) (WH-38) | 6 |
| 2 | 8423 | 量孔(.094)浮子室(WH-35) | JET (.094) FUEL BOWL (.094) (WH-35) | 6 |
| 2 | 6680 | 量孔(.078)燃油室(WH-40) | JET (.078) FUEL BOWL (WH-40) | 6 |
| 3 | NSS | NOT SOLD SEPARATE Gasket-Cover Plate | 3 | |
| 4 | 6032 | 盖板 | PLATE COVER | 3 |
| 5 | NSS | 盖板螺钉(不单独销售) | NOT SOLD SEPARATE Screw-Cover Plate | 15 |
| 6 | 7822 | 燃油室(WH-33) | BOWL Fuel (WH-33) | 3 |
| 6 | 7823 | 燃油杯(顶部) | BOWL Fuel (TOP) | 1 |
| 6 | 7822 | 燃油杯(中部/底部) | BOWL Fuel (CENTER/BOTTOM) | 2 |
| 7 | NSS | 不单独销售 燃油杯螺钉 | NOT SOLD SEPARATE Screw-Fuel Bowl | 18 |
| 8 | 6025 | 主量孔塞 | PLUG MAIN JET | 6 |
| 9 | NSS | 不单独出售主量孔垫片 | NOT SOLD SEPARATE Gasket-Main Jet | 6 |
| 10 | 4216 | 主量孔(.064)(WH-33) | JET (.064) MAIN FUEL (WH-33) | 6 |
| 10 | 6246 | 主量孔(.048)(WH-32) | JET (.048) MAIN FUEL (WH-32) | 6 |
| 10 | 6028 | 主燃油量孔(.050)(WH-35) | JET (.050) MAIN FUEL (WH-35) | 6 |
| 10 | 6359 | 主燃油量孔(.052)(WH-38) | JET (.052) MAIN FUEL (WH-38) | 6 |
| 10 | 6201 | 主量孔(.080)(WH-40) | JET (.080) MAIN FUEL (WH-40) | 6 |
| 11 | NSS | 不单独出售 浮子销螺钉 | NOT SOLD SEPARATE Screw-Float Pin | 6 |
| 12 | NSS | 不单独出售进油针阀座垫片 | NOT SOLD SEPARATE Gasket--Inlet Needle and Seat | 6 |
| 13 | 7824 | 进油针阀总成 | NEEDLE/SEAT ASSEMBLY Inlet | 6 |
| 14 | NSS | 喷嘴座垫片(不单独销售) | NOT SOLD SEPARATE Gasket-Nozzle Boss | 6 |
| 15 | 9267 | 浮子 | FLOAT | 6 |
| 16 | NSS | 浮子杆销(不单独销售) | NOT SOLD SEPARATE Pin-Float Lever | 6 |
| 17 | NSS | NOT SOLD SEPARATE Gasket-Fuel Bowl | 3 | |
| 18 | 4541 | 怠速空气量孔螺钉 | SCREW IDLE AIR BLEED JET | 6 |
| 19 | NSS | 泄放量孔塞垫片(不单独销售) | NOT SOLD SEPARATE Gasket-Bleed Jet Plug | 6 |
| 20 | 5213 | 主量孔(.056)怠速空气量孔(WH-33) | JET Main (.056) IKLE AIR BLEED (WH-33) | 6 |
| 20 | 7831 | 主量孔(.058)怠速空气量孔(.058)(WH-32) | JET Main Fuel (.058) IDLE AIR BLEED (.058) (WH-32) | 6 |
| 20 | 6487 | 主量孔(.060)怠速空气量孔(WH-35) | JET Main (.060) IKLE AIR BLEED (WH-35) | 6 |
| 20 | 5317 | 怠速空气量孔(.046)(WH-38) | JET (.046) IDLE AIR BLEED (WH-38) | 6 |
| 20 | 6246 | 怠速空气量孔(.048)(WH-40) | JET (.048) IDLE AIR BLEED (WH-40) | 6 |
| 21 | 6027 | 节气门杠杆螺钉 | SCREW THROTTLE LEVER | 3 |
| 22 | 67752 | 节流阀杆 | LEVER THROTTLE | 3 |
| 23 | NSS | NOT SOLD SEPARATE Spring-Throttle Return | 3 | |
| 24 | 6031 | 节气门杠杆垫片 | SPACER THROTTLE LEVER | 3 |
| 25 | 6022 | 节流阀轴 | SHAFT THROTTLE | 3 |
| 26 | NSS | 节气门轴挡圈(不单独销售) | NOT SOLD SEPARATE Ring-Retainer-Throttle Shaft | 3 |
| 27 | 6023 | 节气门阀(WH-33)(WH-40) | VALVE Throttle (WH-33) (WH-40) | 6 |
| 27 | 9496 | 节气门阀(WH-32) | VALVE Throttle (WH-32) | 6 |
| 27 | 9545 | 节气门阀(WH-38)(WH-35) | VALVE Throttle (WH-38) (WH-35) | 6 |
| 28 | NSS | NOT SOLD SEPARATE Screw-Throttle Valve | 12 | |
| - | 6452 | 衬垫套件 | GASKET KIT | 1 |
| - | 8506 | 化油器修理包(WH-33)(WH-40) | REPAIR KIT Carburetor (WH-33) (WH-40) | 1 |
| - | 7826 | 修理包(WH-32)(WH-35)(WH-38) | REPAIR KIT (WH-32)(WH-35)(WH-38) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 12430A4 | 传感器总成 | SENSOR ASSEMBLY | 1 |
| 2 | 48409 | 螺钉(#10-16 x .625)不锈钢传感器固定(5/8") | SCREW (#10-16 x .625) Stainless Steel SENSOR ATTACHING (5/8") | 1 |
| 3 | 815699 | 油泵总成 | PUMP ASSEMBLY Oil | 1 |
| 3 | 815699T | 油泵总成 | PUMP ASSEMBLY Oil | 1 |
| 3A | 814103 | 轴承(带密封) | BEARING (W/SEAL) | 1 |
| 3A | 8141032 | 蜗杆衬套 | BUSHING Worm | 1 |
| 4 | 11379 | 油泵O型圈 | O-RING OIL PUMP | 1 |
| 5 | 41429A2 | 驱动齿轮轴承总成 | BEARING ASSEMBLY DRIVE GEAR | 1 |
| 6 | 12726 | 从动齿轮 | GEAR Driven | 1 |
| 6 | 14563 | 从动齿轮 | GEAR Driven | 1 |
| 7 | 32228 | 螺钉(#10-32 x .625)油泵至曲轴箱(5/8") | SCREW (#10-32 x .625) OIL PUMP TO CRANKCASE (5/8") | 1 |
| 7 | 41507 | 螺钉(#10-32 x 1.120)油泵至曲轴箱(1-1/8") | SCREW (#10-32 x 1.120) OIL PUMP TO CRANKCASE (1-1/8") | 1 |
| 8 | 1938512 | 油门连杆至油泵总成 | LINK ASSEMBLY THROTTLE LEVER TO OIL PUMP | 1 |
| 9 | 4301619 | 油泵油管 | TUBING OIL PUMP | 1 |
| 9 | 82381335 | 油管(15.00英寸 散装) | TUBING (15.00 Inches Bulk) | 1 |
| 10 | 99443T | 油箱 | RESERVOIR Oil | 1 |
| 10 | 994436 | 储液罐 | RESERVOIR | 1 |
| 11 | 415823 | 油管卡箍(大) | CLAMP OIL HOSE (LARGE) | 2 |
| 12 | 4301736 | 油箱至油泵油管 | TUBING OIL RESERVOIR TO OIL PUMP | 1 |
| 12 | 82381455 | 油管（25.00英寸散装） | TUBING (25.00 Inches Bulk) | 1 |
| 13 | 69020 | 螺钉(#10-32 x .875)油箱固定(7/8") | SCREW (#10-32 x .875) OIL RESERVOIR ATTACHING (7/8") | 3 |
| 13 | 690201 | 螺钉(#10-32 x .875) | SCREW (#10-32 x .875) | 3 |
| 14 | 42118 | 油箱螺钉垫圈 | WASHER OIL RESERVOIR SCREW | 6 |
| 15 | 42117 | 油箱螺钉衬套 | GROMMET OIL RESERVOIR SCREW | 3 |
| 16 | 42116 | 油箱螺钉轴套 | BUSHING OIL RESERVOIR SCREW | 3 |
| 17 | 99127109 | 油管(57.00英寸散装) | LINE (57.00 Inches Bulk) OIL | 1 |
| 17 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 18 | 42425 | 油管三通 | TEE OIL TUBING | 1 |
| 19 | 9072925 | 油管(6-3/4") | HOSE OIL (6-3/4") | 1 |
| 20 | NA | 不可用壳体总成 | NOT AVAILABLE HOUSING ASSEMBLY | 1 |
| 21 | 99439 | 油管(114.00英寸) | HOSE (114.00 Inches) OIL | 1 |
| 22 | 12540A3 | 壳体 | HOUSING | 1 |
| 23 | 12242A1 | 闩锁 | LATCH | 1 |
| 24 | 43278 | 止回阀接头(曲轴箱) | FITTING CHECK CALVE (CRANKCASE) | 1 |
| 24 | 8781051 | 止回阀 | CHECK VALVE | 1 |
| 25 | 87421 | 油箱 | TANK | 1 |
| 26 | 43298A2 | 油箱盖总成 | CAP ASSEMBLY OIL TANK | 1 |
| 27 | 11332 | O型圈(2.225 x .210)盖 | O-RING (2.225 x .210) CAP | 1 |
| 28 | 43295A5 | 壳体总成适配器 | HOUSING ASSEMBLY Adaptor | 1 |
| 28 | 816190A4 | 机油收集器总成(无传感器) | OIL PICK UP ASSEMBLY Without Sender | 1 |
| 29 | 11332 | O型圈(2.225 x .210)适配器壳体 | O-RING (2.225 x .210) ADAPTOR HOUSING | 1 |
| 30 | 99802 | 吸油管 | TUBE OIL PICK-UP | 1 |
| 31 | 43300A1 | 油箱盖总成 | CAP ASSEMBLY OIL RESERVOIR | 1 |
| 31 | 43300A9 | 盖总成 | CAP ASSEMBLY | 1 |
| 32 | 43307 | 油箱盖衬垫 | GASKET RESERVOIR CAP | 1 |
| 32 | 43307T | 衬垫 | GASKET | 1 |
| 33 | 99022A1 | 浮子总成 | FLOAT ASSEMBLY | 1 |
| 33 | 8M0187298 | 浮子总成 | FLOAT ASSY | 1 |
| 34 | 99265 | 压入式螺母 | PUSH NUT | 1 |
| 35 | 415824 | 油管卡箍(小) | CLAMP OIL HOSE (SMALL) | 2 |
| 36 | 90077 | 扎带 | TIE STRAP | AR |
| 36 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 37 | 12335A1 | 支架套件 | BRACKET KIT | 1 |
| 38 | 12323A1 | 绳索/挂钩套件 | CORD/HOOK KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 74897 | PIVOT TRIGGER PLATE | 1 | |
| 2 | 62459 | 球头总成触发板 | BALL JOINT ASSEMBLY TRIGGER PLATE | 1 |
| 2 | 62459T | 球头节总成 | BALL JOINT ASSY | 1 |
| 3 | 45076 | 螺母(#10-32)黄铜连杆 | NUT (#10-32) Brass LINK ROD | 1 |
| 4 | 76035 | 触发板连杆 | ROD TRIGGER PLATE | 1 |
| 5 | 46438 | 螺母(#10-32)球头 | NUT (#10-32) BALL JOINT | 1 |
| 6 | 41094A3 | 点火提前杆总成 | LEVER ASSEMBLY SPARK ADVANCE | 1 |
| 7 | 64022 | 螺丝(.250-20x2.125)点火提前杆-止动 | SCREW (.250-20 x 2.125) SPARK ADVANCE LEVER - STOP | 1 |
| 8 | 64015 | 螺母(.250-20)点火提前止动螺丝 | NUT (.250-20) SPARK ADVANCE STOP SCREW | 1 |
| 9 | 26852 | 尼龙帽点火提前杆止动螺丝 | CAP Nylon SPARK ADVANCE LEVER STOP SCREW | 1 |
| 10 | 13627 | 螺钉（0.190-32 x 1.250）点火提前杠杆-止动（1-1/4英寸） | SCREW (.190-32 x 1.250) SPARK ADVANCE LEVER - STOP (1-1/4") | 1 |
| 11 | 68219 | 螺母(#10-32)不锈钢点火提前杆止动螺丝 | NUT (#10-32) Stainless Steel SPARK ADVANCE LEVER STOP SCREW | 1 |
| 12 | 48039 | 点火提前杆止动螺丝帽 | CAP SPARK ADVANCE LEVER STOP SCREW | 1 |
| 13 | 41095T | 油门控制杆 | LEVER THROTTLE CONTROL | 1 |
| 13 | 410952 | 杠杆 | LEVER | 1 |
| 14 | 55337 | 螺钉（0.375-16 x 1.75）节气门杠杆/提前杠杆（1-3/4英寸） | SCREW (.375-16 x 1.75) THROTTLE LEVER/ADVANCE LEVER (1-3/4") | 1 |
| 14 | 818165 | 螺钉 (.375-16 x 1.75) | SCREW (.375-16 x 1.75) | 1 |
| 15 | 55164 | 油门杠杆衬套 | BUSHING THROTTLE LEVER | 1 |
| 16 | 55171 | 点火提前杆衬套 | BUSHING SPARK ADVANCE LEVER | 1 |
| 17 | 68784 | 节气门与点火提前杆弹簧 | SPRING THROTTLE AND SPARK ADVANCE LEVER | 1 |
| 18 | 68410 | 点火提前杆垫片 | WASHER SPARK ADVANCE LEVER | 1 |
| 18 | 46765 | 垫圈 (.390 x 1.50 x .120) | WASHER (.390 x 1.50 x .120) | 1 |
| 19 | 64022 | 螺钉（0.250-20 x 2.125）节气门杠杆-止动（2-1/8英寸） | SCREW (.250-20 x 2.125) THROTTLE LEVER - STOP (2-1/8") | 1 |
| 20 | 64015 | 螺母(.250-20)节气门杆止动螺丝 | NUT (.250-20) THROTTLE LEVER STOP SCREW | 1 |
| 21 | 26852 | 尼龙帽节气门杆止动螺丝 | CAP Nylon THROTTLE LEVER STOP SCREW | 1 |
| 22 | 39483 | 锁扣拉线 | LATCH CABLE | 1 |
| 23 | 22486 | 螺丝(.250-28x.880)拉线锁扣至节气门杆 | SCREW (.250-28 x .880) CABLE LATCH TO THROTTLE LEVER | 1 |
| 23 | 69026 | 螺钉 (.250-28 x .880) | SCREW (.250-28 x .880) | 1 |
| 24 | 20099 | 拉线锁扣至节气门杆弹簧 | SPRING CABLE LATCH TO THROTTLE LEVER | 1 |
| 25 | 20586 | 螺母(.250-28)拉线锁扣螺丝 | NUT (.250-28) CABLE LATCH SCREW | 1 |
| 25 | 826709109 | 不锈钢螺母(.250-28) | NUT (.250-28) Stainless Steel | 1 |
| 26 | 14634 | 节气门控制杆 | ROD THROTTLE CONTROL | 1 |
| 27 | 14638 | 节气门控制杆套筒 | BARREL THROTTLE CONTROL ROD | 1 |
| 28 | 146351 | 节气门凸轮 | CAM Throttle | 1 |
| 29 | 93248 | 衬套 | BUSHING | 1 |
| 29 | 8M0215006 | 旋转衬套 | BUSHING Swivel | 1 |
| 30 | 26856 | 节气门凸轮衬套 | BUSHING THROTTLE CAM | 2 |
| 31 | 35045 | 螺母（0.250-28）节气门凸轮螺柱 | NUT (.250-28) THROTTLE CAM STUD | 1 |
| 31 | 826709109 | 不锈钢螺母(.250-28) | NUT (.250-28) Stainless Steel | 1 |
| 32 | 41050 | 节气门复位弹簧 | SPRING THROTTLE RETURN | 1 |
| 33 | 92032A2 | 支架锚-控制电缆 | BRACKET ANCHOR - CTRL CABLES | 1 |
| 33 | 814283A2 | 支架总成 | BRACKET ASSEMBLY | 1 |
| 33 | 814283A1 | 控制线缆锚定支架 | BRACKET ANCHOR - CONTROL CABLES | 1 |
| 33 | 814283A2 | 支架总成 | BRACKET ASSEMBLY | 1 |
| 34 | 98889 | 控制线缆锁扣 | LATCH CONTROL CABLE | 1 |
| 35 | 42975 | 闩锁传动螺钉 | DRIVE SCREW LATCH | 2 |
| 36 | 53167 | 螺丝(.312-18x.880)锚定支架固定 | SCREW (.312-18 x .880) ANCHOR BRACKET ATTACHING | 3 |
| 36 | 53167T | 螺钉 0.312-18X 0.88 | SCREW .312-18X .88 | 3 |
| 37 | 37896 | 连杆导向块 | GUIDE BLOCK LINK ROD | 1 |
| 37 | 814284 | 连杆导向块 | GUIDE BLOCK LINK ROD | 1 |
| 38 | 20099 | 连杆至导向块弹簧 | SPRING LINK ROD TO GUIDE BLOCK | 1 |
| 39 | 67073A1 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 40 | 52100 | 连杆耐磨板 | WEAR PLATE LINK ROD | 1 |
| 41 | 38279 | 控制线缆闩锁紧固件 | LATCH CONTROL CABLE FASTENING | 1 |
| 41 | 8M0036768 | 闩锁 | LATCH | 1 |
| 42 | 35462 | 垫圈(.2656x.625x.0625)不锈钢锁扣 | WASHER (.2656 x .625 x .0625) Stainless Steel LATCH | 1 |
| 43 | 35045 | 螺母（0.250-28）连杆 | NUT (.250-28) LINK ROD | 1 |
| 43 | 826709109 | 不锈钢螺母(.250-28) | NUT (.250-28) Stainless Steel | 1 |
| 44 | 79932A11 | 换挡轴总成 | SHIFT SHAFT ASSEMBLY | 1 |
| 44 | 79932A16 | 换挡轴总成 | SHIFT SHAFT ASSEMBLY | 1 |
| 45 | 29720 | 连杆波形垫圈 | WAVE WASHER LINK ROD | 1 |
| 46 | 26600 | 尼龙衬套-连杆 | BUSHING NYLON - LINK ROD | 1 |
| 47 | 35462 | 垫圈(.2656 x .625 x .0625)不锈钢连杆 | WASHER (.2656 x .625 x .0625) Stainless Steel LINK ROD | 1 |
| 48 | 35045 | 螺母（0.250-28）连杆至换挡轴 | NUT (.250-28) LINK ROD TO SHIFT SHAFT | 1 |
| 48 | 826709109 | 不锈钢螺母(.250-28) | NUT (.250-28) Stainless Steel | 1 |
| 49 | 39519 | 杯形保持器-锚杆 | CUP BARRELL RETAINER - ANCHOR BAR | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8343A10 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 8343A11 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 8343T11 | ORD 1590-8343T10 | ORD 1590-8343T10 | 1 |
| 1 | 813563A1 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 813563T1 | 传动轴壳体-黑色-加长型 | HOUSING Driveshaft - Black - X-Long | 1 |
| 1 | 813563A2 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 1 | 813563T2 | ORD 3503-813563T1 | ORD 3503-813563T1 | 1 |
| 2 | 56295 | 双头螺柱(.437 x 2.69) | STUD (.437 x 2.69) | 2 |
| 3 | 63474 | 螺钉(.500-20 x 6.00) | SCREW (.500-20 x 6.00) | 2 |
| 3 | 898831 | 螺钉(.500-20 x 6.220) | SCREW (.500-20 x 6.220) | 2 |
| 4 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 1 |
| 5 | 77327 | 支架 | MOUNT | 2 |
| 6 | 49339 | 垫圈(.8125) | WASHER (.8125) | 2 |
| 7 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 1 |
| 8 | 28040 | 螺母(.500-20) | NUT (.500-20) | 2 |
| 8 | 898832 | 螺母(.500-20) | NUT (.500-20) | 2 |
| 9 | 41508 | 螺钉(0.250-20×0.500)不锈钢 | SCREW (.250-20 x .500) Stainless Steel | 1 |
| 10 | 45176 | 垫圈(.453 x .812 x .105)不锈钢 | WASHER (.453 x .812 x .105) Stainless Steel | 2 |
| 11 | 34933 | 螺母(.437-20)不锈钢 | NUT (.437-20) Stainless Steel | 2 |
| 11 | 8M0204653 | 螺母 | NUT | 2 |
| 12 | 67076 | 卡箍 | CLAMP | 2 |
| 12 | 8M0036782 | 卡箍 | CLAMP | 2 |
| 13 | 66727 | 螺钉(.312-18 x 1.250) | SCREW (.312-18 x 1.250) | 4 |
| 14 | 67077T | 黑色盖 | COVER Black | 2 |
| 14 | 8M4500752 | 盖板 | COVER | 2 |
| 14 | 67077F1 | 灰色盖板 | COVER Gray | 2 |
| 14 | 67077T | 黑色盖 | COVER Black | 2 |
| 15 | 88417 | 螺钉(#12-24×0.620) | SCREW (#12-24 x .620) | 4 |
| 16 | 35521 | 螺母 | NUT | 4 |
| 17 | 48926 | 垫圈 | WASHER | 1 |
| 18 | 34933 | 螺母(.437-20)不锈钢 | NUT (.437-20) Stainless Steel | 1 |
| 18 | 8M0204653 | 螺母 | NUT | 1 |
| 19 | 20553 | 垫圈(.406 x .734 x .063) | WASHER (.406 x .734 x .063) | 4 |
| 20 | 69254 | 螺母 | NUT | 4 |
| 21 | 828212 | 怠速排气套 | BOOT Idle Exhaust | 1 |
| 21 | 8M0039081 | 护套 | BOOT | 1 |
| 22 | 64649 | 堵头 | PLUG | 1 |
| 23 | 991732 | 衬垫 | GASKET | 1 |
| 23 | 991734 | 衬垫 | GASKET | 1 |
| 24 | 66350 | 下密封件 | SEAL (LOWER) | 1 |
| 24 | 66350001 | 密封件 | SEAL | 1 |
| 25 | 18276 | 排气管 | TUBE Exhaust | 1 |
| 25 | 18276T | 排气管 | EXHAUST TUBE | 1 |
| 26 | 177261 | 上密封件 | SEAL (UPPER) | 1 |
| 26 | 8M0039076 | 密封件 | SEAL | 1 |
| 27 | 812834 | 排气管延长段 | EXTENSION Exhaust | 1 |
| 27 | 812834A2 | 排气延长总成 | EXTENSION ASSEMBLY Exhaust | 1 |
| 27 | 41942F3 | 排气管延长段 | EXTENSION Exhaust | 1 |
| 27 | 879288T71 | 排气管延长段 | EXTENSION Exhaust | 1 |
| 28 | 67295 | 水管 | TUBE Water | 1 |
| 28 | 8M0042788 | 长型水管 | TUBE-WATER-LONG | 1 |
| 28 | 74729 | 管 | TUBE | 1 |
| 28 | 8M0042790 | 水管 | TUBE-WATER | 1 |
| 29 | 78246 | 衬垫 | GASKET | 1 |
| 29 | 782461 | 衬垫 | GASKET | 1 |
| 30 | 18233A3 | 隔板总成 | PLATE ASSEMBLY | 1 |
| 30 | 18233A20 | 传动轴壳体板总成 | PLATE ASSEMBLY Driveshaft Housing | 1 |
| 31 | 8147012 | 密封件 | SEAL | 1 |
| 31 | 8M0043165 | 密封件-27.00英寸 | SEAL-27.00 INCH | 1 |
| 32 | 68011 | 支架 | BRACKET | 1 |
| 33 | 812832 | 螺钉(#10-16 x 0.500) | SCREW (#10-16 x .500) | 12 |
| 33 | 878608 | 螺钉(#10-16 x 0.500) | SCREW (#10-16 x .500) | 12 |
| 34 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 35 | 38970 | 密封件 | SEAL | 1 |
| 36 | 90192 | 螺钉(.250-20 x .750)不锈钢 | SCREW (.250-20 x .750) Stainless Steel | 6 |
| 37 | 183071 | 衬垫 | GASKET | 1 |
| 37 | 183076 | 衬垫 | GASKET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 818186A3 | 动力配平总成 | POWER TRIM ASSEMBLY COMPLETE | 1 |
| 1 | 811604T | 歧管总成 | MANIFOLD ASSEMBLY | 1 |
| 1 | 811604F | 歧管总成 | MANIFOLD ASSEMBLY | 1 |
| 2 | 99616 | 管塞 | PIPE PLUG | 9 |
| 2 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 9 |
| 3 | 811605T | 倾斜油缸总成 | TILT CYLINDER ASSEMBLY | 1 |
| 3 | 880952A03 | ORD 8M0078330 | ORD 8M0078330 | 1 |
| 4 | 811608 | 连杆套件-升降倾斜活塞(螺栓型) | ROD KIT Trim And Tilt Piston (BOLT TYPE) | 1 |
| 5 | 811609 | 连杆-倾斜活塞(螺母型) | ROD Trim Piston (NUT TYPE) | 1 |
| 5 | 823553T | 升降活塞杆 | ROD Trim Piston | 1 |
| 6 | 811606 | 导向套件 | GUIDE KIT | 1 |
| 6 | 878239A02 | 倾斜缸端盖套件 | END CAP KIT Tilt Cylinder | 1 |
| 7 | 811607A1 | 维修套件 | REPAIR KIT | 1 |
| 8 | 811610A1 | 止回阀套件 | CHECK VALVE KIT | 1 |
| 8 | 823553T | 升降活塞杆 | ROD Trim Piston | 1 |
| 9 | 99638A1 | 导向器总成 | GUIDE ASSEMBLY | 2 |
| 9 | 8M0021648 | 端盖总成 | END CAP ASSEMBLY | 2 |
| 10 | 43397A6 | 动力升降活塞/杆总成 (左舷) | PISTON/ROD ASSEMBLY Power Trim (PORT) | 1 |
| 10 | 878413A1 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 10 | 43398A3 | 动力升降活塞/杆总成 (右舷) | PISTON/ROD ASSEMBLY Power Trim (STARBOARD) | 1 |
| 10 | 878414T01 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 11 | 12184A1 | 升降过滤器总成 | TRIM FILTER ASSEMBLY | 1 |
| 12 | 19603 | 槽销 | PIN Groove | 1 |
| 12 | 821539 | 三叶销 | PIN Trilobe | 1 |
| 13 | 811618 | 阀总成 | VALVE ASSEMBY | 1 |
| 13 | 893929A01 | 安全阀套件 | VALVE KIT Relief | 1 |
| 14 | 812844 | E型卡环 | E RING | 1 |
| 14 | 815949001 | E形环 | E-RING | 1 |
| 15 | 4000327 | 螺钉 (M6 x 14) | SCREW (M6 x 14) | 4 |
| 16 | 43450 | 垫圈 | WASHER | 4 |
| 16 | 4002315 | 垫圈(6.60x12.5x1.5mm-不锈钢) | WASHER (6.60 X 12.5 X 1.5 mm -SS) | 4 |
| 17 | 811611 | 盖板 | COVER | 1 |
| 18 | 811612A1 | O型圈套件 | O-RING KIT | 1 |
| 18 | 811612A3 | O型圈套件 | O-RING KIT | 1 |
| 19 | 811613 | 塞子总成 | PLUG ASSEMBLY | 1 |
| 20 | 811614 | 轴总成 | SHAFT ASSEMBLY | 1 |
| 20 | 8M0142997 | 倾斜轴套件 | TILT SHAFT KIT | 1 |
| 21 | 99616 | 管塞 | PIPE PLUG | 2 |
| 21 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 2 |
| 22 | 811628 | 配平电机 | TRIM MOTOR | 1 |
| 22 | 878265A6 | 改装套件-配平 | RETROFIT KIT-TRIM | 1 |
| 23 | 811615 | 螺钉 (长) | SCREW (LONG) | 2 |
| 23 | 811616 | 螺钉 (短) | SCREW (SHORT) | 2 |
| 24 | 811617T | 泵 | PUMP | 1 |
| 24 | 811617T1 | 泵 | PUMP | 1 |
| 25 | 811619 | 驱动轴 | DRIVESHAFT | 1 |
| 26 | 99625 | 轴 | SHAFT | 1 |
| 26 | 99625002 | 轴 | SHAFT | 1 |
| 27 | 43396A2 | 阳极总成 | ANODE ASSEMBLY | 1 |
| 27 | 818298Q1 | 阳极套件 | ANODE KIT | 1 |
| 28 | 4000330 | 螺钉(M6x25) | SCREW (M6 x 25) | 2 |
| 28 | 8M0204707 | 不锈钢六角大帽螺钉(M6x25) | SCREW M6 x 25 HX HD CAP SS | 2 |
| 29 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 29 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 30 | 996301 | 冲击板 | STRIKER PLATE | 2 |
| 30 | 8M0045383 | 冲击板 | STRIKER PLATE | 2 |
| 31 | 58643 | 锁紧垫圈 (.375) | LOCKWASHER (.375) | 2 |
| 32 | 46335 | 螺母 (.375-24) | NUT (.375-24) | 2 |
| 33 | 44431 | 槽销 | PIN Groove | 1 |
| 33 | 878267 | 销 | PIN | 1 |
| 34 | 814609A1 | 线束总成-动力升降控制 | HARNESS ASSEMBLY Control POWER TRIM | 1 |
| 35 | 88808A22 | 电缆总成(6-3/8"-红色) | CABLE ASSEMBLY (6-3/8" - RED) | 1 |
| 35 | 88808A23 | 电缆总成(24"-红色) | CABLE ASSEMBLY (24" - RED) | 1 |
| 35 | 87379A14 | 电线总成 (2.750英寸) | WIRE ASSEMBLY (2.750 Inches) | 1 |
| 36 | 22875 | CLIP PUMP WIRE | 2 | |
| 37 | 69205 | C形垫圈线夹螺钉 | C WASHER CLIP SCREW | 2 |
| 37 | 8M0084613 | C形垫圈 | C-WASHER | 2 |
| 38 | 69079 | 螺钉(#10-16x0.440)-夹子到艉板支架 | SCREW (#10-16 x .440) CLIP TO TRANSOM BRACKET | 2 |
| 39 | 4000377 | SCREW (M10 x 30) MANIFOLD | 6 | |
| 40 | 400258 | 锁紧垫圈(M10)-不锈钢歧管螺钉 | LOCKWASHER (M10) Stainless Steel MANIFOLD SCREW | 6 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8712A41 | 气缸体 | CYLINDER BLOCK | 1 |
| 2 | 76175 | 动力头螺柱 | STUD POWERHEAD | 6 |
| 3 | 67065 | 动力头螺柱 | STUD POWERHEAD | 2 |
| 3 | 670654 | 螺柱(.375-16/.375-24 x 5.620) | STUD (.375-16/.375-24 x 5.620) | 2 |
| 3 | 78438 | 动力头螺柱 | STUD POWERHEAD | 2 |
| 3 | 8M0034454 | 螺柱(.375-16/.375-24 x 6.87) | STUD (.375-16/.375-24 x 6.87) | 2 |
| 4 | 20033 | 定位销 | PIN Dowel LOCATING | 2 |
| 4 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 5 | 67296 | 气缸体销(轴承座圈) | PIN CYLINDER BLOCK (BEARING RACE) | 2 |
| 5 | 8M0036405 | 销 | PIN | 2 |
| 6 | 11338 | 密封垫片 | GASKET SEALING | 2 |
| 7 | 42249 | 启动马达上盖 | COVER STARTER MOTOR (UPPER) | 1 |
| 7 | 8M0088723 | 启动器支架 | BRACKET-STARTER | 1 |
| 8 | 73657 | 盖至曲轴箱螺钉(.312-18 x 1.50) | SCREW (.312-18 x 1.50) COVER TO CRANKCASE | 2 |
| 9 | 26993 | 启动马达盖螺钉锁紧垫圈(0.312) | LOCKWASHER (.312) STARTER MOTOR COVER SCREW | 4 |
| 9 | 8M0204647 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 4 |
| 10 | 76867 | 启动电机盖(下部) | COVER STARTER MOTOR (LOWER) | 1 |
| 11 | 77065 | 盖至曲轴箱螺钉(.312-18 x 2) | SCREW (.312-18 x 2) COVER TO CRANKCASE | 2 |
| 11 | 815549 | 螺钉(.312-18 x 2.00) | SCREW (.312-18 x 2.00) | 2 |
| 12 | 88801 | 杯形塞 | PLUG CUPPED | 2 |
| 12 | 99448 | 衬套 | BUSHING | 1 |
| 13 | 88807A20 | 线束总成盖 | CABLE ASSEMBLY COVER | 1 |
| 14 | 66717 | 螺钉 (.375-16 x 3.250) 曲轴箱气缸体 | SCREW (.375-16 x 3.250) CRANKCASE CYLINDER BLOCK | 8 |
| 14 | 74824 | 曲轴箱至气缸体螺丝(.312-18 x 1.250) | SCREW (.312-18 x 1.250) CRANKCASE TO CYLINDER BLOCK | 6 |
| 15 | 9608A1 | 上端盖总成 | END CAP ASSEMBLY (UPPER) | 1 |
| 15 | 9608T1 | 上盖总成 | CAP-ASSY-UPPER | 1 |
| 16 | 54029 | 端盖O型圈(2.800 x .103) | O-RING (2.800 x .103) END CAP | 1 |
| 17 | 93496 | 端盖滚柱轴承 | BEARING Roller END CAP | 1 |
| 17 | 93496T | 轴承 | BEARING | 1 |
| 18 | 41953 | 端盖密封件 | SEAL END CAP | 1 |
| 19 | 69034 | 螺钉与锁紧垫圈 (.312-18 x 1.00) 上端盖至气缸体 (1") | SCREW AND LOCKWASHER (.312-18 x 1.00) UPPER END CAP TO CYLINDER BLOCK (1") | 4 |
| 19 | 30225 | 螺钉带锁紧垫圈(.312-18 x 1.00) | SCREW WITH LOCKWASHER (.312-18 x 1.00) | 4 |
| 20 | 24220 | 螺钉 (.190-24 x .190) 定位 - 气缸体 (旧设计) | SCREW (.190-24 x .190) SET - CYLINDER BLOCK (OLD DESIGN) | 2 |
| 21 | 38407 | 堵头(.500-14) | PLUG (.500-14) | 1 |
| 22 | 15094 | 飞轮盖至气缸体双头螺柱(.190-32 x 1.870) | STUD (.190-32 x 1.870) FLYWHEEL COVER TO CYLINDER BLOCK | 1 |
| 23 | 15093 | 飞轮盖至支架双头螺柱(#10-32 x 1.00) | STUD (#10-32 x 1.00) FLYWHEEL COVER TO BRACKET | 2 |
| 23 | 8M0034435 | 螺柱 | STUD | 2 |
| 24 | 67269 | 飞轮盖螺柱隔套 | SPACER FLYWHEEL COVER STUD | 1 |
| 25 | 492211 | 飞轮盖螺柱垫圈 | WASHER FLYWHEEL COVER STUD | 6 |
| 25 | 8M0204663 | 垫片@5 | WASHER @5 | 6 |
| 26 | 72761 | 垫圈 (.203 x .562 x .060) 不锈钢 飞轮盖螺柱 | WASHER (.203 x .562 x .060) Stainless Steel FLYHWEEL COVER STUD | 3 |
| 27 | 73651 | 飞轮盖螺柱螺母 | NUT FLYWHEEL COVER STUD | 3 |
| 27 | 816874 | 蝶形螺母 (#10-32) | WING NUT (#10-32) | 3 |
| 28 | 42248 | 飞轮罩支架 | BRACKET FLYWHEEL COVER | 1 |
| 28 | 422482 | 支架 | BRACKET | 1 |
| 29 | 49668 | 支架至曲轴箱螺钉(.250-20 x .750) | SCREW (.250-20 x .750) BRACKET TO CRANKCASE | 2 |
| 30 | 7809A1 | 下端盖总成 | END CAP ASSEMBLY (LOWER) | 1 |
| 30 | 7809T1 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 31 | 62700 | O型圈 (3.237 x .103) 端盖 (3 3/4" 内径) | O-RING (3.237 x .103) END CAP (3 3/4" I.D.) | 1 |
| 32 | 41953 | 端盖密封件 | SEAL END CAP | 2 |
| 33 | 28636 | 螺钉（0.250-20 x 0.750）下端盖至气缸体 | SCREW (.250-20 x .750) LOWER END CAP TO CYLINDER BLOCK | 4 |
| 34 | 26992 | 下端盖螺钉不锈钢锁紧垫圈(.250) | LOCKWASHER (.250) Stainless Steel LOWER END CAP SCREW | 4 |
| 35 | 64022 | 调节螺钉(.250-20 x 2.125)-气缸体 | SCREW (.250-20 x 2.125) ADJUSTING - CYLINDER BLOCK | 1 |
| 36 | 64015 | 锁紧螺母(.250-20)-调节螺钉 | NUT (.250-20) JAM - ADJUSTING SCREW | 1 |
| 37 | 26852 | 调节螺钉尼龙帽 | CAP Nylon NYLON - ADJUSTING SCREW | 1 |
| 38 | 16793 | 卡箍 | CLAMP | 1 |
| 39 | 73286 | 螺钉(0.250-20×0.500)不锈钢 | SCREW (.250-20 x .500) Stainless Steel | 1 |
| 40 | 87076A6 | 怠速控制总成 | IDLE SPEED CONTROL ASSEMBLY | 1 |
| 40 | 87076A10 | 怠速控制器 | IDLE SPEED CONTROL | 1 |
| 41 | 69020 | 螺丝(#10-32 x .875)怠速控制 | SCREW (#10-32 x .875) IDLE SPEED CONTROL | 3 |
| 41 | 690201 | 螺钉(#10-32 x .875) | SCREW (#10-32 x .875) | 3 |
| 42 | 38833 | 垫圈 怠速控制螺钉 | WASHER IDLE SPEED SONTROL SCREW | 3 |
| 43 | 194372 | 端子排 | TERMINAL BLOCK | 1 |
| 44 | 48409 | 螺钉 (#10-16 x .625) 不锈钢 | SCREW (#10-16 x .625) Stainless Steel | 2 |
| 45 | 89302 | 垫圈(0.203×0.406×0.040) | WASHER (.203 x .406 x .040) | 2 |
| 46 | 45076 | 黄铜螺母(#10-32) | NUT (#10-32) Brass | 2 |
| 47 | 813938 | 盖形螺母(#10-32) | CAP NUT (#10-32) | 2 |
| 48 | 63153 | J型卡扣 | J CLIP | 1 |
| - | 812827A89 | 动力总成完整组件 | POWERHEAD ASSEMBLY COMPLETE | 1 |
| - | 812827T89 | 船用动力头 | POWERHEAD MARINE | 1 |
| - | 14697A87 | 衬垫套件 | GASKET SET |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9536A4 | 曲轴总成 | CRANKSHAFT ASSEMBLY | 1 |
| 2 | 67923 | 球轴承(下部) | BEARING Ball (LOWER) | 1 |
| 2 | 67923T | 滚珠轴承 | BEARING Ball | 1 |
| 3 | 67446 | 环 | RING | 1 |
| 4 | 14513A2 | 驱动齿轮段套件 | GEAR SEGMENT KIT Drive | 2 |
| 4 | 14513A09 | 驱动齿轮段套件 | GEAR SEGMENT KIT Drive | 2 |
| 5 | 813073 | 螺钉(#6-32 x .620)内六角头 | SCREW (#6-32 x .620) Socket Head | 2 |
| 6 | 813134 | 螺母(#6-32)专用 | NUT (#6-32) Special | 2 |
| 7 | 54196A6 | 托架总成 | CARRIER ASSEMBLY | 1 |
| 8 | 65800 | 填料 | PACKING | 1 |
| 9 | 67377 | 密封环-曲轴 | RING Sealing SEALING - CRANKSHAFT | 8 |
| 9 | 67377T | 密封环 | RING Sealing | 8 |
| 10 | 16756A1 | 滚子轴承总成-曲轴 | BEARING ASSEMBLY Roller CRANKSHAFT | 2 |
| 10 | 16756A6 | 轴承套件 | BEARING KIT | 2 |
| 11 | 7441A32 | 活塞(右舷-标准) | PISTON (STARBOARD-STANDARD) | 3 |
| 11 | 7441T32 | 活塞 | PISTON | 3 |
| 11 | 7443A11 | 活塞(右舷-0.015加大) | PISTON (STARBOARD-.015 O.S.) | AR |
| 11 | 7445A11 | 活塞(右舷-0.030加大) | PISTON (STARBOARD-.030 OS.) | AR |
| 11 | 7445T11 | 活塞 | PISTON | AR |
| 11 | 7442A32 | 活塞(左舷-标准) | PISTON (PORT-STANDARD) | 3 |
| 11 | 7442T32 | 活塞 | PISTON | 3 |
| 11 | 7444A11 | 活塞(左舷-0.015加大) | PISTON (PORT-.015 O.S.) | AR |
| 11 | 7446A11 | 活塞(左舷-0.030加大) | PISTON (PORT-.030 O.S.) | AR |
| 11 | 9738A7 | 活塞总成(右舷-标准) | PISTON ASSEMBLY (STARBOARD-STANDARD) | 3 |
| 11 | 9738T9 | 活塞总成标准型 | PISTON ASSEMBLY Standard | 3 |
| 11 | 9738A8 | 活塞总成(右舷-0.015加大) | PISTON ASSEMBLY (STARBOARD-.015 O.S.) | AR |
| 11 | 9738T10 | 活塞总成0.015加大 | PISTON ASSEMBLY .015 Oversize | AR |
| 11 | 9737A7 | 活塞总成(左舷-标准) | PISTON ASSEMBLY (PORT-STANDARD) | 3 |
| 11 | 9737T9 | 活塞总成标准型 | PISTON ASSEMBLY Standard | 3 |
| 11 | 9737A8 | 活塞总成(左舷-0.015加大) | PISTON ASSEMBLY (PORT-.015 O.S.) | AR |
| 11 | 9737A10 | 活塞总成0.015加大 | PISTON ASSEMBLY .015 Oversize | AR |
| 12 | 93481A12 | 活塞环组-标准(标准) | RING SET Piston - Standard (STANDARD) | 1 |
| 12 | 78918A4 | 活塞环组-0.015加大(0.015加大) | RING SET Piston - .015 Oversize (.015 O.S.) | AR |
| 12 | 85636A4 | 活塞环组-0.030加大(0.030加大) | RING SET Piston - .030 Oversize (.030 O.S.) | AR |
| 12 | 815515A12 | 活塞环组(标准) | RING SET Piston (STANDARD) | 1 |
| 12 | 815268A4 | 活塞环组(.015加大) | RING SET Piston (.015 O.S.) | AR |
| 13 | 52035 | 锁环 | RING Lock | 12 |
| 13 | 857196 | 锁紧环 | LOCK RING | 12 |
| 14 | 818141A2 | 连杆套件 | CONNECTING ROD KIT | 6 |
| 14 | 818141A13 | 连杆总成 | CONNECTING ROD ASSEMBLY | 6 |
| 15 | 763491 | 螺钉(0.312-24×0.875)连杆 | SCREW (.312-24 x .875) CONNECTING ROD | 12 |
| 16 | 812876 | 定位针垫圈 | WASHER NEEDLE LOCATING | 12 |
| 16 | 8M0012298 | 止推垫片 | THRUST WASHER | 12 |
| 17 | 17514A1 | 轴承套件 | BEARING KIT | 6 |
| 17 | 8M0234886 | 轴承保持架 | CAGE BEARING | 6 |
| 18 | 674831 | 活塞端滚针轴承 | BEARING Needle PISTON END | 174 |
| 18 | 8M0204691 | 滚针轴承@200 | BRG-NEEDLE @200 | 174 |
| - | 815791A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815809A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815810A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8710A20 | 旋转支架总成（黑色） | SWIVEL BRACKET ASSEMBLY (BLACK) | 1 |
| 1 | 8710A21 | 旋转支架总成（灰色） | SWIVEL BRACKET ASSEMBLY (GRAY) | 1 |
| 1 | 8710T21 | 灰色旋转支架总成 | SWIVEL BRACKET ASSEMBLY Gray | 1 |
| 2 | 87735 | SEAL Oil SWIVEL BRACKET (LOWER) | 1 | |
| 3 | 67669 | 旋转支架衬套-上下部 | BUSHING SWIVEL BRACKET-LOWER AND UPPER | 2 |
| 3 | 818764 | 衬套 | BUSHING | 2 |
| 4 | 816039 | 隔套 | SPACER | 1 |
| 5 | 33504 | O型圈 | O-RING | 1 |
| 5 | 8M0214926 | O型圈 @10 | O RING @10 | 1 |
| 6 | 74036 | 润滑脂接头 | FITTING Grease | 2 |
| 6 | 8M0169589 | 润滑脂接头 | FITTING Grease | 2 |
| 7 | 99608 | 转轴支架衬套 | BUSHING SWIVEL BRACKET | 2 |
| 7 | 821207 | 衬套 | BUSHING | 2 |
| 8 | 816432 | 止推垫片 | THRUST WASHER | 1 |
| 9 | 78689 | 螺钉(0.437-20×7.50)转向臂至上支架 | SCREW (.437-20 x 7.50) STEERING ARM TO UPPER MOUNT | 2 |
| 9 | 8M0176309 | 螺钉 | SCREW | 2 |
| 10 | 78687 | 橡胶支架-上部(长型) | MOUNT RUBBER-UPPER (LONG) | 2 |
| 10 | 78687T | 支架 | MOUNT | 2 |
| 10 | 77326 | 支架(加长型)(用于XR4/MAGNUM II) | MOUNT (X-LONG) (USE ON XR4/MAGNUM II) | 2 |
| 11 | 66921 | 上支座螺栓垫圈 | WASHER UPPER MOUNT BOLT | 2 |
| 12 | 814432 | 上支座螺栓垫圈 | WASHER UPPER MOUNT BOLT | 2 |
| 12 | 78688 | 垫圈 | WASHER | 2 |
| 13 | 34933 | 螺母（0.437-20）不锈钢上部安装螺栓 | NUT (.437-20) Stainless Steel UPPER MOUNT BOLT | 2 |
| 13 | 8M0204653 | 螺母 | NUT | 2 |
| 14 | 92876A1 | 转向连杆总成 | LINK ASSEMBLY Steering | 1 |
| 14 | 92876A12 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 15 | 14000 | SCREW (.375-24 x 1.25) STEERING LINK TO STEERING ARM | 1 | |
| 15 | 849838 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 1 |
| 16 | 34863 | NUT (.375-24) STEERING LINK SCREW | 2 | |
| 16 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 2 |
| 17 | 34931 | WASHER (.406 x .734 x .063) Stainless Steel STEERING LINK TO STEERING ARM | 2 | |
| 18 | 67706A35 | 旋转销总成(黑色) | SWIVEL PIN ASSEMBLY (BLACK) | 1 |
| 18 | 67706A55 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 18 | 67706A36 | 旋转销总成(灰色) | SWIVEL PIN ASSEMBLY (GRAY) | 1 |
| 18 | 67706A55 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 19 | 86580A1 | 底部轭架总成（黑色） | YOKE ASSEMBLY Bottom (BLACK) | 1 |
| 19 | 878182T | 轭架底部-不锈钢 | YOKE Bottom - Stainless Steel | 1 |
| 19 | 86580A2 | 底部轭架总成（灰色） | YOKE ASSEMBLY Bottom (GRAY) | 1 |
| 19 | 86580A1 | 底部轭架总成 | YOKE ASSEMBLY Bottom | 1 |
| 20 | 67684 | 卡环-底部轭架 | RING Retaining BOTTOM YOKE | 1 |
| 21 | 88882 | 缓冲垫-顶部轭架 | BUMPER Top Yoke TOP YOKE | 1 |
| 22 | 64014 | SCREW (.250-28 x .500) SWIVEL BRACKET | 2 | |
| 23 | 54457 | J型卡扣 | J CLIP | |
| 24 | 95164A9 | 调整传感器总成 | SENDER ASSEMBLY Trim | 1 |
| 24 | 8M0074846 | ORDER 8M0098273 | ORDER 8M0098273 | 1 |
| 25 | 56682 | 螺钉（#10-24 X 0.750） | SCREW (#10-24 x .750) | 2 |
| 25 | 852368 | 螺钉（#10-24 X 0.750） | SCREW (#10-24 x .750) | 2 |
| 26 | 26996 | 锁紧垫圈(#10)(不锈钢) | LOCKWASHER (#10) Stainless Steel | 2 |
| 27 | 89302 | 垫圈(0.203×0.406×0.040) | WASHER (.203 x .406 x .040) | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 828334F1 | 艉板支架 | BRACKET Transom | 1 |
| 2 | 828333A3 | 艉板支架总成 | BRACKET ASSEMBLY Transom | 1 |
| 2 | 828333T07 | 艉板支架总成-左舷 | BRACKET ASSEMBLY Transom - Port | 1 |
| 3 | 98727 | 润滑脂接头 | FITTING Grease | 1 |
| 3 | 8M0169588 | 润滑脂接头 | FITTING Grease | 1 |
| 4 | 99170A2 | 倾斜管套件 | TUBE KIT Tilt | 1 |
| 4 | 826125A1 | 倾斜管 | TILT TUBE | 1 |
| 4 | 826125A1 | 倾斜管 | TILT TUBE | 1 |
| 5 | 859133 | 螺母(1.00-14) | NUT (1.00-14) | 1 |
| 5 | 82671327 | 螺母(1.0-14) | NUT (1.0-14) | 1 |
| 5 | 826135 | 尼龙锁紧螺母(1.00-14) | NUT Lock (1.00-14) Nylon Insert | 1 |
| 6 | 45711 | O型圈 (.612 x .103) | O-RING (.612 x .103) | 1 |
| 7 | 88750 | 波浪垫圈 (1.62 x 1.05) | WASHER Wave (1.62 x 1.05) | 2 |
| 8 | 858869 | 螺母 (.875-14) | NUT (.875-14) | 1 |
| 8 | 826164 | 螺母 (.875-14) | NUT (.875-14) | 1 |
| 8 | 8M0231351 | 锁紧螺母 | NUT Lock | 1 |
| 9 | 677551 | 螺钉(.500-20×4.500) | SCREW (.500-20 x 4.500) | 4 |
| 9 | 8M0149747 | 螺钉 | SCREW | 4 |
| 10 | 54012 | 垫圈(0.530×0.870×0.105不锈钢) | WASHER (.530 x .870 x .105) Stainless Steel | 4 |
| 10 | 8M0204665 | 垫圈(0.530×0.880×0.104 630不锈钢) | WASHER (.530 x .880 x .104) 630 Stainless Steel | 4 |
| 11 | 28421 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 11 | 8M0204648 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 12 | 82671117 | 螺母(.500-20) | NUT (.500-20) | 4 |
| 13 | 830899 | 张力弹簧 | SPRING Tension | 1 |
| 14 | 821176T1 | 倾斜锁定杆总成 | LEVER ASSEMBLY Tilt Lock | 1 |
| 14 | 8M0109798 | 倾斜锁定杆总成 | LEVER ASSEMBLY Tilt Lock | 1 |
| 15 | 65830 | 尼龙衬套 | NYLINER | 2 |
| 16 | 830900 | 压缩弹簧 | SPRING Compression | 1 |
| 17 | 99633 | 旋钮 | KNOB | 1 |
| 18 | 99615 | 槽销 | PIN Groove | 1 |
| 19 | 99617 | 销 | PIN | 1 |
| 19 | 893709 | 销 | PIN | 1 |
| 20 | 818771T1 | 锚支架 | BRACKET Anchor | 1 |
| 20 | 8M0086406 | 锚支架 | BRACKET Anchor | 1 |
| 21 | 858771 | 螺钉 (M10 x 30) | SCREW (M10 x 30) | 6 |
| 22 | 4002319 | 垫圈 | WASHER | 6 |
| 23 | 40114 | 螺母(M10 x 1.5) | NUT (M10 x 1.5) | 1 |
| 24 | 818298Q1 | 阳极套件 | ANODE KIT | 1 |
| 25 | 4000330 | 螺钉(M6x25) | SCREW (M6 x 25) | 2 |
| 25 | 8M0204707 | 不锈钢六角大帽螺钉(M6x25) | SCREW M6 x 25 HX HD CAP SS | 2 |
| 26 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 26 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 9572A3 | 齿轮箱总成(长型)(黑色) | GEAR HOUSING ASSEMBLY (LONG) (BLACK) | 1 |
| - | 9572A4 | 齿轮箱总成(长型)(灰色) | GEAR HOUSING ASSEMBLY (LONG) (GRAY) | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 9572A1 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| 1 | 814247T8 | 齿轮箱 | GEAR HSG | 1 |
| 1 | 9572A2 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| 1 | 814247T9 | 齿轮箱 | GEAR HSG | 1 |
| 44 | 76039 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 44 | 760394 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 45 | 12239A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 45 | 850315A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 46 | 30622 | 凸轮从动件压缩弹簧 | SPRING COMPRESSION - CAM FOLLOWER | 1 |
| 47 | 44491A1 | 垫片组 | SHIM SET | AR |
| 47 | 8M0063266 | 垫片组 | SHIM SET | AR |
| 48 | 30894A1 | 圆锥轴承组 | BEARING SET Cup And Cone | 1 |
| 49 | 16279A2 | 前进齿轮总成 | GEAR ASSEMBLY Forward | 1 |
| 50 | 30895 | 滚针轴承（前进齿轮） | BEARING Needle FORWARD GEAR | 1 |
| 50 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 51 | 12777 | 棘轮 | RATCHET | 1 |
| 51 | 822539T | 离合器 | CLUTCH | 1 |
| 52 | 30632 | 十字离合器销 | PIN Cross CLUTCH | 1 |
| 52 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 53 | 30893 | 十字销固定弹簧 | SPRING RETAINING - CROSS PIN | 1 |
| 54 | 12238T | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 55 | N.S.S. | 倒车齿轮(不单独销售)(属于43-16279A2部件) | Not Sold Separate Reverse Gear (PART OF 43-16279A2) | 1 |
| 56 | 76358 | 止推垫片轴承座 | THRUST WASHER BEARING CARRIER | 1 |
| 57 | 29976 | 轴承座O型圈 | O-RING BEARING CARRIER | 1 |
| 58 | 41529A2 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 58 | 41529T2 | 托架总成 | CARRIER ASSY | 1 |
| 59 | 98727 | 润滑脂接头 | FITTING Grease | 2 |
| 59 | 8M0169588 | 润滑脂接头 | FITTING Grease | 2 |
| 60 | 30956 | 滚针轴承-轴承座 | BEARING Needle BEARING CARRIER | 1 |
| 60 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 61 | 76868 | 密封件 | SEAL | 2 |
| 61 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 2 |
| 62 | 30281 | KEY LOCATING - BEARING CARRIER | 1 | |
| 63 | 52700 | 齿轮箱盖锁紧垫圈 | TAB WASHER GEAR HOUSING COVER | 1 |
| 64 | 52699 | 齿轮箱盖 | COVER GEAR HOUSING | 1 |
| 65 | 67891 | 填充块 | FILLER BLOCK | 1 |
| 65 | 8M0039169 | 填充块 | FILLER BLOCK | 1 |
| 66 | 30206 | 螺钉(.375-16 x 1.00)不锈钢 | SCREW (.375-16 x 1.00) Stainless Steel | 1 |
| 67 | 31211A2 | 花键垫圈 | WASHER Splined | 1 |
| 67 | 31211Q03 | 垫圈总成 | WASHER ASSEMBLY | 1 |
| 68 | 31210 | 锁紧垫圈 | TAB WASHER | 1 |
| 68 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 69 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 69 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 70 | 316404 | 平衡鳍板 | TRIM TAB | 1 |
| 70 | 31640Q4 | 平衡鳍板 | TRIM TAB | 1 |
| 71 | 15797 | 阳极板螺钉 | SCREW ANODIC PLATE | 1 |
| 72 | 45176 | 不锈钢垫圈(.453 x .812 x .105) 驱动轴壳体螺柱用 | WASHER (.453 x .812 x .105) Stainless Steel DRIVESHAFT HOUSING STUDS | 2 |
| 73 | 34933 | 不锈钢螺母(.437-20) 驱动轴壳体螺柱用 | NUT (.437-20) Stainless Steel DRIVESHAFT HOUSING STUDS | 2 |
| 73 | 8M0204653 | 螺母 | NUT | 2 |
| 74 | 13191A1 | 止推垫片 | THRUST WASHER | 1 |
| 74 | 13191Q01 | 止推垫片 | THRUST WASHER | 1 |
| 75 | 423511 | 齿形锁紧垫圈 | LOCKWASHER Toothed | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 18896A1 | 飞轮盖套件 | COVER KIT FLYWHEEL | 1 |
| 2 | 79022 | 正时标记 | MARKER TIMING | 1 |
| 3 | 37572 | 螺钉(0.190-32x0.380)正时标记 | SCREW (.190-32 x .380) TIMING MARKER | 2 |
| 4 | 72761 | 垫圈(0.203x0.562x0.060)不锈钢正时标记螺钉 | WASHER (.203 x .562 x .060) Stainless Steel TIMING MARKER SCREW | 2 |
| 5 | 89219 | 飞轮盖塞 | PLUG FLYWHEEL COVER | 1 |
| 5 | 89219001 | 堵头 | PLUG | 1 |
| 6 | 45907 | 飞轮黄色塞 | PLUG Yellow FLYWHEEL | 1 |
| 7 | 52901 | 螺母(.625-18)飞轮 | NUT (.625-18) FLYWHEEL | 1 |
| 8 | 68229 | 垫圈(0.641x1.250x0.190)飞轮 | WASHER (.641 x 1.250 x .190) FLYWHEEL | 1 |
| 8 | 33001 | 垫圈 | WASHER | 1 |
| 9 | 9841A7 | 飞轮 | FLYWHEEL | 1 |
| 9 | 859238T16 | 飞轮总成 | FLYWHEEL ASY | 1 |
| 10 | 32417 | 螺钉(.250-28 x .625)飞轮板 | SCREW (.250-28 x .625) FLYWHEEL PLATE | 8 |
| 11 | 68997 | 螺钉(.312-24 x .750)飞轮毂 | SCREW (.312-24 x .750) FLYWHEEL HUB | 8 |
| 12 | 9610A5 | 定子 | STATOR | 1 |
| 13 | 90045 | 螺钉(#10-32 x 1.375)定子 | SCREW (#10-32 x 1.375) STATOR | 4 |
| 14 | 26996 | 锁紧垫圈(#10)不锈钢定子螺钉 | LOCKWASHER (#10) Stainless Steel STATOR SCREW | 4 |
| 15 | 96455A9 | 触发板总成 | PLATE ASSEMBLY Trigger | 1 |
| 16 | 93388A1 | 电缆总成(6.00英寸)黑色板至启动马达 | CABLE ASSEMBLY (6.00 Inches) Black PLATE TO STARTER MOTOR | 1 |
| 17 | 79472 | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 17 | 893893 | 启动马达 | STARTER MOTOR | 1 |
| 18 | 56703 | 启动电机轴环 | COLLAR STARTER MOTOR | 2 |
| 18 | 8M0034918 | 轴环 | COLLAR | 2 |
| 19 | 68042 | 启动马达橡胶止动块 | STOP Rubber RUBBER-STARTER MOTOR | 2 |
| 19 | 8M0043376 | 停机开关 | STOP | 2 |
| 20 | 26992 | 锁紧垫圈(.250) 不锈钢 起动机接线端 | LOCKWASHER (.250) Stainless Steel STARTER MOTOR TERMINAL | 1 |
| 21 | 20890 | 螺母(.250-20) 起动机接线端 | NUT (.250-20) STARTER MOTOR TERMINAL | 1 |
| 22 | 93388A2 | 电磁阀至启动电机黑色电缆总成 | CABLE ASSEMBLY Black SOLENOID TO STARTER MOTOR | 1 |
| 22 | 93388A14 | 线缆总成(黄/黑) | CABLE ASSEMBLY Yellow/Black | 1 |
| 23 | 69035 | 螺钉和锁紧垫圈 (.250-20 x .625) 不锈钢 电缆至启动马达 | SCREW AND LOCKWASHER (.250-20 x .625) Stainless Steel CABLE TO STARTER MOTOR | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 15110A1 | 转速表 | TACHOMETER | 1 |
| 2 | 79101T | 安装支架 | BRACKET MOUNTING | 1 |
| 3 | 72729 | 楔形底座灯泡(14V - 1.9W) | LIGHT BULB Wedge Base (14V - 1.9W) | 1 |
| 4 | 79888 | 灯泡插座 | SOCKET Light Bulb | 1 |
| 5 | 26419 | 螺母（#8-32）黄铜（8-32） | NUT (#8-32) Brass (8-32) | 5 |
| 6 | 86322A7 | 线束总成 (1.50英尺) 黑色 配平表 (BLACK - 1-1/2") | CABLE ASSEMBLY (1.50 Feet) Black TRIM GAUGE (BLACK - 1-1/2") | 1 |
| 6 | 86323A5 | 线束总成 (1.50英尺) 紫色 配平表 (PURPLE - 1-1/2") | CABLE ASSEMBLY (1.50 Feet) Purple TRIM GAUGE (PURPLE - 1-1/2") | 1 |
| 7 | 15113A4 | 配平表 | TRIM GAUGE | 1 |
| 7 | 895292Q41 | 动力升降倾斜指示器 黑面橙白刻度黑边框 | GAUGE Power Trim Indicator, Black Face, Orange/White Graduations, Black Bezel | 1 |
| 8 | 79480 | 安装支架-微调表 | BRACKET MOUNTING - TRIM GAUGE | 1 |
| 9 | 72729 | 灯泡 楔形底座(14V-1.9W)微调表 | LIGHT BULB Wedge Base (14V - 1.9W) TRIM GAUGE | 1 |
| 10 | 79888 | 灯泡插座 微调表 | SOCKET Light Bulb TRIM GAUGE | 1 |
| 11 | 26419 | 螺母 (#8-32) 黄铜 配平表端子 (8-32) | NUT (#8-32) Brass TRIM GAUGE TERMINAL (8-32) | 5 |
| 12 | 26427 | 垫圈 配平表端子 (#8) | WASHER TRIM GAUGE TERMINAL (#8) | 2 |
| 13 | 86396A8 | 转速表线束总成(5.00英尺) | HARNESS ASSEMBLY Tachometer (5.00 Feet) | 1 |
| 14 | 15166A1 | 温度表 | TEMPERATURE GAUGE | 1 |
| 14 | 895287Q41 | 水温表套件(100-240℉)黑面橙白刻度黑框 | WATER TEMPERATURE GAUGE KIT (100-240 F) Black Face, Orange/White Graduations, Black Bezel | 1 |
| 15 | 72729 | 楔形底座灯泡(14V - 1.9W) | LIGHT BULB Wedge Base (14V - 1.9W) | 1 |
| 16 | 79888 | 灯泡插座 | SOCKET Light Bulb | 1 |
| 17 | 26427 | 垫圈 | WASHER | 2 |
| 18 | 79480 | 支架 | BRACKET | 1 |
| 19 | 26419 | 黄铜螺母 (#8-32) | NUT (#8-32) Brass | 5 |
| 20 | 86323A2 | 线束总成 (2.00英尺) 紫色 (PURPLE) | CABLE ASSEMBLY (2.00 Feet) Purple (PURPLE) | 1 |
| 20 | 61600A16 | 线束总成 (17.00英寸) 黑色 (BLACK) | CABLE ASSEMBLY (17.00 Inches) Black (BLACK) | 1 |
| 20 | 88824A4 | 线束总成 (45.00英寸) 米色 (TAN) | CABLE ASSEMBLY (45.00 Inches) Tan (TAN) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 99186T | 泵与电机总成 | PUMP AND MOTOR | 1 |
| 1 | 12659 | 机架与磁场套件 | FRAME AND FIELD KIT | 1 |
| 1 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 2 | 12665 | 电刷弹簧套件 | SPRING KIT Brush | 1 |
| 3 | 13506 | 电刷卡套件 | BRUSH CARD KIT | 1 |
| 3 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 4 | 12662 | 泵与端架套件 | PUMP AND END FRAME KIT | 1 |
| 4 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 5 | 12663 | 泵密封套件 | SEAL KIT Pump | 1 |
| 5 | 126631 | 泵密封套件 | SEAL KIT Pump | 1 |
| 6 | 12660 | 端架套件 | END FRAME KIT | 1 |
| 6 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 7 | 12661 | 电枢套件 | ARMATURE KIT | 1 |
| 7 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 8 | 12664 | 贯穿螺栓套件 | THRU BOLT KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 9572A3 | 齿轮箱总成（长型）（黑色） | GEAR HOUSING ASSEMBLY (LONG)(BLACK) | 1 |
| - | 9572A4 | 齿轮箱总成（长型）（灰色） | GEAR HOUSING ASSEMBLY (LONG)(GRAY) | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 9572A1 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| 1 | 814247T8 | 齿轮箱 | GEAR HSG | 1 |
| 1 | 9572A2 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| 1 | 814247T9 | 齿轮箱 | GEAR HSG | 1 |
| 2 | 85822A1 | CONNECTOR ASSEMBLY SPEEDOMETER | 1 | |
| 2 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 3 | 20033 | 定位销 齿轮箱定位 | PIN Dowel GEAR HOUSING LOCATING | 2 |
| 3 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 4 | 78638 | 齿轮箱螺柱(0.438×3.12) | STUD (.438 x 3.12) GEAR HOUSING | 1 |
| 4 | 786382 | 螺柱(.437-14/.437-20 x 3.120) | STUD (.437-14/.437-20 x 3.120) | 1 |
| 5 | 57920 | 双头螺栓(.44 x 2.06)齿轮箱 | STUD (.44 x 2.06) GEAR HOUSING | 2 |
| 5 | 8M0133358 | 双头螺栓(.437-14/.437-20×2.060) | STUD (.437-14/.437-20 x 2.060) | 2 |
| 6 | 56297 | 双头螺栓(.312 x 3.38)水泵 | STUD (.312 x 3.38) WATER PUMP | 1 |
| 6 | 8M0034463 | 螺柱(.312-24 x 3.38) | STUD (.312-24 x 3.38) | 1 |
| 7 | 30667 | 双头螺栓(.250-20/.250-28 x 3.125)水泵 | STUD (.250-20/.250-28 x 3.125) WATER PUMP | 2 |
| 7 | 306671 | 螺柱 | STUD | 2 |
| 8 | 32898 | 轴承 | BEARING | 1 |
| 8 | 32898T | 轴承 | BEARING | 1 |
| 9 | 79953 | SCREW (.375-16 x .250) GREASE FILLER | 1 | |
| 9 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 10 | 67892 | SCREW Magnetic DRAIN | 1 | |
| 10 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 11 | 15298 | 驱动轴注油嘴 | DRIVESHAFT GREASE FILLER | 1 |
| 12 | NSS | 不单独出售小齿轮（43-16279A2部件） | NOT SOLD SEPARATE PINION GEAR (PART OF 43-16279A2) | 1 |
| 13 | 20260 | 润滑脂加注与排放螺钉垫圈 | WASHER GREASE FILLER AND DRAIN SCREW | 2 |
| 13 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 2 |
| 14 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 15 | 42637A1 | 垫片组 | SHIM SET | AR |
| 15 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 16 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 16 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 17 | 42633 | 传动轴轴承螺母 | NUT DRIVESHAFT BEARING | 1 |
| 17 | 8245191 | 固定座 | RETAINER | 1 |
| 18 | 42579A3 | 水泵底座总成 | BASE ASSEMBLY Water Pump | 1 |
| 18 | 8M0077147 | 带水泵底座总成 | BASE ASSY-W/P | 1 |
| 19 | 42631 | 衬垫 | GASKET | 1 |
| 19 | 8M0204678 | 衬垫 | GASKET | 1 |
| 20 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 20 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 20 | 38099 | O型圈（内径2.109） | O-RING (2.109 I.D.) | 1 |
| 21 | 89238 | 油封 | SEAL Oil | 1 |
| 22 | 16977 | 油封 | SEAL Oil | 1 |
| 23 | 85608 | 下部衬垫 | GASKET LOWER | 1 |
| 23 | 8M0090319 | 衬垫@5 | GASKET @5 | 1 |
| 24 | 85609 | 上衬垫 | GASKET UPPER | 1 |
| 24 | 858524 | 衬垫 | GASKET | 1 |
| 25 | 32435 | 面板 | FACE PLATE | 1 |
| 25 | 8M0204677 | 面板 | PLATE-FACE | 1 |
| 26 | 96148A1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 26 | 96148T1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 27 | 48752 | 水泵体嵌件 | INSERT WATER PUMP BODY | 1 |
| 27 | 48752T | 嵌件 | INSERT | 1 |
| 28 | 38970 | 橡胶密封件 | SEAL RUBBER | 1 |
| 29 | 89984 | 水泵叶轮 | IMPELLER WATER PUMP | 1 |
| 29 | 89984T4 | 叶轮 | IMPELLER | 1 |
| 30 | 56654 | 叶轮驱动键 | KEY IMPELLER DRIVE | 1 |
| 30 | 8M0214992 | 键@5 | KEY @5 | 1 |
| 31 | 96411 | 螺钉(#14-8×2.25) | SCREW (#14-8 x 2.25) | 1 |
| 31 | 8M0215009 | 螺钉 | SCREW | 1 |
| 32 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 32 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 33 | 13438 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 33 | 8267119 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 34 | 36001 | 垫圈 | WASHER | 1 |
| 35 | 13436 | 螺母 | NUT | 1 |
| 36 | 30271 | 橡胶环 | RING Rubber RUBBER | 1 |
| 36 | 8M0214918 | 环@5 | RING @5 | 1 |
| 37 | 29804 | 导向套 | SLEEVE GUIDE | 1 |
| 37 | 29804T | 套筒 | SLEEVE | 1 |
| 38 | 15299 | 换挡轴（下部） | SHAFT SHIFT-LOWER | 1 |
| 39 | 29641 | E型卡环 | E RING | 1 |
| 40 | 25439 | O型圈(.862×0.103) | O-RING (.862 x .103) | 1 |
| 41 | 77631A2 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 42 | 76384 | 油封 | SEAL Oil | 1 |
| 42 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 43 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| - | 42579A4 | 水泵修理包 | REBUILD KIT Water Pump | 1 |
| - | 96148A8 | 水泵维修套件 | WATER PUMP REPAIR KIT | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 9572A3 | 齿轮箱总成（长型）（黑色） | GEAR HOUSING ASSEMBLY (LONG)(BLACK) | 1 |
| - | 9572A4 | 齿轮箱总成（长型）（灰色） | GEAR HOUSING ASSEMBLY (LONG)(GRAY) | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 9572A1 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| 1 | 814247T8 | 齿轮箱 | GEAR HSG | 1 |
| 1 | 9572A2 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| 1 | 814247T9 | 齿轮箱 | GEAR HSG | 1 |
| 44 | 76039 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 44 | 760394 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 45 | 12239A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 45 | 850315A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 46 | 30622 | 弹簧 | SPRING | 1 |
| 47 | 44491A1 | 垫片组 | SHIM SET | AR |
| 47 | 8M0063266 | 垫片组 | SHIM SET | AR |
| 48 | 30894A1 | 圆锥轴承组 | BEARING SET Cup And Cone | 1 |
| 49 | 16279A2 | 前进齿轮总成 | GEAR ASSEMBLY Forward | 1 |
| 50 | 30895 | 滚针轴承 | BEARING Needle | 1 |
| 50 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 51 | 12777 | 棘轮 | RATCHET | 1 |
| 51 | 822539T | 离合器 | CLUTCH | 1 |
| 52 | 30632 | 十字销 | PIN Cross | 1 |
| 52 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 53 | 30893 | 弹簧 | SPRING | 1 |
| 54 | 12238T | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 55 | NSS | NOT SOLD SEPARATE REVERSE GEAR (PART OF 43-16279A2) | 1 | |
| 56 | 76358 | 止推垫片 | THRUST WASHER | 1 |
| 57 | 29976 | O型圈 | O-RING | 1 |
| 58 | 41529A2 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 58 | 41529T2 | 托架总成 | CARRIER ASSY | 1 |
| 59 | 98727 | 润滑脂接头 | FITTING Grease | 2 |
| 59 | 8M0169588 | 润滑脂接头 | FITTING Grease | 2 |
| 60 | 30956 | 滚针轴承 | BEARING Needle | 1 |
| 60 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 61 | 76868 | 密封件 | SEAL | 2 |
| 61 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 2 |
| 62 | 30281 | 键 | KEY | 1 |
| 63 | 52700 | 锁紧垫圈 | TAB WASHER | 1 |
| 64 | 52699 | 盖板 | COVER | 1 |
| 65 | 67891 | 填充块 | FILLER BLOCK | 1 |
| 65 | 8M0039169 | 填充块 | FILLER BLOCK | 1 |
| 66 | 30206 | 螺钉(.375-16 x 1.00)不锈钢 | SCREW (.375-16 x 1.00) Stainless Steel | 1 |
| 67 | 31211A2 | 花键垫圈 | WASHER Splined | 1 |
| 67 | 31211Q03 | 垫圈总成 | WASHER ASSEMBLY | 1 |
| 68 | 31210 | 锁紧垫圈 | TAB WASHER | 1 |
| 68 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 69 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 69 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 70 | 15300 | 阳极配平片 | TRIM TAB Anodic | 1 |
| 71 | 15797 | 螺钉 | SCREW | 1 |
| 72 | 45176 | 垫圈(.453 x .812 x .105)不锈钢 | WASHER (.453 x .812 x .105) Stainless Steel | 2 |
| 73 | 34933 | 螺母(.437-20)不锈钢 | NUT (.437-20) Stainless Steel | 2 |
| 73 | 8M0204653 | 螺母 | NUT | 2 |
| 74 | 13191A1 | 止推垫片 | THRUST WASHER | 1 |
| 74 | 13191Q01 | 止推垫片 | THRUST WASHER | 1 |
| 75 | 423511 | 齿形锁紧垫圈 | LOCKWASHER Toothed | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 79918A1 | 飞轮盖套件 | COVER KIT FLYWHEEL | 1 |
| 2 | 79022 | 正时标记 | MARKER TIMING | 1 |
| 3 | 37572 | 螺钉(0.190-32x0.380)正时标记 | SCREW (.190-32 x .380) TIMING MARKER | 2 |
| 4 | 72761 | 垫圈(0.203x0.562x0.060)不锈钢正时标记螺钉 | WASHER (.203 x .562 x .060) Stainless Steel TIMING MARKER SCREW | 2 |
| 5 | 89219 | 飞轮盖塞 | PLUG FLYWHEEL COVER | 1 |
| 5 | 89219001 | 堵头 | PLUG | 1 |
| 6 | 45907 | 飞轮黄色塞 | PLUG Yellow FLYWHEEL | 1 |
| 7 | 52901 | 螺母(.625-18)飞轮 | NUT (.625-18) FLYWHEEL | 1 |
| 8 | 68229 | 垫圈(0.641x1.250x0.190)飞轮 | WASHER (.641 x 1.250 x .190) FLYWHEEL | 1 |
| 8 | 33001 | 垫圈 | WASHER | 1 |
| 9 | 7555A8 | 飞轮 | FLYWHEEL | 1 |
| 9 | 859238A9 | 飞轮套件 | FLYWHEEL KIT | 1 |
| 9 | 7555A17 | 飞轮 | FLYWHEEL | 1 |
| 9 | 859238A9 | 飞轮套件 | FLYWHEEL KIT | 1 |
| 10 | 32417 | 螺钉(.250-28 x .625)飞轮板 | SCREW (.250-28 x .625) FLYWHEEL PLATE | 8 |
| 11 | 68997 | 螺钉(.312-24 x .750)飞轮毂 | SCREW (.312-24 x .750) FLYWHEEL HUB | 8 |
| 12 | 5454A32 | 定子(配15安培电压调节器) | STATOR (USE WITH VOLTAGE REGULATOR-15AMP) | 1 |
| 12 | 5454A35 | 定子(配15安培电压调节器) | STATOR (USE WITH VOLTAGE REGULATOR-15AMP) | 1 |
| 13 | 76566 | 定子螺钉(#10-24 x 1.00) | SCREW (#10-24 x 1.00) STATOR | 4 |
| 13 | 19926100 | 螺丝（#10-24 x 1.00） | SCREW (#10-24 x 1.00) | 4 |
| 15 | 96455A9 | 触发板总成 | PLATE ASSEMBLY Trigger | 1 |
| 17 | 79472 | 启动电机总成(8齿小齿轮) | STARTER MOTOR ASSEMBLY (8 TOOTH PINION) | 1 |
| 17 | 893893 | 启动马达 | STARTER MOTOR | 1 |
| 18 | 56703 | 启动电机轴环 | COLLAR STARTER MOTOR | 2 |
| 18 | 8M0034918 | 轴环 | COLLAR | 2 |
| 19 | 68042 | 启动电机橡胶止动块 | STOP Rubber RUBBER - STARTER MOTOR | 2 |
| 19 | 8M0043376 | 停机开关 | STOP | 2 |
| 20 | 26992 | 锁紧垫圈(.250) 不锈钢 起动机接线端 | LOCKWASHER (.250) Stainless Steel STARTER MOTOR TERMINAL | 1 |
| 21 | 20890 | 螺母(.250-20) 起动机接线端 | NUT (.250-20) STARTER MOTOR TERMINAL | 1 |
| 22 | 93388A2 | 电磁阀至启动电机黑色电缆总成 | CABLE ASSEMBLY Black SOLENOID TO STARTER MOTOR | 1 |
| 22 | 93388A14 | 线缆总成(黄/黑) | CABLE ASSEMBLY Yellow/Black | 1 |
| 23 | 69035 | 螺钉和锁紧垫圈 (.250-20 x .625) 不锈钢 电缆至启动马达 | SCREW AND LOCKWASHER (.250-20 x .625) Stainless Steel CABLE TO STARTER MOTOR | 1 |
| 24 | 93388A1 | 电缆总成(6.00英寸)黑色板至启动马达 | CABLE ASSEMBLY (6.00 Inches) Black PLATE TO STARTER MOTOR | 1 |
| 25 | 7370A13 | 点火线圈总成 | COIL ASSEMBLY Ignition IGNITION | 6 |
| 25 | 8M0230859 | 点火线圈总成 | COIL IGNITION ASY | 6 |
| 26 | 67614 | 点火线圈盖 | COVER IGNITION COIL | 3 |
| 27 | 88447 | 点火线圈盖螺钉(.190-32 x 1.62) | SCREW (.190-32 x 1.62) IGNITION COIL COVER | 12 |
| 28 | 45076 | 螺母(#10-32)黄铜点火线圈端子 | NUT (#10-32) Brass IGNITION COIL TERMINAL | 12 |
| 29 | 88807A6 | 点火线圈黑色电缆总成(3.50英寸) | CABLE ASSEMBLY (3.50 Inches) Black IGNITION COIL | 6 |
| 30 | 68513 | 接地带不锈钢螺钉(#10-32 x .375) | SCREW (#10-32 x .375) Stainless Steel GROUND STRAP | 6 |
| 31 | 99215A25 | 高压导线总成 | LEAD ASSEMBLY HIGH TENSION | 6 |
| 31 | 813715A1 | 引线 | LEAD WIRE | 6 |
| 32 | 63709A1 | 高压电缆护套/端子套件 | BOOT/TERMINAL KIT HIGH TENSION CABLE | 6 |
| 33 | 136862 | 火花塞 | SPARK PLUG | 6 |
| 33 | 13686Q | NGK BU8H @10 | NGK BU8H @10 | 6 |
| 34 | 69738A1 | 线圈至开关盒线束总成(#2,4&6) | HARNESS ASSEMBLY COIL TO SWITCH BOX (#2, 4 & 6) | 1 |
| 34 | 69738A7 | 线束总成 | HARNESS ASSEMBLY | 1 |
| 34 | 69739A2 | 线圈至开关盒线束总成(#1,3&5) | HARNESS ASSEMBLY COIL TO SWITCH BOX (#1, 3 & 5) | 1 |
| 35 | 30164 | 点火线圈盖螺钉不锈钢垫圈(.192 x .375 x .0312) | WASHER (.192 x .375 x .0312) Stainless Steel IGNITION COIL COVER SCREW | 12 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 92876A9 | 双机延长套件 | EXTENSION KIT Dual Engine | 1 |
| 1 | 48462 | O型圈 (.614 x .070) | O-RING (.614 x .070) | 1 |
| 2 | 71565A2 | 管总成 | TUBE ASSEMBLY | 1 |
| 3 | 41055 | 支架 | MOUNT | 1 |
| 4 | 42100 | 锁紧垫圈 | TAB WASHER | 2 |
| 5 | 37984 | 螺母 (.875-14) | NUT (.875-14) | 2 |
| 5 | 8M0041651 | 螺母 (.875-14) | NUT (.875-14) | 2 |
| 6 | 88404 | 锁紧垫圈 | TAB WASHER | 2 |
| 7 | 38601 | 螺丝(.250-28 x 1.250) | SCREW (.250-28 x 1.250) | 4 |
| 8 | 17729A1 | 支架 | BRACKET | 2 |
| 9 | 62055 | 螺钉(.312-24 x 1.250) | SCREW (.312-24 x 1.250) | 4 |
| 10 | 17728 | 锁紧垫圈 | TAB WASHER | 4 |
| 11 | 140001 | 螺钉(0.375-24×1.38) | SCREW (.375-24 x 1.38) | 4 |
| 12 | 34863 | 螺母 (.375-24) | NUT (.375-24) | 6 |
| 12 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 6 |
| 13 | 979331 | 转向眼环 | STEERING EYE | 2 |
| 13 | 8M0026167 | 转向眼环 | STEERING EYE | 2 |
| 14 | 23651 | 衬套(1.625) | SLEEVE (1.625) | 2 |
| 15 | 97931 | 管材(4.00英寸) | TUBING (4.00 Inches) | 2 |
| 16 | 8149513 | 联轴器(15.00英寸) | COUPLER (15.00 Inches) | 1 |
| 16 | 8M0026098 | 联轴器15英寸 | COUPLER 15 In. | 1 |
| 17 | 42099 | 螺母(.562-18) | NUT (.562-18) | 1 |
| 18 | 821169 | 联轴器 | COUPLING | 1 |
| 19 | 34931 | 不锈钢垫圈(.406x.734x.063) | WASHER (.406 x .734 x .063) Stainless Steel | 2 |
| 20 | 94319 | 螺钉(.375-24 x 1.5) | SCREW (.375-24 x 1.5) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 9148A27 | 齿轮箱总成 反转向(加长型) | GEAR HOUSING ASSEMBLY Counter Rotation (X-LONG) | 1 |
| - | 9148A28 | 齿轮箱总成 反转向(加长型) | GEAR HOUSING ASSEMBLY Counter Rotation (X-LONG) | 1 |
| - | 9148T89 | 齿轮箱壳体-CXL-灰色 | GEAR HSG-CXL-GRAY | 1 |
| - | 9148A30 | 齿轮箱总成 反向旋转(加长型)(黑色) | GEAR HOUSING ASSEMBLY Counter Rotation (X-LONG)(BLACK) | 1 |
| - | 9148T86 | 齿轮箱总成(完整)(鱼雷体直径4.75英寸/120.65毫米) | GEAR HOUSING ASSEMBLY Complete (4.75 Inch/120.65 mm Torpedo Diameter) | 1 |
| - | 9148A31 | 齿轮箱总成 反转向(加长型) | GEAR HOUSING ASSEMBLY Counter Rotation (X-LONG) | 1 |
| - | 9148T92 | ORD 1647-9148T86 | ORD 1647-9148T86 | 1 |
| 1 | 9148A11 | 齿轮箱总成(黑色)(基本型) | GEAR HOUSING ASSEMBLY (BLACK)(BASIC) | 1 |
| 1 | 9148T47 | 齿轮箱-基础型-黑 | GEAR HSG-BASIC-BL | 1 |
| 1 | 9148A12 | 齿轮箱总成(灰色)(基础款) | GEAR HOUSING ASSEMBLY (GRAY)(BASIC) | 1 |
| 1 | 9148T47 | 齿轮箱-基础型-黑 | GEAR HSG-BASIC-BL | 1 |
| 47 | 78956 | 换挡凸轮 | SHIFT CAM | 1 |
| 47 | 789562 | 换挡凸轮 | SHIFT CAM | 1 |
| 48 | 89594A1 | 凸轮从动件总成 | FOLLOWER ASSEMBLY CAM | 1 |
| 49 | 79911 | 离合器作动杆 | ROD CLUTCH ACTUATOR | 1 |
| 49 | 79911A1 | 杆 | ROD | 1 |
| 50 | 79910 | 压缩弹簧 | SPRING COMPRESSION | 2 |
| 51 | 78910 | 弹簧垫圈 | WASHER SPRING | AR |
| 52 | 78906 | PIN SPRING LOCATOR | 1 | |
| 52 | 8M0084245 | 弹簧定位销 | PIN Spring Locator | 1 |
| 53 | 14469 | 轴承杯 | CUP Bearing | 1 |
| 53 | 14469T | 轴承杯 | CUP Bearing | 1 |
| 54 | 88957A1 | 滚珠轴承 | BEARING Ball | 1 |
| 54 | 88957T | 滚珠轴承 | BEARING Ball | 1 |
| 55 | NSS | 倒车齿轮(不单独销售)(43-18572A1或43-18475A1部件) | NOT SOLD SEPARATE Reverse Gear (PART OF 43-18572A1 or 43-18475A1) | 1 |
| 56 | 15844 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 57 | 78909 | 棘轮定位销 | PIN Detent RATCHET | 2 |
| 58 | 78959 | 棘轮滑动离合器 | RATCHET SLIDING CLUTCH | 1 |
| 58 | 823174T | ORD 8M0100493 | ORD 8M0100493 | 1 |
| 59 | 78905 | 十字棘轮销 | PIN Cross RATCHET | 1 |
| 59 | 8M0084243 | 十字销 | PIN Cross | 1 |
| 60 | 78962 | 十字销固定弹簧 | SPRING RETAINING - CROSS PIN | 2 |
| 61 | 18572A1 | 前进齿轮总成 | GEAR ASSEMBLY Forward | 1 |
| 61 | 18572T1 | 齿轮组 | GEAR SET | 1 |
| 61 | 18475A1 | 前进齿轮总成 | GEAR ASSEMBLY Forward | 1 |
| 61 | 18475T1 | 齿轮组 | GEAR SET | 1 |
| 62 | 176151 | 调整垫片(.125) | SPACER SHIM (.125) | AR |
| 62 | 176152 | 调整垫片(.127) | SPACER SHIM (.127) | AR |
| 62 | 176153 | 调整垫片(.129) | SPACER SHIM (.129) | AR |
| 62 | 176154 | 调整垫片(.131) | SPACER SHIM (.131) | AR |
| 62 | 176155 | 调整垫片(.133) | SPACER SHIM (.133) | AR |
| 62 | 176156 | 调整垫片(.135) | SPACER SHIM (.135) | AR |
| 62 | 176157 | 调整垫片(.137) | SPACER SHIM (.137) | AR |
| 62 | 176158 | 调整垫片(.139) | SPACER SHIM (.139) | AR |
| 62 | 176159 | 调整垫片(.141) | SPACER SHIM (.141) | AR |
| 62 | 1761510 | 调整垫片(.143) | SPACER SHIM (.143) | AR |
| 62 | 1761511 | 调整垫片(.145) | SPACER SHIM (.145) | AR |
| 62 | 1761512 | 调整垫片(.147) | SPACER SHIM (.147) | AR |
| 62 | 1761513 | 调整垫片(.149) | SPACER SHIM (.149) | AR |
| 63 | 15841 | 滚柱轴承 | BEARING Roller | 1 |
| 64 | 17616 | 推力环 | THRUST RING | 1 |
| 65 | 31534 | 轴承座O型圈 | O-RING BEARING CARRIER | 1 |
| 65 | 8M0214920 | O型圈 | O RING | 1 |
| 66 | 18447A2 | 轴承适配器总成 | ADAPTER ASSEMBLY Bearing | 1 |
| 66 | 18447T2 | 适配器总成 | ADAPTOR ASSEMBLY | 1 |
| 67 | 15843 | 滚柱轴承 | BEARING Roller | 1 |
| 67 | 15843T | 滚针轴承 | BEARING Needle | 1 |
| 68 | 18448 | 止推垫片 | THRUST WASHER | 2 |
| 69 | 15842 | 推力轴承 | BEARING Thrust | 2 |
| 70 | 18446 | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 71 | 18444A1 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 71 | 818896T2 | 轴承座 | BEARING CARRIER | 1 |
| 72 | 30956 | 滚针轴承-轴承座 | BEARING Needle BEARING CARRIER | 2 |
| 72 | 30956T | 滚针轴承 | BEARING Needle | 2 |
| 73 | 76868 | 密封件 | SEAL | 2 |
| 73 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 2 |
| 74 | 79447 | 齿轮箱盖锁紧垫圈 | TAB WASHER GEAR HOUSING COVER | 1 |
| 75 | 79448 | 齿轮箱固定座 | RETAINER GEAR HOUSING | 1 |
| 75 | 8M2011027 | 固定座 | RETAINER | 1 |
| 76 | 30281 | KEY LOCATING - BEARING CARRIER | 1 | |
| 77 | 31640A1 | TRIM TAB ASSEMBLY GEAR HOUSING | 1 | |
| 77 | 31640Q4 | 平衡鳍板 | TRIM TAB | 1 |
| 78 | 66024 | SCREW (.437-14 x 1.75) TRIM TAB TO GEAR HOUSING | 1 | |
| 79 | 67891 | 填充块 | FILLER BLOCK | 1 |
| 79 | 8M0039169 | 填充块 | FILLER BLOCK | 1 |
| 80 | 45176 | 垫圈(.453 x .812 x .105)不锈钢驱动轴壳体螺柱 | WASHER (.453 x .812 x .105) Stainless Steel DRIVE SHAFT HOUSING STUDS | 2 |
| 81 | 34933 | 螺母(.437-20)不锈钢驱动轴壳体螺柱 | NUT (.437-20) Stainless Steel DRIVE SHAFT HOUSING STUDS | 2 |
| 81 | 8M0204653 | 螺母 | NUT | 2 |
| 82 | 13171 | 推力毂 | THRUST HUB | 1 |
| 82 | 835467Q01 | 止推垫片套件 | THRUST WASHER KIT | 1 |
| 83 | 31211A2 | 螺旋桨螺母花键垫圈 | WASHER Splined PROPELLER NUT | 1 |
| 83 | 31211Q03 | 垫圈总成 | WASHER ASSEMBLY | 1 |
| 84 | 816629 | 螺旋桨螺母锁紧垫圈 | TAB WASHER PROPELLER NUT | 1 |
| 84 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 85 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 85 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 86 | 423511 | 螺旋桨轴齿形锁紧垫圈 | LOCKWASHER Toothed PROPELLER SHAFT | 1 |
| 87 | 65210 | 螺钉(.375-16 x 1.00)齿轮箱 | SCREW (.375-16 x 1.00) GEAR HOUSING | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 15221A2 | 气缸盖总成 | CYLINDER HEAD ASSEMBLY | 2 |
| 2 | 41246 | 气缸盖衬垫 | GASKET CYLINDER HEAD | 2 |
| 2 | 41247T01 | 衬垫 | GASKET | 2 |
| 3 | 98534 | 螺钉 (0.375-16 x 2.30) 气缸盖（2英寸） | SCREW (.375-16 x 2.30) CYLINDER HEAD (2") | 23 |
| 3 | 13450 | 螺钉 (0.375-16 x 2.30) 气缸盖（专用） | SCREW (.375-16 x 2.30) CYLINDER HEAD (SPECIAL) | 1 |
| 4 | 25909 | 气缸盖螺钉垫圈 (.406 x .812 x .065) | WASHER (.406 x .812 x .065) CYLINDER HEAD SCREW | 24 |
| 5 | 75692 | 节温器 | THERMOSTAT | 2 |
| 6 | 62386 | 节温器衬垫 | GASKET THERMOSTAT | 2 |
| 6 | 8M0204714 | 衬垫@4 | GASKET @4 | 2 |
| 7 | 90390A1 | 节温器盖套件 | COVER KIT THERMOSTAT | 2 |
| 8 | 35386 | 螺钉 (0.312-18 x 1.00) 节温器盖（1英寸） | SCREW (.312-18 x 1.00) THERMOSTAT COVER (1") | 4 |
| 9 | 68727 | 90度黄铜弯头接头 (.250-18)（水管用） | FITTING (.250-18) 90 Degree - Brass ELBOW - WATER HOSES | 1 |
| 9 | 687271 | 90度弯头 (.250-18) - 黄铜 | FITTING (.250-18) 90 Degree - Brass | 1 |
| 10 | 7765377 | 配水软管（散装24.500英寸） | HOSE (24.500 Inches Bulk) WATER DISTRIBUTION | 2 |
| 10 | 77653101 | 软管（散装48.00英寸） | HOSE (48.00 Inches Bulk) | 2 |
| 11 | 68728 | 节温器盖至水管接头 | FITTING THERMOSTAT COVER TO WATER HOSES | 1 |
| 12 | 90077 | 水管束带 | TIE STRAP WATER HOSES | AR |
| 12 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 13 | 97465 | 温度传感器（右舷） | SENDER Temperature (STARBOARD) | 1 |
| 13 | 13536A6 | 温度传感器总成（左舷） | SENSOR ASSEMBLY Temperature (PORT) | 1 |
| 14 | 13715 | 传感器固定座 | RETAINER SENSOR AND SENDER | 2 |
| 14 | 137151 | 固定座 | RETAINER | 2 |
| 15 | 98257 | 螺钉 (0.312-18 x 0.500) 固定座 | SCREW (.312-18 x .500) RETAINER | 2 |
| 16 | 13192 | 爆震传感器 | SENSOR Detonation | 1 |
| 16 | 825164A1 | 爆震传感器总成 | SENSOR ASSEMBLY Detonation | 1 |
| 17 | 45076 | 螺母 (#10-32) 黄铜爆震传感器 | NUT (#10-32) Brass DETONATION SENSOR | 1 |
| 18 | 14593A4 | 适配板总成 | ADAPTER PLATE ASSEMBLY | 1 |
| 19 | 28668 | 螺钉 (0.250-20 x 0.875) 不锈钢适配板 | SCREW (.250-20 x .875) Stainless Steel ADAPTOR PLATE | 8 |
| 20 | 146971 | 适配板垫片 | GASKET ADAPTOR PLATE | 1 |
| 21 | 75953 | 簧片阀组 | REED BLOCK | 6 |
| 22 | 75362A1 | 簧片组件 | REED ASSEMBLY | 6 |
| 23 | 96183 | 簧片夹 | CLAMP Reed | 12 |
| 23 | 961832 | 簧片夹 | CLAMP Reed | 12 |
| 24 | 14783 | 螺钉 (#8-32 x 0.187) 簧片至簧片座 | SCREW (#8-32 x .187) REEDS TO REED BLOCK | 60 |
| 24 | 823588 | 螺钉 (#8-32 x .250) | SCREW (#8-32 x .250) | 60 |
| 25 | 21558 | 螺钉 (0.250-20 x 0.75) 簧片座固定（3/4英寸） | SCREW (.250-20 x .75) REED BLOCK ATTACHING (3/4") | 6 |
| 25 | 92160 | 螺钉(.250-20 x .750)不锈钢 | SCREW (.250-20 x .750) Stainless Steel | 6 |
| 26 | 90197 | 螺钉 (0.250-20 x 1.125) 簧片座固定（2英寸） | SCREW (.250-20 x 1.125) REED BLOCK ATTACHING (2") | 6 |
| 27 | 167371 | 适配板垫片 | GASKET ADAPTOR PLATE | 1 |
| - | 14697A87 | 衬垫套件 | GASKET SET |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 828334F1 | 艉板支架 | BRACKET Transom | 1 |
| 2 | 828333A3 | 艉板支架总成 | BRACKET ASSEMBLY Transom | 1 |
| 2 | 828333T07 | 艉板支架总成-左舷 | BRACKET ASSEMBLY Transom - Port | 1 |
| 3 | 98727 | 润滑脂接头 | FITTING Grease | 1 |
| 3 | 8M0169588 | 润滑脂接头 | FITTING Grease | 1 |
| 4 | 99170A2 | 倾斜管套件 | TUBE KIT Tilt | 1 |
| 4 | 826125A1 | 倾斜管 | TILT TUBE | 1 |
| 4 | 826125A1 | 倾斜管 | TILT TUBE | 1 |
| 5 | 859133 | 螺母(1.00-14) | NUT (1.00-14) | 1 |
| 5 | 82671327 | 螺母(1.0-14) | NUT (1.0-14) | 1 |
| 5 | 826135 | 尼龙锁紧螺母(1.00-14) | NUT Lock (1.00-14) Nylon Insert | 1 |
| 6 | 45711 | O型圈 (.612 x .103) | O-RING (.612 x .103) | 1 |
| 7 | 88750 | 波浪垫圈 (1.62 x 1.05) | WASHER Wave (1.62 x 1.05) | 2 |
| 8 | 858869 | 螺母 (.875-14) | NUT (.875-14) | 1 |
| 8 | 826164 | 螺母 (.875-14) | NUT (.875-14) | 1 |
| 8 | 8M0231351 | 锁紧螺母 | NUT Lock | 1 |
| 9 | 677551 | 螺钉(.500-20×4.500) | SCREW (.500-20 x 4.500) | 4 |
| 9 | 8M0149747 | 螺钉 | SCREW | 4 |
| 10 | 54012 | 垫圈(0.530×0.870×0.105不锈钢) | WASHER (.530 x .870 x .105) Stainless Steel | 4 |
| 10 | 8M0204665 | 垫圈(0.530×0.880×0.104 630不锈钢) | WASHER (.530 x .880 x .104) 630 Stainless Steel | 4 |
| 11 | 28421 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 11 | 8M0204648 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 12 | 82671117 | 螺母(.500-20) | NUT (.500-20) | 4 |
| 13 | 830899 | 张力弹簧 | SPRING Tension | 1 |
| 14 | 821176T1 | 倾斜锁定杆总成 | LEVER ASSEMBLY Tilt Lock | 1 |
| 14 | 8M0109798 | 倾斜锁定杆总成 | LEVER ASSEMBLY Tilt Lock | 1 |
| 15 | 65830 | 尼龙衬套 | NYLINER | 2 |
| 16 | 830900 | 压缩弹簧 | SPRING Compression | 1 |
| 17 | 99633 | 旋钮 | KNOB | 1 |
| 18 | 99615 | 槽销 | PIN Groove | 1 |
| 19 | 99617 | 销 | PIN | 1 |
| 19 | 893709 | 销 | PIN | 1 |
| 20 | 818771T1 | 锚支架 | BRACKET Anchor | 1 |
| 20 | 8M0086406 | 锚支架 | BRACKET Anchor | 1 |
| 21 | 858771 | 螺钉 (M10 x 30) | SCREW (M10 x 30) | 6 |
| 22 | 4002319 | 垫圈 | WASHER | 6 |
| 23 | 40114 | 螺母(M10 x 1.5) | NUT (M10 x 1.5) | 1 |
| 24 | 818298Q1 | 阳极套件 | ANODE KIT | 1 |
| 25 | 4000330 | 螺钉(M6x25) | SCREW (M6 x 25) | 2 |
| 25 | 8M0204707 | 不锈钢六角大帽螺钉(M6x25) | SCREW M6 x 25 HX HD CAP SS | 2 |
| 26 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 26 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 814247A3 | 齿轮箱总成1.78:1速比-黑色 | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Black | 1 |
| - | 814247A4 | 齿轮箱总成 1.78:1 减速比 - 灰色 | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Gray | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 814247A1 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 814247T1 | 齿轮箱总成基础型-黑色 | GEAR HOUSING ASSEMBLY Basic-Black | 1 |
| 1 | 814247A2 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 1 | 814247T2 | ORD 1674-814247T1 | ORD 1674-814247T1 | 1 |
| 44 | 76039 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 44 | 760394 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 45 | 12239A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 45 | 850315A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 46 | 30622 | 弹簧 | SPRING | 1 |
| 47 | 44491A1 | 垫片组 | SHIM SET | AR |
| 47 | 8M0063266 | 垫片组 | SHIM SET | AR |
| 48 | 30894A1 | 圆锥轴承组 | BEARING SET Cup And Cone | 1 |
| 49 | 16279A2 | 前进齿轮总成 | GEAR ASSEMBLY Forward | 1 |
| 50 | 30895 | 滚针轴承 | BEARING Needle | 1 |
| 50 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 51 | 814756 | 离合器 | CLUTCH | 1 |
| 51 | 822539T | 离合器 | CLUTCH | 1 |
| 52 | 30632 | 十字销 | PIN Cross | 1 |
| 52 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 53 | 30893 | 弹簧 | SPRING | 1 |
| 54 | 12238T | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 55 | N.S.S. | 倒车齿轮(不单独销售)(属于43-16279A2部件) | Not Sold Separate Reverse Gear (PART OF 43-16279A2) | 1 |
| 56 | 76358 | 止推垫片 | THRUST WASHER | 1 |
| 57 | 29976 | O型圈 | O-RING | 1 |
| 58 | 41529A2 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 58 | 41529T2 | 托架总成 | CARRIER ASSY | 1 |
| 59 | 98727 | 润滑脂接头 | FITTING Grease | 2 |
| 59 | 8M0169588 | 润滑脂接头 | FITTING Grease | 2 |
| 60 | 30956 | 滚针轴承 | BEARING Needle | 1 |
| 60 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 61 | 76868 | 密封件 | SEAL | 2 |
| 61 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 2 |
| 62 | 30281 | 键 | KEY | 1 |
| 63 | 52700 | 锁紧垫圈 | TAB WASHER | 1 |
| 64 | 52699 | 盖板 | COVER | 1 |
| 65 | 67891 | 填充块 | FILLER BLOCK | 1 |
| 65 | 8M0039169 | 填充块 | FILLER BLOCK | 1 |
| 66 | 65210 | 螺钉(.375-16 x 1.00) | SCREW (.375-16 x 1.00) | 1 |
| 68 | 816629 | 锁紧垫圈 | TAB WASHER | 1 |
| 68 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 69 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 69 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 70 | 15300 | 阳极配平片 | TRIM TAB Anodic | 1 |
| 71 | 66024 | 螺钉(.437-14 x 1.75) | SCREW (.437-14 x 1.75) | 1 |
| 72 | 45176 | 垫圈(.453 x .812 x .105)不锈钢 | WASHER (.453 x .812 x .105) Stainless Steel | 2 |
| 73 | 34933 | 螺母(.437-20)不锈钢 | NUT (.437-20) Stainless Steel | 2 |
| 73 | 8M0204653 | 螺母 | NUT | 2 |
| 74 | 13191A1 | 止推垫片 | THRUST WASHER | 1 |
| 74 | 13191Q01 | 止推垫片 | THRUST WASHER | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 99186T | 泵与电机总成 | PUMP AND MOTOR | 1 |
| 1 | 12659 | 机架与磁场套件 | FRAME AND FIELD KIT | 1 |
| 1 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 2 | 12665 | 电刷弹簧套件 | SPRING KIT Brush | 1 |
| 3 | 13506 | 电刷卡套件 | BRUSH CARD KIT | 1 |
| 3 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 4 | 12662 | 泵与端架套件 | PUMP AND END FRAME KIT | 1 |
| 4 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 5 | 12663 | 泵密封套件 | SEAL KIT Pump | 1 |
| 5 | 126631 | 泵密封套件 | SEAL KIT Pump | 1 |
| 6 | 12660 | 端架套件 | END FRAME KIT | 1 |
| 6 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 7 | 12661 | 电枢套件 | ARMATURE KIT | 1 |
| 7 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 8 | 12664 | 贯穿螺栓套件 | THRU BOLT KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9536A4 | 曲轴总成 | CRANKSHAFT ASSEMBLY | 1 |
| 2 | 67923 | 曲轴下球轴承 | BEARING Ball CRANKSHAFT (LOWER) | 1 |
| 2 | 67923T | 滚珠轴承 | BEARING Ball | 1 |
| 3 | 67446 | 球轴承挡圈 | RING BALL BEARING | 1 |
| 4 | 14513A2 | 驱动齿轮段套件 | GEAR SEGMENT KIT Drive | 2 |
| 4 | 14513A09 | 驱动齿轮段套件 | GEAR SEGMENT KIT Drive | 2 |
| 5 | 813073 | 螺钉(#6-32 x .620)内六角头 | SCREW (#6-32 x .620) Socket Head | 2 |
| 6 | 813134 | 螺母(#6-32)专用 | NUT (#6-32) Special | 2 |
| 7 | 54196A6 | 密封载体总成 | CARRIER ASSEMBLY SEAL | 1 |
| 8 | 65800 | 填料载体 | PACKING CARRIER | 1 |
| 9 | 67377 | 密封环-曲轴 | RING Sealing SEALING - CRANKSHAFT | 8 |
| 9 | 67377T | 密封环 | RING Sealing | 8 |
| 10 | 16756A1 | 滚子轴承总成-曲轴 | BEARING ASSEMBLY Roller CRANKSHAFT | 2 |
| 10 | 16756A6 | 轴承套件 | BEARING KIT | 2 |
| 11 | 7441A3 | 活塞总成(右舷-标准) | PISTON ASSEMBLY (STARBOARD-STANDARD) | 3 |
| 11 | 7441T36 | 活塞-右舷-标准 | PISTON-STBD-STD | 3 |
| 11 | 7443A2 | 活塞总成(右舷-0.015加大) | PISTON ASSEMBLY (STARBOARD-.015 O.S.) | AR |
| 11 | 7443A12 | 活塞-右舷-0.015 | PISTON-STBD-.015 | AR |
| 11 | 7445A2 | 活塞总成(右舷-0.030加大) | PISTON ASSEMBLY (STARBOARD-.030 OS.) | AR |
| 11 | 7445A12 | 活塞-右舷-0.030 | PISTON-STBD-.030 | AR |
| 11 | 7442A3 | 活塞总成(左舷-标准) | PISTON ASSEMBLY (PORT-STANDARD) | 3 |
| 11 | 7442T36 | 活塞-左舷-标准 | PISTON-PORT-STD | 3 |
| 11 | 7444A2 | 活塞总成(左舷-0.015加大) | PISTON ASSEMBLY (PORT-.015 O.S.) | AR |
| 11 | 7444A12 | 活塞-左舷-0.015 | PISTON-PORT-.015 | AR |
| 11 | 7446A2 | 活塞总成(左舷-0.030加大) | PISTON ASSEMBLY (PORT-.030 O.S.) | AR |
| 11 | 7446T12 | 活塞-左舷-0.030 | PISTON-PORT-.030 | AR |
| 11 | 8666A22 | 活塞总成(右舷-标准) | PISTON ASSEMBLY (STARBOARD-STANDARD) | 3 |
| 11 | 8666T42 | 活塞总成-右舷-标准 | PIST.ASY.STBD.STD | 3 |
| 11 | 8666A36 | 活塞总成-右舷(0.015加大) | PISTON ASSEMBLY Starboard (015 O.S.) | AR |
| 11 | 8666A43 | 活塞总成-右舷-0.015 | PIST.ASY STBD.015 | AR |
| 11 | 8667A22 | 活塞总成(左舷-标准) | PISTON ASSEMBLY (PORT-STANDARD) | 3 |
| 11 | 8667T42 | 活塞总成-左舷-标准 | PIST.ASY.PORT.STD | 3 |
| 11 | 8667A36 | 活塞总成-左舷(0.015加大) | PISTON ASSEMBLY Port (.015 O.S.) | AR |
| 11 | 8667A43 | 活塞总成-左舷-0.015 | PIST.ASY PORT.015 | AR |
| 11 | 9738A2 | 活塞总成(右舷-标准) | PISTON ASSEMBLY (STARBOARD-STANDARD) | 3 |
| 11 | 9738T4 | 活塞-右舷-标准 | PISTON-STBD-STD | 3 |
| 11 | 9738A3 | 活塞总成(右舷-0.015加大) | PISTON ASSEMBLY (STARBOARD-.015 O.S.) | AR |
| 11 | 9738A5 | 活塞-右舷-0.015 | PISTON-STBD-.015 | AR |
| 11 | 9737A2 | 活塞总成(左舷-标准) | PISTON ASSEMBLY (PORT-STANDARD) | 3 |
| 11 | 9737T4 | 活塞-左舷-标准 | PISTON-PORT-STD | 3 |
| 11 | 9737A3 | 活塞总成(左舷-0.015加大) | PISTON ASSEMBLY (PORT-.015 O.S.) | AR |
| 11 | 9737A5 | 活塞-左舷-0.015 | PISTON-PORT-.015 | AR |
| 12 | 93481A12 | 活塞环组-标准(标准) | RING SET Piston - Standard (STANDARD) | 1 |
| 12 | 78918A4 | 活塞环组-0.015加大(0.015加大) | RING SET Piston - .015 Oversize (.015 O.S.) | AR |
| 12 | 85636A4 | 活塞环组-0.030加大(0.030加大) | RING SET Piston - .030 Oversize (.030 O.S.) | AR |
| 12 | 18487A12 | 活塞环组(标准) | RING SET Piston (STANDARD) | 1 |
| 12 | 815267A4 | 活塞环组(.015加大) | RING SET Piston (.015 O.S.) | AR |
| 12 | 815515A12 | 活塞环组(标准) | RING SET Piston (STANDARD) | 1 |
| 12 | 815268A4 | 活塞环组(.015加大) | RING SET Piston (.015 O.S.) | AR |
| 13 | 52035 | 锁环 | RING Lock | 12 |
| 13 | 857196 | 锁紧环 | LOCK RING | 12 |
| 14 | 8119A5 | 连杆总成 | CONNECTING ROD ASSEMBLY | 6 |
| 14 | 8119A6 | 连杆套件 | CONN ROD KIT | 6 |
| 15 | 93886 | 螺钉(0.312-28×0.875)连杆 | SCREW (.312-28 x .875) CONNECTING ROD | 12 |
| 16 | 47247 | 定位针垫圈 | WASHER NEEDLE LOCATING | 12 |
| 16 | 8M0032839 | 垫片@5 | WASHER @5 | 12 |
| 17 | 17514A1 | 轴承套件 | BEARING KIT | 6 |
| 17 | 8M0234886 | 轴承保持架 | CAGE BEARING | 6 |
| 18 | 67483 | 活塞端滚针轴承 | BEARING Needle PISTON END | 174 |
| - | 815791A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815809A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815810A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8710A17 | 旋转支架总成（黑色） | SWIVEL BRACKET ASSEMBLY (BLACK) | 1 |
| 1 | 8710A18 | 旋转支架总成（灰色） | SWIVEL BRACKET ASSEMBLY (GRAY) | 1 |
| 1 | 8710T21 | 灰色旋转支架总成 | SWIVEL BRACKET ASSEMBLY Gray | 1 |
| 2 | 87735 | SEAL Oil SWIVEL BRACKET (LOWER) | 1 | |
| 3 | 67669 | 旋转支架衬套-上下部 | BUSHING SWIVEL BRACKET-LOWER AND UPPER | 2 |
| 3 | 818764 | 衬套 | BUSHING | 2 |
| 4 | 33466 | 上部O型圈 | O-RING UPPER | 1 |
| 5 | 67668 | 上部隔套 | SPACER UPPER | 1 |
| 6 | 74036 | 润滑脂接头 | FITTING Grease | 2 |
| 6 | 8M0169589 | 润滑脂接头 | FITTING Grease | 2 |
| 7 | 99608 | 转轴支架衬套 | BUSHING SWIVEL BRACKET | 2 |
| 7 | 821207 | 衬套 | BUSHING | 2 |
| 8 | 67706A35 | 旋转销总成(黑色) | SWIVEL PIN ASSEMBLY (BLACK) | 1 |
| 8 | 67706A55 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 8 | 67706A36 | 旋转销总成(灰色) | SWIVEL PIN ASSEMBLY (GRAY) | 1 |
| 8 | 67706A55 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 9 | 78689 | 螺钉(0.437-20×7.50)转向臂至上支架 | SCREW (.437-20 x 7.50) STEERING ARM TO UPPER MOUNT | 2 |
| 9 | 8M0176309 | 螺钉 | SCREW | 2 |
| 10 | 78687 | 橡胶支架-上部(长型) | MOUNT RUBBER-UPPER (LONG) | 2 |
| 10 | 78687T | 支架 | MOUNT | 2 |
| 10 | 77326 | 支架(加长型)(用于XR4/MAGNUM II) | MOUNT (X-LONG) (USE ON XR4/MAGNUM II) | 2 |
| 11 | 66921 | 上支座螺栓垫圈 | WASHER UPPER MOUNT BOLT | 2 |
| 12 | 814432 | 上支座螺栓垫圈 | WASHER UPPER MOUNT BOLT | 2 |
| 12 | 78688 | 垫圈 | WASHER | 2 |
| 13 | 34933 | 螺母（0.437-20）不锈钢上部安装螺栓 | NUT (.437-20) Stainless Steel UPPER MOUNT BOLT | 2 |
| 13 | 8M0204653 | 螺母 | NUT | 2 |
| 14 | 92876A1 | 转向连杆总成 | LINK ASSEMBLY Steering | 1 |
| 14 | 92876A12 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 15 | 14000 | SCREW (.375-24 x 1.25) STEERING LINK TO STEERING ARM | 1 | |
| 15 | 849838 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 1 |
| 16 | 34863 | NUT (.375-24) STEERING LINK SCREW | 2 | |
| 16 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 2 |
| 17 | 34931 | WASHER (.406 x .734 x .063) Stainless Steel STEERING LINK TO STEERING ARM | 2 | |
| 18 | 78854 | WAVE WASHER BOTTOM YOKE | 1 | |
| 19 | 86580A1 | 底部轭架总成（黑色） | YOKE ASSEMBLY Bottom (BLACK) | 1 |
| 19 | 878182T | 轭架底部-不锈钢 | YOKE Bottom - Stainless Steel | 1 |
| 19 | 86580A2 | 底部轭架总成（灰色） | YOKE ASSEMBLY Bottom (GRAY) | 1 |
| 19 | 86580A1 | 底部轭架总成 | YOKE ASSEMBLY Bottom | 1 |
| 20 | 67684 | 卡环-底部轭架 | RING Retaining BOTTOM YOKE | 1 |
| 21 | 67670 | 垫圈 | WASHER | 1 |
| 22 | 88882 | 缓冲垫-顶部轭架 | BUMPER Top Yoke TOP YOKE | 1 |
| 23 | 64014 | SCREW (.250-28 x .500) SWIVEL BRACKET | 2 | |
| 24 | 54457 | J型卡扣 | J CLIP | 1 |
| - | 815791A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815809A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815810A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 816856A3 | 燃油接头总成-塑料 | CONNECTOR ASSEMBLY Fuel - Plastic | 1 |
| 2 | 69067 | 燃油连接器螺钉(.250-20 x 1.375) | SCREW (.250-20 x 1.375) FUEL CONNECTOR | 1 |
| 3 | 812782 | 密封件 | SEAL | 1 |
| 4 | 9912976 | 油管 | TUBING | 1 |
| 4 | 8M0108349 | 软管 (70英寸散装) | HOSE (70 Inches Bulk) | 1 |
| 5 | 816311 | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 5 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 6 | 814964 | 接头 | FITTING | 1 |
| 7 | 19688 | 弯头接头 | FITTING (ELBOW) | 1 |
| 8 | 4301625 | 油管(8.00英寸) | TUBING (8.00 Inches) | 1 |
| 8 | 82381335 | 油管(15.00英寸 散装) | TUBING (15.00 Inches Bulk) | 1 |
| 9 | 99127109 | 管路(57.00英寸 散装) | LINE (57.00 Inches Bulk) | 4 |
| 9 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 4 |
| 10 | 816296 | 燃油滤清器 | FILTER Fuel | 1 |
| 10 | 816296Q03 | 燃油滤清器@3 | FILTER-FUEL @3 | 1 |
| 11 | 67751 | 衬垫 | GASKET | 3 |
| 12 | 27037 | 双头螺栓(.250-28×1.125) | STUD (.250-28 x 1.125) | 6 |
| 12 | 270372 | 双头螺栓(.250-28×1.125) | STUD (.250-28 x 1.125) | 6 |
| 13 | 55098 | J型卡扣 | J CLIP | 1 |
| 13 | 8M0024808 | J型夹 | J-CLIP | 1 |
| 14 | 55715 | 螺钉(.250-20×0.880) | SCREW (.250-20 x .880) | 6 |
| 15 | 26992 | 锁紧垫圈(.250)不锈钢 | LOCKWASHER (.250) Stainless Steel | 6 |
| 16 | 29598 | 不锈钢螺母(.250-28) | NUT (.250-28) Stainless Steel | 6 |
| 17 | 9912878 | 软管 (.187) (26.00英寸散装) | HOSE (.187) (26.00 Inches Bulk) | 3 |
| 18 | 99130122 | 油管(20.00英尺 散装) | TUBING (20.00 Feet Bulk) | 1 |
| 18 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 19 | 42859A2 | 加浓阀总成 | VALVE ASSEMBLY Enrichner | 1 |
| 20 | 633001 | 卡箍 | CLAMP | 1 |
| 21 | 73286 | 螺钉(0.250-20×0.500)不锈钢 | SCREW (.250-20 x .500) Stainless Steel | 1 |
| 22 | 9912688 | 管材 (36.00英寸散装) | TUBING (36.00 Inches Bulk) | 2 |
| 23 | 45915 | 端子排 | TERMINAL BLOCK | AR |
| 24 | 48408 | 螺钉(#10-16 x 0.500) | SCREW (#10-16 x .500) | AR |
| 24 | 38055 | 螺钉(0.190-32x0.620) | SCREW (.190-32 x .620) | AR |
| 24 | 62568 | 螺钉（#10-16 x 0.375） | SCREW (#10-16 x .375) | AR |
| 24 | 69079 | 螺钉 (#10-16 x .440) | SCREW (#10-16 x .440) | AR |
| - | 815791A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815809A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| - | 815810A90 | 衬垫套件 | GASKET SET | 1 |
| - | 815791A92 | 发动机垫片组 | GASKET SET Engine | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 858576T03 | 驱动轴壳体总成 | HOUSING ASSEMBLY Driveshaft | 1 |
| 2 | 903501 | 双头螺柱(M10×100) | STUD (M10 x 100) | 1 |
| 2 | 9035015 | 双头螺柱(M10×227) | STUD (M10 x 227) | 1 |
| 3 | 9035012 | 双头螺柱(M10×63) | STUD (M10 x 63) | 4 |
| 3 | 9035016 | 双头螺柱(M10×190) | STUD (M10 x 190) | 4 |
| 3 | 8M0034462 | 双头螺柱(M10×190) | STUD (M10 x 190) | 4 |
| 4 | 856774 | 垫圈(0.406×0.750×0.105)不锈钢 | WASHER (.406 x .750 x .105) Stainless Steel | 5 |
| 4 | 8M0214963 | 垫圈 | WASHER | 5 |
| 5 | 40140 | 螺母(M10) | NUT (M10) | 5 |
| 6 | 85822A15 | 速度计传感器总成 | PICKUP ASSEMBLY Speedometer | 1 |
| 7 | 43335 | 90度接头(.125-27)尼龙 | CONNECTOR 90 Degree (.125-27) Nylon | 1 |
| 7 | 433351 | 90度接头-带防振密封 | CONNECTOR 90 Degree - With Vibraseal | 1 |
| 8 | 85822 | 直通接头 | CONNECTOR Straight | 1 |
| 8 | 85822T | 直通接头 | CONNECTOR Straight | 1 |
| 9 | 44343T1 | 支架 | MOUNT | 2 |
| 10 | 42973 | 螺栓(M12×154) | BOLT (M12 x 154) | 2 |
| 10 | 898835001 | 螺钉(M12 x 154) | SCREW (M12 x 154) | 2 |
| 11 | 30119 | 垫圈(外径0.875英寸) | WASHER (.875 Inch Outside Diameter) | 2 |
| 12 | 43528 | 螺母(M12) | NUT (M12) | 2 |
| 12 | 8M0204662 | 螺母 | NUT | 2 |
| 13 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 2 |
| 14 | 41508 | 螺钉(0.250-20×0.500)不锈钢 | SCREW (.250-20 x .500) Stainless Steel | 1 |
| 15 | 858916T | 卡箍 | CLAMP | 2 |
| 16 | 4010725 | 螺钉 (M8 x 25) | SCREW (M8 x 25) | 4 |
| 17 | 858745 | 盖帽 | CAP | 4 |
| 17 | 8M0142713 | 支撑盖帽 | CAP Chap Support | 4 |
| 18 | 859550 | 衬套 | BUSHING | 1 |
| 19 | 24873 | 定位销 | PIN Alignment | 1 |
| 20 | 855622 | 接头 | FITTING | 1 |
| 21 | 12092A3 | 隔套套件 | SPACER KIT | 1 |
| 22 | 43043 | 定位销-带孔(0.375×0.625) | PIN Dowel - With Hole (.375 x .625) | 1 |
| 22 | 8M0084244 | 定位销 0.375x0.620 | PIN Dowel, .375 x .620 | 1 |
| 22 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 1 |
| 23 | 813745 | 隔套 | SPACER | 1 |
| 24 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 2 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 99659A21 | 歧管总成 (黑色) | MANIFOLD ASSEMBLY (BLACK) | 1 |
| 1 | 99659A22 | 歧管总成 (灰色) | MANIFOLD ASSEMBLY (GRAY) | 1 |
| 2 | 99616 | 管塞歧管 | PIPE PLUG MANIFOLD | 11 |
| 2 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 11 |
| 3 | 41493A7 | 配平油缸总成 (黑色) | TRIM CYLINDER ASSEMBLY (BLACK) | 1 |
| 3 | 41493A4 | 配平油缸总成 (灰色) | TRIM CYLINDER ASSEMBLY (GRAY) | 1 |
| 3 | 41493A7 | 升降油缸总成 | TRIM CYLINDER ASSEMBLY | 1 |
| 3A | 811600 | 导向套件 | GUIDE KIT | 1 |
| 4 | 41492A1 | 导向器总成 | GUIDE ASSEMBLY | 1 |
| 5 | 41478A1 | 维修套件 | REPAIR KIT | 1 |
| 6 | 41482A2 | 止回阀套件 | CHECK VALVE KIT | 1 |
| 7 | 99638A1 | 导向总成装饰杆 | GUIDE ASSEMBLY TRIM ROD | 2 |
| 7 | 8M0021648 | 端盖总成 | END CAP ASSEMBLY | 2 |
| 8 | 43397A6 | PISTON/ROD ASSEMBLY Power Trim PORT | 1 | |
| 8 | 878413A1 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 9 | 12184A1 | 升降过滤器总成 | TRIM FILTER ASSEMBLY | 1 |
| 10 | 43398A3 | PISTON/ROD ASSEMBLY Power Trim STARBOARD | 1 | |
| 10 | 878414T01 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 11 | 13794 | 开槽销 微调油缸(上部-无头) | PIN Groove TRIM CYLINDER (UPPER - W/O HEAD) | 1 |
| 11 | 821539 | 三叶销 | PIN Trilobe | 1 |
| 11 | 19603 | 开槽销(带头) | PIN Groove (W/ HEAD) | 1 |
| 11 | 821539 | 三叶销 | PIN Trilobe | 1 |
| 12 | 812843A1 | 阀门总成 | VALVE ASSEMBLY | 1 |
| 12 | 893929A01 | 安全阀套件 | VALVE KIT Relief | 1 |
| 12A | 812844 | E型卡环 | E RING | 1 |
| 12A | 815949001 | E形环 | E-RING | 1 |
| 13 | 4000327 | 螺钉(M6x14)-盖板 | SCREW (M6 x 14) COVER | 4 |
| 14 | 43450 | 盖板螺丝垫圈 | WASHER COVER SCREW | 4 |
| 14 | 4002315 | 垫圈(6.60x12.5x1.5mm-不锈钢) | WASHER (6.60 X 12.5 X 1.5 mm -SS) | 4 |
| 15 | 99642 | 歧管盖 | COVER MANIFOLD | 1 |
| 16 | 48462A2 | O型圈套件 | O-RING KIT | 1 |
| 16 | 48462A4 | O型圈套件 | O RING KIT | 1 |
| 17 | 99609A1 | 塞子总成 | PLUG ASSEMBLY | 1 |
| 18 | 99641A1 | 轴总成 | SHAFT ASSEMBLY | 1 |
| 18 | 99641A02 | 轴总成 | SHAFT ASSY | 1 |
| 19 | 99616 | 轴管塞 | PIPE PLUG SHAFT | 2 |
| 19 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 2 |
| 20 | 4008820 | 螺钉(M6x20)-泵与马达 | SCREW (M6 x 20) PUMP AND MOTOR | 2 |
| 21 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 2 |
| 22 | 99186T | 泵与电机总成 | PUMP AND MOTOR | 1 |
| 22 | 826729A10 | ORD 8M0143217 | ORD 8M0143217 | 1 |
| 23 | 99625 | SHAFT UPPER | 1 | |
| 23 | 99625002 | 轴 | SHAFT | 1 |
| 24 | 43396A2 | 阳极总成 | ANODE ASSEMBLY | 1 |
| 24 | 818298Q1 | 阳极套件 | ANODE KIT | 1 |
| 25 | 4000330 | 螺钉(M6 x 25)阳极 | SCREW (M6 x 25) ANODE | 2 |
| 25 | 8M0204707 | 不锈钢六角大帽螺钉(M6x25) | SCREW M6 x 25 HX HD CAP SS | 2 |
| 26 | 29245 | 垫圈(0.281x0.500x0.060)-不锈钢阳极螺钉 | WASHER (.281 x .500 x .060) Stainless Steel ANODE SCREW | 2 |
| 26 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 27 | 996301 | 撞板-升降轴 | STRIKER PLATE TRIM SHAFT | 2 |
| 27 | 8M0045383 | 冲击板 | STRIKER PLATE | 2 |
| 28 | 58643 | 锁紧垫圈 (.375) | LOCKWASHER (.375) | 2 |
| 29 | 46335 | 螺母 (.375-24) | NUT (.375-24) | 2 |
| 30 | 814609A1 | 线束总成-动力升降控制 | HARNESS ASSEMBLY Control POWER TRIM | 1 |
| 31 | 88808A22 | 电缆总成(6-3/8"-红色) | CABLE ASSEMBLY (6-3/8" - RED) | 1 |
| 31 | 88808A23 | 电缆总成(24"-红色) | CABLE ASSEMBLY (24" - RED) | 1 |
| 31 | 87379A14 | 线束总成(2.750英寸)(红色) | WIRE ASSEMBLY (2.750 Inches) (RED) | 1 |
| 32 | 22875 | CLIP PUMP WIRE | 2 | |
| 33 | 69205 | C形垫圈线夹螺钉 | C WASHER CLIP SCREW | 2 |
| 33 | 8M0084613 | C形垫圈 | C-WASHER | 2 |
| 34 | 69079 | 螺钉(#10-16x0.440)-夹子到艉板支架 | SCREW (#10-16 x .440) CLIP TO TRANSOM BRACKET | 2 |
| 35 | 44431 | 沟槽销-升降油缸(下) | PIN Groove TRIM CYLINDER (LOWER) | 1 |
| 35 | 878267 | 销 | PIN | 1 |
| 36 | 4000377 | SCREW (M10 x 30) MANIFOLD | 6 | |
| 37 | 400258 | 锁紧垫圈(M10)-不锈钢歧管螺钉 | LOCKWASHER (M10) Stainless Steel MANIFOLD SCREW | 6 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 43429 | 点火板 | PLATE IGNITION | 1 |
| 2 | 7778A6 | 开关盒总成 | SWITCHBOX ASSEMBLY | 2 |
| 2 | 7778A12 | 开关盒总成 | SWITCHBOX ASSEMBLY | 2 |
| 3 | 13669 | 开关盒至点火板螺钉(#12-24 x 2.00) | SCREW (#12-24 x 2.00) SWITCH BOX TO IGNITION PLATE | 2 |
| 4 | 94304 | 开关盒螺钉垫片(早期型号) | SPACER SWITCH BOX SCREW (EARLY MODELS) | 2 |
| 5 | 94453 | 开关盒螺钉衬套 | BUSHING SWITCH BOX SCREW | 2 |
| 6 | 62310A2 | 开关盒间电缆总成 | CABLE ASSEMBLY SWITCH BOX TO SWITCH BOX | 1 |
| 7 | 45076 | 螺母(#10-32)黄铜开关盒端子 | NUT (#10-32) Brass SWITCH BOX TERMINAL | 20 |
| 8 | 60871A10 | 线束总成-开关盒 | WIRE ASSEMBLY SWITCH BOX | 2 |
| 9 | 62568 | 螺丝(#10-16 x 0.375)导线固定 | SCREW (#10-16 x .375) WIRE ATTACHING | 2 |
| 10 | 38055 | 电缆至点火板螺钉(.190-32 x .620) | SCREW (.190-32 x .620) CABLE TO IGNITION PLATE | 1 |
| 11 | 65999A3 | 线缆总成(黑色) | CABLE ASSEMBLY Black | 1 |
| 12 | 69092 | 点火板螺钉(1.25) | SCREW (1.25) IGNITION PLATE | 3 |
| 12 | 60411 | 螺钉(.312-18 x 1.250) | SCREW (.312-18 x 1.250) | 3 |
| 13 | 26993 | 锁紧垫圈(.312)点火板螺钉 | LOCKWASHER (.312) IGNITION PLATE SCREW | 3 |
| 13 | 8M0204647 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 3 |
| 14 | 36042 | 垫圈 点火板螺钉 | WASHER IGNITION PLATE SCREW | 6 |
| 15 | 67264 | 橡胶垫圈 点火板螺钉 | WASHER (Rubber) IGNITION PLATE SCREW | 6 |
| 16 | 67268 | 衬套 点火板螺钉 | BUSHING IGNITION PLATE SCREW | 3 |
| 17 | 62351A1 | 整流器 | RECTIFIER | 1 |
| 17 | 8M0058226 | 整流器 | RECTIFIER | 1 |
| 18 | 38055 | 螺钉(.190-32 x .620)水银开关至点火板 | SCREW (.190-32 x .620) MERCURY SWITCH TO IGNITION PLATE | 2 |
| 19 | 45076 | 螺母(#10-32)黄铜整流器端子 | NUT (#10-32) Brass RECTIFIER TERMINALS | 3 |
| 20 | 33386A3 | 开关总成 | SWITCH ASSEMLBY | 1 |
| 21 | 38055 | 螺钉(.190-32 x .620)水银开关至点火板 | SCREW (.190-32 x .620) MERCURY SWITCH TO IGNITION PLATE | 1 |
| 22 | 45076 | 螺母 (#10-32) 黄铜水银开关端子 | NUT (#10-32) Brass MERCURY SWITCH TERMINAL | 1 |
| 23 | 87926 | 螺钉(#10-32 x .500)导线固定 | SCREW (#10-32 x .500) LEAD ATTACHING | 1 |
| 24 | 88439A14 | 电缆总成 电池正极 | CABLE ASSEMBLY Battery - Positive POSITIVE | 1 |
| 24 | 88439A2 | 电缆总成 电池负极 | CABLE ASSEMBLY Battery - Negative NEGATIVE | 1 |
| 25 | 96220A4 | 发动机线束总成 | HARNESS ASSEMBLY ENGINE | 1 |
| 26 | 79091 | 保险丝20安培 | FUSE 20 Ampere | 1 |
| 26 | 8M0207796 | 保险丝20安培 | FUSE 20 AMP | 1 |
| 27 | 95084A2 | 电缆总成-保险丝 | CABLE ASSEMBLY FUSE | 1 |
| 28 | 73498 | 线束与电缆夹 | CLAMP HARNESS AND CABLES | 3 |
| 28 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | 3 |
| 29 | 96054 | 启动电磁阀总成 | SOLENOID ASSEMBLY Starter | 1 |
| 29 | 8M0185149 | 启动电磁阀 | SOLENOID START | 1 |
| 30 | 26419 | 螺母（#8-32）黄铜电磁阀端子 | NUT (#8-32) Brass SOLENOID TERMINALS | 2 |
| 31 | 26992 | 锁紧垫圈(.250)不锈钢 电磁阀端子(1/4") | LOCKWASHER (.250) Stainless Steel SOLENOID TERMINALS (1/4") | 2 |
| 32 | 94330 | 螺母（.250-20）黄铜电磁阀端子 | NUT (.250-20) Brass SOLENOID TERMINALS | 2 |
| 29 | 15857 | 启动电磁阀 | SOLENOID Starter | 1 |
| 29 | 853654A1 | 电磁阀 | SOLENOID | 1 |
| 30 | 45076 | 螺母(#10-32)黄铜 电磁阀端子 | NUT (#10-32) Brass SOLENOID TERMINALS | 2 |
| 31 | 53166 | 锁紧垫圈（.312）电磁阀端子 | LOCKWASHER (.312) SOLENOID TERMINALS | 2 |
| 32 | 68292 | 螺母（.312-18）电磁阀端子 | NUT (.312-18) SOLENOID TERMINALS | 2 |
| 32 | 8M0204668 | 螺母(.312-18) | NUT (.312-18) | 2 |
| 33 | 31716 | 螺钉(.250-20 x .620)电磁阀至点火板 | SCREW (.250-20 x .620) SOLENOID TO IGNITION PLATE | 2 |
| 34 | 26992 | 锁紧垫圈(.250)不锈钢 电磁阀至点火板螺钉 | LOCKWASHER (.250) Stainless Steel SOLENOID TO IGNITION PLATE SCREW | 2 |
| 35 | 65999A2 | 电缆总成 黑色 上部安装 | CABLE ASSEMBLY Black UPPER MOUNT | 1 |
| 36 | 97861 | 电磁阀绝缘体 | INSULATOR SOLENOID | 1 |
| 37 | 88825A7 | 电压调节器 | VOLTAGE REGUALTOR | 1 |
| 38 | 48409 | 螺钉(#10-16 x .625)不锈钢 电压调节器 | SCREW (#10-16 x .625) Stainless Steel VOLTAGE REGULATOR | 1 |
| 39 | 13397A1 | 线束总成 | HARNESS ASSEMBLY | 1 |
| 40 | 45076 | 螺母(#10-32)黄铜 电压调节器 | NUT (#10-32) Brass VOLTAGE REGULATOR | 2 |
| 41 | 134731 | 保险丝座 | HOLDER Fuse | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 99186T | 泵与电机总成 | PUMP AND MOTOR | 1 |
| 1 | 12659 | 机架与磁场套件 | FRAME AND FIELD KIT | 1 |
| 1 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 2 | 12665 | 电刷弹簧套件 | SPRING KIT Brush | 1 |
| 3 | 13506 | 电刷卡套件 | BRUSH CARD KIT | 1 |
| 3 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 4 | 12662 | 泵与端架套件 | PUMP AND END FRAME KIT | 1 |
| 4 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 5 | 126631 | 泵密封套件 | SEAL KIT Pump | 1 |
| 6 | 12660 | 端架套件 | END FRAME KIT | 1 |
| 6 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 7 | 12661 | 电枢套件 | ARMATURE KIT | 1 |
| 7 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 8 | 12664 | 贯穿螺栓套件 | THRU BOLT KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9242A10 | 化油器(上) | CARBURETOR (TOP) | 1 |
| 1 | 9242A11 | 化油器(中) | CARBURETOR (CENTER) | 1 |
| 1 | 9242A12 | 化油器(下) | CARBURETOR (BOTTOM) | 1 |
| 3 | NSS | NOT SOLD SEPARATE GASKET, COVER PLATE | 3 | |
| 4 | 6032 | 盖板 | PLATE COVER | 3 |
| 5 | NSS | 不单独销售螺丝,盖板 | NOT SOLD SEPARATE SCREW, COVER PLATE | 15 |
| 6 | 7823 | 燃油杯(顶部) | BOWL Fuel (TOP) | 1 |
| 6 | 7822 | 燃油杯(中部/底部) | BOWL Fuel (CENTER/BOTTOM) | 2 |
| 7 | NSS | 不单独销售螺丝,燃油碗 | NOT SOLD SEPARATE SCREW, FUEL BOWL | 18 |
| 8 | 6025 | 主量孔塞 | PLUG MAIN JET | 6 |
| 9 | NSS | 主量孔垫片(不单独销售) | NOT SOLD SEPARATE GASKET, MAIN JET | 6 |
| 10 | 4216 | 主量孔 (.064) | JET (.064) MAIN FUEL | 4 |
| 10 | 4215 | 燃油主量孔(.066) | JET Main Fuel (.066) | 2 |
| 11 | NSS | 不单独销售螺丝,浮子销 | NOT SOLD SEPARATE SCREW, FLOAT PIN | 6 |
| 12 | NSS | 不单独出售 衬垫、进油针阀及阀座组件 | NOT SOLD SEPARATE GASKET, INLET NEEDLE AND SEAT | 6 |
| 13 | 7824 | 进油针阀总成 | NEEDLE/SEAT ASSEMBLY Inlet | 6 |
| 14 | NSS | 不单独销售垫片,喷嘴座 | NOT SOLD SEPARATE GASKET, NOZZLE BOSS | 6 |
| 15 | 9267 | 浮子 | FLOAT | 6 |
| 16 | NSS | 不单独销售销,浮子杆 | NOT SOLD SEPARATE PIN, FLOAT LEVER | 6 |
| 17 | NSS | 燃油碗垫片(不单独销售) | NOT SOLD SEPARATE GASKET, FUEL BOWL | 3 |
| 18 | 4541 | 怠速空气量孔螺钉 | SCREW IDLE AIR BLEED JET | 6 |
| 19 | NSS | 不单独销售垫片,泄流量孔塞 | NOT SOLD SEPARATE GASKET, BLEED JET PLUG | 6 |
| 20 | 6030 | 怠速空气量孔(.070) | JET (.070) IDLE AIR BLEED | 6 |
| 21 | 6027 | 节气门杠杆螺钉 | SCREW THROTTLE LEVER | 3 |
| 22 | 37752 | 油门标识贴 | DECAL THROTTLE | 3 |
| 23 | NSS | NOT SOLD SEPARATE SPRING, THROTTLE RETURN | 3 | |
| 24 | 6031 | 节气门杠杆垫片 | SPACER THROTTLE LEVER | 3 |
| 25 | 6022 | 节流阀轴 | SHAFT THROTTLE | 3 |
| 26 | NSS | 节流阀轴环/挡圈（不单独销售） | NOT SOLD SEPARATE RING, RETAINER - THROTTLE SHAFT | 3 |
| 27 | 9416 | 油门阀 | VALVE Throttle | 6 |
| 28 | NSS | NOT SOLD SEPARATE SCREW, THROTTLE VALVE | 12 | |
| - | 6452 | 衬垫套件 | GASKET KIT | 1 |
| - | 8506 | 化油器维修套件 | REPAIR KIT Carburetor | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 67245T | 上罩安装支架 | BRACKET COWL MOUNTING - UPPER | 1 |
| 2 | 67272 | 罩壳安装支架衬套 | GROMMET COWL MOUNTING BRACKET | 2 |
| 3 | 90435 | 罩壳安装支架(黑/灰) | MOUNT COWL MOUNTING BRACKET BLACK/GRAY | 2 |
| 4 | 29245 | 安装垫圈(0.281×0.500×0.060)不锈钢 | WASHER (.281 x .500 x .060) Stainless Steel MOUNT ATTACHING | 4 |
| 4 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 4 |
| 5 | 35888 | 安装螺母(0.250-28)不锈钢 | NUT (.250-28) Stainless Steel MOUNT ATTACHING | 4 |
| 6 | 87076A4 | 怠速控制总成 | IDLE SPEED CONTROL ASSEMBLY | 1 |
| 7 | 799831 | 阻风板 | PLATE CHOKE | 1 |
| 8 | 67274 | 阻风板至化油器衬垫 | GASKET CHOKE PLATE TO CARBURETOR | 1 |
| 8 | 672741 | 衬垫 | GASKET | 1 |
| 9 | 68000 | 螺丝(.250-28 x 1.00)阻风板至化油器 | SCREW (.250-28 x 1.00) CHOKE PLATE TO CARBURETOR | 6 |
| 10 | 20583 | 阻风板螺丝垫圈 | WASHER CHOKE PLATE SCREW | 6 |
| 11 | 67275 | 盖衬垫 | GASKET COVER | 1 |
| 11 | 672751 | 衬垫 | GASKET | 1 |
| 12 | 67246T | 进气消音器盖 | COVER INDUCTION SILENCER | 1 |
| 13 | 30720 | 螺丝(.250-20 x 2.25)盖至阻风板 | SCREW (.250-20 x 2.25) COVER TO CHOKE PLATE | 2 |
| 14 | 29245 | 垫圈(.281 x .500 x .060)不锈钢盖螺丝 | WASHER (.281 x .500 x .060) Stainless Steel COVER SCREW | 2 |
| 14 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 15 | 26992 | 锁紧垫圈(.250)不锈钢盖螺丝 | LOCKWASHER (.250) Stainless Steel COVER SCREW | 2 |
| 16 | 90585 | 进气消音器盖塞 | PLUG INDUCTION SILENCER COVER | 1 |
| 17 | 67760 | 油门连杆 | LINK Throttle | 1 |
| 18 | 67759 | 节气门杆(上) | LEVER Throttle UPPER | 1 |
| 19 | 41049 | 节气门杆(中) | LEVER Throttle CENTER | 1 |
| 20 | 67749 | 下节流阀杆 | LEVER Throttle LOWER | 1 |
| 21 | 15124 | 油门杆至油门连杆螺钉(#10-32×0.750) | SCREW (#10-32 x .750) THROTTLE LEVERS TO THROTTLE LINK | 3 |
| 22 | 26996 | 锁紧垫圈(#10)不锈钢节气门杆螺丝 | LOCKWASHER (#10) Stainless Steel THROTTLE LEVERS SCREW | 3 |
| 23 | 56681 | 垫圈(.203 x .500 x .032)节气门杆螺丝 | WASHER (.203 x .500 x .032) THROTTLE LEVERS SCREW | 3 |
| 23 | 8M0204666 | 垫圈 (.203 x .500 x .032) | WASHER (.203 x .500 x .032) | 3 |
| 24 | 67297 | U型销节气门杆至节气门连杆 | PIN Clevis THROTTLE LEVERS TO THROTTLE LINK | 3 |
| 25 | 89302 | 垫圈(.203 x .406 x .040)U型销 | WASHER (.203 x .406 x .040) CLEVIS PIN | 3 |
| 26 | 26953 | 开口销U型销 | COTTER PIN CLEVIS PIN | 3 |
| 27 | 67748 | 下节气门杆滚轮 | ROLLER LOWER THROTTLE LEVER | 1 |
| 28 | 69020 | 螺丝(#10-32 x .875)怠速控制 | SCREW (#10-32 x .875) IDLE SPEED CONTROL | 2 |
| 28 | 690201 | 螺钉(#10-32 x .875) | SCREW (#10-32 x .875) | 2 |
| 29 | 38833 | 怠速调节螺钉垫片 | WASHER IDLE SPEED CONTROL SCREW | 2 |
| - | 90484A88 | 衬垫套件 | GASKET SET |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9744A2 | 下罩总成 | BOTTOM COWL ASSEMBLY | 1 |
| 1 | 9744A16 | 下罩总成 | BOTTOM COWL ASSEMBLY | 1 |
| 1 | 9744A3 | 下罩总成 | BOTTOM COWL ASSEMBLY | 1 |
| 1 | 9744A16 | 下罩总成 | BOTTOM COWL ASSEMBLY | 1 |
| 2 | 9745A1 | 下罩总成 | BOTTOM COWL ASSEMBLY | 1 |
| 2 | 9745A2 | 下罩总成 | BOTTOM COWL ASSEMBLY | 1 |
| 3 | 18701A1 | SEAL KIT Bottom Cowls | 1 | |
| 4 | 18699 | 螺钉（0.250-20 x 1.320）（机罩右舷） | SCREW (.250-20 x 1.320) Cowl (Starboard) | 4 |
| 5 | 18872A1 | 盖总成 | COVER ASSEMBLY | 1 |
| 5 | 18872A2 | 盖总成 | COVER ASSEMBLY | 1 |
| 5 | 18872A1 | 盖总成 | COVER ASSEMBLY | 1 |
| 6 | 813692 | 锁紧螺母 | LOCKNUT | 2 |
| 6 | 8136921 | 锁紧螺母 | LOCKNUT | 2 |
| 7 | 90077 | 扎带 | TIE STRAP | AR |
| 7 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 8 | 18727 | 杆 | ROD | 1 |
| 9 | 65830 | 尼龙衬套 | NYLINER | 6 |
| 10 | 19666 | 衬套 | BUSHING | 1 |
| 11 | 99611 | 波形垫圈 | WAVE WASHER | 3 |
| 12 | 69057 | 垫片(.281 x .734 x .063) | WASHER (.281 x .734 x .063) | 3 |
| 13 | 18192 | 螺钉(0.250-20x0.620) | SCREW (.250-20 x .620) | 1 |
| 14 | 19648A3 | 手柄总成 | HANDLE ASSEMBLY | 1 |
| 14 | 19648A2 | 左舷手柄总成 | HANDLE ASSY PORT | 1 |
| 14 | 19648A4 | 手柄总成 | HANDLE ASSEMBLY | 1 |
| 14 | 19648A2 | 左舷手柄总成 | HANDLE ASSY PORT | 1 |
| 15 | 19647A3 | 手柄总成 | HANDLE ASSEMBLY | 1 |
| 15 | 19647A4 | 手柄总成 | HANDLE ASSEMBLY | 1 |
| 15 | 19647A3 | 手柄总成 | HANDLE ASSEMBLY | 1 |
| 16 | 19370 | PAWL (Port) | 1 | |
| 17 | 19369 | PAWL (Starboard) | 1 | |
| 18 | 90047 | 螺钉 | SCREW | 2 |
| 19 | 19749 | CLAMP Upper | 1 | |
| 20 | 197481 | 卡箍-下部 | CLAMP Lower | 1 |
| 21 | 92799 | 螺钉(#10-16x1.12) | SCREW (#10-16 x 1.12) | 2 |
| 22 | 16636A1 | 升降线束总成 | HARNESS ASSEMBLY Trim | 1 |
| 23 | 72202 | 螺钉(#10-32 x 1.25) | SCREW (#10-32 x 1.25) | 2 |
| 24 | 56681 | 垫圈 (.203 x .500 x .032) | WASHER (.203 x .500 x .032) | 2 |
| 24 | 8M0204666 | 垫圈 (.203 x .500 x .032) | WASHER (.203 x .500 x .032) | 2 |
| 25 | 29488 | 螺母 (#10-32) | NUT (#10-32) | 2 |
| 25 | 8M0204718 | 螺母 | NUT | 2 |
| 26 | 16639A1 | 线束总成 | HARNESS ASSEMBLY | 1 |
| 27 | 79091 | 保险丝20安培 | FUSE 20 Ampere | 1 |
| 27 | 8M0207796 | 保险丝20安培 | FUSE 20 AMP | 1 |
| 28 | 95084A2 | 保险丝线束总成 | CABLE ASSEMBLY Fuse | 1 |
| 29 | 813613 | 示踪管接头 | FITTING Telltale | 1 |
| 30 | 90824 | TEE Telltale | 1 | |
| 30 | 90824001 | 三通接头 | TEE FITTING | 1 |
| 31 | 99127109 | LINE (57.00 Inches Bulk) Telltale | 1 | |
| 31 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 32 | 8130761 | 前手柄总成 | FRONT HANDLE ASSEMBLY | 1 |
| 32 | 8130762 | 前手柄总成 | FRONT HANDLE ASSEMBLY | 1 |
| 33 | 813925 | 手柄锁 | HANDLE LOCK | 1 |
| 33 | 813076A2 | 手柄套件 | HANDLE KIT | 1 |
| 34 | 813926 | 手柄 | HANDLE | 1 |
| 34 | 813076A2 | 手柄套件 | HANDLE KIT | 1 |
| 35 | 8139291 | 弹簧 | SPRING | 1 |
| 35 | 813076A2 | 手柄套件 | HANDLE KIT | 1 |
| 36 | 69079 | 螺钉 (#10-16 x .440) | SCREW (#10-16 x .440) | 2 |
| 37 | 813930 | 锁止销 | PIN Lock | 1 |
| 37 | 815296 | 锁止销 | PIN Lock | 1 |
| 38 | 26992 | 锁紧垫圈(.250)不锈钢 | LOCKWASHER (.250) Stainless Steel | 2 |
| - | 813096A1 | 后锁扣套件 | REAR LATCH KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9671A1 | 化油器(上) | CARBURETOR (TOP) | 1 |
| 1 | 9671A2 | 化油器(中) | CARBURETOR (CENTER) | 1 |
| 1 | 9671A3 | 化油器(下) | CARBURETOR (BOTTOM) | 1 |
| 2 | 3796 | 浮子室通气量孔(0.076) | JET (.076) BOWL VENT | 3 |
| 3 | NSS | NOT SOLD SEPARATE Gasket-Cover Plate | 3 | |
| 4 | 6032 | 盖板 | PLATE COVER | 3 |
| 5 | NSS | 盖板螺钉(不单独销售) | NOT SOLD SEPARATE Screw-Cover Plate | 15 |
| 6 | 7823 | 燃油杯(顶部) | BOWL Fuel (TOP) | 1 |
| 6 | 7822 | 燃油杯(中部/底部) | BOWL Fuel (CENTER/BOTTOM) | 2 |
| 7 | NSS | 不单独销售 燃油杯螺钉 | NOT SOLD SEPARATE Screw-Fuel Bowl | 18 |
| 8 | 6025 | 主量孔塞 | PLUG MAIN JET | 6 |
| 9 | NSS | 不单独出售主喷油嘴固定垫片 | NOT SOLD SEPARATE Gasket-Main Jet Retainer | 6 |
| 10 | 3794 | 主量孔 (.074) | JET (.074) MAIN FUEL | 6 |
| 11 | NSS | 不单独出售 浮子销螺钉 | NOT SOLD SEPARATE Screw-Float Pin | 6 |
| 12 | NSS | NOT SOLD SEPARATE Gasket-Inlet Needle and Seat | 6 | |
| 13 | 7824 | 进油针阀总成 | NEEDLE/SEAT ASSEMBLY Inlet | 6 |
| 14 | NSS | 喷嘴座垫片(不单独销售) | NOT SOLD SEPARATE Gasket-Nozzle Boss | 6 |
| 15 | 9267 | 浮子 | FLOAT | 6 |
| 16 | NSS | 浮子杆销(不单独销售) | NOT SOLD SEPARATE Pin-Float Lever | 6 |
| 17 | NSS | NOT SOLD SEPARATE Gasket-Fuel Bowl | 3 | |
| 18 | 4541 | 怠速空气量孔螺钉 | SCREW IDLE AIR BLEED JET | 6 |
| 19 | NSS | 泄放量孔塞垫片(不单独销售) | NOT SOLD SEPARATE Gasket-Bleed Jet Plug | 6 |
| 20 | 6359 | 怠速空气量孔（0.052） | JET (.052) IDLE AIR BLEED | 6 |
| 21 | 6027 | 节气门杠杆螺钉 | SCREW THROTTLE LEVER | 3 |
| 22 | 67752 | 节流阀杆 | LEVER THROTTLE | 3 |
| 23 | NSS | NOT SOLD SEPARATE Spring-Throttle Return | 3 | |
| 24 | 6031 | 节气门杠杆垫片 | SPACER THROTTLE LEVER | 3 |
| 25 | 6022 | 节流阀轴 | SHAFT THROTTLE | 3 |
| 26 | NSS | 节气门轴挡圈(不单独销售) | NOT SOLD SEPARATE Ring-Retainer-Throttle Shaft | 3 |
| 27 | 6023 | 油门阀 | VALVE Throttle | 6 |
| 28 | NSS | NOT SOLD SEPARATE Screw-Throttle Valve | 12 | |
| - | 6452 | 衬垫套件 | GASKET KIT | 1 |
| -- | 8506 | 化油器维修套件 | REPAIR KIT Carburetor | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 67245T | 机罩支架（上部） | BRACKET COWL MOUNTING (UPPER) | 1 |
| 2 | 67272 | 罩壳安装支架衬套 | GROMMET COWL MOUNTING BRACKET | 2 |
| 3 | 90435 | 罩壳安装支架座 | MOUNT COWL MOUNTING BRACKET | 2 |
| 4 | 29245 | 安装垫圈(0.281×0.500×0.060)不锈钢 | WASHER (.281 x .500 x .060) Stainless Steel MOUNT ATTACHING | 4 |
| 4 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 4 |
| 5 | 35888 | 安装螺母(0.250-28)不锈钢 | NUT (.250-28) Stainless Steel MOUNT ATTACHING | 4 |
| 7 | 799831 | 阻风板 | PLATE CHOKE | 1 |
| 8 | 67274 | 阻风板至化油器衬垫 | GASKET CHOKE PLATE TO CARBURETOR | 1 |
| 8 | 672741 | 衬垫 | GASKET | 1 |
| 9 | 68000 | 螺丝(.250-28 x 1.00)阻风板至化油器 | SCREW (.250-28 x 1.00) CHOKE PLATE TO CARBURETOR | 6 |
| 10 | 20583 | 阻风板螺丝垫圈 | WASHER CHOKE PLATE SCREW | 6 |
| 11 | 67275 | 盖衬垫 | GASKET COVER | 1 |
| 11 | 672751 | 衬垫 | GASKET | 1 |
| 12 | 67246T | 进气消音器盖 | COVER INDUCTION SILENCER | 1 |
| 13 | 30720 | 螺丝(.250-20 x 2.25)盖至阻风板 | SCREW (.250-20 x 2.25) COVER TO CHOKE PLATE | 2 |
| 14 | 29245 | 垫圈(.281 x .500 x .060)不锈钢盖螺丝 | WASHER (.281 x .500 x .060) Stainless Steel COVER SCREW | 2 |
| 14 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 15 | 26992 | 锁紧垫圈(.250)不锈钢盖螺丝 | LOCKWASHER (.250) Stainless Steel COVER SCREW | 2 |
| 16 | 67760 | 油门连杆 | LINK Throttle | 1 |
| 17 | 67759 | 油门杆（上部） | LEVER Throttle (UPPER) | 1 |
| 18 | 41049 | 油门杆（中部） | LEVER Throttle (CENTER) | 1 |
| 19 | 67749 | 油门杆（下部） | LEVER Throttle (LOWER) | 1 |
| 20 | 15124 | 螺钉 (#10-32 x .750) | SCREW (#10-32 x .750) | 3 |
| 21 | 26996 | 锁紧垫圈 (#10) 不锈钢 节气门杆螺钉 | LOCKWASHER (#10) Stainless Steel THROTTLE LEVER SCREW | 3 |
| 22 | 56681 | 垫圈 (.203 x .500 x .032) 节气门杆螺钉 | WASHER (.203 x .500 x .032) THROTTLE LEVER SCREW | 3 |
| 22 | 8M0204666 | 垫圈 (.203 x .500 x .032) | WASHER (.203 x .500 x .032) | 3 |
| 23 | 67297 | U型销节气门杆至节气门连杆 | PIN Clevis THROTTLE LEVERS TO THROTTLE LINK | 3 |
| 24 | 89302 | 垫圈(.203 x .406 x .040)U型销 | WASHER (.203 x .406 x .040) CLEVIS PIN | 3 |
| 25 | 26953 | 开口销U型销 | COTTER PIN CLEVIS PIN | 3 |
| 26 | 67748 | 下节气门杆滚轮 | ROLLER LOWER THROTTLE LEVER | 1 |
| 27 | 90585 | 进气消音器盖塞 | PLUG INDUCTION SILENCER COVER | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8745A5 | 曲轴总成 | CRANKSHAFT ASSEMBLY | 1 |
| 2 | 67923 | 曲轴下球轴承 | BEARING Ball CRANKSHAFT (LOWER) | 1 |
| 2 | 67923T | 滚珠轴承 | BEARING Ball | 1 |
| 3 | 67446 | 滚珠轴承环 | RING BALL BAEARING | 1 |
| 4 | 99727A1 | 驱动齿轮 | GEAR Drive | 1 |
| 5 | 54196A6 | 密封载体总成 | CARRIER ASSEMBLY SEAL | 1 |
| 6 | 65800 | 填料载体 | PACKING CARRIER | 1 |
| 7 | 67377 | 曲轴密封环(.124厚度) | RING Sealing SEALING - CRANKSHAFT (.124 THICK) | AR |
| 7 | 67377T | 密封环 | RING Sealing | AR |
| 7 | 78633 | 曲轴密封环(.139厚度) | RING SEALING - CRANKSHAFT (.139 THICK) | AR |
| 8 | 93495 | 曲轴滚柱轴承 | BEARING Roller CRANKSHAFT | 2 |
| 8 | 93495T | 滚柱轴承 | BEARING Roller | 2 |
| 9 | 67444 | 滚柱轴承挡圈 | RING Retaining ROLLER BEARING | 2 |
| 10 | 8666A22 | 活塞总成(右舷) | PISTON ASSEMBLY (STARBOARD) | 3 |
| 10 | 8666T42 | 活塞总成-右舷-标准 | PIST.ASY.STBD.STD | 3 |
| 10 | 8666A36 | 活塞总成 右舷 | PISTON ASSEMBLY Starboard | AR |
| 10 | 8666A43 | 活塞总成-右舷-0.015 | PIST.ASY STBD.015 | AR |
| 10 | 8667A22 | 活塞总成(左舷) | PISTON ASSEMBLY (PORT) | 3 |
| 10 | 8667T42 | 活塞总成-左舷-标准 | PIST.ASY.PORT.STD | 3 |
| 10 | 8667A36 | 活塞总成 左舷 | PISTON ASSEMBLY Port | 3 |
| 10 | 8667A43 | 活塞总成-左舷-0.015 | PIST.ASY PORT.015 | 3 |
| 11 | 18487A12 | 活塞环组 | RING SET Piston | 1 |
| 11 | 815267A4 | 活塞环组 | RING SET Piston | 1 |
| 12 | 52035 | RING Lock PISTON | 12 | |
| 12 | 857196 | 锁紧环 | LOCK RING | 12 |
| 13 | 8119A5 | 连杆总成 | CONNECTING ROD ASSEMBLY | 6 |
| 13 | 8119A6 | 连杆套件 | CONN ROD KIT | 6 |
| 14 | 93886 | 螺钉(0.312-28×0.875)连杆 | SCREW (.312-28 x .875) CONNECTING ROD | 12 |
| 15 | 47247 | 定位针垫圈 | WASHER NEEDLE LOCATING | 12 |
| 15 | 8M0032839 | 垫片@5 | WASHER @5 | 12 |
| 16 | 17514A1 | 曲轴端轴承套件 | BEARING KIT CRANKSHAFT END | 6 |
| 16 | 8M0234886 | 轴承保持架 | CAGE BEARING | 6 |
| 17 | 67483 | 活塞端滚针轴承 | BEARING Needle PISTON END | 174 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8712A43 | 气缸体 | CYLINDER BLOCK | 1 |
| 2 | 76175 | 动力头螺柱(1-7/8英寸) | STUD POWERHEAD (1-7/8") | 6 |
| 3 | 67065 | 双头螺柱(5-1/2") | STUD (5-1/2") | 2 |
| 3 | 670654 | 螺柱(.375-16/.375-24 x 5.620) | STUD (.375-16/.375-24 x 5.620) | 2 |
| 3 | 78438 | 动力头螺柱(6-3/4英寸) | STUD POWERHEAD (6-3/4") | 2 |
| 3 | 8M0034454 | 螺柱(.375-16/.375-24 x 6.87) | STUD (.375-16/.375-24 x 6.87) | 2 |
| 4 | 20033 | 定位销 | PIN Dowel LOCATING | 2 |
| 4 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 5 | 67296 | 气缸体销(轴承座圈) | PIN CYLINDER BLOCK (BEARING RACE) | 2 |
| 5 | 8M0036405 | 销 | PIN | 2 |
| 6 | 11338 | 密封垫片 | GASKET SEALING | 2 |
| 7 | 42249 | 启动马达上盖 | COVER STARTER MOTOR (UPPER) | 1 |
| 7 | 8M0088723 | 启动器支架 | BRACKET-STARTER | 1 |
| 8 | 73657 | 盖至曲轴箱螺钉(.312-18 x 1.50) | SCREW (.312-18 x 1.50) COVER TO CRANKCASE | 2 |
| 9 | 26993 | 启动马达盖螺钉锁紧垫圈(0.312) | LOCKWASHER (.312) STARTER MOTOR COVER SCREW | 4 |
| 9 | 8M0204647 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 4 |
| 10 | 76867 | 启动电机盖(下部) | COVER STARTER MOTOR (LOWER) | 1 |
| 11 | 77065 | 盖至曲轴箱螺钉(.312-18 x 2) | SCREW (.312-18 x 2) COVER TO CRANKCASE | 2 |
| 11 | 815549 | 螺钉(.312-18 x 2.00) | SCREW (.312-18 x 2.00) | 2 |
| 11A | 99448 | 衬套 | BUSHING | 1 |
| 12 | 66717 | 曲轴箱至气缸体螺钉(.375-16 x 3.250) | SCREW (.375-16 x 3.250) CRANKCASE TO CYLINDER BLOCK | 8 |
| 12 | 74824 | 曲轴箱至气缸体螺丝(.312-18 x 1.250) | SCREW (.312-18 x 1.250) CRANKCASE TO CYLINDER BLOCK | 6 |
| 13 | 8454A2 | 上端盖总成 | END CAP ASSEMBLY UPPER | 1 |
| 13 | 8454T2 | 端盖总成 | END CAP ASSY | 1 |
| 14 | 54029 | 端盖O型圈(2.800 x .103) | O-RING (2.800 x .103) END CAP | 1 |
| 15 | 93496 | 端盖滚柱轴承 | BEARING Roller END CAP | 1 |
| 15 | 93496T | 轴承 | BEARING | 1 |
| 16 | 41953 | 端盖密封件 | SEAL END CAP | 1 |
| 17 | 69034 | 上端盖至气缸体螺钉及锁紧垫圈(.312-18 x 1.00) | SCREW AND LOCKWASHER (.312-18 x 1.00) UPPER END CAP TO CYLINDER BLOCK | 4 |
| 17 | 30225 | 螺钉带锁紧垫圈(.312-18 x 1.00) | SCREW WITH LOCKWASHER (.312-18 x 1.00) | 4 |
| 18 | 24220 | 气缸体定位螺钉(.190-24 x .190) | SCREW (.190-24 x .190) SET - CYLINDER BLOCK | 2 |
| 19 | 38407 | 气缸体水套螺塞(.500-14) | PLUG (.500-14) CYLINDER BLOCK (WATER JACKET) | 1 |
| 20 | 15094 | 飞轮盖至气缸体双头螺柱(.190-32 x 1.870) | STUD (.190-32 x 1.870) FLYWHEEL COVER TO CYLINDER BLOCK | 1 |
| 21 | 15093 | 飞轮盖至支架双头螺柱(#10-32 x 1.00) | STUD (#10-32 x 1.00) FLYWHEEL COVER TO BRACKET | 2 |
| 21 | 8M0034435 | 螺柱 | STUD | 2 |
| 22 | 67269 | 飞轮盖螺柱隔套 | SPACER FLYWHEEL COVER STUD | 1 |
| 23 | 492211 | 飞轮盖螺柱垫圈 | WASHER FLYWHEEL COVER STUD | 6 |
| 23 | 8M0204663 | 垫片@5 | WASHER @5 | 6 |
| 24 | 72761 | 飞轮盖螺柱不锈钢垫圈(.203 x .562 x .060) | WASHER (.203 x .562 x .060) Stainless Steel FLYWHEEL COVER STUD | 3 |
| 25 | 73651 | 飞轮盖螺柱螺母 | NUT FLYWHEEL COVER STUD | 3 |
| 25 | 816874 | 蝶形螺母 (#10-32) | WING NUT (#10-32) | 3 |
| 26 | 42248 | 飞轮罩支架 | BRACKET FLYWHEEL COVER | 1 |
| 26 | 422482 | 支架 | BRACKET | 1 |
| 27 | 49668 | 支架至曲轴箱螺钉(.250-20 x .750) | SCREW (.250-20 x .750) BRACKET TO CRANKCASE | 2 |
| 28 | 7809A1 | 下端盖总成 | END CAP ASSEMBLY LOWER | 1 |
| 28 | 7809T1 | 端盖总成 | END CAP ASSEMBLY | 1 |
| 29 | 62700 | 端盖O型圈(3.237 x .103) | O-RING (3.237 x .103) END CAP | 1 |
| 30 | 41953 | 端盖密封件 | SEAL END CAP | 2 |
| 31 | 28636 | 螺钉（0.250-20 x 0.750）下端盖至气缸体 | SCREW (.250-20 x .750) LOWER END CAP TO CYLINDER BLOCK | 4 |
| 32 | 26992 | 下端盖螺钉不锈钢锁紧垫圈(.250) | LOCKWASHER (.250) Stainless Steel LOWER END CAP SCREW | 4 |
| 33 | 64022 | 调节螺钉(.250-20 x 2.125)-气缸体 | SCREW (.250-20 x 2.125) ADJUSTING - CYLINDER BLOCK | 1 |
| 34 | 64015 | 锁紧螺母(.250-20)-调节螺钉 | NUT (.250-20) JAM - ADJUSTING SCREW | 1 |
| 35 | 26852 | 调节螺钉尼龙帽 | CAP Nylon NYLON - ADJUSTING SCREW | 1 |
| - | 66517 | 气缸体泄流限制器 | RESTRICTOR BLEED - CYLINDER BLOCK | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | -- |
| - | 18274A88 | 动力头总成 | POWERHEAD ASSEMBLY | -- |
| - | 18274T88 | 船用动力头 | POWERHEAD MARINE | -- |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8343A7 | 传动轴壳体总成(黑色) | HOUSING ASSEMBLY Driveshaft (BLACK) | 1 |
| 1 | 8343A8 | 传动轴壳体总成(灰色) | HOUSING ASSEMBLY Driveshaft (GRAY) | 1 |
| 2 | 56295 | 螺柱 (.437 x 2.69) 驱动轴壳体/齿轮壳体 (长型) | STUD (.437 x 2.69) DRIVE SHAFT HSG./GEAR HSG (LONG) | 2 |
| 3 | 25067 | 下安装座螺钉缓冲垫 | BUMPER LOWER MOUNT SCREW | 2 |
| 4 | 63474 | 下安装座螺钉(.500-20 x 6.00) | SCREW (.500-20 x 6.00) LOWER MOUNT | 2 |
| 4 | 898831 | 螺钉(.500-20 x 6.220) | SCREW (.500-20 x 6.220) | 2 |
| 5 | 77327 | 支架 (下部) | MOUNT (LOWER) | 2 |
| 6 | 49339 | 下部安装螺钉垫圈(.8125) | WASHER (.8125) LOWER MOUNT SCREW | 2 |
| 7 | 25096 | 下安装螺丝螺母 | NUT LOWER MOUNT SCREW | 2 |
| 8 | 88238A1 | 接地线总成 | CABLE ASSEMBLY Ground | 1 |
| 8 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 1 |
| 9 | 67076 | 下安装夹 | CLAMP LOWER MOUNT | 2 |
| 9 | 8M0036782 | 卡箍 | CLAMP | 2 |
| 10 | 66727 | 螺钉(.312-18 x 1.250) | SCREW (.312-18 x 1.250) | 4 |
| 11 | 67077 | 下部安装夹盖（黑色） | COVER LOWER MOUNT CLAMP (BLACK) | 2 |
| 11 | 8M4500752 | 盖板 | COVER | 2 |
| 11 | 67077T6 | 下安装座夹具盖(灰色) | COVER LOWER MOUNT CLAMP (GRAY) | 2 |
| 11 | 67077F1 | 灰色盖板 | COVER Gray | 2 |
| 12 | 88417 | 盖固定螺钉(#12-24 x .620) | SCREW (#12-24 x .620) COVER ATTACHING | 4 |
| 13 | 35521 | 盖至夹具螺钉尼龙螺母 | NUT NYLON - COVER TO CLAMP SCREW | 4 |
| 14 | 88238A2 | 接地线总成 | CABLE ASSEMBLY Ground | 1 |
| 14 | 88238A10 | 接地线总成 | CABLE ASSEMBLY Ground | 1 |
| 15 | 41508 | 螺丝(.250-20 x .500)不锈钢接地线 | SCREW (.250-20 x .500) Stainless Steel GROUND WIRE | 1 |
| 16 | 73862 | 齿轮箱壳体螺柱垫圈 | WASHER GEAR HOUSING STUD | 1 |
| 17 | 29489 | 齿轮箱壳体螺柱盖形螺母 | NUT GEAR HOUSING STUD (CAP) | 1 |
| 18 | 45176 | 齿轮箱壳体螺柱不锈钢垫圈(.453 x .812 x .105) | WASHER (.453 x .812 x .105) Stainless Steel GEAR HOUSING STUD | 2 |
| 19 | 34933 | 齿轮箱壳体螺柱不锈钢螺母(.437-20) | NUT (.437-20) Stainless Steel GEAR HOUSING STUD | 2 |
| 19 | 8M0204653 | 螺母 | NUT | 2 |
| 20 | 64649 | 驱动轴壳体塞 | PLUG DRIVE SHAFT HOUSING | 1 |
| 21 | 89743 | 排气管 | TUBE Exhaust | 1 |
| 22 | 66350 | 排气管密封件 (下部) | SEAL EXHAUST TUBE (LOWER) | 1 |
| 22 | 66350001 | 密封件 | SEAL | 1 |
| 23 | 86027 | 排气管密封件 (上部) | SEAL EXHAUST TUBE (UPPER) | 1 |
| 24 | 67295 | 长型水管 | TUBE Water WATER (LONG) | 1 |
| 24 | 8M0042788 | 长型水管 | TUBE-WATER-LONG | 1 |
| 25 | 99173 | 驱动轴壳体至板衬垫 | GASKET DRIVE SHAFT HOUSING TO PLATE | 1 |
| 25 | 991734 | 衬垫 | GASKET | 1 |
| 26 | 41945A6 | 驱动轴壳体板总成 | PLATE ASSEMBLY DRIVE SHAFT HOUSING | 1 |
| 27 | 707482 | 支架密封条 | SEAL BRACKET | 1 |
| 28 | 68011 | 密封件固定支架 | BRACKET SEAL RETAINING | 1 |
| 29 | 48408 | 支架至板件螺钉(#10-16 x .500) | SCREW (#10-16 x .500) BRACKET TO PLATE | 12 |
| 30 | 20033 | 定位销 | PIN Dowel LOCATING | 2 |
| 30 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 31 | 38970 | 水管密封件 | SEAL WATER TUBE | 1 |
| 32 | 90192 | 螺钉 (.250-20 x .750) 不锈钢 扩散器至板 | SCREW (.250-20 x .750) Stainless Steel DIFFUSER TO PLATE | 6 |
| 33 | 99177 | 驱动轴壳体板至排气板衬垫 | GASKET DRIVE SHAFT HOUSING PLATE TO EXHAUST PLATE | 1 |
| 33 | 991772 | 衬垫 | GASKET | 1 |
| 34 | 25970 | 动力头螺柱垫圈 | WASHER POWERHEAD STUD | 4 |
| 34 | 20553 | 垫圈(.406 x .734 x .063) | WASHER (.406 x .734 x .063) | 4 |
| 35 | 69254 | 动力头螺柱螺母 | NUT POWER HEAD STUD | 4 |
| 36 | 17303 | 扩散器 排气 | DIFFUSER EXHAUST | 1 |
| 36 | 17303T1 | 排气延长管 | EXH. EXTENSION | 1 |
| 37 | 78246 | 排气扩散器衬垫 | GASKET EXHAUST DIFFUSER | 1 |
| 37 | 782461 | 衬垫 | GASKET | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 90484 | 分隔板衬垫 | GASKET DIVIDER PLATE | 2 |
| 2 | 99169 | 分隔板 | DIVIDER PLATE | 1 |
| 2 | 99169A1 | 安装板 | PLATE | 1 |
| 3 | 69668 | 分隔板密封件 | SEAL DIVIDER PLATE | 1 |
| 3 | 814754 | 密封件(12.50英寸) | SEAL (12.50 Inches) | 1 |
| 4 | 95067 | 排气歧管盖 | COVER EXHAUST MANIFOLD | 1 |
| 5 | 74824 | 螺钉（0.312-18 x 1.250）盖和板至气缸体 | SCREW (.312-18 x 1.250) COVER AND PLATE TO CYLINDER BLOCK | 21 |
| 6 | 14462A1 | 安全阀盖 | COVER RELIEF VALVE | 1 |
| 7 | 74824 | 缸体盖板螺钉(.312-18 x 1.250) | SCREW (.312-18 x 1.250) COVER TO CYLINDER BLOCK | 4 |
| 8 | 16497A1 | 安全阀板 | PLATE RELIEF VALVE | 1 |
| 9 | 78690 | 安全阀板衬垫 | GASKET RELIEF VALVE PLATE | 2 |
| 9 | 78690002 | 衬垫 | GASKET | 2 |
| 10 | 14479 | 隔膜 | DIAPHRAGM | 1 |
| 10 | 144791 | 隔膜 | DIAPHRAGM | 1 |
| 11 | 16496 | 导水板 | DEFLECTOR Water | 1 |
| 12 | 76451 | 膜片螺钉垫片 | WASHER DIAPHRAGM SCREW | 1 |
| 13 | 69570 | 膜片至板件螺钉(#10-16 x .750) | SCREW (#10-16 x .750) DIAPHRAGM TO PLATE | 1 |
| 14 | 64878 | 提升阀黑色压缩弹簧 | SPRING (Black) COMPRESSION POPPET VALVE | 1 |
| 15 | 14480 | 提升阀 | POPPET VALVE | 1 |
| 16 | 65848 | 提升阀座 | CARRIER POPPET VALVE | 1 |
| 17 | 64872 | 提升阀衬套 | GROMMET POPPET VALVE | 1 |
| 18 | 85303 | 提升阀弹簧垫片 | WASHER POPPET SPRING | 1 |
| 19 | 41944A2 | 排气板总成 | PLATE ASSEMBLY EXHAUST | 1 |
| 19 | 41944A5 | 隔板总成 | PLATE ASSEMBLY | 1 |
| 20 | 99664 | 排气板弯头 | ELBOW EXHAUST PLATE | 1 |
| 20 | 996642 | 90度弯头接头(0.125-27x0.250)尼龙 | FITTING Elbow 90 Degree (.125-27 x .250) Nylon | 1 |
| 21 | 20033 | 排气板定位销 | PIN Dowel LOCATING - EXHAUST PLATE | 2 |
| 21 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 22 | 707482 | 排气板密封件 | SEAL EXHAUST PLATE | 1 |
| 23 | 68010 | 密封件固定支架 | BRACKET SEAL RETAINING | 1 |
| 23 | 680101 | 支架 | BRACKET | 1 |
| 24 | 48408 | 支架至排气板螺钉(#10-16 x .500) | SCREW (#10-16 x .500) BRACKET TO EXHAUST PLATE | 8 |
| 25 | 25970 | 动力头螺柱垫圈 | WASHER POWERHEAD STUD | 6 |
| 25 | 20553 | 垫圈(.406 x .734 x .063) | WASHER (.406 x .734 x .063) | 6 |
| 26 | 69254 | 动力头螺柱螺母 | NUT POWERHEAD STUD | 6 |
| 27 | 27132 | 排气板衬套 | BUSHING EXHAUST PLATE | 1 |
| 28 | 66727 | 螺钉(.312-18 x 1.250)排气板固定 | SCREW (.312-18 x 1.250) EXHAUST PLATE ATTACHING | 1 |
| 29 | 68783 | 螺钉(.312-18 x 2.50)排气板固定 | SCREW (.312-18 x 2.50) EXHAUST PLATE ATTACHING | 1 |
| 30 | 66725 | 螺钉(.375-16 x 3.50)排气板固定 | SCREW (.375-16 x 3.50) EXHAUST PLATE ATTACHING | 3 |
| 30 | 898833 | 螺钉(.375-16 x 3.500) | SCREW (.375-16 x 3.500) | 3 |
| 31 | 12602 | 排气板衬套 | GROMMET EXHAUST PLATE | 1 |
| 31 | 12602002 | 护孔环 | GROMMET | 1 |
| 32 | 99176 | 排气板衬垫 | GASKET EXHAUT PLATE | 1 |
| 32 | 991764 | 衬垫 | GASKET | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 18896A1 | COVER KIT Flywheel | 1 | |
| 2 | 79022 | MARKER Timing | 1 | |
| 3 | 37572 | SCREW (.190-32 x .380) Timing Marker | 2 | |
| 4 | 72761 | WASHER (.203 x .562 x .060) Stainless Steel Timing Marker Screw | 2 | |
| 5 | 89219 | PLUG Flywheel Cover | 1 | |
| 5 | 89219001 | 堵头 | PLUG | 1 |
| 6 | 45907 | PLUG Yellow Flywheel | 1 | |
| 7 | 52901 | NUT (.625-18) Flywheel | 1 | |
| 8 | 68229 | WASHER (.641 x 1.250 x .190) Flywheel | 1 | |
| 8 | 33001 | 垫圈 | WASHER | 1 |
| 9 | 9841A2 | 飞轮 | FLYWHEEL | 1 |
| 9 | 859238T16 | 飞轮总成 | FLYWHEEL ASY | 1 |
| 10 | 32417 | SCREW (.250-28 x .625) Flywheel Plate | 8 | |
| 11 | 68997 | SCREW (.312-24 x .750) Flywheel Hub | 8 | |
| 12 | 9610A5 | 定子 | STATOR | 1 |
| 13 | 90045 | SCREW (#10-32 x 1.375) Stator | 4 | |
| 14 | 26996 | LOCKWASHER (#10) Stainless Steel Stator Screw | 4 | |
| 15 | 96455A9 | 触发板总成 | PLATE ASSEMBLY Trigger | 1 |
| 16 | 93388A1 | CABLE ASSEMBLY (6.00 Inches) Black Plate to Starter Motor | 1 | |
| 17 | 79472 | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 17 | 893893 | 启动马达 | STARTER MOTOR | 1 |
| 18 | 56703 | 启动电机轴套 | COLLAR Starter Motor | 2 |
| 18 | 8M0034918 | 轴环 | COLLAR | 2 |
| 19 | 68042 | STOP Rubber Rubber-Starter Motor | 2 | |
| 19 | 8M0043376 | 停机开关 | STOP | 2 |
| 20 | 26992 | 锁紧垫圈 (.250) 不锈钢 启动电机至端子 | LOCKWASHER (.250) Stainless Steel Starter Motor to Terminal | 1 |
| 21 | 20890 | NUT (.250-20) Starter Motor Terminal | 1 | |
| 22 | 93388A2 | CABLE ASSEMBLY Black Solenoid to Starter Motor | 1 | |
| 22 | 93388A14 | 线缆总成(黄/黑) | CABLE ASSEMBLY Yellow/Black | 1 |
| 23 | 69035 | 螺钉和锁紧垫圈 (.250-20 x .625) 不锈钢 电缆至启动电机 | SCREW AND LOCKWASHER (.250-20 x .625) Stainless Steel Cable to Starer Motor | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9671A1 | 化油器(上) | CARBURETOR (TOP) | 1 |
| 2 | 9671A2 | 化油器(中) | CARBURETOR (CENTER) | 1 |
| 3 | 9671A3 | 化油器(下) | CARBURETOR (BOTTOM) | 1 |
| 4 | 6232 | 燃油进口接头(上部) | FITTING FUEL INLET (UPPER) | 1 |
| 5 | 70007 | 45度燃油入口接头 | FITTING 45 Degree FUEL INLET | 4 |
| 6 | 90430 | 化油器衬垫 | GASKET CARBURETOR | 3 |
| 6 | 904301 | 衬垫 | GASKET | 3 |
| 7 | 20184 | 化油器安装螺母(1/4-28X7/32) | NUT (1/4-28X7/32) CARBURETOR MOUNTING | 12 |
| 7 | 8M0207775 | 螺母 @5 | NUT @5 | 12 |
| 8 | 73498 | 化油器燃油管卡箍 | CLAMP FUEL HOSE TO CARBURETOR | AR |
| 8 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 9 | 42859A2 | 加浓阀总成 | VALVE ASSEMBLY Enrichner | 1 |
| 10 | 633001 | 加浓阀卡箍 | CLAMP ENRICHER VALVE | 1 |
| 11 | 73286 | 螺钉(0.250-20×0.500)不锈钢阀门卡箍 | SCREW (.250-20 x .500) Stainless Steel VALVE CLAMP | 1 |
| 12 | 45915 | 端子排簧片块壳体 | TERMINAL BLOCK REED BLOCK HOUSING | 2 |
| 13 | 35519 | 端子块固定螺钉(#10-16 x .500) | SCREW (#10-16 x .500) TERMINAL BLOCK ATTACHING | 2 |
| 14 | 99130122 | 管材(20英尺整卷)化油器顶部至阀门(裁切至7.75英寸) | TUBING (20.00 Feet Bulk) TOP CARBURETOR TO VALVE (Cut to 7.75 Inches) | 1 |
| 14 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 15 | 9912688 | 管材(36英寸整卷)化油器间连接(裁切至4.25英寸) | TUBING (36.00 Inches Bulk) CARBURETOR TO CARBURETOR (Cut to 4.25 Inches) | 2 |
| 16 | 15930A15 | 燃油泵套件 | PUMP KIT Fuel | 1 |
| 17 | 42990A3 | 膜片组件 | DIAPHRAGM KIT | 1 |
| 17 | 857005A1 | 膜片组件 | DIAPHRAGM KIT | 1 |
| 18 | NSS | 橡胶止回阀(不单独销售) | NOT SOLD SEPARATE Check Valve-Rubber | 2 |
| 19 | NSS | 增压垫片(不单独销售) | NOT SOLD SEPARATE Gasket-Boost | 1 |
| 20 | NSS | 膜片(不单独销售) | NOT SOLD SEPARATE Diaphragm | 2 |
| 21 | NSS | 脉冲垫片(不单独销售) | NOT SOLD SEPARATE Gasket-Pulse | 1 |
| 22 | NSS | 弹簧(不单独销售) | NOT SOLD SEPARATE Spring | 1 |
| 23 | NSS | 盖帽(不单独销售) | NOT SOLD SEPARATE Cap | 1 |
| 24 | NSS | 止回阀(不单独销售) | NOT SOLD SEPARATE Check Vavle | 2 |
| 25 | NSS | 固定座(不单独销售) | NOT SOLD SEPARATE Retainer | 2 |
| 26 | NSS | 弹簧(不单独销售) | NOT SOLD SEPARATE Spring | 1 |
| 27 | NSS | 盖帽(不单独销售) | NOT SOLD SEPARATE Cap | 1 |
| 28 | 98769 | 底座衬垫 | GASKET BASE | 1 |
| 28 | 8M0204705 | 衬垫@2 | GASKET @2 | 1 |
| 29 | 144303 | 燃油泵底座 | BASE FUEL PUMP | 1 |
| 30 | 98775A2 | 燃油泵板 | PLATE FUEL PUMP | 1 |
| 30 | 987752 | 安装板 | PLATE | 1 |
| 31 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 1 |
| 32 | 64704 | 接头 | FITTING | 1 |
| 32 | 19688 | 接头 | FITTING | 1 |
| 33 | 16452 | 燃油泵螺钉(#12-24 x 2.00) | SCREW (#12-24 x 2.00) FUEL PUMP | 2 |
| 34 | 4000310 | 燃油泵至曲轴箱螺钉(M5 x 40) | SCREW (M5 x 40) FUEL PUMP TO CRANKCASE | 2 |
| 35 | 4002314 | 燃油泵螺钉垫圈 | WASHER FUEL PUMP SCREW | 2 |
| 36 | 14868 | 燃油泵弯头接头 | FITTING FUEL PUMP (ELBOW) | 1 |
| 37 | 64704 | 燃油泵弯头接头 | FITTING FUEL PUMP (ELBOW) | 1 |
| 37 | 19688 | 接头 | FITTING | 1 |
| 38 | 99127109 | 管路(57.00英寸 散装) | LINE (57.00 Inches Bulk) | 1 |
| 38 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 39 | 16494 | 燃油滤清器 | FILTER Fuel | 1 |
| 39 | 816296Q03 | 燃油滤清器@3 | FILTER-FUEL @3 | 1 |
| 40 | 15279 | 燃油滤清器卡箍 | CLAMP FUEL FILTER | 1 |
| 41 | 64705 | 脉冲软管接头 | FITTING PULSE HOSE | 1 |
| 42 | 9912976 | 油管 | TUBING | 1 |
| 42 | 8M0108349 | 软管 (70英寸散装) | HOSE (70 Inches Bulk) | 1 |
| 43 | 424251 | 三通 | TEE | 1 |
| 43 | 424253 | 接头 | FITTING | 1 |
| 44 | 36221 | 燃油管路至适配器弯头 | ELBOW FUEL LINE TO ADAPTOR | 1 |
| 45 | 30186 | 止回转接器总成 | ADAPTER CHECK UNIT | 1 |
| 46 | 30187 | 适配器阀杆止回单元 | STEM CHECK UNIT ADAPTOR | 1 |
| 46 | 30185Q3 | 油箱端快速断开总成-卡口式 | QUICK DISCONNECT ASSEMBLY Tank End - Bayonet Style | 1 |
| 47 | 30189 | 适配器阀杆弹簧 | SPRING ADAPTOR STEM | 1 |
| 48 | 20415 | 适配器阀杆O型圈 | O-RING ADAPTOR STEM | 1 |
| 48 | 16524 | 燃油接头O型圈 | O-RING Fuel Connector | 1 |
| 49 | 30188 | 适配器垫片 | WASHER ADAPTOR | 1 |
| 50 | 69067 | 适配器至下罩螺钉(.250-20 x 1.375) | SCREW (.250-20 x 1.375) ADAPTOR TO BOTTOM COWL | 1 |
| 51 | 92037 | 燃油连接器密封件 | SEAL FUEL CONNECTOR | 1 |
| 52 | 9912976 | 油管 | TUBING | 1 |
| 52 | 8M0108349 | 软管 (70英寸散装) | HOSE (70 Inches Bulk) | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 814247A3 | 齿轮箱总成（1.78:1传动比 - 黑色）（完整） | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Black (Complete) | 1 |
| - | 814247A4 | 齿轮箱总成（1.78:1传动比 - 灰色）（完整） | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Gray (Complete) | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 814247A1 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 814247T1 | 齿轮箱总成基础型-黑色 | GEAR HOUSING ASSEMBLY Basic-Black | 1 |
| 1 | 814247A2 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 1 | 814247T2 | ORD 1674-814247T1 | ORD 1674-814247T1 | 1 |
| 2 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 2A | 43998 | 套筒 | SLEEVE | 1 |
| 3 | 20033 | 定位销 | PIN Dowel | 2 |
| 3 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 4 | 78638 | 双头螺柱(.438 x 3.12) | STUD (.438 x 3.12) | 1 |
| 4 | 786382 | 螺柱(.437-14/.437-20 x 3.120) | STUD (.437-14/.437-20 x 3.120) | 1 |
| 5 | 57920 | 双头螺柱(.44 x 2.06) | STUD (.44 x 2.06) | 2 |
| 5 | 8M0133358 | 双头螺栓(.437-14/.437-20×2.060) | STUD (.437-14/.437-20 x 2.060) | 2 |
| 6 | 56297 | 双头螺栓(.312×3.38) | STUD (.312 x 3.38) | 1 |
| 6 | 8M0034463 | 螺柱(.312-24 x 3.38) | STUD (.312-24 x 3.38) | 1 |
| 7 | 30667 | 双头螺栓(.250-20/.250-28×3.125) | STUD (.250-20/.250-28 x 3.125) | 2 |
| 7 | 306671 | 螺柱 | STUD | 2 |
| 8 | 35934A1 | 滚柱轴承总成 | BEARING ASSEMBLY Roller | 1 |
| 9 | 79953 | SCREW (.375-16 x .250) GREASE FILLER | 1 | |
| 9 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 10 | 67892 | SCREW Magnetic DRAIN | 1 | |
| 10 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 11 | 815168 | 驱动轴 | DRIVESHAFT | 1 |
| 12 | NSS | 不单独出售小齿轮（43-16279A2部件） | NOT SOLD SEPARATE PINION GEAR (PART OF 43-16279A2) | 1 |
| 13 | 19183 | 纤维垫圈 | WASHER Fiber | 2 |
| 13 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 2 |
| 14 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 15 | 42637A1 | 垫片组 | SHIM SET | AR |
| 15 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 16 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 16 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 17 | 42633 | 螺母 | NUT | 1 |
| 17 | 8245191 | 固定座 | RETAINER | 1 |
| 18 | 42579A3 | 水泵底座总成 | BASE ASSEMBLY Water Pump | 1 |
| 18 | 8M0077147 | 带水泵底座总成 | BASE ASSY-W/P | 1 |
| 19 | 426311 | 衬垫 | GASKET | 1 |
| 19 | 8M0204678 | 衬垫 | GASKET | 1 |
| 20 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 20 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 21 | 89238 | 油封 | SEAL Oil | 1 |
| 22 | 16977 | 油封 | SEAL Oil | 1 |
| 23 | 856081 | 下部衬垫 | GASKET LOWER | 1 |
| 23 | 8M0090319 | 衬垫@5 | GASKET @5 | 1 |
| 24 | 856091 | 上衬垫 | GASKET UPPER | 1 |
| 24 | 858524 | 衬垫 | GASKET | 1 |
| 25 | 32435 | 面板 | FACE PLATE | 1 |
| 25 | 8M0204677 | 面板 | PLATE-FACE | 1 |
| 26 | 96148A1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 26 | 96148T1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 27 | 48752 | 嵌件 | INSERT | 1 |
| 27 | 48752T | 嵌件 | INSERT | 1 |
| 28 | 38970 | 橡胶密封件 | SEAL RUBBER | 1 |
| 29 | 899841 | 叶轮 | IMPELLER | 1 |
| 29 | 89984T3 | 叶轮 | IMPELLER | 1 |
| 30 | 56654 | 键 | KEY | 1 |
| 30 | 8M0214992 | 键@5 | KEY @5 | 1 |
| 31 | 96411 | 螺钉(#14-8×2.25) | SCREW (#14-8 x 2.25) | 1 |
| 31 | 8M0215009 | 螺钉 | SCREW | 1 |
| 32 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 32 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 33 | 13438 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 33 | 8267119 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 34 | 36001 | 垫圈 | WASHER | 1 |
| 35 | 13436 | 螺母 | NUT | 1 |
| 37 | 29804 | 套筒 | SLEEVE | 1 |
| 37 | 29804T | 套筒 | SLEEVE | 1 |
| 38 | 815264 | 换档轴 | SHIFT SHAFT | 1 |
| 38 | 8152641 | 换档轴 | SHIFT SHAFT | 1 |
| 39 | 29641 | E型卡环 | E RING | 1 |
| 40 | 25439 | O型圈(.862×0.103) | O-RING (.862 x .103) | 1 |
| 41 | 77631A2 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 42 | 816464 | 油封 | SEAL Oil | 1 |
| 42 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 43 | 77674 | 垫圈（0.35 x 0.75 x 0.12）橡胶（换挡轴衬套） | WASHER (.35 x .75 x .12) RUBBER -SHIFT SHAFT BUSHING | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| - | 96148A5 | 水泵维修套件 | REPAIR KIT Water Pump | 1 |
| - | 96148A8 | 水泵维修套件 | WATER PUMP REPAIR KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 9572A3 | 齿轮箱总成（长型）（黑色） | GEAR HOUSING ASSEMBLY (LONG)(BLACK) | 1 |
| - | 9572A4 | 齿轮箱总成（长型）（灰色） | GEAR HOUSING ASSEMBLY (LONG)(GRAY) | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 9572A1 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| 1 | 814247T8 | 齿轮箱 | GEAR HSG | 1 |
| 1 | 9572A2 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| 1 | 814247T9 | 齿轮箱 | GEAR HSG | 1 |
| 2 | 85822A1 | CONNECTOR ASSEMBLY SPEEDOMETER | 1 | |
| 2 | 85822A10 | 连接器总成 | CONNECTOR ASSEMBLY | 1 |
| 3 | 20033 | 定位销 齿轮箱定位 | PIN Dowel GEAR HOUSING LOCATING | 2 |
| 3 | 43044 | 定位销-无孔(.375 x .625) | PIN Dowel - Without Hole (.375 x .625) | 2 |
| 4 | 78638 | 齿轮箱螺柱(0.438×3.12) | STUD (.438 x 3.12) GEAR HOUSING | 1 |
| 4 | 786382 | 螺柱(.437-14/.437-20 x 3.120) | STUD (.437-14/.437-20 x 3.120) | 1 |
| 5 | 57920 | 双头螺栓(.44 x 2.06)齿轮箱 | STUD (.44 x 2.06) GEAR HOUSING | 2 |
| 5 | 8M0133358 | 双头螺栓(.437-14/.437-20×2.060) | STUD (.437-14/.437-20 x 2.060) | 2 |
| 6 | 56297 | 双头螺栓(.312 x 3.38)水泵 | STUD (.312 x 3.38) WATER PUMP | 1 |
| 6 | 8M0034463 | 螺柱(.312-24 x 3.38) | STUD (.312-24 x 3.38) | 1 |
| 7 | 30667 | 双头螺栓(.250-20/.250-28 x 3.125)水泵 | STUD (.250-20/.250-28 x 3.125) WATER PUMP | 2 |
| 7 | 306671 | 螺柱 | STUD | 2 |
| 8 | 32898 | 轴承 | BEARING | 1 |
| 8 | 32898T | 轴承 | BEARING | 1 |
| 9 | 79953 | SCREW (.375-16 x .250) GREASE FILLER | 1 | |
| 9 | 79953Q04 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 10 | 67892 | SCREW Magnetic DRAIN | 1 | |
| 10 | 8M0058389 | 放油螺钉套件 | SCREW KIT Drain | 1 |
| 11 | 15298 | 驱动轴注油嘴 | DRIVESHAFT GREASE FILLER | 1 |
| 12 | NSS | 不单独出售小齿轮（43-16279A2部件） | NOT SOLD SEPARATE PINION GEAR (PART OF 43-16279A2) | 1 |
| 13 | 20260 | 润滑脂加注与排放螺钉垫圈 | WASHER GREASE FILLER AND DRAIN SCREW | 2 |
| 13 | 8M0187157 | 蓝色密封件@15 | SEAL-BLUE @15 | 2 |
| 14 | 35921 | 螺母(0.625-18) | NUT (.625-18) | 1 |
| 15 | 42637A1 | 垫片组 | SHIM SET | AR |
| 15 | 8M0063267 | 垫片组 | SHIM SET | AR |
| 16 | 36387A1 | 轴承总成(滚子/外圈) | BEARING ASSEMBLY Roller/Cup | 1 |
| 16 | 8M0146566 | 杯/锥轴承总成 | BEARING ASSEMBLY Cup/Cone | 1 |
| 17 | 42633 | 传动轴轴承螺母 | NUT DRIVESHAFT BEARING | 1 |
| 17 | 8245191 | 固定座 | RETAINER | 1 |
| 18 | 42579A3 | 水泵底座总成 | BASE ASSEMBLY Water Pump | 1 |
| 18 | 8M0077147 | 带水泵底座总成 | BASE ASSY-W/P | 1 |
| 19 | 42631 | 衬垫 | GASKET | 1 |
| 19 | 8M0204678 | 衬垫 | GASKET | 1 |
| 20 | 90011 | O型圈(2.175 x 0.175) | O-RING (2.175 x .175) | 1 |
| 20 | 8M0142854 | O型圈(2.175 x 0.103) | O-RING (2.175 x .103) | 1 |
| 20 | 38099 | O型圈（内径2.109） | O-RING (2.109 I.D.) | 1 |
| 21 | 89238 | 油封 | SEAL Oil | 1 |
| 22 | 16977 | 油封 | SEAL Oil | 1 |
| 23 | 85608 | 下部衬垫 | GASKET LOWER | 1 |
| 23 | 8M0090319 | 衬垫@5 | GASKET @5 | 1 |
| 24 | 85609 | 上衬垫 | GASKET UPPER | 1 |
| 24 | 858524 | 衬垫 | GASKET | 1 |
| 25 | 32435 | 面板 | FACE PLATE | 1 |
| 25 | 8M0204677 | 面板 | PLATE-FACE | 1 |
| 26 | 96148A1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 26 | 96148T1 | 水泵壳体总成 | BODY ASSEMBLY Water Pump | 1 |
| 27 | 48752 | 水泵体嵌件 | INSERT WATER PUMP BODY | 1 |
| 27 | 48752T | 嵌件 | INSERT | 1 |
| 28 | 38970 | 橡胶密封件 | SEAL RUBBER | 1 |
| 29 | 89984 | 水泵叶轮 | IMPELLER WATER PUMP | 1 |
| 29 | 89984T4 | 叶轮 | IMPELLER | 1 |
| 30 | 56654 | 叶轮驱动键 | KEY IMPELLER DRIVE | 1 |
| 30 | 8M0214992 | 键@5 | KEY @5 | 1 |
| 31 | 96411 | 螺钉(#14-8×2.25) | SCREW (#14-8 x 2.25) | 1 |
| 31 | 8M0215009 | 螺钉 | SCREW | 1 |
| 32 | 29245 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 32 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 33 | 13438 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 33 | 8267119 | 螺母(.250-28) | NUT (.250-28) | 2 |
| 34 | 36001 | 垫圈 | WASHER | 1 |
| 35 | 13436 | 螺母 | NUT | 1 |
| 36 | 30271 | 橡胶环 | RING Rubber RUBBER | 1 |
| 36 | 8M0214918 | 环@5 | RING @5 | 1 |
| 37 | 29804 | 导向套 | SLEEVE GUIDE | 1 |
| 37 | 29804T | 套筒 | SLEEVE | 1 |
| 38 | 15299 | 换挡轴（下部） | SHAFT SHIFT-LOWER | 1 |
| 39 | 29641 | E型卡环 | E RING | 1 |
| 40 | 25439 | O型圈(.862×0.103) | O-RING (.862 x .103) | 1 |
| 41 | 77631A2 | 衬套总成 | BUSHING ASSEMBLY | 1 |
| 42 | 76384 | 油封 | SEAL Oil | 1 |
| 42 | 8M0246145 | 油封 | OIL SEAL | 1 |
| 43 | 77674 | 垫圈(.35 x .75 x .12) | WASHER (.35 x .75 x .12) | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| - | 42579A4 | 水泵修理包 | REBUILD KIT Water Pump | 1 |
| - | 96148A8 | 水泵维修套件 | WATER PUMP REPAIR KIT | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 9572A3 | 齿轮箱总成（长型）（黑色） | GEAR HOUSING ASSEMBLY (LONG)(BLACK) | 1 |
| - | 9572A4 | 齿轮箱总成（长型）（灰色） | GEAR HOUSING ASSEMBLY (LONG)(GRAY) | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 9572A1 | 齿轮箱总成(黑色) | GEAR HOUSING ASSEMBLY (BLACK) | 1 |
| 1 | 814247T8 | 齿轮箱 | GEAR HSG | 1 |
| 1 | 9572A2 | 齿轮箱总成(灰色) | GEAR HOUSING ASSEMBLY (GRAY) | 1 |
| 1 | 814247T9 | 齿轮箱 | GEAR HSG | 1 |
| 44 | 76039 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 44 | 760394 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 45 | 12239A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 45 | 850315A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 46 | 30622 | 弹簧 | SPRING | 1 |
| 47 | 44491A1 | 垫片组 | SHIM SET | AR |
| 47 | 8M0063266 | 垫片组 | SHIM SET | AR |
| 48 | 30894A1 | 圆锥轴承组 | BEARING SET Cup And Cone | 1 |
| 49 | 16279A2 | 前进齿轮总成 | GEAR ASSEMBLY Forward | 1 |
| 50 | 30895 | 滚针轴承 | BEARING Needle | 1 |
| 50 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 51 | 12777 | 棘轮 | RATCHET | 1 |
| 51 | 822539T | 离合器 | CLUTCH | 1 |
| 52 | 30632 | 十字销 | PIN Cross | 1 |
| 52 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 53 | 30893 | 弹簧 | SPRING | 1 |
| 54 | 12238T | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 55 | NSS | NOT SOLD SEPARATE REVERSE GEAR (PART OF 43-16279A2) | 1 | |
| 56 | 76358 | 止推垫片 | THRUST WASHER | 1 |
| 57 | 29976 | O型圈 | O-RING | 1 |
| 58 | 41529A2 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 58 | 41529T2 | 托架总成 | CARRIER ASSY | 1 |
| 59 | 98727 | 润滑脂接头 | FITTING Grease | 2 |
| 59 | 8M0169588 | 润滑脂接头 | FITTING Grease | 2 |
| 60 | 30956 | 滚针轴承 | BEARING Needle | 1 |
| 60 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 61 | 76868 | 密封件 | SEAL | 2 |
| 61 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 2 |
| 62 | 30281 | 键 | KEY | 1 |
| 63 | 52700 | 锁紧垫圈 | TAB WASHER | 1 |
| 64 | 52699 | 盖板 | COVER | 1 |
| 65 | 67891 | 填充块 | FILLER BLOCK | 1 |
| 65 | 8M0039169 | 填充块 | FILLER BLOCK | 1 |
| 66 | 30206 | 螺钉(.375-16 x 1.00)不锈钢 | SCREW (.375-16 x 1.00) Stainless Steel | 1 |
| 67 | 31211A2 | 花键垫圈 | WASHER Splined | 1 |
| 67 | 31211Q03 | 垫圈总成 | WASHER ASSEMBLY | 1 |
| 68 | 31210 | 锁紧垫圈 | TAB WASHER | 1 |
| 68 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 69 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 69 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 70 | 15300 | 阳极配平片 | TRIM TAB Anodic | 1 |
| 71 | 15797 | 螺钉 | SCREW | 1 |
| 72 | 45176 | 垫圈(.453 x .812 x .105)不锈钢 | WASHER (.453 x .812 x .105) Stainless Steel | 2 |
| 73 | 34933 | 螺母(.437-20)不锈钢 | NUT (.437-20) Stainless Steel | 2 |
| 73 | 8M0204653 | 螺母 | NUT | 2 |
| 74 | 13191A1 | 止推垫片 | THRUST WASHER | 1 |
| 74 | 13191Q01 | 止推垫片 | THRUST WASHER | 1 |
| 75 | 423511 | 齿形锁紧垫圈 | LOCKWASHER Toothed | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 814247A3 | 齿轮箱总成（1.78:1传动比 - 黑色）（完整） | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Black (Complete) | 1 |
| - | 814247A4 | 齿轮箱总成（1.78:1传动比 - 灰色）（完整） | GEAR HOUSING ASSEMBLY 1.78:1 Gear Ratio - Gray (Complete) | 1 |
| - | 814247T4 | 齿轮箱总成(完整) | GEAR HOUSING ASSEMBLY Complete | 1 |
| 1 | 814247A1 | 齿轮箱总成 基础型-黑色 | GEAR HOUSING ASSEMBLY Basic - Black | 1 |
| 1 | 814247T1 | 齿轮箱总成基础型-黑色 | GEAR HOUSING ASSEMBLY Basic-Black | 1 |
| 1 | 814247A2 | 齿轮箱总成 基础型-灰色 | GEAR HOUSING ASSEMBLY Basic - Gray | 1 |
| 1 | 814247T2 | ORD 1674-814247T1 | ORD 1674-814247T1 | 1 |
| 44 | 76039 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 44 | 760394 | 换挡凸轮控制 | CAM Shift Control | 1 |
| 45 | 12239A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 45 | 850315A1 | 凸轮从动件套件 | FOLLOWER KIT Cam | 1 |
| 46 | 30622 | 弹簧 | SPRING | 1 |
| 47 | 44491A1 | 垫片组 | SHIM SET | AR |
| 47 | 8M0063266 | 垫片组 | SHIM SET | AR |
| 48 | 30894A1 | 圆锥轴承组 | BEARING SET Cup And Cone | 1 |
| 49 | 16279A2 | 前进齿轮总成 | GEAR ASSEMBLY Forward | 1 |
| 50 | 30895 | 滚针轴承 | BEARING Needle | 1 |
| 50 | 30895T | 滚针轴承 | BEARING Needle | 1 |
| 51 | 814756 | 离合器 | CLUTCH | 1 |
| 51 | 822539T | 离合器 | CLUTCH | 1 |
| 52 | 30632 | 十字销 | PIN Cross | 1 |
| 52 | 8M0100263 | 十字销 | PIN Cross | 1 |
| 53 | 30893 | 弹簧 | SPRING | 1 |
| 54 | 12238T | 螺旋桨轴 | PROPELLER SHAFT | 1 |
| 55 | NSS | NOT SOLD SEPARATE REVERSE GEAR (PART OF 43-16279A2) | 1 | |
| 56 | 76358 | 止推垫片 | THRUST WASHER | 1 |
| 57 | 29976 | O型圈 | O-RING | 1 |
| 58 | 41529A2 | 轴承座总成 | CARRIER ASSEMBLY Bearing | 1 |
| 58 | 41529T2 | 托架总成 | CARRIER ASSY | 1 |
| 59 | 98727 | 润滑脂接头 | FITTING Grease | 2 |
| 59 | 8M0169588 | 润滑脂接头 | FITTING Grease | 2 |
| 60 | 30956 | 滚针轴承 | BEARING Needle | 1 |
| 60 | 30956T | 滚针轴承 | BEARING Needle | 1 |
| 61 | 76868 | 密封件 | SEAL | 2 |
| 61 | 8M0248882 | 油封@5 | SEAL-OIL @5 | 2 |
| 62 | 30281 | 键 | KEY | 1 |
| 63 | 52700 | 锁紧垫圈 | TAB WASHER | 1 |
| 64 | 52699 | 盖板 | COVER | 1 |
| 65 | 67891 | 填充块 | FILLER BLOCK | 1 |
| 65 | 8M0039169 | 填充块 | FILLER BLOCK | 1 |
| 66 | 65210 | 螺钉(.375-16 x 1.00) | SCREW (.375-16 x 1.00) | 1 |
| 68 | 816629 | 锁紧垫圈 | TAB WASHER | 1 |
| 68 | 816629Q | 锁紧垫圈 | TAB WASHER | 1 |
| 69 | 52707A1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 69 | 52707Q1 | 螺旋桨螺母套件 (.750-16) | PROP NUT KIT (.750-16) | 1 |
| 70 | 31640A1 | 平衡板总成 | TRIM TAB ASSEMBLY | 2 |
| 70 | 31640Q4 | 平衡鳍板 | TRIM TAB | 2 |
| 71 | 66024 | 螺钉(.437-14 x 1.75) | SCREW (.437-14 x 1.75) | 1 |
| 72 | 45176 | 垫圈(.453 x .812 x .105)不锈钢 | WASHER (.453 x .812 x .105) Stainless Steel | 2 |
| 73 | 34933 | 螺母(.437-20)不锈钢 | NUT (.437-20) Stainless Steel | 2 |
| 73 | 8M0204653 | 螺母 | NUT | 2 |
| 74 | 13191A1 | 止推垫片 | THRUST WASHER | 1 |
| 74 | 13191Q01 | 止推垫片 | THRUST WASHER | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| - | 89238A2 | 密封套件 | SEAL KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 19587 | 安装板 | PLATE Mounting | 1 |
| 2 | 30720 | SCREW (.250-20 x 2.25) Voltage Regulator | 4 | |
| 3 | 26992 | 锁紧垫圈(.250)不锈钢 | LOCKWASHER (.250) Stainless Steel | 4 |
| 4 | 19661 | 衬套 | BUSHING | 4 |
| 5 | 18736A8 | 电压调节器总成 | REGULATOR ASSEMBLY Voltage | 1 |
| 5 | 18736A21 | 调节器总成 | REGULATOR ASSY | 1 |
| 6 | 18717 | 密封件 | SEAL | 1 |
| 7 | 96158 | 启动电磁阀 | SOLENOID Starter | 2 |
| 7 | 8M0185622 | 电磁阀 | SOLENOID | 2 |
| 8 | 28635 | SCREW (.250-20 x .620) Stainless Steel Starter Solenoid | 3 | |
| 9 | 88807A6 | 黑色电缆总成 (3.50 英寸) | CABLE ASSEMBLY (3.50 Inches) Black | 1 |
| 10 | 56374 | NUT (.250-20) Solenoid Screw | 3 | |
| 10 | 8267098 | 螺母 (.250-20) 不锈钢 | NUT (.250-20) Stainless Steel | 3 |
| 11 | 26419 | NUT (#8-32) Brass Solenoid Terminal | 4 | |
| 12 | 94330 | NUT (.250-20) Brass Solenoid Terminal | 2 | |
| 13 | 97861 | INSULATOR Starter Solenoid | 2 | |
| 14 | 88807A8 | 黑色电缆总成 (3.50 英寸) | CABLE ASSEMBLY (3.50 Inches) Black | 2 |
| 15 | 88807A29 | 拉线总成 | CABLE ASSEMBLY | 1 |
| 16 | 90077 | 扎带 | TIE STRAP | AR |
| 16 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 17 | 43542 | 点火线圈盖 | COVER Ignition Coil | 2 |
| 18 | 7370A13 | 点火线圈总成 | COIL ASSEMBLY Ignition | 6 |
| 18 | 8M0230859 | 点火线圈总成 | COIL IGNITION ASY | 6 |
| 19 | 90048 | SCREW (#10-32 x 2.125) Ignition Coil Cover | 12 | |
| 20 | 90078 | NUT (#10-32) Cover Screw/Ground Wire | 14 | |
| 21 | 813715A9 | CABLE KIT Ignition High Tension | 1 | |
| 22 | 63709A1 | BOOT/TERMINAL KIT High Tension Cable | 6 | |
| 23 | 136862 | 火花塞 | SPARK PLUG | 6 |
| 23 | 13686Q | NGK BU8H @10 | NGK BU8H @10 | 6 |
| 24 | 45076 | NUT (#10-32) Brass Ignition Coil Terminal | 12 | |
| 25 | 88807A13 | 拉线总成 | CABLE ASSEMBLY | 6 |
| 26 | 69022 | 不锈钢接地线螺丝（#10-32 x .500） | SCREW (#10-32 x .500) Stainless Steel Grounding Wire | 2 |
| 27 | 69738A9 | HARNESS ASSEMBLY Coil to Switch Box | 1 | |
| 27 | 69739A6 | HARNESS ASSEMBLY Coil to Switch Box | 1 | |
| 28 | 54676 | 双线固定夹 | RETAINER Two Wire | 2 |
| 29 | 814407A3 | 倾斜开关套件 (动力艇) | SWITCH KIT Tilt (Powerboat) | 1 |
| 30 | 814407A2 | 倾斜开关 (动力艇) | TILT SWITCH (Powerboat) | 1 |
| 31 | 99629A3 | 倾斜杆总成 (动力艇) | LEVER ASSEMBLY Tilt (Powerboat) | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 15110A1 | 转速表 | TACHOMETER | 1 |
| 2 | 79101 | 安装支架 | BRACKET MOUNTING | 1 |
| 2 | 79101T | 支架 | BRACKET | 1 |
| 3 | 72729 | 楔形底座灯泡(14V - 1.9W) | LIGHT BULB Wedge Base (14V - 1.9W) | 1 |
| 4 | 79888 | 灯泡插座 | SOCKET Light Bulb | 1 |
| 5 | 26419 | 黄铜螺母 (#8-32) | NUT (#8-32) Brass | 5 |
| 6 | 86322A7 | 电缆总成(1.50英尺)黑色 微调表 | CABLE ASSEMBLY (1.50 Feet) Black TRIM GAUGE | 1 |
| 6 | 86323A5 | 电缆总成(1.50英尺)紫色 微调表 | CABLE ASSEMBLY (1.50 Feet) Purple TRIM GAUGE | 1 |
| 7 | 15113A4 | 配平表 | TRIM GAUGE | 1 |
| 7 | 895292Q41 | 动力升降倾斜指示器 黑面橙白刻度黑边框 | GAUGE Power Trim Indicator, Black Face, Orange/White Graduations, Black Bezel | 1 |
| 8 | 79480 | 安装支架-配平表 | BRACKET MOUNTING-TRIM GAUGE | 1 |
| 9 | 72729 | 灯泡 楔形底座(14V-1.9W)微调表 | LIGHT BULB Wedge Base (14V - 1.9W) TRIM GAUGE | 1 |
| 10 | 79888 | 灯泡插座 微调表 | SOCKET Light Bulb TRIM GAUGE | 1 |
| 11 | 26419 | 螺母(#8-32)黄铜 微调表端子 | NUT (#8-32) Brass TRIM GAUGE TERMINAL | 5 |
| 12 | 26427 | 调整垫片（仪表端子） | WASHER TRIM GAUGE TERMINAL | 2 |
| 13 | 86396A8 | 转速表线束总成(5.00英尺) | HARNESS ASSEMBLY Tachometer (5.00 Feet) | 1 |
| 14 | 15166A1 | 温度表 | TEMPERATURE GAUGE | 1 |
| 14 | 895287Q41 | 水温表套件(100-240℉)黑面橙白刻度黑框 | WATER TEMPERATURE GAUGE KIT (100-240 F) Black Face, Orange/White Graduations, Black Bezel | 1 |
| 15 | 72729 | 楔形底座灯泡(14V - 1.9W) | LIGHT BULB Wedge Base (14V - 1.9W) | 1 |
| 16 | 79888 | 灯泡插座 | SOCKET Light Bulb | 1 |
| 17 | 26427 | 垫圈 | WASHER | 2 |
| 18 | 79480 | 支架 | BRACKET | 1 |
| 19 | 26419 | 黄铜螺母 (#8-32) | NUT (#8-32) Brass | 5 |
| 20 | 86323A2 | 电缆总成(2英尺)紫色 | CABLE ASSEMBLY (2.00 Feet) Purple | 1 |
| 20 | 61600A16 | 电缆总成(17英寸)黑色 | CABLE ASSEMBLY (17.00 Inches) Black | 1 |
| 20 | 88824A4 | 电缆总成(45英寸)棕褐色 | CABLE ASSEMBLY (45.00 Inches) Tan | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 12430A1 | 传感器总成 | SENSOR ASSEMBLY | 1 |
| 2 | 48409 | 螺钉(#10-16 x .625)不锈钢传感器固定 | SCREW (#10-16 x .625) Stainless Steel SENSOR ATTACHING | 1 |
| 3 | 41470A11 | 报警模块总成 | WARNING MODULE ASSEMBLY | 1 |
| 3 | 41470A27 | 机油报警模块 | MODULE-OILWARNING | 1 |
| 4 | 38833 | 警告模块螺钉垫圈 | WASHER WARNING MODULE SCREW | 3 |
| 5 | 69020 | 螺钉(#10-32 x .875)警告模块至气缸体 | SCREW (#10-32 x .875) WARNING MODULE TO CYLINDER BLOCK | 3 |
| 5 | 690201 | 螺钉(#10-32 x .875) | SCREW (#10-32 x .875) | 3 |
| 6 | 41032 | 油泵总成 | PUMP ASSEMBLY Oil | 1 |
| 6 | 815698T | 油泵 | PUMP Oil | 1 |
| 7 | 32228 | 油泵至曲轴箱螺钉 (#10-32 x .625) | SCREW (#10-32 x .625) OIL PUMP TO CRANKCASE | 1 |
| 7 | 41507 | 油泵至曲轴箱螺钉 (#10-32 x 1.120) | SCREW (#10-32 x 1.120) OIL PUMP TO CRANKCASE | 1 |
| 8 | 962556 | 节气门连杆至油泵 | LINK THROTTLE LEVER TO OIL PUMP | 1 |
| 8 | 193856 | 连接杆 | LINK | 1 |
| 9 | 41429A1 | 驱动齿轮轴承总成 | BEARING ASSEMBLY DRIVE GEAR | 1 |
| 9 | 41429A2 | 轴承总成 | BEARING ASSEMBLY | 1 |
| 10 | 12726 | 从动齿轮 | GEAR Driven | 1 |
| 10 | 14563 | 从动齿轮 | GEAR Driven | 1 |
| 11 | 4301619 | 油泵至三通油管 | TUBING OIL PUMP TO TEE | 1 |
| 11 | 82381335 | 油管(15.00英寸 散装) | TUBING (15.00 Inches Bulk) | 1 |
| 12 | 11379 | 油泵O型圈 | O-RING OIL PUMP | 1 |
| 13 | 42813 | 警告模块导线螺钉 (#10-32 X .380) | SCREW (#10-32 X .380) WARNING MODULE LEAD | 1 |
| 14 | 87421 | 油箱 | TANK | 1 |
| 15 | 43298A2 | 油箱盖总成 | CAP ASSEMBLY OIL TANK | 1 |
| 16 | 11332 | O型圈(2.225 x .210)盖 | O-RING (2.225 x .210) CAP | 1 |
| 17 | 43295A5 | 壳体总成适配器 | HOUSING ASSEMBLY Adaptor | 1 |
| 17 | 816190A4 | 机油收集器总成(无传感器) | OIL PICK UP ASSEMBLY Without Sender | 1 |
| 18 | 11332 | O型圈(2.225 x .210)适配器壳体 | O-RING (2.225 x .210) ADAPTOR HOUSING | 1 |
| 19 | 99802 | 吸油管 | TUBE OIL PICK-UP | 1 |
| 20 | 12540A2 | 飞轮壳体总成 | HOUSING ASSEMBLY Flywheel | 1 |
| 20 | 816190A4 | 机油收集器总成(无传感器) | OIL PICK UP ASSEMBLY Without Sender | 1 |
| 21 | 99439 | 油管(114.00英寸) | HOSE (114.00 Inches) OIL | 1 |
| 22 | 12540A3 | 壳体 | HOUSING | 1 |
| 23 | 12242A1 | 闩锁 | LATCH | 1 |
| 24 | 99443 | 油箱 | RESERVOIR Oil | 1 |
| 24 | 994436 | 储液罐 | RESERVOIR | 1 |
| 25 | 69020 | 油箱固定螺钉 (#10-32 x .875) | SCREW (#10-32 x .875) OIL RESERVOIR ATTACHING | 3 |
| 25 | 690201 | 螺钉(#10-32 x .875) | SCREW (#10-32 x .875) | 3 |
| 26 | 42118 | 油箱螺钉垫圈 | WASHER OIL RESERVOIR SCREW | 6 |
| 27 | 42117 | 油箱螺钉衬套 | GROMMET OIL RESERVOIR SCREW | 3 |
| 28 | 42116 | 油箱螺钉轴套 | BUSHING OIL RESERVOIR SCREW | 3 |
| 29 | 4301736 | 油管 油箱至油泵 (截断至5.25英寸) | TUBING OIL RESERVOIR TO OIL PUMP (Cut to 5.25 Inches) | 1 |
| 29 | 82381455 | 油管（25.00英寸散装） | TUBING (25.00 Inches Bulk) | 1 |
| 30 | 43300A1 | 油箱盖总成 | CAP ASSEMBLY OIL RESERVOIR | 1 |
| 30 | 43300A9 | 盖总成 | CAP ASSEMBLY | 1 |
| 31 | 43307 | 油箱盖衬垫 | GASKET RESERVOIR CAP | 1 |
| 31 | 43307T | 衬垫 | GASKET | 1 |
| 32 | 99022A1 | 浮子总成 | FLOAT ASSEMBLY | 1 |
| 32 | 8M0187298 | 浮子总成 | FLOAT ASSY | 1 |
| 33 | 99265 | 压入式螺母 | PUSH NUT | 1 |
| 34 | 415821 | 油管卡箍(小) | CLAMP OIL HOSE (SMALL) | 2 |
| 35 | 415823 | 油管卡箍(大) | CLAMP OIL HOSE (LARGE) | 2 |
| 36 | 99127109 | 油管(57.00英寸散装) | LINE (57.00 Inches Bulk) OIL | 1 |
| 36 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 37 | 42425 | 油管三通 | TEE OIL TUBING | 1 |
| 38 | 9072925 | 油管 (截断至6.75英寸) | HOSE OIL (Cut to 6.75 Inches) | 1 |
| 39 | 34395A1 | 软管 | HOSE | 1 |
| 39 | 8M0108355 | 软管(57英寸 散装) | HOSE (57 Inches Bulk) | 1 |
| 40 | 43278 | 止回阀接头（曲轴箱） | FITTING CHECK VALVE (CRANKCASE) | 1 |
| 40 | 8781051 | 止回阀 | CHECK VALVE | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 99659A21 | 歧管总成 (黑色) | MANIFOLD ASSEMBLY (BLACK) | 1 |
| 1 | 99659A22 | 歧管总成 (灰色) | MANIFOLD ASSEMBLY (GRAY) | 1 |
| 2 | 99616 | 管塞歧管 | PIPE PLUG MANIFOLD | 11 |
| 2 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 11 |
| 3 | 41493A7 | 配平油缸总成 (黑色) | TRIM CYLINDER ASSEMBLY (BLACK) | 1 |
| 3 | 41493A4 | 配平油缸总成 (灰色) | TRIM CYLINDER ASSEMBLY (GRAY) | 1 |
| 3 | 41493A7 | 升降油缸总成 | TRIM CYLINDER ASSEMBLY | 1 |
| 4 | 41492A1 | 导向器总成 | GUIDE ASSEMBLY | 1 |
| 5 | 41478A1 | 维修套件 | REPAIR KIT | 1 |
| 6 | 41482A2 | 止回阀套件 | CHECK VALVE KIT | 1 |
| 7 | 99638A1 | 导向总成装饰杆 | GUIDE ASSEMBLY TRIM ROD | 2 |
| 7 | 8M0021648 | 端盖总成 | END CAP ASSEMBLY | 2 |
| 8 | 43397A6 | PISTON/ROD ASSEMBLY Power Trim PORT | 1 | |
| 8 | 878413A1 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 9 | 12184A1 | 升降过滤器总成 | TRIM FILTER ASSEMBLY | 1 |
| 10 | 43398A3 | PISTON/ROD ASSEMBLY Power Trim STARBOARD | 1 | |
| 10 | 878414T01 | 活塞总成 | PISTON ASSEMBLY | 1 |
| 11 | 13794 | 沟槽销-升降油缸(上) | PIN Groove TRIM CYLINDER (UPPER) | 1 |
| 11 | 821539 | 三叶销 | PIN Trilobe | 1 |
| 12 | 99660A1 | 阀门总成 | VALVE ASSEMBLY | 1 |
| 12A | 812844 | E型卡环 | E RING | 1 |
| 12A | 815949001 | E形环 | E-RING | 1 |
| 13 | 4000327 | 螺钉(M6x14)-盖板 | SCREW (M6 x 14) COVER | 4 |
| 14 | 43450 | 盖板螺丝垫圈 | WASHER COVER SCREW | 4 |
| 14 | 4002315 | 垫圈(6.60x12.5x1.5mm-不锈钢) | WASHER (6.60 X 12.5 X 1.5 mm -SS) | 4 |
| 15 | 99642 | 歧管盖 | COVER MANIFOLD | 1 |
| 16 | 48462A2 | O型圈套件 | O-RING KIT | 1 |
| 16 | 48462A4 | O型圈套件 | O RING KIT | 1 |
| 17 | 99609A1 | 塞子总成 | PLUG ASSEMBLY | 1 |
| 18 | 99641A1 | 轴总成 | SHAFT ASSEMBLY | 1 |
| 18 | 99641A02 | 轴总成 | SHAFT ASSY | 1 |
| 19 | 99616 | 轴管塞 | PIPE PLUG SHAFT | 2 |
| 19 | 56800 | 管塞 (.0625-27) | PLUG Pipe (.0625-27) | 2 |
| 20 | 4008820 | 螺钉(M6x20)-泵与马达 | SCREW (M6 x 20) PUMP AND MOTOR | 2 |
| 21 | 400256 | 锁紧垫圈 (M6) | LOCKWASHER (M6) | 2 |
| 22 | 99186T | 泵与电机总成 | PUMP AND MOTOR | 1 |
| 22 | 826729A10 | ORD 8M0143217 | ORD 8M0143217 | 1 |
| 23 | 99625 | SHAFT UPPER | 1 | |
| 23 | 99625002 | 轴 | SHAFT | 1 |
| 24 | 43396A1 | 阳极总成 | ANODE ASSEMBLY | 1 |
| 24 | 818298Q1 | 阳极套件 | ANODE KIT | 1 |
| 25 | 4000332 | 螺钉(M6x35)-阳极 | SCREW (M6 x 35) ANODE | 2 |
| 26 | 29245 | 垫圈(0.281x0.500x0.060)-不锈钢阳极螺钉 | WASHER (.281 x .500 x .060) Stainless Steel ANODE SCREW | 2 |
| 26 | 8M0204649 | 不锈钢垫圈(0.281x0.500x0.060) | WASHER (.281 x .500 x .060) Stainless Steel | 2 |
| 27 | 996301 | 撞板-升降轴 | STRIKER PLATE TRIM SHAFT | 2 |
| 27 | 8M0045383 | 冲击板 | STRIKER PLATE | 2 |
| 28 | 58643 | 锁紧垫圈 (.375) | LOCKWASHER (.375) | 2 |
| 29 | 46335 | 螺母 (.375-24) | NUT (.375-24) | 2 |
| 30 | 17201A2 | 电缆总成(17英寸)-动力升降 | CABLE ASSEMBLY (17.00 Inches) POWER TRIM | 1 |
| 31 | 79138A12 | 电缆总成 (13-1/4") (黑色) | CABLE ASSEMBLY (13-1/4") (BLACK) | 1 |
| 31 | 87379A25 | 线束总成(4.750英寸) | WIRE ASSEMBLY (4.750 Inches) | 1 |
| 31 | 88807A8 | 黑色电缆总成 (3.50 英寸) | CABLE ASSEMBLY (3.50 Inches) Black | 2 |
| 32 | 96158 | 启动电磁阀 | SOLENOID Starter | 2 |
| 32 | 8M0185622 | 电磁阀 | SOLENOID | 2 |
| 33 | 28635 | 螺钉 (.250-20 x .620) 不锈钢 电磁阀 | SCREW (.250-20 x .620) Stainless Steel SOLENOID | 4 |
| 34 | 26419 | 螺母(#8-32)-黄铜电磁阀端子 | NUT (#8-32) Brass SOLENOID TERMINAL | 4 |
| 35 | 26992 | 锁紧垫圈 (.250) 不锈钢电磁阀端子 | LOCKWASHER (.250) Stainless Steel SOLENOID TERMINAL | 4 |
| 36 | 94330 | 螺母 (.250-20) 黄铜电磁阀端子 | NUT (.250-20) Brass SOLENOID TERMINAL | 4 |
| 37 | 97861 | 电磁阀绝缘体 | INSULATOR SOLENOID | 2 |
| 38 | 22875 | CLIP PUMP WIRE | 2 | |
| 39 | 69205 | C形垫圈线夹螺钉 | C WASHER CLIP SCREW | 2 |
| 39 | 8M0084613 | C形垫圈 | C-WASHER | 2 |
| 40 | 69079 | 螺钉(#10-16x0.440)-夹子到艉板支架 | SCREW (#10-16 x .440) CLIP TO TRANSOM BRACKET | 2 |
| 41 | 44431 | 沟槽销-升降油缸(下) | PIN Groove TRIM CYLINDER (LOWER) | 1 |
| 41 | 878267 | 销 | PIN | 1 |
| 42 | 4000377 | SCREW (M10 x 30) MANIFOLD | 6 | |
| 43 | 400258 | 锁紧垫圈(M10)-不锈钢歧管螺钉 | LOCKWASHER (M10) Stainless Steel MANIFOLD SCREW | 6 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 99186T | 泵与电机总成 | PUMP AND MOTOR | 1 |
| 1 | 12659 | 机架与磁场套件 | FRAME AND FIELD KIT | 1 |
| 1 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 2 | 12665 | 电刷弹簧套件 | SPRING KIT Brush | 1 |
| 3 | 13506 | 电刷卡套件 | BRUSH CARD KIT | 1 |
| 3 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 4 | 12662 | 泵与端架套件 | PUMP AND END FRAME KIT | 1 |
| 4 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 5 | 12663 | 泵密封套件 | SEAL KIT Pump | 1 |
| 5 | 126631 | 泵密封套件 | SEAL KIT Pump | 1 |
| 6 | 12660 | 端架套件 | END FRAME KIT | 1 |
| 6 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 7 | 12661 | 电枢套件 | ARMATURE KIT | 1 |
| 7 | 991861 | 动力升降泵总成 | PUMP ASSEMBLY Power Trim | 1 |
| 8 | 12664 | 贯穿螺栓套件 | THRU BOLT KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 15221A1 | 气缸盖总成 | CYLINDER HEAD ASSEMBLY | 2 |
| 2 | 41246 | 气缸盖衬垫 | GASKET CYLINDER COVER | 2 |
| 2 | 41247T01 | 衬垫 | GASKET | 2 |
| 3 | 98534 | 气缸盖螺钉 (.375-16 x 2.30) | SCREW (.375-16 x 2.30) CYLINDER HEAD | 24 |
| 4 | 25909 | 气缸盖螺钉垫圈 (.406 x .812 x .065) | WASHER (.406 x .812 x .065) CYLINDER HEAD SCREW | 24 |
| 5 | 62386 | 节温器衬垫 | GASKET THERMOSTAT | 2 |
| 5 | 8M0204714 | 衬垫@4 | GASKET @4 | 2 |
| 6 | 90390A1 | 节温器盖套件 | COVER KIT THERMOSTAT | 2 |
| 7 | 35386 | 节温器盖螺钉 (.312-18 x 1.00) | SCREW (.312-18 x 1.00) THERMOSTAT COVER | 4 |
| 8 | 68727 | 90度黄铜弯头接头 (.250-18)（水管用） | FITTING (.250-18) 90 Degree - Brass ELBOW - WATER HOSES | 1 |
| 8 | 687271 | 90度弯头 (.250-18) - 黄铜 | FITTING (.250-18) 90 Degree - Brass | 1 |
| 9 | 7765377 | 配水软管（散装24.500英寸） | HOSE (24.500 Inches Bulk) WATER DISTRIBUTION | 2 |
| 9 | 77653101 | 软管（散装48.00英寸） | HOSE (48.00 Inches Bulk) | 2 |
| 10 | 68728 | 节温器盖至水管接头 | FITTING THERMOSTAT COVER TO WATER HOSES | 1 |
| 11 | 73498 | 水管卡箍 | CLAMP WATER HOSES | AR |
| 11 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 12 | 97465 | 温度传感器（右舷） | SENDER Temperature (STARBOARD) | 1 |
| 13 | 75692 | 节温器 | THERMOSTAT | 2 |
| 14 | 13536A7 | 温度传感器总成（左舷） | SENSOR ASSEMBLY Temperature (PORT) | 1 |
| 15 | 13715 | 传感器固定座 | RETAINER SENSOR AND SENDER | 2 |
| 15 | 137151 | 固定座 | RETAINER | 2 |
| 16 | 98257 | 螺钉 (0.312-18 x 0.500) 固定座 | SCREW (.312-18 x .500) RETAINER | 2 |
| 17 | 99747A9 | 簧片阀壳体 | HOUSING REED BLOCK | 1 |
| 18 | 24878 | 簧片阀壳体螺钉 (.250-20 x 1.25) | SCREW (.250-20 x 1.25) REED BLOCK HOUSING | 1 |
| 18 | 69093 | 簧片阀壳体螺钉 (.250-20 x 1.50) | SCREW (.250-20 x 1.50) REED BLOCK HOUSING | 8 |
| 18 | 69067 | 簧片阀壳体螺钉 (.250-20 x 1.375) | SCREW (.250-20 x 1.375) REED BLOCK HOUSING | 1 |
| 19 | 93536 | 簧片阀壳体衬垫 | GASKET REED BLOCK HOUSING | 1 |
| 19 | 935361 | 衬垫 | GASKET | 1 |
| 20 | 65744 | 簧片阀衬垫 | GASKET REED BLOCK | 6 |
| 20 | 657443 | 衬垫 | GASKET | 6 |
| 21 | 75953 | 簧片阀组 | REED BLOCK | 6 |
| 22 | 75362A1 | 簧片组件 | REED ASSEMBLY | 6 |
| 23 | 96183 | 簧片夹 | CLAMP Reed | 12 |
| 23 | 961832 | 簧片夹 | CLAMP Reed | 12 |
| 24 | 57583 | 簧片至簧片阀螺钉 (#8-32 x .375) | SCREW (#8-32 x .375) REEDS TO REED BLOCK | 60 |
| 24 | 57583T | 螺丝#8-32×3/8 | SCREW #8-32x3/8 | 60 |
| 25 | 65746 | 簧片阀固定螺钉 (.250-20 x .750) | SCREW (.250-20 x .750) REED BLOCK ATTACHING | 12 |
| 26 | 27037 | 化油器安装螺柱 (.250-28 x 1.125) | STUD (.250-28 x 1.125) CARBURETOR MOUNTING | 12 |
| 26 | 270372 | 双头螺栓(.250-28×1.125) | STUD (.250-28 x 1.125) | 12 |
| 27 | 42658 | 簧片阀壳体泄油软管止回阀 | CHECK VALVE BLEED HOSE TO REED BLOCK HOUSING | 5 |
| 27 | 426585 | 止回阀 | CHECK VALVE | 5 |
| 28 | 15133 | 接头 泄放软管至气缸体 (90度) | FITTING BLEED HOSE TO CYLINDER BLOCK (90 Degree) | 5 |
| 29 | 99130122 | 泄油管路（散装20.00英尺） | TUBING (20.00 Feet Bulk) BLEED LINE | 1 |
| 29 | 892024122 | 管(240.00英寸散装) | TUBING (240.00 Inches Bulk) | 1 |
| 30 | 42657A1 | 止回阀 | CHECK VALVE | 1 |
| 30 | 42657A3 | 止回阀 | CHECK VALVE | 1 |
| 31 | 65857 | 泄油软管连接器（压入式） | CONNECTOR BLEED HOSE (PRESS-IN) | 1 |
| 31 | 56759 | 倒钩接头 | FITTING Barbed | 1 |
| 32 | 64871A2 | 止回阀 | CHECK VALVE | 1 |
| 33 | 23567 | 卡箍(9/16英寸) | CLIP (9/16") | 1 |
| 33 | 26404 | 管夹(1英寸) | CLAMP (1") | 1 |
| 34 | 69079 | 螺钉 (#10-16 x .440) 夹子 | SCREW (#10-16 x .440) CLIP | 2 |
| 35 | 69205 | C形垫圈 | C WASHER | 2 |
| 35 | 8M0084613 | C形垫圈 | C-WASHER | 2 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 814840 | 零件手册 Mariner 40 | PARTS MANUAL Mariner 40 | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| - | 79472 | 启动电机总成 | STARTER MOTOR ASSEMBLY | 1 |
| 1 | 90645 | 驱动套件 | DRIVE KIT | 1 |
| 2 | 75661 | 驱动小齿轮总成 | PINION ASSEMBLY Drive | 1 |
| 2 | 13310T1 | 小齿轮总成 | PINION ASSEMBLY | 1 |
| 3 | 75660 | 驱动端板 | PLATE DRIVE END | 1 |
| 4 | 74968 | 贯穿螺栓 | BOLT THRU | 2 |
| 6 | N.S.S. | 不单独出售垫圈(美国博世WA3122) | Not Sold Separate Washer (AMERICAN BOSCH #WA3122) | 1 |
| 7 | 79216 | 电枢 | ARMATURE | 1 |
| 8 | 75384 | 电刷/弹簧套件 | BRUSH/SPRING KIT | 1 |
| 8 | 898265016 | 电刷/弹簧套件 | BRUSH/SPRING KIT | 1 |
| 9 | 61787 | 电刷架 | HOLDER BRUSH | 2 |
| 9 | 898265014 | 电刷支架 | HOLDER-BRUSH | 2 |
| 10 | 68586 | 电刷及支架螺钉 | SCREW BRUSH AND HOLDER | 2 |
| 11 | 15386 | 换向器端盖 | END CAP COMMUTATOR | 1 |
| 11 | 15386001 | 端盖 | END CAP | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8710A4 | 旋转支架总成（黑色） | SWIVEL BRACKET ASSEMBLY (BLACK) | 1 |
| 1 | 8710A13 | 旋转支架总成（灰色） | SWIVEL BRACKET ASSEMBLY (GRAY) | 1 |
| 1 | 8710T21 | 灰色旋转支架总成 | SWIVEL BRACKET ASSEMBLY Gray | 1 |
| 2 | 87735 | SEAL Oil SWIVEL BRACKET (LOWER) | 1 | |
| 3 | 67669 | BUSHING SWIVEL BRACKET (LOWER AND UPPER) | 2 | |
| 3 | 818764 | 衬套 | BUSHING | 2 |
| 4 | 33466 | 旋转支架O型圈(上部) | O-RING SWIVEL BRACKET (UPPER) | 1 |
| 5 | 67668 | 旋转支架垫片(上部) | SPACER SWIVEL BRACKET (UPPER) | 1 |
| 6 | 74036 | 润滑脂接头 | FITTING Grease | 2 |
| 6 | 8M0169589 | 润滑脂接头 | FITTING Grease | 2 |
| 7 | 99608 | 衬套 | BUSHING | 2 |
| 7 | 821207 | 衬套 | BUSHING | 2 |
| 8 | 67706A18 | 转向臂旋转销总成（黑色） | SWIVEL PIN ASSEMBLY Steering Arm (BLACK) | 1 |
| 8 | 67706A55 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 8 | 67706A17 | 转向臂旋转销总成（灰色） | SWIVEL PIN ASSEMBLY Steering Arm (GRAY) | 1 |
| 8 | 67706A55 | 转向臂转销总成 | SWIVEL PIN ASSEMBLY Steering Arm | 1 |
| 9 | 78689 | 螺钉(0.437-20×7.50)转向臂至上支架 | SCREW (.437-20 x 7.50) STEERING ARM TO UPPER MOUNT | 2 |
| 9 | 8M0176309 | 螺钉 | SCREW | 2 |
| 10 | 77326 | 橡胶安装座-上部 | MOUNT RUBBER - UPPER | 2 |
| 11 | 66921 | 上支座螺栓垫圈 | WASHER UPPER MOUNT BOLT | 2 |
| 12 | 78688 | 上支座螺栓垫圈 | WASHER UPPER MOUNT BOLT | 2 |
| 13 | 34933 | 螺母（0.437-20）不锈钢上部安装螺栓 | NUT (.437-20) Stainless Steel UPPER MOUNT BOLT | 2 |
| 13 | 8M0204653 | 螺母 | NUT | 2 |
| 14 | 92876A1 | 转向连杆总成 | LINK ASSEMBLY Steering | 1 |
| 14 | 92876A12 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 15 | 14000 | SCREW (.375-24 x 1.25) STEERING LINK TO STEERING ARM | 1 | |
| 15 | 849838 | 螺钉(.375-24 x 1.250) | SCREW (.375-24 x 1.250) | 1 |
| 16 | 34863 | NUT (.375-24) STEERING LINK SCREW | 2 | |
| 16 | 8M0204726 | 黄铜螺母 (.375-24) | NUT (.375-24) Brass | 2 |
| 17 | 34931 | WASHER (.406 x .734 x .063) Stainless Steel STEERING LINK TO STEERING ARM | 2 | |
| 18 | 78854 | WAVE WASHER BOTTOM YOKE | 1 | |
| 19 | 86580A1 | 底部轭架总成（黑色） | YOKE ASSEMBLY Bottom (BLACK) | 1 |
| 19 | 878182T | 轭架底部-不锈钢 | YOKE Bottom - Stainless Steel | 1 |
| 19 | 86580A2 | 底部轭架总成（灰色） | YOKE ASSEMBLY Bottom (GRAY) | 1 |
| 19 | 86580A1 | 底部轭架总成 | YOKE ASSEMBLY Bottom | 1 |
| 20 | 67684 | 卡环-底部轭架 | RING Retaining BOTTOM YOKE | 1 |
| 21 | 67670 | WASHER THRUST - SWIVEL BRACKET | 1 | |
| 22 | 88882 | 上轭缓冲垫 | BUMPER Top Yoke | 1 |
| 23 | 95164A9 | 调整传感器总成 | SENDER ASSEMBLY Trim | 1 |
| 23 | 8M0074846 | ORDER 8M0098273 | ORDER 8M0098273 | 1 |
| 24 | 56682 | 螺丝(#10-24x.750)配平传感器 | SCREW (#10-24 x .750) TRIM SENDER | 2 |
| 24 | 852368 | 螺钉（#10-24 X 0.750） | SCREW (#10-24 x .750) | 2 |
| 25 | 26996 | 配平传感器螺钉不锈钢锁紧垫圈(#10) | LOCKWASHER (#10) Stainless Steel TRIM SENDER SCREW | 2 |
| 26 | 89302 | WASHER (.203 x .406 x .040) TRIM SENDER SCREW | 2 | |
| 27 | 64014 | SCREW (.250-28 x .500) SWIVEL BRACKET | 2 | |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 74897 | PIVOT TRIGGER PLATE | 1 | |
| 2 | 62459 | 球头总成触发板 | BALL JOINT ASSEMBLY TRIGGER PLATE | 1 |
| 2 | 62459T | 球头节总成 | BALL JOINT ASSY | 1 |
| 3 | 45076 | 螺母(#10-32)黄铜连杆 | NUT (#10-32) Brass LINK ROD | 1 |
| 4 | 76035 | 触发板连杆 | ROD TRIGGER PLATE | 1 |
| 5 | 46438 | 螺母(#10-32)球头 | NUT (#10-32) BALL JOINT | 1 |
| 6 | 41094A3 | 点火提前杆总成 | LEVER ASSEMBLY SPARK ADVANCE | 1 |
| 7 | 64022 | 螺丝(.250-20x2.125)点火提前杆-止动 | SCREW (.250-20 x 2.125) SPARK ADVANCE LEVER - STOP | 1 |
| 8 | 64015 | 螺母(.250-20)点火提前止动螺丝 | NUT (.250-20) SPARK ADVANCE STOP SCREW | 1 |
| 9 | 26852 | 尼龙帽（火花提前杆止动螺钉） | CAP Nylon SPARK AADVANCE LEVER STOP SCREW | 1 |
| 10 | 69560 | 螺钉（0.190-32 x 1.250）点火提前杠杆-止动 | SCREW (.190-32 x 1.250) SPARK ADVANCE LEVER - STOP | 1 |
| 11 | 68219 | 螺母(#10-32)不锈钢点火提前杆止动螺丝 | NUT (#10-32) Stainless Steel SPARK ADVANCE LEVER STOP SCREW | 1 |
| 12 | 48039 | 点火提前杆止动螺丝帽 | CAP SPARK ADVANCE LEVER STOP SCREW | 1 |
| 13 | 41095T | 油门控制杆 | LEVER THROTTLE CONTROL | 1 |
| 13 | 410952 | 杠杆 | LEVER | 1 |
| 14 | 55337 | 螺钉（0.375-16 x 1.75）（油门杆/提前杆） | SCREW (.375-16 x 1.75) THROTTLE LEVER/ADVANCE LEVER | 1 |
| 14 | 818165 | 螺钉 (.375-16 x 1.75) | SCREW (.375-16 x 1.75) | 1 |
| 15 | 55164 | 油门杠杆衬套 | BUSHING THROTTLE LEVER | 1 |
| 16 | 55171 | 点火提前杆衬套 | BUSHING SPARK ADVANCE LEVER | 1 |
| 17 | 68784 | 节气门与点火提前杆弹簧 | SPRING THROTTLE AND SPARK ADVANCE LEVER | 1 |
| 18 | 68410 | 点火提前杆垫片 | WASHER SPARK ADVANCE LEVER | 1 |
| 18 | 46765 | 垫圈 (.390 x 1.50 x .120) | WASHER (.390 x 1.50 x .120) | 1 |
| 19 | 64022 | 螺丝(.250-20x2.125)节气门杆-止动 | SCREW (.250-20 x 2.125) THROTTLE LEVER - STOP | 1 |
| 20 | 64015 | 螺母（0.250-20）（油门杆止动螺钉） | NUT (.250-20) THROTTLE LEVER STOP SCERW | 1 |
| 21 | 26852 | 尼龙帽节气门杆止动螺丝 | CAP Nylon THROTTLE LEVER STOP SCREW | 1 |
| 22 | 39483 | 锁扣拉线 | LATCH CABLE | 1 |
| 23 | 22486 | 螺丝(.250-28x.880)拉线锁扣至节气门杆 | SCREW (.250-28 x .880) CABLE LATCH TO THROTTLE LEVER | 1 |
| 23 | 69026 | 螺钉 (.250-28 x .880) | SCREW (.250-28 x .880) | 1 |
| 24 | 20099 | 拉线锁扣至节气门杆弹簧 | SPRING CABLE LATCH TO THROTTLE LEVER | 1 |
| 25 | 20586 | 螺母(.250-28)拉线锁扣螺丝 | NUT (.250-28) CABLE LATCH SCREW | 1 |
| 25 | 826709109 | 不锈钢螺母(.250-28) | NUT (.250-28) Stainless Steel | 1 |
| 26 | 79949 | 节气门控制杆 | ROD THROTTLE CONTROL | 1 |
| 27 | 60572 | 节气门控制杆套筒 | BARREL THROTTLE CONTROL ROD | 2 |
| 27 | 8M0221994 | 筒形接头 | BARREL FITTING | 2 |
| 28 | 178861 | 节气门凸轮 | CAM Throttle | 1 |
| 29 | 20353 | 螺柱(.250-28x1.750)节气门凸轮固定 | STUD (.250-28 x 1.750) THROTTLE CAM ATTACHING | 1 |
| 30 | 26856 | 节气门凸轮衬套 | BUSHING THROTTLE CAM | 2 |
| 31 | 36069 | 节气门凸轮螺柱螺母 | NUT THROTTLE CAM STUD | 1 |
| 32 | 41050 | 节气门复位弹簧 | SPRING THROTTLE RETURN | 1 |
| 33 | 92032A2 | 控制线缆锚定支架 | BRACKET ANCHOR - CONTROL CABLES | 1 |
| 33 | 814283A2 | 支架总成 | BRACKET ASSEMBLY | 1 |
| 34 | 98889 | 控制线缆锁扣 | LATCH CONTROL CABLE | 1 |
| 35 | 42975 | 闩锁传动螺钉 | DRIVE SCREW LATCH | 2 |
| 36 | 53167 | 螺丝(.312-18x.880)锚定支架固定 | SCREW (.312-18 x .880) ANCHOR BRACKET ATTACHING | 3 |
| 36 | 53167T | 螺钉 0.312-18X 0.88 | SCREW .312-18X .88 | 3 |
| 37 | 37896 | 连杆导向块 | GUIDE BLOCK LINK ROD | 1 |
| 38 | 20099 | 连杆至导向块弹簧 | SPRING LINK ROD TO GUIDE BLOCK | 1 |
| 39 | 67073A1 | 连杆总成 | LINK ROD ASSEMBLY | 1 |
| 40 | 52100 | 连杆耐磨板 | WEAR PLATE LINK ROD | 1 |
| 41 | 38279 | 控制线缆闩锁紧固件 | LATCH CONTROL CABLE FASTENING | 1 |
| 41 | 8M0036768 | 闩锁 | LATCH | 1 |
| 42 | 35462 | 垫圈(.2656x.625x.0625)不锈钢锁扣 | WASHER (.2656 x .625 x .0625) Stainless Steel LATCH | 1 |
| 43 | 36069 | 连杆螺母 | NUT LINK ROD | 1 |
| 44 | 79932A7 | 换挡轴总成 | SHIFT SHAFT ASSEMBLY | 1 |
| 44 | 79932A16 | 换挡轴总成 | SHIFT SHAFT ASSEMBLY | 1 |
| 45 | 29720 | 连杆波形垫圈 | WAVE WASHER LINK ROD | 1 |
| 46 | 26600 | 尼龙衬套-连杆 | BUSHING NYLON - LINK ROD | 1 |
| 47 | 35462 | 垫圈(.2656 x .625 x .0625)不锈钢连杆 | WASHER (.2656 x .625 x .0625) Stainless Steel LINK ROD | 1 |
| 48 | 36069 | 连杆至换挡轴螺母 | NUT LINK ROD TO SHIFT SHAFT | 1 |
| 49 | 39519 | 杯形套筒固定器-锚杆 | CUP BARREL RETAINER - ANCHOR BAR | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 9742A19 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 9742T90 | 顶盖总成-黑色 | TOP COWL ASY-BLK | 1 |
| 1 | 9742A20 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 1 | 9742A91 | 顶盖总成 | TOP COWL ASSEMBLY | 1 |
| 2 | 812784 | 密封件 | SEAL | 1 |
| 3 | 813566 | 密封件 | SEAL | 1 |
| 3 | 815478 | 密封件 | SEAL | 1 |
| 4 | 813670 | 隔音垫(侧) | SOUND BLANKET (SIDE) | 2 |
| 4 | 814823 | 隔音毯 | SOUND BLANKET | 2 |
| 5 | 813671 | 隔音垫(顶) | SOUND BLANKET (TOP) | 1 |
| 5 | 814837 | 隔音毯 | SOUND BLANKET | 1 |
| 6 | 17196A1 | 进气口护罩 | SHIELD AIR INLET | 2 |
| 7 | 11316 | 快速螺母 | SPEED NUT | 12 |
| 8 | 17238 | 进气口密封件 | SEAL AIR INLET | 4 |
| 9 | 17194 | 进气口护罩 (左舷) | SHIELD AIR INLET (PORT) | 1 |
| 9 | 17195 | 进气口护罩 (右舷) | SHIELD AIR INLET (STARBOARD) | 1 |
| 10 | 184741 | 后支架 | BRACKET REAR | 2 |
| 11 | 18506 | 护孔环 | GROMMET | 3 |
| 11 | 18506001 | 护孔环 | GROMMET | 3 |
| 12 | 28636 | 螺钉(.250-20 x .750) 后支架 | SCREW (.250-20 x .750) REAR BRACKET | 8 |
| 13 | 26992 | 锁紧垫圈(.250)不锈钢 后支架螺钉 | LOCKWASHER (.250) Stainless Steel REAR BRACKET SCREW | 8 |
| 14 | 813096 | 挂钩 | HOOK | 2 |
| 14 | 813096A2 | 挂钩套件 | HOOK KIT | 2 |
| 15 | 73286 | 螺钉(0.250-20×0.500)不锈钢 | SCREW (.250-20 x .500) Stainless Steel | 8 |
| 16 | 813074 | 滚轮 | ROLLER | 2 |
| 16 | 8M0207770 | 滚轮@3 | ROLLER @3 | 2 |
| 17 | 13194 | 挡圈 | RING Retaining | 2 |
| 18 | 813553 | 安装板 | PLATE | 1 |
| 18 | 56720 | 垫圈(0.330×0.750×0.060)不锈钢 | WASHER (.330 x .750 x .060) Stainless Steel | 1 |
| 19 | 187021 | 定位器 | LOCATOR | 1 |
| 20 | 18173 | 锁扣滚轮支架总成 | BRACKET ASSEMBLY Latch Roller | 1 |
| 20 | 893763 | 滚轮锁扣支架 | BRACKET Roller Latch | 1 |
| 21 | 813552 | 隔套 | SPACER | 1 |
| 21 | 813076A2 | 手柄套件 | HANDLE KIT | 1 |
| 22 | 31984 | 螺钉(0.312-18×1.375) | SCREW (.312-18 x 1.375) | 2 |
| 23 | 67980 | 螺母(.312-18) | NUT (.312-18) | 2 |
| 23 | 82670910 | 不锈钢螺母(.312-18) | NUT (.312-18) Stainless Steel | 2 |
| 24 | 47341A1 | 手动/应急启动绳和手柄套件 (用于手动启动) | ROPE AND HANDLE KIT Manual/Emergency Start (FOR MANUAL STARTING) | 1 |
| 24 | 47341A11 | 手动启动绳柄套件 | ROPE AND HANDLE KIT Manual Starting | 1 |
| 25 | 18755A1 | 前护罩总成 | FRONT SHIELD ASSEMBLY | 1 |
| 25 | 18755A2 | 前护罩总成 | FRONT SHIELD ASSEMBLY | 1 |
| 26 | 813562 | 密封件 | SEAL | 1 |
| 27 | 48409 | 螺钉 (#10-16 x .625) 不锈钢 | SCREW (#10-16 x .625) Stainless Steel | 4 |
| 28 | 42118 | 垫圈 | WASHER | 4 |
| 29 | 70132 | 垫圈(0.323×0.563×0.063)不锈钢 | WASHER (.323 x .563 x .063) Stainless Steel | 2 |
| 29 | 8M0042642 | 垫圈(.323 x .562 x .063) | WASHER (.323 x .562 x .063) | 2 |
| - | 813096A1 | 后锁扣套件 | REAR LATCH KIT | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 8718A1 | 艉板支架总成(右舷)(黑色) | BRACKET ASSEMBLY Transom (STARBOARD) (BLACK) | 1 |
| 1 | 8718A2 | 艉板支架总成（右舷）（灰色） | BRACKET ASSEMBLY Transom (STARBOARD)(GRAY) | 1 |
| 1 | 8718F8 | 艉板支架 | BRACKET Transom | 1 |
| 2 | 8716A1 | 艉板支架总成(左舷)(黑色) | BRACKET ASSEMBLY Transom (PORT) (BLACK) | 1 |
| 2 | 8716A8 | 艉板支架总成 | BRACKET ASSEMBLY Transom | 1 |
| 2 | 8716A2 | 艉板支架总成(左舷)(灰色) | BRACKET ASSEMBLY Transom (PORT) (GRAY) | 1 |
| 2 | 8716A9 | 艉板支架总成 | BRACKET ASSEMBLY Transom | 1 |
| 3 | 98727 | 润滑配件左舷艉板支架 | FITTING Grease PORT TRANSOM BRACKET | 1 |
| 3 | 8M0169588 | 润滑脂接头 | FITTING Grease | 1 |
| 5 | 99170A1 | 倾斜管 | TILT TUBE | 1 |
| 5 | 99170A2 | 倾斜管套件 | TUBE KIT Tilt | 1 |
| 6 | 90068T | 倾斜管螺母(1"-14)(黑色) | NUT TILT TUBE (1"-14) (BLACK) | 1 |
| 6 | 859133 | 螺母(1.00-14) | NUT (1.00-14) | 1 |
| 6 | 90068T6 | 倾斜管螺母(1"-14)(灰色) | NUT TILT TUBE (1"-14) (GRAY) | 1 |
| 6 | 859133 | 螺母(1.00-14) | NUT (1.00-14) | 1 |
| 7 | 45711 | O-RING (.612 x .103) TILT TUBE | 1 | |
| 8 | 88750 | 波形垫圈(1.62 x 1.05)倾斜管 | WASHER Wave (1.62 x 1.05) TILT TUBE | 2 |
| 9 | 56041 | 螺母(.875-14)倾斜管 | NUT (.875-14) TILT TUBE | 1 |
| 9 | 858869 | 螺母 (.875-14) | NUT (.875-14) | 1 |
| 10 | 677551 | 螺钉(.500-20 x 4.500)艉板支架至艉板 | SCREW (.500-20 x 4.500) TRANSOM BRACKET TO TRANSOM | 4 |
| 10 | 8M0149747 | 螺钉 | SCREW | 4 |
| 11 | 28421 | 垫圈(1.5 x 3.05 x 0.13)不锈钢艉板支架螺栓 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel TRANSOM BRACKET BOLT | 4 |
| 11 | 8M0204648 | 垫圈(1.5x3.05x0.13)不锈钢 | WASHER (1.5 x 3.05 x 0.13) Stainless Steel | 4 |
| 12 | 8M0027784 | 艉板支架螺栓螺母 | NUT TRANSOM BRACKET BOLT | 4 |
| 12 | 82671117 | 螺母(.500-20) | NUT (.500-20) | 4 |
| 13 | 99629A2 | 倾斜锁杆总成 | LEVER ASSEMBLY TILT LOCK | 1 |
| 13 | 8M0115104 | 倾斜锁定杆总成 | LEVER ASSEMBLY Tilt Lock | 1 |
| 14 | 99611 | 波形垫圈（倾斜杆） | WAVE WASHER TILTLEVER | 1 |
| 15 | 65830 | 倾斜杆尼龙衬套 | NYLINER TILT LEVER | 2 |
| 16 | 99633 | 倾斜锁杆旋钮(黑色) | KNOB TILT LOCK LEVER (BLACK) | 1 |
| 16 | 99633T6 | 倾斜锁杆旋钮(灰色) | KNOB TILT LOCK LEVER (GRAY) | 1 |
| 16 | 99633 | 旋钮 | KNOB | 1 |
| 17 | 99615 | 槽销 | PIN Groove | 1 |
| 18 | 99622 | 弹簧 | SPRING | 1 |
| 19 | 99604 | 槽销 | PIN Groove | 1 |
| 20 | 96930A1 | 倾斜锁螺栓总成 | BOLT ASSEMBLY TILT LOCK | 1 |
| 21 | 23161 | 螺栓螺母（3/8英寸-24牙） | NUT (.375-24) BOLT | 1 |
| - | 11338A88 | 发动机大修垫片套装 | GASKET SET Engine Overhaul | 1 |
| REF | 零件编号 | 中文名称 | 英文名称 | 数量 |
|---|---|---|---|---|
| 1 | 43429 | PLATE Ignition | 1 | |
| 2 | 7778A9 | 开关盒总成 | SWITCHBOX ASSEMBLY | 2 |
| 2 | 7778A12 | 开关盒总成 | SWITCHBOX ASSEMBLY | 2 |
| 3 | 13669 | SCREW (#12-24 x 2.00) Switch Box to Ignition Plate | 2 | |
| 4 | 94453 | BUSHING Switch Box Screw | 2 | |
| 5 | 62310A2 | CABLE ASSEMBLY Switch Box to Switch Box | 1 | |
| 6 | 45076 | NUT (#10-32) Brass Switch Box Terminal | 20 | |
| 7 | 60871A10 | WIRE ASSEMBLY Switch Box | 2 | |
| 8 | 62568 | SCREW (#10-16 x .375) Wire Attaching | 3 | |
| 9 | 65999A3 | 线缆总成(黑色) | CABLE ASSEMBLY Black | 1 |
| 10 | 69092 | SCREW (1.25) Ignition Plate | 3 | |
| 10 | 60411 | 螺钉(.312-18 x 1.250) | SCREW (.312-18 x 1.250) | 3 |
| 11 | 26993 | LOCKWASHER (.312) Ignition Plate Screw | 3 | |
| 11 | 8M0204647 | 锁紧垫圈 (.312) | LOCKWASHER (.312) | 3 |
| 12 | 36042 | WASHER Ignition Plate Screw | 6 | |
| 13 | 67264 | WASHER (Rubber) Ignition Plate Screw | 6 | |
| 14 | 67268 | BUSHING Ignition Plate Screw | 3 | |
| 15 | 33386A3 | 开关总成 | SWITCH ASSEMLBY | 1 |
| 16 | 38055 | 螺钉 (.190-32 x .620) 开关至点火板 | SCREW (.190-32 x .620) Switch to Ignition Plate | 1 |
| 17 | 45076 | 螺母 (#10-32) 黄铜开关端子 | NUT (#10-32) Brass Switch Terminal | 1 |
| 18 | 87926 | SCREW (#10-32 x .500) Lead Attaching | 1 | |
| 19 | 88439A3 | 正极电缆总成-蓄电池 | CABLE ASSEMBLY Positive - Battery | 1 |
| 19 | 88439A2 | CABLE ASSEMBLY Battery - Negative Negative | 1 | |
| 20 | 96220A12 | 发动机线束总成 | HARNESS ASSEMBLY Engine | 1 |
| 21 | 79091 | 保险丝20安培 | FUSE 20 Ampere | 1 |
| 21 | 8M0207796 | 保险丝20安培 | FUSE 20 AMP | 1 |
| 22 | 95084A2 | 保险丝线束总成 | CABLE ASSEMBLY Fuse | 1 |
| 23 | 134731 | 保险丝座 | HOLDER Fuse | 1 |
| 24 | 90077 | TIE STRAP Harness and Cables | AR | |
| 24 | 816311T | 捆扎带 (8.00英寸) | TIE STRAP (8.00 Inches) | AR |
| 25 | 15857 | 启动电磁阀 | SOLENOID Starter | 1 |
| 25 | 853654A1 | 电磁阀 | SOLENOID | 1 |
| 26 | 45076 | NUT (#10-32) Brass Solenoid Terminals | 2 | |
| 27 | 53166 | LOCKWASHER (.312) Solenoid Terminals | 2 | |
| 28 | 68292 | NUT (.312-18) Solenoid Terminals | 2 | |
| 28 | 8M0204668 | 螺母(.312-18) | NUT (.312-18) | 2 |
| 29 | 31716 | SCREW (.250-20 x .620) Solenoid to Ignition Plate | 2 | |
| 30 | 26992 | LOCKWASHER (.250) Stainless Steel Solenoid to Ignition Plate Screw | 2 | |
| 31 | 65999A2 | CABLE ASSEMBLY Black Upper Mount | 1 | |
| 32 | 78866 | INSULATOR Solenoid | 1 | |
| 33 | 47483 | J型卡扣 | J CLIP | 2 |
